Genetic Mechanism of Double-Layer Structure in Paleogene of Fushan Sag, Beibu Gulf Basin
-
摘要: 以北部湾盆地区域构造分析为基础, 在福山凹陷构造活动性研究的基础上探讨了福山凹陷形成的动力学机制, 分析了凹陷东部地区古近系地层中双层结构的形成机制问题.研究认为: 福山凹陷在平面上受红河断裂的左行走滑和海南隆起顺时针旋转的双重作用, 流三段沉积期凹陷在旋转-拉分作用下发生强烈的水平伸展, 为东部地区下构造层中的反向断层提供动力源, 海南隆起的快速隆升作用形成了上构造层中的重力滑动生长断层, 渐新统早期在流二段泥岩中发育的火成岩侵入体在凹陷的东部地区形成一道天然屏障, 最终形成双层结构.结果表明, 双层结构形成过程可划分为裂陷雏形期、下构造层伸展断裂期、中部塑性层发育期、上构造层形成期以及双层结构定形期5个主要阶段.Abstract: Based on the regional tectonic analysis of Beibu Gulf basin, in this paper, the tectonic activities of Fushan sag is studied, the dynamic formation mechanism of the sag is discussed, and the formation mechanism of double-layer structure in Paleogene strata of the eastern area is analyzed. It is regarded that Fushan sag was under the dual effect of sinistral strike-slip of Red River fault and clockwise rotation of Hainan uplift. During the deposition period of the third member of Liushagang Formation (Els3), intense horizontal extension occurred during the rotation and pull-apart of the sag, which provided dynamic source for the antithetic faults of the lower tectonic layer in the eastern area. The rapid uplift of Hainan uplift led to the formation of gravity slumping growth faults in the upper tectonic layer. In the Early Oligocene, the intrusive igneous rocks in the second member of Liushagang Formation (Els2) formed a natural barrier. Finally, there formed the double-layer structure. The forming process of the double-layer can be divided into five major stages as follows: rifting embryonic period, extending faulted period of the lower tectonic layer, development period of middle plastic layer, formation period of tectonic system, and finalizing period of double-layer structure.
-
Key words:
- difference extension /
- double-layer structure /
- genetic mechanism /
- Fushan sag /
- Beibu Gulf basin /
- petroleum geology
-
图 4 福山凹陷古近系主控断层走向演化及沉积中心演化
A.长流组，1 000 m厚度等值线；B.流三段段，1 000m厚度等值线；C.流二段，500 m厚度等值线；D.流一段，1 000 m厚度等值线；E.涠三段+涠二段，800 m厚度等值线；F.涠一段，800 m厚度等值线
Fig. 4. The evolution of the main fault structure and deposition center of Fushan sag in Paleogene
图 5 福山凹陷流二段侵入岩厚度分布
Fig. 5. The isopach map of the Intrusive rocks in the second member of the Liushagang Formation, Fushan sag
图 6 福山凹陷南部斜坡带地层分布特征
a.地层分布范围；b.地层产状
Fig. 6. Stratigraphic distribution characteristics of the south slope belt
-
Hao, T, Y., Jiang, W.W., Xu, Y., et al., 2005. Geophysical Research on Deep Structure Feature in Study Region of Red River Fault Zone. Progress in Geophysics, 20(3): 584-593(in Chinese with English abstract). Jiang, H., Wang, H., Xiao, J., et al., 2008. Tectonic Inversion and Its Relationship with Hydrocarbon Accumulation in Zhu-3 Depression of Pearl River Mouth Basin. Acta Petrolei Sinica, 29(3): 372-377(in Chinese with English abstract). http://www.cqvip.com/QK/95667X/20083/27698977.html Leloup, P.H., Lacassin, R., Tapponnier, P., 1995. The Ailao Shan-Red River Shear Zone(Yunnan, China), Tertiary Transform Boundary of Indochina. Tectonophsics, 251(1-4): 3-84. doi: 10.1016/0040-1951(95)00070-4 Li, D.W., 2008. Three-Stage Tectonic Evolution and Metallogenic Evolution in the Qinghai-Tibet Plateau and Its Adjacent Area. Earth Science—Journal of China University of Geosciences, 33(6): 723-742(in Chinese with English abstract). doi: 10.3799/dqkx.2008.089 Li, S.T., Xie, X.N., Wang, H., et al., 2004. Sedimentary Basin Analysis Principle and Application. Higher Education Press, Beijing, 275-305(in Chinese). Lin, Z.L., 2011. Research on the Tectonic Characteristics of Paleogene in Fushan Sag, Beibuwan Basin(Dissertation). China University of Geosciences, Wuhan, 37-40(in Chinese with English abstract). Lin, Z.L., Wang, H., Jiang, H., et al., 2009. The Association Analysis of Tectonic Stress Field to Episodic Rifting in Cenozoic of Beitang Sag of Bohai Bay Basin. Journal of Oil and Gas Technology, 31(3): 24-29(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-JHSX200903005.htm Lister, G.S., 1986. Detachment Faulting and the Evolution of Passive Continental Margins. Geology, 14(10): 890-891. doi:10.1130/0091-7613(1986)14<890:CARODF>2.0.CO;2 Liu, E.T., Wang, H., Lin, Z.L., et al, 2012. Characteristics and Hydrocarbon Enrichment Rules of Transfer Zone in Fushan Sag, Beibuwan Basin. Journal of Central South University(Science and Technology), 43(10): 3946-3953(in Chinese with English abstract). http://www.ingentaconnect.com/content/brill/me/2012/00000018/F0020002/art00001 Liu, H.F., Li, X.Q., Liu, L.Q., et al., 2005. Petroleum Plays in Rift Basins and Extensional Structures. Oil & Gas Geology, 26(5): 537-552(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SYYT200505000.htm Luo, Q., Jiang, Z.X., Pang, X.Q., 2007. Mechanism and Model of Fault Controlling Petroleum Accumulation. Petroleum Industry Press, Beijing, 68-70(in Chinese). Luo, Q., Pang, X.Q., 2008. Reservior Controlling Mechanism and Petroleum Accumulation Model for Consequent Fault and Antithetic Fault in Fushan Depression of Hainan Area. Acta Petrolei Sinica, 29(3): 363-367(in Chinese with English abstract). http://www.researchgate.net/publication/281538548_Reservoir_controlling_mechanism_and_petroleum_accumulation_model_for_consequent_fault_and_antithetic_fault_in_Fushan_Depression_of_Hainan_area Ma, Q.L., Zhao, S.E., Liao, Y.T., et al., 2012. Sequence Architectures of Paleogene Liushagang Formation and Its Significance in Fushan Sag of the Beibuwan Basin. Earth Science—Journal of China University of Geosciences, 37(4): 667-678(in Chinese with English abstract). http://www.sciencedirect.com/science/article/pii/S1876380412600482 Mo, Y.Q., Shi, Y.S., 1987. Paleomagnetic Study and Tectonic Evolution of Hainan Terrane and Its Vicinal Continental Coast the Late Mesozoic to Cenozoic. Journal of Nanjing University(Natural Sciences Edition), 23(3): 521-532(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-NJDZ198703013.htm Shi, X.B., Zhou, D., Zhang, Y.X., 2000. The Continental Margin of the Northern South China Sea Lithospheric Thermo Rheological Structure. Chinese Science Bulletion, 45(15): 1660-1665(in Chinese). doi: 10.1360/csb2000-45-15-1660 Shi, X.P., Li, L., 2010. Modeling Experiments of Structural Evolution since Late Mesozoic in West Shandong Uplift, China. Journal of China University of Petroleum, 34(3): 25-29, 33(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SYDX201003007.htm Shi, Y.M., Liu, J., Zhang, M.Z., et al., 2007. Experience and Understand in Oil and Gas Exploration in Fushan Sag, Hainan Province. South China Journal of Seismology, 27(3): 57-68(in Chinese with English abstract). http://d.wanfangdata.com.cn/Periodical_hndz200703006.aspx Tian, Z.Y., Wang, S.S., 1985. Geological Structures and Oil and Gas Sedimentary Basins in the China Seas. Acta Petrolei Sinica, 6(3)1-10(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SYXB198503000.htm Wang, Y., 1994. Analysis of Activity of the Red River Fault. Geological Hazards and Environment Preservation, 5(2): 28-35(in Chinese). Wernicke, B., 1981. Low-angle Normal Faults in the Basin and Range Province: Nappe Tectonics in an Extending Orogen. Nature, 291(25): 645-648. http://www.nature.com/articles/291645a0 Xu, X.B., Li, Y., Xue, D.J., et al., 2014. Deformation Characteristics and Geochronological Constraints of Late Mesozoic Extensional Structures in Quanzhou, Fujian Province. Earth Science—Journal of China University of Geosciences, 39(8): 1079-1098(in Chinese with English abstract). doi: 10.3799/dqkx.2014.096 Xu, Y.D., Liang, Y.P., Jiang, S.S., et al., 2014. Evolution of Cenozoic Sedimentary Basins in Eastern Chin. Earth Science—Journal of China University of Geosciences, 39(1): 45-63(in Chinese with English abstract). doi: 10.3799/dqkx.2014.005 Yan, Q.S., Shi, X.F., 2007. Hainan Mantle Plume and the Formation and Evolution of the South China Sea. Geological Journal of China Universities, 13(2): 311-322(in Chinese with English abstract). Yu, J.J., Luo, Q., Zhang, D.J., et al, 2004. Characteristics of Faults in the Fushan Depression of Hannan, the Beibuwan Basin and Their Controlling Roles to Hydrocarbon Pool-Formation. Petroleum Geology & Expeximent, 26(3): 241-248(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SYSD200403005.htm Zhang, J.G., Huangfu, G., Xie, Y.Q., et al., 2009. Study on the Activity of Red River Fault in Vietnam. Seismology and Geology, 31(3): 389-400(in Chinese with English abstract). Zhang, X., Ma, Y., 1996. Photoelastic Modeling Experiment of Tectonic Stress Field Evolution in Huanghua Depression. Petroleum Exploration and Development, 23(1): 21-24(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-SKYK601.004.htm Zhu, Z.C., 1987. Extensional Tectonics and Detachment Fault. Geological Science and Technology Information, 6(1): 18-25(in Chinese with English abstract). 郝天珧, 江为为, 胥颐, 等, 2005. 红河断裂带研究区深部结构特点的地球物理研究. 地球物理学进展, 20(3): 584-593. doi: 10.3969/j.issn.1004-2903.2005.03.002 姜华, 王华, 肖军, 等, 2008. 珠江口盆地珠三坳陷构造反转与油气聚集. 石油学报, 29(3): 372-377. doi: 10.3321/j.issn:0253-2697.2008.03.011 李德威, 2008. 青藏高原及邻区三阶段构造演化与成矿演化. 地球科学——中国地质大学学报, 33(6): 723-742. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX200806000.htm 李思田, 解习农, 王华, 等, 2004. 沉积盆地分析基础与应用. 北京: 高等教育出版社, 275-305. 林正良, 2011. 北部湾盆地福山凹陷古近纪构造特征研究(博士学位论文). 武汉: 中国地质大学(武汉), 37-40. 林正良, 王华, 姜华, 等, 2009. 渤海湾盆地北塘凹陷新生代幕式裂陷过程与构造应力场变化的关联分析. 石油天然气学报, 31(3): 24-29. doi: 10.3969/j.issn.1000-9752.2009.03.005 刘恩涛, 王华, 林正良, 等, 2012. 北部湾盆地福山凹陷构造转换带及其油气富集规律. 中南大学学报, 43(10): 3946-3953. https://www.cnki.com.cn/Article/CJFDTOTAL-ZNGD201210031.htm 刘和甫, 李晓清, 刘立群, 等, 2005. 伸展构造与裂谷盆地成藏区带. 石油与天然气地质, 26(5): 537-552. doi: 10.3321/j.issn:0253-9985.2005.05.001 罗群, 姜振学, 庞雄奇, 2007. 断裂控藏机理与模式. 北京: 石油工业出版社, 68-70. 罗群, 庞雄奇, 2008. 海南福山凹陷顺向和反向断裂控藏机理及油气聚集模式. 石油学报, 29(3): 363-367. doi: 10.3321/j.issn:0253-2697.2008.03.009 马庆林, 赵淑娥, 廖远涛, 等, 2012. 北部湾盆地福山凹陷古近系流沙港组层序地层样式及其研究意义. 地球科学——中国地质大学学报, 37(4): 667-678. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX201204007.htm 莫宴情, 施央申, 1987. 海南岛地体及其毗邻陆缘晚中生代-新生代古地磁研究和构造演化. 南京大学学报, 23(3): 521-532. https://www.cnki.com.cn/Article/CJFDTOTAL-NJDZ198703013.htm 施小斌, 周蒂, 张毅祥, 2000. 南海北部陆缘岩石圈热-流变结构. 科学通报, 45(15): 1660-1665. doi: 10.3321/j.issn:0023-074X.2000.15.017 时秀朋, 李理, 2010. 鲁西隆起中-新生代伸展构造演化的模拟试验. 中国石油大学学报, 34(3): 25-29, 33. doi: 10.3969/j.issn.1673-5005.2010.03.005 石彦民, 刘菊, 张梅珠, 等, 2007. 海南福山凹陷油气勘探实践与认识. 华南地震, 27(3): 57-68. doi: 10.3969/j.issn.1001-8662.2007.03.006 田在艺, 王善书, 1985. 我国海域地质构造与含油气沉积盆地特征. 石油学报, 6(3): 1-10. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB198503000.htm 王宇, 1994. 红河断裂南段活动性分析. 地质灾害与环境保护, 5(2): 28-35. https://www.cnki.com.cn/Article/CJFDTOTAL-DZHB199402003.htm 徐先兵, 李源, 薛德杰, 等, 2014. 福建泉州晚中生代伸展构造变形特征与年代学制约. 地球科学——中国地质大学学报, 39(1): 45-63. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX201401005.htm 徐亚东, 梁银平, 江尚松, 等, 2014. 中国东部新生代沉积盆地演化. 地球科学——中国地质大学学报, 39(8): 1079-1098. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX201408011.htm 鄢全树, 石学法, 2007. 海南地幔柱与南海形成演化. 高校地质学报, 13(2): 311-322. doi: 10.3969/j.issn.1006-7493.2007.02.014 于俊吉, 罗群, 张多军, 等, 2004. 北部湾盆地海南福山凹陷断裂特征及其对油气成藏的控制作用. 石油实验地质, 26(3): 241-248. doi: 10.3969/j.issn.1001-6112.2004.03.005 张建国, 皇甫岗, 谢英情, 等, 2009. 越南红河断裂活动性研究. 地震地质, 31(3): 389-400. doi: 10.3969/j.issn.0253-4967.2009.03.002 张兴, 马寅, 1996. 黄骅坳陷构造应力场演化光弹模拟实验. 石油勘探与开发, 23(1): 21-24. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK601.004.htm 朱志澄, 1987. 伸展构造和拆离断层. 地质科技情报, 6(1): 18-25. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKQ198701004.htm -
