Theoretical Simulation of Co-Seismic and Post-Seismic Deformations and Gravity Changes of Lushan Earthquake
-
摘要: 为了研究芦山地震的孕震过程和震源区的长期构造过程以及解释实测的震后形变和重力资料, 采用分层介质模型, 利用数值模拟的方法, 考虑区域流变系数, 计算了地震引起的地表同震、震后的形变和重力变化以及区域内部分GPS与重力连续观测台站的震后形变和重力变化的时间序列.结果表明: 芦山地震的地表同震形变显示出发震断层明显的逆冲特性; 粘弹性松弛效应引起的震后地表形变和重力变化比同震形变和重力变化的范围明显扩大, 但随着粘滞系数的增加, 变化量明显减小; 观测台站的震后变化时变曲线显示震后形变和重力变化在震后50 a间变化显著, 100 a后基本平缓, 趋于稳定; 模拟计算的GPS台站中除了MEIG台和MYAN台以外, 其余台站的震后观测必须考虑粘弹性松弛的影响.Abstract: This paper aims at studying the seismogenic process and long-term tectonic process of the source area and explain the post-seismic deformation and gravity data in Lushan earthquake. Based on the layered half-space model, we calculate the co- and post-seismic surface deformations and gravity changes and their time series gained by the GPS and gravity stations, considering regional rheological coefficients, and using the numerical simulation method. It is found that the surface co-seismic deformation shows seismogenic fault is of obvious thrusting characteristics The range of influence of viscoelastic relaxation is significantly enlarged than that of the co-seismic, but changes gradually reduce with the increase of viscousity coefficients. The time-variable curves of the stations show that post-seismic deformation and gravity changes are significant in 50 years after the earthquake, become gentle after 100 years and tend to be stable. The post-seismic observations of the GPS stations are convinced to consider the effect of viscoelastic relaxation except for the MEIG and the MYAN.
-
Key words:
- Lushan earthquake /
- ground deformation /
- gravity change /
- viscoelastic relaxation /
- geophysics
-
图 1 芦山地震滑动模型
模型1为刘成利等(2013)给出的模型；模型2为王卫民等(2013)给出的模型
Fig. 1. The slip distribution models of Lushan earthquake
图 2 地表同震形变和重力变化
上图为模型1模拟的结果，下图为模型2模拟的结果；紫色和棕色矩形分别为模型1和模型2断层面在地表的投影.a.地表同震水平形变；b.地表垂直形变；c.同震重力变化
Fig. 2. Surface coseismic deformation and gravity changes
图 3 不同粘滞系数模型引起的10 a后地表水平形变
图a, b, c, d分别对应模型A, 模型B, 模型C, 模型D模拟的结果
Fig. 3. Surface horizontal deformation caused by the models with different viscosity coefficients 10 years after the earthquake
图 4 不同粘滞系数模型引起的10 a后地表垂直形变
图a, b, c, d分别对应模型A、模型B、模型C、模型D模拟的结果
Fig. 4. Surface vertical deformation caused by the models with different viscosity coefficients 10 years after the earthquake
图 5 粘弹性松弛效应引起的震后200 a形变和重力变化
a.总的水平形变；b.总的垂直形变；c.总的重力变化
Fig. 5. The surface deformation and gravity change caused by viscoelastic relaxation 200 years after the earthquake
图 6 10个GPS和6个重力连续观测台站的震后形变和重力变化时间序列
Fig. 6. Time series of the post-seismic deformation and gravity changes of 10 GPS and 6 gravity continuous observation stations
表 1 芦山地震区域分层介质模型参数
Table 1. Parameters of the layered earth model of Lushan earthquake
层位 深度(km) Vp(km/s) Vs(km/s) 密度(kg/m3) 平均泊松比 软沉积层 1 2.5 1.2 2 100 硬沉积层 1 4.0 2.1 2 400 上地壳 20 6.1 3.5 2 750 0.26 中地壳 20 6.3 3.6 2 800 下地壳 4 7.2 4.0 3 100 地壳以下 ∞ 8.0 4.6 3 350 0.25
下载: 导出CSV
表 2 GPS连续观测台站同震形变模拟结果与实测结果的比较
Table 2. Comparison of the simulated coseismic deformation with the measured results at GPS stations
GPS台站 经向形变(mm) 纬向形变(mm) 垂向形变(mm) 观测结果 模拟结果 观测结果 模拟结果 观测结果 模拟结果 LESH -2.7(±1.2) -2.064 0 0.8(±1.0) 1.842 00 0.3(±4.9) 0.028 96 LUZH -0.5(±0.6) -0.299 4 -0.7(±0.5) 0.183 50 3.9(±2.7) 0.055 11 MEIG -1.4(±1.2) -0.118 2 -0.3(±1.1) 0.195 30 -0.4(±5.4) -0.056 94 MYAN -0.5(±1.1) -0.124 8 0.1(±1.0) 0.010 71 -1.4(±4.7) -0.091 12 QLAI -11.6(±1.0) -3.941 0 0.8(±0.9) 2.540 00 -4.9(±4.1) -0.790 10 ROXI -0.1(±1.2) -0.985 9 -0.5(±1.1) 0.607 50 -4.3(±5.8) 0.101 90 YAAN -7.0(±1.1) -3.283 0 6.4(±1.0) 0.873 30 -3.5(±4.5) -1.207 00 注: 括号中数字表示观测误差；模拟结果均为采用模型1计算得到.
下载: 导出CSV
表 3 成都台和姑咱台同震重力变化模拟结果与实测结果的比较
Table 3. Comparison of the simulated coseismic gravity changes with the measured results at Chengdu station and Guza station
重力台站 模拟的同震重力变化(10-8 m·s-2) 实测同震重力变化(10-8 m·s-2) 成都台 0.10(±15) 0 姑咱台 0.03(±15) -10 注: 括号中数字表示观测误差；模拟结果均为采用模型1计算得到.
下载: 导出CSV
-
Bürgmann, R., Dresen, G., 2008. Rheology of the Lower Crust and Upper Mantle: Evidence from Rock Mechanics, Geodesy, and Field Observations. Ann. Rev. Earth Planet. Sci., 36: 531-567. doi: 10.1146/annurev.earth.36.031207.124326 Diao, F.Q., 2011. The Study of Coseismic and Postseismic Deformation Based on GPS Observation (Dissertation). Institute of Geodesy and Geophysics, Chinese Academy of Sciences, Wuhan (in Chinese with English abstract). Diao, F.Q., Xiong, X., Wang, R.J., 2010. Mechanism of Transient Post-Seismic Deformation Following the 2001 Mw7.8 Kunlun (China) Earthquake. Pure and Applied Geophysics, 168: 767-779. doi: 10.1007/s00024-010-0154-5 Du, F., Long, F., Ruan, X., et al., 2013. The Ms7.0 Lushan Earthquake and the Relationship with the M8.0 Wenchuan Earthquake in Sichuan, China. Chinese J. Geophys., 56(5): 1772-1783 (in Chinese with English abstract). doi: 10.6038/cjg20130535 Freed, A.M., 2007. Afterslip (and Only Afterslip) Following the 2004 Parkfield, California Earthquake. Geophys. Res. Lett., 34. doi: 10.1029/2006GL029155 Liu, C.L., Zheng, Y., Ge, C., et al., 2013. Rupture Process of the M7.0 Lushan Earthquake. Science in China (Series D), 43(6): 1020-1026 (in Chinese). doi: 10.1007/s11430-01304639-9 Liu, J., Yi, G.X., Zhang, Z.W., et al., 2013. Introduction to the Lushan, Sichuan Ms7.0 Earthquake on 20 April 2013. Chinese J. Geophys., 56(4): 1404-1407 (in Chinese with English abstract). doi: 10.6038/cjg20130434 Long, F., Ni, S.D., Wen, X.Z., 2011. Variations of Moho Depth and Velocity Ratio along and Surrounding the Longmenshan Fault Zone from Tele-Seismic Receiver Functions. Acta Geoscientica Sinica, 32(4): 438-446 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DQXB201104014.htm Lorenzo-Martín, F., Roth, F., Wang, R., 2006. Inversion for Rheological Parameters from Postseismic Surface Deformation Associated to the 1960 Valdivia Earthquake, Chile. Geophys. J. Int., 164: 75-87. doi: 10.1111/j.1365-246X.2005.02803.x Lü, J., Wang, X.S., Su, J.R., et al., 2013. Hypocentral Location and Source Mechanism of the Ms7.0 Lushan Earthquake Sequence. Chinese J. Geophys., 56(5): 1753-1763 (in Chinese with English abstract). doi: 10.6038/cjg20130533 Nur, A., Mavok, G., 1974. Postseismic Viscoelastic Rebound. Science, 183: 204-206. doi:10.1126/ science.183.4121.204 Peltzer, G., Rosen, P., Rogez, F., et al., 1998. Poroelastic Rebound along the Landers 1992 Earthquake Surface Rupture. J. Geophys. Res., 103(B12): 30131-30145. doi: 10.1029/98JB02302 Pollitz, F.F., Peltzer, G., Bürgmann, R., 2000. Mobility of the Continental Mantle: Evidence from Postseismic Geodetic Observations Following the 1992 Landers Earthquake. J. Geophys. Res., 105(B4): 8035-8054. doi: 10.1029/1999JB900380 Reilinger, R.E., Ergintav, S., Burgmann, R., et al., 2000. Coseismic and Postseismic Fault Slip for the 17 August 1999, M=7.5, Izmit, Turkey Earthquake. Science, 289: 1519-1523. doi:10.1126/ SCIENCE.289.5484.1519 Ryder, I., Parsons, B., Wright, T.J., et al., 2007. Post-Seismic Motion Following the 1997 Manyi (Tibet) Earthquake: InSAR Observations and Modeling. Geophys. J. Int., 169: 1009-1027. doi:10.1111/j.1365 -246X.2006.03312.x Segall, P., Davis, J.L., 1997. GPS Applications for Geodynamics and Earthquake Studies. Ann. Rev. Earth Planet. Sci., 25: 301-36. doi: 10.1146/annurev.earth.25.1.301 Shao, Z.G., Wang, R.J., Wu, Y.Q., et al., 2011. Rapid Afterslip and Short-Term Viscoelastic Relaxation Following the 2008 Mw7.9 Wenchuan Earthquake. Earthq. Sci., 24: 163-175. doi:10.1007/ s11589-010-0781-z Shen, Z.K., Lü, J.N., Wang, M., et al., 2005. Contemporary Crustal Deformation around the Southeast Borderland of the Tibetan Plateau. J. Geophys. Res., 110, B11409. doi: 10.1029/2004JB003421 Wang, R., Roth, F., Lorenzo-Martín, F., 2006. PSGRN/PSCMP—A New Code for Calculating Co- and Post-Seismic Deformation, Geoid and Gravity Changes Based on the Viscoelastic-Gravitational Dislocation Theory. Computers and Geosciences, 32(4): 527-541. doi: 10.1016/j.cageo.2005.08.006 Wang, W.M., Hao, J.L., Yao, Z.X., 2013. Preliminary Result for Rupture Process of Apr. 20, 2013, Lushan Earthquake, Sichuan, China. Chinese J. Geophys., 56(4): 1412-1417 (in Chinese with English abstract). doi: 10.6038/cjg20130436 Wu, Y.Q., Jiang, Z.S., Wang, M., et al., 2013. Preliminary Results of the Co-Seismic Displacement and Pre-Seismic Strain Accumulation of the Lushan Ms7.0 Earthquake Reflected by the GPS Surveying. Chin. Sci. Bull., 58(20): 1910-1916 (in Chinese). doi: 10.1007/s11434-013-5998-5 Xie, Z.J., Jin, B.K., Zheng, Y., et al., 2013. Source Parameters Inversion of the 2013 Lushan Earthquake by Combining Teleseismic Waveforms and Local Seismograms. Science in China (Series D), 43: 1010-1019 (in Chinese). doi: 10.1007/s11430-013-4640-3 Xu, X.W., Chen, G.H., Yu, G.H., et al., 2013. Seismogenic Structure of Lushan Earthquake and Its Relationship with Wenchuan Earthquake. Earth Science Frontiers, 20(3): 11-20 (in Chinese with English abstract). http://d.wanfangdata.com.cn/Periodical/dxqy201303002 Zeng, X.F., Luo, Y., Han, L.B., et al., 2013. The Lushan Ms7.0 Earthquake on 20 April 2013: A High-Angle Thrust Event. Chinese J. Geophys., 56(4): 1418-1424 (in Chinese with English abstract). doi:10.6038/ cjg20130437 Zhang, C.J., Shi, Y.L., Ma, L., 2009. Numerical Simulation of Crust Rheological Property Reflected by Post-Seismic Deformation of Kunlun Large Earthquake. Rock and Soil Mechanics, 30(9): 2552-2558 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-YTLX200909005.htm Zhang, Y., Xu, L.S., Chen, Y.T., 2013. Rupture Process of the Lushan 4.20 Earthquake and the Preliminary Analysis on the Disaster-Causing Mechanism. Chinese J. Geophys., 56(4): 1408-1411 (in Chinese with English abstract). doi: 10.6038/cjg20130435 Zhou, Q.Y., 2011. Crustal Structure of South Longmenshan Fault Zone from Teleseismic Receive Functions (Dissertation). Institute of Earthquake Science, China Earthquake Administration, Beijing (in Chinese with English abstract). 刁法启, 2011. 基于GPS观测的同震、震后形变研究(博士学位论文). 武汉: 中国科学院测量与地球物理研究所. 杜方, 龙锋, 阮祥, 等, 2013. 四川芦山7.0级地震及其与汶川8.0级地震的关系. 地球物理学报, 56(5): 1772-1783. https://www.cnki.com.cn/Article/CJFDTOTAL-DQWX201305036.htm 刘成利, 郑勇, 葛粲, 等, 2013.2013年芦山7.0级地震的动态破裂过程. 中国科学(D辑), 43(6): 1020-1026. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK201306010.htm 刘杰, 易桂喜, 张致伟, 等, 2013.2013年4月20日四川芦山Ms7.0地震介绍. 地球物理学报, 56(4): 1404-1407. 龙锋, 倪四道, 闻学泽, 2011. 用远震接收函数研究龙门山断裂带与其邻区的莫霍面深度及波速比分布. 地球学报, 32(4): 438-446. doi: 10.3975/cagsb.2011.04.07 吕坚, 王晓山, 苏金蓉, 等, 2013. 芦山7.0级地震序列的震源位置与震源机制解特征. 地球物理学报, 56(5): 1753-1763. https://www.cnki.com.cn/Article/CJFDTOTAL-DQWX201305034.htm 王卫民, 郝金来, 姚振兴, 2013.2013年4月20日四川芦山地震震源破裂过程反演初步结果. 地球物理学报, 56(4): 1412-1417. https://www.cnki.com.cn/Article/CJFDTOTAL-DQWX201304038.htm 武艳强, 江在森, 王敏, 等. 2013. GPS监测的芦山7.0级地震前应变积累及同震位移场初步结果. 科学通报, 58(20): 1910-1916. https://www.cnki.com.cn/Article/CJFDTOTAL-KXTB201320005.htm 谢祖军, 金笔凯, 郑勇, 等, 2013. 近远震波形反演2013年芦山地震震源参数. 中国科学(D辑), 43: 1010-1019. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK201306009.htm 徐锡伟, 陈桂华, 于贵华, 等, 2013. 芦山地震发震构造及其与汶川地震关系讨论. 地学前缘, 20(3): 11-20. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201303002.htm 曾祥方, 罗艳, 韩立波, 等. 2013.2013年4月20日四川芦山MS7.0地震: 一个高角度逆冲地震. 地球物理学报, 56(4): 1418-1424. https://www.cnki.com.cn/Article/CJFDTOTAL-DQWX201304039.htm 张晁军, 石耀林, 马丽, 2009. 昆仑山大地震震后形变反映的地壳岩石流变特性. 岩土力学, 30(9): 2552-2558. doi: 10.3969/j.issn.1000-7598.2009.09.002 张勇, 许力生, 陈运泰, 2013. 芦山4.20地震破裂过程及其致灾特征初步分析. 地球物理学报, 56(4): 1408-1411. https://www.cnki.com.cn/Article/CJFDTOTAL-DQWX201304037.htm 周青云, 2011. 龙门山断裂带南段地壳的接收函数方法研究(硕士论文). 北京: 中国地震局地震预测研究所. -
