    致密油藏储层微观孔隙特征与可动用性评价

    熊生春 储莎莎 皮淑慧 何英 李树铁 张亚蒲

    熊生春, 储莎莎, 皮淑慧, 何英, 李树铁, 张亚蒲, 2017. 致密油藏储层微观孔隙特征与可动用性评价. 地球科学, 42(8): 1379-1385. doi: 10.3799/dqkx.2017.550
    引用本文: 熊生春, 储莎莎, 皮淑慧, 何英, 李树铁, 张亚蒲, 2017. 致密油藏储层微观孔隙特征与可动用性评价. 地球科学, 42(8): 1379-1385. doi: 10.3799/dqkx.2017.550
    Xiong Shengchun, Chu Shasha, Pi Shuhui, He Ying, Li Shutie, Zhang Yapu, 2017. Micro-Pore Characteristics and Recoverability of Tight Oil Reservoirs. Earth Science, 42(8): 1379-1385. doi: 10.3799/dqkx.2017.550
    Citation: Xiong Shengchun, Chu Shasha, Pi Shuhui, He Ying, Li Shutie, Zhang Yapu, 2017. Micro-Pore Characteristics and Recoverability of Tight Oil Reservoirs. Earth Science, 42(8): 1379-1385. doi: 10.3799/dqkx.2017.550

    致密油藏储层微观孔隙特征与可动用性评价

    doi: 10.3799/dqkx.2017.550
    基金项目:

    中国石油重大科技攻关项目 2016E-1303

    国家油气重大专项 2017ZX05013-001

    详细信息
      作者简介:

      熊生春(1981-), 男, 高级工程师, 主要从事低渗致密油藏渗流理论与应用方面的研究

    • 中图分类号: P554

    Micro-Pore Characteristics and Recoverability of Tight Oil Reservoirs

    • 摘要: 致密油储层主要包括致密灰岩和致密砂岩,两者微观特征差异明显.但目前针对致密灰岩和致密砂岩的对比研究相对较少,因此开展致密油藏不同岩性微观孔隙结构特征及可动用性研究具有十分重要的意义.利用低温氮吸附比表面、核磁共振、压汞等方法,从纳米级、亚微米级、微米级孔隙等不同尺度表征了致密灰岩和致密砂岩孔隙结构差异,分析了不同孔隙对渗透率的贡献和对流体赋存的影响,研究了启动压力梯度的差异和喉道对启动压力梯度的影响.以川中灰岩和长庆砂岩为例,结果表明渗透率大于0.01 mD储层具备开发潜力,致密灰岩中的亚微米和微米级孔隙是重要的储集和流动空间,致密砂岩中微米级孔隙是重要的储集和流动空间.基于微观实验分析和低渗透油藏评价方法,提出了致密油藏分级评价参数,并给出了分级评价界限,对确定致密油藏攻关目标和优选区块新建产能意义重大.



    • 图  1  致密灰岩和致密砂岩岩心孔渗关系

      图  2  致密岩心渗透率与可动流体百分数关系

      Fig.  2.  Relationship between permeability and movable fluid percentage of tight cores

      图  3  致密岩心孔隙度与可动流体百分数关系

      Fig.  3.  Relationship between porosity and movable fluid percentage of tight cores

      图  4  致密灰岩不同喉道的可动流体份额

      Fig.  4.  Movable fluid share of different throats in tight limestone

      图  5  致密砂岩不同喉道的可动流体份额

      Fig.  5.  Movable fluid share of different throats in tight sandstone

      图  6  致密灰岩和致密砂岩启动压力梯度对比

      Fig.  6.  Comparison of starting pressure gradient between tight limestone and tight sandstone

      图  7  致密灰岩和致密砂岩不同级别渗透率岩心喉道分布

      Fig.  7.  Different levels of permeability core throat distribution of tight limestone and tight sandstone

      表  1  33块岩心微观孔隙结构测试结果

      Table  1.   Micro pore structure measurement results of 33 cores

      岩性 渗透率(mD) 纳米级r≤0.1 μm 亚微米0.1<r≤1.0 μm 微米级r>1.0 μm
      控制体积比例
      (%)
      渗透率贡献比例
      (%)
      控制体积比例
      (%)
      渗透率贡献比例
      (%)
      控制体积比例
      (%)
      渗透率贡献比例
      (%)
      致密灰岩 小于0.01 80.62 21.85 19.31 76.56 0.07 1.59
      0.01~0.1 66.76 8.35 31.89 68.16 1.35 23.49
      0.1~1 71.75 0.31 22.09 22.96 6.17 76.74
      致密砂岩 小于0.01 84.85 33.03 15.15 66.97 0.00 0.00
      0.01~0.1 62.37 24.50 37.57 73.68 0.05 1.82
      0.1~1 27.13 1.06 72.73 97.41 0.14 1.53
      下载: 导出CSV

      表  2  致密油储层特征参数及分类界限

      Table  2.   Characteristic parameters and classification boundaries of tight oil reservoirs

      类别 渗透率
      (mD)
      r>0.1 μm
      大孔隙比例(%)
      r>0.1 μm
      渗透率贡献(%)
      可动流体百分数
      (%)
      启动压力梯度
      (MPa/m)
      原油粘度
      (mPa·s)
      岩石脆性指数 压力系数
      一类 0.1~1 >40 >90 >40 <0.5 <2 >60 >1.1
      二类 0.01~0.1 20~40 80~90 20~40 0.5~1 2~5 20~40 0.9~1.1
      三类 <0.01 <20 <80 <20 >1 >5 <40 <0.9
      备注 储层宏观流动能力 大孔隙储集能力 大孔隙流动能力 大孔隙供给能力 储层流动阻力 流体流动能力 缝网重要条件 能量是否充足
      下载: 导出CSV
    • [1] Cai, J.C., Yu, B.M., 2011.A Discussion of the Effect of Tortuosity on the Capillary Imbibition in Porous Media.Transport in Porous Media, 89(2):251-263.doi: 10.1007/s11242-011-9767-0
      [2] Cai, J.C., Yu, B.M., Zou, M.Q., et al., 2010.Fractal Characterization of Spontaneous Co-Current Imbibition in Porous Media.Energy & Fuels, 24(3):1860-1867.doi: 10.1021/ef901413p
      [3] Du, J.H., Liu, H., Ma, D.S., et al., 2014.Discussion on Effective Development Techniques for Continental Tight Oil in China.Petroleum Exploration and Development, 41(2):198-205 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SKYK201402010.htm
      [4] EIA, 2013.Technically Recoverable Shale Oil and Shale Gas Resources:An Assessment of 137 Shale Formations in 41 Countries outside the United States.http://www.eia.gov/analysis/studies/worldsh-alegas/pdf/overview.pdf, 1-79
      [5] EIA, 2017.Oil and Gas Supply Module.https://www.eia.gov/outlooks/aeo/assumptions/pdf/oilgas.pdf, 131-149.
      [6] Gui, L.L., Liu, K.Y., Liu, S.B., et al., 2015.Hydrocarbon Charge History of Yingdong Oilfieiid, Western Qaidam Basin.Earth Science, 40(5):890-899 (in Chinese with English abstract).
      [7] Jia, C.Z., Zheng, M., Zhang, Y.F., 2012a.Unconventional Hydrocarbon Resources in China and the Prospect of Exploration and Development.Petroleum Exploration and Development, 39(2):129-136 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SKYK201202002.htm
      [8] Jia, C.Z., Zou, C.N., Li, J.Z., et al., 2012b.Assessment Criteria, Main Types, Basic Features and Resource Prospects of the Tight Oil in China.Acta Petrolei Sinica, 33(3):343-350 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SYXB201203000.htm
      [9] Jia, P.F., Yang, Z.M., Xiao, Q.H., et al., 2015.A New Method to Evaluate Tight Oil Reservoirs.Special Oil and Gas Reservoirs, 22(4):33-36 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-TZCZ201504009.htm
      [10] Leng, Z.P., Yang, S.J., Lü, W.F., et al., 2016.Pore Structure Characterization for Tight Oil Reservoirs:Taking Chuanzhong Tight Oil Reservoir Coers Example.Fault-Block Oil & Gas Field, 23(2):161-165 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-DKYT201602007.htm
      [11] Liu, W.C., Yao, J., Chen, Z.X., et al., 2015.Research on Analytical and Numerical Solutions of a Moving Boundary Model of Seepage Flow in Low-Permeable Porous Media.Chinese Journal of Theoretical and Applied Mechanics, 47(4):605-612 (in Chinese with English abstract). http://www.en.cnki.com.cn/Article_en/CJFDTOTAL-LXXB201504008.htm
      [12] Wang, X.W., Yang, Z.M., Li, H.B., et al., 2013.Microscopic Distribution of Remaining Oil of Ultra-Low Permeability Reservoir by Using NMR Technique.Journal of Basic Science and Engineering, 21(4):702-708 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-YJGX201304013.htm
      [13] Wu, S.T., Zou, C.N., Zhu, R.K., et al., 2015.Reservoir Quality Characterization of Upper Triassic Chang 7 Shale in Ordos Basin.Earth Science, 40(11):1810-1823 (in Chinese with English abstract). http://www.en.cnki.com.cn/Article_en/CJFDTotal-DQKX201511004.htm
      [14] Xiao, Q.H., Zhang, Y., Yang, Z.M., et al., 2015.Experiment on Low-Temperature Nitrogen Adsorption in Typical Tight Oil Zones in China.Special Oil & Gas Reservoirs, 22(4):82-85, 155 (in Chinese with English abstract).
      [15] Xiong, S.C., Chu, S.S., Zhao, G.M., et al., 2015.Quality Limit of Effective Injection Water in Low Permeability Reservoirs.Petroleum Geology and Recovery Efficiency, 22(3):100-105 (in Chinese with English abstract). http://www.sciencedirect.com/science/article/pii/S0013468613021373
      [16] Yang, Z.M., Miao, S., Liu, X.G., et al., 2007.Percentage Parameter of the Movable Fluid in Ultra-Low Permeability Reservoir and Its Application.Journal of Xi'an Shiyou University (Natural Science Edition), 22(2):96-99 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-XASY200702024.htm
      [17] Yu, J., Yang, X., Li, B., et al., 2014.A Method of Determining Movable Fluid Saturation of Tight Oil Reservoirs.Petroleum Geology & Experiment, 36(6):767-770 (in Chinese with English abstract).
      [18] Zhang, H., Zhang, S.C., Liu, S.B., et al., 2014.A Theoretical Discussion and Case Study on the Oil-Charging Throat Threshold for Tight Reservoirs.Petroleum Exploration and Development, 41(3):367-374 (in Chinese with English abstract). http://www.en.cnki.com.cn/Article_en/CJFDTOTAL-SKYK201403017.htm
      [19] Zhang, J.F., Bi, H.B., Xu, H., et al., 2015.New Progress and Reference Significance of Overseas Tight Oil Exploration and Development.Acta Petrolei Sinica, 36(2):129-137 (in Chinese with English abstract). http://www.en.cnki.com.cn/Article_en/CJFDTOTAL-SYXB201502001.htm
      [20] Zhang, Z.H., Yang, Z.M., Liu, X.G., et al., 2012.A Grading Evaluation Method for Low-Permeability Reservoirs and Its Application.Acta Petrolei Sinica, 33(3):437-441 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SYXB201203013.htm
      [21] Zhang, Z.Y., Chen, S.J., Yao, J.L., et al., 2016.A Study on Microscopic Pore Characteristic of Tight Reservoir of Chang 7 Sedimentation Section of Yanchan.Journal of Southwest Petroleum University (Science & Technology Edition), 38(6):70-80 (in Chinese with English abstract). http://www.en.cnki.com.cn/Article_en/CJFDTOTAL-XNSY201606007.htm
      [22] Zou, C.N., Zhu, R.K., Bai, B., et al., 2015.Significance, Geologic Characteristics, Resource Potential and Future Challenges of Tight Oil and Shale Oil.Bulletin of Mineralogy, Petrology and Geochemistry, 34(1):3-17 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-KYDH201501002.htm
      [23] 杜金虎, 刘合, 马德胜, 等, 2014.试论中国陆相致密油有效开发技术.石油勘探与开发, 41(2): 198-205. doi: 10.11698/PED.2014.02.09
      [24] 桂丽黎, 刘可禹, 柳少波, 等, 2015.柴达木盆地西部英东地区油气成藏过程.地球科学, 40(5): 890-899. http://earth-science.net/WebPage/Article.aspx?id=3081
      [25] 贾承造, 郑民, 张永峰, 2012a.中国非常规油气资源与勘探开发前景.石油勘探与开发, 39(2):129-136. http://www.cnki.com.cn/Article/CJFDTOTAL-SKYK201202002.htm
      [26] 贾承造, 邹才能, 李建忠, 等, 2012b.中国致密油评价标准、主要类型、基本特征及资源前景.石油学报, 33(3): 343-350. http://www.cnki.com.cn/Article/CJFDTOTAL-SYXB201203000.htm
      [27] 贾培锋, 杨正明, 肖前华, 等, 2015.致密油藏储层综合评价新方法.特种油气藏, 22(4): 33-36. http://www.cnki.com.cn/Article/CJFDTOTAL-TZCZ201504009.htm
      [28] 冷振鹏, 杨胜建, 吕伟峰, 等, 2016.致密油孔隙结构表征方法——以川中致密油储层岩心为例.断块油气田, 23(2): 161-165. http://www.cnki.com.cn/Article/CJFDTOTAL-DKYT201602007.htm
      [29] 刘文超, 姚军, 陈掌星, 等, 2015.低渗透多孔介质渗流动边界模型的解析与数值解.力学学报, 47(4): 605-612. doi: 10.6052/0459-1879-14-385
      [30] 王学武, 杨正明, 李海波, 等, 2013.利用核磁共振研究特低渗透油藏微观剩余油分布.应用基础与工程科学学报, 21(4): 702-708. http://www.cnki.com.cn/Article/CJFDTOTAL-YJGX201304013.htm
      [31] 吴松涛, 邹才能, 朱如凯, 等, 2015.鄂尔多斯盆地上三叠统长7段泥页岩储集性能.地球科学, 40(11): 1810-1823. http://earth-science.net/WebPage/Article.aspx?id=3188
      [32] 肖前华, 张尧, 杨正明, 等, 2015.中国典型致密油区低温氮气吸附实验.特种油气藏, 22(4): 82-85, 155. http://www.cnki.com.cn/Article/CJFDTOTAL-TZCZ201504021.htm
      [33] 熊生春, 储莎莎, 赵国梅, 等, 2015.低渗透油藏有效注入水水质界限.油气地质与采收率, 22(3): 100-105. http://www.cnki.com.cn/Article/CJFDTOTAL-YQCS201503018.htm
      [34] 杨正明, 苗盛, 刘先贵, 等, 2007.特低渗透油藏可动流体百分数参数及其应用.西安石油大学学报(自然科学版), 22(2): 96-99. http://www.cnki.com.cn/Article/CJFDTOTAL-XASY200702024.htm
      [35] 喻建, 杨孝, 李斌, 等, 2014.致密油储层可动流体饱和度计算方法——以合水地区长7致密油储层为例.石油实验地质, 36(6): 767-770. doi: 10.11781/sysydz201406767
      [36] 张洪, 张水昌, 柳少波, 等, 2014.致密油充注孔喉下限的理论探讨及实例分析.石油勘探与开发, 41(3): 367-374. doi: 10.11698/PED.2014.03.14
      [37] 张君峰, 毕海滨, 许浩, 等, 2015.国外致密油勘探开发新进展及借鉴意义.石油学报, 36(2): 129-137. http://www.cnki.com.cn/Article/CJFDTOTAL-SYXB201502001.htm
      [38] 张仲宏, 杨正明, 刘先贵, 等, 2012.低渗透油藏储层分级评价方法及应用.石油学报, 33(3): 437-441. doi: 10.7623/syxb201203013
      [39] 张忠义, 陈世加, 姚泾利, 等, 2016.鄂尔多斯盆地长7段致密储层微观特征研究.西南石油大学学报(自然科学版), 38(6): 70-80. doi: 10.11885/j.issn.1674-5086.2015.05.01.02
      [40] 邹才能, 朱如凯, 白斌, 等, 2015.致密油与页岩油内涵、特征、潜力及挑战.矿物岩石地球化学通报, 34(1): 3-17. http://www.cnki.com.cn/Article/CJFDTOTAL-KYDH201501002.htm
