Algorithm of Auto-Creation of Two Types of Logic Diagrams of Telecommunication Network
-
摘要: 为解决电信手工绘制的逻辑图不易维护的问题,研究了电信带方向逻辑图和不带方向逻辑图的自动生成算法.算法是从数据库提取缆线的路由信息,用深度优先的方式遍历缆线经过的所有坐标,采取回溯的方式,计算缆线在每个点的偏移值,调整缆线顺序,自动绘制逻辑图.产生的逻辑图没有不必要的交叉,避免了传统的手工绘制.结果表明,对于常用的电信逻辑图,自动生成算法是可以满足要求的.Abstract: This paper studies the algorithm of auto-creation of logic diagrams with or without orientation of telecommunication to overcome the maintenance difficulty of hand-drawn logic diagram telecommunications. This algorithm initializes the graph by database, traverses the graph by deep-search-first method, and sets the vertex's offset of every line. At a result, a diagram is created without needless intercrossing by adjusting the line's order. This method avoids getting this diagram manually. Therefore this algorithm works when the diagram is of normal scale.
-
Key words:
- auto-creation of logic diagram /
- backtracking /
- deep search first (DSF)
-
