Surface Deformation Characteristics and Seismo-Tectonics of the 2025 Dingri Ms6.8 Earthquake in Southern Tibet
-
摘要: 破坏性地震等自然灾害不仅会引起区域生态环境恶化，导致水土流失和地方贫困化，更为直接的影响就是人民生命财产的损失及对民居等地面建筑的破坏和地表变形.通过野外现场地面调查综合分析了2025年1月7日藏南定日6.8级地震形成的地表变形特征，地面沉降及造成的建筑物倒塌破坏情况.沿丁木错断裂从北海拔5 500多米垂向位移 > 185 cm向南至丁木错东海拔4 200多米垂向位移<120 cm，整体由北向南的垂向位移强度有所减小；北段断层陡坎倾向西，丁木错断裂上盘整体下降，局部地段呈台阶式依次下降，导致冰蚀U型谷中冰水沉积物及坡脚冲洪积物出现最高可达3 m的陡坎；干枯的牛粪、冻土鼓包及巨大的冰漂砾被左行错断，显示此次地震还有较明显的走滑特征. 丁木错东更新世洪冲积物中出现南北延伸较长且东西宽度达50 m的地表变形，以中部塌陷呈地堑式张性破裂为主，张性破裂出现的陡坎高度一般不超过120 cm，在张性破裂的前缘端即靠近丁木错局部地段还发育高约50 cm的挤压隆起和地震鼓包. 位于地表地裂缝中心地带的吉翁村和古荣村等村庄是本次地震受灾最为严重的村区.结合区域地质背景分析表明，定日地震是伸展构造控制的浅源破坏性地震，新生代地幔热物质的底辟上涌，活化了以南北向丁木错平移正断层及近东西向藏南拆离系为代表的伸展构造，从而在这些伸展构造交汇部位释放能量引起地震.Abstract: Destructive earthquakes and other natural disasters not only cause deterioration of the regional ecological environment, but also lead to soil erosion and local poverty, but also have a more direct impact on the loss of people's lives and property, as well as the destruction and deformation of ground buildings such as residential buildings. The Surface deformation characteristics, ground subsidence, and building collapse caused by the Ms 6.8 earthquake occurred in Dingri County, southern Tibet on January 7, 2025 were comprehensively analyzed through field investigations. The vertical displacement intensity along the Dingmu Co fault decreases from vertical displacement of over 185 cm at an altitude of over 5 500 meters in the north to vertical displacement of less than 120 cm at an altitude of over 4 200 meters in the east of Dingmu Co; The northern section has a westward drop, which is due to the overall descent of the upper plate of the Dingmu Co fault, with some sections descending in a stepped manner, resulting in steep slopes of up to 3 meters for ice water sediments and slope foot alluvial deposits in the ice eroded U-shaped valley; Occasionally, dry cow manure, Permafrost bulge, and huge ice debris being left displaced, indicating that this earthquake also had obvious strike slip characteristics. A Surface deformation with a north-south extension and an east-west width of up to 50 meters appeared in the alluvial deposits of the eastern Pleistocene in Dingmu Co, characterized by a central collapse and overall westward subsidence. The steep slope of the tensile rupture generally does not exceed 120 cm, and up to 50 cm squeezing uplift and seismic bulges are also developed at the leading edge of the tensile rupture, near the local section of Dingmu Co. The villages of Jiweng and Gurong, located in the center of the surface fissure, were the most severely affected by the Dingri earthquake. Except for a few cement and brick houses, most of the houses collapsed, making them the most severely affected villages in this earthquake. Based on the analysis of regional geological background, the Dingri earthquake is a shallow source destructive earthquake controlled by extensional structures. The upwelling of mantle thermal material in the Cenozoic era activated extensional structures represented by the north-south Dingmu Co strike-slip normal fault and the nearly east-west Tibetan southern detachment system, releasing energy at the intersection of these extensional structures and causing earthquakes.
-
Key words:
- South Tibet /
- Dingri earthquake /
- surface deformation /
- genetic mechanism /
- extensional structure /
- earthquake
-
图 1 青藏高原大地构造格架图
1. 正断层；2. 拆离断层；3. 逆冲断层；4. 走滑断层；5. 缝合带；6. 定日地震；Ⅰ. 主前缘逆冲推覆构造带；Ⅱ. 藏南拆离系；Ⅲ. 雅鲁藏布江缝合带；Ⅳ. 班公湖-怒江缝合带；Ⅴ. 龙木错-双湖-沧江缝合带；Ⅵ. 西昆仑-金沙江缝合带；Ⅶ. 木孜塔格-玛沁-广济断裂带
Fig. 1. Geotechnical framework map of the Qinghai Tibet Plateau
图 2 定日地震及邻区地质构造图
Fig. 2. Geological structure map of the Dingri earthquake and adjacent areas
图 3 定日地震对不同村庄房屋破坏影响照片
a.吉定村房屋破坏照片；b.强嘎村房屋破坏照片；c.嘎布村房屋破坏照片；d.玉白村房屋破坏照片
Fig. 3. Photos of house damageof the several villages
图 4 定日地震地表变形带的展布，野外调查点的分布及垂向位移测量对比图
Fig. 4. Distribution map of surface deformations, field survey points and vertical displacement measurement of the Dingri earthquake
图 5 锯齿状张性地表变形野外照片
a.强嘎村左行特征明显的地表变形；b.错果湖左行特征不明显的地表变形；c，d. 尼辖错左行特征明显的地表变形；e. 朋曲河旁左行特征不明显的地表变形
Fig. 5. Field photos of serrated tensile surface deformations
图 6 平直地裂缝野外照片
a.T字形地表变形；b.Y字形地表变形；c.三角形地表变形
Fig. 6. Field photos of flat surface deformations
图 7 不同组合特征的地表变形野外照片
a，b. 台阶式组合特征的地表变形；c，d. 地堑式组合特征的地表变形
Fig. 7. Field photos of surface fractures with different combinations of features
图 8 平移地表变形野外照片
a. 干枯的牛粪指示左行滑动；b，c. 冻土鼓包指示左行滑动；d.松散的洪冲积物指示微弱右行滑动
Fig. 8. Strike-slip surface deformations
图 10 地表变形与房屋裂缝对比照片
a. 墙体中的破裂缝与地表变形有明显错移；b. 墙体中的破裂缝与地表变形重合；c. 多组地表变形交汇于墙体；d.张性地表变形导致墙体中形成多条错位的破裂
Fig. 10. Comparison photos of surface deformation house fissures
-
Armijo, R., Tapponnier, P., Mercier, J. L., et al., 1986. Quaternary Extension in Southern Tibet: Field Observations and Tectonic Implications. Journal of Geophysical Research: Solid Earth, 91(B14): 13803-13872. https://doi.org/10.1029/jb091ib14p13803 Bian, S., Yu, Z. Q., Gong J. F., et al., 2021. Spatial-Temporal Distribution and Geodynamic Mechanism of the Nearly NS Trending Rifts in the Tibetan Plateau. Journal of Geomechanics, 27(2): 178-194(in Chinese with English abstract). Dang, G. M., Wang, Z. J., 2002. Characteristics of the Surface Rupture Zone and Main Seismic Hazards Caused by the Ms8.1 Earthquake West of the Kunlun Pass, China-Constraints on the Regional Stability of the Qinghai-Tibet Plateau. Geological Bulletin of China, 21(2): 105-108(in Chinese with English abstract). doi: 10.3969/j.issn.1671-2552.2002.02.013 Gao, Y., 2024. Spatial-Temporal Characteristic of the Quaternary NS Trending Normal Faulting in the Dinggye Gyrong Area, Southern Tibet(Dissertation). Pekin Unversity, Beijing(in Chinese with English abstract). Kali, E., Leloup, P. H., Arnaud, N., et al., 2010. Exhumation History of the Deepest Central Himalayan Rocks, Ama Drime range: Key Pressure-Temperature-Deformation-Time Constraints on Orogenic Models: Ama Drime Exhumation History. Tectonics, 29(2): 1-10. https://doi.org/10.1029/2009tc002551 Huang, T., Wu, Z. H., Han, S., et al., 2024. The Basic Characteristics of Active Faults in the Region of Xigaze, Xizangand the Assessment of Potential Earthquake Disaster Risks. Progress in Earthquake Sciences, 54(10): 696-711(in Chinese with English abstract). Leloup, P. H., Mahéo, G., Arnaud, N., et al., 2010. The South Tibet Detachment Shear Zone in the Dinggye Area Time Constraints on Extrusion Models of the Himalayas. Earth and Planetary Science Letters, 292(1/2): 1-16. https://doi.org/10.1016/j.epsl.2009.12.035 Li, H. B., Fu, X. F., Woerd, J., et al., 2008. Co-Seisimic Surface Rupture and Dextral-Slip Oblique Thrusting of the MS 8.0 Wenchuan Earthquake. Acta Geologica Sinica, 82(12): 1623-1643(in Chinese with English abstract). doi: 10.3321/j.issn:0001-5717.2008.12.002 Li, N., Liu, L. Q, Zhu, L. D, et al., 2024. Quaternarу Soft-Sediment Deformation Structures in the Dingmucuo Graben, Northern Himalaуa. Journal of Chengdu University of Technology (Science & Technology Edition), 51(6): 1048-1069(in Chinese with English abstract). Liu, D. M., Li, D. W., 2003. Detachment Faults in Dingjie Area, Middle Segment of Himalayan Orogenic Belt. Geotectonica et Metallogenia, 27(1): 37-42(in Chinese with English abstract). doi: 10.3969/j.issn.1001-1552.2003.01.005 Liu, D. M., Li, D. W., Yang, W. R., 2003. Study of Mylonite and Deformation of Ductile Shear Zone, Dingjie Area. Earth Science Frontiers, 10(2): 479-486(in Chinese with English abstract). doi: 10.3321/j.issn:1005-2321.2003.02.028 Liu, D. M., Yang, W. R., Guo, T. Y., 2020. Discussion on Cenozoic Tectonic Development and Dynamics in South Tibet. Earth Sciences Frontiers, 27(1): 194-203(in Chinese with English abstract). Liu, D. M., Wang, J., Jiang, H., et al., 2024. Evolutionary Geodynamics and Remote Effects of the Uplift of the Qinghai-Tibet Plateau. Earth Science Frontiers, 31(1): 154-169(in Chinese with English abstract). Liu, F. C., Pan, J. W., Li, H. B., et al., 2025. Co-Seismic Surface Rupture of the 2025 Mw7.1 Tingri Earthquake and Potential Seismic Risk in Southern Tibetan Plateau. Acta Geologica Sinica, 99(3): 685-703(in Chinese with English abstract). Lu, Z. W., Gao, R., Li, Q. S., et al., 2006. Deep Geophysical Probe and Geodynamic Study on the Qinghai_Tibet Plateau(1958-2004). Chinese Journal of Geophysics, 49(3): 753-770(in Chinese). doi: 10.3321/j.issn:0001-5733.2006.03.019 Molnar, P., England, P., Martinod, J., 1993. Mantle Dynamics, Uplift of the Tibetan Plateau, and the Indian Monsoon. Reviews of Geophysics, 31(4): 357-396. https://doi.org/10.1029/93rg02030 Pan, J. W., Li, H. B., Wu, F. X., 2011. Surface Rupture Characteristics, Rupture Mechanics, and Rupture Process of the Yushu Earthquake(Ms7.1), 14/04/2010. Acta Petrologica Sinica, 27(11): 3449-3459(in Chinese with English abstract). Shao, Y. S., Wang, A. S., Liu, J., et al., 2025. Preliminary Investigation on Surface Rupture and CoseismicDisplacement of the January 7, 2025 Dingri Earthquake in Xizang. Earth Science, 50(5): 1677-1695(in Chinese with English abstract). Sheng, S. Z., Wang, Q. R., Li, Z. Y., et al., 2025. Investigation of the Seismogenic Structure of the 2025 Dingri MS 6.8 Earthquake in Xizang Base on the Tectonic Stress Field Perspective. Seismology and Geology, 47(1): 49-63(in Chinese with English abstract). doi: 10.3969/j.issn.0253-4967.2025.01.004 Shi, F., Lian, M. J., Luo, Q. X., et al., 2025. Seismogenic Fault and Coseimic Surface Deformation of the Dingri Ms 6.8 Earthquake in Tibet, China. Seismology and Geology, 47(1): 1-15(in Chinese with English abstract). doi: 10.3969/j.issn.0253-4967.2025.01.001 Tapponnier, P., Xu, Z. Q., Roger, F., et al., 2001. Oblique Stepwise Rise and Growth of the Tibet Plateau. Science, 294(5547): 1671-1677. https://doi.org/10. 1126/science.105978 doi: 10.1126/science.105978 Tian, T. T., 2021. Dating of Late Quaternary Paleoseismic Events of the DingmuCuo Fault in the Southern Section of Shenzha-Dingjie Rift(Dissertation). China University of Geosciences, Beijing (in Chinese with English abstract). Tian, T. T., Wu, Z. H., 2023. Recent Prehistoric Major Earthquake Event of Dingmucuo Normal Fault in the Southern Segment of Shenzha-Dingjie Rift and Its Seismic Geological Significance. Geological Review, 69(s1): 53-55(in Chinese with English abstract). Wang, H., Elliott, J. R., Craig, T. J., et al., 2014. Normal Faulting Sequence in the Pumqu-Xainza Rift Constrained by InSAR and Teleseismic Body-Wave Seismology. Geochemistry, Geophysics, Geosystems, 15(7): 2947-2963. https://doi.org/10.1002/2014gc005369 Wang, H., Wright, T. J., Jing, L. Z., et al., 2019. Strain Rate Distribution in South-Central Tibet from Two Decades of InSAR and GPS. Geophysical Research Letters, 46(10): 5170-5179. https://doi.org/10.1029/2019gl081916 Wu, Z. H., Zhang, Y. S., Hu, D. G., et al., 2008. Quaternary Normal Faulting and Its Dynamic Mechanism of the Cona-Nariyong Co Graben in South-Eastern Tibet. Quaternary Sciences, 28(2): 232-242(in Chinese with English abstract). doi: 10.3321/j.issn:1001-7410.2008.02.005 Wu, Z. M., Cao, Z. Q., Shen, T. B. M., et al., 1994. Seismogenic Tectonics in the Central Tibet. Earthquake Research in China, 10(1): 19-27(in Chinese). Xu, X. Y., 2019. Late Quaternary Activity and Its Environmental Effects of the N-S Trend Kharta Fault in Shenzha-Dingjie Rift, Southern Tibet(Dissertation). Institute of Geology, China Earth quake Administration, Beijing(in Chinese). Yang, T., Wang, S. G., Fang, L. H., et al., 2025. Aftershock Sequence Characteristics and Seismogenic Structure of the Ms 6.8 Dingri Earthquake in Tibet. Earth Science, 50(5): 1721-1732(in Chinese with English abstract). Yin, A., Kapp, P. A., Murphy, M. A., et al., 1999. Significant Late Neogene East-West Extension in Northern Tibet. Geology, 27: 787-790. Yin, A., 2000. Mode of Cenozoic East-West Extension in Tibet Suggesting a Common Origin of Rifts in Asia during the Indo-Asian Collision. Journal of Geophysical Research: Solid Earth, 105(B9): 21745-21759. https://doi.org/10.1029/2000jb900168 Zhang, J. J., 2007. Review on the Extensional Structures in the Northern Himalaya and Southern Tibet. Geological Bulletin of China, 26(6): 639-649(in Chinese with English abstract). doi: 10.3969/j.issn.1671-2552.2007.06.003 Zhou, J. J., Shao, Z. G., He, H. L., et al., 2025. Surface Rupture Interpretation and Building Damage Assessment of Xizang Dingri MS6.8 Earthquake on January 7, 2025. Seismology and Geology, 47(1): 16-35(in Chinese with English abstract). doi: 10.3969/j.issn.0253-4967.2025.01.002 卞爽, 于志泉, 龚俊峰, 等, 2021. 青藏高原近SN向裂谷的时空分布特征及动力学机制. 地质力学学报, 27(2): 178-194. 党光明, 吴赞军, 2002. 青海昆仑山口西Ms8.1级地震地表破裂带特征与主要震害——对青藏高原区域稳定性评价的制约. 地质通报, 21(2): 105-108. doi: 10.3969/j.issn.1671-2552.2002.02.013 高扬, 2024. 藏南定结—吉隆地区第四纪近SN向正断层作用的时空特征(博士学位论文). 北京: 北京大学. 黄婷, 吴中海, 韩帅, 等, 2024. 西藏日喀则地区的活断层基本特征及地震灾害潜在风险评估. 地震科学进展, 54(10): 696-711. 李海兵, 付小方, Jérme Van Der Woerd, 等, 2008. 汶川地震(MS8.0)地表破裂及其同震右旋斜向逆冲作用. 地质学报, 82(12): 1623-1643. doi: 10.3321/j.issn:0001-5717.2008.12.002 李楠, 刘陇强, 朱利东, 等, 2024. 喜马拉雅北缘丁木错地堑第四纪软沉积物变形构造. 成都理工大学学报(自然科学版), 51(6): 1048-1069. 刘德民, 李德威, 2003. 喜马拉雅造山带中段定结地区拆离断层. 大地构造与成矿学, 27(1): 37-42. doi: 10.3969/j.issn.1001-1552.2003.01.005 刘德民, 李德威, 杨巍然, 2003. 定结地区韧性剪切带变形特征与糜棱岩研究. 地学前缘, 10(2): 479-486. doi: 10.3321/j.issn:1005-2321.2003.02.028 刘德民, 杨巍然, 郭铁鹰, 2020. 藏南地区新生代多阶段构造演化及其动力学的探讨. 地学前缘, 27(1): 194-203. 刘德民, 王杰, 姜淮, 等, 2024. 青藏高原形成演化动力机制及其远程效应. 地学前缘, 31(1): 154-169. 刘富财, 潘家伟, 李海兵, 等, 2025. 2025年Mw7.1西藏定日地震地表破裂与同震位移分布特征. 地质学报, 99(3): 685-703. 卢占武, 高锐, 李秋生, 等, 2006. 中国青藏高原深部地球物理探测与地球动力学研究(1958—2004). 地球物理学报, 49(3): 753-770. doi: 10.3321/j.issn:0001-5733.2006.03.019 潘家伟, 李海兵, 吴富峣, 等, 2011. 2010年玉树地震(Ms7.1)地表破裂特征、破裂机制与破裂过程. 岩石学报, 27(11): 3449-3459. 邵延秀, 王爱生, 刘静, 等, 2025. 2025年1月7日西藏定日地震地表破裂特征和野外同震位移测量初步结果. 地球科学, 50(5): 1677-1695. doi: 10.3799/dqkx.2025.040 盛书中, 王倩茹, 李振月, 等, 2025. 基于构造应力场研究2025年西藏定日6.8级地震的发震构造. 地震地质, 47(1): 49-63. doi: 10.3969/j.issn.0253-4967.2025.01.004 石峰, 梁明剑, 罗全星, 等, 2025. 2025年1月7日西藏定日6.8级地震发震构造与同震地表破裂特征. 地震地质, 47(1): 1-15. doi: 10.3969/j.issn.0253-4967.2025.01.001 田婷婷, 2021. 申扎-定结裂谷南段丁木错断裂晚第四纪古地震事件研究(博士学位论文). 北京: 中国地质大学. 田婷婷, 吴中海, 2023. 西藏申扎-定结裂谷南段丁木错正断层的最新史前大地震事件及其地震地质意义. 地质论评, 69(s1): 53-55. 吴中海, 张永双, 胡道功, 等, 2008. 西藏错那-拿日雍错地堑的第四纪正断层作用及其形成机制探讨. 第四纪研究, (2): 232-242. doi: 10.3321/j.issn:1001-7410.2008.02.005 吴章明, 曹忠权, 申屠炳明, 1994. 西藏中部的发震构造. 中国地震, 10(1): 19-27. 徐心悦, 2019. 藏南申扎-定结断裂系卡达正断裂晚第四纪活动性及其环境效应(博士学位论文). 北京: 中国地震局地质研究所. 杨婷, 王世广, 房立华, 等, 2025. 西藏定日Ms6.8地震余震序列特征与发震构造. 地球科学, 50(5): 1721-1732. doi: 10.3799/dqkx.2025.033 张进江, 郭磊, 丁林, 2002. 申扎-定结正断层体系中、南段构造特征及其与藏南拆离系的关系. 科学通报, 47(10): 738-743. doi: 10.3321/j.issn:0023-074X.2002.10.003 张进江, 2007. 北喜马拉雅及藏南伸展构造综述. 地质通报, 26(6): 639-649. doi: 10.3969/j.issn.1671-2552.2007.06.003 邹俊杰, 邵志刚, 何宏林, 等, 2025. 2025年1月7日西藏定日MS6.8地震地表破裂解译与建筑物震害损毁统计. 地震地质, 47(1): 16-35. -
