Cenozoic Episodic Subsidence in the Middle and North Part of Huanghua Depression, Bohai Bay Basin
-
摘要: 黄骅坳陷中北区是位于渤海湾盆地中部的一个重要新生代构造单元.构造层序界面分析、同生断裂活动和盆地沉降史回剥分析表明该区经历了幕式沉降过程,沉降中心显示出规律性的迁移演化特征.馆陶组底界面为区域性裂后不整合界面,将研究区的演化划分为裂陷期和裂后期.在裂陷期的充填序列中,沙一段底界面为整个研究区都可以识别的显著的角度不整合界面,以此界面为界,盆地的裂陷期进一步划分为裂陷Ⅰ幕和裂陷Ⅱ幕.裂陷Ⅰ幕发育了Es3-Es2地层,断裂几何学和断裂的性质表明该幕构造活动为北西南东向伸展作用所致,而裂陷Ⅱ幕发育了Es1-Ed地层,为近南北向拉伸作用的结果.裂后期,从早到晚则表现为由稳定热沉降到加速沉降的过程.分析认为上述盆地的幕式沉降过程与区域应力场的转变密切相关,受控于周缘板块的动力学事件,尤其是晚始新世之后,太平洋板块对欧亚大陆向西的加速俯冲,促使了郯庐断裂右旋活动向南延伸和穿过黄骅坳陷的兰聊断裂北段的活化,形成了位于渤海海域的南北向伸展叠加区,从根本上改变了黄骅坳陷中北区应力场的分布,由此导致了盆地同裂陷阶段的幕式演化.Abstract: The middle and north area of Huanghua depression, located in the middle of the Bohai Bay basin, is a significant Cenozoic tectonic unit. This study area underwent the episodic subsidence and the subsidence center migrated regularly which was interpreted through the analysis of the tectonic-sequence surface, syn-sedimentary fault's activity and the back-stripping of the subsidence history. The bottom interface of Guantao Formation is a regional post-rifting unconformity surface and divides the basin's Cenozoic evolution into rifting and post-rifting stage. In the filling sequence of the rifting stage, the bottom interface of the first member of Shahejie Formation is also a regional recognizable angle disconformity surface in the whole basin and divides the rifting stage into Episodic Ⅰ and Episodic Ⅱ. The geometry feature and property of the fault system shows that the tectonic deformation of the study area was controlled by the NW-SE extending stress field in the rifting Episodic Ⅰ from Es3 to Es2. However, the extending stress field turned to NS in the Episodic Ⅱ from Es1 to Ed. In the post-rifting stage, the middle and north area of Huanghua depression underwent stable subsidence at early stage and accelerated subsidence at late stage. This episodic subsidence process is closely related to the change of the regional extending stress field orientation which was controlled by the tectonic events of the surrounding plates. Especially, the accelerated westward subduction from the Pacific Plate to the Eurasia Plate triggered the southward expanding of the dextral slipping of the Tanlu fault and the activity of the north section of the Lanliao fault through the Huanghua depression after the Late Eocene. The continued dextral slipping between the east and west boundary faults created a NS trending extensional overlap at the Bohai Sea, completely changed the stress field distribution in the middle and north area of Huanghua depression, and generated the episodic evolution in the rifting stage.
-
Key words:
- Huanghua depression /
- episodic subsidence /
- Cenozoic /
- tectonics
-
图 3 黄骅坳陷中北区不整合界面反射特征(位置见图 1)
Fig. 3. Reflection characteristics of the unconformity in the middle and north part of Huanghua depression
图 6 黄骅坳陷中北区古近纪沉积时期构造格架
a.Es3沉积时期;b.Es2沉积时期;c.Es1沉积时期;d.Ed沉积时期;断层名称见图 1
Fig. 6. Paleogene tectonic framework in different stages of the middle and north part of Huanghua depression
图 7 渤海湾盆地新生代构造演化动力学背景
a.中国东部新生代伸展盆地的形成机制(Watson et al., 1987;任建业和李思田,2000);b.新生代太平洋板块对欧亚板块俯冲的变迁过程,据Northrup et al.(1995)、Allen et al.(1998)和Zhang et al., 2003修改;c.渤海湾盆地孔店组地层残余厚度图(Alllen et al., 1997);d.渤海湾沙河街组三段地层残余厚度图(田克勤等,2000)
Fig. 7. Dynamic setting maps of Cenozoic tectonic in the middle and north part of Huanghua depression
-
Allen, M.B., Macdonald, D.I.M., Zhao, X., et al., 1997. Early Cenozoic two-phase extension and Late Cenozoic thermal subsidence and inversion of the Bohai basin, northern China. Marine and Petroleum Geology, 14(7-8): 951-972. doi: 10.1016/S0264-8172(97)00027-5 Allen, M.B., Macdonald, D.I.M., Zhao, X., et al., 1998. Transtensional deformation in the evolution of the Bohai basin, northern China. In: Holdsworth, R.E., Strachan, R.A., Dewey, J.E., eds., Continental transpressional and transtensional tectonics. Geological Society, London, Special Publications, 135: 215-229. doi: 10.1144/GSL.SP.1998.135.01.14 Fan, J.L., Qi, J.F., Gao, A.H., et al., 2004. Genetic analysis of discontinuous of tectonic line on both sides of coastline in Huanghua basin. Journal of China University of Mining & Technology, 33(3): 287-291 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-ZGKD200403012.htm Han, H.J., Zheng, D.S., 2007. Characteristic contrast of Mesozoic and Cenozoic faults of eastern and western structure units in Jiyang depression and its controlling factors. Petroleum Geology and Recovery Efficiency, 14(3): 12-15 (in Chinese with English abstract). http://d.wanfangdata.com.cn/periodical/yqdzycsl200703004 Hou, Z.Q., Mo, X.X., Gao, Y.F., et al., 2006. Early processes and tectonic model for the Indian-Asian continental collision: evidence from the Cenozoic Gangdese igneous rocks in Tibet. Acta Geologica Sinica, 80(9): 1233-1248 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DZXE200609001.htm Hou, Z.Q., Yang, Y.Q., Qu, X.M., et al., 2004. Tectonic evolution and mineralization systems of the Yidun arc orogen in Sanjiang region, China. Acta Geologica Sinica, 78(1): 109-120 (in Chinese with English abstract). http://www.cnki.com.cn/Article/CJFDTotal-DZXE200401013.htm Hsiao, L.Y., Graham, S.A., Tilander, N., 2004. Seismic reflection imaging of a major strike-slip fault zone in a rift system: paleogene structure and evolution of the Tan-Lu fault system, Liaodong bay, Bohai, offshore China. AAPG Bull., 88(1): 71-97. doi: 10.1306/09090302019 Li, S.T., Xie, X.N., Wang, H., et al., 2004. Sedimentary basin analysis: principle and application. Higher Education Press, Beijing, 275-280 (in Chinese). Lin, C.S., Zhang, Y.M., Li, S.T., et al., 2004. Episodic rifting dynamic process and quantitative model of Mesozoic-Cenozoic faulted basins in eastern China. Earth Science—Journal of China University of Geosciences, 29(5): 583-588 (in Chinese with English abstract). http://www.researchgate.net/publication/279902759_Episodic_rifting_dynamic_process_and_quantitative_model_of_mesozoic-cenozoic_faulted_basins_in_eastern_China Liu, J.Q., Han, J.T., Fyfe, W.S., 2001. Cenozoic episodic volcanism and continental rifting in Northeast China and possible link to Japan Sea development as revealed from K-Ar geochronology. Tectonophysics, 399(3-4): 385-401. doi: 10.1016/S0040-1951(01)00132-9 Mckenzie, D., 1978. Some remarks on the development of sedimentary basin. Earth and Planetary Science Letters, 48(1): 25-32. doi: 10.1016/0012-821X(78)90071-7 Northrup, C.J., Royden, L.H., Burchfiel, B.C., 1995. Motion of the Pacific plate relative to Eurasia and its potential relation to Cenozoic extension along the eastern margin of Eurasia. Geology, 23(8): 719-722. doi: 10.1130/0091-7613(1995)023<0719:MOTPPR>2.3.CO;2 Pu, X.G., Zhou, L.H., Zhou, J.S., et al., 2009. Study on the sedimentary system of Member 1-S of Shahejie Formation and Dongying Formation of the Qikou sag in Bohaiwan basin, China. Journal of Chengdu University of Technology (Science & Technology Edition), 36(1): 45-50 (in Chinese with English abstract). http://www.researchgate.net/publication/283961938_Study_on_the_sedimentary_system_of_Member_1-S_of_Shahejie_Formation_and_Dongying_Formation_of_the_Qikou_sag_in_Bohaiwan_basin_China Qi, J.F., 2004. Two tectonic systems in the Cenozoic Bohai Bay basin and their genetic interpretation. Geology in China, 31(1): 15-22 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DIZI200401001.htm Ren, J.Y., Li, S.T., 2000. Spreading and dynamic setting of marginal basins of the western Pacific. Earth Science Frontiers, 7(3): 203-213 (in Chinese with English abstract). http://www.researchgate.net/publication/305387234_Spreading_and_dynamic_setting_of_marginal_basins_of_the_western_Pacific Ren, J.Y., Tamaki, K., Li, S.T., et al., 2002. Late Mesozoic and Cenozoic rifting and its dynamic setting in eastern China and adjacent areas. Tectonophysics, 344(3-4): 175-205. doi: 10.1016/S0040-1951(01)00271-2 Schellart, W.P., Lister, G.S., 2005. The role of the East Asian active margin in widespread extensional and strike-slip deformation in East Asia. Journal of the Geological Society, 162(6): 959-972. doi: 10.1144/0016-764904-112 Sun, X.X., Li, Y., Qiu, D.Z., et al., 2006. The heavy minerals and provenances of the Neogene Guantao Formation in the Huanghua depression. Sedimentary Geology and Tethyan Geology, 26(3): 61-66 (in Chinese with English abstract). http://www10215.edu6.org/cjiyttis/qkwy/sunxiaoxia-e.pdf Tapponnier, P., Peltzer, G., Armijo, R., 1986. On the mechanics of the collision between India and Asia. In: Coward, M.P., Ries, A.C., eds., Collision tectonics. Geological Society, London, Special Publications, 19: 113-157. doi: 10.1144/GSL.SP.1986.019.01.07 Tian, K.Q., Yu, Z.H., Feng, M., et al., 2000. Hydrocarbon geology and exploration of the deep Paleogene strata in Bohaibay basin. Petroleum Industry Press, Beijing, 100-107 (in Chinese). Wang, C.S., Li, X.H., Hu, X.M., 2003. Age of initial collision of India with Asia: review and constraints from sediments in southern Tibet. Acta Geologica Sinica, 77(1): 16-24 (in Chinese with English abstract). Wang, G.Q., Qi, J.F., Yue, Y.F., 2003. Formation and evolution of the Cenozoic tectonics within and surrounding the Qikou sag. Chinese Journal of Geology, 38(2): 230-240 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DZKX200302010.htm Wang, H., Bai, Y.F., Huang, C.Y., et al., 2009. Reconstruction and application of the Paleogene provenance system of the Dongying Formation in Qikou depression. Earth Science—Journal of China University of Geosciences, 34(3): 448-456 (in Chinese with English abstract). doi: 10.3799/dqkx.2009.050 Watson, M.P., Hayward, A.B., Parkinson, D.N., et al., 1987. Plate tectonic history, basin development and petroleum source rock deposition onshore China. Marine and Petroleum geology, 4(3): 205-225. doi: 10.1016/0264-8172(87)90045-6 Wu, L., Xu, H.M., Ji, H.C., 2006. Evolution of sedimentary system and analysis of sedimentary source in Paleogene of Bozhong sag, Bohai Bay. Marine Geology & Quaternary Geology, 26(1): 81-88 (in Chinese with English abstract). http://www.cnki.com.cn/Article/CJFDTotal-HYDZ200601018.htm Xia, B., Lin, Q.C., Zhang, Y.Q., et al., 2009. SHRIMP U-Pb dating of zircon from gneiss in the Tongmai region: evidence for the India-Eurasia collision time. Acta Geologica Sinica, 83(3): 347-352 (in Chinese with English abstract). http://www.zhangqiaokeyan.com/academic-journal-cn_acta-geologica-sinica_thesis/0201252707483.html Xu, J.Y., Zhang, L.Y., Yang, D.S., et al., 1996. Tectonic evolution of Qikou depression in the Bohaiwan basin of East China. Experimental Petroleum Geology, 18(4): 348-355 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SYSD604.001.htm Xu, S.M., Zhai, S.K., Li, S.Z., et al., 2001. Seismic reflections and sequence division of lower Tertiary in Qikou sag. Journal of Ocean University of Qingdao, 31(5): 739-746 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-QDHY200105019.htm Yan, D.T., Wang, H., Xiao, D.Q., et al., 2007. Sedimentary systems of the third member of Shahejie Formation, central Huanghua depression. Petroleum Exploration and Development, 34(3): 328-334 (in Chinese with English abstract). http://d.wanfangdata.com.cn/periodical/syktykf200703010 Yin, A., 2000. Mode of Cenozoic east-west extension in Tibet suggesting a common origin of rifts in Asia during the Indo-Asian collision. Journal of Geophysical Research, 105(B9): 21745-21759. doi: 10.1029/2000JB900168 樊敬亮, 漆家福, 高爱华, 等, 2004. 黄骅盆地海岸线两侧构造线不连续之成因分析. 中国矿业大学学报, 33(3): 287-291. doi: 10.3321/j.issn:1000-1964.2004.03.012 韩会军, 郑德顺, 2007. 济阳坳陷东西部构造单元中-新生代断裂特征对比及其控制因素. 油气地质与采收率, 14(3): 12-15. doi: 10.3969/j.issn.1009-9603.2007.03.004 侯增谦, 莫宣学, 高永丰, 等, 2006. 印度大陆与亚洲大陆早期碰撞过程与动力学模型——来自西藏冈底斯新生代火成岩证据. 地质学报, 80(9): 1233-1248. doi: 10.3321/j.issn:0001-5717.2006.09.001 侯增谦, 杨岳清, 曲晓明, 等, 2004. 三江地区义敦岛弧造山带演化和成矿系统. 地质学报, 78(1): 109-120. https://www.cnki.com.cn/Article/CJFDTOTAL-DZXE200401013.htm 李思田, 解习农, 王华, 等, 2004. 沉积盆地分析基础与应用. 北京: 高等教育出版社, 275-280. 林畅松, 张燕梅, 李思田, 等, 2004. 中国东部中新生代断陷盆地幕式裂陷过程的动力学响应和模拟模型. 地球科学——中国地质大学学报, 29(5): 583-588. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX200405012.htm 蒲秀刚, 周立宏, 周建生, 等, 2009. 歧口凹陷沙一上亚段-东营组沉积体系. 成都理工大学学报(自然科学版), 36(1): 45-50. doi: 10.3969/j.issn.1671-9727.2009.01.008 漆家福, 2004. 渤海湾新生代盆地的两种构造系统及其成因解释. 中国地质, 31(1): 15-22. https://www.cnki.com.cn/Article/CJFDTOTAL-DIZI200401001.htm 任建业, 李思田, 2000. 西太平洋边缘海盆地的扩张过程和动力学背景. 地学前缘, 7(3): 203-213. doi: 10.3321/j.issn:1005-2321.2000.03.019 孙小霞, 李勇, 丘东洲, 等, 2006. 黄骅坳陷新近系馆陶组重矿物特征及物源区意义. 沉积与特提斯地质, 26(3): 61-66. doi: 10.3969/j.issn.1009-3850.2006.03.011 田克勤, 于志海, 冯明, 等, 2000. 渤海湾盆地下第三系深层油气地质与勘探. 北京: 石油工业出版社, 100-107. 王成善, 李祥辉, 胡修棉, 2003. 再论印度-亚洲大陆碰撞的启动时间. 地质学报, 77(1): 16-24. doi: 10.3321/j.issn:0001-5717.2003.01.003 王光奇, 漆家福, 岳云福, 2003. 歧口凹陷及周缘新生代构造的成因和演化. 地质科学, 38(2): 230-240. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKX200302010.htm 王华, 白云风, 黄传炎, 等, 2009. 歧口凹陷古近纪东营期古物源体系重建与应用. 地球科学——中国地质大学学报, 34(3): 448-456. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX200903009.htm 吴磊, 徐怀民, 季汉成, 2006. 渤海湾盆地渤中凹陷古近系沉积体系演化及物源分析. 海洋地质与第四纪地质, 26(1): 81-88. https://www.cnki.com.cn/Article/CJFDTOTAL-HYDZ200601018.htm 夏斌, 林清茶, 张玉泉, 等, 2009. 印度与欧亚两大陆块碰撞时间的厘定: 来自锆石SHRIMP U-Pb年龄的证据. 地质学报, 83(3): 347-352. doi: 10.3321/j.issn:0001-5717.2009.03.004 许浚远, 张凌云, 杨东胜, 等, 1996. 歧口凹陷构造演化. 石油实验地质, 18(4): 348-355. https://www.cnki.com.cn/Article/CJFDTOTAL-SYSD604.001.htm 许淑梅, 翟世奎, 李三忠, 等, 2001. 歧口凹陷滩海区下第三系地震反射特征及层序划分. 青岛海洋大学学报, 31(5): 739-746. doi: 10.3969/j.issn.1672-5174.2001.05.016 严德天, 王华, 肖敦清, 等, 2007. 黄骅坳陷中部沙三段沉积体系分析. 石油勘探与开发, 34(3): 328-334. doi: 10.3321/j.issn:1000-0747.2007.03.010
