应用多重分形滤波技术提取致矿地球化学异常: 以西南“三江”南段Cu、Zn致矿异常提取为例

陈永清; 张生元; 夏庆霖; 李文昌; 卢映祥; 黄静宁

应用多重分形滤波技术提取致矿地球化学异常: 以西南“三江”南段Cu、Zn致矿异常提取为例

陈永清^{1, 2,},
张生元³,
夏庆霖⁴,
李文昌⁵,
卢映祥⁵,
黄静宁¹

1.
中国地质大学地球科学与资源学院, 北京 100083
2.
中国地质调查局发展研究中心, 北京 100037
3.
石家庄经济学院经贸学院, 河北石家庄 050031
4.
中国地质大学资源学院, 湖北武汉 430074
5.
云南省地质调查院, 云南昆明 650051

基金项目:

国家“十五”科技攻关课题 2003BA612A-02

国土资源大调查项目 200110200009

详细信息

作者简介:
陈永清(1960—), 男, 博士, 教授, 主要从事矿产综合定量勘查与评价研究.E-mail：Fzcyongqing@cgs.gov.cn

中图分类号: P628
计量
- 文章访问数: 3911
- HTML全文浏览量: 673
- PDF下载量: 15
- 被引次数: 0
出版历程
- 收稿日期: 2006-03-06
- 刊出日期: 2006-11-25

Application of Multi-Fractal Filtering to Extraction of Geochemical Anomalies from Multi-Geochemical Backgrounds: A Case Study of the Southern Section of "Sanjiang Ore-Forming Zone", Southwestern China

1.
Faculty of Earth Sciences and Mineral Resources, China University of Geosciences, Beijing 100083, China
2.
Development and Research Center, China Geological Survey, Beijing 100037, China
3.
School of Economics and Commerce, Shijiazhuang University of Economics, Shijiazhuang 050031, China
4.
Faculty of Earth Resources, China University of Geosciences, Wuhan 430074, China
5.
Yunnan Geological Survey, Kunming 650051, China

摘要

摘要: 西南“三江”南段位于印度板块与扬子板块的结合带, 是特提斯-喜马拉雅成矿域的重要组成部分.在多旋回的构造岩浆活动过程中, 形成了复杂的成矿地质地球化学背景和丰富的有色金属和贵金属矿产.正是这种复杂的地质地球化学背景, 使得应用地质统计学方法提取致矿地球化学异常遇到了挑战.为此, 多重分形滤波技术被引进, 试图从复杂的多重地球化学背景中有效地分离与成矿有关的Cu、Zn异常.研究表明: (1) 由于研究区存在多重地球化学背景, 克里格方法揭示的Cu、Zn剩余异常通常是受区域线形构造控制的区域异常, 多重分形滤波技术则揭示了与矿化有关的Cu、Zn局部致矿异常; (2) Cu致矿异常的提取表明, 多重分形滤波技术能够克服某些岩性(譬如玄武岩) 引起的Cu高背景的影响, 并从多重地球化学背景中有效提取致矿异常, 包括低背景中的弱异常和隐蔽异常; (3) 运用多重分形滤波技术清晰揭示了一系列Zn原始数据图上没有显示的、规模不等的NNE向Zn矿化异常带, 其中那条穿越整个研究区的Zn矿化异常带含有金顶巨型Pb-Zn矿床和一系列矿床、矿点、矿化点.整个研究工作是基于MORPAS3.0软件系统实现的.
- 多重分形滤波技术 /
- 多重地球化学背景 /
- Cu-Zn致矿异常 /
- 西南“三江”成矿带
Abstract: The southern section of "Sanjiang ore-forming zone" (the western Yunnan terrain), southwestern China, located at the joined belt between the Indian plate and Yangtze plate, is an important area of eastern Tethyan tectonic ore-forming domain. The polycyclic tectono-magmatic activities resulted both in the diversity of ore-forming geochemical background, and in the numerous base metal deposits and precious metal deposits, including a few such world-class deposits as the Jinding Pb-Zn deposit and the Laowangzhai Au deposit within the section. Such a complex geochemical background challenges us with the geostatistical extraction of geochemical anomalies for the mineralization purpose. For this, the multi- fractal filtering (S-A method) technique is introduced to isolate effectively the Cu and Zn anomalies related to mineralization in the complex multi-geochemical background. The following three research results are obtained in this study: (1) In the complicated geochemical background, the residual anomalies of Cu and Zn uncovered by Kriging are typical of the regional anomalies controlled by the regional linear fractural pattern; but the S-A method reveals the local anomalies of Cu and Zn associated with mineralization; (2) The separation of the Cu anomaly from its background demonstrates that the S-A method could effectively identify the high geochemical background of Cu from basalts and extract the Cu anomalies from multi-geochemical background, including weak and hidden Cu anomalies from their low background; (3) A few NNE-trending Zn mineralized and anomalous belts containing the super-large Jinding Pb-Zn deposit and a series of some other Pb-Zn deposits, that are absent at the Zn original data map, are clearly shown at the S-A anomalous map. This discovery presents us with not only new areas for prospecting Cu-Pb-Zn deposits but also new perspectives for the research into new ore-controlling factors, for the regional distribution of Pb-Zn deposits, which may include NNE-trending hidden fractures. All the research work is completed with the help of MORPAS 3.0.
- multi-fractal filtering techniques /
- multi-geochemical background /
- Cu-Zn geochemical anomalies /
- Sanjiang ore-forming zone of southwestern China

HTML全文

图 1 西南“三江”南段地质矿产简图(据云南省地质调查院 1∶50 万数字地质图编绘, 2003)

Kz.新生代碎屑岩、局部夹火山岩; Mz.中生代碎屑岩、碳酸盐岩、局部夹火山岩; Pz.古生代碳酸盐岩、碎屑岩、夹火山岩; Pt.元古宇变质岩; 1.新近纪-古近纪安山岩; 2.二叠纪玄武岩; 3.中酸性岩体; 4.基性岩体; 5.断层; 6.地质界线; 7.国界; 8.省界; 9.湖泊

Fig. 1. Geological map and the distribution of the known mineral deposits in southern region of "Sanjiang ore-forming zone", southwestern China

下载: 全尺寸图片幻灯片

图 2 (a) Cu原始含量; (b) IDW方法获取的Cu剩余异常

Fig. 2. (a) Cu original concentration; (b) Cu residual anomaly using the IDW method

下载: 全尺寸图片幻灯片

图 3 Cu的lnA (> S) -lnS图

使用最小二乘法模拟4条具有不同斜率的线段, 并分别获取3个临界点: lnS₀=9.05, lnS₁=7.3, lnS₂=6.5

Fig. 3. ln-ln plot showing the relationships between power spectrum value S and area A (> S) on Cu

下载: 全尺寸图片幻灯片

图 4 S-A方法获取的Cu异常

Fig. 4. Cu anomaly obtained using the S-A method

下载: 全尺寸图片幻灯片

图 5 (a) Zn原始含量; (b) IDW方法获取的Zn剩余异常

Fig. 5. (a) Zn original concentration; (b) Zn residual anomaly using the IDW method

下载: 全尺寸图片幻灯片

图 6 Zn的lnA (> S) -lnS图

使用最小二乘法模拟3条具有不同斜率的线段, 并分别获得2个临界点: lnS₀=12.52, lnS₁=11.49

Fig. 6. ln-ln plot showing the relationships between power spectrum value S and area A (> S) on Zn

下载: 全尺寸图片幻灯片

图 7 S-A方法获取的Zn异常

Fig. 7. Zn anomaly obtained using the S-A method

下载: 全尺寸图片幻灯片

参考文献(16)

Chen, Y. Q., Chen, J. G., Wang, X. Q., 2006. GIS based integrated quantitative assessment of mineral resources. Geological Bulletin of China (in Press, in Chinese with English abstract).
Chen, Y. Q., Lu, Y. X., Xia, Q. L., 2005. Geochemical characteristics of the Hetaoping Pb-Zn deposit, Baoshan area, Yunnan Province, and its genetic model and ore prospecting pattern. Geology in China, 32 (1): 90-99 (in Chinese with English abstract).
Chen, Y. Q., Xia, Q. L., Liu, H. G., 2003. Geochemical characteristics of Pt-Pd-Cu ore-bearing formations in eastern Yunnan and analysis of their ore potentiality. Geology in China, 30 (3): 225-234 (in Chinese with English abstract).
Cheng, Q. M., 2001. Selection of multifractal scaling breaks and separation of geochemical and geophysical anomalies. Journal of China University of Geosciences, 12 (1): 54-59.
Cheng, Q. M., 2002. Geodata analysis system (Geo Das) for mineral exploration: User 'guide and exercise manual. Material for thetraining workshop on Geo Das held at York University, November1-3.289 (http://www.gisworld.org/geodas).
Cheng, Q. M., 2004. A new model for quantifying anisotropic scale invariance and for decomposition of mixing patterns. Mathematical Geology, 36 (3): 345-360. doi: 10.1023/B:MATG.0000028441.62108.8a
Cheng, Q. M., 2006. Singularity-generalized self-similarity-fractal spectrum (3S). Earth Science—Journal of China University of Geosciences, 31 (3): 337-348 (in Chinese with English abstract).
Cheng, Q. M., Xu, Y. G., Grunsky, E., 2000. Integrated spatial and spectrum analysis for geochemical anomaly separation. Nature Resources Research, 9 (1): 43-56. doi: 10.1023/A:1010109829861
Gorelov, D. A., 1982. Quantitative characteristics of geologic anomalies in assessing ore capacity. International Geology Review, 24 (4): 457-465. doi: 10.1080/00206818209452430
Herzfeld, U. C., Overbeck, C., 1999. Analysis and simulation of scale-dependent fractal surfaces with application to seafloor morphology. Computer & Geosciences, 25 (9): 963-978.
Lovejoy, S., Schertzer, D., Gagnon, J. S., et al., 2005. Multifractal simulation of the earth's surface and interior: Anisotropic singularities and morphology. In: Cheng, Q. M., Bonham-Carter, G., eds., Proceeding of IAMG: GIS and spatial analysis, 1: 37-54.
Xu, Y. G., Cheng, Q. M., 2001. A multifractal filter technique for geochemical data analysis from Nova Scotia, Canada. Geochemistry: Exploration, Analysis and Environment, 1 (2): 1-12.
陈永清, 陈建国, 汪新庆, 2006. 基于GIS的矿产资源综合定量评价. 地质通报(待刊).
陈永清, 卢映祥, 夏庆霖, 2005. 云南保山核桃坪铅锌矿床地球化学特征及其成矿模式与找矿模型. 中国地质, 32 (1): 90-99. https://www.cnki.com.cn/Article/CJFDTOTAL-DIZI200501012.htm
陈永清, 夏庆霖, 刘红光, 2003. 滇东Pt-Pd-Cu含矿建造地球化学特征及其含矿性分析. 中国地质, 30 (3): 225-234. doi: 10.3969/j.issn.1000-3657.2003.03.001
成秋明, 2006. 非线性成矿预测理论: 多重分形奇异性-广义自相似性-分形谱系模型与方法. 地球科学——中国地质大学学报, 31 (3): 337-348. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX200603008.htm
