Lithosphere Stretching Model of Deep Water in Qiongdongnan Basin, Northern Continental Margin of South China Sea, and Controlling of the Post-Rift Subsidence
-
摘要: 为了揭示盆地深水区演化及裂后期大规模沉降的成因机制, 在琼东南盆地典型的、高品质地震剖面地质构造精细解释基础上, 结合岩石圈变形的挠曲悬臂梁模型和挠曲均衡模型, 应用正演和反演模拟技术, 定量恢复了该盆地所处地区的上地壳、地壳以及岩石圈的伸展程度.结果表明, 琼东南盆地自陆架边缘到深水坳陷区, 岩石圈上地壳的伸展系数较小, β值最大为1.23~1.32;整个地壳的伸展系数变化较大, 盆地边缘隆起区的β值在1.1~1.2之间, 向盆地中部β值逐渐增大到3.14;而对整个岩石圈而言, 其伸展系数β值由陆架到陆坡深水盆地也从1.2逐渐增大到4.2.根据对南海地区的构造及岩石圈和地壳的结构分析认为, 与McKenzie的岩石圈均一伸展以及由热控制的裂后期缓慢沉降过程不同的是, 上述与深度相关的岩石圈伸展减薄是由南海西北次海盆扩张过程中深部物质的离散上涌流动所导致的下地壳的快速而强烈的塑性流动所引起的, 并由此建立了琼东南盆地的形成演化模式, 来解释和探讨深水坳陷区及裂后期快速而大规模沉降的成因机制.Abstract: In order to thoroughly explain the mechanism of significant subsidence in deep waters of Qiongdongnan basin, a rifted continental marginal basin, we analyzed the high resolution seismic reflection profiles in the study area, and conduct a quantitative study on upper-crust, whole crust and whole lithosphere stretching and thinning respectively by incorporating flexural cantilever model and flexural cantilever isostasy model and using both forward and reverse basin modeling techniques Our integrated analysis shows that the extension in brittle upper crust decreases from shelf to deep basin. And the largest amount of stretching factor β is 1.23-1.32; the whole crust stretching factors change from β=1.1-1.2 of uplifts in basin margin to β=3.14 in central basin; And estimates of the whole lithosphere stretching factor change from β=1.2 on continental shelf to β=4.2 in deep basin. Theanalysis of tectonic geology involving lithosphere and crust, depth-dependent stretching of lithosphere in Qiongdongnan basin described above is closely related with sea floor spreading of northwestern South China Sea, which caused the discrete upwelling flow of middle and deep substance, then it resulted in the plastic flow of the lower crust rapidly and intensely. This model is different from the depth-uniform lithosphere stretching model and its slow post-rift subsidence controlled by geothermal isostatic re-equilibration (McKenzie, 1978). The formation and evolution model of Qiongdongnan basin is proposed to interpret the mechanism of rapid and large-amplitude post-rift subsidence in deep water.
-
图 1 琼东南盆地区域地质背景及其构造单元划分(据龚再升等, 2004)
1.新生代盆地(E-Q); 2.海底火山弧; 3.海陆边界; 4.盆地中的隆起、低凸起; 5.俯冲及仰冲带; 6.海壳及磁条带、扩张轴; 7.断裂
Fig. 1. Regional geological setting and its tectonic unit division of Qiongdongnan basin
图 2 琼东南盆地地层及盆地演化综合柱状图
Fig. 2. Comprehensive column map of strata and basin evolution of Qiongdongnan basin
图 3 岩石圈内不同深度的伸展计算方法示意图(Davis and Kusznir, 2004)
Fig. 3. Schematic diagram illustrating the three methods used to estimate stretching at depth within the lithosphere
图 4 岩石圈变形的挠曲悬臂梁模型(Kusznir et al., 1991)
Fig. 4. A schematic diagram of the flexural-cantilever model for lithosphere deformation
图 5 琼东南盆地地震剖面及其地质构造解释(位置见图 1)
Fig. 5. Seismic profile and geological structure interpretation across the Qiongdongnan basin
图 6 正演及挠曲回剥反演模拟琼东南盆地A-B剖面形态及其伸展系数β
a.正演模拟的裂陷期剖面; b.裂陷期上地壳伸展系数β剖面; c.挠曲回剥反演恢复的现今剖面形态; d.反演到裂后初期(21 Ma) 时的剖面形态; e.控制热演化的伸展系数β剖面
Fig. 6. The setions and and the stretching factor profile by forward modeling and flexural backstripping reverse modeling ofA-B section in Qiongdongnan basin
图 7 琼东南盆地A-B剖面地壳结构及岩石圈不同深度的伸展和减薄系数
a.琼东南盆地剖面A-B的地壳结构; b.整个岩石圈, 整个地壳以及上地壳的伸展系数β变化剖面; c.整个岩石圈.整个地壳以及上地壳的减薄系数(1-1/β变化剖面
Fig. 7. The crustal structure and the stretching and thinning factors of different depths within the lithosphere of A-B sectionin Qiongdongnan basin
图 8 琼东南盆地A-B剖面裂后阶段不同时期沉降速率曲线(位置见图 1)
Fig. 8. The subsidence rate of different post-rift stages of the A-B section in Qiongdongnan basin
表 1 正演和反演模拟所用的属性参数
Table 1. Property parameters used in the forward modeling and reverse modeling
-
Alessandro, O. S., Eris, C. J., Arturo, A. M. J., et al., 1997. The petroleum potential of deep-water Northwest Palawan Block GSEC66. Journal of Asian Earth Sciences, 15 (2-3): 217-240. Baxter, K., Cooper, G. T., Hill, K. C., et al., 1999. Late Ju-rassic subsidence and passive margin evolution in theVulcan sub-basin, North-West Australia: Constraints from basin modelling. Basin Research, 11 (2): 97-111. doi: 10.1046/j.1365-2117.1999.00088.x Briais, A., Patriat, P., Tapponnier, P., 1993. Updated interpretation of magnetic anomalies and seafloor spreading stages in the South China Sea: I mplications for the Tertiary tectonics of Southeast Asia. Journal of Geophysical Research, 98 (B4): 6299-6328. doi: 10.1029/92JB02280 Cande, S. C., Kent, D. V., 1995. Revised calibration of the geomagnetic polarity timescale for the Late Cretaceous and Cenozoic. Journal of Geophysical Research, 100 (B4): 6093-6095. doi: 10.1029/94JB03098 Clift, P., Lin, J., Barckhausen, U. E., 2002. Evidence of low flexural rigidity and low viscosity lower continental crust during continental break-up in the South China Sea. Marine and Petroleum Geology, 19 (8): 951-970. doi: 10.1016/S0264-8172(02)00108-3 Cui, T., Xie, X. N., Ren, J. Y., et al., 2008. Dynamic mechanismof anomalous post-rift subsidence in the Yinggehai basin. Earth Science—Journal of China University ofGeosciences, 33 (3): 349-356 (in Chinese with Englishabstract). doi: 10.3799/dqkx.2008.046 Davis, M., Kusznir, N. J., 2004. Depth-dependent lithospheric stretching at rifted continental margins. In: Karner, G. D., ed., Proceedings of NSF rifted margins theoretical institute. Columbia University Press, New York, 92-136. Driscoll, N. W., Karner, G. D., 1998. Lower crustal extension across the northern Carnarvon basin, Australia: Evidence for an eastward dipping detachment. Journal of Geophysical Research, 103 (B3): 4975-4991. doi: 10.1029/97JB03295 Fang, N. Q., Yao, B. C., Wan, L., et al., 2007. The velocity structure of the lithosphere and the origin of sedimentary basins in the South China and northern margin of the South China Sea. Earth Science—Journal of China University of Geosciences, 32 (2): 147-154 (in Chinesewith English abstract). Gong, Z. S., Li, S. T., Wang, J. Y., et al., 2004. Dynamic research of oil and gas accumulation in northern marginal basins of South China Sea. Science Press, Beijing, 3-45 (in Chinese). Gong, Z. S., Li, S. T., Xie, T. J., et al., 1997. Continental marginal basins analysis and hydrocarbon accumulation of the northern South China Sea. Science Press, Beijing, 1-192 (in Chinese). He, J. X., Xia, B., Shi, X. B., et al., 2006. Prospect and progress for oil and gas in deep waters of the world, and the potential and prospect foreground for oil and gas in deep waters of the South China Sea. Natural Gas Geoscience, 17 (6): 747-752, 806 (in Chinese with English abstract). Jeremy, B., 2001. Productivity shortfall puts deepwater exploration gains in perspective. Offshore, 61 (4): 84. Kusznir, N. J., Hunsdale, R., Roberts, A. M., et al., 2005. Timing and magnitude of depth-dependent lithosphere stretching on the southern Lofoten and northern Vϕring continental margins offshore Mid-Norway: I mplications for subsidence and hydrocarbon maturation at volcanic rifted margins. In: Doré, A. G., Vining, B. A., eds, Pe-troleum geology: North-West Europe and global per-spectives—Proceedings of the6th Petroleum GeologyConference. Geological Society, London, 767-783. Kusznir, N. J., Karner, G. D., 2007. Continental lithospheric thinning and breakupin response to upwelling divergent mantle flow: Application to the Woodlark, Newfoundland and Iberia margins. Geological Society, London, Special Publications, 282: 389-419. doi: 10.1144/SP282.16 Kusznir, N. J., Marsden, G., Egan, S. S., 1991. A flexuralcantilever simple-shear/pure-shear model of continental lithosphere extension. In: Roberts, A. M., Yielding, G., Freeman, B., eds, The geometry of normal faults. Geological Society, London Special Publications, 56: 41-60. Li, S. T., Lin, C. S., Zhang, Q. M., et al., 1998. Episodic rifting andits dynamical process in north continental margin of South China Sea, and the tectonic event from 10 Ma. Science Bulletin, 43 (8): 797-810 (in Chinese). McKenzie, D. P., 1978. Some remarks on the development of sedimentary basins. Earth and Planetary Science Letters, 40 (1): 25-32. doi: 10.1016/0012-821X(78)90071-7 Pang, X., Chen, C. M., Peng, D. J., et al., 2008. Basic geology of Baiyun deep-water areainthe northern South China Sea. China Offshore Oil and Gas, 20 (4): 215-222 (in Chinese with English abstract). Pettingill, H. S., Weimer, P., 2002. Deepwater remains immature frontier. Offshore, 62 (10): 48-50. Ren, J. Y., Tamaki, K., Li, S. T., et al., 2002. Late Mesozoic and Cenozoic rifting and its dynamic setting in eastern China and adjacent areas. Tectonophysics, 344 (3-4): 175-205. doi: 10.1016/S0040-1951(01)00271-2 Roberts, A. M., Lundin, E. R., Kusznir, N. J., 1997. Subsidence of the Vϕring basin and the influence of the Atlantic continental margin. Journal ofthe Geological Society, 154 (3): 551-557. doi: 10.1144/gsjgs.154.3.0551 Sclater, J. G., Christie, P. A. F., 1980. Continental stretching: An explanation of the post-Mid-Cretaceous subsidence of the central North Sea basin. Journal of Geophysical Research, 85 (B7): 3711-3739. doi: 10.1029/JB085iB07p03711 Sun, Z., Pang, X., Zhong, Z. H., et al., 2005. Dynamics of Tertiary tectonic evolution of the Baiyun sag in the Pearl River Mouth basin. Earth Science Frontiers, 12 (4): 489-498 (in Chinese with English abstract). Sun, Z., Sun, L. T., Zhou, D., et al., 2009. Discussion on the South China Sea evolution and lithospheric breakup through 3D analogue modeling. Earth Science—Journalof China University of Geosciences, 34 (3): 435-447 (in Chinese with English abstract). doi: 10.3799/dqkx.2009.049 Tao, W. X., Ding, F., He, S. B., et al., 2006. Deepwater petroleum exploration abroad and deepwater petroleum. Geological Science and Technology Information, 25 (6): 59-66 (in Chinese with English abstract). Xie, X. N., Müller, R. D., Li, S. T., et al., 2006. Origin of anomalous subsidence along the northern South China Sea margin and its relationship to dynamic topography. Marine and Petroleum Geology, 23 (7): 745-765. doi: 10.1016/j.marpetgeo.2006.03.004 Yao, B. C., 1998. Crust structure of the northern margin of the South China Sea and its tectonic significance. Marine Geology & Quaternary Geology, 18 (2): 1-16 (inChinese with English abstract). Yao, B. C., 2002. Deformation characteristics of break off and separation of continental lithosphere. In: Gao, S., Li, J. B., eds., Formation and evolution of Chinese marginal sea. China Ocean Press, Beijing, 1-13 (in Chinese). Yao, B. C., Wan, L., Wu, N. Y., 2005. Cenoziic tectonic evolution and the 3D structure of the lithosphere of the South China Sea. Geological Bulletin of China, 24 (1): 1-8 (in Chinese with English abstract). Zhang, J., Wang, J. Y., 2000. Deep geodynamic characteristics of tectonic spreading in continental margin of the northern South China Sea. Sciencein China (Series D), 30 (6): 561-567 (in Chinese). Zhou, D., Sun, Z., Chen, H. Z., 2007. Tectonic features of world's major deep-water oil/gas fields and their enlightenment to deep-water explorationin northern South China Sea. Advances in Earth Science, 22 (6): 561-571 (in Chinese with English abstract). 崔涛, 解习农, 任建业, 等, 2008. 莺歌海盆地异常裂后沉降的动力学机制. 地球科学———中国地质大学学报, 33 (3): 349-356. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX200803009.htm 方念乔, 姚伯初, 万玲, 等, 2007. 华南和南海北部陆缘岩石圈速度结构特征与沉积盆地成因. 地球科学———中国地质大学学报, 32 (2): 147-154. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX200702000.htm 龚再升, 李思田, 汪集?, 等, 2004. 南海北部大陆边缘盆地油气成藏动力学研究. 北京: 科学出版社, 3-45. 龚再升, 李思田, 谢泰俊, 等, 1997. 南海北部大陆边缘盆地分析与油气聚集. 北京: 科学出版社, 1-192. https://www.cnki.com.cn/Article/CJFDTOTAL-HYDZ201504011.htm 何家雄, 夏斌, 施小斌, 等, 2006. 世界深水油气勘探进展与南海深水油气勘探前景. 天然气地球科学, 17 (6): 747-752, 806. doi: 10.3969/j.issn.1672-1926.2006.06.002 李思田, 林畅松, 张启明, 等, 1998. 南海北部大陆边缘盆地幕式裂陷的动力过程及10Ma以来的构造事件. 科学通报, 43 (8): 797-810. doi: 10.3321/j.issn:0023-074X.1998.08.003 庞雄, 陈长民, 彭大钧, 等, 2008. 南海北部白云深水区之基础地质. 中国海上油气, 20 (4): 215-222. doi: 10.3969/j.issn.1673-1506.2008.04.001 孙珍, 庞雄, 钟志洪, 等, 2005. 珠江口盆地白云凹陷新生代构造演化动力学. 地学前缘, 12 (4): 489-498. doi: 10.3321/j.issn:1005-2321.2005.04.018 孙珍, 孙龙涛, 周蒂, 等, 2009. 南海岩石圈破裂方式与扩张过程的三维物理模拟. 地球科学———中国地质大学学报, 34 (3): 435-447. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX200903008.htm 陶维祥, 丁放, 何仕斌, 等, 2006. 国外深水油气勘探述评及中国深水油气勘探前景. 地质科技情报, 25 (6): 59-66. doi: 10.3969/j.issn.1000-7849.2006.06.010 姚伯初, 1998. 南海北部陆缘的地壳结构及构造意义. 海洋地质与第四纪地质, 18 (2): 1-16. https://www.cnki.com.cn/Article/CJFDTOTAL-HYDZ802.000.htm 姚伯初, 2002. 大陆岩石圈在张裂和分离时的变形特征. 见: 高抒, 李家彪编, 中国边缘海的形成演化. 北京: 海洋出版社, 1-13. https://www.cnki.com.cn/Article/CJFDTOTAL-HYDZ200203010.htm 姚伯初, 万玲, 吴能友, 2005. 南海新生代构造演化及岩石圈三维结构特征. 地质通报, 24 (1): 1-8. doi: 10.3969/j.issn.1671-2552.2005.01.001 张健, 汪集?, 2000. 南海北部陆缘带构造扩张的深部地球动力学特征. 中国科学(D辑), 30 (6): 561-567. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK200006000.htm 周蒂, 孙珍, 陈汉宗, 2007. 世界著名深水油气盆地的构造特征及对我国南海北部深水油气勘探的启示. 地球科学进展, 22 (6): 561-571. doi: 10.3321/j.issn:1001-8166.2007.06.002 -
