Detrital Zircon U-Pb Geochronology and Provenance Tracing of the Fan Deltas along the Southwestern Slope of the Shijiutuo Uplift
-
摘要: 为了示踪渤海湾盆地石臼坨凸起西南陡坡带扇三角洲源汇体系，对其东三段层序（Ed3）的6个砂岩样品进行碎屑锆石U-Pb定年分析.西部扇体（C6-4-4井）富含白垩纪（K）锆石并具有110 Ma峰值，母岩以白垩系义县组火成岩为主；中部（C6-4-3、C6-4-6D井）、东部扇体（C6-4-5D）富含侏罗纪（J）锆石并具有152 Ma或168 Ma峰值，母岩以侏罗系蓝旗组火成岩为主，古生代（Pz）锆石则来自中生界碎屑岩.所有样品都含有太古代（Ar）、元古代（Pt）锆石，母岩为花岗岩基底.研究表明，除古生界碳酸盐岩外，源区的母岩地层均可通过碎屑锆石U-Pb年龄示踪，各扇体物源的差异性是由母岩地层倾向控制的，由于中生界向西北倾斜，白垩系主控西部扇体沉积，侏罗系则是中部、东部扇体的主要物源区.Abstract: To trace sedimentary Source-to-Sink systems of the southwestern Shijiutuo uplift, Bohai bay basin, 6 sandstone cuttings from 3 fan deltas of the third member of Dongying Formation (Ed3), along the southwestern slope of Shijiutuo uplift, were systematically sampled for detrital zircon U-Pb dating analysis in this study. It is found that sediments of the western fan delta (C6-4-4) were characterized with abundant Cretaceous zircons and a notable peak at 110 Ma, controlled by volcanic rocks of Cretaceous Yixian Formation. The sediments of the middle fan delta (C6-4-3, C6-4-6D) and the eastern fan delta (C6-4-5D) were characterized by high percentage of Jurassic zircons and a 152 Ma or 168 Ma peak, dominated by volcanic rocks of Jurassic Lanqi Formation, while their Paleozoic zircons derived from the Mesozoic sedimentary rocks. Moreover, all the samples received Archean-Proterozoic zircons from the exposed basement. This study shows that all the source strata can be traced by detrital zircon U-Pb dating except for the Paleozoic carbonate. The diversity of the provenances of the fan deltas was controlled by the inclination of the source strata:as the Mesozoic strata inclined to northwest, the Cretaceous strata dominated the western fan delta while the Jurassic strata controlled the middle and eastern fan deltas.
-
图 1 石臼坨凸起西部残余地层地质图及井位、地震剖面位置
岩性修改自庞小军等(2016)；沟谷修改自王启明等(2016)
Fig. 1. The geology map of the remaining strata on the western Shijiutuo uplift and the location of the wells and the seismic profiles
图 2 各井位东三段岩性及取样位置示意
红色星号为取样位置
Fig. 2. The Ed3 lithology of the wells and their sample depth
图 3 曹妃甸6-4构造东三段砂岩碎屑锆石Th/U比值
Fig. 3. The Th/U ratio of the detrital zircons of the Ed3 sandstone, CFD6-4
图 4 曹妃甸6-4构造东三段砂岩碎屑锆石U-Pb年龄含量分布
Fig. 4. The U-Pb age composition distribution of the detrital zircons of the Ed3 sandstone, CFD6-4
图 5 曹妃甸6-4构造东三段砂岩碎屑锆石U-Pb年龄谱图
n为年龄点个数
Fig. 5. The U-Pb age spectra of the detrital zircons of the Ed3 sandstone, CFD6-4
图 6 曹妃甸6-4构造过井地震剖面与残余侏罗系
剖面位置及图例见图 1
Fig. 6. The cross-well seismic profiles, CFD6-4 and the recovered Jurassic
表 1 曹妃甸6-4构造东三段砂岩碎屑锆石U-Pb年龄含量统计(%)
Table 1. The U-Pb age composition of the detrital zircons of the Ed3 sandstone, CFD6-4
井名 年龄(Ma) ＜140 ＜208 ＜250 ＜290 ＜362 ＜409 ＜439 ＜510 ＜570 ＜1 000 ＜1 800 ＜2 500 ＜2 500 Mz Pz2 Pz1 点数 K J T P C D S O ∈ Pt3 Pt2 Pt1 Ar C6-4-4 45 42.2 4.4 8.9 0.0 2.2 0.0 0.0 0.0 0.0 0.0 4.4 22.2 15.6 55.6 2.2 0.0 C6-4-3 71 4.2 19.7 4.2 9.9 7.0 1.4 0.0 0.0 0.0 1.4 11.3 23.9 16.9 28.2 18.3 0.0 C6-4-6D 112 3.6 13.4 2.7 8.0 8.9 1.8 1.8 0.0 0.0 1.8 11.6 32.1 14.3 19.6 18.8 1.8 C6-4-5D 63 3.2 25.4 11.1 4.8 6.3 3.2 1.6 1.6 0.0 0.0 9.5 17.5 15.9 39.7 14.3 3.2
下载: 导出CSV
-
Burrett, C., Zaw, K., Meffre, S., et al., 2014.The Configuration of Greater Gondwana-Evidence from LA-ICPMS, U-Pb Geochronology of Detrital Zircons from the Palaeozoic and Mesozoic of Southeast Asia and China.Gondwana Research, 26(1):31-51.doi: 10.1016/j.gr.2013.05.020 Cao, L.C., Jiang, T., Wang, Z.F., et al., 2015.Provenance of Upper Miocene Sediments in the Yinggehai and Qiongdongnan Basins, Northwestern South China Sea:Evidence from REE, Heavy Minerals and Zircon U-Pb Ages.Marine Geology, 361:136-146. doi: 10.1016/j.margeo.2015.01.007 Cawood, P.A., Hawkesworth, C.J., Dhuime, B., 2012.Detrital Zircon Record and Tectonic Setting.Geology, 40(10):875-878.doi: 10.1130/g32945.1 Cawood, P.A., Nemchin, A.A., Freeman, M., et al., 2003.Linking Source and Sedimentary Basin:Detrital Zircon Record of Sediment Flux along a Modern River System and Implications for Provenance Studies.Earth and Planetary Science Letters, 210(1-2):259-268.doi: 10.1016/s0012-821x(03)00122-5 Clift, P.D., Blusztajn, J., Nguyen, A.D., 2006.Large-Scale Drainage Capture and Surface Uplift in Eastern Tibet-SW China before 24 Ma Inferred from Sediments of the Hanoi Basin, Vietnam.Geophysical Research Letters, 33:L19403.doi: 10.1029/2006gl027772 Dai, L.M., Yang, B., Liu, X.J., et al., 2014.Sequence Stratigraphy Characteristics and Sedimentary System Evolution of Dongying Formation, Western Subsag in Bozhong Sag.Petroleum Geology and Engineering, 28(4):7-10 (in Chinese with English abstract). doi: 10.1007/s12182-014-0332-7 DeGraaff-Surpless, K., Graham, S.A., Wooden, J.L., et al, 2002.Detrital Zircon Provenance Analysis of the Great Valley Group, California:Evolution of an Arc-Forearc System.Geological Society of America Bulletin, 114(12):1564-1580.doi:10.1130/0016-7606(2002)114<1564:dzpaot> 2.0.co;2 He, M.Y., Zheng, H.B., Clift, P.D., 2013.Zircon U-Pb Geochronology and Hf Isotope Data from the Yangtze River Sands:Implications for Major Magmatic Events and Crustal Evolution in Central China.Chemical Geology, 360-361:186-203.doi: 10.1016/j.chemgeo.2013.10.020 Jiang, T., Cao, L.C., Xie, X.N., et al., 2015.Insights from Heavy Minerals and Zircon U-Pb Ages into the Middle Miocene-Pliocene Provenance Evolution of the Yinggehai Basin, Northwestern South China Sea.Sedimentary Geology, 327:32-42.doi: 10.1016/j.sedgeo.2015.07.011 Li, H., Yang, X.H., Zhu, H.T., et al., 2015.The Provenance Transformation and Sedimentary Filling Response of Paleogene Dongying Formation in Western Slope of Bozhong Sag.Acta Sedimentologica Sinica, 33(1):36-48 (in Chinese with English abstract). https://www.deepdyve.com/lp/elsevier/provenance-identification-and-sedimentary-analysis-of-the-beach-and-BMpbQosRYJ Li, J.P., Zhou, X.H., Lv, D.Y., 2011.Distribution and Evolution of Paleogene Delta Systems in Bohai Sea.China Offshore Oil and Gas, 23(5):293-298 (in Chinese with English abstract). Liu, J., 2006.Yanshanian Tectonic Evolution of the Chengde Basin and the Adjacent Area in the Eastern Segment of the Yanshan Fold-and-Thrust Belt (Dissertation).Chinese Academy of Geological Sciences, Beijing (in Chinese with English abstract). Liu, Q.H., Zhu, H.T., Shu, Y., et al., 2015.Provenance Systems and Their Control on the Beach-Bar of Paleogene Enping Formation, Enping Sag, Pearl River Mouth Basin.Acta Petrolei Sinica, 36(3):286-299 (in Chinese with English abstract). http://www.sciencedirect.com/science/article/pii/B9780128050934000070 Liu, Q.H., Zhu, H.T., Shu, Y., et al., 2016.Provenance Identification and Sedimentary Analysis of the Beach and Bar Systems in the Palaeogene of the Enping Sag, Pearl River Mouth Basin, South China Sea.Marine and Petroleum Geology, 70:251-272. doi: 10.1016/j.marpetgeo.2015.12.002 Liu, Q.H., Zhu, X.M., Li, S.L., et al., 2016.Pre-Paleogene Bedrock Distribution and Source-to-Sink System Analysis in the Shaleitian Uplift.Earth Science, 41(11):1935-1949 (in Chinese with English abstract). http://interpretation.geoscienceworld.org/content/5/4/ST65 Nie, J.S., Horton, B.K., Saylor, J.E., et al., 2012.Integrated Provenance Analysis of a Convergent Retroarc Foreland System:U-Pb Ages, Heavy Minerals, Nd Isotopes, and Sandstone Compositions of the Middle Magdalena Valley Basin, Northern Andes, Colombia.Earth-Science Reviews, 110(1-4):111-126. doi: 10.1016/j.earscirev.2011.11.002 Pang, X.J., Wang, Q.B., Du, X.F., et al., 2016.Provenance Evolution and Its Effect on Reservoir during Palaeogene in Northwest of Bozhong Sag.Petroleum Geology & Oilfield Development in Daqing, 35(5):34-41 (in Chinese with English abstract). Shao, L., Cao, L.C., Pang, X., et al., 2016.Detrital Zircon Provenance of the Paleogene Synrift Sediments in the Northern South China Sea.Geochemistry, Geophysics, Geosystems, 17(2):255-269.doi: 10.1002/2015GC006113 Sircombe, K.N., Hazelton, M.L., 2004.Comparison of Detrital Zircon Age Distributions by Kernel Functional Estimation.Sedimentary Geology, 171(1-4):91-111.doi: 10.1016/j.sedgeo.2004.05.012 van Hoang, L., Wu, F.Y., Clift, P.D., et al., 2009.Evaluating the Evolution of the Red River System Based on in Situ U-Pb Dating and Hf Isotope Analysis of Zircons.Geochemistry, Geophysics, Geosystems, 10:Q11008.doi: 10.1029/2009GC002819 Vermeesch, P., 2005.Statistical Uncertainty Associated with Histograms in the Earth Sciences.Journal of Geophysical Research:Solid Earth, 110:B02211.doi: 10.1029/2004JB003479 Vermeesch, P., 2012.On the Visualisation of Detrital Age Distributions.Chemical Geology, 312-313:190-194.doi: 10.1016/j.chemgeo.2012.04.021 Wang, C., Liang, X.Q., Xie, Y.H., et al., 2014.Provenance of Upper Miocene to Quaternary Sediments in the Yinggehai-Song Hong Basin, South China Sea:Evidence from Detrital Zircon U-Pb Ages.Marine Geology, 355:202-217.doi: 10.1016/j.margeo.2014.06.004 Wang, C., Liang, X.Q., Xie, Y.H., et al., 2015.Late Miocene Provenance Change on the Eastern Margin of the Yinggehai-Song Hong Basin, South China Sea:Evidence from U-Pb Dating and Hf Isotope Analyses of Detrital Zircons.Marine and Petroleum Geology, 61:123-139.doi: 10.1016/j.marpetgeo.2014.12.004 Wang, C., Liang, X.Q., Zhou, Y., et al., 2015.Construction of Age Frequencies of Provenances on the Eastern Side of the Yinggehai Basin:Studies on LA-ICP-MS U-Pb Ages of Detrital Zircons from Six Modern Rivers, Western Hainan, China.Earth Science Frontiers, 22(4):277-289 (in Chinese with English abstract). https://www.deepdyve.com/lp/elsevier/zircon-u-pb-geochronology-and-heavy-mineral-composition-constraints-on-eHHruUxGUG Wang, Q.M., Li, J., Zhou, X.G, et al., 2016.Characteristics of Paleo-Geomorphic and Its Controlling Effect on Deposition of Ed3 in Steep Slope Zone of West Southern Shijiutuo Uplift.Journal of Northeast Petroleum University, 40(6):53-61 (in Chinese with English abstract). Wang, W., Ye, J.R., Yang, X.H., et al., 2015.Sediment Provenance and Depositional Response to Multistage Rifting, Paleogene, Huizhou Depression, Pearl River Mouth Basin.Earth Science, 40(6):1061-1071 (in Chinese with English abstract). https://www.deepdyve.com/lp/elsevier/major-unconformities-termination-of-extension-events-and-associated-A0CAzkNY51 Wu, L., Xu, H.M., Ji, H.C., 2006.Evolution of Sedimentary System and Analysis of Sedimentary Source in Paleogene of Bozhong Sag, Bohai Bay.Marine Geology & Quaternary Geology, 26(1):81-88 (in Chinese with English abstract). Xu, C.G., Lai, W.C., Xue, Y.A., et al., 2004.Paleo-Geomorphology Analysis for the Paleognene Reservoir Prediction in Bohai Sea Area.Petroleum Exploration and Development, 31(5):53-56 (in Chinese with English abstract). Xu, X.S., O'Reilly, S.Y., Griffin, W.L., et al., 2007.The Crust of Cathaysia:Age, Assembly and Reworking of Two Terranes.Precambrian Research, 158(1-2):51-78.doi: 10.1016/j.precamres.2007.04.010 Yan, Y., Carter, A., Palk, C., et al., 2011.Understanding Sedimentation in the Song Hong-Yinggehai Basin, South China Sea.Geochemistry Geophysics Geosystems, 12:Q06014.doi: 10.1029/2011gc003533 Zhao, M., Shao, L., Liang, J.S., et al., 2015.No Red River Capture since the Late Oligocene:Geochemical Evidence from the Northwestern South China Sea.Deep Sea Research Part Ⅱ:Topical Studies in Oceanography, 122:185-194.doi: 10.1016/j.dsr2.2015.02.029 Zhao, M., Shao, L., Qiao, P.J., 2015.Characteristics of Detrital Zircon U-Pb Geochronology of the Pearl River Sands and Its Implication on Provenances.Journal of Tongji University (Natural Science), 43(6):915-923 (in Chinese with English abstract). Zheng, H., Clift, P.D., Wang, P., et al., 2013.Pre-Miocene Birth of the Yangtze River.Proceedings of the National Academy of Sciences, 110(19):7556-7561.doi: 10.1073/pnas.1216241110 代黎明, 杨波, 刘晓健, 等, 2014.渤中西次洼东营组层序地层特征与沉积体系演化.石油地质与工程, 28(4):7-10. http://d.wanfangdata.com.cn/Periodical/hnsy201404002 李欢, 杨香华, 朱红涛, 等, 2015.渤中西环古近系东营组物源转换与沉积充填响应.沉积学报, 33(1):36-48. http://d.wanfangdata.com.cn/Periodical/cjxb201501004 李建平, 周心怀, 吕丁友, 2011.渤海海域古近系三角洲沉积体系分布与演化规律.中国海上油气, 23(5):293-298. http://d.wanfangdata.com.cn/Periodical/zghsyq-gc201105002 刘健, 2006. 燕山褶皱带东段承德盆地及邻区燕山期构造演化(博士学位论文). 北京: 中国地质科学院. http://cdmd.cnki.com.cn/Article/CDMD-82501-2007213440.htm 刘强虎, 朱红涛, 舒誉, 等, 2015.珠江口盆地恩平凹陷古近系恩平组物源体系及其对滩坝的控制.石油学报, 36(3):286-299. doi: 10.7623/syxb201503004 刘强虎, 朱筱敏, 李顺利, 等, 2016.沙垒田凸起前古近系基岩分布及源-汇过程.地球科学, 41(11):1935-1949. http://earth-science.net/WebPage/Article.aspx?id=3391 庞小军, 王清斌, 杜晓峰, 等, 2016.渤中凹陷西北缘古近系物源演化及其对储层的影响.大庆石油地质与开发, 35(5):34-41. http://d.wanfangdata.com.cn/Periodical/dqsydzykf201605006 王策, 梁新权, 周云, 等, 2015.莺歌海盆地东侧物源年龄标志的建立:来自琼西6条主要河流碎屑锆石LA-ICP-MS U-Pb年龄的研究.地学前缘, 22(4):277-289. http://d.wanfangdata.com.cn/Periodical/ddgzyckx201606006 王启明, 李瑾, 周晓光, 等, 2016.石臼坨凸起西南缘陡坡带东三段古地貌对沉积的控制.东北石油大学学报, 40(6):53-61. http://d.wanfangdata.com.cn/Periodical/dqsyxyxb201606007 王维, 叶加仁, 杨香华, 等, 2015.珠江口盆地惠州凹陷古近纪多幕裂陷旋回的沉积物源响应.地球科学, 40(6):1061-1071. http://earth-science.net/WebPage/Article.aspx?id=3103 吴磊, 徐怀民, 季汉成, 2006.渤海湾盆地渤中凹陷古近系沉积体系演化及物源分析.海洋地质与第四纪地质, 26(1):81-88. http://d.wanfangdata.com.cn/Periodical/hydzydsjdz200601013 徐长贵, 赖维成, 薛永安, 等, 2004.古地貌分析在渤海古近系储集层预测中的应用.石油勘探与开发, 31(5):53-56. http://d.wanfangdata.com.cn/Periodical/syktykf200405012 赵梦, 邵磊, 乔培军, 2015.珠江沉积物碎屑锆石U-Pb年龄特征及其物源示踪意义.同济大学学报(自然科学版), 43(6):915-923. http://d.wanfangdata.com.cn/Periodical/tjdxxb201506018 -
