Genetic Mechanism of T2 Reflector Fault Dense Zones in Northern Songliao Basin
-
摘要: 松辽盆地北部T2反射层断裂与中浅层油气的运聚成藏关系紧密, 揭示T2反射层断裂密集带的成因机制对指导油气勘探至关重要.基于松辽盆地北部区域地震解释, 从分析断裂发育特征着手, 以断裂形成演化过程为主线, 系统剖析了盆地演化不同阶段断裂的变形机制, 揭示了T2反射层断裂密集带的形成机制及其对油气运聚成藏的指示作用.研究表明, T2反射层断裂密集带是在断陷演化基础上, 在断陷期断裂先存构造、泉一二段塑性泥岩盖层水平拆离作用和近EW向拉张应力场的控制下形成的, 全区以近SN向拉张机制伸展型密集带为主, NE向、NW向和近EW向斜拉机制调节型密集带和走滑调节型密集带零星分布.盆地反转期受断陷半地堑、基底深大断裂和左旋压扭变形场控制形成反转构造带的同时, 反转构造带内的断裂密集带被逆时针旋转改造而定型, 呈NW-NNW向展布为主.反转构造带内T2反射层NW-NNW向断裂密集带边部断裂和未反转区带内T2反射层近SN向断裂密集带边部断裂长期活动, 与油气大量生排烃时期匹配, 是中浅层油气运聚成藏的油源断层.Abstract: The relationship between T2 reflector fault and hydrocarbon accumulation reservoir of middle-shallow layer is close, which proves genetic mechanism of T2 reflector fault dense zones is important for hydrocarbon exploration. Based on the northern Songliao basin regional seismic interpretation, the analysis of the development characteristics and the formation and evolution of fault, we systematically analyze fault deformation mechanism at different stages, which reveal formation mechanism of T2 reflector fault dense zones and indication of hydrocarbon exploration. This study shows that T2 reflector fault dense zones have been formed through the following three preriods, namely, the initial faulted period, pre-structure in faulted period, and level detachment of plastic mudstone cap rock and EW tension stress field in Quanyi member. Stretch dense zones of SN tension stress mechanism dominates the region. Accommodation and strike slip accommodation dense zones of NE, NW and EW oblique stretch mechanism is fragmentary in distribution. Sinistral compresso-shear deformation field, half grabens during faulted period and basal huge faults jointly control the formation of subprime anticlines and structural inversion belts during reversed period, meanwhile, fault dense zones of structural inversion belts reform and setting as main NW-NNW by counterclockwise rotation. Edge fault in T2 reflector NW-NNW fault dense zones of structural inversion belts and SN fault dense zones of structural non-inversion belts are long-term activity, of which matches with hydrocarbon generation and expulsion phase in time. They are oil-migrating faults of hydrocarbon accumulation reservoir in middle-shallow layer.
-
图 1 松辽盆地北部工区位置及T2反射层断裂密集带平面、剖面特征
a.T2反射层断裂和断裂密集带分布;b.构造层划分及T2反射层断裂剖面特征(剖面位置见图 1a)
Fig. 1. Work area position, plane and profile of T2 reflector fault dense zones in Northern Songliao basin
图 6 先存构造走滑递进位移引起的浅部地层变形过程(Harding and Lowell, 1979)
Fig. 6. Pre-structure Strike-slip progression displacement caused by formation of low layer
-
Amilibia, A., McClay, K.R., Sabat, F., et al., 2005. Analogue Modeling of Inverted Oblique Rift Systems. Geologica Acta, 3(3): 251-271. http://www.redalyc.org/articulo.oa?id=50530304 Chen, X., Li, Z.Q., Chen, J.L., et al., 2010. Determination of the Reverse Period of Songliao Basin, China. Geological Bulletin of China, 29(2-3): 305-311(in Chinese with English abstract). http://d.wanfangdata.com.cn/Periodical/zgqydz201002015 Fang, L.M., Li, Y.X., Yin, J.Y., et al., 2003. Characters of Reverse Tectonics and Its Forming Mechanism in Late of Fault Depression in Songliao Basin. Oil Geophysical Prospecting, 38(2): 190-193(in Chinese with English abstract). http://www.zhangqiaokeyan.com/academic-journal-cn_oil-geophysical-prospecting_thesis/0201217963457.html Feng, Z.Q., Zhang, S., Fu, X.L., 2012. Depositional Evolution and Accumulation Response of Yaojia-Nenjiang Formation in Songliao Basin. Earth Science Frontiers, 19(1): 78-88(in Chinese with English abstract). http://d.wanfangdata.com.cn/periodical/dxqy201201012 Fu, X.F., Wang, P.Y., Lv, Y.F., et al., 2007. Tectonic Features and Control of Oil-Gas Accumulation in the West Slope of Songliao Basin. Chinese Journal of Geology, 42(2): 209-222(in Chinese with English abstract). doi: 10.1007/s10488-005-0002-6 Fu, X.L., Zhang, S., Liang, J.P., 2010. Characteristics of Hydrocarbon Accumulation in the Shallow Secondary Reservoirs in the Northern Songliao Basin. Natural Gas Industry, 30(4): 29-34(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-TRQG201004010.htm Harding, T.P., 1984. Structural Inversion at Rambutan Oil Field, South Sumatra Basin. AAPG Bullt. , 3: 33-362. Harding, T.P., Lowell, J.D., 1979. Structural Styles, Their Plate-Tectonic Habitats, and Hydrocarbon Traps in Petroleum Provinces. American Assoc. Petroleum Geol. Bull. , 63(7): 1016-1058. http://adsabs.harvard.edu/abs/1979BAAPG..69.1016H Hou, G.T., Feng, D.C., Wang, W.M., et al., 2004. Reverse Structures and Their Impacts on Hydrocarbon Accumulation in Songliao Basin. Oil & Gas Geology, 25(1): 49-53(in Chinese with English abstract). http://www.researchgate.net/publication/288942797_Reverse_structures_and_their_impacts_on_hydrocarbon_accumulation_in_Songliao_Basin Hu, W.S., 1995. "T2" Faults System and Early Qingshankou Stretched Rifiting in Songliao Basin. Petroleum Exploration and Development, 22(2): 8-12(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SKYK502.001.htm Hu, W.S., Lü, B.Q., Zhang, W.J., et al., 2005. An Approach to Tectonic Evolution and Dynamics of the Songliao Basin. Chinese Journal of Geology, 40(1): 16-31(in Chinese with English abstract). http://d.wanfangdata.com.cn/Periodical/dzkx200501002 Koopman, A., Speksnijder, A., Horsfield, W.T., 1987. Sandbox Model Studies of Inversion Tectonics. Tectonophysics, 137(1-4): 379-388. doi: 10.1016/0040-1951(87)90329-5 Li, J., Huang, Z.L., Liu, B.Z., et al., 2008. Control Effects of Spreading Structure and Reversal Structure on Hydrocarbon Distribution—An Example from Dongnan Uplift in Songliao Basin. Xinjiang Petroleum Geology, 29(1): 19-21(in Chinese with English abstract). http://www.zhangqiaokeyan.com/academic-journal-cn_xinjiang-petroleum-geology_thesis/0201218676347.html Liu, D.L., Chen, F.J., Wen, X.Q., 1996. Analysis on the Rigin of T2 Post-Rift Formations in Songliao Basin. Journal of Daqing Petroleum Institute, 20(1): 23-23(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DQSY601.005.htm McClay, K.R., 1995. The Geometries and Kinematics of Inverted Fault Systems: A Review of Analogue Model Studies. Geological Society, 88: 97-118. doi: 10.1144/GSL.SP.1995.008.01.07 Meng, Q.A., Yang, Y.B., Jin, M.Y., 2006. Controlling Role of Faults to Giant Qingshen Gas Field in Songliao Basin. Acta Petrolei Sinica, 27(Suppl. ): 14-17(in Chinese with English abstract). http://www.researchgate.net/publication/292871439_Controlling_role_of_faults_to_giant_Qingshen_Gas_Field_in_Songliao_Basin Mitra S., 1993. Geometry and Kinematic Evolution of Inversion Structures. AAPG Bull. , 77(7): 1159-1191. http://www.researchgate.net/publication/255918756_Geometry_and_Kinematic_Evolution_of_Inversion_Structures Shi, S.S., Ren, J.Y., Zhang, S., et al., 2012. Sequence Stratigraphic Framework and Its Formation Mechanism of Post-Rift Inversion Successions in North of Songliao Basin, China. Earth Science—Journal of China University of Geosciences, 37(3): 545-555(in Chinese with English abstract). http://d.wanfangdata.com.cn/Periodical/dqkx201203015 Song, Y., Ren, J.Y., Yang, H.Z., et al., 2010. Characteristics and Dynamic Background of Bottom Boundary in Yaojia Formation of The Northern Songliao Basin. Acta Petrolei. Sinica, 31(2): 187-195(in Chinese with English abstract). http://www.researchgate.net/publication/283945513_Characteristics_and_dynamic_background_of_bottom_boundary_in_Yaojia_Formation_of_the_northern_Songliao_Basin Ventisette, C.D., Montanari, D., Sani, F., et al., 2006. Basin Inversion and Fault Reactivation in Laboratory Experiments. Journal of Structural Geology, 28(11): 2067-2083. doi: 10.1016/j.jsg.2006.07.012 Yin, J.Y., Liu, H.F., Chi, H.J., 2002. Evolution and Gas Accumulation of Xujiaweizi Depression in Songliao Basin. Acta Petrolei. Sinica, 23(2): 26-29(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SYXB200202008.htm Yu, D., Lu, Y.F., Fu, X.F., et al., 2010. Characteristics of Fault Structure and Its Control on Deep Gas Reservoir in Xujiaweizi Fault Depression, Songliao Basin. Geological Review, 56(2): 237-245(in Chinese with English abstract). http://www.researchgate.net/publication/292702343_Characteristics_of_fault_structure_and_its_control_on_deep_gas_reservoir_in_Xujiaweizi_fault_depression_Songliao_Basin Yun, J.B., Jin, Z.J., Yin, J.Y., et al., 2008. Reflection Feature and Geodynamic Significance of Deep Seismic Reflection in Xujiaweizi Region of North Songliao Basin. Earth Science Frontiers, 15(4): 307-314(in Chinese with English abstract). http://www.researchgate.net/publication/288870267_Reflection_feature_and_geodynamic_significance_of_deep_seismic_reflection_in_Xujiaweizi_region_of_north_Songliao_Basin Zhang, G.C., Xu, H., Liu, H.F., et al., 1996. Inversion Structures in Relation to Oil and Gas Field Distribution in Songliao Basin. Acta Petrolei Sinica, 17(2): 9-14(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SYXB602.001.htm Zhang, L., Yue, L.P., Yang, Y.J., et al., 2002. Fracture Features of Reversed Basin: Taking Sanzhao Area of Songliao Basin for Example. Oil & Gas Geology, 23(4): 361-363(in Chinese with English abstract). http://www.cnki.com.cn/Article/CJFDTotal-SYYT200204011.htm Zhang, W.J., Hu, W.S., Guan, D.Y., et al., 2004. An Analysis of Tectonic Inversion in Songliao Basin China. Offshore Oil and Gas, 16(4): 230-234(in Chinese with English abstract). Zhang, X.J., Zou, Y.L., Huo, Q.L., 2008. Application of Fluid Inclusions to Period Research on Oil and Gas Accumulation in Songliao Basin. China Petroleum Exploration, (4): 50-55(in Chinese with English abstract). http://www.cqvip.com/qk/90278A/200804/1000396359.html Zhong, Y.Q., Ma, W.J., 2011. Mesozoic, Cenozoic Tectonic Movements and the Control on Sandstone-Hosted Uranium Deposit in North Songliao Basin. Contributions to Geology and Mineral Resources Research, 26(4): 411-416(in Chinese with English abstract). http://www.cnki.com.cn/Article/CJFDTotal-DZZK201104010.htm 陈骁, 李忠权, 陈均亮, 等, 2010. 松辽盆地反转期的界定. 地质通报, 29(2-3): 305-311. https://www.cnki.com.cn/Article/CJFDTOTAL-ZQYD2010Z1016.htm 方立敏, 李玉喜, 殷进垠, 等, 2003. 松辽盆地断陷末期反转构造特征与形成机制. 石油地球物理勘探, 38(2): 190-193. doi: 10.3321/j.issn:1000-7210.2003.02.018 冯志强, 张顺, 付秀丽, 2012. 松辽盆地姚家组-嫩江组沉积演化与成藏响应. 地学前缘, 19(1): 78-87. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201201011.htm 付晓飞, 王朋岩, 吕延防, 等, 2007. 松辽盆地西部斜坡构造特征及对油气成藏的控制. 地质科学, 42(2): 209-222. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKX200702000.htm 付秀丽, 张顺, 梁江平, 2010. 松辽盆地北部浅层次生油气藏成藏特征. 天然气工业, 30(4): 29-34. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG201004010.htm 侯贵廷, 冯大晨, 王文明, 等, 2004. 松辽盆地的反转构造作用及其对油气成藏的影响. 石油与天然气地质, 25(1): 49-53. doi: 10.3321/j.issn:0253-9985.2004.01.009 胡望水, 1995. 松辽盆地"T2"断层系及青山口早期伸展裂陷. 石油勘探与开发, 22(2): 8-12. doi: 10.3321/j.issn:1000-0747.1995.02.012 胡望水, 吕炳全, 张文军, 等, 2005. 松辽盆地构造演化及成盆动力学探讨. 地质科学, 40(1): 16-31. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKX200501002.htm 李君, 黄志龙, 刘宝柱, 等, 2008. 伸展构造与反转构造对油气分布的控制作用——以松辽盆地东南隆起区为例. 新疆石油地质, 29(1): 19-21. https://www.cnki.com.cn/Article/CJFDTOTAL-XJSD200801008.htm 刘德来, 陈发景, 温详泉, 1996. 松辽盆地坳陷期T2断层成因机制分析. 大庆石油学院学报, 20(1): 23-23. https://www.cnki.com.cn/Article/CJFDTOTAL-DQSY601.005.htm 蒙启安, 杨永斌, 金明玉, 2006. 断裂对松辽盆地庆深大气田的控制作用. 石油学报, 27(增刊): 14-17. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB2006S1007.htm 史双双, 任建业, 张顺, 等, 2012. 松辽盆地北部裂后反转期层序地层格架及其形成机制. 地球科学——中国地质大学学报, 37(3): 545-555. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX201203018.htm 宋鹰, 任建业, 阳怀忠, 等, 2010. 松辽盆地北部姚家组底界面特征及其动力学背景. 石油学报, 31(2): 187-195. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB201002004.htm 殷进垠, 刘和甫, 迟海江, 2002. 松辽盆地徐家围子断陷构造演化. 石油学报, 23(2): 26-29. doi: 10.3321/j.issn:0253-2697.2002.02.006 于丹, 吕延防, 付晓飞, 等, 2010. 松辽盆地北部徐家围子断陷断裂构造特征及对深层天然气的控制作用. 地质论评, 56(2): 237-245. https://www.cnki.com.cn/Article/CJFDTOTAL-DZLP201002011.htm 云金表, 金之钧, 殷进垠, 等, 2008. 松辽盆地徐家围子地区深反射结构及其盆地动力学意义. 地学前缘, 15(4): 307-314. doi: 10.3321/j.issn:1005-2321.2008.04.036 张功成, 徐宏, 刘和甫, 等, 1996. 松辽盆地反转构造与油气田分布. 石油学报, 17(2): 9-14. doi: 10.3321/j.issn:0253-2697.1996.02.002 张莉, 岳乐平, 杨亚娟, 等, 2002. 反转构造盆地裂缝特征以松辽盆地大庆三肇地区为例. 石油与天然气地质, 23(4): 361-363. doi: 10.3321/j.issn:0253-9985.2002.04.012 张文军, 胡望水, 官大勇, 等, 2004. 松辽裂陷盆地反转期构造分析. 中国海上油气, 16(4): 230-234. doi: 10.3969/j.issn.1673-1506.2004.04.003 张学军, 邹育良, 霍秋立, 2008. 流体包裹体在松辽盆地成藏期次研究中的应用. 中国石油勘探, (4): 50-55. doi: 10.3969/j.issn.1672-7703.2008.04.010 钟延秋, 马文娟, 2011. 松辽盆地北部中、新生代构造运动特征及对砂岩型铀矿的控制作用. 地质找矿论丛, 26(4): 411-416. https://www.cnki.com.cn/Article/CJFDTOTAL-DZZK201104010.htm
