Reworked Pyroclastics Deposits and Facies Model of Cretaceous Yingcheng Formation in Songliao Basin, NE China
-
摘要: 以松辽盆地东南缘营城组二段两类火山碎屑岩(沉凝灰岩、凝灰质砂岩)为研究对象, 进行了火山碎屑粒度特征、碎屑组成和火山碎屑岩相研究.结果显示, 火山碎屑搬运除受火山作用激发控制外, 还受牵引流、重力流以及牵引流和重力流的双重机制影响.火山碎屑微观特征、成因分析和岩相分析认为, 本区火山碎屑堆积主体为热基浪堆积和热碎屑流堆积, 部分为空落堆积.火山碎屑组成特征为晶屑含量多, 玻屑和岩屑含量少, 且岩屑仅在较粗粒级颗粒组成中存在.研究认为, 本区发育的火山碎屑为沉积环境中的再搬运火山碎屑, 共识别出4种火山碎屑岩相, 河流故道上的热基浪, 河流故道上的热碎屑流, 冲积平原上的热基浪和空落相.建立了松辽盆地东南缘露头区营城组二段河流-冲积平原沉积环境的再搬运火山碎屑岩相模式.Abstract: The pyroclastics grain size characteristics, the pyroclastics composition and the pyroclastics rocks facies of two types of pyroclastics rocks samples of Yingcheng Formation in the southeast edge of Songliao basin, tuffs and tuffaceous sandstone, had been studied. The results show that, the pyroclastics had been transported at the beginning by volcanism excitation, however, traction flow, gravity flow and the double mechanism of traction flow and gravity flow controlled the transportation process. The conclusion drawn from pyroclastic microscopic characteristics study, genetic type analysis and lithofacies analysis of those samples in study area calculates that, the majority volcanic debris accumulation was composed of hot base surge and pyroclastic flow deposition and a small portion had been composed of fallout. The characteristics of detrital composition were those, there were a large amount of crystal fragments, a small amount of shard and lithic fragments, and the lithic fragments existed only in coarse grain composition. Studies suggest that, the pyroclastics outcropped in this area were the reworked pyroclastics in the depositional environment. There were 4 types of pyroclastics facies, the hot base surge in the previous valley, the pyroclastics flow in the previous valley and the base surge and fallout on the alluvial plain had been distinguished in this area. Based on the member Ⅱ of Yingcheng Formation in the southeast edge of Songliao basin, facies models of the reworked pyroclastics in these fluvial-alluvial plain sedimentary environments were established.
-
Key words:
- Songliao basin /
- Yingcheng Formation /
- pyroclastic rock /
- reworked pyroclastics /
- facies model /
- sedimentology
-
图 1 松辽盆地东南缘六台石场村营城组二段出露位置及柱状剖面(据侯景涛等，2007)
Fig. 1. Location and columnar section of the member Ⅱ of Yingcheng Formation in Shichang village, Liutai in the southeast margin of Songliao basin
图 2 营城组二段剖面3的S旋回
a.剖面2的23-③层炭化木；b.剖面3的71层凝灰质砂岩透镜体；c.剖面2的23-④层顶部冲刷面；d.浮岩屑，Y1D1井82.95 m；e.浮岩屑，Y1D1井82.95 m；f.凝灰质砂岩中玻屑(+10)，剖面3样品PSC-3；g.凝灰质砂岩中玻屑(-10)，剖面3样品PSC-3；h.沉凝灰岩中浮岩屑(-10)，剖面3样品④-9；i.玻屑，Y1D1井82.95 m
Fig. 2. S cycle of the third profile of the upper section of the member Ⅱ Yingcheng Formation
图 3 营城组二段剖面2的G旋回(a)和剖面3的S旋回(b)
Fig. 3. G cycle of the second profile (a) and S cycle of the third profile (b) of the member Ⅱ of Yingcheng Formation
图 4 营城组二段火山碎屑偏度-标准偏差
Fig. 4. Diagram of skewness-standard deviation of the member Ⅱ of Yingcheng Formation
图 5 剖面2、剖面3样品累积频率和概率累积曲线
Fig. 5. The accumulated frequency curve and cumulative grain size characteristics of samples of the second and the third profiles
图 6 剖面2和剖面3火山碎屑成分、含量及其粒度特征
Fig. 6. Pyroclastic composition, contents and its cumulative grain size characteristics of samples in the second profile and the third profile
图 7 营城组二段火山碎屑成因类型(底图据Walker，1983)
Fig. 7. Pyroclastic genetic type of the member Ⅱ of the Yingcheng Formation
图 8 岩石样品的阴极发光特征
a.白色斜长石(+10)，剖面2的④-5；b.粉色斜长石(+10)，剖面2的④-2；c.绿色钾长石(+10)，剖面2的④-1；d.石英、长石(+10)，剖面3样品2；e.长石(+10)，剖面3样品5；f.蓝色石英(+10)，剖面2的④-1
Fig. 8. Rock sample characteristics under the cathodoluminescence microscope
-
Cheng, L.H., Chen, S.Y., Jiang, Z.X., et al., 2005. Distribution Features of Grain Size of Yinxian Stream Sediments in Dali Basin. Journal of China University of Petroleum, 29(1): 7-11(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-SYDX200501002.htm Cheng, R.H., Liu, W.Z., Wang, P.J., et al., 2007. Processes, Facies and Architecture of the Early Cretaceous Pyroclastic Deposits of the Second Member, Yingcheng Formation, the Eastern Margin of the Songliao Basin. Journal of Jilin University(Earth Science Edition), 37(6): 1166-1175(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-CCDZ200706015.htm Fisher, R.V., Schmincke, H.U., 1984. Pyroclastic Rocks. Springe-Verlag, Heideberg, New York, Berlin, 247-256. Hou, J.T., Cheng, R.H., Wang, P.J., et al., 2007. Sedimentary Characteristics and Origin Model of Conglomerate of Second Member, Yingcheng Formation in Liutai, Southeast Margin of Songliao Basin. Journal of Jilin University(Earth Science Edition), 37(6): 1176-1182(in Chinese with English abstract). Kuenzi, W.D., Horst, O.H., McGehee, R.V., 1979. Effect of Volcanic Activity on Fluvial-Deltaic Sedimentation in a Modern Arc-Trench Gap, Southwestern Guatemala. Geol. Soc. Am. Bull. , 90(9): 827-838. doi: 10.1130/0016-7606(1979)90<827:EOVAOF>2.0.CO;2 Leahy, K., 1997. Discrimination of Reworked Pyroclastics from Primary Tephra-Fall Tuffs: A Case Study Using Kimberlites of Fort a La Corne, Saskatchewan, Canada. Bulletin of Volcanol. , 59(1): 65-71. doi: 10.1007/s004450050175 Liu, X., 1996. Advance in Pyroclastic Deposits at Present and the Main Types of the Pyroclastic Deposits. World Geology, 15(1): 1-6(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SJDZ601.000.htm Qiu, X.W., Liu, C.Y., Mao, Z.G., et al., 2011, Petrological-Geochemical Characteristics of Volcanic Ash Sediments in Yanchang Formation in Ordos Basin. Earth Science—Journal of China University of Geosciences, 36(1): 139-150 (in Chinese with English abstract). http://www.researchgate.net/publication/281263347_Petrological-geochemical_characteristics_of_volcanic_ash_sediments_in_Yanchang_Formation_in_Ordos_basin Smith, G.A., 1987. The Influence of Explosive Volcanism on Fluvial Sedimentation: The Deschutes Formation (Neogene) in Central Oregon. Journal of Sedimentary Petrology, 57(4): 613-629. doi: 10.1306/212F8BBB-2B24-11D7-8648000102C1865D Smith, G.A., Campbell, N.P., Deacon, M.W., et al., 1988. Eruptive Style and Location of Volcanic Centers in the Miocene Washington Cascade Range: Reconstruction from the Sedimentary Record. Geology, 16(4): 337-340. doi: 10.1130/0091-7613(1988)016<0337:ESALOV>2.3.CO;2 Sun, S.P., Li, J.Z., Zhu, Q.W., et al., 1987. A Review of Nomenclature of Pyroclastic Rock Classification and Its Present Status both Abroad and at Home. Earth Science—Journal of China University of Geosciences, 12(6): 571-577(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DQKX198706001.htm Sun, S.P., Liu, Y.S., Zhong, R., et al., 2001. Classification of Pyroclastic Rocks and Trend of Volcanic Sedimentology: A Review. Acta Petrologica et Mineralogica, 20(3): 313-328(in Chinese with English abstract). http://d.wanfangdata.com.cn/Periodical/yskwxzz200103014 Walker, G.P.L., 1971. Grain-Size Characteristics of Pyroclastic Deposits. The Journal of Geology, 79(6): 696-714. doi: 10.1086/627699 Walker, G.P.L., 1973. Explosive Volcanic Eruptions—A New Classification Scheme. Geol. Rundsch. , 62(2): 431-446. doi: 10.1007/BF01840108 Walton, A.W., 1979. Volcanic Sediment Apron in the Tascotal Formation, Trans-Pecos Texas. Sediment Petrol. , 49(1): 303-314. doi: 10.1306/212F7725-2B24-11D7-8648000102C1865D Wang, P.J., Chi, Y.L., Liu, W.Z., et al., 2003. Volcanic Facies of the Songliao Basin: Classification, Characteristics and Reservoir Significance. Journal of Jilin University(Earth Science Edition), 33(4): 449-456(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-CCDZ200304011.htm Wang, P.J., Zheng, C.Q., Shu, P., et al., 2007. Classification of Deep Volcanic Rocks in Songliao Basin. Petroleum Geology & Oilfield Development in Daqing, 26(4): 17-22(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-DQSK200704006.htm Wohletz, K.H., Sheridan, M.F., 1979. A Model of Pyroclastic Surge. Geological Society of America Special Paper, 180: 177-194. Wright, J.V., 1980. Stratigraphy and Geology of the Welded Air Fall Tuffs of Pantelleria, Italy. Geologische Rundschau, 69(1): 263-291. doi: 10.1007/BF01869037 Xie, J.Y., Tao, K.Y., Yin, J.H., et al., 1996, Mesozoic Volcano-Intrusive Complexes of Southeast China Continent. Geological Publishing House, Beijing, 40-71(in Chinese). Xu, H.F., Chen, T., 1987. Application of Cathodoluminescence to Metamorphic and Granitic Rocks. Acta Petrologica et Mineralogica, 6(3): 279-285(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-YSKW198703008.htm Yu, Z.F., Cheng, R.H., Zhao, X.Q., et al., 2012. Types and Succession of Pyroclastic Roks Diagenesis in Lower Cretaceous of Wuerxun and Bei'er Depression in Hailaer Basin. Earth Science—Journal of China University of Geosciences, 37(4): 851-859(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DQKX201204025.htm 程立华, 陈世悦, 姜在兴, 等, 2005. 大理盆地隐仙溪河道沉积物粒度分布特征. 石油大学学报(自然科学版), 29(1): 7-11. https://www.cnki.com.cn/Article/CJFDTOTAL-SYDX200501002.htm 程日辉, 刘万洙, 王璞珺, 等, 2007. 松辽盆地东缘下白垩统营城组二段火山碎屑沉积的过程、相和结构. 吉林大学学报(地球科学版), 37(6): 1166-1175. https://www.cnki.com.cn/Article/CJFDTOTAL-CCDZ200706015.htm 侯景涛, 程日辉, 王璞珺, 等, 2007. 松辽盆地东南缘六台地区下白垩统营城组二段砾岩沉积特征及成因模型. 吉林大学学报(地球科学版), 37(6): 1176-1182. https://www.cnki.com.cn/Article/CJFDTOTAL-CCDZ200706016.htm 刘祥, 1996. 当代火山喷发碎屑堆积物的研究进展及其主要类型. 世界地质, 15(1): 1-6. https://www.cnki.com.cn/Article/CJFDTOTAL-SJDZ601.000.htm 邱欣卫, 刘池洋, 毛周光, 等, 2011. 鄂尔多斯盆地延长组火山灰沉积物岩石地球化学特征. 地球科学——中国地质大学学报, 36(1): 139-150. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX201101016.htm 孙善平, 李家振, 朱勤文, 等, 1987. 国内外火山碎屑岩的分类命名历史及现状. 地球科学——中国地质大学学报, 12(6): 571-577. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX198706001.htm 孙善平, 刘永顺, 钟蓉, 等, 2001. 火山碎屑岩分类评述及火山沉积学研究展望. 岩石矿物学杂志, 20(03): 313-328. doi: 10.3969/j.issn.1000-6524.2001.03.014 王璞珺, 迟元林, 刘万洙, 等, 2003. 松辽盆地火山岩相: 类型、特征和储层意义. 吉林大学学报(地球科学版), 33(4): 449-456. https://www.cnki.com.cn/Article/CJFDTOTAL-CCDZ200304011.htm 王璞珺, 郑长青, 舒萍, 等, 2007. 松辽盆地深层火山岩岩性分类方案. 大庆石油地质与开发, 26(4): 17-22. https://www.cnki.com.cn/Article/CJFDTOTAL-DQSK200704006.htm 谢家莹, 陶奎元, 尹家衡, 等, 1996. 中国东南大陆中生代地质及火山-侵入杂岩. 北京: 地质出版社, 40-71. 徐惠芬, 陈涛, 1987. 阴极发光仪在变质岩和花岗岩类岩石中的应用. 岩石矿物学杂志, 6(3): 279-285. https://www.cnki.com.cn/Article/CJFDTOTAL-YSKW198703008.htm 于振锋, 程日辉, 赵小青, 等, 2012. 海拉尔盆地乌尔逊-贝尔凹陷下白垩统火山碎屑岩成岩作用类型及序列. 地球科学——中国地质大学学报, 37(4): 851-859. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX201204025.htm -
