Gravity Inversion on Crust Structures of the Shikoku Basin, Philippine Sea, and Its Implication to the Evolution Process
-
摘要: 四国海盆是位于菲律宾海板块内由岛弧张裂形成的弧后盆地，其深部地壳结构对认识伊豆小笠原岛弧的裂解和弧后盆地的扩张过程有重要的意义.在反射多道地震剖面和深部海底地震（OBS）探测剖面的约束下，结合磁异常条带数据，利用两条横穿四国海盆的重力测线数据对海盆的地壳物性结构反演，对比重力反演剖面与深部探测剖面地壳厚度和密度特征，得到更加精细的四国海盆地壳结构.研究结果显示，四国海盆洋壳厚度自西向东逐渐增厚，在残留扩张脊处莫霍面深度迅速增加.根据地壳密度和厚度将四国海盆分为：洋壳减薄区、洋壳增厚区、后扩张洋壳增生区，分别对应初始慢速张裂、单翼快速扩张、对称慢速扩张3期扩张活动.南北测线不同构造分区得到的扩张速率与由磁异常条带得到扩张速率相同；洋壳减薄区下地壳均有高密度体，与OBS剖面中下地壳高速体相对应，可能是由于洋壳慢速扩张过程中强烈拆离作用，地幔蛇纹石化导致.Abstract: The Shikoku basin is a back-arc basin in the Philippine Sea which experienced arc rifting in Cenozoic. Study on deep structures plays an important role in understanding the break-up of the Izu-Bonin-Mariana arc and back-arc rifting history. With constraints of multi-channel seismic data and refraction seismic data, as well as the magnetic data, we carry out gravity inversion on two profiles crossing the whole Shikoku basin to study the density changes along the lines, and to reconstruct the deep structures. Results show that the oceanic crustin creases gradually from west to east, and the Moho depth increases sharply in the residual spreading ridge. According to the crustal density and thickness, we separate the Shikoku basin into three domains:the thin nedoceanic domain, the thickened oceanic domain, and the domain affected by post-spreading magmatism, which corresponds to th einitial slow spreading stage, single-wing fast spreading stage, and the symmetrical spreading stage, respectively. The spreading rate calculated from the different tectonic domains fits well with that from the magnetic omalies. High-density body exists under the oceanic crust with in thinned oceanic domain, which is correspondence with high-velocity layer in the refraction seismic velocity model. We suggest that this high-density body was formed by mantle serpentinization caused by active detachments during slow-spreading stage.
-
图 1 研究区位置以及地球物理探测剖面分布
红线部分：两条重力反演线位置；背景是地形图
Fig. 1. Location of the study area and the distribution of geophysical exploration profiles in the Shikoku basin
图 4 四国海盆南部密度D(g/cm3)模型剖面(剖面AA')
Fig. 4. Vertical cross section of density (g/cm3) model through the southern Shikoku basin
图 5 四国海盆北部密度D(g/cm3)模型剖面(剖面BB')
Fig. 5. Vertical cross section of density (g/cm3) model through the northern Shikoku basin
图 6 四国海盆OBS速度剖面与密度D(g/cm3)模型地壳结构对比
图中黑色线为OBS探测的莫霍面，白色线为洋壳层2、层3分界面
Fig. 6. Comparison of crustal structure between refraction seismic velocity model and density model in the Shikoku basin
表 1 反演建模采用的密度参数
Table 1. Densities used in the modeling
模型块体 海水 新生代沉积 大洋层1 大洋层2 大洋层3 海山 岩浆侵入体 上地壳 中地壳 下地壳 密度(g/cm3) 1.03 1.96~2.30 1.96~2.30 2.38~2.81 2.81~3.05 2.50~2.69 2.54~2.62 2.40~2.70 2.69~2.78 2.80~2.95
下载: 导出CSV
表 2 迭代拟合反演密度
Table 2. Densities from iterative inversion
模型块体 海水 新生代沉积 大洋层1 大洋层2 大洋层3 海山 岩浆侵入体 上地壳 中地壳 下地壳 密度(g/cm3) 1.03 1.96~2.30 1.96~2.30 2.38~2.81 2.81~3.05 2.50~2.69 2.54~2.62 2.40~2.70 2.69~2.78 2.80~2.95
下载: 导出CSV
-
Arculus, R.J., Ishizuka, O., Bogus, K.A., et al., 2015.A Record of Spontaneous Subduction Initiation in the Izu-Bonin-Mariana Arc.Nature Geoscience, 8(9):728-733. https://doi.org/10.1038/ngeo2515 Chamot-Rooke, N., Renard, V., Le Pichon, X., 1987.Magnetic Anomalies in the Shikoku Basin:A New Interpretation.Earth and Planetary Science Letters, 83(1):214-228. https://doi.org/10.1016/0012-821X(87)90067-7 Fang, P.G., Ding, W.W., Fang, Y.X., et al., 2015.Development of Carbonate Platform and Its Response to Cenozoic Tectonic in Reed Bank Area, the South China Sea.Earth Science, 40(12):2052-2066(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqkx201512008 Fang, Y., Li, J., Li, M., et al., 2011.The Formation and Tectonic Evolution of Philippine Sea Plate and KPR.Acta Oceanologica Sinica, 30(4):75-88. https://doi.org/10.1007/s13131-011-0135-2 Hall, R., Ali, J.R., Anderson, C.D., et al., 1995a.Origin and Motion History of the Philippine Sea Plate.Tectonophysics, 251(1):229-250. https://doi.org/10.1016/0040-1951(95)00038-0 Hall, R., Fuller, M., Ali, J.R., et al., 1995b.The Philippine Sea Plate:Magnetism and Reconstructions.Active Margins and Marginal Basins of the Western Pacific, 88:371-404. https://doi.org/10.1029/GM088p0371 Higuchi, Y., Yanagimoto, Y., Hoshi, K., et al., 2007.Cenozoic Stratigraphy and Sedimentation History of the Northern Philippine Sea Based on Multichannel Seismic Reflection Data.Island Arc, 16(3):374-393.https://doi.org/10.1111/j.1440-1738.2007.00588.x doi: 10.1111/iar.2007.16.issue-3 Honza, E., Fujioka, K., 2004.Formation of Arcs and Backarc Basins Inferred from the Tectonic Evolution of Southeast Asia since the Late Cretaceous.Tectonophysics, 384(1-4):23-53. https://doi.org/10.1016/j.tecto.2004.02.006 Hoshi, K., Yanagimoto, Y., Akiba, F., et al., 2015.Architecture and Tectonic Evolution of Sedimentary Basins in the Izu-Ogasawara on a Seismic Reflection Survey Interpretation.Journal of Geography, 124(5):847-876. https://doi.org/10.5026/jgeography.124.847 Ishihara, T., Koda, K., 2007.Variation of Crustal Thickness in the Philippine Sea Deduced from Three-Dimensional Gravity Modeling.Island Arc, 16(3):322-337.doi: 10.1111/j.1440-1738.2007.00593.x Kaneda, K., Nishizawa, A., Oikawa, M., 2015.Large-Scale Seismic Experiments Conducted by Japan Coast Guard in the Northwestern Pacific Plate and the Philippine Sea Plate.Journal of Geography, 124(5):787-811. https://doi.org/10.5026/jgeography.124.787 Kasahara, J., Unou, S., Tsuruga, K., et al., 2008.Characteristics of Moho Reflections Identified by MCS Reflection Records in the Western Pacific Ocean and Effects of Moho Transition Zone Properties.Journal of Geography-Tokyo, 117(1):5-44. https://doi.org/10.5026/jgeography.117.5 Klein, G.D., Kobayashi, K., Chamley, H., et al., 1978.Off-Ridge Volcanism and Seafloor Spreading in the Shikoku Basin.Nature, 273:746-748.doi: 10.1038/273746a0 Klein, G., Kobayashi, K., 1981.Geological Summary of the Shikoku Basin and Northwestern Philippine Sea, Leg 58, DSDP/IPOD Drilling Results.Oceanologica Sinica, (Special Issue):399-1784 Kobayashi, K., Kasuga, S., Okino, K., 1995.Shikoku Basin and Its Margins.In:Taylor, B., ed., Back-Arc Basins.Plenum, New York, 381-405. Martinez, F., Taylor, B., Baker, E.T., et al., 2006.Opposing Trends in Crustal Thickness and Spreading Rate along the Back-Arc Eastern Lau Spreading Center:Implications for Controls on Ridge Morphology, Faulting, and Hydrothermal Activity.Earth and Planetary Science Letters, 245:655-672. https://doi.org/10.1016/j.epsl.2006.03.049 Murauchi, S., Den, N., Asano, S., et al., 1968.Crustal Structure of the Philippine Sea.Journal of Geophysical Research, 73(10):3143-3171. https://doi.org/10.1029/JB073i010p03143 Nishizawa, A., Kaneda, K., Nakanishi, A., et al., 2006.Crustal Structure of the Ocean-Island Arc Transition at the Mid Izu-Ogasawara (Bonin) Arc Margin.Earth, Planets and Space, 58(8):33-36. https://doi.org/10.1186/BF03352594 Nishizawa, A., Kaneda, K., Oikawa, M., 2011.Back Arc Basin Oceanic Crust and Uppermost Mantle Seismic Velocity Structure of the Shikoku Basin, South of Japan.Earth, Planets and Space, 63(2):151-155.doi: 10.5047/eps.2010.12.003 Nishizawa, A., Kaneda, K., Oikawa, M., 2016.Crust and Uppermost Mantle Structure of the Kyushu-Palau Ridge, Remnant Arc on the Philippine Sea Plate.Earth, Planets and Space, 68(1):30-47. https://doi.org/10.1186/s40623-016-0407-3 Okino, K., Kasuga, S., Ohara, Y., 1998.A New Scenario of the Parece Vela Basin Genesis.Marine Geophysical Researches, 20(1):21-40. https://doi.org/10.1023/A:1004377422118 Okino, K., Ohara, Y., Kasuga, S., et al., 1999.The Philippine Sea:New Survey Results Reveal the Structure and the History of the Marginal Basins.Geophysical Research Letters, 26(15):2287-2290.https://doi.org/10.1029/1999gl900537 doi: 10.1029/1999GL900537 Okino, K., Shimakawa, Y., Nagaoka, S., 1994.Evolution of the Shikoku Basin.Journal of Geomagnetism and Geoelectricity, 46(6):463-479. https://doi.org/10.5636/jgg.46.463 Ren, J.Y., Li, S.T., 2000.Spreading and Dynamic Setting of Marginal Basins of the Western Pacific.Earth Science Frontiers, 7(3):203-213(in Chinese with English abstract). Sdrolias, M., Müller, R.D., 2006.Controls on Back-Arc Basin Formation.Geochemistry, Geophysics, Geosystems, 7(4):290. https://doi.org/10.1029/2005gc001090 Sdrolias, M., Roest, W.R., Müller, R.D., 2004.An Expression of Philippine Sea Plate Rotation:The Parece Vela and Shikoku Basins.Tectonophysics, 394(1-2):69-86.doi: 10.1016/j.tecto.2004.07.061 Shi, X.F., Yan, Q.S., 2013.Magmatism of Typical Marginal Basins (or Back-Arc Basins) in the West Pacific.Advances in Earth Science, 28(7):737-750(in Chinese with English abstract). Shih, T.C., 1980.Magnetic Lineations in the Shikoku Basin.Initial Reports of the Deep Sea Drilling Project, 58:783-788.doi: 10.2973/dsdp.proc.58.131.1980 Sibuet, J.C., Hsu, S.K., Le Pichon, X., et al., 2002.East Asia Plate Tectonics since 15 Ma:Constraints from the Taiwan Region.Tectonophysics, 344(1):103-134.doi: 10.1016/S0040-1951(01)00202-5 Takahashi, N., Kodaira, S., Tatsumi, Y., et al., 2008.Structure and Growth of the Izu-Bonin-Mariana Arc Crust:1.Seismic Constraint on Crust and Mantle Structure of the Mariana Arc-Back-Arc System.Journal of Geophysical Research, 113(B1):699-701.doi: 10.1029/2007jb005120 Tang, Y., Li, M., Li, J., et al., 2011.The Geomorphological Features and Continuity of the Kyushu-Palau Ridge (KPR).Acta Oceanologica Sinica, 30(5):114-124. https://doi.org/10.1007/s13131-011-0136-1 Taylor, B., Martinez, F., 2003.Back-Arc Basin Basalt Systematics.Earth and Planetary Science Letters, 210(3-4):481-497.https://doi.org/10.1016/s0012-821x(03)00167-5 doi: 10.1016/S0012-821X(03)00167-5 Watts, A.B., Weissel, J.K., 1975.Tectonic History of the Shikoku Marginal Basin.Earth and Planetary Science Letters, 25(3):239-250.https://doi.org/10.1016/0012-812X(75)90238-1 doi: 10.1016/0012-821X(75)90238-1 Wu, S.G., Fan, J.K., Dong, D.D., 2013.Discussion on the Tectonic Division of the Philippine Sea Plate.Chinese Journal of Geology, 48(3):677-692(in Chinese with English abstract). Xu, S.M., Zhang, X.D., Zhai, S.K., 2004.The Origin and Sedimentary Environment Evolution of the Shikoku Basin.Marine Geology & Quaternary Geology, 24(2):119-123(in Chinese with English abstract). Yamashita, M., Tsuru, T., Takahashi, N., et al., 2007.Fault Configuration Produced by Initial Arc Rifting in the Parece Vela Basin as Deduced from Seismic Reflection Data.Island Arc, 16(3):338-347.https://doi.org/10.1002/gj.2778 doi: 10.1111/iar.2007.16.issue-3 Zang, S.X., Ning, J.Y., 1996.Study on the Subduction Zone in Western Pacific and Its Implication for the Geodynamics.Chinese Acta Geophysica Sinica, 39(2):188-202 (in Chinese with English abstract). Zhang, J., Li, J., Ruan, A., et al., 2016.The Velocity Structure of a Fossil Spreading Centre in the Southwest Sub-Basin, South China Sea.Geological Journal, 51(S1):548-561. https://doi.org/10.1111/j.1440-1738.2007.00594.x Zhao, Z.G., Wang, P., Qi, P., et al., 2016.Regional Background and Tectonic Evolution of East China Sea Basin.Earth Science, 41(3):546-554(in Chinese with English abstract). https://doi.org/10.3799/dqkx.2016.045 Zong, T., Zhai, S.K., Yu, Z.H., 2016.Regional Differences of Magmatism in the Okinawa Trough.Earth Science, 41(6):1031-1040(in Chinese with English abstract). https://doi.org/10.3799/dqkx.2016.085 方鹏高, 丁巍伟, 方银霞, 等, 2015.南海礼乐滩碳酸盐台地的发育及其新生代构造响应.地球科学, 40(12):2052-2066. http://www.earth-science.net/WebPage/Article.aspx?id=3208 任建业, 李思田, 2000.西太平洋边缘海盆地的扩张过程和动力学背景.地学前缘, 7(3):203-213. http://bianke.cnki.net/Web/Article/DXQY200003025.html 石学法, 鄢全树, 2013.西太平洋典型边缘海盆的岩浆活动.地球科学进展, 28(7):737-750. doi: 10.11867/j.issn.1001-8166.2013.07.0737 吴时国, 范建柯, 董冬冬, 2013.论菲律宾海板块大地构造分区.地质科学, 48(3):677-692. http://www.doc88.com/p-2042066656926.html 许淑梅, 张晓东, 翟世奎, 2004.四国海盆起源与沉积环境演化.海洋地质与第四纪地质, 24(2):119-123. http://www.cnki.com.cn/Article/CJFDTotal-HYDZ200402019.htm 臧绍先, 宁杰远, 1996.西太平洋俯冲带的研究及其动力学意义.地球物理学报, 39(2):188-202. http://mall.cnki.net/magazine/Article/DQWX199602005.htm 赵志刚, 王鹏, 祁鹏, 等, 2016.东海盆地形成的区域地质背景与构造演化特征.地球科学, 41(3):546-554. http://www.earth-science.net/WebPage/Article.aspx?id=3269 宗统, 翟世奎, 于增慧, 2016.冲绳海槽岩浆作用的区域性差异.地球科学, 41(6):1031-1040. http://www.earth-science.net/WebPage/Article.aspx?id=3314 -
