    致密砂岩气层中成岩相对岩电特征的影响

    刘洪平 骆杨 赵彦超 陈召佑 穆国栋

    刘洪平, 骆杨, 赵彦超, 陈召佑, 穆国栋, 2017. 致密砂岩气层中成岩相对岩电特征的影响. 地球科学, 42(4): 652-660. doi: 10.3799/dqkx.2017.053
    引用本文: 刘洪平, 骆杨, 赵彦超, 陈召佑, 穆国栋, 2017. 致密砂岩气层中成岩相对岩电特征的影响. 地球科学, 42(4): 652-660. doi: 10.3799/dqkx.2017.053
    Liu Hongping, Luo Yang, Zhao Yanchao, Chen Zhaoyou, Mu Guodong, 2017. Effects of Diagenetic Facies on Rock Electrical Properties in Tight Gas Sandstones. Earth Science, 42(4): 652-660. doi: 10.3799/dqkx.2017.053
    Citation: Liu Hongping, Luo Yang, Zhao Yanchao, Chen Zhaoyou, Mu Guodong, 2017. Effects of Diagenetic Facies on Rock Electrical Properties in Tight Gas Sandstones. Earth Science, 42(4): 652-660. doi: 10.3799/dqkx.2017.053

    致密砂岩气层中成岩相对岩电特征的影响

    doi: 10.3799/dqkx.2017.053
    基金项目:

    国家自然科学基金青年基金 41402117

    构造与油气资源教育部重点实验室开放基金 TPR-2015-11

    详细信息
      作者简介:

      刘洪平 (1988-),男,博士研究生,主要从事油气藏精细描述、非常规油气储层测井评价.ORCID:0000-0002-0721-7144.E-mail: liuhongping12@126.com

      通讯作者:

      赵彦超,ORCID:0000-0003-3459-8656.E-mail: ychzhao2008@163.com

    • 中图分类号: P631

    Effects of Diagenetic Facies on Rock Electrical Properties in Tight Gas Sandstones

    • 摘要: 致密砂岩气层的研究是目前的研究前沿之一.利用铸体薄片、物性、高压压汞、micro-CT、岩电实验等分析化验资料,探讨了鄂尔多斯盆地定北地区二叠系太原组致密砂岩不同成岩相类型对岩电特征的控制作用.研究表明:研究区可以划分为4种成岩相类型,包括硅质胶结成岩相、高岭石部分充填成岩相、不稳定组分溶蚀成岩相,压实致密成岩相.4种成岩相类型地层因素和孔隙度在同一趋势线上,可以采用统一的am值.4种成岩相类型的n值有明显差异,取值依次为2.30、1.51、2.03和4.04.含气饱和度解释实例显示,对不同成岩相取不同n值与试气结果吻合较好,优于n值取理论值2的结果.



    • 图  1  不同成岩相微观照片

      a.硅质胶结成岩相;b.高岭石部分充填成岩相;c.不稳定组分溶蚀成岩相;d.压实致密成岩相

      Fig.  1.  Photomicrographs of various diagenetic facies

      图  2  不同成岩相类型泥质含量与粒度中值关系

      Fig.  2.  Clay content versus median grain diameter of different diagenetic facies

      图  3  不同成岩相类型孔隙度与渗透率关系

      Fig.  3.  Air permeability versus porosity of different diagenetic facies

      图  4  不同成岩相类型与各种参数的关系

      a.不同成岩相类型地层因素和孔隙度的关系;b.不同成岩相类型胶结指数与孔隙度的关系;c.不同成岩相类型胶结指数与平均孔喉半径的关系;d.不同成岩相类型胶结指数与退汞效率的关系

      Fig.  4.  The relationship between porosity of different diagenetic facies

      图  5  不同成岩相类型电阻率增大系数与含水饱和度的关系

      Fig.  5.  Resistivity index versus water saturation of different diagenetic facies

      图  6  不同成岩相类型与各种参数的关系

      a.不同成岩相类型饱和度指数和孔隙度的关系;b.不同成岩相类型饱和度指数和渗透率的关系;c.不同成岩相类型饱和度指数与平均孔喉半径的关系;d.不同成岩相类型饱和度指数和泥质含量的关系

      Fig.  6.  The relationship between porosity of different diagenetic facies

      图  7  不同成岩相类型micro-CT扫描图

      分辨精度分别为1.5、0.9和0.9 μm;a.硅质胶结成岩相;b.高岭石部分充填成岩相;c.不稳定组分溶蚀成岩相

      Fig.  7.  Micro-CT image of different diagenetic facies

      图  8  DB13井测井综合解释

      Fig.  8.  Well logging interpretation graph of well DB13

      图  9  DB17井测井综合解释

      Fig.  9.  Well logging interpretation graph of well DB17

      图  10  DB27井测井综合解释

      Fig.  10.  Well logging interpretation graph of well DB27

    • Bian, H.Y., Wang, F., Yue, C.W., et al., 2014.Fluid Property of Sandstone Reservoir Identified with Elastic Parameters.Journal of Earth Sciences and Environment, 36(4):99-106 (in Chinese with English abstract).
      Cluff, R.M., Byrnes, A.P., 2008.Evidence for a Variable Archie Porosity Exponent 'm' and Impact on Saturation Calculations for Mesaverde Tight Gas Sandstones:Piceance, Uinta, Green River, Wind River, and Powder River Basins.Proceeding of the AAPG Rocky Mountain Section Meeting, Denver. http://www.kgs.ku.edu/mesaverde/04_Web_Structure/Reports_and_Presentations/5_Denver_RMS-AAPG_July-08/2008_RMS-AAPG_Cluff_Byrnes-Evidence_for_a_variable_Archie_porosity_exponent.pdf
      Herrick, D.C., Kennedy, W.D., 1994.Electrical Efficiency—A Pore Geometric Theory for Interpreting the Electrical Properties of Reservoir Rocks.Geophysics, 59(6):918-927.doi: 10.1190/1.1443651
      Herrick, D.C., Kennedy, W.D., 2009.A New Look at Electrical Conduction in Porous Media:A Physical Description of Rock Conductivity:SPWLA 50th Annual Logging Symposium, Woodlands. https://www.onepetro.org/mslib/app/Preview.do?paperNumber=SPWLA-2009-10142
      Li, J., Zhang, C.M., Xiao, C.W., 2009.Influence of Sandstone Pore Texture on Cementation Exponent and Saturation Error Analysis in Kuche Area, Tarim Basin.Well Logging Technology, 33(4):325-328 (in Chinese with English abstract).
      Li, P.J., Zhang, Z.P., Jiang, D.P., 2011.Review on Fluid Identification Methods with NMR Logging.Well Logging Technology, 35(5):396-401 (in Chinese with English abstract).
      Ozkan, A., Cumella, S.P., Milliken, K.L., et al., 2011.Prediction of Lithofacies and Reservoir Quality Using Well Logs, Late Cretaceous Williams Fork Formation, Mamm Creek Field, Piceance Basin, Colorado.AAPG Bulletin, 95(10):1699-1723.doi: 10.1306/01191109143
      Sakhaee-Pour, A., Bryant, S.L., 2014.Effect of Pore Structure on the Producibility of Tight-Gas Sandstones.AAPG Bulletin, 98(4):663-694.doi: 10.1306/08011312078
      Shi, T.T., Sun, W., He S.P., et al., 2012.Diagenetic Facies and Its Micro-Pore Structure of Yanchang Formation Chang 6 Reservoir in Huaqing Area.Journal of Lanzhou University (Natural Sciences), 48(3):7-12 (in Chinese with English abstract).
      Shi, Y.J., Xiao, L., Mao, Z.Q., et al., 2011.An Identification Method for Diagenetic Facies with Well Logs and Its Geological Significance in Low-Permeability Sandstones:A Case Study on Chang 8 Reservoirs in the Jiyuan Region, Ordos Basin.Acta Petrolei Sinica, 32(5):820-828 (in Chinese with English abstract). https://www.researchgate.net/publication/287728260_An_identification_method_for_diagenetic_facies_with_well_logs_and_its_geological_significance_in_low-permeability_sandstones_A_case_study_on_Chang_8_reservoirs_in_the_Jiyuan_region_Ordos_Basin
      Suman, R.J., Knight, R.J., 1997.Effects of Pore Structure and Wettability on the Electrical Resistivity of Partially Saturated Rocks—A Network Study.Geophysics, 62(4):1151-1162.doi: 10.1190/1.1444216
      Torskaya, T.S., 2013.Pore-Scale Analysis of Grain Shape and Sorting Effects on Fluid Transport Phenomena in Porous Media (Dissertation).The University of Texas at Austin, Austin:59-63.
      Verwer.K., Eberli, G.P., Weger, R.J., 2011.Effect of Pore Structure on Electrical Resistivity in Carbonates.AAPG Bulletin, 95(2):175-190.doi: 10.1306/06301010047
      Wang, K.W., Sun, J.M., Guan, J.T., et al., 2005.Percolation Network Modeling of Electrical Properties of Reservoir Rock.Applied Geophysics, 2(4):223-229.doi: 10.1007/s11770-005-0028-2
      Xiao, L., Zou, C.C., Mao, Z.Q., 2013.Estimation of Water Saturation from Nuclear Magnetic Resonance (NMR) and Conventional Logs in Low Permeability Sandstone Reservoirs.Journal of Petroleum Science and Engineering, 108:40-51. doi: 10.1016/j.petrol.2013.05.009
      Yu, Z.C., Liu, K.Y., Zhao, M.J., et al., 2016.Characterization of Diagenesis and the Petroleum Charge in Kela 2 Gas Filed, Kuqa Depression, Tarim Basin.Earth Science, 41(3):533-545 (in Chinese with English abstract).
      Zeng, W.C., Liu, X.F., 2013.Interpretation of Non-Archie Phenomenon for Carbonate Reservoir.Well Logging Technology, 37(4):341-351 (in Chinese with English abstract).
      Zhang, M.L., Shi, Y.J., 2005.On Archie's Electrical Parameters of Sandstone Reservoir with Complicated Pore Structures.Well Logging Technology, 29(5):59-61 (in Chinese with English abstract).
      Zou, C.N., Tao, S.Z., Zhou, H., et al., 2008.Genesis, Classification and Evaluation Method of Diagenetic Facies.Petroleum Exploration and Development, 35(5):526-540 (in Chinese with English abstract). doi: 10.1016/S1876-3804(09)60086-0
      边会媛, 王飞, 岳崇旺, 等, 2014.利用弹性参数识别致密砂岩储层流体性质.地球科学与环境学报, 36(4): 99-106. http://www.cnki.com.cn/Article/CJFDTOTAL-XAGX201404011.htm
      曾文冲, 刘学锋, 2013.碳酸盐岩非阿尔奇特性的诠释.测井技术, 37(4): 341-351. http://www.cnki.com.cn/Article/CJFDTOTAL-CJJS201304002.htm
      李军, 张超馍, 肖承文, 等, 2009.库车地区砂岩孔隙结构对胶结指数影响及饱和度误差分析.测井技术, 33(4): 325-328. http://www.cnki.com.cn/Article/CJFDTOTAL-CJJS200904005.htm
      李鹏举, 张智鹏, 姜大鹏, 2011.核磁共振测井流体识别方法综述.测井技术, 35(5): 396-401. http://www.cnki.com.cn/Article/CJFDTOTAL-CJJS201105005.htm
      师调调, 孙卫, 何生平, 等, 2012.华庆地区延长组长6储层不同类型成岩相微观孔隙结构特征及生产动态分析.兰州大学学报 (自然科学版), 48(3): 7-12. http://www.cnki.com.cn/Article/CJFDTOTAL-LDZK201203004.htm
      石玉江, 肖亮, 毛志强, 等, 2011.低渗透砂岩储层成岩相测井识别方法及其地质意义——以鄂尔多斯盆地姬塬地区长8段储层为例.石油学报, 32(5): 820-828. doi: 10.7623/syxb201105012
      于志超, 刘可禹, 赵孟军, 等, 2016.库车凹陷克拉2气田储层成岩作用和油气充注特征.地球科学, 41(3): 533-545. http://www.earth-science.net/WebPage/Article.aspx?id=3268
      张明禄, 石玉江, 2005.复杂孔隙结构砂岩储层岩电参数研究.测井技术, 29(5): 59-61. http://www.cnki.com.cn/Article/CJFDTOTAL-CJJS200505015.htm
      邹才能, 陶士振, 周慧, 等, 2008.成岩相的形成、分类与定量评价方法.石油勘探与开发, 35(5): 526-540. http://www.cnki.com.cn/Article/CJFDTOTAL-SKYK200805004.htm
