    塔里木盆地麦盖提斜坡玉北地区奥陶系油气输导体系与成藏期

    斯尚华 陈红汉 谭先锋 李纯泉 吴悠 李楠

    斯尚华, 陈红汉, 谭先锋, 李纯泉, 吴悠, 李楠, 2013. 塔里木盆地麦盖提斜坡玉北地区奥陶系油气输导体系与成藏期. 地球科学, 38(6): 1271-1280. doi: 10.3799/dqkx.2013.124
    引用本文: 斯尚华, 陈红汉, 谭先锋, 李纯泉, 吴悠, 李楠, 2013. 塔里木盆地麦盖提斜坡玉北地区奥陶系油气输导体系与成藏期. 地球科学, 38(6): 1271-1280. doi: 10.3799/dqkx.2013.124
    SI Shang-hua, CHEN Hong-han, TAN Xian-feng, LI Chun-quan, WU You, LI Nan, 2013. Hydrocarbon Accumulation Period and Its Carrier Systems in Ordovician Reservoir of Yubei Area, Markit Slope Tarim Basin. Earth Science, 38(6): 1271-1280. doi: 10.3799/dqkx.2013.124
    Citation: SI Shang-hua, CHEN Hong-han, TAN Xian-feng, LI Chun-quan, WU You, LI Nan, 2013. Hydrocarbon Accumulation Period and Its Carrier Systems in Ordovician Reservoir of Yubei Area, Markit Slope Tarim Basin. Earth Science, 38(6): 1271-1280. doi: 10.3799/dqkx.2013.124

    塔里木盆地麦盖提斜坡玉北地区奥陶系油气输导体系与成藏期

    doi: 10.3799/dqkx.2013.124
    基金项目:

    国家重点基础研究发展项目"973"计划 2012CB214804

    国家自然科学青年基金 41202043

    重庆市自然科学基金项目 cstc2012jja90007

    详细信息
      作者简介:

      斯尚华(1981-), 男, 博士, 讲师, 主要从事油气成藏地质学研究.E-mail: sishanghua0724@163.com

    • 中图分类号: TE122

    Hydrocarbon Accumulation Period and Its Carrier Systems in Ordovician Reservoir of Yubei Area, Markit Slope Tarim Basin

    • 摘要: 对玉北地区输导体系进行研究, 分析其油气运聚过程, 研究结果表明, 玉北地区油气基本输导介质主要分为: 断层、不整合、输导层, 其中玉北中部地区输导能力较强, 而玉北东部地区的输导能力较差.对玉北地区奥陶系3口井25块样品的有机和无机包裹体进行了分析, 分析结果表明, 玉北地区奥陶系油藏主要发生了两期成藏: 第1期发生在海西晚期262~252 Ma期间, 主要为发黄色荧光的低成熟油充注; 第2期发生喜山晚期12.5~0 Ma, 主要为发蓝白色荧光的高成熟度油充注.玉北地区奥陶系油藏有效烃源岩为下寒武统和上寒武统-下奥陶统两套烃源岩, 且发育储盖组合为: 下石炭统巴楚组泥岩、泥灰岩盖层与中-下奥陶统风化岩溶型储层组成的不连续层间组合.



    • 图  1  巴麦地区构造单元划分及工区位置

      Fig.  1.  The structural units and research areas in Bamai

      图  2  玉北地区断裂输导体系地震剖面

      Fig.  2.  The fault-carrier system in Yubei area

      图  3  玉北地区输导层类型

      a.玉北1-1井,5 985.0~5 985.5 m(O1-2y),微晶灰岩,溶蚀孔洞、裂缝发育;b.玉北1井,5 615.27~5 615.53 m(O1-2y),泥晶灰岩,立缝、平行缝及微裂缝发育,褐色原油外渗;c.玉北3井,5 165 m(O1-2y),1×10,灰岩,网状张开裂缝发育;d.玉北3井,5 258.75 m(O1-2y),1×5,灰岩,构造-溶蚀裂缝

      Fig.  3.  The carrier layer types in Yubei area

      图  4  玉北地区奥陶系代表性流体包裹体产状及荧光颜色

      a1、a2.YB1,层位O1-2y,5 604.78 m,灰岩.溶孔充填方解石晶体中检测到大量发黄色和橙色荧光油包裹体;b1、b2.YB1-1,层位O1-2y,5 983.03 m,微晶灰岩.裂缝充填方解石晶体中检测到大量发橙色荧光油包裹体;c1、c2.YB3-a,层位O1-2y,5 494.45 m,泥晶灰岩.溶孔充填方解石晶体中检测到大量不发荧光的纯气相包裹体;d1、d2.YB3-b,层位O1-2y,5 444.8 m,泥晶灰岩.溶孔充填方解石晶体中大量发蓝白色荧光油包裹体;橙色、黄色和蓝白色分别指示第1、第2和第3幕次油充注.左为透射光,右为荧光

      Fig.  4.  Occurrences of the representative fluid inclusions and the fluorescence colors of oil inclusions in the Ordovician of Yubei area

      图  5  玉北地区奥陶系不同幕次油包裹体荧光光谱

      Fig.  5.  The micro-beam fluorescence spectra of different times of oil inclusions from Ordovician in Yubei area

      图  6  玉北地区奥陶系油包裹体QF535与λmax相关关系

      Fig.  6.  Relationship between QF535 and λmax of oil inclusions from Ordovician in Yubei area

      图  7  玉北地区盐水包裹体均一温度-埋藏史投影法确定油气充注年龄

      Fig.  7.  Hydrocarbon charging ages determinated by aqueous inclusion homogenization temperature projecting on the burial historical charts in Yubei area

      图  8  玉北地区奥陶系油气成藏期次划分和成藏时期确定

      Fig.  8.  The determination of hydrocarbon charging events and ages of Ordovician in Yubei area

      图  9  玉北地区油藏成藏模式

      Fig.  9.  The migration and accumulation model in Yubei area

      表  1  玉北地区奥陶系流体包裹体平均均一温度(Th)统计

      Table  1.   The fluid inclusions homogenization temperature of Ordovician in Yubei area

      井号 深度(m) 盐水包裹体(℃) 油包裹体(℃)
      Th1 Th2 Th3 Th4 Th5 Th1 Th2 Th3 Th4
      YB1井 5 603.89 88.1 103.2 - - - 75.4 101.2 - -
      5 604.78 89.3 103 - 152.4 - 75.3 103.2 134.3 -
      5 604.83 - 104.4 120.1 - - 85.5 98.4 - -
      5 605.07 88 112.5 136 - - 82.4 - - -
      5 605.74 81.6 103.3 - - - - - - -
      5 605.98 89 107.7 128.3 - - 75 - 130.3 189.7
      5 606.34 - 104.1 - 148.1 164.8 - - - -
      5 608.00 - 108.9 120 147.9 168.9 - - - -
      5 617.03 80.3 - 121 145.3 - 78.1 - - -
      5 617.43 97.7 - - 145.7 - 89.6 - - -
      5 716.8 92 102.5 130.2 - - - - - -
      5 722.97 80.7 102.2 123.4 141.3 - - - - -
      YB1-1井 5 983.03 - 105.4 123 - - 76 110.4 137.2 -
      YB3井 5 160 84.9 105.9 128.6 - - - - - -
      5 164 83.2 - 124.9 - - - - - -
      5 165 84.7 109.3 - 148 - - - - -
      5 166 84.6 - 124.9 - - - - - -
      5 258.75 84.8 105.6 127 - - - - - -
      5 365 - - 122.3 137.5 160 80.7 104.5 - 176.9
      5 365.5 82.2 107 121.9 153.4 - - 108 129.8 -
      5 444.8 - 108 125.6 155.5 - 75.4 94.1 121.9 -
      5 446.52 - - 126.8 144.8 - 65 98.7 134.3 -
      5 451.9 - 107.2 122.6 - - 82 106.9 - -
      5 494.1 91.4 101.6 124.3 145.9 175.5 69.2 102.2 - 173.4
      5 494.45 85.3 106.4 - - - 80.3 - - -
      下载: 导出CSV
    • [1] Chen, H.H., 2007. Advances in Geochronology of Hydrocarbon Accumulation. Oil & Gas Geology, 28(2): 143-150 (in Chinese with English abstract). http://www.cqvip.com/QK/95357X/20072/24496620.html
      [2] Chen, S.J., Ma, L.Y., Fu, X.W., et al., 2001. Genetic Discrimination of Marine Sapropelic Type Gas in Tarim Basin. Oil & Gas Geology, 22(2): 100-101 (in Chinese with English abstract). http://d.wanfangdata.com.cn/Periodical_syytrqdz200102002.aspx
      [3] Fan, M., Zheng, B., 2001. Types of Stratigraphic-Lithologic Traps in the Maigaiti Slope. Petroleum Geology & Experiment, 23(1): 38-40 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SYSD200101006.htm
      [4] Goldstein, R.H., 2001. Fluid Inclusions in Sedimentary and Diagenetic Systems. Lithos, 55(1-4): 159-193. doi: 10.1016/S0024-4937(00)00044-X
      [5] Jiang, L.Z., Yu, D.L., 2003. Research on Reservoir Characteristics of Carboniferous Bioclast Limestone Member in Maigaiti Slope, Tarim Basin. Acta Scientiarum Naturalium Universitatis Pekinensis, 39(3): 428-434 (in Chinese with English abstract). http://www.cnki.com.cn/Article/CJFDTotal-BJDZ200303023.htm
      [6] Kang, Y.Z., 2001. Geological Condition for Forming Big Gas Fields in Tarim Basin. Oil & Gas Geology, 22(1): 21-25 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SYYT200101004.htm
      [7] Li, R.X., Jin, K. l., Liao, Y.S., 1998. Analysis of Organic Inclusions Using Micro-FT. IR and Fluorescence Microscopy and Its Significance. Geochimica, 27(3): 244-250 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DQHX199803004.htm
      [8] Liu, D.H., Lu, H.Z., Xiao, X.M., 2007. Oil and Gas Fluid Inclusion and Its Application in the Hydrocarbon Exploration and Exploitation. Scientific and Technologic Press in Guangdong Province, Guangzhou, 135-150 (in Chinese).
      [9] Liu, G.B., Shi, Z.J., She, X.Y., 2004. Regional Tectonic Evolution and Distribution of Bachu-Maigaiti. Journal of Chengdu University of Technology (Science & Technology Edition), 31(2): 157-161 (in Chinese with English abstract).
      [10] Lu, H.Z., Fan, H.R., et al., 2004. Fluid Inclusion. Science Press, Beijing, 1-8 (in Chinese).
      [11] Lü, X.X., Yang, H.J., Bai, Z.K., et al., 2010. Hydrocarbon Exploration Prospects in the East Section of the Maigaiti Slope in the Tarim Basin. Petroleum Geology & Experiment, 32(6): 521-526 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SYSD201006003.htm
      [12] Ma, H.Q., Wang, S.Y., Lin, J., 2006. Hydrocarbon Migration and Accumulation Characteristics in the Bachu-Maigaiti Area of the Tarim Basin. Petroleum Geology & Experiment, 28(3): 243-248 (in Chinese with English abstract). http://www.researchgate.net/publication/302931465_Hydrocarbon_migration_and_accumulation_characteristics_in_the_Bachu-Maigaiti_area_of_the_Tarim_basin
      [13] Munz, I.A., 2001. Petroleum Inclusion in Sedimentary Basins: Systematics, Analytical Methods and Application. Lithos, 55(1-4): 195-212. doi: 10.1016/S0024-4937(00)00045-1
      [14] She, X.Y., Shi, Z.J., Liu, G.B., 2003. Pathway System of Oil and Gas Migration in Bachu-Maigaiti Area. Oil & Gas Geology, 24(4): 346-350 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SYYT200304007.htm
      [15] Wang, J., Zhao, X.K., Li, K., et al., 2012. Evolution and Its oil and Gas Significance in Manan Fault of Markit Slope. Fault-Block Oil & Gas Field, 19(1): 27-31 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DKYT201201007.htm
      [16] Wu, L.M., 2010. The Study of Tectonic Evolution and Evaluation of Advantage Ordovician Reservoirs in Bachu-Markit Area (Dissertation). China University of Geosciences, Beijing (in Chinese with English abstract).
      [17] Yang, M.H., Jin, Z.J., Lv, X.X., et al., 2007. Basement-Involved Transpressional Structure and the Formation of the Bachu Uplift, Tarim Basin, Northwestern China. Acta Geologica Sinica, 81(2): 158-164 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DZXE200702003.htm
      [18] Zhang, W.H., Zha, M., Qu, J.X., 2003. The Type and Configuration of Petroleum Transportation System. Xinjiang Petroleum Geology, 24(2): 118- 120 (in Chinese with English abstract).
      [19] Zhang, X.J., Wang, Y.H., Ma, L.K., et al., 2006. Novel Progress of Upper Carboniferous Study in West Section of Mageti Slope, Tarim Basin. Xinjiang Petroleum Geology, 27(1): 56-58 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-XJSD200601015.htm
      [20] Zhang, Z.P., Liu, S.L., Yang, Z.Y., et al., 2011. Tectonic Evolution and Its Petroleum Geological Significances of the Maigaiti Slop, Tarim Basin. Oil & Gas Geology, 32(54): 909-919 (in Chinese with English abstract). http://www.cnki.com.cn/Article/CJFDTotal-SYYT201106015.htm
      [21] 陈红汉, 2007. 油气成藏年代学研究进展. 石油与天然气地质, 28(2): 143-150. doi: 10.3321/j.issn:0253-9985.2007.02.003
      [22] 陈世加, 马力宇, 付晓文, 等, 2001. 塔里木盆地海相腐泥型天然气的成因判识. 石油与天然气地质, 22(2): 100-101. doi: 10.3321/j.issn:0253-9985.2001.02.002
      [23] 范明, 郑冰, 2001. 麦盖提斜坡地层-岩性圈闭类型. 石油实验地质, 23(1): 38-40. doi: 10.3969/j.issn.1001-6112.2001.01.007
      [24] 蒋凌志, 于德龙, 2003. 塔里木盆地麦盖提斜坡石炭系生屑灰岩段储层特征研究. 北京大学学报(自然科学版), 39(3): 428-434. doi: 10.3321/j.issn:0479-8023.2003.03.020
      [25] 康玉柱, 2001. 塔里木盆地大气田形成的地质条件. 石油与天然气地质, 22(1): 21-25. doi: 10.3321/j.issn:0253-9985.2001.01.005
      [26] 李荣西, 金奎励, 廖永胜, 1998. 有机包裹体显微傅立叶红外光谱和荧光光谱测定及其意义. 地球化学, 27(3): 244-250. doi: 10.3321/j.issn:0379-1726.1998.03.005
      [27] 刘德汉, 卢焕章, 肖贤明, 2007. 油气包裹体及其在石油勘探和开发中的应用. 广州: 广东科技出版社, 135-150.
      [28] 刘高波, 施泽进, 佘晓宇, 2004. 巴楚-麦盖提的区域构造演化与油气分布规律. 成都理工大学学报(自然科学版), 31(2): 157-161. doi: 10.3969/j.issn.1671-9727.2004.02.009
      [29] 卢焕章, 范宏瑞, 倪培, 等, 2004. 流体包裹体. 北京: 科学出版社, 1-8.
      [30] 吕修祥, 杨海军, 白忠凯, 等, 2010. 塔里木盆地麦盖提斜坡东段油气勘探前景. 石油实验地质, 32(6): 521-526. doi: 10.3969/j.issn.1001-6112.2010.06.001
      [31] 马红强, 王恕一, 蔺军, 2006. 塔里木盆地巴楚-麦盖提地区油气运聚与成藏. 石油实验地质, 28(3): 243-248. doi: 10.3969/j.issn.1001-6112.2006.03.009
      [32] 佘晓宇, 施泽进, 刘高波, 2003. 巴楚-麦盖提地区油气成藏的输导系统. 石油与天然气地质, 24(4): 346-350. doi: 10.3321/j.issn:0253-9985.2003.04.008
      [33] 王晶, 赵锡奎, 李坤, 等, 2012. 麦盖提斜坡玛南断裂演化及其油气意义. 断块油气田, 19(1): 27-31. https://www.cnki.com.cn/Article/CJFDTOTAL-DKYT201201007.htm
      [34] 吴礼明, 2010. 巴-麦地区构造演化及奥陶系储层有利区带评价研究(硕士学位论文). 北京: 中国地质大学.
      [35] 杨明慧, 金之钧, 吕修祥, 等, 2007. 塔里木盆地基底卷入扭压构造与巴楚隆起的形成. 地质学报, 81(2): 158-164. doi: 10.3321/j.issn:0001-5717.2007.02.003
      [36] 张卫海, 查明, 曲江秀, 2003. 油气输导体系的类型及配置关系. 新疆石油地质, 24(2): 118-120. doi: 10.3969/j.issn.1001-3873.2003.02.008
      [37] 张现军, 王月华, 玛丽克, 等, 2006. 塔里木盆地麦盖提斜坡西段上石炭统研究新进展. 新疆石油地质, 27(1): 56-58. doi: 10.3969/j.issn.1001-3873.2006.01.015
      [38] 张仲培, 刘士林, 杨子玉, 等, 2011. 塔里木盆地麦盖提斜坡构造演化及油气地质意义. 石油与天然气地质, 32(54): 909-919. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201106015.htm
