排烃门限存在的地质地球化学证据及其应用

庞雄奇; 李素梅; 金之钧; 黎茂稳

排烃门限存在的地质地球化学证据及其应用

庞雄奇^{1, 2,},
李素梅^{1, 2},
金之钧¹,
黎茂稳^{1, 3}

1.
石油大学石油与天然气成藏机理教育部重点实验室, 北京 102249
2.
石油大学盆地与油藏研究中心, 北京 102249
3.
加拿大地质调查局卡尔加里分部

基金项目:

国家重点基础研究发展规划项目 G199943310

国家“十五”攻关课题 2001BA605A09

详细信息

作者简介:
庞雄奇(1961-), 男, 博士, 教授, 主要从事油气成藏机理与资源评价的科研与教学工作.E-mail: pangxq@bjpeu.edu.cn

中图分类号: P618.130
计量
- 文章访问数: 3992
- HTML全文浏览量: 820
- PDF下载量: 17
- 被引次数: 0
出版历程
- 收稿日期: 2004-03-18
- 刊出日期: 2004-07-25

Geochemical Evidences of Hydrocarbon Expulsion Threshold and Its Application

PANG Xiong-qi^{1, 2
,},
LI Su-mei^{1, 2},
JIN Zhi-jun¹,
LI Mao-wen^{1, 3}

1.
Key Laboratory for Hydrocarbon Accumulation Mechanism, University ofPetroleum, Ministry ofEducation, Beijing 102249, China
2.
Basin & Reservoir Research Center, University ofPetroleum, Beijing 102249, China
3.
Geological Survey ofCanada, Calgary

摘要

摘要: 排烃门限概念的提出为有效源岩的判识奠定了理论基础, 它在油气勘探与资源评价中具有重要意义.采用地球化学的方法论证了排烃门限的客观存在.研究表明, 源岩进入排烃门限后, 其反映生烃潜能的指标(S₁+S₂)/TOC、氢指数以及反映烃源岩残留烃量的指标氯仿沥青“A”都开始明显降低; 烃源岩中可溶有机质的化学成分、生物标志物的含量与分布特征也都发生明显的变化, 没有进入排烃门限的源岩可溶有机质与原油差别大, 进入门限后的源岩可溶有机质开始与原油组分较为一致.渤海湾盆地东营凹陷沙四段泥岩和页岩的排烃门限分别为2 200 m和2 000 m左右, 排烃强度分别为0~1 100 kg/m²和0~150 kg/m², 累积排出烃量为7.365×10⁸ t和1.435×10⁸ t.
- 排烃门限 /
- 资源评价 /
- 生烃潜力 /
- 烃类组分 /
- 生物标志物
Abstract: The concept of "Hydrocarbon expulsion threshold" is taken as an important theoretical base in the identification of effective source rock, and therefore, plays a significant role in petroleum exploration and resource assessment. Occurrence of hydrocarbon expulsion threshold is discussed by means of geochemical approaches. The results show that the parameters of (S₁+S₂)/TOC, HI showing source rock potential and the abundance of resident hydrocarbons-"A" decrease obviously with increasing depth once source rocks reach the expulsion threshold, and obvious variation of chemical composition as well as (abundance) and relative distribution of biomarkers can also be observed. Similar chemical compositions between crude oils and soluble organic matters are observed after the source rocks entered the expulsion threshold, however, the discrepancies are present within the source rocks below the expulsion threshold. Taking as an example of the Dongying depression of the Bohaiwan basin, the expulsion thresholds of Es⁴ mudstone and shale in Bamianhe area are about 2 200 and 2 000 m respectively, with expulsion intensity of 0-1 100 and 0-150 kg/m² and expulsed accumulative hydrocarbons of 7.365×10⁸ and 1.435×10⁸ t.
- hydrocarbon expulsion threshold /
- resource assessment /
- source rock potential /
- hydrocarbon composition /
- biomarker

HTML全文

图 1 排烃门限地质概念模型(据庞雄奇等, 2001)

Q_p.累积生烃量; Q_rm.残留烃临界饱和量; Q_r.实际残烃量; Q_e.源岩排烃总量; Q_ew, Q_ed, Q_es.源岩水溶相、扩散相、游离相排烃量

Fig. 1. Geological model for hydrocarbon expulsion threshold

下载: 全尺寸图片幻灯片

图 2 排烃门限存在的证据

a.煤化热模拟实验: A、B、C、D、E分别表示5种不同的煤岩; b.排油气门限数值模拟(海拉尔盆地煤源岩)

Fig. 2. Evidences for hydrocarbon expulsion threshold

下载: 全尺寸图片幻灯片

图 3 热演化过程中源岩生烃潜能变化特征

Fig. 3. Variation of hydrocarbon generation potential with depth

下载: 全尺寸图片幻灯片

图 4 氯仿沥青“A”与埋深关系

Fig. 4. Relationship of rock extracts verse depth

下载: 全尺寸图片幻灯片

图 5 八面河地区烃源岩、原油中生物标志物的分布特征反映排烃门限的客观存在

Fig. 5. Distribution of biomarkers in rock extracts and crude oils indicating hydrocarbon expulsion threshold

下载: 全尺寸图片幻灯片

图 6 排烃量计算理论模型

Fig. 6. Calculation model for expulsed hydrocarbons

下载: 全尺寸图片幻灯片

图 7 八面河地区沙四段泥岩、页岩的排烃强度等值线

Fig. 7. Hydrocarbons expulsion intensity of Es⁴ mudstone and shale of Bamianhe area

下载: 全尺寸图片幻灯片

表 1 不同层位烃源岩排烃量统计

Table 1. Total hydrocarbons expulsed from diverse strata of Bamianhe area

表 2 八面河地区源岩排烃量相对贡献大小评价

Table 2. Relative contribution of hydrocarbons expulsed from Bamianhe area

参考文献(21)

Burnham, A.K., Braun, R.L., 1990. Development of a detailed model of petroleum formation, destruction, and expulsion from lacustrine and marine source rocks. Organic Geochemistry, 16(1-3): 27-39. doi: 10.1016/0146-6380(90)90023-S
Cooles, G.P., Mackenzie, A.S., Quigley, T.M., 1986. Calculation of petroleum masses generated and expelled from source rocks. Organic Geochemistry, 10(1-3): 235-245. doi: 10.1016/0146-6380(86)90026-4
Davis, B.P., Bery, E.E., 1969. Analysis of oil and cap rock from Chanllenger(Sigsbee) Knoll. In: Ewing, W.M., ed., Initial Reports of the Deep Sea Drilling Project, 1: 415-499.
Lafargue, E., Espitalie, J., Jacobsen, T., et al., 1990. Experimental simulation of hydrocarbon expulsion. Organic Geochemistry, 16(1-3): 121-131. doi: 10.1016/0146-6380(90)90032-U
Lewan, M.D., Henry, M.E., Higley, D.K., et al., 2002. Material-balance assessment of the new Albany-Chesterian petroleum system of the Illinois basin. AAPG Bulletin, 86 (5): 754-777. https://pubs.er.usgs.gov/publication/70024630
Li, S.M., Li, M.W., Pang, X.Q., et al., 2003. Geochemistry of petroleum systems in the Niuzhuang south slope of Bohai Bay basin-Part 1: Source rock characterization. Organic Geochemistry, 34(3): 389-412. doi: 10.1016/S0146-6380(02)00210-3
Pang, X.Q., 1995. Theory of expulsion threshold controlling oil distribution and its application. Petroleum Industry Press, Beijing, 15-133(in Chinese).
Pang, X.Q., Chen, Z.M., Chen, F.J., 1993. Digital simulation of tectonic, thermal, hydrocarbon generation, residence and expulsion history, and source rock quantitative evaluation. Geological Publishing House, Beijing, 10-85(in Chinese).
Pang, X.Q., Ian, L., Wang, Y.C., et al., 2001. Theoretical study and application of hydrocarbon expulsion threshold of coal measures. Petroleum Industry Press, Beijing, 270 (in Chinese).
Pang, X.Q., Jiang, Z.X., Li, J.Q., et al., 2000. Geologic thresholds in the process of forming oil and gas reservoir and their functions of controlling petroleum. Journal of Universityof Petroleum, China, 24(4): 53-58(in Chinese with English abstract).
Pang, X.Q., Li, M.W., Li, S.M., et al., 2003. Geochemistry of petroleum systems in the Niuzhuang south slope of Bohai Bay basin-Part 2: Evidence for significant contribution of mature source rocks to" immature oils" in the Bamianhe field. Organic Geochemistry, 34(7): 931-950. doi: 10.1016/S0146-6380(03)00032-9
Snowdon, L.R., 1980. Resinite-A potential petroleum source in the Upper Cretaceous/Tertiary of the BeaufortMachenzie basin. In: Miall, A.D., ed., Facts and principles of world petroleum occurrence. Canadian Soc. of Petroleum Geologists Mem., 6: 509-521.
Snowdon, L.R., Powell, T.G., 1982. Immature oil and condensate-Modification of hydrocarbon generation model for terrestrial organic matter. AAPG Bulletin, 66(6): 775-788. https://pubs.geoscienceworld.org/aapgbull/article/66/6/775/37520/Immature-Oil-and-Condensate-Modification-of
Tissot, B.P., Welte, D.H., 1984. Petroleum formation and Occurrence. Springer-Verlag, New York, 23-78.
Ungerer, P., 1990. State of the art of research in kinetic modeling of oil formation and expulsion. Organic Geochemistry, 16(1-3): 1-25. doi: 10.1016/0146-6380(90)90022-R
Zhang, L.Y., Zhang, C.R., 1999. Origins of immature oils and related petroleum systems: Case studies from the southern slope of Niuzhuang sag, Jiyang depression. Petroleum Industry Press, Beijing, 35-110(in Chinese).
庞雄奇, 1995. 排烃门限控油气理论与应用. 北京: 石油工业出版社, 15-133.
庞雄奇, 陈章明, 陈发景, 1993. 含油气盆地地史、热史、生留排烃史数值模拟研究与烃源岩定量评价. 北京: 地质出版社, 10-85.
庞雄奇, Ian, L., 王雅春, 等, 2001. 煤系源岩排烃门限理论研究与应用. 北京: 石油工业出版社, 270.
庞雄奇, 姜振学, 李建青, 等, 2000. 油气成藏过程中的地质门限及其控油气作用. 石油大学学报, 24(4): 53-58. https://www.cnki.com.cn/Article/CJFDTOTAL-SYDX200004012.htm
张林晔, 张春荣, 1999. 低熟油生成机理及成油体系-以济阳坳陷牛庄洼陷南部斜坡为例. 北京: 石油工业出版社, 35-110.
