库车坳陷迪那2构造油气运聚模拟实验

张振红; 吕修祥; 李建交; 彭更新; 孙冬胜; 雷刚林; 杨明慧

库车坳陷迪那2构造油气运聚模拟实验

张振红^{1, 2,},
吕修祥^{1, 2},
李建交^{1, 2},
彭更新^{1, 3},
孙冬胜^{1, 2},
雷刚林³,
杨明慧^{1, 2}

1.
石油大学盆地与油藏研究中心, 北京 102249
2.
石油大学石油与天然气成藏机理教育部重点实验室, 北京 102249
3.
中国石油塔里木油田分公司, 新疆库尔勒 841000

基金项目:

国家“十五”重点科技攻关项目“塔里木盆地大中型气田勘探开发关键技术研究”项目 2001BA605A-02

详细信息

作者简介:
张振红(1977-), 女, 硕士, 矿产普查与勘探专业.E-mail: Zhangzhenh7611@sohu.com

中图分类号: P618.130
计量
- 文章访问数: 3867
- HTML全文浏览量: 1011
- PDF下载量: 12
- 被引次数: 0
出版历程
- 收稿日期: 2004-03-19
- 刊出日期: 2004-07-25

Experimental Evidence of Oil and Gas Migration and Accumulation in Dina 2 Structure of Kuqa Depression

ZHANG Zhen-hong^{1, 2
,},
LU: Xiu-xiang^{1, 2},
LI Jian-jiao^{1, 2},
PENG Geng-xin^{1, 3},
SUN Dong-sheng^{1, 2},
LEI Gang-lin³,
YANG Ming-hui^{1, 2}

1.
Basin and Reservoir Research Centre, University of Petroleum, Beijing 102249, China
2.
Key Laboratory for Hydrocarbon Accumulation Mechanism, University of Petroleum, Ministry of Education, Beijing 102249, China
3.
Branch of Tarim Oilfield Company, CNPC, Kuerle 841000, China

摘要

摘要: 为了研究油气运聚过程, 以迪那2构造为地质模型, 在构造特征、储盖组合、油气来源分析的基础上建立油气运聚过程物理模拟的二维实验模型.通过模拟实验, 揭示: (1)断层是迪那2构造中油气运移的主要通道; (2)泄压区是油气运移的有利指向区; (3)毛管力及浮力在渗透性相近的砂岩中起重要作用; (4)油气总是选择优势通道运移, 在沿断层运移的同时, 也向两侧砂体中扩散; (5)油驱水之后的气驱油运移通道具有继承性的特点.
- 迪那2构造 /
- 优势通道 /
- 油气运聚 /
- 模拟实验 /
- 库车坳陷
Abstract: Two dimensional experimental model of hydrocarbon migration and accumulation has been built up according to the geological model of the Dina 2 structure including the database of structure, assemble of reservoir and caprock, and hydrocarbon sources. The results indicate that (1) faults are predominant pathways for oil and gas migration in the Dina 2 structure; (2) the pressure released zones are available for oil and gas migration; (3) capillary and buoyancy play an important role in sandstone with similar permeability; (4) hydrocarbon migrates always along the predominant pathways, such as faults and associated sandstone in both sides; (5) pathways of oil and gas migration have the nature of succession, such as oil driving water and following gas driving oil.
- Dina 2 structure /
- predominant pathway /
- oil and gas migration and accumulation /
- simulation test /
- Kuqa depression

HTML全文

图 1 过迪那2井构造剖面

Fig. 1. Strucure profile over Dina 2 well

下载: 全尺寸图片幻灯片

图 2 迪那2构造砂层-断裂输导体系油气运移和聚集实验模型

Fig. 2. Experimental model about oil and gas migfration and focus in sand-fault transport system of Dina 2

下载: 全尺寸图片幻灯片

图 3 第一组实验结果

Fig. 3. Conventional diagram of the first experiment

下载: 全尺寸图片幻灯片

图 4 第二组实验结果

Fig. 4. Conventional diagram of the second experiment

下载: 全尺寸图片幻灯片

表 1 模拟实验中砂层物性参数

Table 1. Physical property parameters of sand bed in simulating experiment

表 2 气驱后各层含油饱和度

Table 2. Oil saturation of each layer after gas drive

参考文献(16)

Li, M.C., 1994. Migration of oil and gas(the second edition). Petroleum Industry Press, Beijing, 127-164(in Chinese).
Li, M.C., 2000. The investigative actual state and primary progress of oil and gas migration. World Oil Industry, (1): 24-27(in Chinese with English abstract).
Lǜ, X.X., 2000. Experimental study on losing amount of oil migration along the surface of unconformity in Tarim basin. Journal of the University of Petroleum, China, 24(4): 112-114(in Chinese with English abstract).
Ma, Y.J., Xie, H.W., Cai, Z.Z., et al., 2003. The geology feature of Dina 2 gas field, Kuche depression. Natural Gas Geoscience, 14(5): 371-374(in Chinese with English abstract).
Xin, R.C., Jiang, Z.X., Li, S.T., 2002. Physical modeling of secondary oil migration and accumulation in deltaic sandstone reservoiv and its result analysis. Earth Science—Journal ofChina University of Geosciences, 27(6): 780-782(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DQKX200206023.htm
Zeng, J.H., Jin, Z.J., Wang, H.Y., et al., 2000. Physical simulation of the secondary migration and accumulation oil and gas. Petroleum Industry Press, Beijing(in Chinese).
Zha, M., 1997. The secondary migration and accumulation oil and gas in rifted basin. Geological Publishing House, Beijing, 9-16(in Chinese).
Zhang, H.F., 1993. The investigative articles collection of oil and gas migration. Petroleum Industry Press, Beijing(in Chinese).
李明诚, 1994. 石油与天然气运移(第二版). 北京: 石油工业出版社, 127-164.
李明诚, 2000. 油气运移研究的现状及主要进展. 世界石油工业, (1): 24-27. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT200503001.htm
吕修祥, 2000. 塔里木盆地不整合面石油运移散失量的实验研究. 石油大学学报, 24(4): 112-114. https://www.cnki.com.cn/Article/CJFDTOTAL-SYDX200004028.htm
马玉杰, 谢会文, 蔡振忠, 等, 2003. 库车坳陷迪那2气田地质特征. 天然气地球科学, 14(5): 371-374. https://www.cnki.com.cn/Article/CJFDTOTAL-TDKX200305008.htm
辛仁臣, 姜振学, 李思田, 2002. 三角洲前缘砂体中石油二次运移与聚集过程物理模拟及结果分析. 地球科学——中国地质大学学报, 27(6): 780-782. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX200206023.htm
曾溅辉, 金之钧, 王洪玉, 等, 2000. 油气二次运移和聚集物理模拟. 北京: 石油工业出版社.
查明, 1997. 断陷盆地油气二次运移与聚集. 北京: 地质出版社, 9-16.
张厚福, 1993. 油气运移研究论文集. 北京: 石油工业出版社.
