东乌旗罕乌拉韧性剪切带的构造属性及其年代约束

程银行; 滕学建; 李艳锋; 杨俊泉; 刘洋; 彭丽娜; 李影; 李敏

doi:10.3799/dqkx.2014.036

东乌旗罕乌拉韧性剪切带的构造属性及其年代约束

doi: 10.3799/dqkx.2014.036

天津地质矿产研究所，天津 300170

基金项目:

内蒙古1∶5万沙麦 1212011120697

奥尤特区调项目 1212011220446

详细信息

作者简介:
程银行(1982-)，男，助理研究员，地质学专业，主要从事矿产地质调查与研究工作.E-mail: weicheng1858@163.com

中图分类号: P542
计量
- 文章访问数: 4798
- HTML全文浏览量: 569
- PDF下载量: 1224
- 被引次数: 0
出版历程
- 收稿日期: 2013-09-15
- 刊出日期: 2014-04-15

Chronology Constraint and Tectonic Evolution of Hanwula Early Cretaceous Ductile Shear Belt in Dong Ujimqin, Inner Mongolia

Tianjin Institute of Geology and Mineral Resources, Tianjin 300170, China

摘要

摘要: 为研究东乌旗北部罕乌拉韧性剪切带的运动学性质及其时代，通过野外宏观调查和定向标本显微分析来研究花岗质糜棱岩的宏观－微观变形构造特征，并对经韧性剪切作用的花岗质糜棱岩进行LA-MC-ICPMS锆石U-Pb定年.研究表明花岗质糜棱岩的长石、石英等主要造岩矿物具塑性变形和动态生长的特征，发育典型的“σ”、“δ”和“S-C”组构，对研究区34组糜棱面理和线理数据进行赤平投影，剪切面(C面)平均面理产状为338°∠24°，线理产状为303°∠17°，显示出左行滑脱型韧性剪切带的特征；锆石U-Pb测年结果表明韧性剪切作用之前就位的花岗质岩石成岩年龄为135.9±1.2 Ma~130.0±0.5 Ma，属早白垩世，且该剪切带被下白垩统大磨拐河组(相当于凡兰吟期－欧特里沃期)砂砾岩覆盖.综上所述，结合最新区域研究成果认为，早白垩世(135.9±1.2 Ma~130.0±0.5 Ma)东乌旗地区经历了大规模左行伸展构造活动，这一成果深化了对该区早白垩世地壳构造演化的认识.
- 早白垩世 /
- 韧性剪切带 /
- 花岗质糜棱岩 /
- 构造 /
- 锆石U-Pb年龄 /
- 地质年代学
Abstract: Through field investigation, microscopic analyses of oriented samples and zircon LA-MC-ICPMS U-Pb dating, granitic mylonites of the ducticle shear belt in Hanwula area have been studied, for their kinematic characteristics and ages. In these rocks, main rock-forming minerals (feldspar and quartz) all show the typical characteristics of plastic deformation and dynamic crystallization, with typical fabrics such as "σ", "δ" and "S-C" structures. Averages of 34 coupled attitudes of mineral lineation and shearing foliation are 338°∠24° and 303°∠17°. All the above indicate the left-lateral slip in this belt. The zircon U-Pb dating data suggest that these granitic mylonites are formed in Early Cretaceous with detail ages of 135.9±1.2 Ma to 130.0±0.5 Ma and the ductile shear belt is covered by glutenite of the Lower Cretaceous Damoguaihe Group (Valanginian-Hauterivian). Thus, we consider that Dong Ujimqin area had experienced regional left-lateral extensional structure movement in Early Cretaceous. This study filled the blank of petrology and geochronology study of the ductile shear belt in Hanwula and enhanced the understanding of the Early Cretaceous crust tectonic evolution in Dong Ujimqin.
- Early Cretaceous /
- ductile shear belt /
- granitic mylolite /
- tectonics /
- zircon U-Pb dating /
- geochronology

HTML全文

图 1 罕乌拉韧性剪切带地质简图(据滕学建等内蒙古东乌旗罕乌拉早白垩世韧性剪切带1∶1万地质图，2012改编)

1.早白垩世二长花岗岩；2.早白垩世糜棱岩化二长花岗岩；3.早白垩世花岗质初糜棱岩；4.早白垩世花岗质糜棱岩；5.下白垩统大磨拐河组(K₁d)砂砾岩；6.构造剖面；7.野外采样；8.糜棱线理面理产状；9.第四系；c.研究区糜棱面理、矿物拉伸线理的极射赤平投影(吴氏网，下半球)

Fig. 1. Geological sketch map of ductile shear zone in Hanwula area

下载: 全尺寸图片幻灯片

图 2 罕乌拉韧性剪切带剖面简图(图例同图 1)

Fig. 2. The sectional drawing of ductile shear zone in Hanwula area

下载: 全尺寸图片幻灯片

图 3 罕乌拉韧性剪切带宏观构造特征

a、b.强应变带弱变形域；c.强应变带中不对称褶皱和石香肠构造；d.“A”型褶皱指示左行剪切方向；e、f.“δ”、“σ”旋转残斑运动指向；g.弱变形域中沿糜棱面理发育长英质石香肠构造；h.弱变形域中“S-C”、“S-L”、“L”组构运动指向(镜头方向均为50°~70°)

Fig. 3. Macroscopic structures of ductile shear zone in Hanwula area

下载: 全尺寸图片幻灯片

图 4 罕乌拉韧性剪切带微观构造特征

a.钾长石卡式双晶，绢云母、黑云母绕晶定向分布；b.显微拉张和剪切破裂，斜长石残斑中张性破裂被新生石英充填；c.山羊须结构，钾长石两端被拉断，空隙被新生石英充填；d.眼球状斜长石残斑及其边部石英亚颗粒，石英、黑云母定向绕晶排列；e.钾长石残斑内的蠕虫状石英，蠕英交代结构；f.显微尺度反“S”型“S-C”组构运动指向，石英呈似透镜状定向分布

Fig. 4. Microstructures of ductile shear zone in Hanwula area

下载: 全尺寸图片幻灯片

图 5 罕乌拉地区花岗质糜棱岩部分锆石阴极发光图像

Fig. 5. CL images of selected zircons for granitic mylonites in Hanwula areas

下载: 全尺寸图片幻灯片

图 6 罕乌拉地区花岗质糜棱岩锆石U-Pb年龄谐和图

Fig. 6. Zircon U-Pb concordia diagrams of the granitic mylonites in Hanwula areas

下载: 全尺寸图片幻灯片

图 7 罕乌拉韧性剪切带韧性变形时间上限的地质证据

a.大磨拐河组(K₁d)砂砾岩中花岗质糜棱岩砾岩；myl.花岗质糜棱岩；b.石英脉截切韧性剪切带糜棱面理；Kf.钾长石；Q.条带状石英、石英脉；C.糜棱面理；L.石英拉伸线理；c.最大压扁面，钾长石旋转碎斑，石英拉伸线理(L)和眼球状石英

Fig. 7. Geologic evidences on the ductile shear timing in Hanwula area

下载: 全尺寸图片幻灯片

表 1 罕乌拉地区花岗质糜棱岩LA-MC-ICPMS锆石U-Pb同位素分析结果

Table 1. LA-MC-ICPMS zircon U-Pb dating results of granitic mylonites in Hanwula area

测点号	元素含量及比值			同位素比值						年龄(Ma)
测点号	U(10^-6)	Th(10^-6)	²³²Th/²³⁸U	²⁰⁶Pb/²³⁸U	±1σ	²⁰⁷Pb/²³⁵U	±1σ	²⁰⁷Pb/²⁰⁶Pb	±1σ	²⁰⁶Pb/²³⁸U	±1σ	²⁰⁷Pb/²³⁵U	±1σ
1503.1.1	771	1 176	1.525 1	0.020 4	0.000 2	0.136 1	0.004 3	0.048 4	0.001 5	130	1	130	4
1503.1.2	1 730	3 686	2.130 2	0.020 4	0.000 2	0.136 9	0.002 1	0.048 6	0.000 7	130	1	130	2
1503.1.3	902	1 135	1.258 5	0.020 6	0.000 2	0.136 7	0.002 9	0.048 2	0.001 0	131	1	130	3
1503.1.4	358	433	1.209 2	0.020 4	0.000 4	0.137 2	0.012 5	0.048 8	0.004 4	130	2	131	12
1503.1.5	636	983	1.546 6	0.020 4	0.000 2	0.137 3	0.005 0	0.048 9	0.001 8	130	1	131	5
1503.1.6	1 166	1 921	1.646 6	0.020 5	0.000 2	0.136 7	0.003 1	0.048 5	0.001 1	131	1	130	3
1503.1.7	1 814	1 169	0.644 5	0.026 3	0.000 3	0.179 6	0.002 0	0.049 6	0.000 5	167	2	168	2
1503.1.8	723	1 006	1.392 4	0.020 4	0.000 2	0.136 5	0.004 1	0.048 6	0.001 4	130	1	130	4
1503.1.9	391	620	1.587 0	0.020 7	0.000 3	0.137 6	0.012 8	0.048 2	0.004 5	132	2	131	12
1503.1.10	751	1 496	1.993 3	0.020 4	0.000 2	0.137 2	0.003 1	0.048 8	0.001 1	130	1	131	3
1503.1.11	744	1 330	1.787 2	0.020 4	0.000 2	0.136 7	0.003 9	0.048 5	0.001 4	130	1	130	4
1503.1.12	730	1 208	1.654 7	0.020 5	0.000 2	0.136 3	0.005 5	0.048 3	0.001 9	131	1	130	5
1503.1.13	829	1 507	1.818 2	0.020 5	0.000 1	0.136 8	0.003 1	0.048 5	0.001 1	131	1	130	3
1503.1.14	733	1 229	1.676 2	0.020 4	0.000 2	0.136 5	0.003 5	0.048 5	0.001 3	130	1	130	3
1503.1.15	504	653	1.295 3	0.020 2	0.000 3	0.136 3	0.011 6	0.048 9	0.004 4	129	2	130	11
1503.1.16	704	868	1.233 0	0.020 5	0.000 2	0.138 0	0.003 7	0.048 8	0.001 3	131	1	131	4
1503.1.17	673	933	1.387 3	0.020 3	0.000 2	0.137 1	0.003 7	0.049 1	0.001 3	129	1	130	4
1503.1.18	1 029	1 739	1.690 6	0.019 7	0.000 2	0.137 5	0.005 3	0.050 5	0.001 9	126	1	131	5
1503.1.19	625	39	0.062 8	0.020 4	0.000 2	0.136 6	0.006 4	0.048 6	0.002 3	130	2	130	6
1503.1.20	516	601	1.163 0	0.020 1	0.000 2	0.136 6	0.005 0	0.049 3	0.001 8	128	1	130	5
1503.1.21	486	574	1.181 6	0.020 5	0.000 3	0.136 5	0.007 5	0.048 4	0.002 6	131	2	130	7
1503.1.22	801	1 650	2.059 1	0.020 3	0.000 2	0.137 1	0.004 3	0.048 9	0.001 5	130	1	130	4
1503.1.23	1 182	2 215	1.874 7	0.020 5	0.000 2	0.136 2	0.002 7	0.048 2	0.000 9	131	1	130	3
1503.1.24	1 150	1 826	1.588 4	0.020 2	0.000 2	0.136 4	0.002 6	0.047 3	0.000 8	129	2	130	2
P19.1.1	1 688	1 295	0.767 1	0.021 4	0.000 2	0.148 2	0.002 4	0.050 3	0.000 8	136	1	140	2
P19.1.3	237	331	1.395 2	0.025 7	0.000 3	0.198 4	0.011 0	0.056 1	0.003 1	163	2	184	10
P19.1.4	1 512	929	0.614 4	0.021 1	0.000 4	0.149 2	0.002 3	0.051 3	0.000 9	135	3	141	2
P19.1.5	757	962	1.270 5	0.025 8	0.000 3	0.178 2	0.003 6	0.050 1	0.001 0	164	2	166	3
P19.1.6	2 016	2 081	1.032 4	0.021 8	0.000 3	0.148 5	0.002 0	0.049 5	0.000 8	139	2	141	2
P19.1.7	1 169	1 461	1.249 9	0.021 7	0.000 3	0.148 1	0.005 1	0.049 6	0.001 7	138	2	140	5
P19.1.8	302	149	0.494 7	0.025 6	0.000 5	0.177 5	0.009 3	0.050 3	0.002 6	163	3	166	9
P19.1.9	773	312	0.403 8	0.021 7	0.000 3	0.147 7	0.003 5	0.049 4	0.001 2	138	2	140	3
P19.1.10	1 487	1 201	0.807 7	0.021 7	0.000 2	0.148 3	0.002 3	0.049 7	0.000 7	138	1	140	2
P19.1.11	1 069	1 033	0.966 5	0.021 5	0.000 3	0.151 7	0.007 4	0.051 1	0.002 5	137	2	143	7
P19.1.12	620	594	0.957 8	0.021 8	0.000 3	0.147 8	0.005 4	0.049 2	0.001 8	139	2	140	5
P19.1.13	1 134	96	0.084 2	0.021 6	0.000 2	0.147 6	0.002 7	0.049 7	0.000 9	137	2	140	3
P19.1.14	1 147	268	0.233 5	0.021 7	0.000 2	0.148 2	0.003 3	0.049 6	0.001 1	138	1	140	3
P19.1.16	941	515	0.547 3	0.020 7	0.000 3	0.148 3	0.003 4	0.052 0	0.001 2	132	2	140	3
P19.1.17	721	1 111	1.539 6	0.021 1	0.000 2	0.147 6	0.003 7	0.050 7	0.001 3	135	2	140	4
P19.1.18	1 126	1 160	1.030 3	0.021 6	0.000 3	0.147 9	0.002 6	0.049 8	0.000 9	137	2	140	2
P19.1.19	1 988	125	0.062 8	0.021 6	0.000 2	0.146 1	0.002 0	0.049 0	0.000 6	138	2	139	2
P19.1.20	1 153	1 439	1.247 7	0.020 6	0.000 2	0.162 2	0.004 6	0.057 1	0.001 6	131	1	153	4
P19.1.21	1 996	592	0.296 5	0.025 7	0.000 3	0.178 0	0.002 4	0.050 2	0.000 7	164	2	166	2
P19.1.22	950	172	0.181 2	0.021 2	0.000 3	0.147 1	0.013 4	0.050 4	0.004 5	135	2	139	13
P19.1.23	314	157	0.498 5	0.021 7	0.000 3	0.147 4	0.012 4	0.049 4	0.004 1	138	2	140	12
P19.1.24	3 243	2 414	0.744 3	0.020 6	0.000 2	0.160 7	0.001 5	0.056 5	0.000 5	132	1	151	1
P19.1.25	1 393	875	0.628 0	0.021 6	0.000 2	0.148 8	0.002 5	0.049 9	0.000 8	138	1	141	2
P19.1.26	1 748	1 457	0.833 4	0.021 5	0.000 3	0.148 7	0.002 3	0.050 1	0.000 8	137	2	141	2
P19.1.27	794	1 016	1.280 1	0.025 6	0.000 3	0.177 4	0.005 4	0.050 3	0.001 5	163	2	166	5
P19.1.28	1 476	433	0.293 5	0.021 6	0.000 3	0.174 0	0.002 7	0.058 5	0.000 9	138	2	163	2
P19.1.29	728	892	1.225 5	0.021 1	0.000 4	0.174 1	0.003 2	0.059 7	0.001 0	135	2	163	3
P19.1.30	1 939	305	0.157 4	0.020 8	0.000 2	0.157 3	0.002 0	0.054 8	0.000 7	133	1	148	2
P19.1.31	533	137	0.257 8	0.025 6	0.000 3	0.199 2	0.005 6	0.056 5	0.001 5	163	2	184	5
P19.1.32	1 339	524	0.391 3	0.025 5	0.000 3	0.176 8	0.002 0	0.050 2	0.000 7	163	2	165	2
注：测试单位为天津地质矿产研究所.

下载: 导出CSV

参考文献(55)

Bose, S., Marques, F.O., 2004. Controls on the Geometry of Tails around Rigid Circular Inclusions: Insights from Analogue Modeling in Simple Shear. Journal of Structural Geology, 26(12): 2145-2156. doi: 10.1016/j.jsg.2004.05.004
Chen, H., Hu, J.M., Wu, G.L., 2009. Current Situation of Research on the Simulating Experiments for the Shear Direction of Asymmetry Rotated Porphyroclast in the Ductile Shear Zone of Mylonites. Geological Bulletin of China, 28(4): 439-455(in Chinese with English abstract). http://www.cqvip.com/QK/95894A/20094/30104597.html
Chen, Z.G., Zhang, L.C., Zhou, X.H., et al., 2006. Geochronology and Geochemical Characteristics of Volcanic Rocks Section in Manzhouli Xinyouqi, Inner-Mongolia. Acta Petrologica Sinica, 22(12): 2971-2986(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-YSXB200612013.htm
Ge, W.C., Lin, Q., Sun, D.Y., et al., 2000. Geochemical Research into Origins of Two Types of Mesozoic Rhyolites in Daxing'anling. Earth Science—Journal of China University of Geosciences, 25(2): 172-178(in Chinese with English abstract). http://www.researchgate.net/publication/313219007_Geochemical_research_into_origins_of_two_types_of_Mesozoic_rhyolites_in_Daxing'anling
Gou, J., Sun, D.Y., Zhao, Z.H., et al., 2010. Zircon LA-ICPMS U-Pb Dating and Petrogenesis of Rhyolite in Baiyingaolao Formation from the Southern Manzhouli, Inner-Mongolia. Acta Petrologica Sinica, 26(1): 333-344(in Chinese with English abstract). http://www.oalib.com/paper/1472934
Guo, F., Fan, W.M., Wang, Y.J., et al., 2001. Petrogenesis of the Late Mesozoic Bimodal Volcanic Rocks in the Southern Da Hinggan Mts, China. Acta Petrologica Sinica, 17(1): 161-168(in Chinese with English abstract). http://www.cqvip.com/Main/Detail.aspx?id=4917727
Hoskin, P.W.O., Schaltegger, U., 2003. The Composition of Zircon and Igneous and Metamorphic Petrogenesis. Mineral Geochem. , 53(1): 27-62. doi: 10.2113/0530027
Hu, P., Nie, F.J., He, Y., et al., 2006. A Peraluminous Granite with Positive ε_Nd(t) Values: The Shamai Pluton in Inner Mongolia, Northeast China. Acta Petrologica Sinica, 22(11): 2781-2790(in Chinese with English abstract). http://ci.nii.ac.jp/naid/10030174700
Li, G.R., Chi, X.G., Dong, C.Y., et al., 2006. Rb-Sr Isotopic Dating of Mylonitize Granite in Southeast Mid-Da Hinggan Mountains. Journal of Jilin University (Earth Science Edition), 36(Suppl. ): 11-14(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-CCDZ2006S1002.htm
Li, H.K., Su, W.B., Zhou, H.Y., et al., 2011. The Base Age of the Changchengian System at the Northern North China Craton should be Younger than 1 670 Ma: Constraints from Zircon U-Pb LA-MC-ICPMS Dating of a Granite-Porphyry Dike in Miyun County, Beijing. Earth Science Frontiers, 18(3): 108-120(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DXQY201103013.htm
Li, H.K., Zhu, S.X., Xiang, Z.Q., et al., 2010. Zircon U-Pb Dating on Tuff Bed from Gaoyuzhuang Formation in Yanqing, Beijing: Further Constraints on the New Subdivision of the Mesoproterozoic Stratigraphy in the Northern North China Craton. Acta Petrologica Sinica, 26(7): 2131-2140 (in Chinese with English abstract). http://www.researchgate.net/publication/279645000_Zircon_U-Pb_dating_on_tuff_bed_from_Gaoyuzhuang_Formation_in_Yanqing_Beijing_Further_constraints_on_the_new_subdivision_of_the_Mesoproterozoic_stratigraphy_in_the_northern_North_China_Craton
Li, J.Y., 1998. Some New Ideas on Tectonics of NE China and Its Neighboring Areas. Geological Review, 44(4): 339-347 (in Chinese with English abstract). http://www.cqvip.com/QK/91067X/199804/3089913.html
Li, J.Y., He, Z.J., Mo, S.G., et al., 2004a. The Age of Conglomerates in the Lower Part of the Xiufeng Formation in the Northern Da Hinggan Mountains, NE China, and Their Tectonic Implications. Geological Bulletin of China, 23(2): 120-129(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-ZQYD200402003.htm
Li, J.Y., Mo, S.G., He, Z.J., et al., 2004b. The Timing of Crustal Sinistral Strike-Slip Movement in the Northern Great Khing'an Ranges and Its Constraint on Reconstruction of the Crustal Tectonic Evolution of NE China and Adjacent Areas since the Mesozoic. Earth Science Frontiers, 11(3): 157-168 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DXQY200403022.htm
Li, L., Zhang, W.J., Gao, D.Z., et al., 2000. Early Ductile Shear Zone and Tectonic Evolution in the Middle of Linhe-Jining Deep Fault, Inner Mongolia. Earth Science—Journal of China University of Geosciences, 25(3): 227-231(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DQKX200003001.htm
Li, S.T., Yang, S.G., Wu, C.L., et al., 1987. The Late Mesozoic Rifting in the Northeastern China and the Fault-Rifting Basins in East Asia. Science in China (Series B), 21(2): 185-195(in Chinese).
Mancktelow, N.S., 2004. How Ductile are Ductile Shear Zones? Geology, 34(5): 345-348. doi: 10.1130/G22260.1
Marques, F.O., Bose, S., 2004. Influence of a Permanent Low-Friction Boundary on Rotation and Flow in Rigid Inclusion/Viscous Matrix Systems from an Analogue Perspective. Tectonophysics, 382(3/4): 229-245. doi: 10.1016/j.tecto.2004.01.004
Meng, F.C., Liu, J.Q., Li, M., et al., 2010. Geochemistry and Tectonic Implications of Rhyolites from Yingcheng Formation in Xujiaweizi, Songliao Basin. Acta Petrologica Sinica, 26(1): 227-241(in Chinese with English abstract). http://qikan.cqvip.com/Qikan/Article/Detail?id=1003850509
Meng, Q.A., Wan, C.B., Qiao, X.Y., et al., 2003. Palynological Assemblages from the Damoguaihe Formation in the Hailer Basin, Inner Mongolia. Journal of Stratigraphy, 27(3): 173-184(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DCXZ200303001.htm
Meng, Q.R., 2003. What Drove Late Mesozoic Extension of the Northern China-Mongolia Tract? Tectonophysics, 369 (324): 155-174. doi: 10.1016/S0040-1951(03)00195-1
Miao, L.C., Fan, W.M., Zhang, F.Q., et al., 2003. Zircon SHRIMP Geochronology of Xinkailing-Kele Complex in the Northwestern Lesser Xing'an Range, and Its Geological Implications. Chinese Science Bulletin, 48(22): 2315-2323(in Chinese). doi: 10.1360/csb2003-48-22-2315
Miao, P.S., Zhang, Z.F., 1995. Ductile Shear Zones Formed by Different Mechanisms. Regional Geology of China, 4: 353-359(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-ZQYD504.011.htm
Paterson, S.R., Fowler, T.K. Jr., Schmidt, K.L., et al., 1998. Interpreting Magmatic Fabric Patterns in Plutons. Lithos, 44(1-2): 53-82. doi: 10.1016/S0024-4937(98)00022-X
Paterson, S.R., Vernon, R.H., Tobisch, O.T., 1989. A Review of the Criteria for the Identification of Magmatic and Tectonic Foliations in Ganitoids. J. Struct. Geol. , 11(3): 349-363. doi: 10.1016/0191-8141(89)90074-6
Rubatto, D., Gebauer, D., 2000. Use of Cathodoluminescence for U-Pb Zircon Dating by IOM Microprobe: Some Examples from the Western Alps. In: Pagel, M., Barbin, V., Blanc, P., et al., eds., Cathodoluminescence in Geoscience. Springer-Verlag, Berlin Heidelberg, German, 373-400.
Shao, J.A., Zhang, L.Q., Mu, B.L., 1999. Magmatism in the Mesozoic Extending Orogenic Process of Da Hinggan Mts. . Earth Science Frontiers, 6(4): 339-346(in Chinese with English abstract). http://www.researchgate.net/publication/313051174_Magmatism_in_the_Mesozoic_Extending_Orogenic_Process_of_Da_Hinggan_MTS
Sun, Z.X., Li, G.X., Yao, Y.F., et al., 2003. Characteristics of the Meso-Cenozoic Extensional Structures in Samai Region, East Ujimqin Qi, Inner Mongolia. Acta Geologica Sichuan, 23(4): 198-201(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SCDB200304001.htm
Wang, T., Zheng, Y.D., Liu, S.W., et al., 2002. Mylonitic Potassic Granitoids from the Yagan Metamorphic Core Complex on Sion-Mongolian Border: A Mark of Transition from Contractile to Extensional Tectonic Regime. Acta Petrologica Sinica, 18(2): 177-186(in Chinese with English abstract). http://www.oalib.com/paper/1471885
Wu, F.Y., Lin, Q., Ge, W.C., et al., 1998. The Petrogenesis and Age of Xinhuatun Pluton in Zhangguangcailing. Acta Petrologica et Mineralogica, 17(3): 226-234(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-YSKW803.003.htm
Zhang, L.Q., Shao, J.A., Zheng, G.R., 1998. Metamorphic Core Complex in Ganzhuermiao, Inner Mongolia. Scientia Geologica Sinica, 33(2): 140-146(in Chinese with English abstract). http://d.wanfangdata.com.cn/periodical/QK199800069873
Zhao, X., Coe, R.S., 1996. Paleomagnetic Constraints on the Paleogeography of China: Implications for Gondwana Land. Abstract of 30th IGC, 1: 200-231. doi: 10.1080/08120099608728285
陈虹, 胡健民, 武国利, 2009. 韧性剪切带糜棱岩中不对称旋转碎斑系剪切指向模拟实验研究现状及其问题. 地质通报, 28(4): 439-455. doi: 10.3969/j.issn.1671-2552.2009.04.005
陈志广, 张连昌, 周新华, 等, 2006. 满洲里新右旗火山岩剖面年代学和地球化学特征. 岩石学报, 22(12): 2971-1986. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB200612013.htm
葛文春, 林强, 孙德有, 等, 2000. 大兴安岭中生代两类流纹岩成因的地球化学研究. 地球科学——中国地质大学学报, 25(2): 172-178. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX200002012.htm
苟军, 孙德有, 赵忠华, 等, 2010. 满洲里南部白音高老组流纹岩锆石U-Pb定年及岩石成因. 岩石学报, 26(1): 333-344. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201001038.htm
郭锋, 范蔚茗, 王岳军, 等, 2001. 大兴安岭南段晚中生代双峰式火山作用. 岩石学报, 17(1): 161-168. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB200101016.htm
胡朋, 聂风军, 赫英, 等, 2006. 内蒙古沙麦岩体: 正ε_Nd(t)值的过铝质花岗岩. 岩石学报, 22(11): 2781-2790. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB200611015.htm
黎广荣, 迟效国, 董春艳, 等, 2006. 大兴安岭中段东南部糜棱岩化花岗岩的Rb-Sr年龄. 吉林大学学报, 36(增刊): 11-14. https://www.cnki.com.cn/Article/CJFDTOTAL-CCDZ2006S1002.htm
李怀坤, 苏文博, 周红英, 等, 2011. 华北克拉通北部长城系底界年龄小于1 670 Ma: 来自北京密云花岗斑岩岩脉锆石LA-MC-ICPMS U-Pb年龄的约束. 地学前缘, 18(3): 108-120. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201103013.htm
李怀坤, 朱士兴, 相振群, 等, 2010. 北京延庆高于庄组凝灰岩的锆石U-Pb定年研究及其对华北北部中元古界划分新方案的进一步约束. 岩石学报, 26(7): 2131-2140. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201007016.htm
李锦轶, 1998. 中国东北及邻区若干地质构造问题的新认识. 地质论评, 44 (4): 339-347. doi: 10.3321/j.issn:0371-5736.1998.04.002
李锦轶, 和政军, 莫申国, 等, 2004a. 大兴安岭北部绣峰山组下部砾岩的形成时代及其大地构造意义. 地质通报, 23(2): 120-129. https://www.cnki.com.cn/Article/CJFDTOTAL-ZQYD200402003.htm
李锦轶, 莫申国, 和政军, 等, 2004b. 大兴安岭北段地壳左行走滑运动的时代及其对中国东北及邻区中生代以来地壳构造演化重建的制约. 地学前缘, 11(3): 157-168. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY200403022.htm
李龙, 张维杰, 高德臻, 等, 2000. 内蒙古临河-集宁深断裂中段早期韧性剪切带及其构造演化. 地球科学——中国地质大学学报, 25(3): 227-231. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX200003001.htm
李思田, 杨世恭, 吴冲龙, 等, 1987. 中国东北部晚中生代裂陷作用和东北亚断陷盆地系. 中国科学(B辑), 21(2): 185-195. https://www.cnki.com.cn/Article/CJFDTOTAL-JBXK198702009.htm
孟凡超, 刘嘉麒, 李明, 等, 2010. 松辽盆地徐家围子营城组流纹岩地球化学特征及构造指示意义. 岩石学报, 26(1): 227-241. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201001027.htm
蒙启安, 万传彪, 乔秀云, 等, 2003. 内蒙古海拉尔盆地大磨拐河组孢粉组合. 地层学杂志, 27(3): 173-184. doi: 10.3969/j.issn.0253-4959.2003.03.002
苗来成, 范蔚茗, 张福勤, 等, 2003. 小兴安岭西北部新开岭-科洛杂岩锆石SHRIMP年代学研究及其意义. 科学通报, 48(22): 2315-2323. doi: 10.3321/j.issn:0023-074X.2003.22.004
苗培森, 张振福, 1995. 不同构造机制韧性剪切带研究. 中国区域地质, 4: 353-359. https://www.cnki.com.cn/Article/CJFDTOTAL-ZQYD504.011.htm
邵济安, 张履桥, 牟保磊, 1999. 大兴安岭中生代伸展造山过程中的岩浆作用. 地学前缘, 6(4): 339-346. doi: 10.3321/j.issn:1005-2321.1999.04.017
孙泽轩, 李国新, 姚毅锋, 等, 2003. 内蒙古东乌珠穆沁旗沙麦地区中-新生代伸展构造特征研究. 四川地质学报, 23(4): 198-201. https://www.cnki.com.cn/Article/CJFDTOTAL-SCDB200304001.htm
王涛, 郑亚东, 刘树文, 等, 2002. 中蒙边界亚干变质核杂岩糜棱状钾质花岗岩早中生代收缩与伸展构造体制的转换标志. 岩石学报, 18(2): 177-186. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB200202004.htm
吴福元, 林强, 葛文春, 等, 1998. 张广才岭新华屯岩体的形成时代与成因研究. 岩石矿物学杂志, 17(3): 226-234. https://www.cnki.com.cn/Article/CJFDTOTAL-YSKW803.003.htm
张履桥, 邵济安, 郑广瑞, 1998. 内蒙古甘珠尔庙变质核杂岩. 地质科学, 33(2): 140-146. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKX802.001.htm
