Quaternary Activity Characteristics of the Yiong-Zayu Segment of the Jiali Fault Zone
-
摘要: 嘉黎断裂带通常被认为是控制青藏高原东南缘物质向东南挤出的重要边界构造之一，但其第四纪是否仍在活动以及活动特征如何一直存在争议. 在前人工作基础上，通过高分辨率遥感影像解译、DEM数据分析和详细的地表调查，并结合震源机制解和GPS观测等数据，分析研究了嘉黎断裂带易贡-察隅段的第四纪活动性及特征. 结果表明，嘉黎断裂带易贡-察隅段在第四纪期间未显示出明显的右旋走滑活动特征，仅在局部段落发育小规模的北西或近东西向的正断层活动. GPS速率分析也显示，嘉黎断裂带易贡-察隅段的现今右旋走滑活动不明显，而表现出以伸展变形为主，这与震源机制解反映出的沿断裂带主要发生正断型地震的特征向吻合. 综合分析认为，伴随青藏高原东南缘地区构造变形方式由早期向东横向挤出转变为围绕东构造结的顺时针旋转运动，嘉黎断裂带易贡-察隅段第四纪期间整体上已不活动，不再是调节物质向东挤出运动的边界走滑断裂，而局部的小规模正断层活动可能与东构造结强挤压背景下引起的局部张裂或者冰川融化引发地壳回弹作用相关. 新的研究结果支持藏东-川西地区第四纪构造变形模式更符合深部通道流驱动下的围绕东构造结顺时针旋转-挤出模式，而非横向或侧向挤出模式.Abstract: The Jiali Fault Zone is one of the major active tectonic structures along the southeastern margin of the Tibetan Plateau, playing a crucial role in regional seismicity and geomorphic evolution. This study systematically analyzes the tectonic activity of the Yiong-Zayu segment of the Jiali Fault Zone by integrating high-resolution remote sensing imagery, DEM data, field investigations, and focal mechanism solutions.The results indicate that the Jiali Fault Zone has exhibited weak tectonic activity since the Quaternary, with no significant evidence of right-lateral strike-slip motion. Instead, localized NW- and nearly E-W-trending normal faulting has been observed along certain segments, and seismic activity is predominantly characterized by local normal-faulting earthquakes. GPS velocity analysis reveals that the fault exhibits low horizontal slip rates, with deformation primarily characterized by extension, suggesting that it does not function as a major boundary fault.By integrating previous studies, we further infer that the formation of local normal faults is primarily influenced by localized shear stress or post-glacial rebound. Moreover, the kinematic model of southeastern Tibet is more consistent with a clockwise rotational extrusion mechanism.
-
图 1 嘉黎断裂带易贡-察隅段地震地质图
其中地震目录来源于USGS，DEM高程数据源自AsterDEM 30 m分辨率数据，前人研究断层位置来源于李鸿儒等（2021））
Fig. 1. Seismogeological map of the Yiong-Zayu Segment of the Jiali Fault zone
图 2 嘉黎断裂带易贡-察隅段河道两侧冲洪积扇高清DEM影像
a.波密段高清DEM解译；b.然乌段高清DEM解译；c.察隅段高清DEM解译，其中红色箭头指示断层位置，黄色虚线指示冲沟，黑色实线指示扇体或者阶地
Fig. 2. High-resolution DEM image of the fluvial and alluvial fans on both sides of the river in the Yiong-Zayu Segment of the Jiali Fault zone
图 3 嘉黎断裂带高清遥感影像图
a.波密县西侧阶地面地貌图；b.易贡乡南侧阶地地貌面图；c.下察隅镇北侧阶地地貌面图
Fig. 3. High-resolution remote sensing image of the Jiali Fault zone
图 4 嘉黎断裂带沿线扇体14C测年采样地貌面及剖面图
a.波密县西侧阶地面采样点；b. 波密县西侧阶地面采样剖面及结果；c.古玉乡北侧桑曲阶地面采样点；d. 玉乡北侧桑曲阶地面采样剖面及结果；e.古玉乡西侧阶地采样点；f. 古玉乡北侧桑曲阶地面采样剖面及结果
Fig. 4. Landform surface and profile of 14C dating sampling sites along the Jiali Fault zone
图 5 走滑地貌示意图及嘉黎断裂沿线盆地DEM影像图
a. 走滑作用产生的盆地形态示意图；b. 易贡段宽谷地貌解译图；c. 波密段高清DEM宽谷地貌解译；d. 然乌段宽谷地貌解译图；e. 察隅段宽谷地貌解译图，其中红色箭头指示断层位置，黄色虚线指示冲沟，黑色实线指示扇体或者阶地
Fig. 5. Schematic diagram of strike-slip landforms and DEM image of basins along the Jiali Fault zone
图 6 嘉黎断裂易贡-通麦段地貌
a.正断层带；b. R剪切面及擦痕；c. 断层三角面及扇体无明显错动
Fig. 6. Geomorphology of the Yiong-Tongmai Segment of the Jiali Fault
图 7 嘉黎断裂古乡段地貌
a.正断层剖面图；b. 断层面及擦痕
Fig. 7. Geomorphology of the Guxiang Segment of the Jiali Fault
图 8 嘉黎断裂然乌段地质地貌图
a. 康沙村东路上出露的台地；b. 走滑断层剖面；c，d. 正断层剖面
Fig. 8. Geomorphology of the Ranwu Segment of the Jiali Fault
图 9 嘉黎断裂察隅段地貌
a. 山前断层行迹，红色箭头指示断层位置；b. 古玉乡阶地面地貌图，未见明显错动；c.察瓦龙乡段见断层破碎带，其中红色箭头指示断层位置
Fig. 9. Geomorphology of the Zayu Segment of the Jiali Fault
图 10 嘉黎断裂带易贡-察隅段震源机制解图
GPS数据引自Wang et al.（2020）；震源机制解数据引用自陈平光等（2023）
Fig. 10. Focal mechanism solutions map of the Yiong-Zayu Segment of the Jiali Fault zone
图 11 嘉黎断裂带易贡-察隅段GPS速率剖面图
a. 察隅段N50°E平行于嘉黎断裂带速率分量；b. 察隅段N50°E垂直于嘉黎断裂带速率分量；c. 波密段N30°E平行于嘉黎断裂带速率分量；d. 波密段N30°E垂直于嘉黎断裂带速率分量，其中灰色虚线代表断裂两边均值，黑色虚线为断裂东西两端分界线，定义东向、北向为正值，西向、南向为负值
Fig. 11. GPS velocity N50°E profile of the Yiong-Zayu Segment of the Jiali Fault zone
图 12 藏东南构造变形4种代表性运动学模型（修改自吴中海等, 2015）
Fig. 12. Four representative kinematic models of tectonic deformation in Southeastern Tibet (modified from Wu et al., 2015)
图 13 青藏高原东南缘顺时针旋转-挤出模式图
JLF. 嘉黎断裂带；YD-YX. 羊达-亚许断裂带；NJF. 怒江断裂带；BTF. 巴塘断裂带；LTF. 理塘断裂带；XH-XJF. 鲜水-小江河断裂带
Fig. 13. Clockwise rotation-extrusion model of the Southeastern Tibet
表 1 嘉黎断裂带14C结果表
Table 1. Radiocarbon age of Jiali Fault zone
样品 经度
(°E)纬度
(°N)海拔(m) 年龄(a BP) 校正年龄（cal a BP） 0829-1 94.88 30.26 2 308 9 000±30 10 183±58 10 145~10 240 (95.4%) 10 045~10 059 (1.5%) 9 965~9 985 (3.5%) 0831-1 97.26 29.11 3 159 9 700±30 11 124±88 11 075~11 210 (86.5%) 10 880~10 928 (8.9%) 0901-1 97.11 29.19 3 563 1 050±30 959±37 1 025~1 055 (11.0%) 916~1 001 (84.5%) 0902-1 97.62 28.79 3 926 > 43 500 - -
下载: 导出CSV
-
Adams, K. D., Wesnousky, S. G., Bills, B. G., 1999. Isostatic Rebound, Active Faulting, and Potential Geomorphic Effects in the Lake Lahontan Basin, Nevada and California. Geological Society of America Bulletin, 111(12): 1739-1756. https://doi.org/10.1130/0016-7606(1999)1111739:irafap>2.3.co;2 doi: 10.1130/0016-7606(1999)1111739:irafap>2.3.co;2 Armijo, R., Tapponnier, P., Han, T. L., 1989. Late Cenozoic Right-Lateral Strike-Slip Faulting in Southern Tibet. Journal of Geophysical Research: Solid Earth, 94(B3): 2787-2838. https://doi.org/10.1029/JB094iB03p02787 Chen, P. G., He, X. H., Xu, S. F., et al., 2023. Earthquake Relocation and Regional Stress Field around the Eastern Himalayan Syntaxis. Reviews of Geophysics and Planetary Physics, 54(6): 667-683(in Chinese with English abstract). Chung, L., 2014. Activity of the Eastern Karakoram-Jiali Fault Zone in Tibet(Dissertation). National Taiwan University, Taibei, 81-107(in Chinese). Gao, Y., Wu, Z. H., Zuo, J. M., et al., 2024. Spatial-Temporal Activity of Quaternary Faults at Southern End of Nyalam-Coqen Rift, Southern Tibet. Earth Science, 49(7): 2552-2569(in Chinese with English abstract). Grosset, J., Mazzotti, S., Vernant, P., 2023. Glacial-Isostatic-Adjustment Strain Rate-Stress Paradox in the Western Alps and Impact on Active Faults and Seismicity. Solid Earth, 14(10): 1067-1081. https://doi.org/10.5194/se-14-1067-2023 Hampel, A., Hetzel, R., 2006. Response of Normal Faults to Glacial-Interglacial Fluctuations of Ice and Water Masses on Earth's Surface. Journal of Geophysical Research: Solid Earth, 111(B6): 1-13. https://doi.org/10.1029/2005JB004124 He, Z. H., Yang, D. M., Wang, T. W., 2006. Zircon SHRIMP U-Pb Age and Petrochemical and Geochemical Features of Mesozoic Muscovite Monzonitic Granite at Ningzhong, Tibet. Acta Petrologica Sinica, 22(3): 653-660 (in Chinese with English abstract). Li, C. Y., Zhang, P. Z., Zhang, J. X., et al., 2007. Late-Quaternary Activity and Slip Rate of the Western Qinling Fault Zone at Huangxianggou. Quaternary Sciences, 27(1): 54-63(in Chinese with English abstract). Li, H. R., Bai, L., Zhan, H. L., 2021. Research Progress of Jiali Fault Activity. Reviews of Geophysics and Planetary Physics, 52(2): 182-193 (in Chinese with English abstract). Li, Z. J., Wang, Y., Liu, L. J., et al., 2025. Lithospheric Deformation and Corresponding Deep Geodynamic Process of the SE Tibetan Plateau. Science China Earth Sciences, 55(5): 1351-1376 (in Chinese with English abstract). Liu, S. J., Lan, H. X., Strom, A., et al., 2024. Spatial Segmentation of Jiali Fault's Holocene Activity in the Southeastern Tibetan Plateau. NPJ Natural Hazards, 1: 42. https://doi.org/10.1038/s44304-024-00038-3 Liu, Y. H., Zhang, Y. F., Shan, X. J., et al., 2019, Use of Seismic Waveforms and Insar Data for Determination of the Seismotectonics of the Mainling Ms6.9 Earthquake on Nov. 18, 2017. Seismology and Geology, 34(3): 896-907 (in Chinese with English abstract). Miao, S. Q., Hu, Z. K., Zhang, L., et al., 2021. Geomorphic Analysis of Strike-Slip Faulting at the Top of Alluvial Fan: a Case Study at Ahebiedou River on the Eastern Margin of Tacheng Basin, Xinjiang, China. Seismology and Geology, 43(3): 488-503 (in Chinese with English abstract). Molnar, P., Lyon-Caent, H., 1989. Fault Plane Solutions of Earthquakes and Active Tectonics of the Tibetan Plateau and Its Margins. Geophysical Journal International, 99(1): 123-154. https://doi.org/10.1111/j.1365-246X.1989.tb02020.x Molnar, P., Tapponnier, P., 1978. Active Tectonics of Tibet. Journal of Geophysical Research: Solid Earth, 83(B11): 5361-5375. https://doi.org/10.1029/JB083iB11p05361 Nichols, G., 2009. Sedimentology and Stratigraphy. Ladybird, UK, 420-425. Ren, J. W., Shen, J., Cao, Z. Q., et al., 2000. Quaternary Faulting of Jiali Fault, Southeast Tibetan Plateau. Seismology and Geology, 22(4): 344-350 (in Chinese with English abstract). doi: 10.3969/j.issn.0253-4967.2000.04.002 Royden, L. H., Burchfiel, B. C., King, R. W., et al., 1997. Surface Deformation and Lower Crustal Flow in Eastern Tibet. Science, 276(5313): 788-790. https://doi.org/10.1126/science.276.5313.788 Song, J., 2010. Study on Current Movement Characteristics and Numerical Simulation of the Main Faults Around the Eastern Himalayan Syntaxis(Dissertation). Institute of Geology, China Earthquake Administration, Beijing, 34-43 (in Chinese with English abstract). Song, J., Tang, F. T., Deng, Z. H., et al., 2013. Late Quaternary Movement Characteristic of Jiali Fault in Tibetan Plateau. Acta Scientiarum Naturalium Universitatis Pekinensis, 49(6): 973-980 (in Chinese with English abstract). Steffen, R., Wu, P., Steffen, H., et al., 2014. On the Implementation of Faults in Finite-Element Glacial Isostatic Adjustment Models. Computers & Geosciences, 62: 150-159. https://doi.org/10.1016/j.cageo.2013.06.012 Stewart, I. S., Sauber, J., Rose, J., 2000. Glacio-Seismotectonics: ice Sheets, Crustal Deformation and Seismicity. Quaternary Science Reviews, 19(14/15): 1367-1389. https://doi.org/10.1016/S0277-3791(00)00094-9 Tang, F. T., Song, J., Cao, Z. Q., et al., 2010. The Movement Characters of Main Faults around Eastern Himalayan Syntaxis Revealed by the Latest GPS Data. Chinese Journal of Geophysics, 53(9): 2119-2128 (in Chinese with English abstract). Tapponnier, P., Molnar, P., 1976. Slip-Line Field Theory and Large-Scale Continental Tectonics. Nature, 264(5584): 319-324. https://doi.org/10.1038/264319a0 Taylor, M., Yin, A., 2009. Active Structures of the Himalayan-Tibetan Orogen and Their Relationships to Earthquake Distribution, Contemporary Strain Field, and Cenozoic Volcanism. Geosphere, 5(3): 199-214. https://doi.org/10.1130/ges00217.1 Taylor, M., Yin, A., Ryerson, F. J., et al., 2003. Conjugate Strike-Slip Faulting along the Bangong-Nujiang Suture Zone Accommodates Coeval East-West Extension and North-South Shortening in the Interior of the Tibetan Plateau. Tectonics, 22(4): 1-25. https://doi.org/10.1029/2002TC001361 Wang, E., Burchfiel, B. C., 1997. Interpretation of Cenozoic Tectonics in the Right-Lateral Accommodation Zone between the Ailao Shan Shear Zone and the Eastern Himalayan Syntaxis. International Geology Review, 39(3): 191-219. https://doi.org/10.1080/00206819709465267 Wang, H., Li, K. J., Chen, L. C., et al., 2020. Evidence for Holocene Activity on the Jiali Fault, an Active Block Boundary in the Southeastern Tibetan Plateau. Seismological Research Letters, 91(3): 1776-1780. https://doi.org/10.1785/0220190371 Wang, M., Shen, Z. K., 2020. Present-Day Crustal Deformation of Continental China Derived from GPS and Its Tectonic Implications. Journal of Geophysical Research: Solid Earth, 125(2): e2019JB018774. https://doi.org/10.1029/2019JB018774 Wang, S. Y., Ai, M., Wu, C. Y., et al., 2018. Application of Dem Generation Technology from High Resolution Satellite Image in Quantitative Active Tectonics Study: a Case Study of Fault Scarps in the Southern Margin of Kumishi Basin. Seismology and Geology, 40(5): 999-1017 (in Chinese with English abstract). Wang, X. N., Tang, F. T., Shao, C. R., 2018. The Current Movement Characters of Main Faults Surrounding the Namcha Barwa Syntaxis. Technology for Earthquake Disaster Prevention, 13(2): 267-275 (in Chinese with English abstract). Wu, Z. H., Long, C. X., Fan, T. Y., et al., 2015. The Arc Rotational-Shear Active Tectonic System on the Southeastern Margin of Tibetan Plateau and Its Dynamic Characteristics and Mechanism. Geological Bulletin of China, 34(1): 1-31 (in Chinese with English abstract). Xiang, S. Y. M., Ma, X. M., Ze, R., et al., 2007. Record of Apatite Fission Track of the Differential Uplift in both Sides of Jiali Fault Belt since Late Cenozoic. Earth Science, 32(5): 615-621 (in Chinese with English abstract). Xu, Z. Q., Li, H. B., Tang, Z. M., et al., 2011. The Transformation of the Terrain Structures of the Tibet Plateau through Large-Scale Strike-Slip Faults. Acta Petrologica Sinica, 27(11): 3157-3170 (in Chinese with English abstract). http://www.oalib.com/paper/1475130 Zhang, J. J., Ji, J. Q., Zhong, D. L., et al., 2003. Discussion on the Tectonic Pattern and Formation Process of the South Ngangla Ring of the Eastern Himalayas. Science in China (Series D), 4: 373-383(in Chinese). Zhao, T. X., Su, X. N., Zhu, Q., et al., 2024. The Crustal Deformation Characteristics of Typical Tectonic Region in the Western Segment of the Jiali Fault Derived from GPS Observations. Science of Surveying and Mapping, 49(3): 27-35 (in Chinese with English abstract). Zhao, Y. F., Gong, W. B., Jiang, W., et al., 2021. Multi-Stage Characteristics and Tectonic Significance of the Jiali Fault in Guxiang-Tongmai Section, South Tibet. Geoscience, 35(1): 220-233(in Chinese with English abstract). Zhong, N., Guo, C. B., Huang, X. L., et al., 2022. Late Quaternary Activity and Paleoseismic Records of the Middle South Section of the Jiali-Zayu Fault. Acta Geologica Sinica. 95(12): 3642-3659(in Chinese with English abstract). 陈平光, 何骁慧, 徐树峰, 等, 2023. 喜马拉雅东构造结地震精定位及其区域应力场研究. 地球与行星物理论评, (6): 667-683. 高扬, 吴中海, 左嘉梦, 等, 2024. 藏南聂拉木-措勤裂谷南段第四纪正断层作用的时空特征. 地球科学, 49(7): 2552-2569. doi: 10.3799/dqkx.2023.009 和钟铧, 杨德明, 王天武, 2006. 西藏嘉黎断裂带凯蒙蛇绿岩的年代学、地球化学特征及大地构造意义. 岩石学报, (3): 653-660. 李传友, 张培震, 张剑玺, 等, 2007. 西秦岭北缘断裂带黄香沟段晚第四纪活动表现与滑动速率. 第四纪研究, (1): 54-63. 李鸿儒, 白玲, 詹慧丽, 2021. 嘉黎断裂带活动性研究进展. 地球与行星物理论评, 52(2): 182-193. 李长军, 王洋, 刘丽军, 等, 2025. 青藏高原东南缘岩石圈变形特征及其深部动力学过程. 中国科学: 地球科学, 55(5): 1351-1376. 刘云华, 张迎峰, 张国宏, 等, 2019. 2016年1月21日门源MS 6.4级地震InSAR同震形变及发震构造研究. 地球物理学进展, 34(3): 896-907. 苗树清, 胡宗凯, 张玲, 等, 2021. 洪积扇顶部活动走滑断裂的断错地貌分析——以新疆塔城盆地东缘阿合别斗河冲洪积扇为例. 地震地质, 43(3): 488-503. 任金卫, 沈军, 曹忠权, 等, 2000. 西藏东南部嘉黎断裂新知. 地震地质, (4): 344-350. 宋键, 2010. 喜马拉雅东构造结周边地区主要断裂现今运动特征与数值模拟研究(博士学位论文). 北京: 中国地震局地质研究所. 34-43. 宋键, 唐方头, 邓志辉, 等, 2013. 青藏高原嘉黎断裂晚第四纪运动特征. 北京大学学报(自然科学版), 49(6): 973-980. 唐方头, 宋键, 曹忠权, 等, 2010. 最新GPS数据揭示的东构造结周边主要断裂带的运动特征. 地球物理学报, 53(9): 2119-2128. 汪思妤, 艾明, 吴传勇, 等, 2018. 高分辨率卫星影像提取DEM技术在活动构造定量研究中的应用——以库米什盆地南缘断裂陡坎为例. 地震地质, 40(5): 999-1017. 王晓楠, 2018. 南迦巴瓦构造结周边地区主要断裂带现今运动特征(博士学位论文). 北京: 中国地震局地球物理研究所, 15-66. 吴中海, 龙长兴, 范桃园, 等, 2015. 青藏高原东南缘弧形旋扭活动构造体系及其动力学特征与机制. 地质通报, 34(01): 1-31. 向树元民, 马新民, 泽仁扎西, 等, 2007. 嘉黎断裂带两侧晚新生代差异隆升的磷灰石裂变径迹纪录. 地球科学, (5): 615-621. http://www.earth-science.net/article/id/3521 许志琴, 李海兵, 唐哲民, 等, 2011. 大型走滑断裂对青藏高原地体构架的改造. 岩石学报, 27(11): 3157-3170. 张进江, 季建清, 钟大赉, 等, 2003. 东喜马拉雅南迦巴瓦构造结的构造格局及形成过程探讨. 中国科学(D辑: 地球科学), (4): 373-383. 赵天祥, 苏小宁, 朱庆, 等, 2024. GPS观测的嘉黎断裂西段典型构造区域地壳变形特征. 测绘科学, 49(3): 27-35. 赵远方, 公王斌, 江万, 等, 2021. 藏南嘉黎断裂古乡-通麦段多期活动特征及其构造意义. 现代地质, 35(1): 220-233. 钟令和, 2014. 西藏地区喀喇昆仑-嘉黎断裂带东段活动性讨论(博士学位论文). 台北: 国立台湾大学. 81-107. 钟宁, 郭长宝, 黄小龙, 等, 2021. 嘉黎-察隅断裂带中南段晚第四纪活动性及其古地震记录. 地质学报, 95(12): 3642-3659. -
