Seismic Damage Characteristics Investigation of Dingri Ms6.8 Earthquake in Xizang
-
摘要: 为研究西藏定日6.8级地震房屋的震害机理，通过实地调查，发现本次地震中土木结构出现的震害主要有倒塌、整体倒塌、墙体开裂、木构件受损；框架结构出现倒塌，梁柱构件发生损伤的建筑较少而且损伤较轻，震害主要出现在多层建筑的框架填充墙；砌体结构出现局部倒塌，底框架砌体结构节点受损严重，承重墙开裂.总结了各类建筑结构的震害特征并进行分析，结果表明土木结构存在竖向刚度不均匀、平面刚度不均匀，墙体整体性差等问题；部分框架结构存在拉结筋缺失、柱子配筋率低、混凝土级配差等问题；砌体结构存在砂浆强度不足、缺乏抗震措施等问题. 最后针对本次地震中房屋出现的震害特征提出了抗震加固建议.Abstract: In order to study the Seismic damage mechanism.Based on the field investigation, it was found that the seismic damages of adobe-timber structures are collapse, partial collapse, cracking on walls, damage to timber parts, frame structure occured collapse, the damage to the beams and columns is rare and light, and the seismic damage mainly occurred in infilled walls.Masonry structures occured partial collapse, the joints of bottom frame structures were seriously damaged, shear damage to walls.The result shows that adobe-timber structures exist vertical rigidity irregular, plane rigidity irregular, poor integrity of wall, etc.Frame structures exit the construction quality problem like lack of tie bar, low reinforcement ratio in columns and poor quality of concrete.Masonry structures also exit construction quality problems, such as low mortar strength, lack of seismic measures, etc.At the end of this article, some suggestions about the buliding defects are provided in order to provide ideas for reinforcement and reconstruction.
-
图 1 西藏定日6.8级地震烈度图
Fig. 1. Seismic Intensity Map of survey points of the 6.8 magnitude Earthquake in Dingri, Xizang
图 4 地上承重体系
a. 模式一展示图；b. 模式一一层承重；c. 模式二展示图；d. 模式二一层承重；e. 平搁节点；f. 暗梢连接节点；g. 钉装节点；h. 二层木构件
Fig. 4. Load-bearing system above ground
图 6 倒塌、局部坍塌及二层面积减少现象
a. 倒塌（定日县长所乡森噶村，Ⅸ度区）；b. 倒塌（拉孜县芒普乡达龙村，Ⅷ度区）；c. 二层倒塌（拉孜县芒普乡达龙村，Ⅷ度区）；d. 单侧倒塌（定日县措果乡吉翁村，Ⅷ度区）；e. “凹”型；f. “凹”型；g.“L”型；h.“日”字型
Fig. 6. Collapse、partial collapse and reduced building area reduction of second floor
图 7 墙体的震害
a. 墙角破坏（定日县曲洛乡吉翁村，Ⅷ度区）；b. 纵横墙脱开（定日县曲洛乡吉翁村，Ⅷ度区）；c. 梁下墙体开裂（Ⅶ度区拉孜县芒普乡达龙村，）；d. 梁下墙体开裂（拉孜县曲下镇耐莎，Ⅶ度区）；e. 门窗洞口开裂（拉孜县曲下镇曲下，Ⅶ度区）；f. 墙体斜向裂缝（拉孜县曲下镇耐莎，Ⅶ度区）；g. 墙体竖裂缝（定日县曲洛乡木队村，Ⅷ度区）；h. 墙体外闪坍塌（拉孜县芒普乡达龙村，Ⅷ度区）
Fig. 7. Seismic damage of walls
图 8 节点震害
a. 柱头开裂（拉孜县芒普乡达龙村，Ⅷ度区）；b. 元宝木开裂（定日县曲洛乡曲洛，Ⅷ度区）；c. 拔榫（拉孜县芒普乡达龙村，Ⅷ度区）；d. 节点歪斜（昂仁县日吾其乡色米村Ⅵ度区）
Fig. 8. Seismic damages of joints
图 9 非承重构件及附属结构的震害
a.围墙倒塌（拉孜县查务乡查务村Ⅶ度区）；b.围墙大门门头掉落（拉孜县查务乡查务村Ⅶ度区）；c.厕所墙体开裂（拉孜县查务乡查务村Ⅶ度区）；d. 厕所墙体开裂（拉孜县查务乡查务村Ⅶ度区）；e. 厕所墙体开裂（拉孜县查务乡森坚村Ⅶ度区）；f. 厕所墙体开裂（定日县加措门当岗村乡Ⅷ度区）
Fig. 9. Seismic damages of accessory structure
图 10 框架结构倒塌
a. 底层倒塌（定日县曲洛乡嘎白村Ⅸ度区）；b. 底层倒塌（定日县曲洛乡嘎白村Ⅸ度区）；c. 柱子配筋率不足（定日县曲洛乡嘎白村Ⅸ度区）
Fig. 10. Collapsed frame structure
图 11 承重构件的震害
a. 柱体开裂（定日县曲洛乡嘎白村Ⅸ度区）；b. 梁头混凝土剥落（拉孜县中心医院Ⅶ度区）；c. 梁中开裂（拉孜县芒普乡幼儿园Ⅶ度区）
Fig. 11. Seismic damages of load-bearing components
图 12 填充墙震害
a. 交接处震害（拉孜县曲下镇曲下村Ⅶ度区）；b. 交接处震害（定日县曲洛乡左措村Ⅸ度区）；c. 交接处震害（定日县加措乡门当岗村Ⅶ度区）；d. 不设拉结筋（拉孜县芒普乡查务村Ⅶ度区）；e. 填充墙顶斜砌（拉孜县曲下镇Ⅶ度区）；f洞口角部开裂（拉孜县曲下镇耐莎Ⅶ度区）；g. 电表口裂缝（拉孜县曲下镇耐莎Ⅶ度区）；h. 洞口间开裂（拉孜县曲下镇耐莎Ⅶ度区）；i. 洞口间墙体开裂（定日县曲洛乡左措村Ⅶ度区）；j. 墙体开裂（定日县曲洛乡左措村Ⅶ度区）；k. 斜裂缝（定日县曲洛乡左措村Ⅶ度区）；l. 交叉裂缝（定日县曲洛乡左措村Ⅶ度区）
Fig. 12. Seismic damages of infilled wall
图 14 砌体结构震害
a. 承重墙开裂（拉孜县拉孜镇拉龙村Ⅵ度区）；b. 承重墙开裂（拉孜县拉孜镇拉龙村Ⅵ度区）；c. 承重墙开裂（定日县加措乡拉龙村Ⅵ度区）；d. 窗间墙受损（拉孜县查务乡查务村Ⅶ度区）；e. 屋盖滑落（定日县曲洛乡噶白村Ⅸ度区）；f. 节点受损（定日县曲洛乡噶白村Ⅸ度区）
Fig. 14. Seismic damages of masonry structure
图 15 非承重构件震害
a.女儿墙掉落（拉孜县拉孜镇拉龙村，Ⅵ度区）；b.女儿墙掉落（拉孜县拉孜镇拉龙村，Ⅵ度区）；c. 女儿墙掉落（拉孜县曲下镇曲下村，Ⅶ度区）；d. 牛粪砖散落（拉孜县曲下镇曲下村，Ⅶ度区）；e. 装饰斗拱掉落（拉孜县拉孜镇拉孜村，Ⅵ度区）；f. 装饰斗拱开裂（（拉孜县拉孜镇拉孜村，Ⅵ度区）；g. 风旗插台断裂（拉孜县拉孜镇拉孜村，Ⅵ度区）；h. 风旗插台受损（拉孜县曲下镇曲下村，Ⅶ度区）；i. 民用房吊顶损坏（（拉孜县曲下镇市区，Ⅶ度区）；j. 公用房吊顶损坏（拉孜县曲下镇市区，Ⅶ度区）；k. 瓷砖掉落（拉孜县曲下镇市区，Ⅶ度区）；l. 管道包柱受损（拉孜县曲下镇市区，Ⅶ度区）；m. 玻璃受损（拉孜县曲下镇市区，Ⅶ度区）；n. 玻璃受损（拉孜县曲下镇市区，Ⅶ度区）
Fig. 15. Seismic damages of non load-bearing structure
表 1 5.0级及以上历史地震信息（1949—2025年）
Table 1. The records of earthquakes above 5.0 magnitude(1949-2025)
地震时间
(年/月/日)位置 震级 经度
(°E)纬度
(°N)深度(km) 距离(km) 2020/03/20 西藏自治区日喀则市定日县 5.9 87.42 28.63 10 15 2016/05/22 西藏自治区日喀则市定日县 5.3 87.59 28.41 6 17 2016/05/22 西藏自治区日喀则市定结县 5.3 87.60 28.36 10 21 2015/04/25 西藏自治区日喀则市定日县 5.9 87.30 28.40 20 18 2001/04/28 西藏自治区日喀则市定日县 5.2 87.00 28.80 0 55 1998/09/04 西藏自治区日喀则市定日县 6.1 86.94 27.85 33 88 1993/03/31 西藏自治区日喀则市拉孜县 5.0 87.50 29.20 32 78 1993/03/20 西藏自治区日喀则市昂仁县 6.4 87.40 29.10 21 67 1975/11/26 西藏自治区日喀则市定结县 5.2 87.80 28.15 52 1973/03/22 西藏自治区日喀则市定日县 5.3 87.20 28.10 33 51 1971/12/04 尼泊尔梅吉专区 5.4 87.90 27.90 29 80 1971/10/24 西藏自治区日喀则市定日县 5.0 87.20 28.30 57 33 1958/11/24 西藏自治区日喀则市定日县 5.2 86.90 28.80 63 1951/05/28 西藏自治区日喀则市定日县 5.5 87.00 29.00 71
下载: 导出CSV
表 2 结构震害对比与原因分析
Table 2. The comparison of seismic damage and the cause analysis
总结 土木结构 框架结构 砌体结构 震害对比 破坏形式 房屋倒塌; 房屋局部倒塌; 木构件受损; 女儿墙受损; 纵横交接处墙开裂; 墙梁交接处开裂; 门窗洞角开裂; 墙体平面开裂 底层倒塌; 墙梁墙柱交接处开裂; 墙体交叉裂缝、斜裂缝; 门窗洞角开裂; 填充墙倒塌; 瓷砖剥落; 吊顶损坏; 女儿墙受损 底框架砌体结构梁柱节点开裂; 轻钢屋顶坍塌; 承重墙开裂; 女儿墙受损 极震区破坏程度 大量土木结构倒塌，或是破坏严重无法居住 有两栋框架结构出现一层坍塌现象；绝大多数框架结构非承重构件受损 两栋底框架砌体结构梁柱节点受损严重；多数砌体结构出现承重墙开裂 结构分布 绝大多数存在于村镇地区，震区数量占比超过80% 少数存在于乡镇，多数存在于城区，震区数量占比约15% 数量较少，散落分布于城镇与村镇，震区占比约5% 原因剖析 结构 竖向刚度不连续，一二层承重构件变化，二层建筑缩进；平面刚度不均匀，承重墙与木构件共同承重；整体性不强，使用黄泥作为承重墙砌筑砂浆，纵横墙拉结弱 承重柱配筋率低；墙体不设拉结筋或拉结措施较弱；砂浆强度低；女儿墙与主体拉结弱 砂浆强度低；女儿墙与主体拉结弱；底框架砌体结构竖向刚度不均匀 施工 施工缺乏专业化培训，多靠居民传统经验，无专业施工队伍 公用建筑基本经过正规设计，但个别建筑施工可能存在不足；民用建筑部分经过正规设计，少数未经正规设计，施工质量总体良莠不齐 多为自建或民间施工队，施工质量欠佳 场地 村庄多位于谷地，受场地条件影响，出现地震放大效应，尤其震中长所乡位于湖边，软土沉积更易产生地震放大
下载: 导出CSV
-
Bai, W. G., Sun, D. X., Wu, Z. H., et al., 2024. Overview of Historical Earthquake Disasters in Xizang Autonomous Region from 1949 to 2020. Progress in Earthquake Sciences, 54(10): 712-720 (in Chinese with English abstract). Basang, C. R., Guo, C. M., Deng, G. Y., et al., 2009. Analysis on Seismic Disaster Characteristics of Dangxiong Ms6.6 and Zhongba Ms 6.8 Earthquake in Xizang. Plateau Earthquake Research, 21(3): 64-69(in Chinese with English abstract). doi: 10.3969/j.issn.1005-586X.2009.03.011 Cao, Z. Q., Huang, Q. J., Deng, G. Y., 1999. Estimation of Northern Xietongmen Ms6.1 Earthquake and Disaster. Earthquake Research in Plateau, (3): 65-68(in Chinese with English abstract). Chen, Y. K., Gao, W. P., Yao, X. Q., et al., 2012. Intensity Distribution and Tectonic Background Analysis of Sikkim 6.8 Earthquake in Xizang, China. Recent Developments in World Seismology, (6): 34(in Chinese with English abstract). Ciren, D. J., Wen, S. L., Zhang, J. L., 2017. Ananlysis on the Characteritics of Seismic Intensity and Seismic Damage about Dingqing Ms5.5 Earthquake in Xizang in 2016. Plateau Earthquake Research, 29(3): 60-64(in Chinese with English abstract). doi: 10.3969/j.issn.1005-586X.2017.03.011 Cui, Y., Yang, N., 2023. Structural Characteristics and Seismic Performance of Ancient Zang-Style Architecture on Sloped Lands. Journal of Building Structures, 44(S2): 20-31(in Chinese with English abstract). Du, Y. F., Li, F. Y., Han, B., et al., 2021. Earthquake Damage Analysis of Tibetan Traditional Timber Frame Structures Subjected to the Xiahe 5.7 Earthquake. Earthquake Resistant Engineering and Retrofitting, 43(2): 153-161(in Chinese with English abstract). Li, B. X., Wang, T. T., Zhao, K. P., etal., 2021. Typical Earthquake Damage of Traditional Xizang Dwellings and Its Vulnerability. Journal of Building Structures, 42(S1): 165-173(in Chinese with English abstract). Li, B. X., Zhao, K. P., Wang, T. T., et al., 2022. Structural Features and Seismic Performance of Tibet and Wellings in Amdo, Northwest Sichuan. World Earthquake Engineering, 38(2): 21-28(in Chinese with English abstract). Li, J. J., Wang, X. K., Jin, H., et al., 2014. The Characteristics of Seismic Damage of Buildings Caused by 6.1 Earthquake IN2013 in Zuogong-Mangkang in Tibet. Plateau Earthquake Research, 26(2): 49-54(in Chinese with English abstract). Li, Z. C., Wu, J., Li, C. L., 2018. Seismic Hazard Analysis of Building Structures for Milin Ms6.9 Earthquake, Xizang. Recent Developments in World Seismology, (12): 2-9(in Chinese with English abstract). Li, Z. Q., Hou, J. S., Li, Y., et al., 2013. Analysis on the Charateristics of the Ms7.0 Lushan, Sichuan Province, Earthquake Hazard on April 20, 2013. Seismology and Geology, 35(2): 398-410(in Chinese with English abstract). Liu, K. . Sun, B. T., Li, Y. G., et al., 2019. Study on the Relationship Between the Earthquake Damage Distribution and Geological Structure of the 2015 Ms8.1 Nepal Earthquake. Journal of Natural Disasters, 28(5): 59-65(in Chinese with English abstract). Lou, Y. F., 2015. Seismic Behavior Analysis of Typical Single-Layer Masonry Structure in Xizang(Dissertation). Harbin Engineering University, Harbin (in Chinese with English abstract). Wang, Y., Liu, A. W., Li, X. X., et al., 2021. Vulnerability Analysis of Typical Dwellings in Tibet Based on Earthquake Damage Data. Technology for Earthquake Disaster Prevention, 16(2): 245-252 (in Chinese with English abstract). Wei. B. Y., Zhang. Y. M., Shi, F., et al., 2025. Analysis of Housing Damage and Casualties in the 2025 Xizang Dingri Ms6.8 Earthquake Based on Field Investigation. Seismology and Geology, 47(1): 64-79(in Chinese with English abstract). Wen, S. L., Tao, X. L., Cao, H. W., et al., 2010. Seismic Characteristic Analysis of Nima Ms5.6 Earthquake in Tibet. Journal of Institute of Disaster-Prevention Science and Technology, 12(1): 36-39 (in Chinese with English abstract). Xie, Y. Q., Fei, M. L., Li, X., et al., 2008. The 2008 Dangxiong, Xizang, Ms6.6 Earthquake: Intensity and Disaster Characteristics. Journal of Seismological Research, 31(S2): 575-584(in Chinese with English abstract). Xu, Z. S., Wen, X. T., Xi, N., et al., 2025. Precise Positioning and Seismic Intensity of Aftershock Sequence of 2025 Dingri Ms 6.8 Earthquake in Xizang. Earth Science, 50(5): 1759-1769 (in Chinese with English abstract). Zhang, J. L., Ni, M., Sijin, L. B., et al., 2021. Estimate of Seismic Intensity and Seismic Damage Analysis of Ms5.9 Earthquake in Dingri, Xizang. Xizang Science and Technology, (1): 48-49+59(in Chinese with English abstract). Zhou, J. X., Nie, G. Z., Tan, J. X., et al., 2017. Analysis on Disaster Characteristics of the Ms 5.4 Gangwu, Guangxi Earthquake, July, 31th, 2016. Seismology and Geology, 39(4): 780-792(in Chinese with English abstract). Zhu, H. T., Yang, X. H., Zhou, X. H., et al., 2013. Analysis of Provenance Channel Characteristics of Continental Lacustrine Basin Based on Seismic Data: A Case Study of Dongying Formation on the Western Slope of Bozhong Sag. Earth Science, 38(1): 121-129(in Chinese with English abstract). 柏伟国, 孙东霞, 吴中海, 等, 2024. 西藏自治区1949—2020年历史地震灾害调查概要. 地震科学进展, 54(10): 712-720. 巴桑次仁, 郭春明, 邓桂英, 等, 2009. 西藏当雄6.6级地震与仲巴6.8级地震震害特征分析. 高原地震, 21(3): 64-69. 曹忠权, 黄庆江, 邓桂英, . 1999. 西藏谢通门县北1998年7月20日6.1级地震烈度及灾害损失评估. . 高原地震, (3): 65-68. 陈宇昆, 高武平, 姚新强, 等, 2012. 印度锡金邦6.8级地震中国西藏地区烈度分布与构造背景分析. 国际地震态, (6): 34. 次仁多吉, 文升梁, 张建龙, 2017. 2016年西藏丁青5.5级地震烈度及震害特征分析. 高原地震, 29(3): 60-64. 崔玥, 杨娜, 2023. 藏式山地古建筑结构特征及抗震性能. 建筑结构学报, 44(S2): 20-31. 杜永峰, 李芳玉, 韩博登, 2021. 夏河5.7级地震藏式木构架房屋震害分析. 工程抗震与加固改造, 43(2): 153-161. 李碧雄, 王甜恬, 赵开鹏, 等, 2021. 传统藏式民居的典型震害及易损性研究. 建筑结构学报, 42(S1): 165-173. 李碧雄, 赵开鹏, 王甜恬, 等, 2022. 川西北安多藏式民居的结构特点及抗震性能. 世界地震工程, 38(2): 21-28. 李佳辑, 王希康, 金花, 等, 2014. 2013年西藏左贡与芒康交界6.1级地震的房屋震害特征. 高原地震, 26(2): 49-54. 李宗超, 吴健, 李昌珑, 2018. 西藏米林MS6.9地震震害分析. 国际地震动态, (12): 2-9. 李志强, 侯建盛, 李洋, 等, 2013. 2013年4月20日四川芦山MS 7.0地震灾害特点分析. 地震地质, 35(2): 398-410. 刘亢, 孙柏涛, 李亦纲, 等, 2019. 2015年尼泊尔Ms8.1地震震害分布与地质构造关系研究. 自然灾害学报, , 28(5): 59-65. 楼亚非, 2015. 西藏典型单层砌体民居抗震性能研究(博士学位论文). 哈尔滨: 哈尔滨工程大学. 王郁, 刘爱文, 李祥秀, 等, 2021. 基于震害资料的西藏地区典型民居易损性分析. 震灾防御技术, 16(2): 245-252. 魏本勇, 张钰曼, 石峰, 等, 2025. 基于现场调查的2025西藏定日Ms6.8地震房屋震害与人员伤亡分析. 地震地质, 2025, 47(1): 64-79. 文升梁, 陶晓莉, 曹华文, 等, 2010. 西藏尼玛5.6级地震房屋震害特征分析. 防灾科技学院报, 12(1): 36-39. 谢英情, 非明伦, 李西, 等, 2008. 2008年西藏当雄6.6级地震烈度与震害特征. 地震研究, 31(S2): 575-584. 徐志双, 文鑫涛, 席楠, 等, 2025. 2025年西藏定日Ms 6.8级地震余震序列精定位与地震烈度. 地球科学, 50(5): 1759-1769. doi: 10.3799/dqkx.2025.044 张建龙, 尼玛, 司金罗布, 等, 2021. 西藏定日Ms5.9地震烈度评定及震害特征分析. 西藏科技, (1): 48-49+59. 周军学, 聂高众, 谭劲先, 等, 2017. 2016年7月31日广西苍梧5.4级地震灾害特征分析. 地震地质, 39(4): 780-792. 朱红涛, 杨香华, 周心怀, 等, 2013. 基于地震资料的陆相湖盆物源通道特征分析: 以渤中凹陷西斜坡东营组为例. 地球科学, 38(1): 121-129. doi: 10.3799/dqkx.2013.012 -
