Gas Migration and Accumulation Modelling in Volcanic Reservoirs, Xujiaweizi Fault Depression, Songliao Basin
-
摘要: 与火山岩有关的油气藏或油气显示已在世界范围内被广泛发现，然而受火山岩储层强非均质性的影响，揭示火山岩油气成藏过程的盆地模拟研究进展十分缓慢，尚未见到关于火山岩储层中油气运聚成藏模拟研究的报道.采用PetroMod软件首次成功模拟了火山岩储层天然气运聚成藏过程，系统论述了含油气盆地模拟工作中三维精细地质模型的建立、关键参数的选取，并在统计国内外火山岩物性的基础上提出了不同岩性火山岩孔隙度与深度的关系，结合研究区岩相分布，考察了不同断裂活动期和不同运移算法时深层火山岩天然气运聚过程.结果揭示：徐家围子断陷深层有机质具有接力生气的特征，无主生气期，火山岩气藏主要形成于泉头组-青山口组末期，气藏发育位置受控于断裂分布与活动期、火山岩体和储层孔隙度；活动期次与时间可影响天然气聚集层位，深层气源断裂活动期要早于94.5 Ma；采用混合法模拟火山岩储层中的油气运聚成藏比较合适.徐家围子断陷深层火山岩天然气的下一步勘探方向为斜坡带、洼陷深部的微幅度构造、火山岩体和岩性尖灭带，同时深层致密砂砾岩储层也应有较大潜力.Abstract: Volcanic reservoirs and oil & gas shows have been found worldwide. However, the modelling of volcanic rocks related hydrocarbon accumulation process shows little progress due to strong volcanic reservoir heterogeneity. Using PetroMod software, gas migration and accumulation in the volcanic reservoirs has been successfully modelled for the first time in this study. Three dimensional geological modelling, key parameters or methods selection are described in detail. Based on the statistical porosity of volcanic rocks, the relationship of porosity versus depth for volcanic rocks was established using an exponential model, then the gas migration and accumulation processes under different situations, such as fault activity periods and flow simulation methods, were modelled. The results show that gas generation from organic matter in the study area has a long period in a relay mode without major gas generation period; volcanic gas reservoirs formed mainly during Quantou-Qingshankou Formation end period, and gas reservoir distributions were controlled by fault locations, activity periods, volcanic rock mass and porosities; the fault activity time is before 94.5 Ma indicated by simulation results. It is concluded that the integrated migration method is the best way for describing gas migration in the volcanic rocks. Slope zone, micro-structures in the sag, lithologic pinchout and volcanic mass are favorable zones for the volcanic gas exploration in the study area, meanwhile, the tight conglomerate or tight sand in the deep formation should also have a great potential for gas exploration.
-
图 1 徐家围子断陷工区简图及模型关键层位岩性柱状图
Fig. 1. Sketch of Xujiaweizi fault depression and lithological column of key strata
图 2 工区标准层 (营城组顶界) 埋深
井轨迹上的刻线来自分层数据
Fig. 2. Burial depth of standard formation (top depth of K1yc), marks in the well track were derived from geologic stratification data
图 3 徐家围子断陷热史模拟结果
a.实测温标与模拟值对比图；b.徐家围子断陷热流演化史，图中显示部分井
Fig. 3. Thermal history simulation results of Xujiaweizi fault depression
图 4 不同断裂活动期对深层火山岩气藏聚集的影响
图中底部时间表示断裂活动时期：-118 Ma表示断裂活动早于118 Ma；113.5~103.0 Ma表示断裂活动时期介于113.5和103.0 Ma之间，显示的聚集情况均为现今状态
Fig. 4. Influence of activity times of different faults on the simulated gas accumulation reservoirs at present time
图 5 不同运移算法时深层火山岩气藏聚集情况
Fig. 5. Gas accumulation results at present time by using different migrated methods
图 6 不同岩性火山岩孔隙度与深度关系
Fig. 6. Porosity of volcanic rock with different lithology versus burial depth
图 7 靶区营城组一段、三段火山岩岩相分布 (a) 和各岩相内岩性组成 (b)
Fig. 7. Diagram of volcanic lithofacies from K1yc1 and K1yc3 (a) and volcanic composition chart for different lithofacies rock (b)
图 8 火山岩孔隙度演化及其与天然气聚集关系
Fig. 8. Relationships of porosity and gas accumulation site at different geological times
图 9 徐家围子断陷沙河子组烃源岩有机质成熟度演化史
Fig. 9. K1sh source rock maturity charts at different geological times, Xujiaweizi fault depression
图 10 徐家围子断陷深层有机质生烃史
Fig. 10. Hydrocarbon generation history from deep source rocks, Xujiaweizi fault depression
图 11 徐家围子断陷深层火山岩气藏聚集过程
Fig. 11. Volcanic gas reservoir forming process, Xujiaweizi fault depression
图 12 模拟的火山岩气藏与勘探证实气藏边界叠合图，图中给出了5个预测区块位置
Fig. 12. Comparison between simulated gas reservoir and proved gas reservoir, and 5 probable gas reservoirs tagged as red ellipses
表 1 靶区深层有利火山岩气藏区块预测评价
Table 1. Estimated parameters of probable gas reservoirs in the deep layers of Xujiaweizi Fault depression
预测区块 聚集条件 圈闭条件
盖层封闭性储集条件 运移条件 综合评价 排序 距生烃中心距离 (km) 预计产量 (104 m3) 生气强度 (108 m3/km3) 营一段顶部年龄 (MPa) 登二段年龄 (MPa) 构造形态 圈闭大小 风化壳厚度 (m) 裂缝/条 (m) 次生孔隙度 (%) 断裂 预测1 8.015 3.5~25 3.83 5.72 6.54 微幅度构造 大 40 2.28 0.80 多条走滑调整断裂 聚集、储集、运移条件均好，圈闭大 1 预测2 14.280 5~80 52.90 1.55 6.90 洼陷深部斜坡带 小 - 0.50 1.11 徐中断裂 聚集条件较好，运移条件差，圈闭小，储集条件中等 4 预测3 32.460 8~12 0.80 6.47 5.16 斜坡带 较大 70 0.81 1.06 徐西断裂 圈闭较大，储集、运移条件较好，聚集条件差 2 预测4 35.560 8~10 1.30 6.26 5.20 斜坡带 中 50 0.46 1.01 徐西断裂 圈闭、储集条件中等，运移、聚集条件较差 3 预测5 29.910 8~14 1.40 6.47 7.08 微幅度构造 较小 - 4.97 3.36 近南北断裂 聚集条件中等，圈闭较小，储集、运移条件差 5
下载: 导出CSV
-
Baur, F., di Primio, R., Lampe, C., et al., 2011.Mass Balance Calculations for Different Models of Hydrocarbon Migration in the Jeanne D'arc Basin, Offshore Newfoundland.Journal of Petroleum Geology, 34(2):181-198.doi: 10.1111/j.1747-5457.2011.00500.x Casuscelli, S.G., Eimer, G.A., Canepa, A., et al., 1984.Determination of Paleoheat Flux from Vitrinite Reflectance Data.AAPG Bulletin, 68(11):1704-1717.doi: 10.1306/AD461980-16F7-11D7-8645000102C1865D Feng, Z.H., Ren, Y.G., Wang, C., et al., 2003.Study on Inclusion of Deep Buried Igneous Reservoir and Formation Period of Gas Pool in Songliao Basin.Natural Gas Geoscience, 14(6):436-442 (in Chinese with English abstract). http://www.oalib.com/paper/1417488 Feng, Z.H., Yin, C.H., Liu, J.J., et al., 2014.Formation Mechanism of In-Situ Volcanic Reservoirs in Eastern China:A Case Study from Xushen Gasfield in Songliao Basin.Science in China (Series D), 44(10):2221-2237 (in Chinese with English abstract). http://www.cnki.com.cn/Article/CJFDTOTAL-JDXG201412013.htm Feng, Z.H., Yin, C.H., Qi, J.S., et al., 2010.Main Factors Controlling Hydrocarbon Accumulation in Large Volcanic Gas Fields:A Case Study of the Qingshen Gas Field in the Songliao Basin.Acta Petrologica Sinica, 26(1):21-32 (in Chinese with English abstract). Feng, Z.Q., 2008.Volcanic Rocks as Prolific Gas Reservoir:A Case Study from the Qingshen Gas Field in the Songliao Basin, NE China.Marine and Petroleum Geology, 25(4-5):416-432.doi: 10.1016/j.marpetgeo.2008.01.008 Fu, G., Shi, W., 2006.Study on Deep Gas Reservoir Forming Mechanism of Xujiaweizi Area and Prediction of Favorable Exploration Areas.Petroleum Geology & Oilfield Development in Daqing, 25(3):23-26 (in Chinese with English abstract). Fu, G., Wang, Y.G., 2008.Time and Space Matching Relation among Accumulation Essential Factors of Gas Reservoirs in Volcanic Rock and Its Control Ling to Gas Accumulation:A Case Study of Deep Strata of Xujiaweizi Region.Earth Science, 33(3):342-348 (in Chinese with English abstract). Fu, G., Wu, W., Li, N., 2014.Control Effect of Three Large Faults on the Gas Pools in the Xujiaweizi Fault Depression, Songliao Basin.Natural Gas Industry, 34(7):7-12 (in Chinese with English abstract). https://www.researchgate.net/publication/289616128_Control_effect_of_three_large_faults_on_the_gas_pools_in_the_Xujiaweizi_faulted_depression_Songliao_Basin Fu, X.F., Sha, W., Yu, D., et al., 2010.Lateral Sealing of Faults and Gas Reservoir Formation in Volcanic Rocks in Xujiaweizi Fault Depression.Geological Review, 56(1):60-70 (in Chinese with English abstract). Gao, N., Wang, G.Q., He, S.J., et al., 2011.A Method of Forecasting Distribution Regions of Gas Reservoirs with Different Reserve Abundance by Cap Rocks:An Example of Xujiaweizi Depression in Songliao Basin.Journal of Daqing Petroleum Institute, 35(3):1-6 (in Chinese with English abstract). Guo, Q.L., Xie, H.B., Mi, S.Y., et al., 2009.Fractal Model for Petroleum Resource Distribution and Its Application.Acta Petrolei Sinica, 30(3):379-385 (in Chinese with English abstract). https://www.researchgate.net/publication/286862433_Fractal_model_for_petroleum_resource_distribution_and_its_application Hu, M., Fu, G., Lü, Y.F., et al., 2010.The Fault Activity Period and Its Relalionship to Deep Gas Accumulation in the Xujiaweizi Depression, Songliao Basin.Geological Review, 56(5):710-718 (in Chinese with English abstract). Jones, S.F., Wielens, H., Williamson, M., et al., 2007.Impact of Magmatism on Petroleum Systems in the Sverdrup Basin, Canadian Arctic Islands, Nunavut:A Numerical Modelling Study.Journal of Petroleum Geology, 30(3):237-256.doi: 10.1111/j.1747-5457.2007.00237.x Kuhn, P.P., di Primio, R., Hill, R., et al., 2012.Three-Dimensional Modeling Study of the Low-Permeability Petroleum System of the Bakken Formation.AAPG Bulletin, 96(10):1867-1897.doi: 10.1306/03261211063 Li, J.K., Liu, W., Song, L.B., 2006.A Study of Hydrocarbon Generation Conditions of Deep Source Rocks in Xujiaweizi Fault Depression of the Songliao Basin.Natural Gas Industry, 26(6):21-24 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-TRQG200606006.htm Liu, J.Q., Meng, F.C., Cui, Y., et al., 2010.Discussion on the Formation Mechanism of Volcanic Oil and Gas Reservoirs.Acta Petrologica Sinica, 26(1):1-13 (in Chinese with English abstract). https://www.researchgate.net/publication/286291433_Discussion_on_the_formation_mechanism_of_volcanic_oil_and_gas_reservoirs Liu, W.Z., Wang, P.J., Men, G.T., 2003.Characteristics of Deep Volcanic Reservoirs in Northern Songliao Basin.Oil & Gas Geology, 24(1):28-31 (in Chinese with English abstract). http://d.wanfangdata.com.cn/Periodical_syytrqdz200301006.aspx Luo, J.L., Shao, H.M., Zhang, C.L., 2003.Summary of Research Methods and Exploration Technologies for Volcanic Reservoirs.Acta Petrolei Sinica, 24(1):31-38 (in Chinese with English abstract). Ni, Y.Y., Dai, J.X., Zhou, Q.H., et al., 2009.Geochemical Characteristics of Abiogenic Gas and Its Percentage in Xujiaweizi Fault Depression, Songliao Basin, NE China.Petroleum Exploration and Development, 36(1):35-45 (in Chinese with English abstract). doi: 10.1016/S1876-3804(09)60109-9 Shan, X.L., Li, J.Y., Chen, S.M., et al., 2014.Subaquatic Volcanic Eruptions in Continental Facies and Their Influence on High Quality Source Rocks Shown by the Volcanic Rocks of a Faulted Depression in Northeast China.Science in China (Series D), 56:1926-1933 (in Chinese). http://en.cnki.com.cn/Article_en/CJFDTotal-JDXG201311010.htm Shi, G.R., 2000.Numerical Simulation Method of Oil and Gas Basin.Petroleum Industry Press, Beijing (in Chinese). Sweeney, J.J., Burnham, A.K., 1990.Evaluation of a Simple Model of Vitrinite Reflectance Based on Chemical Kinetics.AAPG Bulletin, 74(10):1559-1570. http://aapgbull.geoscienceworld.org/content/74/10/1559 Tang, W.X., Cao, Q., 2014.Modeling of Hydrocarbon Secondary Migration in the Chaluhe Sag, Yitong Basin.Earth Science, 39(6):741-750 (in Chinese with English abstract). https://www.researchgate.net/publication/286555772_Modeling_of_hydrocarbon_secondary_migration_in_the_Chaluhe_sag_Yitong_Basin Wang, G.W., Hui, S., Fu, G., 2008.Gas Distribution Rules and Main Controlling Factors in Xujiaweizi Rift.Petroleum Geology & Oilfield Development in Daqing, 27(1):6-9 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DQSK200801003.htm Wang, M., Lu, S.F., Xue, H.T., et al., 2010.The Effects of Magmatic Intrusions on the Maturation of Organic Matter and Its Numerical Simulation.Acta Petrologica Sinica, 26(1):177-184 (in Chinese with English abstract). https://www.researchgate.net/publication/279669806_The_effects_of_magmatic_intrusions_on_the_maturation_of_organic_matter_and_its_numerical_simualtion Wang, M., Lu, S., Chen, S., et al., 2015.Thermal Effect of Intrusive Rock on Hydrocarbon Generation from Organic Matter.Arabian Journal of Geosciences, 8(1):39-56 (in Chinese with English abstract). doi: 10.1007/s12517-013-1186-9 Wang, M., Sun, Y.F., Wang, W.G., et al., 2014.Gas Generation Characteristics and Resource Potential of the Deep Source Rock in Xuejiaweizi Fault Depression, Northern Songliao Basin.Natural Gas Geoscience, 25(7):1011-1018 (in Chinese with English abstract). https://www.researchgate.net/publication/286884585_Gas_generation_characteristics_and_resource_potential_of_the_deep_source_rock_in_Xujiaweizi_fault_depression_Northern_Songliao_Basin Wang, P.J., Chi, Y.L., Liu, W.Z., et al., 2003.Volcanic Facies of the Songliao Basin:Classification, Characteristics and Reservoir Significance.Journal of Jilin University (Earth Science Edition), 33(4):449-456 (in Chinese with English abstract). Wang, P., Chen, S., 2015.Cretaceous Volcanic Reservoirs and Their Exploration in the Songliao Basin, Northeast China.AAPG Bulletin, 99(3):499-523.doi: 10.1306/09041413095 Wang, S.J., Hu, S.B., Wang, J.S., 1999.The Geothermal Effect of Radioactive Heat Generation and Its Significance to Hydrocarbon Maturation in Tarim Basin.Petroleum Exploration and Development, 26(5):36-38 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-SKYK199905012.htm Yang, H., Zhang, Y., Zou, C.N., et al., 2006.Exploration Scheme of Gas in Deep-Seated Volcanic Rocks in Songliao Basin.Petroleum Exploration and Development, 33(3):274-281 (in Chinese with English abstract). Zhao, W.Z., Zou, C.N., Li, J.Z., et al., 2009.Comparative Study on Volcanic Hydrocarbon Accumulations in Western and Eastern China and Its Significance.Petroleum Exploration and Development, 36(1):1-11 (in Chinese with English abstract). doi: 10.1016/S1876-3804(09)60106-3 Zhu, H.T., Liu, Y.M., Wang, Y.L., et al., 2014.Volcanic Eruption Phases and 3-D Characterization of Volcanic Rocks in BZ-34-9 Block of Huanghekou Sag, Bohai Bay Basin.Earth Science, 39(9):1309-1316 (in Chinese with English abstract). https://www.researchgate.net/publication/287306438_Volcanic_eruption_phases_and_3-D_characterization_of_volcanic_rocks_in_BZ34-9_block_of_Huanghekou_Sag_Bohai_Bay_Basin Zou, C.N., Zhao, W.Z., Jia, C.Z., et al., 2008.Formation and Distribution of Volcanic Hydrocarbon Reservoirs in Sedimentary Basins of China.Petroleum Exploration and Development, 35(3):257-271 (in Chinese with English abstract). doi: 10.1016/S1876-3804(08)60071-3 冯子辉, 任广, 王成, 等, 2003.松辽盆地深层火山岩储层包裹体及天然气成藏期研究.天然气地球科学, 14(6):436-442. http://www.cnki.com.cn/Article/CJFDTOTAL-TDKX200306002.htm 冯子辉, 印长海, 刘家军, 等, 2014.中国东部原位火山岩油气藏的形成机制——以松辽盆地徐深气田为例.中国科学 (D辑), 44(10):2221-2237. http://www.cnki.com.cn/Article/CJFDTOTAL-JDXK201410011.htm 冯子辉, 印长海, 齐景顺, 等, 2010.大型火山岩气田成藏控制因素研究——以松辽盆地庆深气田为例.岩石学报, 26(1):21-32. http://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201001005.htm 付广, 石巍.2006.徐家围子地区深层天然气成藏机制及有利勘探区预测.大庆石油地质与开发, 25(3):23-26. http://www.cnki.com.cn/Article/CJFDTOTAL-DQSK200603007.htm 付广, 王有功.2008.火山岩天然气成藏要素时空匹配及对成藏的控制作用:以徐家围子地区深层为例.地球科学, 33(3):342-348. http://www.earth-science.net/WebPage/Article.aspx?id=1701 付广, 吴薇, 历娜.2014.松辽盆地徐家围子断陷大型断裂带对天然气成藏的控制作用.天然气工业, 34(7):7-12. http://www.cnki.com.cn/Article/CJFDTOTAL-TRQG201407004.htm 付晓飞, 沙威, 于丹, 等, 2010.松辽盆地徐家围子断陷火山岩内断层侧向封闭性及与天然气成藏.地质论评, 56(1):60-70. http://www.cnki.com.cn/Article/CJFDTOTAL-DZLP201001011.htm 高宁, 王国庆, 何淑娟, 等, 2011.一种利用盖层预测不同储量丰度气藏分布区的方法——以松辽盆地徐家围子断陷为例.大庆石油学院学报, 35(3):1-6. http://www.cnki.com.cn/Article/CJFDTOTAL-DQSY201103000.htm 郭秋麟, 谢红兵, 米石云, 等, 2009.油气资源分布的分形特征及应用.石油学报, 30(3):379-385. http://www.cnki.com.cn/Article/CJFDTOTAL-SYXB200903012.htm 胡明, 付广, 吕延防, 等, 2010.松辽盆地徐家围子断陷断裂活动时期及其与深层气成藏关系分析.地质论评, 56(5):710-718. http://www.cnki.com.cn/Article/CJFDTOTAL-DZLP201005015.htm 李景坤, 刘伟, 宋兰斌, 2006.徐家围子断陷深层烃源岩生烃条件研究.天然气工业, 26(6):21-24. http://www.cnki.com.cn/Article/CJFDTOTAL-TRQG200606006.htm 刘嘉麒, 孟凡超, 崔岩, 等, 2010.试论火山岩油气藏成藏机理.岩石学报, 26(1):1-13. http://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201001003.htm 刘万洙, 王璞珺, 门广田, 等, 2003.松辽盆地北部深层火山岩储层特征.石油与天然气地质, 24(1):28-31. http://www.cnki.com.cn/Article/CJFDTOTAL-SYYT200301005.htm 罗静兰, 邵红梅, 张成立, 2003.火山岩油气藏研究方法与勘探技术综述.石油学报, 24(1):31-38. http://www.cnki.com.cn/Article/CJFDTOTAL-SYXB200301006.htm 倪云燕, 戴金星, 周庆华, 等, 2009.徐家围子断陷无机成因气证据及其份额估算.石油勘探与开发, 36(1):35-45. http://www.cnki.com.cn/Article/CJFDTOTAL-SKYK200901006.htm 石广仁, 2000.油气盆地数值模拟方法.北京:石油工业出版社. 单玄龙, 李吉焱, 陈树民, 等, 2014.陆相水下火山喷发作用及其对优质烃源岩形成的影响:以松辽盆地徐家围子断陷营城组为例.中国科学 (D辑), 44(12):2637-2644. http://www.cnki.com.cn/Article/CJFDTOTAL-JDXK201412003.htm 唐文旭, 曹强, 2014.伊通盆地岔路河断陷油气二次运移模拟.地球科学, 39(6):741-750. http://www.earth-science.net/WebPage/Article.aspx?id=2880 王贵文, 惠山, 付广, 2008.徐家围子断陷天然气分布规律及其主控因素.大庆石油地质与开发, 27(1):6-9. http://www.cnki.com.cn/Article/CJFDTOTAL-DQSK200801003.htm 王民, 卢双舫, 薛海涛, 等, 2010.岩浆侵入体对有机质生烃 (成熟) 作用的影响及数值模拟.岩石学报, 26(1):177-184. http://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201001022.htm 王民, 孙业峰, 王文广, 等, 2014.松辽盆地北部徐家围子断陷深层烃源岩生气特征及天然气资源潜力.天然气地球科学, 25(7):1011-1018. http://www.cnki.com.cn/Article/CJFDTOTAL-TDKX201407008.htm 王璞珺, 迟元林, 刘万洙, 等, 2003.松辽盆地火山岩相:类型、特征和储层意义.吉林大学学报 (地球科学版), 33(4):449-456. http://www.cnki.com.cn/Article/CJFDTOTAL-CCDZ200304011.htm 王社教, 胡圣标, 汪集晠, 1999.塔里木盆地沉积层放射性生热的热效应及其意义.石油勘探与开发, 26(5):36-38. http://www.cnki.com.cn/Article/CJFDTOTAL-SKYK199905012.htm 杨辉, 张研, 邹才能, 等, 2006.松辽盆地深层火山岩天然气勘探方向.石油勘探与开发, 33(3):274-281. http://www.cnki.com.cn/Article/CJFDTOTAL-SKYK200603003.htm 赵文智, 邹才能, 李建忠, 等, 2009.中国陆上东、西部地区火山岩成藏比较研究与意义.石油勘探与开发, 36(1):1-11. http://www.cnki.com.cn/Article/CJFDTOTAL-SKYK200901003.htm 朱红涛, 刘依梦, 王永利, 等, 2014.渤海湾盆地黄河口凹陷BZ34-9区带火山岩三维刻画及火山喷发期次.地球科学, 39(9):1309-1316. http://www.earth-science.net/WebPage/Article.aspx?id=2944 邹才能, 赵文智, 贾承造, 等, 2008.中国沉积盆地火山岩油气藏形成与分布.石油勘探与开发, 35(3):257-271. http://www.cnki.com.cn/Article/CJFDTOTAL-SKYK200803002.htm -
