    GPR,GPS与GIS支持下的冰川厚度及冰储量分析:以天山博格达峰黑沟8号冰川为例

    王璞玉 李忠勤 吴利华 李慧林 王文彬 金爽 周平

    王璞玉, 李忠勤, 吴利华, 李慧林, 王文彬, 金爽, 周平, 2012. GPR,GPS与GIS支持下的冰川厚度及冰储量分析:以天山博格达峰黑沟8号冰川为例. 地球科学, 37(S1): 179-187. doi: 10.3799/dqkx.2012.S1.018
    引用本文: 王璞玉, 李忠勤, 吴利华, 李慧林, 王文彬, 金爽, 周平, 2012. GPR,GPS与GIS支持下的冰川厚度及冰储量分析:以天山博格达峰黑沟8号冰川为例. 地球科学, 37(S1): 179-187. doi: 10.3799/dqkx.2012.S1.018
    WANG Pu-yu, LI Zhong-qin, WU Li-hua, LI Hui-lin, WANG Wen-bin, JIN Shuang, ZHOU Ping, 2012. Ice Thickness and Volume Based on GPR, GPS and GIS: Example from the Heigou Glacier No.8, Bogda-Peak Region, Tianshan, China. Earth Science, 37(S1): 179-187. doi: 10.3799/dqkx.2012.S1.018
    Citation: WANG Pu-yu, LI Zhong-qin, WU Li-hua, LI Hui-lin, WANG Wen-bin, JIN Shuang, ZHOU Ping, 2012. Ice Thickness and Volume Based on GPR, GPS and GIS: Example from the Heigou Glacier No.8, Bogda-Peak Region, Tianshan, China. Earth Science, 37(S1): 179-187. doi: 10.3799/dqkx.2012.S1.018

    GPR,GPS与GIS支持下的冰川厚度及冰储量分析:以天山博格达峰黑沟8号冰川为例

    doi: 10.3799/dqkx.2012.S1.018
    基金项目:

    国家重点基础研究发展计划 2010CB951003

    中国科学院知识创新工程重要方向项目 KZCX2-YW-127

    国家自然科学基金项目 40631001

    国家自然科学基金项目 40701034

    国家自然科学基金项目 J0630966

    国家自然科学基金项目 41001040

    国家自然科学基金项目 41101066

    详细信息
      作者简介:

      王璞玉(1983-),女,助理研究员,主要从事冰川变化与环境研究.E-mail: wangpuyu@lzb.ac.cn

    • 中图分类号: P343.6

    Ice Thickness and Volume Based on GPR, GPS and GIS: Example from the Heigou Glacier No.8, Bogda-Peak Region, Tianshan, China

    • 摘要: 本研究以天山博格达峰黑沟8号冰川为例,基于2009年探地雷达(GPR)冰川厚度测量资料以及高精度RTK-GPS(全球定位系统)定位数据,在地理信息系统(GIS)技术的支持下,开展了冰川厚度分布、冰储量分析及其变化特征研究.结果表明,黑沟8号冰川冰舌平均厚度为58.7 m,冰储量为115.1×106 m3,相当于水量103.5×106 m3;1986—2009年,冰舌平均减薄13±6 m,年均减薄约0.57±0.26 m,冰储量亏损达(25.5±11.8)×106 m3((22.9±10.6)×106 m3水当量),是该区气温显著升高的结果.相比反距离加权法和径向基函数法,普通克里格法插值精度较高(计算误差均值:-0.166 5;误差均方根:2.822),更适合于黑沟8号此类山地冰川的厚度分布研究;该冰川减薄速率与中国西部典型监测冰川近几十年的变化基本保持一致.本项研究将GPR、GPS和GIS技术综合运用于冰川学领域,可以有效解决数据获取、精确定位、空间分析等一系列问题,具有广阔的应用前景.



    • 图  1  黑沟8号冰川位置

      Fig.  1.  Location map of Heigou glacier No.8

      图  2  黑沟8号冰川雷达测厚路线分布

      Fig.  2.  GPR measuring lines of Heigou glacier No.8

      图  3  黑沟8号冰川C1-C2测线雷达图像

      Fig.  3.  Radar image along the sounding transect C1-C2 on Heigou glacier No.8

      图  4  基于普通克里格法的黑沟8号冰川冰舌厚度分布及1962—2009年冰川末端变化

      Fig.  4.  Ice thickness isoline map of Heigou glacier No.8 using ordinary kriging interpolation method and the terminus change from 1962 to 2009

      表  1  冰川厚度不同方法插值结果比较

      Table  1.   Comparison of ice thickness using different interpolation methods

      插值方法 参数模型 误差均值(MEAN) 误差均方根(RMS)
      反距离加权法(IDW) 指数为2 -0.785 0 7.663
      径向基函数法(RBF) 函数参数为35.715 -0.800 2 6.795
      普通克里格方法(OK) - -0.166 5 2.822
      下载: 导出CSV

      表  2  我国西部典型监测冰川近几十年变化比较

      Table  2.   Comparison of the changes of the typical monitored glaciers in western China in recent years

      冰川名称 位置 末端海拔(m) 厚度变化 面积变化 末端变化 资料来源
      时间段 年均减薄(m·a-1) 时间段 年均(km2·a-1) 时间段 年均(m·a-1)
      黑沟8号冰川 43°46'N, 88°23"E 3 380 1986——2009 0.57±0.26 (冰舌) 1962——2009 -0.002(冰舌) 1962——2009
      1959——1993
      -11
      -4.5
      本研究
      乌鲁木齐河源1号冰川 43°06'N, 86°49'E 3 736 1981——2006 0.40~0.72 (东支中轴线剖面) 1962——2006 -0.006 1993——2004 -3.5(东支)
      -5.8(西支)
      李忠勤等, 2007a
      科其喀尔冰川 41°49'N, 80°10'E 3 060 1981——2004 0.5~1.5 (冰舌) - 1974——2004 -12.7 谢昌卫等, 2006
      哈密庙尔沟冰川 43°03'N, 94°19'E 3 840 1981——2005 0.21 (海拔4295~4 357 m) - - 李忠勤等, 2007b
      海螺沟冰川 29°36'N, 101°57'E 2 910 1966——2009 1.1±0.4 - - Zhang et al., 2010
      下载: 导出CSV
    • Du, J., Yang, Q.H., Yan, J., et al., 2010. Hazard evaluation of secondary geological disaster based on GIS and information value method. Earth Sciences—Journal of China University of Geosciences, 35(2): 324-330 (in Chinese with English abstract). doi: 10.3799/dqkx.2010.034
      Farinotti, D., Huss, M., Bauder, A., et al., 2009. A method to estimate the ice volume and ice-thickness distribution of alpine glaciers. Journal of Glaciology, 55(191): 422-430. doi: 10.3189/002214309788816759
      Fischer, A., 2009. Calculation of glacier volume from sparse ice-thickness data, applied to Schaufelferner, Austria. Journal of Glaciology, 55(191): 453-460. doi: 10.3189/002214309788816740
      Hou, J.R., Yin, Z.N., Li, W.M., et al., 1998. The applied geostatistics. Geological Publ. House, Beijing (in Chinese).
      Jiang, Y., Li, Q., Zhang, X.K., et al., 2006. Kriging prediction of soil zinc in contaminated field by using an auxiliary variable. Chinese Journal of Applied Ecology, 17(1): 97-101 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-YYSB200601019.htm
      Kang, E.S., Cheng, G.D., Dong, Z.C., 2002. Glacier-snow water resources and mountain runoff in the arid area of Northwest China. Science Press, Beijing (in Chinese).
      Koch, J., Mennounos, B., Clague, J.J., 2009. Glacier change in Garibaldi Provincial Park, southern coast mountains, British Columbia, since the little ice age. Global and Planetary Change, 66(3-4): 161-178. doi: 10.1016/j.gloplacha.2008.11.006
      Li, T.W., 2003. Theory and application of GPS. Science Press, Beijing (in Chinese).
      Li, Z.Q., Shen, Y.P., Wang, F.T., et al., 2007a. Response of glacier melting to climate change—take Urumqi glacier No. 1 as an example. Journal of Glaciology and Geocryology, 29(3): 333-342 (in Chinese with English abstract). http://www.scienceopen.com/document?vid=0c3ad3b1-ad0b-422e-a392-7e635cb61a2d
      Li, Z.Q., Wang, F.T., Zhu, G.C., et al., 2007b. Basic features of the Miaoergou flat-topped glacier in east Tianshan Mountains and its thickness change over the past 24 years. Journal of Glaciology and Geocryology, 29(1): 61-65 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-BCDT200701009.htm
      Li, Z.Q., Li, K.M., Wang, L., 2010. Study on recent glacier changes and their impact on water resources in Xinjiang, North Western China. Quaternary Sciences, 30(1): 96-106 (in Chinese with English abstract).
      Li, Z.X., He, Y.Q., Wang, S.J., et al., 2009. Changes of some monsoonal temperate glaciers in Hengduan Mountains region during 1900-2007. Acta Geographica Sinica, 64(11): 1319-1330 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DLXB200911008.htm
      Li, Z.X., He, Y.Q., Wen, Y.H., et al., 2010. Response of runoff in high altitude area over the typical Chinese monsoonal temperate glacial region to climate warming. Earth Sciences—Journal of China University of Geosciences, 35(1): 43-50 (in Chinese with English abstract). doi: 10.3799/dqkx.2010.005
      Linton, D.L., 1963. The forms of glacial erosion. Institute of British Geographers Transactions, Blackwell Publishing, London, 33: 1-28.
      Liu, C.H., Kang, E.S., Liu, S.Y., et al., 1999. A study of arid land glacier changes and its impact on the runoff in the northwest. Science in China (Ser. D), 29(Suppl. 1): 55-62 (in Chinese).
      Liu, J.S., Chen, H., Yang, B.Y., et al., 2009. Comparison of interpolation methods on annual mean precipitation in Hebei Province. Acta Ecologica Sinica, 29(7): 3493-3500 (in Chinese with English abstract). http://www.oalib.com/paper/1400887
      Liu, S.Y., Ding, Y.J., Li, J., et al., 2006. Glaciers in response to recent climate warming in western China. Quaternary Sciences, 26(5): 762-771 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DSJJ200605010.htm
      Ma, H.L., Ma, Y., Xue, F.M., 2010. Variation characteristics of climate change at Tianchi in Tianshan Mountains in recent 49 years. Meteorological Science and Technology, 38(2): 209-213 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-QXKJ201002014.htm
      Paterson, W.S.B., 1994. The physics of glacier (Third Edition). Pergamon Press, Oxford.
      Paul, F., Kääb, A., Haeberli, W., 2007. Recent glacier changes in the Alps observed by satellite: consequences for future monitoring strategies. Global and Planetary Change, 56(1-2): 111-122. doi: 10.1016/j.gloplacha.2006.07.007
      Rivera, A., Casassa, G., Bamber, J.L., et al., 2005. Ice elevation changes of Glaciar Chico, southern Patagonia, using ASTER DEMs, aerial photographs and GPS data. Journal of Glaciology, 51(172): 105-112. doi: 10.3189/172756505781829557
      Shangguan, D.H., 2007. Glacier changes in Tarim interior river basin using 3S cold and arid regions environmental and engineering research institute. Chinese Academy of Sciences, Lanzhou (in Chinese).
      Shean, D.E., Marchant, D.R., 2010. Seismic and GPR surveys of Mullins glacier, McMurdo dry valleys, Antarctica: ice thickness, internal structure and implications for surface ridge formation. Journal of Glaciology, 56(195): 48-64. doi: 10.3189/002214310791190901
      Shi, H.D., Gao, Q.X., Zhuang, D.F., et al., 2008. Using RBFN model and GIS technique to assess wind erosion hazard in Inner Mongolia. Research of Environment Sciences, 21(5): 129-133 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-HJKX200805022.htm
      Shi, Y.F., 2005. Brief of glacier inventory of China. Shanghai Popular Science Press, Shanghai (in Chinese).
      Sun, B., He, M.B., Zhang, P., et al., 2003. Determination of ice thickness, subice topography and ice volume at glacier No. 1 in the Tianshan, China, by ground penetrating radar. Chinese Journal of Polar Research, 15(1): 35-44 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-JDYZ200301004.htm
      Tang, G.A., Yang, X., 2006. The experimental guide to spatial analysis of geographic information system based on ArcGIS. Science Press, Beijing (in Chinese).
      Wang, J.X., Wang, J., Lu, C.P., 2003. Problem of coordinate transformation between WGS-84 and BEIJING54. Journal of Geodesy and Geodynamics, 23(3): 70-73 (in Chinese with English abstract).
      Wang, P.Y., Li, Z.Q., Gao, W.Y., 2011a. Rapid shrinking of glaciers in the middle Qilian Mt. region of Northwest China, during the last ~50 years. Journal of Earth Science, 22(4): 539-548. doi: 10.1007/s12583-011-0195-4
      Wang, P.Y., Li, Z.Q., Li, H.L., 2011b. Ice volume changes and their characteristics for representative glacier against the background of climatic warming—a case study of Urumqi glacier No. 1, Tianshan, China. Journal of Natural Resources, 26(7): 1189-1198 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-ZRZX201107010.htm
      Wang, Y.S., Qiu, J.Q., 1983. Distributive features of the glaciers in Bogda region, Tian Shan. Journal of Glaciology and Geocryology, 5(3): 17-24 (in Chinese with English abstract).
      Wang, Z.T., 1991. A discussion on the questions of development of Heigou glacier No. 8, Bogda-peak region. Journal of Glaciology and Geocryology, 13(2): 141-158 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-BCDT199102004.htm
      Wu, G.H., Ageta, Y., Qiu, J.Q., 1983a. Physical geographic features and climate conditions of glacial development in Bogda area, Tianshan. Journal of Glaciology and Geocryology, 5(3): 5-16 (in Chinese with English abstract).
      Wu, G.H., Zhang, S.Y., Wang, Z.X., 1983b. Retreat and advance of Modern glaciers in Bogda, Tianshan. Journal of Glaciology and Geocryology, 5(3): 143-152 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-BCDT198303015.htm
      Xie, C.W., Ding, Y.J., Liu, S.Y., et al., 2006. Variation of Keqikaer glacier terminus in Tomur Peak during last 30 years. Journal of Glaciology and Geocryology, 28(5): 672-677 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-BCDT200605007.htm
      Yao, T.D., Liu, S.Y., Pu, J.C., et al., 2004. Recent glacial retreat in high-Asia in China and its impact on water resources in Northwest China. Science in China (Series D), 34(6): 535-543 (in Chinese). doi: 10.1360/03yd0256
      Zhang, H.J., Wang, X.L., Ding, L., et al., 2007. Carbonate diagenesis controlled by glacioeustatic sea-level changes: a case study of the Carboniferous-Permian boundary section at Xikou, Zhen'an County, Shaanxi Province, China. Earth Sciences—Journal of China University of Geosciences, 32(3): 329-338 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DQKX200703004.htm
      Zhang, X.S., Zhu, G.C., Qian, S.L., et al., 1985. Radar measuring ice thickness of No. 1 glacier at the source of Urumqi River, Tianshan. Journal of Glaciology and Geocryology, 7(2): 153-162 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-BCDT198502006.htm
      Zhang, Y., Fujita, K., Liu, S.Y., et al., 2010. Multi-decadal ice-velocity and elevation changes of a monsoonal maritime glacier: Hailuogou glacier, China. Journal of Glaciology, 56(195): 65-74. doi: 10.3189/002214310791190884
      杜军, 杨青华, 严嘉, 等, 2010. 基于GIS与信息量模型的汶川次生地质灾害危险性评价. 地球科学——中国地质大学学报, 35(2): 324-330. http://www.cnki.com.cn/Article/CJFDTotal-DQKX201002018.htm
      侯景儒, 尹镇南, 李维明, 等, 1998. 实用地质统计学. 北京: 地质出版社.
      姜勇, 李琪, 张晓珂, 等, 2006. 利用辅助变量对污染土壤锌分布的克里格估值. 应用生态学报, 17(1): 97-101. doi: 10.3321/j.issn:1001-9332.2006.01.020
      康尔泗, 程国栋, 董增川, 2002. 中国西北干旱区冰雪水资源与出山径流. 北京: 科学出版社.
      李天文, 2003. GPS原理及应用. 北京: 科学出版社.
      李忠勤, 沈永平, 王飞腾, 等, 2007a. 冰川消融对气候变化的响应——以乌鲁木齐河源1号冰川为例. 冰川冻土, 29(3): 333-342.
      李忠勤, 王飞腾, 朱国才, 等, 2007b. 天山庙尔沟平顶冰川的基本特征和过去24 a间的厚度变化. 冰川冻土, 29(1): 61-65. http://www.cnki.com.cn/Article/CJFDTotal-bcdt200701009.htm
      李忠勤, 李开明, 王林, 2010. 新疆冰川近期变化及其对水资源的影响研究. 第四纪研究, 30(1): 96-106. doi: 10.3969/j.issn.1001-7410.2010.01.09
      李宗省, 何元庆, 王世金, 等, 2009.1900—2007年横断山区部分海洋型冰川变化. 地理学报, 64(11): 1319-1330. http://www.cnki.com.cn/Article/CJFDTotal-DLXB200911008.htm
      李宗省, 何元庆, 温煜华, 等, 2010. 我国典型海洋型冰川区高海拔区输出水量变化对气候变暖的响应. 地球科学——中国地质大学学报, 35(1): 43-50. http://www.cnki.com.cn/Article/CJFDTotal-DQKX201001008.htm
      刘潮海, 康尔泗, 刘时银, 等, 1999. 西北干旱区冰川变化及其径流效应研究. 中国科学(D辑), 29(增1): 55-62. http://qikan.cqvip.com/Qikan/Article/Detail?id=4000778645
      刘劲松, 陈辉, 杨彬云, 等, 2009. 河北省年均降水量插值方法比较. 生态学报, 29(7): 3493-3500. doi: 10.3321/j.issn:1000-0933.2009.07.006
      刘时银, 丁永建, 李晶, 等, 2006. 中国西部冰川对近期气候变暖的响应. 第四纪研究, 26(5): 762-771. doi: 10.3321/j.issn:1001-7410.2006.05.011
      马洪亮, 马燕, 薛福民, 2010. 天山天池近49年气候变化特征. 气象科技, 38(2): 209-213. doi: 10.3969/j.issn.1671-6345.2010.02.013
      上官冬辉, 2007. 基于3S的塔里木河流域冰川变化应用研究. 兰州: 中国科学院寒区旱区环境与工程研究所.
      师华定, 高庆先, 庄大方, 等, 2008. 基于径向基函数神经网络(RBFN)的内蒙古土壤风蚀危险度评价. 环境科学研究, 21(5): 129-133. http://www.cnki.com.cn/Article/CJFDTotal-HJKX200805022.htm
      施雅风, 2005. 简明中国冰川目录. 上海: 上海科学普及出版社.
      孙波, 何茂兵, 张鹏, 等, 2003. 天山1号冰川厚度和冰下地形探测与冰储量分析. 极地研究, 15(1): 35-44. doi: 10.3969/j.issn.1674-9928.2003.01.004
      汤国安, 杨昕, 2006. ARCGIS地理信息系统空间分析实验教程. 北京: 科学出版社.
      王解先, 王军, 陆彩萍, 2003. WGS-84与北京54坐标的转换问题. 大地测量与地球动力学, 23(3): 70-73. http://www.cnki.com.cn/Article/CJFDTotal-DKXB200303013.htm
      王璞玉, 李忠勤, 李慧林, 2011b. 气候变暖背景下典型冰川储量变化及其特征分析——以天山乌鲁木齐河源1号冰川为例. 自然资源学报, 26(7): 1189-1198. http://www.cnki.com.cn/Article/CJFDTotal-ZRZX201107010.htm
      王银生, 仇家琪, 1983. 天山博格达峰地区现代冰川分布特征. 冰川冻土, 5(3): 17-24. http://www.cnki.com.cn/Article/CJFDTotal-BCDT198303003.htm
      王宗太, 1991. 博格达峰黑沟8号冰川发育若干问题浅析. 冰川冻土, 13(2): 141-158. http://www.cnki.com.cn/Article/CJFDTotal-BCDT199102004.htm
      伍光和, 上田丰, 仇家琪, 1983a. 天山博格达山脉的自然地理特征及冰川发育的气候条件. 冰川冻土, 5(3): 5-16. http://www.cnki.com.cn/Article/CJFDTotal-BCDT198303002.htm
      伍光和, 张顺英, 王仲祥, 1983b. 天山博格达峰现代冰川的进退变化. 冰川冻土, 5(3): 143-152. http://www.cnki.com.cn/article/cjfdtotal-bcdt198303015.htm
      谢昌卫, 丁永建, 刘时银, 等, 2006. 近30a来托木尔峰南麓科其喀尔冰川冰舌区变化. 冰川冻土, 28(5): 672-677. doi: 10.3969/j.issn.1000-0240.2006.05.008
      姚檀栋, 刘时银, 蒲健成, 等, 2004. 高亚洲冰川的近期退缩及其对西北水资源的影响. 中国科学(D辑), 34(6): 535-543. http://www.cnki.com.cn/article/cjfdtotal-jdxk200406005.htm
      张海军, 王训练, 丁林, 等, 2007. 冰川型海平面变化控制下的台地碳酸盐岩成岩作用: 以陕西镇安西口石炭—二叠系界限剖面为例. 地球科学——中国地质大学学报, 32(3): 329-338. http://www.cnki.com.cn/Article/CJFDTotal-DQKX200703004.htm
      张祥松, 朱国才, 钱嵩林, 等, 1985. 天山乌鲁木齐河源1号冰川雷达测厚. 冰川冻土, 7(2): 153-162. http://www.cnki.com.cn/Article/CJFDTotal-BCDT198502006.htm
