    广西凌云-凤山"6·28"震群: 岩溶发育区流体触发断层浅层活动机理

    李志勇 李细光 严小敏 姚宏 曾佐勋 王鹏来

    李志勇, 李细光, 严小敏, 姚宏, 曾佐勋, 王鹏来, 2015. 广西凌云-凤山'6·28'震群: 岩溶发育区流体触发断层浅层活动机理. 地球科学, 40(10): 1667-1676. doi: 10.3799/dqkx.2015.150
    引用本文: 李志勇, 李细光, 严小敏, 姚宏, 曾佐勋, 王鹏来, 2015. 广西凌云-凤山"6·28"震群: 岩溶发育区流体触发断层浅层活动机理. 地球科学, 40(10): 1667-1676. doi: 10.3799/dqkx.2015.150
    Li Zhiyong, Li Xiguang, Yan Xiaomin, Yao Hong, Zeng Zuoxun, Wang Penglai, 2015. Earthquake Swarms on June 28th of 2010, near Lingyun and Fengshan County, South China: Shallow Seismic Activity of Fault Induced by Surface Fluid in Karst Geology Area. Earth Science, 40(10): 1667-1676. doi: 10.3799/dqkx.2015.150
    Citation: Li Zhiyong, Li Xiguang, Yan Xiaomin, Yao Hong, Zeng Zuoxun, Wang Penglai, 2015. Earthquake Swarms on June 28th of 2010, near Lingyun and Fengshan County, South China: Shallow Seismic Activity of Fault Induced by Surface Fluid in Karst Geology Area. Earth Science, 40(10): 1667-1676. doi: 10.3799/dqkx.2015.150

    广西凌云-凤山"6·28"震群: 岩溶发育区流体触发断层浅层活动机理

    doi: 10.3799/dqkx.2015.150
    基金项目:

    广西地震科学基础研究项目 桂科攻12426001-4

    广西科学研究与技术开发计划项目 桂科攻1298005-1

    广西科学研究与技术开发计划项目 桂科攻1355010-6

    详细信息
      作者简介:

      李志勇(1979-), 男, 博士, 主要从事构造地质学教学、构造定量解析与模拟研究.E-mail: zhiyong.li@cug.edu.cn

      通讯作者:

      李细光, E-mail: hnouyang@163.com

    • 中图分类号: P315.1

    Earthquake Swarms on June 28th of 2010, near Lingyun and Fengshan County, South China: Shallow Seismic Activity of Fault Induced by Surface Fluid in Karst Geology Area

    • 摘要: 2010年6月28日, 广西凌云-凤山地区在特大强降雨活动之后发生密集的浅源低震级地震活动, 造成严重经济损失.该震群活动是否与强降雨有关, 强降雨是否可以触发震群活动, 仍存在争议.基于该地区地震构造背景, 对震群的活动特征、震源机制解及其与断裂构造的关系进行了分析, 并建立了断层内流体孔隙压力触发断层滑动的力学模型.该浅层震群活动的发生时间、震中位置和活动频次均与特大强降雨具有密切的相关性.认为岩溶地区长期干旱和地下水缺乏有利于地壳浅层的应力积累.地表流体很难通过下渗扩散触发断层的完全解锁和深部滑动, 但岩溶裂隙和管道有利于地表流体快速汇聚下渗, 引起断层浅层强度的弱化, 导致断层部分解锁滑动.并在断层附近形成局部应力场异常和离散的封闭性超压流体, 触发密集的浅层低震级震群活动.



    • 图  1  震群震中位置及降雨量分布

      Fig.  1.  Location of epicenters and distribution of rainfall

      图  2  地质构造和震群位置

      F1.百色-合浦断裂带;F2.巴马-博白断裂带;F3.河池-宜州断裂带;F4.木伦-东兰-逻楼断裂带;F5.更新-凌云-那能断裂带;f1.江州-高家洞断裂;f2.逻楼-江州断裂;f3.寅村断裂;f4.坡楼断裂;f5.那林断裂;f6.岩板断裂;f7.逻楼-平吕断裂;f8.陇仓断裂;f9.沙里-弄所断裂

      Fig.  2.  Geology setting and earthquake swarms

      图  3  2010年6月江洲流动台记录的S-P波速差随时间变化

      Fig.  3.  The time series of S-P velocity difference recorded by mobile Seismic station in Jiangzhou, June 2010

      图  4  震源分布与断层关系剖面

      f1.江州-高家洞断裂;f2.逻楼-高家洞断裂;震群精定位分析结果由广西地震局台网中心提供

      Fig.  4.  Cross section profile of earthquake swarms and faults

      图  5  凌云凤山震群日降雨量与地震日频次统计

      a.江州站降雨量;b.罗楼站降雨量;c.地震日频次;数据由广西区气象局提供

      Fig.  5.  The time series of the daily rain amount

      图  6  断层内流体孔隙压力触发断层滑动的应力模型

      a.岩溶管道和裂隙有利于地表流体快速下渗,从而弱化断层强度,引起断层浅层部位的局部解锁滑动;b.断层内流体孔隙压力触发断层滑动的影响深度,图中假定岩石平均密度为2.5×103 kg/m3,断层面摩擦系数为0.6;c.流体作用下断层滑动准的应力莫尔图解,φ为内摩擦角,σn为断层面上正应力,σn为断层面上剪应力

      Fig.  6.  Stress model showing fault slip triggered by pore-fluid pressure

      表  1  凌云-凤山震群ML≥2.0地震震源机制(蒙荣国等,2012)

      Table  1.   Focal mechanism of the earthquake swarms with ML≥2.0

      时间 纬度(N) 经度(E) ML 节面Ⅰ 节面Ⅱ P轴 T轴 滑动性质
      走向 倾角 走向 倾角 走向 倾角 走向 倾角
      6月28日12∶41 24.38° 106.90° 3.0 26° 22° 190° 69° 105° 23° 269° 66° 逆倾滑动
      6月28日17∶36 24.38° 106.88° 2.0 142° 23° 321° 67° 50° 68° 231° 22° 正倾滑动
      6月28日18∶02 24.35° 106.95° 2.4 112° 81° 30° 173° 47° 45° 30° 正倾滑动
      6月28日19∶55 24.40° 106.86° 2.6 281° 20° 67° 73° 142° 60° 346° 28° 正倾滑动
      6月28日19∶58 24.38° 106.90° 2.6 292° 76° 180° 34° 347° 49° 225° 24° 正倾滑动
      6月28日20∶08 24.38° 106.88° 2.3 266° 24° 59° 69° 132° 65° 337° 23° 正倾滑动
      6月28日20∶34 24.40° 106.88° 2.4 210° 67° 320° 51° 348° 46° 88° 正倾滑动
      6月28日21∶06 24.38° 106.90° 2.3 271° 27° 88° 299° 37° 70° 41° 走滑
      6月28日21∶34 24.38° 106.88° 2.2 29° 26° 206° 64° 293° 71° 117° 19° 正倾滑动
      6月28日22∶02 24.38° 106.88° 2.5 285° 19° 138° 74° 243° 60° 40° 28° 正倾滑动
      6月28日23∶13 24.38° 106.90° 2.5 31° 23° 190° 69° 265° 65° 106° 23° 正倾滑动
      6月29日02∶03 24.38° 106.88° 2.2 117° 89° 24° 33° 177° 38° 55° 35° 走滑
      6月29日02∶04 24.41° 106.85° 2.2 36° 24° 220° 66° 314° 68° 129° 21° 正倾滑动
      6月29日02∶01 24.38° 106.88° 3.1 120° 87° 26° 31° 182° 40° 56° 35° 走滑
      6月29日03∶11 24.38° 106.88° 2.0 26° 36° 258° 66° 148° 17° 27° 59° 逆倾滑动
      6月29日06∶09 24.40° 106.88° 2.5 18° 37° 262° 72° 148° 20° 30° 52° 逆倾滑动
      6月29日06∶05 24.38° 106.86° 2.3 120° 87° 27° 43° 175° 34° 63° 29° 走滑
      6月29日10∶38 24.38° 106.91° 2.5 24° 22° 195° 68° 279° 66° 107° 23° 正倾滑动
      6月29日11∶22 24.38° 106.88° 2.3 30° 32° 152° 72° 208° 82° 22° 正倾滑动
      6月29日13∶06 24.38° 106.88° 2.3 275° 28° 185° 90° 300° 39° 70° 39° 走滑
      6月30日10∶17 24.38° 106.91° 2.3 29° 76° 274° 31° 88° 51° 320° 26° 正倾滑动
      6月30日13∶51 24.38° 106.90° 2.8 204° 48° 308° 74° 355° 41° 250° 16° 正倾滑动
      7月01日10∶27 24.38° 106.86° 3.2 26° 23° 210° 67° 117° 22° 300° 68° 逆倾滑动
      7月04日19∶45 24.45° 106.88° 2.6 197° 89° 290° 26° 311° 41° 83° 38° 走滑
      7月05日03∶24 24.38° 106.88° 2.5 262° 27° 154° 81° 271° 48° 43° 31° 走滑
      下载: 导出CSV
    • Bollinger, L., Nicolas, M., Marin, S., 2010. Hydrological Triggering of the Seismicity around a Salt Diapir in Castellane, France. Earth and Planetary Science Letters, 290(1-2): 20-29. doi: 10.1016/j.epsl.2009.11.051
      Du, Y.L., Wang, H. T, Yuan, L.W., 2008. Analysis and Research of China's Reservoir Induced Seismicity. Earthquake, 28(4): 39-51 (in Chinese with English abstract).
      Ellsworth, W.L., 2013. Injection-Induced Earthquakes. Science, 341(6142): 142-143.
      Farrell, N.J.C., Healy, D., Taylor, C., 2014. Anisotropy of Permeability in Faulted Porous Sandstones. Journal of Structural Geology, 63(2): 50-67. doi: 10.1016/j.jsg.2014.02.008
      Grünthal, G., 2013. Induced Seismicity Related to Geothermal Projects Versus Natural Tectonic Earthquakes and Other Types of Induced Seismic Events in Central Europe. Geothermics, 52(9): 22-35. doi: 10.1016/j.geothermics.2013.09.009
      Hainzl, S., Kraft, T., Wassermann, J., et al., 2006. Evidence for Rainfall-Triggered Earthquake Activity. Geophysical Research Letters, 33(19). doi: 10.1029/2006GL027642
      Hunt, J.M., 1990. Generation and Migration of Petroleum from Abnormally Pressured Fluid Compartments. AAPG Bulletin, 74(1): 1-12.
      Husen, S., Bachmann, C., Giardini, D., 2007. Locally Triggered Seismicity in the Central Swiss Alps Following the Large Rainfall Event of August 2005. Geophys. J. Int. , 171(3): 1126-1134. doi: 10.1111/j.1365-246X.2007.03561.x
      Jiang, H.K., Yang, M.L., Sun, X.J., et al., 2011. A Typical Example of Locally Triggered Seismicity in the Boundary Area of Lingyun and Fengshan Following the Large Rainfall Event of June 2010. Chinese J. Geophys. , 54(10): 2606-2619 (in Chinese with English abstract).
      Kodaira, S., Idaka, T., Kato, A., et al., 2004. High Pore Fluid Pressure may Cause Silent Slip in the Nankai Trough. Science, 304(5675): 1295- 1298. doi: 10.1126/science.1096535
      Kraft, T., Wassermann, J., Igel, H., 2006. High-Precision Relocation and Focal Mechanism of the 2002 Rain-Triggered Earthquake Swarms at Mt Hochstaufen, SE Germany. Geophys. J. Int. , 167(3): 1513-1528. doi: 10.1111/j.1365-246X.2006.03171.x
      Li, T., Cai, M.F., Zhang, S. Q, et al., 2005. Mining-Induced Seismicity in China. Seismological Research of Northeast China, 21(3): 1-26 (in Chinese with English abstract).
      Liu, M.L., 2001. Overpressured Fluids in Fault Zones and Their Roles in Earthquake and Hydrothermal Metallogeny. Advance in Earth Sciences, 16(2): 238-243 (in Chinese with English abstract).
      Meng, R.G., Li, X.G., Yao, H., et al., 2012. Investigation Report on Relationship of Environmental Hydrogeology Conditions and Earthquake Swarms on June 28th of 2010, in Area of Lingyun and Fengshan County, South China, 72-102.
      Miller, S.A., 2008. Note on Rain-Triggered Earthquakes and Their Dependence on Karst Geology. Geophys. J. Int., 173(1): 334-338. [doi: 101111/j.1365-246X.2008.03735.x]
      Miller, S.A., Collettini, C., Chiaraluce, L., et al., 2004. Aftershocks Driven by a High-Pressure CO2 Source at Depth. Nature, 427(6976): 724-727. doi: 10.1038/nature02251
      Muco, B., 1999. Statistical Investigation on Possible Seasonality of Seismic Activity and Rainfall-Induced Earthquakes in Balkan Area. Phys. Earth Planet. Inter. , 114(3-4): 119-127. doi: 10.1016/S0031-9201(99)00051-5
      Nicol, A., Gerstenberger, M., Bromley, C., et al., 2013. Induced Seismicity; Observations, Risks and Mitigation Measures at CO2 Storage Sites Original Research Article. Energy Procedia, 37(6): 4749-4756. doi: 10.1016/j.egypro.2013.06.384
      Orlecka-Sikora, B., Lasocki, S., Lizurek, G., et al., 2012. Response of Seismic Activity in Mines to the Stress Changes due to Mining Induced Strong Seismic Events. International Journal of Rock Mechanics and Mining Sciences, 53(5): 151-158. doi: 10.1016/j.ijrmms.2012.05.010
      Saar, O., Manga, M., 2003. Seismicity Induced by Seasonal Groundwater Recharge at Mt. Hood, Oregon. Earth Planet. Sci. Lett. , 214(3-4): 605-618. doi: 10.1016/S0012-821X(03)00418-7
      杜运连, 王洪涛, 袁丽文, 2008. 我国水库诱发地震研究. 地震, 28(4): 39-51. https://www.cnki.com.cn/Article/CJFDTOTAL-DIZN200804005.htm
      蒋海昆, 杨马陵, 孙学军, 等, 2011. 暴雨触发局部地震活动的一个典型例子: 2010年6月广西凌云—凤山交界3级震群活动. 地球物理学报, 54(10): 2606-2619. doi: 10.3969/j.issn.0001-5733.2011.10.018
      李铁, 蔡美峰, 张少泉, 等, 2005. 我国的采矿诱发地震. 东北地震研究, 21(3): 1-26. https://www.cnki.com.cn/Article/CJFDTOTAL-DDYJ200503000.htm
      刘亮明, 2001. 断层带中超压流体及其在地震和成矿中的作用. 地球科学进展, 16(2): 238-243. doi: 10.3321/j.issn:1001-8166.2001.02.016
      蒙荣国, 李细光, 姚宏, 等, 2012. 凤山县至凌云县一带岩溶区环境水文地质条件与"6·28"震群活动关系调查研究报告. 广西: 广西水文地质工程地质队, 72-102.
