Reservoir-Forming Mechanism of Coalbed Methane in Jincheng Anthracite
-
摘要: 通过晋城煤层气的规模开发、压裂煤层气井的解剖、井下煤层瓦斯抽放、构造地应力场研究、煤储层大裂隙系统“CT”式解剖与煤层气封闭保存条件研究, 发现3#煤储层内部存在大量煤层气包, 构造微破裂作用促使煤层气包之间广泛合并联通, 煤层气包内部储层的非均质性弱化, 渗透率增加, 煤层气包内部的游离气体比例增加, 流体压力系统边界逐渐清晰并形成煤层气藏. 揭示煤层气藏的成藏机制, 认识煤层气藏的内部细节特征, 促进了该区的煤层气开发技术进步, 提高了井下煤层瓦斯的抽放效率.Abstract: With the aim of studying reservoir-forming mechanism of coalbed methane (CBM) in the area of Jincheng, through the continuous development of coalbed methane in Jincheng, the dissection of fracturing coalbed methane wells, the extraction of underground coal seam gas, the study of tectonic stress field, the "CT"-dissection of the fracture system of coal reservoir and the sutdy of closed preservation conditions on coalbed methane, we found that there are a lot of CBM packages in 3 coal reservoir and these CBM packages merge together because of micro-structural breakdown. As a result, the heterogeneity of reservoir in CBM packages becomes weak; the permeability increases; the proportion of free gas increases in CBM package and the fluid pressure system gradually clears. Eventually, the above factors jointly contribute to the formation of the border of coalbed methane reservoir. The study on the accumulation mechanism of coalbed methane and the characteristics of the internal details of coalbed methane reservoir promotes the development of coalbed methane exploiting technology and improves the efficiency of extracting the underground coal seam gas.
-
图 1 晋城煤区成庄矿2314工作面3#煤储层剖面图
Fig. 1. No.3 coalseam profile of 2134 working face in Chengzhuang coalmine of Jincheng city
图 2 晋城煤区成庄矿二盘区3煤储层节理裂隙系统实测图
Fig. 2. The joint fissure system of Erpan section of Chengzhuang coalmine of Jincheng city messured on the spot
图 3 晋城无烟煤层气藏成藏机制示意图
a.孤立的煤层气包: A.煤层气包内部裂隙系统发育, 外生节理发育、气胀节理十分发育、内生裂隙发育.内部流体压力比外围高.体积规模一般为几百-几千m3; B.尚未发育煤层气包的部分.外生节理不发育、仅有少许内生裂隙、气胀节理欠发育.在一定的体积空间内尚未形成一致的流体压力系统.b.构造微破裂作用促使煤层气包之间联合: ①煤层气包; ②成群成带的煤层气包.成群的煤层气包沿大裂隙系统中的主干节理成带发育, 在两组节理相互交叉地带煤层气包联通变大.c.构造微破裂作用促使煤层气包进一步扩大联合形成煤层气藏(水力压裂可以局部起到类似效果) : ①煤层气包; ②成群成带的煤层气包; ③构造作用产生的通道
Fig. 3. The mechanism modle of coalbed meathne reservoir Jincheng anthracite
-
Coal Staff Room of Wuhan Institute of Geology, 1979. Coal geology. Geological Publishing House, Beijing(in Chinese). Du, S.M., Hu, G.C., LI, J.M., et al., 2004. Natural gas resources exploration. Petroleum Industry Press, Beijing (in Chinese). Hou, G.J., Wang, S.W., Zhang, X.J., 2005. Investigation on joints in the coalbeds in Chengzhuang coal mine of Jincheng coal-bearing district and its significance. Nature Gas Industry, 25(1): 41-43(in Chinese with English abstract). Li, M.C., Liang, S.Z., Zhao, K.J., 1996. Exploration and development of coalbed methane. Geological Publishing House, Beijing(in Chinese). Qian, K., Zhao, Q.B., Wang, Z.C., et al., 1996. Coalbed methane exploration and development theory and experimental and measuring technique. Petroleum Industry Press, Beijing(in Chinese). Song, Y., Liu, S.B., Hong, F., 2005. Forming geological conditions of coalbed methane reservoir and types of gas reservoir. In: Reservoir-forming mechanism of coalbed methane and theoretical foundation of economic exploitation. Science Press, Beijing(in Chinese). Stach, E., Mackowsky, M.T.H., Teichmuller, M., 1982. Stach's textbook of coal petrology, 3rd. Gebruder Borntraeger, Stuttgart, Berlin. Wang, H.Y., Liu, H.L., Zhao, Q.B., et al., 2005. Enrichment and reservoiring laws of the coalbed methane. Petroleum Industry Press, Beijing(in Chinese). Wang, S.W., Chen, Z.H., Zhang, M., et al., 1997. Coal reservoir petrophysical used in the coalbed methane exploration and selecting districts: As an example to a certain number of coal mining in North China. China University of Geosciences Press, Wuhan(in Chinese). Wang, S.W., Duan, L.X., Chen, Z.H., et al., 1999. Research into coalbed methane pool trap and its significance: An example of carboniferous-permian coalbed methane pool trap in North China. Earth Science-Journal of China University of Geosciences, 24(1): 49-53(in Chinese with English abstract). Wang, S.W., Duan, L.X., Zhang, M., et al., 2000. Parameters and flow chart for coalbed methane pool analysis. Earth Science-Journal of China University of Geosciences, 25 (6): 613-616(in Chinese with English abstract). Wang, S.W., Hou, G.J., Zhang, M., 2005. Analysis of the visible fracture system of coalseam in Chengzhuang coalmine of Jincheng city, Shanxi Province. Chinese Science Bulletin, 50(Suppl.): 45-51. Wang, S.W., Zhang, M., Zhuang, X.L., 1996. On the trap types of coalbed methane pools. Proceedings of international mining tech'96 symposium, 257-266. Wang, Y.C., Kong, J.X., Li, H.P., et al., 2004. Geology of gas reservoir. Petroleum Industry Press, Beijing(in Chinese). Yang. Q., Han, D.X., Ren, D.Y., 1979. Coal geology(list). Coal Industry Press, Beijing(in Chinese). Zhang, X.M., Zhuang, J., Zhang, S.A., 2002. Coalbed methane geology and resource evaluation in China. Science Press, Beijing(in Chinese). 杜尚明, 胡光灿, 李景明, 等, 2004. 天然气资源勘探. 北京: 石油工业出版社. 侯光久, 王生维, 张先进, 2005. 晋城成庄矿煤层中节理研究及其意义. 天然气工业, 25(1): 41-43. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG20050100F.htm 李明潮, 梁生正, 赵克镜, 1996. 煤层气及其勘探开发. 北京: 地质出版社. 钱凯, 赵庆波, 汪泽成, 等, 1996. 煤层甲烷气勘探开发理论与实验测试技术. 北京: 石油工业出版社. 宋岩, 柳少波, 洪峰, 2005. 煤层气成藏地质条件及气藏类型. 见: 煤层气成藏机制及经济开采理论基础. 北京: 科学出版社. 王红岩, 刘洪林, 赵庆波, 等, 2005. 煤层气富集成藏规律. 北京: 石油工业出版社. 王生维, 陈钟惠, 张明, 等, 1997. 煤储层岩石物理研究与煤层气勘探选区: 以华北若干煤区为例. 武汉: 中国地质大学出版社. 王生维, 段连秀, 陈钟惠, 等, 1999. 煤层气藏的封闭及其研究意义——华北石炭-二叠系煤层气藏封闭特征. 地球科学——中国地质大学学报, 24(1): 49-53. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX901.009.htm 王生维, 段连秀, 张明, 等, 2000. 煤层气藏分析的参数与流程. 地球科学——中国地质大学学报, 25(6): 613616. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX200006013.htm 王允诚, 孔金详, 李海平, 等, 2004. 气藏地质. 北京: 石油工业出版社. 武汉地质学院煤田教研室, 1979. 煤田地质学(上). 北京: 地质出版社. 杨起, 韩德馨, 任德贻, 1979. 中国煤田地质学(上册). 北京: 煤炭工业出版社. 张新民, 庄军, 张遂安, 2002. 中国煤层气地质与资源评价. 北京: 科学出版社. -
