Coseismic Surface Deformation of the 2025 Ms6.8 Dingri Earthquake in Tibet, China Based on GaoFen-7 Imagery and DSM Differencing Technique
-
摘要: 精细的同震地表变形是理解断层浅层破裂机制和准确评估地震危害的关键参数. 首次利用中国高分七号光学影像和数字地表模型差分技术获取了2025年1月7日西藏定日地震高分辨率的同震地表垂向形变场，揭示的发震断层地表形迹与垂向位移特征与正断活动为主的登么错断裂吻合，表明本次地震为正断型地震. 本次地震造成长42 km的地表形变带，垂向位移幅度、形变梯度和形变带宽度具有明显的分段性，与断层几何复杂性和动态破裂过程有关. 自北向南分为N22°E的扎南拉段、N160°E的登么错湖段和N25°E的措果乡段；显著变形集中发生在扎南拉段，最大垂向位移约2.97±0.20 m；登么错段地表变形最微弱，可能与断层走向变化有关. 沿同震形变带多处宽度达100~150 m，表明在断层周围上百米范围内的弥散性变形可能被忽视或被低估，有必要开展高精度地连续形变测量.Abstract: High-precision coseismic surface deformation is a key parameter for understanding shallow fault rupture mechanisms and accurately assessing seismic hazard. For the first time, GaoFen-7 imagery and Digital Surface Model (DSM) differencing technique were employed to obtain high-resolution coseismic surface vertical deformation associated with the January 7, 2025 Dingri Ms6.8 earthquake in Tibet, China. The revealed surface trace of the seismogenic fault and vertical deformation characteristics coincide with the Dengmocuo Fault dominated by normal faulting, indicating that the earthquake was a normal-faulting event. This earthquake generated a 42-kilometer-long surface deformation zone, with distinct segmentation in both deformation amplitude, gradient and width related to fault geometric complexity and dynamic rupture process. The deformation zone is divided into three segments from north to south: the N22°E-trending Zhananla segment, the N160°E-trending Dengmocuo Lake segment, and the N25°E-trending Cuoguoxiang segment. Pronounced deformation occurred in the Zhananla segment, reaching a maximum vertical displacement of approximately 2.97±0.20 m meters. The surface deformation observed along the Dengmocuo Lake segment is the least pronounced, potentially attributable to a change in the fault's orientation.The width of the coseismic deformation zone on fault segments spans 100 to 150 meters, suggesting that the diffuse deformation occurring within a limited volume surrounding the faults may be overlooked or underestimated, so it is necessary to carry out high-precision continuous monitoring.
-
图 1 青藏高原南部正断层裂谷系
断层改自Tapponnier et al.（2001）；1976年以来的Mw≥6.0震源机制解引自GCMT；1976年以前的M > 7.5地震来自《全球地震目录》和《全球地震灾害信息目录》
Fig. 1. Normal fault rift system in southern Tibetan Plateau
图 3 登么错断裂不同段落的地形差异
a.登么错断裂带地形剖面；b.扎南拉段断层槽谷；c. 登么错湖段断层陡坎；d. 措果乡段断层坡折带
Fig. 3. Topographic variations along different segments of Dengmocuo Fault
图 4 基于DSM差分技术获取地表垂向形变场路线图
Fig. 4. Technique framework for surface vertical deformation derived by DSM differencing methodology
图 5 震前、震后DSM及精度评估
a.震前DSM；b.震后DSM；c. 震前震后DSM高程分布直方图；d. 拟合残差分布图
Fig. 5. Pre- and post-earthquake DSM and accuracy assessment
图 6 全域高程差分布趋势及其与坡度的相关性
a.高程差分布；b. 全域高程差分图；c.高程差与坡度的相关性
Fig. 6. Distribution trend of elevation differences in the entire region and its correlation with slope gradients
图 7 近场（<1 km）高程差分布趋势及其与坡度的相关性
a.高程差分布；b. 近场（<1 km）高程差分图；c. 高程差与坡度的相关性
Fig. 7. Distribution trend of elevation differences in the near field and its correlation with slope gradients
图 8 近场（<1 km）分段高程差分布趋势及其与坡度的相关性
Fig. 8. Distribution trend of elevation differences in the near field along each fault segment
图 9 跨断层同震垂向位移测量示意图
a.形变梯度 > 1%的实例；b. 形变梯度<1%的实例
Fig. 9. Schematic diagram of cross-fault coseismic vertical displacement measurement
图 10 定日地震地表垂向形变
a.沿登么错断裂垂向位移分布图；b.垂向位移沿走向分布；c.光学垂向位移及误差；d.光学形变梯度；e.形变带宽度
Fig. 10. Surface vertical displacements of the Dingri Earthquake
图 11 不同断层段地表垂向变形及其误差、形变带宽度
Fig. 11. Comparison of surface vertical deformations, their errors and deformation zone widths among different fault segments
表 1 来自不同机构的定日地震震源机制解
Table 1. The earthquake source mechanism of the Dingri earthquake by different institutions
来源 纬度(N) 经度(E) 深度（km） 震级（Mw） 节面Ⅰ（°） 节面Ⅱ（°） 走向 倾角 滑动角 走向 倾角 滑动角 CENC 28.590° 87.330° 15.0 7.10 348 40 -100 181 51 -81 GCMT 28.560° 87.470° 12.0 7.10 356 42 -88 173 48 -92 USGS 28.573° 87.375° 11.5 7.05 349 42 -103 187 49 -78 GFZ 28.570° 87.410° 14.0 7.10 0 49 -79 164 41 -102 注：CENC（中国地震台网中心， https://www.cenc.ac.cn/cenc/tpxw/414670/index.html ），GCMT（全球矩心矩张量，https://www.globalcmt.org/ ），USGS（美国地质调查局，https://earthquake.usgs.gov/earthquakes/eventpage/us6000pi9w/moment-tensor ），GFZ（德国地球科学研究中心，https://geofon.gfz.de/eqinfo/event.php？id=gfz2025albe ）.
下载: 导出CSV
表 2 定日地震震前和震后高分七号影像序列
Table 2. GF-7 satellite imagery sequences before and after the Dingri earthquake
卫星类型 产品序列号 轨道号 产品级别 数据采集时间 GF-7 1351763 23451 LEVEL1A 2023-12-05 GF-7 1351764 23451 LEVEL1A 2023-12-05 GF-7 1351765 23451 LEVEL1A 2023-12-05 GF-7 1834696 29736 LEVEL1A 2025-01-16 GF-7 1834697 29736 LEVEL1A 2025-01-16 GF-7 1834698 29736 LEVEL1A 2025-01-16
下载: 导出CSV
-
Armijo, R., Tapponnier, P., Mercier, J. L., et al., 1986. Quaternary Extension in Southern Tibet: Field Observations and Tectonic Implications. Journal of Geophysical Research: Solid Earth, 91(B14): 13803-13872. https://doi.org/10.1029/JB091iB14p13803 Barnhart, W. D., Gold, R. D., Hollingsworth, J., 2020. Localized Fault-Zone Dilatancy and Surface Inelasticity of the 2019 Ridgecrest Earthquakes. Nature Geoscience, 13(10): 699-704. https://doi.org/10.1038/s41561-020-0628-8 Besl, P. J., McKay, N. D., 2002. A Method for Registration of 3-D Shapes. IEEE Transactions on Pattern Analysis and Machine Intelligence, 14(2): 239-256. https://doi.org/10.1109/34.121791 Cao, H. Y., Zhang, X. W., Zhao, C. G., et al., 2020. System Design and Key Technolongies of the GF-7 Satellite. Chinese Space Science and Technology, 40(5): 1-9(in Chinese with English abstract). Chen, H., Qu, C. Y., Zhao, D. Z., et al., 2024. Large-Scale Extensional Strain in Southern Tibet from Sentinel-1 InSAR and GNSS Data. Geophysical Research Letters, 51(19): e2024GL110512. https://doi.org/10.1029/2024GL110512 Fan, X. D., Wang, Y. Y., Tang, X. M., 2023. Block Adjustment without GCPS and Accuracy Verification for GF-7 Satellite Stereo Images. Remote Sensing Information, 38(5): 73-80(in Chinese with English abstract). Gold, R. D., Reitman, N. G., Briggs, R. W., et al., 2015. On- and Off-Fault Deformation Associated with the September 2013 Mw 7.7 Balochistan earthquake: Implications for Geologic Slip Rate Measurements. Tectonophysics, 660: 65-78. https://doi.org/10.1016/j.tecto.2015.08.019 Hirschmuller, H., 2008. Stereo Processing by Semiglobal Matching and Mutual Information. IEEE Transactions on Pattern Analysis and Machine Intelligence, 30(2): 328-341. https://doi.org/10.1109/TPAMI.2007.1166 Kapp, P., Guynn, J. H., 2004. Indian Punch Rifts Tibet. Geology, 32(11): 993. https://doi.org/10.1130/g20689.1 Klinger, Y., Okubo, K., Vallage, A., et al., 2018. Earthquake Damage Patterns Resolve Complex Rupture Processes. Geophysical Research Letters, 45(19): 10, 279-10, 287. https://doi.org/10.1029/2018GL078842 Leprince, S., Barbot, S., Ayoub, F., et al., 2007. Automatic and Precise Orthorectification, Coregistration, and Subpixel Correlation of Satellite Images, Application to Ground Deformation Measurements. IEEE Transactions on Geoscience and Remote Sensing, 45(6): 1529-1558. https://doi.org/10.1109/TGRS.2006.888937 Li, C. L., Li, T., Shan, X. J., et al., 2023. Extremely Large Off-Fault Deformation during the 2021 Mw 7.4 Maduo, Tibetan Plateau, Earthquake. Seismological Research Letters, 94(1): 39-51. https://doi.org/10.1785/0220220139 Li, D. D., Sui, Z. W., Long, X. X., et al., 2024. Geometry Processing and Accuracy Verification of Dual-Line Array Cameras of GF-7 Satellite. National Remote Sensing Bulletin, 28(3): 756-766(in Chinese with English abstract). Liu, F. C., Pan, J. W., Li, H. B., et al., 2025. Co-Seismic Surface Rupture of the 2025 Mw7.1 Tingri Earthquake and Potential Seismic Risk in Southern Tibetan Plateau. Acta Geologica Sinica, 99(3): 685-703(in Chinese with English abstract). Liu, J. H., Jónsson, S., Li, X., et al., 2025. Extensive Off-Fault Damage around the 2023 Kahramanmaraş Earthquake Surface Ruptures. Nature Communications, 16: 1286. https://doi.org/10.1038/s41467-025-56466-w Liu, X. L., Xia, T., Liu, J., et al., 2022. Distributed Characteristics of the Surface Deformations Associated with the 2021 MW7.4 Madoi Earthquake, Qinghai, China. Seismology and Geology, 44(2): 461-483(in Chinese with English abstract). doi: 10.3969/j.issn.0253-4967.2022.02.012 Nissen, E., Maruyama, T., Ramon Arrowsmith, J., et al., 2014. Coseismic Fault Zone Deformation Revealed with Differential lidar: Examples from Japanese Mw∼7 Intraplate Earthquakes. Earth and Planetary Science Letters, 405: 244-256. https://doi.org/10.1016/j.epsl.2014.08.031 Oskin, M. E., Arrowsmith, J. R., Corona, A. H., et al., 2012. Near-Field Deformation from the El Mayor-Cucapah Earthquake Revealed by Differential LiDAR. Science, 335(6069): 702-705. Shao, Y. X., Wang, A. S., Liu, J., et al., 2025. Preliminary Investigation on Surface Rupture and Coseismic Displacement of the January 7, 2025 Dingri Earthquake in Xizang. Earth Science, 50(5): 1677-1695(in Chinese with English abstract). Shi, F., Liang, M. J., Luo, Q. X., et al., 2025. Seismogenic Fault and Coseismic Surface Deformation of the Dingri MS6.8 Earthquake in Xizang, China. Seismology and Geology, 47(1): 1-15(in Chinese with English abstract). doi: 10.3969/j.issn.0253-4967.2025.01.001 Tang, H. Z., Xie, J. F., Tang, X. M., et al., 2022. On-Orbit Radiometric Performance of GF-7 Satellite Multispectral Imagery. Remote Sensing, 14(4): 886. https://doi.org/10.3390/rs14040886 Tapponnier, P., Xu, Z. Q., Roger, F., et al., 2001. Oblique Stepwise Rise and Growth of the Tibet Plateau. Science, 294(5547): 1671-1677. https://doi.org/10.1126/science. 105978 doi: 10.1126/science.105978 Tian, T. T., Wu, Z. H., 2023. Recent Prehistoric Major Earthquake Event of Dingmucuo Normal Fault in the Southern Segment of Shenzha-Dingjie Rift and Its Seismic Geological Significance. Geological Review, 69(S1): 53-55 (in Chinese with English abstract). Wang, H., Wright, T. J., Jing, L. Z., et al., 2019. Strain Rate Distribution in South-Central Tibet from Two Decades of InSAR and GPS. Geophysical Research Letters, 46(10): 5170-5179. https://doi.org/10.1029/2019GL081916 Wang, M., Shen, Z. K., 2020. Present-Day Crustal Deformation of Continental China Derived from GPS and Its Tectonic Implications. Journal of Geophysical Research: Solid Earth, 125(2): e2019JB018774. https://doi.org/10.1029/2019JB018774 Wang, N., Li, Y. S., Shen, W. H., et al., 2025. Source Parameters and Rapid Simulation of Strong Ground Motion of the Ms 6.8 Earthquake on January 7, 2025 in Dingri(Xizang, China)Derived from InSAR Observation. Geomatics and Information Science of Wuhan University, 50(2): 404-411(in Chinese with English abstract). Wells, D. L., Coppersmith, K. J., 1994. New Empirical Relationships among Magnitude, Rupture Length, Rupture Width, Rupture Area, and Surface Displacement. Bulletin of the Seismological Society of America, 84(4): 974-1002. https://doi.org/10.1785/bssa0840040974 Wesnousky, S. G., 2008. Displacement and Geometrical Characteristics of Earthquake Surface Ruptures: Issues and Implications for Seismic-Hazard Analysis and the Process of Earthquake Rupture. Bulletin of the Seismological Society of America, 98(4): 1609-1632. https://doi.org/10.1785/0120070111 Xu, X. H., Tong, X. P., Sandwell, D. T., et al., 2016. Refining the Shallow Slip Deficit. Geophysical Journal International, 204(3): 1843-1862. https://doi.org/10.1093/gji/ggv563 Xu, X. Y., 2019. Late Quaternary Activity of Kada Normal Fault in Shenzha-Dingjie Fault System in Southern Tibet and Its Environmental Effects(Dissertation). Institute of Geology, China Earthquake Administration, Beijing (in Chinese with English abstract). Xu, X., Chen, W., Ma, W., et al., 2002. Surface Rupture of the Kunlunshan Earthquake (ms 8.1), Northern Tibetan Plateau, China. Seismological Research Letters, 73(6): 884-892. https://doi.org/10.1785/gssrl.73.6.884 Xu, Y. R., Fu, G. C., Liang, Z. Y., et al., 2025. Preliminary Study on the Characteristics of Landslides and Soil Liquefaction Triggered by the Dingri MS6.8 Earthquake on January 7, 2025, Southern Tibetan Plateau. Earth Science, 50(5): 1813-1829(in Chinese with English abstract). Yang, B., Wang, M., Xu, W., et al., 2017. Large-Scale Block Adjustment without Use of Ground Control Points Based on the Compensation of Geometric Calibration for ZY-3 Images. ISPRS Journal of Photogrammetry and Remote Sensing, 134: 1-14. https://doi.org/10.1016/j.isprsjprs. 2017.10.013. doi: 10.1016/j.isprsjprs.2017.10.013 Yang, T., Wang, S. G., Fang, L. H., et al., 2025. Analysis of Earthquake Sequence and Seismogenic Structure of the 2025 MS6.8 Dingri Earthquake in Tibetan Plateau. Earth Science, 50(5): 1721-1732(in Chinese with English abstract). Yang, W. C., Jiang, J. S., Qu, C., et al., 2019. A Study on Origin of Cenozoic Rifts in Qinghai-Xizang(Tibetan) Plateau. Geological Review, 65(2): 267-279(inChinesewithEnglishabstract). Yang, W. H., 2020. Digital Surface Model Generation of Weak Texture Regions in Optical Satellite Remote Sensing Images(Dissertation). Wuhan University, Wuhan(in Chinese with English abstract). Yin, A., 2000. Mode of Cenozoic East-West Extension in Tibet Suggesting a Common Origin of Rifts in Asia during the Indo-Asian Collision. Journal of Geophysical Research: Solid Earth, 105(B9): 21745-21759. https://doi.org/10.1029/2000JB900168 Zhao, J. M., Du, P. R., 2016. On the Initial Collision between the Indian and Eurasian Continents. Seismology and Geology, 38(3): 783-796(in Chinese with English abstract). doi: 10.3969/j.issn.0253-4967.2016.03.022 Zhou, Y., Parsons, B. E., Walker, R. T., 2018. Characterizing Complex Surface Ruptures in the 2013 Mw 7.7 Balochistan Earthquake Using Three-Dimensional Displacements. Journal of Geophysical Research: Solid Earth, 123(11): 10, 191-10, 211. https://doi.org/10.1029/2018JB016043 曹海翊, 张新伟, 赵晨光, 等, 2020. 高分七号卫星总体设计与技术创新. 中国空间科学技术, 40(5): 1-9. 范鑫东, 王洋洋, 唐新明, 2023. 高分七号卫星立体影像无地面控制区域网平差与精度验证. 遥感信息, 38(5): 73-80. 李对对, 隋正伟, 龙小祥, 等, 2024. 高分七号卫星双线阵相机几何处理及其精度验证. 遥感学报, 28(3): 756-766. 刘小利, 夏涛, 刘静, 等, 2022. 2021年青海玛多MW7.4地震分布式同震地表裂缝特征. 地震地质, 44(2): 461-483. doi: 10.3969/j.issn.0253-4967.2022.02.012 刘富财, 潘家伟, 李海兵, 等, 2025. 2025年Mw7.1西藏定日地震地表破裂与同震位移分布特征. 地质学报, 99(3): 685-703. 邵延秀, 王爱生, 刘静, 等, 2025.2025年1月7日西藏定日地震地表破裂特征和野外同震位移测量初步结果. 地球科学, 50(5): 1677-1695. doi: 10.3799/dqkx.2025.040 石峰, 梁明剑, 罗全星, 等, 2025. 2025年1月7日西藏定日6.8级地震发震构造与同震地表破裂特征. 地震地质, 47(1): 1-15. doi: 10.3969/j.issn.0253-4967.2025.01.001 田婷婷, 吴中海, 2023. 西藏申扎-定结裂谷南段丁木错正断层的最新史前大地震事件及其地震地质意义. 地质论评, 69(S1): 53-55. 王楠, 李永生, 申文豪, 等, 2025. 2025年1月7日西藏定日Ms 6.8地震震源机制InSAR反演及强地面运动快速模拟. 武汉大学学报(信息科学版), 50(2): 404-411. 徐心悦, 2019. 藏南申扎-定结断裂系卡达正断裂晚第四纪活动性及其环境效应(博士毕业论文). 北京: 中国地震局地质研究所. 徐岳仁, 付国超, 梁泽毓, 等, 2025. 2025年1月7日西藏定日MS6.8地震触发滑坡与砂土液化特征初步研究. 地球科学, 50(5): 1813-1829. doi: 10.3799/dqkx.2025.043 杨婷, 王世广, 房立华, 等, 2025. 2025年1月7日西藏定日MS6.8地震余震序列特征与发震构造. 地球科学, 50(5): 1721-1732. doi: 10.3799/dqkx.2025.033 杨文环, 2020. 光学卫星遥感影像弱纹理区域数字表面模型提取方法研究(博士学位论文). 武汉: 武汉大学. 赵俊猛, 杜品仁, 2016. 印度-亚洲大陆的初始碰撞. 地震地质, 38(3): 783-796. 中华人民共和国应急管理部, 2025. 2025年1月全国自然灾害情况. http://220.197.169.100/xw/yjglbgzdt/202503/t20250306_516049.shtml . -
