On-Site Preparation of Opaque Glass Using Liquid Phosphorus Slag
-
摘要: 为实现炼磷排放的高温液态磷渣的热能、物质的同步回收利用, 并消除其环境污染问题, 通过现场试验, 以高温液态磷渣为主要原料, 直接与16.5%的石英粉和8.5%的高岭土热配合, 再经1450℃熔炼、浇铸成型和850℃乳化热处理, 制得了乳浊玻璃板材.磷渣乳浊玻璃的抗折强度为43.68MPa, 耐酸性为0.51%, 耐碱性为0.04%, 能满足建筑装饰材料的质量要求.ESEM、XRD和EDS分析结果共同表明, 母玻璃的乳浊机理在于主体玻璃中析出了富Ca元素的粒径为0.1~0.4μm的非晶质球形颗粒.由于高温液态磷渣掺量高达75%, 改性剂掺量低且成本低廉, 生产线易于配置, 本研究具有较高的工业化生产可行性、较佳的经济效益和应用前景.Abstract: In order to recycle both the heat energy and the material of hot liquid phosphorus slag discharged from the phosphorus smelting furnace and eliminate its environmental problem, on-site preparation tests were carried out beside the smelting furnace by undertaking the following process: first, 75.0 % fresh hot liquid phosphorus slag was mixed directly with 16.5% quartz powder and 8.5% kaolin clay, and then melted at 1450℃ and cast-molded into parent glass panels which were subsequently heat-treated at 850℃ and transformed into opaque glass, which possesses bending strength, acid resistance and alkali resistance respectively of 43.68MPa, 0.51% and 0.04%, and so is applicable for wall decorating in buildings.Resultsof ESEM, XRD and EDS analyses indicate that the mechanism of emulsification of parent glass is attributed to the phase separation of parent glass and so the deposition of the non-crystalline spherical granules with particle sizes of about 0.1-0.4μm. Since high proportion of hot liquid phosphorus slag is consumed, cheap modifying raw materials are used and ordinary glass manufacturing facilities can be directly employed, the proposed on-site test process is cost-effective and feasible for industrial manufacturing.
-
Key words:
- liquid phosphorus slag /
- opaque glass /
- pollution control /
- waste recycling
-
表 1 2007年不同月份高温液态磷渣(LPS) 和改性剂的化学组成(%)
Table 1. Chemical compositions of liquid phosphorus slag (LPS) in different months of 2007 and that of modifying raw materials
表 2 现场试验配方
Table 2. Dosage of raw materials used in the on-site preparation test
表 3 乳浊玻璃的化学组成(%)
Table 3. Chemical compositions of the opaque glass
表 4 磷渣乳浊玻璃及其母玻璃的物理化学性能及其与天然花岗岩的对比
Table 4. Properties of the opaque glass and the parent glass and those of the natural granite
-
Chen, H. L., 1999. Comprehensive utilization of slag of yellow phosphor furnace. Guizhou Chemical Industry, 4: 7-8, 24 (in Chinese with English abstract). Gao, M., Wei, C. F., Zhou, B. T., et al., 2003. Study on characteristics of chemical component and agrochemistry behavior of slag containing silicon. Plant Nutrition and Fertilizer Science, 9 (2): 220-228 (in Chinesewith English abstract). Lebedeva, O. E., Dubovichenko, A. E., Kotsubinskaya, O. I., et al., 2000. Preparation of porous glasses from phosphorus slag. Journal of Non-crystalline Solids, 277 (1): 10-14. doi: 10.1016/S0022-3093(00)00301-X Liu, D. M., Fang, K. H., Shi, Y., 2007. Effects of phosphorus slag on hydration properties and pore structure of cement paste. Journal of the Chinese Ceramic Society, 35 (1): 109-113 (in Chinese with English abstract). Liu, Q. M., Cao, J. X., Yang, L., 2007. Study on the influences of phosphorus slags powder on the property of high performance concrete. Concrete, 6: 54-55, 62 (inChinese with English abstract). McMillan, P. W., 1979. Glass-ceramics (second ed). Academic Press, London. Parks, G. S., Kelly, K. K., 1926. The heat capacity of calcium silicate. Journal of Physical Chemistry, 30 (9): 1175-1178. doi: 10.1021/j150267a004 Shi, C. J., Qian, J. S., 2000. High performance cementing materials from industrial slags—A review. Resources, Conservation and Recycling, 29: 195-207. doi: 10.1016/S0921-3449(99)00060-9 Tao, J. F., 2008. Present status and development prospect of yellow phosphorus industry in China. Inorganic Chemicals Industry, 40 (6): 1-4 (in Chinese with English ab-stract). Wang, C. Y., Tao, Y., 1998. Opaque glass (Ⅰ). Glass & Enamel, 26 (2): 57-59 (in Chinese). Wang, J., Zhang, H. F., Xu, W. C., et al., 2008. Petrogenesis of granites from Dangchuan area in West Qinling orogenic belt and its tectonic implication. Earth Science—Journal of China University of Geosciences, 33 (4): 474-486 (in Chinese with English abstract). doi: 10.3799/dqkx.2008.062 Yang, J. K., Xiao, B., Yao, D. W., et al., 2003. Preparation and microstructure analysis of glass-ceramics based on yellow phosphorus slag. Multipurpose Utilization of Mineral Resources, 2: 40-43 (in Chinese with Englishabstract). 陈豪立, 1999. 黄磷炉渣的综合利用途径. 贵州化工, 4: 7-8, 24. https://www.cnki.com.cn/Article/CJFDTOTAL-GZHG199904001.htm 高明, 魏朝富, 周保同, 等, 2003. 含硅熔渣的化学组成特征与农业化学行为研究. 植物营养与肥料学报, 9 (2): 220-228. doi: 10.3321/j.issn:1008-505X.2003.02.016 刘冬梅, 方坤河, 石妍, 2007. 磷渣对水泥浆体水化性能和孔结构的影响. 硅酸盐学报, 35 (1): 109-113. doi: 10.3321/j.issn:0454-5648.2007.01.024 刘秋美, 曹建新, 杨林, 2007. 磷渣粉对高性能混凝土性能影响的研究. 混凝土, 6: 54-55, 62. https://www.cnki.com.cn/Article/CJFDTOTAL-HLTF200706017.htm 陶俊法, 2008. 中国黄磷工业现状与发展前景. 无机盐工业, 40 (6): 1-4. doi: 10.3969/j.issn.1006-4990.2008.06.001 王承遇, 陶瑛, 1998. 乳浊玻璃(一). 玻璃与搪瓷, 26 (2): 57-59. https://www.cnki.com.cn/Article/CJFDTOTAL-BLTC802.013.htm 王婧, 张宏飞, 徐旺春, 等, 2008. 西秦岭党川地区花岗岩的成因及其构造意义. 地球科学——中国地质大学学报, 33 (4): 474-486. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX200804006.htm 杨家宽, 肖波, 姚鼎文, 等, 2003. 黄磷渣微晶玻璃制备及显微结构分析. 矿产综合利用, 2: 40-43. https://www.cnki.com.cn/Article/CJFDTOTAL-KCZL200302009.htm
