Paleao-Drainage System and Integrated Paleo-Geomorphology Restoration in Depositional and Erosional Areas:Guantao Formation in East Liaodong Area, Bohai Bay Basin, China
-
摘要: 古地貌是控制古水系、沉积体系的关键因素之一.以渤海湾盆地渤中坳陷东部的辽东东地区中新世馆陶组为例，对馆陶组的沉积区和剥蚀区分别开展了基于残余地层厚度法和印模法的古地貌恢复，以增进对研究区古水系、源－汇系统的整体认识，为其物源体系、沉积环境、砂体分布的预测提供科学依据.两种方法的古地貌及古水系恢复结果对比研究表明，基于残余地层厚度法的沉积区古地貌恢复结果适用于目的层沉积区古水系的恢复；而基于印模法的沉积区－剥蚀区一体化的古地貌恢复结果实现了剥蚀区、沉积区古水系的统一解释.沉积区－剥蚀区一体化的古地貌恢复弥补了基于沉积区古地貌的古水系恢复中难以判断"源－汇体系"中源区古水系分布及从源到汇古水系派生关系的局限性.Abstract: Paleo-geomorphology is one of key controls on paleo-drainage and depositional systemson. In order to better understand the paleo-drainage system and Source-to-Sink system to provide scientific evidences for predictions of provenance system, deposition system and sand stone distribution, the paleo-geomorphology of the Guantao Formation in East Liaodong area, East Bozhong depression of Bohai bay basin are reconstructed using two methods in this paper. Comparison of paleo-morphological reconstruction and paleo-drainage interpretation with different methods shows that paleo-morphology restoration of deposition area using residual thickness may be used in understanding of paleo-drainage outlines for deposition area only. However, paleo-geomorphology restoration for depositional area and erosional areas provides a comprehensive paleo-drainage interpretation for depositional and erosional areas taken as a whole. The integrated paleo-morphology restoration can facilitate the prediction of paleo-drainage distribution in source area of "Source-to-Sink system", and establishment of relationship of paleo-drainage systems from source area to sink area.
-
图 2 辽东东地区地层综合柱状图及层序地层划分方案
Fig. 2. Comprehensive stratigraphic column and sequence division of the east of Liaodong area
图 3 研究区及外围地区古近系与新近系地层解释剖面
a.CR08测线地层解释结果；b.L03A测线地层解释结果.剖面位置详见图 1
Fig. 3. Paleogene and Neogene stratigraphic profiles in study area and surrounding regions
图 4 研究区新生代地层发育样式及平面分区
Fig. 4. Stratigraphic development pattern and planar division of Paleogene and Neogene in study area
图 5 馆下段沉积区残余地层厚度等值线图(a)及古地貌恢复结果(b)
图a中地层厚度数据来自图 4中H1
Fig. 5. Contour map of thickness of the upper member of Guantao Formation in deposition area (a) and corresponding paloe-geomorphological map (b)
图 6 馆上段沉积区基于残余地层的古地貌与古水系恢复结果
地层厚度数据来自图 4中H2
Fig. 6. Paleo-geomorphology and paleo-drainage system reconstructed by residued thickness of the upper member of Guantao Formation in deposition area
图 7 基于印模法的馆下段沉积区－剥蚀区上覆地层厚度等值线图(a)及基于印模法的馆下段沉积区－剥蚀区一体化三级古地貌恢复结果(山地剥蚀区、山前剥蚀区和洼地沉积区)及古水系解释(b)
地层厚度数据来自图 4中H3
Fig. 7. Contour map of thickness of overlying stratigraphy of deposition and erosion areas using impression method (a) and three-grade geomorphologic and paleo-drainage-system integrated restoration for deposition and erosion areas of the lower member of Guantao Formation using impression method (b)
图 8 基于印模法的馆上段沉积区－剥蚀区上覆地层厚度等值线图(a)及古地貌恢复与古水系解释(b)
地层厚度数据来自图 4中H4
Fig. 8. Contour map of thickness of overlying stratigraphy using impression method (a) and responding paleo-geomorphology and paleo-drainage interpretation (b)
-
Bhattacharya, J.P., Copeland, P., Lawton, T.F., et al., 2016.Estimation of Source Area, River Paleo-Discharge, Paleoslope, and Sediment Budgets of Linked Deep-Time Depositional Systems and Implications for Hydrocarbon Potential.Earth-Science Reviews, 153:77-110.doi: 10.1016/j.earscirev.2015.10.013 Cai, J., 2009.Paleo-Morphologic Restoration of Paleogene in Qiongdongnan Basin and Its Control on Sequence Architecture and Sedimentary Characteristics(Disstertation).China University of Geoscience, Beijing (in Chinese with English abstract). Cassel, E.J., Grove, M., Graham, S.A., 2012.Eocene Drainage Evolution and Erosion of the Sierra Nevada Batholith across Northern California and Nevada.American Journal of Science, 312(2SI):117-144.doi: 10.2475/02.2012.03 Chen, S.G., Ren, J.Y., Wu, F., et al., 2015.Palaeogeomorphic Recovery and Its Application in Shabei Area, Central Bohai Depression.Special Oil and Gas Reservoir, 22(2):52-55 (in Chinese with English abstract). Davidson, S.K., Hartley, A.J., 2010.Towards a Quantitative Method for Estimating Paleohydrology from Clast Size and Comparison with Modern Rivers.Journal of Sedimentary Research, 80(7-8):688-702.doi: 10.2110/jsr.2010.062 Deng, H.W., Wang, H.L., Wang, D.Z., 2001.Control of Paleo-Morphology to Stratigraphic Sequence in Continental Rift Basins:Take Lower Tertiary of Western Slope in Bozhong Depression as an Example.Oil & Gas Geology, 22(4):293-296 (in Chinese with English abstract). Gao, Y., Jiang, Z.X., Li, J.J., et al., 2015.Restoration of Paleogeomorphology and Its Controlling Effect on Deposition of Beach-Bar Sand Bodies:A Case Study of the Fourth Member of Shahejie Formation, Shubei Area, Liaohe Western Sag.Petroleum Geology and Recovery Efficiency, 22(5):40-46 (in Chinese with English abstract). Guo, S.B., Sun, S.H., 2006.Rebuilding Paleogeomorphology of Pre-Jurassic and Oil-Gas Accumulation Regulation in Zhoujiawan Area.Earth Science, 31(3):372-377 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DQKX200603013.htm Hong, Z., Su, M., Liu, H., et al., 2016.Clastic Compaction Unit Classification Based on Clay Content and Integrated Compaction Recovery Using Well and Seismic Data.Petroleum Science, 13(4):685-697.doi: 10.1007/s12182-016-0129-y House, M.A., Wernicke, B.P., Farley, K.A., 2001.Paleo-Geomorphology of the Sierra Nevada, California, from (U-Th)/He Ages in Apatite.American Journal of Science, 301(2):77-102.doi: 10.2475/ajs.301.2.77 Lai, S.H., Li, X.H., 2007.A New Approach in Studying Depositional System within Rift-Subsidence Basin:From Paleogeomorphology, Lithologic Change and Water Depth to Depositional System.Acta Sedimentologica Sinica, 25(5):663-670 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-CJXB200705001.htm Li, J.Q., 2008.Application of Bedding Flattening in the Process of Rebuilding Paleomorpholog before Basin Deposition:A Case Study in Dongying Sag, Jiyang Depression.Petroleum Geophysics, 6(2):46-49 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-YQDL200802012.htm Li, J.P., Yang, B., Zhou, X.H., et al., 2012.Analysis of Sedimentary Facies of Dongying Formation in the Bozhong Sag.Journal of Northeast Petroleum University, 36(4):1-10 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DQSY201204003.htm Li, R.Q., Sun, X.P., 1985.A Preliminary Research on the Ancient Rever Systems and Its Features of the Plain in Front of the Moutains in Fangshan County of Beijing.Journal of Beijing Normal University(Natural Science), (4):85-92 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-BSDZ198504016.htm Li, Y., Li, B., Steffen, D., et al., 2006.Provenance Analysis and Drainage Evolution in Late Cenozoic Chengdu Basin on Eastern Margin of Tibetan Plateau.Acta Sedimentologica Sinica, 24(3):309-320 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-CJXB200603000.htm Liu, H.Q., Li, X.B., Wan, Y.R., et al., 2011.Palaeogeographic and Sedimentological Characteristics of the Triassic Chang 8, Ordos Basin, China.Acta Sedimentologica Sinica, 29(6):1086-1095 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-CJXB201106009.htm Liu, J.E., Jian, X.L., Kang, B., et al., 2014.Paleogeomorphology of the Middle Part of 3rd Member of Shahejie Formation and Their Effects on Depositional Systems, Dongying Delta, Dongying Depression.Petroleum Geology and Recovery Efficiency, 21(1):20-23 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-YQCS201401005.htm Liu, Q.H., Zhu, X.M., Li, S.L., et al., 2016.Pre-Paleogene Bedrock Distribution and Source-to-Sink System Analysis in the Shehejie Uplift.Earth Science, 41(11):1935-1949 (in Chinese with English abstract). Liu, X.F., Xie, X.N., Zhang, C., 2008.Characteristics and Generation of the Reservoir Overpressure in Bozhong Depression, Bohai Bay Basin.Earth Science, 33(3):337-341 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DQKX200803007.htm Miao, Q.Y., Zhu, X.M., Li, G.B., et al., 2014.Paleogeomorphology Recovery and Reservoir Prediction of Upper Carboniferous in M Block, Pre-Caspian Basin.Earth Science, 39(7):871-879 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DQKX201407009.htm Pang, J.G., Yang, Y.Y., Li, W.H., et al., 2013.Study Development of Palaeogeomorphology Reconstructions in Continental Facies Hydrocarbon Basin.Journal of Xi'an University of Science and Technology, 33(4):424-430 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-XKXB201304008.htm Qian, S.Y., Zeng, J.H., Lin, H.X., et al., 2008.Physical Simulation Experiment and Mechanism Analysis on Oil Migration and Accumulation in East Liaodong Area.Natural Gas Geoscience, 19(5):604-610 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-TDKX200805007.htm Roden, J., Abdelsalam, M.G., Atekwana, E., et al., 2011.Structural Influence on the Evolution of the Pre-Eonile Drainage System of Southern Egypt:Insights from Magnetotelluric and Gravity Data.Journal of African Earth Sciences, 61(5):358-368.doi: 10.1016/j.jafrearsci.2011.08.007 Wang, H., Bai, Y.F., Huang, C.Y., et al., 2009.Reconstruction and Application of the Paleogene Provenance System of the Dongying Formation in Qikou Depression.Earth Science, 34(3):448-456 (in Chinese with English abstract). http://d.wanfangdata.com.cn/Periodical/dqkx200903009 Wang, J.H., Wang, H., Zhao, Z.X., et al., 2003.Sequence Stratigraphy in Paleogeomorphy Analysis:An Example from Tahe Oilfield.Earth Science, 28(4):425-430 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DQKX200304011.htm Wang, M.F., Jiao, Y.Q., Ren, J.Y., et al., 2006.Method and Thinking of Palaeogeomorphologic Reconstruction in Sedimentary Basin-Example from Depositional Stage of Xishanyao Formation in Junggar Basin.Xinjiang Geology, 24(3):326-330 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-XJDI200603024.htm Wang, Z., Jiang, H., Wang, T., et al., 2014.Paleo-Geomorphology Formed during Tongwantectonization in Sichuan Basin and Its Significance for Hydrocarbon Accumulation.Petroleum Exploration and Development, 41(3):338-345 doi: 10.1016/S1876-3804(14)60038-0 Wu, L.Y., Chen, C.Q., Jiang, C.M., et al., 2005.Paleogeomorphic Restoring Techniques in China's Hydrocarbon Exploration.Journal of Oil and Gas Technology, 27(4):25-26 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-JHSX2005S4005.htm Xin, Y.L., Ren, J.Y., Li, J.P., 2013.Control of Tectonic-Paleogeomorphology on Deposition:A Case from the Shahejie Formation Sha 3 Member, Laizhouwan Sag, Southern Bohai Sea.Petroleum Exploration and Development, 40(3):302-308 (in Chinese with English abstract). http://www.sciencedirect.com/science/article/pii/S1876380413600397 Xu, H.Q., 2017.Fault Characteristics and Construction Patterns of the Liaodongdong Area in Bohai Sea.Journal of Shengli College China University of Petroleum, 31(1):7-10 (in Chinese with English abstract). Yang, G.L., 2014.Analysis on Oil/Gas Reservoir-Forming Conditions in Eastern Liaodong Region, Bohai Sea.Special Oil and Gas Reservoir, 21(4):76-79 (in Chinese with English abstract). Zhang, C., Xie, X.N., Guo, X.R., et al., 2013.Pathway System of Large-Scale Petroleum System and Its Controls on Hydrocarbon Accumulation in the Bazhong Sub-Basin, Bohai Bay Basin.Earth Science, 38(4):807-818 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DQKX201304015.htm Zhang, Y.K., Hu, X.Q., Niu, T., et al., 2015.Controlling of Paleogeomorphology to Peleogene Sedimentary System of Shijiutuo Uplift in Bohai Basin.Journal of Jilin University (Earth Science Edition), 45(6):1589-1596 (in Chinese with English abstract). http://linkinghub.elsevier.com/retrieve/pii/S0264817204000534 Zhu, H.T., Yang, X.H., Zhou, X.H., et al., 2013.Sediment Transport Pathway Characteristics of Continental Lacustrine Basins Based on 3-D Seismic Data:An Example From Dongying Formation of Western Slope of Bozhong Sag.Earth Science, 38(1):121-129 (in Chinese with English abstract). http://d.wanfangdata.com.cn/Periodical/dqkx201301012 蔡佳, 2009.琼东南盆地古近系古地貌恢复及其对层序样式和沉积特征的控制(博士学位论文).北京:中国地质大学. 陈树光, 任建业, 吴峰, 等, 2015.渤中坳陷沙北地区古地貌恢复及其应用.特种油气藏, 22(2):52-55. http://d.wanfangdata.com.cn/Periodical/tzyqc201502012 邓宏文, 王红亮, 王敦则, 2001.古地貌对陆相裂谷盆地层序充填特征的控制——以渤中凹陷西斜坡区下第三系为例.石油与天然气地质, 22(4):293-296. doi: 10.11743/ogg20010402 高艺, 姜在兴, 李俊杰, 等, 2015.古地貌恢复及其对滩坝沉积的控制作用——以辽河西部凹陷曙北地区沙四段为例.油气地质与采收率, 22(5):40-46. http://d.wanfangdata.com.cn/Periodical/yqdzycsl201505007 郭少斌, 孙绍寒, 2006.周家湾地区前侏罗纪古地貌恢复及油气富集规律.地球科学, 31(3):372-377. http://earth-science.net/WebPage/Article.aspx?id=1560 赖生华, 李晓宏, 2007.断陷盆地沉积体系研究新思路:从古地貌、岩性变化、水体深度到沉积体系.沉积学报, 25(5):663-670. http://d.wanfangdata.com.cn/Periodical/cjxb200705002 李家强, 2008.层拉平方法在沉积前古地貌恢复中的应用——以济阳坳陷东营三角洲发育区为例.油气地球物理, 6(2):46-49. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=yqdl200802012&dbname=CJFD&dbcode=CJFQ 李建平, 杨波, 周心怀, 等, 2012.渤中凹陷东营组层序地层及其沉积相分析.东北石油大学学报, 36(4):1-10. http://d.wanfangdata.com.cn/Periodical/dqsyxyxb201204001 李容全, 孙秀萍, 1985.北京房山县山前平原古水系及其特征初步研究.北京师范大学学报(自然科学版), (4):85-92. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=bsdz198504016&dbname=CJFD&dbcode=CJFQ 李勇, 黎兵, Steffen, D., 等, 2006.青藏高原东缘晚新生代成都盆地物源分析与水系演化.沉积学报, 24(3):309-320. http://d.wanfangdata.com.cn/Periodical/cjxb200603001 刘化清, 李相博, 完颜容, 等, 2011.鄂尔多斯盆地长8油层组古地理环境与沉积特征.沉积学报, 29(6):1086-1095. http://d.wanfangdata.com.cn/Periodical/cjxb201106009 刘军锷, 简晓玲, 康波, 等, 2014.东营凹陷东营三角洲沙三段中亚段古地貌特征及其对沉积的控制.油气地质与采收率, 21(1):20-23. http://d.wanfangdata.com.cn/Periodical/yqdzycsl201401005 刘强虎, 朱筱敏, 李顺利, 等, 2016.沙垒田凸起前古近系基岩分布及源－汇过程.地球科学, 41(11):1935-1949. http://earth-science.net/WebPage/Article.aspx?id=3391 刘晓峰, 解习农, 张成, 2008.渤海湾盆地渤中坳陷储层超压特征与成因机制.地球科学, 33(3):337-341. http://earth-science.net/WebPage/Article.aspx?id=1700 苗钱友, 朱筱敏, 李国斌, 等, 2014.滨里海盆地M区块晚石炭世古地貌恢复与白云岩储层预测.地球科学, 39(7):871-879. http://earth-science.net/WebPage/Article.aspx?id=2887 庞军刚, 杨友运, 李文厚, 等, 2013.陆相含油气盆地古地貌恢复研究进展.西安科技大学学报, 33(4):424-430. http://d.wanfangdata.com.cn/Periodical/xakyxyxb201304009 钱诗友, 曾溅辉, 林会喜, 等, 2008.辽东东地区石油运移和聚集物理模拟实验及机理分析.天然气地球科学, 19(5):604-610. http://d.wanfangdata.com.cn/Periodical/trqdqkx200805005 王华, 白云风, 黄传炎, 等, 2009.歧口凹陷古近纪东营期古物源体系重建与应用.地球科学, 34(3):448-456. http://earth-science.net/WebPage/Article.aspx?id=1848 王家豪, 王华, 赵忠新, 等, 2003.层序地层学应用于古地貌分析——以塔河油田为例.地球科学, 28(4):425-430. http://earth-science.net/WebPage/Article.aspx?id=1273 王敏芳, 焦养泉, 任建业, 等, 2006.沉积盆地中古地貌恢复的方法与思路——以准噶尔盆地西山窑组沉积期为例.新疆地质, 24(3):326-330. http://d.wanfangdata.com.cn/Periodical/xjdz200603024 吴丽艳, 陈春强, 江春明, 等, 2005.浅谈我国油气勘探中的古地貌恢复技术.石油天然气学报(江汉石油学院学报), 27(4):25-26. http://d.wanfangdata.com.cn/Conference/7068880 辛云路, 任建业, 李建平, 2013.构造-古地貌对沉积的控制作用——以渤海南部莱州湾凹陷沙三段为例.石油勘探与开发, 40(3):302-308. doi: 10.11698/PED.2013.03.06 徐昊清, 2017.渤海海域辽东东地区断裂特征及构造样式.中国石油大学胜利学院学报, 31(1):7-10. http://d.wanfangdata.com.cn/Periodical/slytsfzkxxxb201701003 杨贵丽, 2014.渤海海域辽东东地区油气成藏条件分析.特种油气藏, 21(4):76-79. http://d.wanfangdata.com.cn/Periodical/tzyqc201404018 张成, 解习农, 郭秀蓉, 等, 2013.渤中坳陷大型油气系统输导体系及其对油气成藏控制.地球科学, 38(4):807-818. http://earth-science.net/WebPage/Article.aspx?id=2756 张宇焜, 胡晓庆, 牛涛, 等, 2015.古地貌对渤海石臼坨凸起古近系沉积体系的控制作用.吉林大学学报(地球科学版), 45(6):1589-1596. http://d.wanfangdata.com.cn/Periodical/cckjdxxb201506003 朱红涛, 杨香华, 周心怀, 等, 2013.基于地震资料的陆相湖盆物源通道特征分析:以渤中凹陷西斜坡东营组为例.地球科学, 38(1):121-129. http://earth-science.net/WebPage/Article.aspx?id=2349 -
