EARLY DUCTILE SHEAR ZONE AND TECTONIC EVOLUTION IN THE MIDDLE SECTION OF LINHE-JINING DEEP FAULT, INNER MONGOLIA
-
摘要: 临河-集宁深断裂是一条具长期活动历史的复杂断裂带, 以往对其早期演化研究甚少.在1∶5万区调工作基础上, 测制了5条1∶2 0 0 0构造剖面, 室内进行了大量的显微构造观察和组构测量.研究表明, 该断裂太古宙末表现为高角闪岩相—麻粒岩相的高温韧性剪切带, 古元古代地壳在伸展体制下抬升之后又叠加有浅层次的绿片岩相低温韧性剪切活动.中元古代之后转化为脆性断层活动, 控制着不同时期的沉积和岩浆建造.Abstract: The deep fault from Linhe to Jining, a complex longterm active fault zone has not been under thorough investigation in terms of its early evolution for the past years. However, in the present research, five tectonic sections in the proportion 1:2 000 are mapped on the basis of the 1:50 000 regional geological surveying. In addition, a great number of micro-structural observations and fabric measurements are completed in the laboratory. The research shows that the evidence of the Neo-Archaean fault is expressed by the high-temperature ductile shear zone of high amphibolite facies-granulite facies that is overprinted by the low-temperature ductile shear zone of the greenschist in the shallow layers after the Lower Proterozoic crust was elevated in the extension system. After the Middle Proterozoic, this ductile shear zone is transformed into brittle fault, controlling deposition and magma formation in different periods.
-
图 1 固阳县东卜界—大南窑子地质图
1.第四系; 2.下第三系; 3.太古宙乌拉山群浅色片麻岩岩组; 4.太古宙乌拉山群深色片麻岩岩组; 5.太古宙变质深成体-石家渠片麻岩; 6.混合花岗岩; 7.石英岩层; 8.辉绿岩脉; 9.脆性断裂; 10.低温绿片岩相韧性剪切带; 11.高温高角闪岩相—麻粒岩相韧性剪切带—强带; 12.高温高角闪岩相—麻粒岩相韧性剪切带弱带; 13.片麻理; 14.片麻理产状; 15.角度不整合
Fig. 1. Geological sketch map of the Dongpujie-Da'nanyaozi, Guyang County
-
[1] 内蒙古自治区地质矿产局. 内蒙古自治区区域地质志[M]. 北京: 地质出版社, 1991. 595~629. [2] 嵇少丞. 部分熔融的构造地质意义(1). 变形机制转变的实验研究[J]. 地质科学, 1988, (4): 347~356. [3] 胡玲. 燕山北缘断裂带及其西延断裂研究[D]. 北京: 中国地质大学, 1999. 40~52. [4] 钟增球, 郭宝罗. 构造岩与显微构造[M]. 武汉: 中国地质大学出版社, 1991. 76~80. [5] White J C, Mawer C K. Dynamic recrystallization and as-sociated exsolution in Perthites: evidence of deep crustal thrusting[J]. J Geophys Res, 1988, 93: 325~337. [6] 李树勋, 徐学纯, 刘喜山, 等. 内蒙古乌拉山区早前寒武纪地质[M]. 北京: 地质出版社, 1994. 105~119. -
