Source-to-Sink System of the Steep Slope Fault in the Western Shaleitian Uplift
-
摘要: 沙垒田凸起西部发育完整的受断裂陡坡带控制的源-汇系统.基于最新的钻井、薄片资料及高分辨率三维地震资料,精细刻画沙垒田凸起西部源-汇三要素(即物源体系、搬运体系及沉积体系),探讨要素间相关性并建立耦合模式.通过岩石学分析,物源区以混合花岗岩为主,结合古地貌恢复,划分4个三级汇水单元并定量拾取垂向高差与汇水面积参数,明确古沟谷与断槽物源通道的分布及尺度,应用地震沉积学精细刻画沙三段内部3个亚段扇三角洲沉积时空展布及演化.定量探讨源-汇各要素间的相关性,明确汇水单元面积与垂向高差是沉积扇体发育规模的主控因素,构建断裂陡坡带控制下的混合花岗岩-古沟谷或断槽与断面组合的物源通道-近源粗粒扇三角洲-浊积扇-湖泊体系耦合模式.Abstract: During the early stage of Palaeogene, western Shaleitian uplift and surrounding areas constituted a complete Source-to-Sink system under the control of steep slope fault. We analyzed the characteristics of Source-to-Sink elements (provenance system, sediment-routing system, and sedimentary system), discussed the relativities among the three elements and established the coupling model of steep slope fault based on detritus, thin section and the geophysical response datain this study. Results show that the provenance of western Shaleitian uplifts was filled by Proterozoic metamorphic rocks. Based on the Paleogene palaeo-geomorphology, we divided the provenance into four third-order catchment units, obtained the quantitative parameters of height difference and catchment area, and confirmed the distribution and scales of incised valleys and faulted-troughsediment-transport pathways. The facies architecture and sediment-dispersal characters of fan-deltas system in the third member of Eocene Shahejie Formation have been analyzed by the stratal slice images. Quantitative analysis of the parameters in the source-to-sink system show that the total sediment volume yielded by the eroded and weathered hinterland into the basin is closely related to the catchment area and the height difference of the hinterland. Then, the coupling model of source (migmatitic granite)-channel (incised valleys or fault-trough sediment-transport pathways)-sink (near-source coarse grain size fan delta-gravity flow-lake system) controlled by fault steep slopehas been established.
-
图 5 沙垒田凸起区沙三段(Es3)物源通道剖面指示及参数统计
地震剖面位置见图 4
Fig. 5. The section indicator of sediment transport pathways and parametric statistics of the third member of Eocene Shahejie Formation (Es3) in the western Shaleitian uplift
图 6 沙垒田凸起西部典型地震相特征(a, b, c, d)及GR曲线-波阻抗关系(e)
地震剖面位置见图 4b;红色数值表示切片位置
Fig. 6. Seismic facies characteristics of the fan deltas (a, b, c, d) and a cross-plot of GR and wave impedance extracted from wireline-logs (e) in the western Shaleitian uplift
表 1 沙垒田凸起西部沙三段断裂陡坡带源-汇系统主要要素单元
Table 1. Quantitative main parameter of the Source-to-Sink systems of steep slope fault in the third member of Eocene Shahejie Formation, western Shaleitian uplift
物源区 基岩组成 混合花岗岩或花岗岩 碳酸盐岩 汇水单元 b1 b2 b3 b4 c 汇水面积(km2) 56 47 28 36 104 垂向高差(km) 1.726 1.470 1.150 0.850 0.720 水系长度(km) 14.7 13.6 10.4 8.7 12.5 搬运区 通道类型 古沟谷 断槽 通道编号 V6 V5 V4 V3 V2 宽深比 23.81 25.96 19.72 22.96 21.80 截面积(km2) 0.009 0.041 0.044 0.108 0.052 沉积区 沉积单元 A B C D 断裂倾角(°) 22.9 28.2 30.9 26.1 平均沉降速率(m/Ma) 485 300 220 220 260 最大扇体面积(km2) 30.5 17.8 10.1 11.0 16.0 平均厚度(km) 0.65 0.40 0.30 0.30 0.35 最大扇体体积(km3) 24.40 7.12 3.03 3.30 5.60 -
