    博茨瓦纳Sua盐湖地下卤水来源及成因

    单慧媚 马腾 谭婷 罗朝晖 祁志冲 翟明哲 LekgoweOteng M.

    单慧媚, 马腾, 谭婷, 罗朝晖, 祁志冲, 翟明哲, LekgoweOteng M., 2013. 博茨瓦纳Sua盐湖地下卤水来源及成因. 地球科学, 38(3): 607-615. doi: 10.3799/dqkx.2013.061
    引用本文: 单慧媚, 马腾, 谭婷, 罗朝晖, 祁志冲, 翟明哲, LekgoweOteng M., 2013. 博茨瓦纳Sua盐湖地下卤水来源及成因. 地球科学, 38(3): 607-615. doi: 10.3799/dqkx.2013.061
    SHAN Hui-mei, MA Teng, TAN Ting, LUO Zhao-hui, QI Zhi-chong, ZHAI Ming-zhe, Lekgowe Oteng M., 2013. Sources and Genesis of Subsurface Brine in Sua Pan, Botswana. Earth Science, 38(3): 607-615. doi: 10.3799/dqkx.2013.061
    Citation: SHAN Hui-mei, MA Teng, TAN Ting, LUO Zhao-hui, QI Zhi-chong, ZHAI Ming-zhe, Lekgowe Oteng M., 2013. Sources and Genesis of Subsurface Brine in Sua Pan, Botswana. Earth Science, 38(3): 607-615. doi: 10.3799/dqkx.2013.061

    博茨瓦纳Sua盐湖地下卤水来源及成因

    doi: 10.3799/dqkx.2013.061
    基金项目:

    国家自然科学基金项目 40872157

    国家自然科学基金项目 40830748

    教育部新世纪优秀人才支持计划 NCET-07-0773

    中央高校基本科研业务费专项基金资助 CUGL100501

    详细信息
      作者简介:

      单慧媚(1985-), 女, 博士, 主要从事同位素生物地球化学方面研究. E-mail: shanhuimei1985@163.com

      通讯作者:

      马腾, E-mail: mateng@cug.edu.cn

    • 中图分类号: X142;P592

    Sources and Genesis of Subsurface Brine in Sua Pan, Botswana

    • 摘要: Sua盐湖是博茨瓦纳面积最大的盐湖之一, 是南半球重要的天然碱资源.为进一步揭示该盐湖的成因, 对盐湖区地下水、地表水以及晒盐场盐结晶进行了常规阴阳离子含量、D、18O和37Cl同位素组成及地下水14C年龄分析.水化学结果显示Sua盐湖的地下卤水具有富Na和K, 贫Ca和Mg的特征.氢氧同位素关系和37Cl结果显示, 附近河流地表水与Sua盐湖地下卤水具有密切的水力联系, 而地下水对其补给作用较弱(37Cl差异为0.04‰~0.06‰).TDS-γNa/γCl关系揭示Sua盐湖地下卤水受到盐岩地层溶滤作用的影响(γNa/γCl≈1), 而14C年龄(距今约2万年)表明古气候的波动变化是其重要影响因素.基于以上认识, 运用PHREEQC软件对Sua盐湖地下卤水进行反向地球化学模拟, 结果表明地表水的强烈蒸发浓缩以及附近地下水对盐岩地层的溶滤是控制Sua盐湖卤水形成的主要因素.



    • 图  1  马卡迪卡迪流域地理位置、地形和降雨量

      Fig.  1.  Makgadikgadi Pans showing locations, terrain and rainfall

      图  2  马卡迪卡迪流域水文模型及Sua盐湖采样点位置

      Fig.  2.  Hydrological model for the Makgadikgadi, locations and sampling sites of Sua Pan

      图  3  水样的Piper三线图

      Fig.  3.  Piper graph of water samples

      图  4  Sua盐湖水样氢氧同位素组成变化图(SMOW,标准平均大洋水)

      Fig.  4.  Variations of δD and δ18O values of water samples collected from Sua Pan

      图  5  Sua盐湖北部及附近水样γNa/γCl与TDS分布

      Fig.  5.  Relationship between γNa/γCl and TDS of water samples from northern part of Sua Pan

      表  1  Sua盐湖水样采集信息

      Table  1.   Water samples collected from Sua pan

      样品编号 SW01 SW02 GW03 GW04 BW06 SW07
      经纬度 26°11.224′E 26°22.055′E 26°27.126′E 26°28.373′E 25°57.871′E 26°14.439′E
      20°12.798′S 20°05.645′S 20°30.683′S 20°30.517′S 20°27.852′S 20°17.889′S
      类型 地表水 地表水 地下水 地下水 地下卤水 地表水
      地点 Nata河 Nata河 Dukwi地区 Dukwi地区 Sua盐湖 Nata国家公园
      采样深度 0~30 cm 0~30 cm >36.93 m >34.50 m 约20 m 0~30 cm
      下载: 导出CSV

      表  2  水样的水化学分析结果

      Table  2.   Results of hydrochemical analysis of water samples

      指标 SW01 SW02 GW03 GW04 BW06 SW07
      EC(μs/cm) 1 024.0 138.3 1 556.0 1 562.0 183 300.0 4 333.0
      pH 8.80 8.89 7.16 7.08 9.50 8.83
      温度(℃) 32.9 26.4 28.8 27.8 29.0 30.3
      HCO3-(mg/L) 130.43 85.81 583.50 518.97 4 118.85 364.52
      CO32-(mg/L) 49.52 0.00 0.00 0.00 15 445.06 210.80
      Cl-(mg/L) 207.44 3.20 216.75 252.79 41 640.00 1 076.08
      SO42-(mg/L) 20.58 0.90 93.22 95.40 12 480.00 97.90
      K+(mg/L) 14.91 6.33 4.81 4.14 2 108.90 49.23
      Ca2+(mg/L) 16.81 16.26 23.08 16.34 7.30 10.64
      Mg2+(mg/L) 3.05 2.78 35.22 30.94 3.50 0.78
      Na+(mg/L) 185.30 5.43 269.76 296.44 46 278.01 1 028.80
      TDS(g/L) 0.630 0.121 1.229 1.218 112.655 2.841
      阴阳离子平衡(%) 0.981 4.486 1.548 0.017 4.371 4.808
      库尔洛夫式 Cl·HCO3-Na HCO3-Ca·Na HCO3·Cl-Na HCO3·Cl-Na Na-Cl Na-Cl
      下载: 导出CSV

      表  3  样品的37Cl测试结果

      Table  3.   δ37Cl values of water and salt crystals samples from Sua Pan

      样品 δ 37Cl(‰) d值(‰)
      GW03 0.22 0.06
      GW04 0.24 0.04
      BW06 0.18 0.02
      盐结晶 0.29 0.07
      下载: 导出CSV

      表  4  Sua盐湖卤水的14C年龄

      Table  4.   14C age of brine water from Sua Pan

      编号 现代碳百分数(%) 14C年龄(ka) 校正后年龄(ka)
      BW06 13.464 16.580±0.27 21.459
      下载: 导出CSV

      表  5  Sua盐湖卤水演化的地球化学模型(单位:mol/L)

      Table  5.   Geochemistry models for the evolution of brines in Sua pan

      起点 终点 H2O 岩盐 方解石 钾长石 石膏 白云石 钠长石 CO2
      SW01 BW06 -1.261e+4 1.538e-1 -1.891e-1 -3.514e-2 1.220e-1 -2.844e-2 3.514e-2 3.779e-1
      SW02 BW06 -7.794e+4 1.418 -6.526e-1 -1.756e-1 1.578e-1 -1.605e-1 1.756e-1 -6.335e-1
      SW07 BW06 -2.567e+3 - -1.320e-1 -7.751e-3 1.210e-1 -1.356e-3 7.751e-3 2.735e-1
      BW06 -2.578e+3 - -1.302e-1 - 1.191e-1 -1.362e-3 - -
      GW03 BW06 -2.869e+3 1.271 -7.363e-2 4.542e-2 1.197e-1 -7.626e-2 -4.542e-2 -8.165e-2
      GW04 BW06 -2.720e+3 1.242 -7.786e-2 4.661e-2 1.212e-1 -6.354e-2 -4.661e-2 -7.031e-2
      注:负值表示从水溶液中迁移出来的摩尔量;正值表示进入水溶液的摩尔量.
      下载: 导出CSV
    • Burrough, S.L., Thomas, D.S.G., Bailey, R.M., 2009. Mega-Lake in the Kalahari: A Late Pleistocene Record of the Palaeolake Makgadikgadi System. Quaternary Science Reviews, 28(15-16): 1392-1411. doi: 10.1016/j.quascirev.2009.02.007
      Cao, B.X., 1995. Geomorphology and Quaternary Geology. China University of Geosciences Press, Wuhan (in Chinese).
      Clayton, R.N., Friedman, I., Graf, D.L. et al., 1966. The Origin of Saline Formation Waters 1. Isotopic Composition. Journal of Geophysical Research-Atmospheres, 71 (16): 3869-3882. doi: 10.1029/JZ071i016p03869
      Eckardt, F.D., Bryant, R.G., McCulloch, G., et al., 2008. The Hydrochemistry of a Semi-arid Pan Basin Case Study: Sua Pan, Makgadikgadi, Botswan. Applied Geochemistry, 23 (6): 1563-1580. doi: 10.1016/j.apgeochem.2007.12.033
      Fan, Q.S., Ma, H.Z., Tan, H.B., et al., 2007. Characteristics and Origin of Brines in Western Qaidam Basin. Geochimica, 36(6): 601-611(in Chinese with English abstract). http://d.wanfangdata.com.cn/periodical/dqhx200706008
      Holmgren, K., Lee-Thorp, J.A., Cooper, G.R.J., et al., 2003. Persistent Millennial-Scale Climatic Variability over the Past 25 000 Years in Southern Africa. Quaternary Science Reviews, 22(21-22): 2311-2326. doi: 10.1016/S0277-3791(03)00204-X
      Liu, H.Y., 2002. Quaternary Ecology and Global Change. Science Press, Beijing (in Chinese).
      Liu, W.G., Xiao, Y.K., Sun, D.P., et al., 1995. Characteristics and Significance of Chlorine Isotope of Brine and Deposits in the Mahai Salt Lakes. Journal of Salt Lake Science, 3(2): 29-33(in Chinese with English abstract). http://www.researchgate.net/publication/285751263_Characteristics_and_significance_of_chlorine_isotope_of_brine_and_deposits_in_the_Mahai_salt_lakes
      Liu, W.G., Xiao, Y.K., Sun, D.P., et al., 1996. Chlorine Isotopic Composition in Qaidam Basin. Geochimica, 25(3): 296-303 (in Chinese with English abstract).
      McCulloch, G.P., Irvine, K., Eckardt, F., et al., 2008. Hydrochemical Fluctuations and Crustacean Community Composition in an Ephemeral Saline Lake (Sua Pan, Makgadikgadi Botswana). Hydrobiologia, 596(1): 31-46. doi: 10.1007/s10750-007-9055-8
      Ringrose, S., Huntsman-Mapila, P., Kampunzu, A.B., et al., 2005. Sedimentological and Geochemical Evidence for Palaeo-Environmental Change in the Makgadikgadi subbasin, in Relation to the MOZ Rift Depression, Botswana. Palaeo, 217(3-4): 265-287. doi: 10.1016/j.palaeo.2004.11.024
      Servant, M., Maley, J., Turcq, B., et al., 1993. Tropical Forest Changes during the Late Quaternary in African and South American Lowlands. Global and Planetary Change, 7(1-3): 25-40. http://www.researchgate.net/profile/Jean_Maley2/publication/32975443_Tropical_forest_changes_during_the_Late_Quaternary_in_African_and_South_American_lowlands/links/0deec521daf6da3824000000.pdf
      Shaw, P.A., Cooke, H.J., 1986. Geomorphic Evidence for the Late Quaternary Palaeoclimates of the Middle Kalahari of Northern Botswana. Catena, 13(4): 349-359. doi: 10.1016/0341-8162(86)90009-3
      Shaw, P.A., Thomas, D.S., G., Nash, D.J., 1992. Late Quaternary Fluvial Activity in the Dry Valleys (mekgacha) of the Middle and Southern Kalahari, Southern Africa. Journal of Quaternary Science, 7(4): 273-281. doi: 10.1002/jqs.3390070402
      Taylor, H.P., 1974. The Application of Oxygen and Hydrogen Isotope Studies to Problems of Hydrothermal Alteration and Ore Deposition. Economic Geology, 69 (6): 843-883. doi: 10.2113/gsecongeo.69.6.843
      Thomas, D.S.G., Shaw, P.A., 1991. The Kalahari Environment. Cambridge University Press, Cambridge.
      Wan, J.W., Liu, C.F., Chao, N.Y., et al., 2003. Isotope Hydrology Theory and Practice. China University of Geosciences Press, Wuhan (in Chinese).
      Wang, M.L., Yang, Z.C., Liu, C.L., et al., 1996. The Northern Qaidam Basin Salt Lake Potash Deposit and Its Development Prospects. Geological Publishing House, Beijing (in Chinese).
      Wang, Z.Y., Meng, G.L., Wang, S.Q., 2003. Geochemistry Modeling of Quaternary Subsurface Brines in South Coast of the Laizhou Bay, the Bohai Sea—Taking Brines from Core-aoli501 in Changyi Area as an Example. Marine Geology & Quaternary Geology, 23(1): 49-53 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-HYDZ200301008.htm
      Xiao, Y.K., Jin, L., Liu, W.G., et al., 1994. Chlorine Isotope Composition in Big Tsaidam Lake. Chinese Science Bulletin, 39(14): 1319-1322(in Chinese). doi: 10.1360/csb1994-39-14-1319
      Yang, L., Liu, S.F., Wang, J.S., 1998. General Geology Brief Tutorial. China University of Geosciences Press, Wuhan (in Chinese).
      Zhang, C.D., 2006. Present Situation of Trona Development in Botswana. Soda Industry, (4): 3-6(in Chinese).
      Zhang, Z.G., 2009. Unconfined Brine Hydrochemistry Characteristic and Brine Cause Analysis of East Section of Qarhan Salt Lake. Journal of Salt Lake Research, 17(1): 19-26(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-YHYJ200901006.htm
      Zheng, M.P., 2006. Salinology: Research and Prospects. Geological Review, 52(6): 737-746(in Chinese with English abstract). http://www.cqvip.com/Main/Detail.aspx?id=23387131
      Zheng, Y.H., Chen, J.F., 2000. Stable Isotope Geochemistry. Science Press, Beijing (in Chinese).
      曹博勋, 1995. 地貌学及第四纪地质学. 武汉: 中国地质大学出版社.
      樊启顺, 马海州, 谭红兵, 等, 2007. 柴达木盆地西部卤水特征及成因探讨. 地球化学, 36 (6): 601-611. doi: 10.3321/j.issn:0379-1726.2007.06.008
      刘鸿雁, 2002. 第四纪生态学与全球变化. 北京: 科技出版社.
      刘卫国, 肖应凯, 孙大鹏, 等, 1995. 马海盐湖区卤水和盐类矿物的氯同位素特征及意义. 盐湖研究, 3(2): 29-33. https://www.cnki.com.cn/Article/CJFDTOTAL-YHYJ502.004.htm
      刘卫国, 肖应凯, 孙大鹏, 等, 1996. 柴达木盆地氯同位素组成特征. 地球化学, (3): 296-303. doi: 10.3321/j.issn:0379-1726.1996.03.011
      万军伟, 刘存富, 晁念英, 等, 2003. 同位素水文学理论与实践. 武汉: 中国地质大学出版社.
      王弭力, 杨智琛, 刘成林, 等, 1996. 柴达木盆地北部盐湖钾矿床及其开发前景. 北京: 地质出版社.
      王珍岩, 孟广兰, 王少青, 2003. 渤海莱州湾南岸第四纪地下卤水演化的地球化学模拟. 海洋地质与第四纪地质. 23(1): 49-53. https://www.cnki.com.cn/Article/CJFDTOTAL-HYDZ200301008.htm
      肖应凯, 金琳, 刘卫国, 等, 1994. 大柴达木湖的氯同位素组成. 科学通报, 39(14): 1319-1322. https://www.cnki.com.cn/Article/CJFDTOTAL-KXTB199414021.htm
      杨伦, 刘少峰, 王家生, 1998. 普通地质学简明教程. 武汉: 中国地质大学出版社.
      张晨鼎, 2006. 博茨瓦纳天然碱的开发现状. 纯碱工业, (4): 3-6. doi: 10.3969/j.issn.1005-8370.2006.04.001
      张兆广, 2009. 察尔汗盐湖东段潜卤水水文地球化学特征及卤水成因分析. 盐湖研究, 17 (1): 19-26. https://www.cnki.com.cn/Article/CJFDTOTAL-YHYJ200901006.htm
      郑绵平, 2006. 盐湖学的研究与展望. 地质论评, 52 (6): 737-746. doi: 10.3321/j.issn:0371-5736.2006.06.003
      郑永红, 陈江峰, 2000. 稳定同位素地球化学. 北京: 科学出版社.
