    川西南部须二段低渗透砂岩储层裂缝类型及其形成序列

    曾联波 李跃纲 王正国 李梅

    曾联波, 李跃纲, 王正国, 李梅, 2007. 川西南部须二段低渗透砂岩储层裂缝类型及其形成序列. 地球科学, 32(2): 194-200.
    引用本文: 曾联波, 李跃纲, 王正国, 李梅, 2007. 川西南部须二段低渗透砂岩储层裂缝类型及其形成序列. 地球科学, 32(2): 194-200.
    CENG Lian-bo, LI Yue-gang, WANG Zheng-guo, LI Mei, 2007. Type and Sequence of Fractures in the Second Member of Xujiahe Formation at the South of Western Sichuan Depression. Earth Science, 32(2): 194-200.
    Citation: CENG Lian-bo, LI Yue-gang, WANG Zheng-guo, LI Mei, 2007. Type and Sequence of Fractures in the Second Member of Xujiahe Formation at the South of Western Sichuan Depression. Earth Science, 32(2): 194-200.

    川西南部须二段低渗透砂岩储层裂缝类型及其形成序列

    基金项目:

    CNPC石油科技中青年创新基金项目 05E7026

    详细信息
      作者简介:

      曾联波(1967-), 男, 博士, 教授, 主要从事裂缝的形成、分布及定量预测、应力场分析与应用、油气构造地质学等方面的科研与教学工作.E-mail: lbzeng@sina.com

    • 中图分类号: P618.13

    Type and Sequence of Fractures in the Second Member of Xujiahe Formation at the South of Western Sichuan Depression

    • 摘要: 裂缝是川西坳陷须二段低渗透砂岩天然气藏分布的重要控制因素.利用地表露头、岩心、薄片和成像测井等资料, 对该区裂缝的成因类型、分布特征及其形成序列进行了分析.须二段低渗透砂岩储层主要发育有构造裂缝、成岩裂缝以及与异常高压有关的裂缝等3种裂缝类型, 其中以构造剪切裂缝为主, 主要有近南北向、北东向、近东西向和北西向4组, 它们的发育程度依次由强变弱.但在现今应力场作用下, 北西向裂缝表现为主渗流裂缝.此外, 该区还发育有大量被沥青或碳质充填的裂缝扩张脉群, 结合岩石的声发射等实验结果, 表明该区在白垩纪中晚期曾经经历过异常高压作用, 其最大压力系数可达1.6~2.1, 在新近纪中晚期释放以后的压力系数为1.2~1.3.在中粗粒砂岩中, 还发育大量在构造挤压作用下由于断层的逆冲作用或层间滑动造成的剪切作用有关的近水平剪切裂缝.构造裂缝主要在三叠纪末、白垩纪末和新近纪末—早更新世末形成.



    • 图  1  川西南部须二段裂缝方位图

      a.据平落坝构造定向取心井裂缝统计; b.据白马庙构造FMI和裂缝识别测井解释结果统计; c.据邛西构造地磁定向以后的岩心裂缝统计; d.据花水湾上三叠统地表露头区的裂缝统计

      Fig.  1.  Orientation of fractures in the second member of Xujiahe Formation in the southwestern Sichuan depression

      图  2  川西南部须二段FMI成像测井裂缝解释图

      a.垂直裂缝和低角度裂缝; b.垂直裂缝

      Fig.  2.  Interpretative plot of fractures by FMI imaging logging in the second member of Xujiahe Formation in the southwestern Sichuan depression

      图  3  川西南地区须二段岩石破裂序列图

      Fig.  3.  Sequence of fractures in the second member of Xujiahe Formation in the southwestern Sichuan depression

    • Ding, Y. C., Shao, Z. G., 2001. An experi mental research in to determination of highest paleotectonic stress state expe-rienced by rock through geological ages. Earth Sci-ence—Journal of China University of Geosciences, 26(1): 99-104(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DQKX200101020.htm
      Finkbeiner, T., Barton, C. A., Zoback, M. D., 1997. Rela-tionships among in-situ stress, fractures and faults, andfluid flow: Monterey Formation, Santa Maria basin, Cal-ifornia. AAPG Bulletin, 81(12): 1975-1999. http://www.onacademic.com/detail/journal_1000041660124799_c683.html
      Fu, X. F., Fang, D. Q., Lü, Y. F., et al., 2005. Method ofevaluating vertical sealing of faults interms of theinter-nal structure of fault zones. Earth Science—Journal ofChina University of Geosciences, 30(3): 328-336(inChinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DQKX200503008.htm
      Hao, F., Dong, W. L., 2001. Evolution of fluid flow and pe-troleumaccumulation in overpressured systems in sedi-mentary basins. Advance in Earth Sciences, 16(1): 79-84(in Chinese with English abstract).
      Huang, Z. G., Liu, G. X., Pan, W. L, et al., 2003. Deforma-tion characteristics and petroleum geological signifi-cances of compress-shear stress fields in the West Si-chuan depression. Petroleum Geology & Experi ment, 25(6): 701-707(in Chinese with English abstract).
      Hunt, J. M., 1990. Generation and migration of petroleumfrom abnormally pressure fluid compart ments. AAPGBulletin, 74(1): 1-12.
      Liao, X., He, X. Q., Shen, H., et al., 2002. Fracture distributionand prediction of low permeability gas reservoirs in sometypical structuresin Sichuan basin. Natural Gas Industry, 22(Suppl. ): 45-50(in Chinese with English abstract).
      Liu, C. R., 2002. Numerical si mulation of Hi malayan epochtectonic stress field in West Sichuan depression and itsfracture prediction. Natural Gas Industry, 22(3): 10-13(in Chinese with English abstract).
      Narr, W., 1991. Fracture density in the deep subsurface: Te-chiques with application to point Arguello oilfield. AAPG Bulletin, 66: 1231-1247. https://pubs.geoscienceworld.org/aapgbull/article-abstract/75/8/1300/38701/Fracture-Density-in-the-Deep-Subsurface-Techniques
      Peter, C., John, C., 1999. Prediction of fracture-induced per-meability and fluid flowin the crust using experi mentalstress data. AAPG Bulletin, 83(5): 757-777. https://www.researchgate.net/publication/279192677_Intrinsic_anisotropy_in_fracture_permeability
      Roberts, S. J., Nunn, J. A., 1995. Episodic fluid expulsionfrom geopressured sedi ments. Marine and PetroleumGeology, 12(2): 195-204. doi: 10.1016/0264-8172(95)92839-O
      Tang, L. Z., Zhang, G. S., Zhang, X. P., et al., 2004. Main con-trol factors of forming the tight sandstone gas reservoirs inXujiahe Formation in West Sichuan depression. NaturalGas Industry, 24(9): 5-7(in Chinese with English ab-stract).
      Wang, S. C., Zhang, J. C., Jia, Q. S., 2004. Formation mecha-nismof abnormal formation pressures in West Sichuandepression and its relation to the distribution of naturalgas. Natural Gas Industry, 24(3): 5-8(in Chinesewith English abstract).
      Wang, Z. L., Sun, M. L., Zhang, L. K., et al., 2004. Evolu-tion of abnormal pressure and model of gas accumula-tion in Xujiahe Formation, western Sichuan basin. Earth Science—Journal of China University of Geosciences, 29(4): 433-439(in Chinese with English abstract).
      Wu, S. X., Wang, Z. C., Zhang, L., et al., 2002. Analysis ofpool-forming factors and promising exploration belts ofUpper Triassic in western Sichuan basin. Journal ofChina University of Mining & Technology, 31(1): 75-79(in Chinese with English abstract).
      Xie, X. N., Wang, Q. Y., Li, S. T., 1997. Hydrofracturing andpulse compaction of argillaceous rock in sedi mentary basin. Chinese Science Bulletin, 42(20): 2193-2195(in Chinese). doi: 10.1360/csb1997-42-20-2193
      Xu, Y. G., Xu, H. J., Yu, X. H., 2004. Identification and pre-diction of fractures in the median-deep burial strata inWest Sichuan depression. Natural Gas Industry, 24(3): 9-11(in Chinese with English abstract).
      Yang, K. M., 2003. Characteristics of gas distribution andreservoiring in Upper Triassic Xujiahe Formation inwestern Sichuan depression. Oil & Gas Geology, 24(4): 322-326(in Chinese with English abstract).
      Yu, H. F., Zhou, W., 2001. Aresearch on distribution law of fracture in Xujiahe Formationin Songhua-Bai ma region. Journal of Chengdu University of Technology, 28(2): 174-178(in Chinese with English abstract).
      Yue, S. D., 2004. Prospects and countermeasure against deep natu-ral gas explorationin West Sichuan depression. Natural GasIndustry, 24(6): 1-3(in Chinese with English abstract).
      Zeng, L. B., 2004. Fissure and its seepage characteristics in low-permeability sandstone reservoir. Chinese Journal of Geolo-gy, 39(1): 11-17(in Chinese with English abstract). https://www.sciencedirect.com/science/article/pii/S1674526409601447
      Zeng, L. B., Tan, C. X., Zhang, M. L., 2004a. Tectonic stress fieldandits effect on hydrocarbon migration and accumulation inMesozoic and Cenozoicin Kuqa depression, Tari m basin. Sci-encein China(Ser. D), 47(Suppl. Ⅱ): 114-124.
      Zeng, L. B., Zhou, T. W., Lü, X. X., 2004b. Influence of tec-tonic compression on the anormal formation pressureinthe Kuqa depression. Geological Review, 50(5): 471-475(in Chinese with English abstract). http://www.nggs.ac.cn/CN/Y2017/V28/I2/199
      Zhang, S. R., Wan, T. F., Chen, J. P., 2004. Tectonic stress fieldmodeling and fracture prediction in T3x2-4strata inXiaoquan-Xinchang area, western Sichuan depression. Oil & Gas Geology, 25(1): 70-74(in Chinese with English ab-stract).
      Zhang, Y., 2003. Fracture log evaluation techniques of thefractured reservoirs in West Sichuan depression. Natu-ral Gas Industry, 23(Suppl. ): 43-45(in Chinese withEnglish abstract).
      Zhou, W., 1998. The evaluation method of fractured reservoir. Si-chuan Science and Technology Press, Chengdu(in Chinese).
      丁原辰, 邵兆刚, 2001. 测定岩石经历的最高古应力状态实验研究. 地球科学——中国地质大学学报, 26(1): 99-104. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX200101020.htm
      付晓飞, 方德庆, 吕延防, 等, 2005. 从断裂带内部结构出发评价断层垂向封闭性的方法. 地球科学——中国地质大学学报, 30(3): 328-336. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX200503008.htm
      郝芳, 董伟良, 2001. 沉积盆地超压系统演化、流体流动与成藏机理. 地球科学进展, 16(1): 79-84. doi: 10.3321/j.issn:1001-8166.2001.01.015
      黄泽光, 刘光祥, 潘文蕾, 等, 2003. 川西坳陷压扭应力场的形变特征及油气地质意义. 石油实验地质, 25(6): 701-707. doi: 10.3969/j.issn.1001-6112.2003.06.012
      廖曦, 何绪全, 沈浩, 等, 2002. 四川盆地典型构造低渗气藏储层裂缝分布及预测. 天然气工业, 22(增刊): 45-50. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG2002S1011.htm
      刘翠荣, 2002. 川西坳陷喜山期构造应力场数值模拟及裂缝预测. 天然气工业, 22(3): 10-13. doi: 10.3321/j.issn:1000-0976.2002.03.003
      唐立章, 张贵生, 张晓鹏, 等, 2004. 川西须家河组致密砂岩成藏主控因素. 天然气工业, 24(9): 5-7. doi: 10.3321/j.issn:1000-0976.2004.09.002
      汪时成, 张金川, 贾庆素, 2004. 川西坳陷异常高压形成机理与天然气分布关系研究. 天然气工业, 24(3): 5-8. doi: 10.3321/j.issn:1000-0976.2004.03.002
      王震亮, 孙明亮, 张立宽, 等, 2004. 川西地区须家河组异常压力演化与天然气成藏模式. 地球科学——中国地质大学学报, 29(4): 433-439. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX200404008.htm
      吴世祥, 汪泽成, 张林, 等, 2002. 川西坳陷T3成藏主控因素与有利勘探区带分析. 中国矿业大学学报, 31(1): 75-79. https://www.cnki.com.cn/Article/CJFDTOTAL-ZGKD200201017.htm
      解习农, 王其允, 李思田, 1997. 沉积盆地泥质岩石的水力破裂和幕式压实作用. 科学通报, 42(20): 2193-2195. doi: 10.3321/j.issn:0023-074X.1997.20.018
      徐言岗, 徐宏节, 虞显和, 2004. 川西坳陷中深层裂缝的识别与预测. 天然气工业, 24(3): 9-11. doi: 10.3321/j.issn:1000-0976.2004.03.003
      杨克明, 2003. 川西坳陷油气资源现状及勘探潜力. 石油与天然气地质, 24(4): 322-326. doi: 10.3321/j.issn:0253-9985.2003.04.003
      于红枫, 周文, 2001. 松华镇——白马庙地区须二段储层裂缝分布规律. 成都理工学院学报, 28(2): 174-178. doi: 10.3969/j.issn.1671-9727.2001.02.014
      乐绍东, 2004. 川西坳陷深层天然气勘探前景与对策. 天然气工业, 24(6): 1-3. doi: 10.3321/j.issn:1000-0976.2004.06.001
      曾联波, 2004. 低渗透砂岩油气储层裂缝及其渗流特征. 地质科学, 39(1): 11-17. doi: 10.3321/j.issn:0563-5020.2004.01.002
      曾联波, 周天伟, 吕修祥, 2004b. 构造挤压对库车前陆逆冲带异常地层压力的影响. 地质论评, 50(5): 471-475.
      张守仁, 万天丰, 陈建平, 2004. 川西坳陷孝泉——新场地区须家河组二——四段构造应力场模拟及裂缝发育区带预测. 石油与天然气地质, 25(1): 70-74. doi: 10.3321/j.issn:0253-9985.2004.01.013
      张筠, 2003. 川西坳陷裂缝型储层的裂缝测井评价技术. 天然气工业, 23(增刊): 43-45. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG2003S1011.htm
      周文, 1998. 裂缝性油气储集层评价方法. 成都: 四川科技出版社.
