Soil Engineering Division of Geological Units Based on the Combination of Stratigraphic Age and Lithological Association for Wuhan Metropolitan Area
-
摘要: 第四纪地质是工程地质的基础，第四纪沉积物的地层时代、岩性组合等是土体工程地质单元划分的重要依据.通过武汉市地貌、第四纪地质特征（地层、成因、岩性等）及土体工程地质性质等综合调查和分析，提出基于"地层时代+岩性组合（岩石地层单位）+岩性层"的武汉市工程地质单元体划分原则.根据城市建设的需要，将武汉市都市发展区土体工程地质单元体分为3级：单元层（1）、亚单元层（1-1）、基本单元层（1-1-1），其划分的控制因素依次为：地层时代、岩性组合（岩石地层单位）、岩性层.据此划分出工程地质单元层6个、亚单元层14个、基本单元层28个.并对各个工程地质单元体的特征进行了分析.Abstract: Stratigraphic age, lithological association and other parameters of Quaternary sediment are important basis of soil engineering division of geological units. Based on the comprehensive survey and integrated analysis of geomorphology features, the Quaternary geological characteristics (e.g. stratigraphic sequences, strata genesis and lithological characters, etc.) and the soil engineering geological properties, the zonation principle of soil unit of Wuhan Metropolitan Area is proposed as the combination of stratigraphic age, lithological association and stratigraphic sequences. In order to meet the requirements of the city construction, soil engineering of geological units of Wuhan Metropolitan Area is divided into three levels:unit layer (1), sub-unit layer (1-1), and basic unit layer (1-1-1). And the division of control factors is stratigraphic age, lithological association (rock stratigraphic units) and stratigraphic sequences, respectively. According to the above division principle, it is proposed that soil engineering division of geological units of Wuhan Metropolitan Area could be divided into 6 unit layers, 14 sub-unit layers, and 28 basic unit layers. In addition, the characteristics of each geological unit are also analyzed, respectively.
-
表 1 武汉市都市发展区工程地质单元划分
Table 1. Division of engineering geological units in Wuhan Metropolitan Area
单元层及编号 划分依据 亚单元编号 划分依据 基本单元层编号 划分依据 工程力学性质 承载力特征值fak (kPa) 压缩模量Es（MPa） 第一单元层（1） 现代沉积层 1-1 人工填土 （1-1-1） 杂填土层 （1-1-2） 素填土层 1-2 自然冲淤层 （1-2-1） 冲积砂土层 （1-2-2） 淤泥（塘泥）层 40~70 1.8~2.5 第二单元层（2） 全新世地质体（Q4） 2-1 黏土类 2-1-1 粉土层 90~120 6.0~8.5 2-1-2 密实黏土 100~150 4.5~6.5 2-1-3 黏性土层 80~100 3.8~4.5 2-1-4 淤泥质土、淤泥 60~80 2.5~3.5 2-1-5 黏土、砂土互层. 90~130 6.0~9.0 2-2 砂层 2-2-1 粉砂 110~150 9.0~13.0 2-2-2 粉细砂层 150~250 13.0~23.0 2-2-3 细砂层 250~320 23.0~30.0 2-3 砾卵石层 2-3-1 中粗砂夹砾石层 300~400 18.0~25.0 2-3-2 砾卵石层 350~450 23.0~28.0 第三单元层（3） 晚更新世（Q3）地质体 3-1 青山组 3-1-1 细砂层 50 — 3-2 下蜀组 3-2-1 砂质黏土层 200~300 8.5~11.0 3-2-2 黏性土层 330~500 14.0~19.0 3-2-3 夹碎石黏性土 400~500 15.0~20.0 第四单元层（4） 中更新世（Q2）地质体 4-1 辛安渡组 4-1-1 黏性土层 300~400 12.0~16.0 4-1-2 砂土层 250~350 14.0~21.0 4-1-3 砾卵石层 320~400 20.0~26.0 4-2 王家店组 4-2-1 网纹红土 330~450 14.0~18.0 4-2-2 网纹残坡积土 400~500 15.0~20.0 第五单元层（5） 早更新世（Q1）地质体 5-1 东西湖组 5-1-1 黏性土层 330~450 14.0~18.0 5-1-2 粉细砂 160~240 14.0~22.0 5-1-3 含砾中粗砂层 250~350 14.0~21.0 5-2 阳逻组 5-2-1 含砾黏性土 330~450 14.0~18.0 5-2-2 中粗砂、砾砂 300~400 20.0~26.0 第六单元层（6） 第四纪（Q）地质体 6-1 坡积土 200~300 20.0~28.0 6-2 残积土 200~300 8.0~15.0 6-3 赭土
下载: 导出CSV
-
Bai, D.Y., Li, C.G., 2010.Status of Quaternary Geology Research of Jianghan Basin. Geological Science and Technology Information, 29(6):1-6(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzkjqb201006001 Fan, S.K., 2006.A Macro-Control Theory of Soil Engineering Geology.Resources Environment & Engineering, 20(S1):585-594(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hbdk2006z1001 Gu, D.G., Huang, D.C., 1979. Classification of Rock Mass Structure and Determination of Quality Factor. Hydrogeology and Engineering Geology, 2(2):7-13(in Chinese with English abstract). Gu, D.Z., 1963. Geological Structure and Engineering Construction. Chinese Science Bulletin, 8(10):23-29(in Chinese). http://d.old.wanfangdata.com.cn/Periodical/dzlp201705021 Gu, Y.S., Guan, S., Ma, T., et al., 2018.Quaternary Sedimentary Environment Documented by Borehole Stratigraphical Records in Eastern Jianghan Basin. Earth Science, 43(11):3989-4000(in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/dqkx201811015 Guan, S.Y., Pang, S.D., Long, Z.G., 2007. Review on Environmental and Engineering Geological Problems in Wuhan City. Journal of Engineering Geology, 15(Suppl.):186-190(in Chinese with English abstract). Guan, S.Y., Zhu, R., Pang, S.D., et al., 2016.The Study for Engineering Geological Zonation of Metropolitan Development Area in Wuhan. Urban Geotechnical Investigation & Surveying, (6):172-176(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=cskc201606046 Liu, J.X., Yan, C.H., Xu, B.T., 2005.Analysis of Engineering Geology Problem of Sensitive Preferred Stratum for the Foundation of Suzhou-Nantong Bridge. Geological Review, 51(6):719-723(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzlp200506015 Luo, G.Y., Liu, S.Y., Yang, W.D., et al., 1992.Analysis of Regional Stability by Theory of Preferred Plane. Chinese Journal of Geotechnical Engineering, 14(6):10-18(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=10.1177/002200276400800402 Luo, G.Y., Wang, P.Q., Cai, Z.Y., et al., 1982.On the Concept of Two Preferred Planes and Its Analysis Methods. Chinese Journal of Geotechnical Engineering, 4(2):57-66(in Chinese with English abstract). Luo, G.Y., Yan, C.H., Li, X.Z., et al., 2002.Engineering Geology in China:Reviews and Projects at the Beginning of the New Century. Journal of Engineering Geology, 10(1):3-9(in Chinese with English abstract). Pang, S.D., Xiong, Y. M., Xiao, Y. M., 2005. The Idea of the Engineering Geological Zoning in Wuhan City. Urban Exploration, (2):52-55(in Chinese with English abstract). Sun, G. Z., 1992. Mechanics of Rock Mass Structure. Advance in Earth Sciences, 7(1):87-89(in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/gyjz201803019 Sun, G. Z., 1993. On the Theory of Structure-Controlled Rock Mass. Journal of Engineering Geology, First Issue:14-18(in Chinese with English abstract). Sun, G.Z., Zhang, W.B., 1985.A Commonly-Sighted Rock Mass Structure-Slab-Rent Structure and Its Mechanical Model. Chinese Journal of Geology, 20(3):275-282(in Chinese with English abstract). Tang, H.M., 2006.A Review on the Study of Geological Environment and City Development. Journal of Engineering Geology, 14(6):728-733(in Chinese with English abstract). http://cn.bing.com/academic/profile?id=f72e7a4d0a63b5616320ec6865a90706&encoded=0&v=paper_preview&mkt=zh-cn Tian, W. X., Mao, X. W., He, R. L., et al., 2011.Progresses in Quaternary System of Wuhan Area in 1:50 000 Regional Geological Survey. Geology and Mineral Resources of South China, 27(4):286-291(in Chinese with English abstract). http://cn.bing.com/academic/profile?id=3b72b845fdca5da9327699165e925ada&encoded=0&v=paper_preview&mkt=zh-cn Wang, Y.Y., Huang, S.B., Zhao, L., et al., 2017.Evolution of Quaternary Sedimentary Environment in Shallow Aquifers, at Shahu Area, Jianghan Plain. Earth Science, 42(5):751-760(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqkx201705011 Yan, C.H., Wu, H.R., Xu, B.T., et al., 2015.Engineering Geological Properties of Different Sedimentary Types of Soft Soils in Eastern China-Take the 4 Typical Types of Soft Soil in Lianyungang, Nanjing, Wujiang and Xuyi Area as Examples. Geological Review, 61(3):561-569(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzlp201503011 Yang, Y., Li, C.G., Hu, S.H., et al., 2008.Grain Size Features and Genesis of the Qingshan "Sand-Dune" in Wuhan. Acta Sedimentologica Sinica, 26(3):487-493(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=cjxb200803016 Zhang, X.G., Zhang, Z.Y., Xu, B., et al., 2000.Engineering Geology in China. Science Press, Beijing, 14-33(in Chinese). Zheng, J., Yan, C.H., Xia, W.J., et al., 2008.Study on Engineering Geological Characteristics of the Special Soft-Soil in Xuyi Area, Jiangsu Province. Geological Review, 54(1):138-134(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzlp200801015 柏道远, 李长安, 2010.江汉盆地第四纪地质研究现状.地质科技情报, 29(6):1-6. doi: 10.3969/j.issn.1000-7849.2010.06.001 范士凯, 2006.土体工程地质的宏观控制论.资源环境与工程, 20(S1):585-594. http://d.old.wanfangdata.com.cn/Periodical/hbdk2006z1001 谷德振, 1963.地质构造与工程建设.科学通报, 8(10):23-29. http://d.old.wanfangdata.com.cn/Periodical/dzzhyhjbh201502014 谷德振, 黄鼎成, 1979.岩体结构的分类及其质量系数的确定.水文地质工程地质, 6(2):8-13. http://www.cnki.com.cn/Article/CJFDTotal-SWDG197902001.htm 顾延生, 管硕, 马腾, 等, 2018.江汉盆地东部第四纪钻孔地层与沉积环境.地球科学, 43(11):3989-4000. doi: 10.3799/dqkx.2018.324 官善友, 庞设典, 龙治国. 2007.论武汉市环境工程地质问题.工程地质学报, 15(Suppl.):186-190. http://d.old.wanfangdata.com.cn/Conference/6465837 官善友, 朱锐, 庞设典, 等, 2016.武汉都市发展区工程地质分区研究.城市勘测, (6):172-176. doi: 10.3969/j.issn.1672-8262.2016.06.046 刘军熙, 阎长虹, 许宝田, 2005.苏通大桥地基中敏感优势层工程地质问题分析.地质论评, 51(6):719-723. doi: 10.3321/j.issn:0371-5736.2005.06.015 罗国煜, 刘松玉, 杨卫东, 等, 1992.区域稳定性优势面分析理论与方法.岩土工程学报, 14(6):10-18. doi: 10.3321/j.issn:1000-4548.1992.06.002 罗国煜, 王培清, 蔡钟业, 等, 1982.论边坡两类优势面的概念及其研究方法.岩土工程学报, 4(2):57-66. doi: 10.3321/j.issn:1000-4548.1982.02.006 罗国煜, 阎长虹, 李晓昭, 等, 2002.新世纪伊始中国工程地质回顾与展望.工程地质学报, 10(1):3-9. doi: 10.3969/j.issn.1004-9665.2002.01.001 庞设典, 熊毅明, 肖炎明, 等, 2005.武汉市工程地质分区的构想.城市勘测, (2):52-55. doi: 10.3969/j.issn.1672-8262.2005.02.022 孙广忠, 1992.岩体结构力学.地球科学进展, 7(1):87-89. http://d.old.wanfangdata.com.cn/Thesis/Y776746 孙广忠, 1993.论"岩体结构控制论".工程地质学报, 创刊号, 14-18. http://www.cnki.com.cn/Article/CJFDTotal-GCDZ199301003.htm 孙广忠, 张文彬, 1985.一种常见的岩体结构——板裂结构及其力学模型.地质科学, 20(3):275-282. http://www.cnki.com.cn/Article/CJFDTotal-DZKX198503007.htm 唐辉明, 2006.地质环境与城市发展研究综述.工程地质学报, 14(6):728-733. doi: 10.3969/j.issn.1004-9665.2006.06.002 田望学, 毛新武, 何仁亮等. 2011.武汉地区1:5万区调第四系研究进展.华南地质与矿产, 4(4):286-291. doi: 10.3969/j.issn.1007-3701.2011.04.005 王妍妍, 黄爽兵, 赵龙, 等, 2017.江汉平原沙湖地区浅层含水层第四纪沉积环境演化.地球科学, 42(5):751-760. doi: 10.3799/dqkx.2017.063 阎长虹, 吴焕然, 许宝田, 等, 2015.不同成因软土工程地质特性研究——以连云港、南京、吴江、盱眙等地四种典型软土为例.地质论评, 61(3):561-569. http://d.old.wanfangdata.com.cn/Periodical/dzlp201503011 杨勇, 李长安, 胡思辉, 等, 2008.武汉青山"砂山"粒度特征及其成因指示.沉积学报, 26(3):487-493. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=cjxb200803016 张咸恭, 张倬元, 许兵, 等, 2000.中国工程地质学.北京:科学出版社, 14 -33. http://d.old.wanfangdata.com.cn/Periodical/gcdzxb200404005 郑军, 阎长虹, 夏文俊, 等, 2008.江苏盱眙特殊软土的工程地质特性研究.地质论评, 54(1):138-134. http://d.old.wanfangdata.com.cn/Periodical/dzlp200801015 -
