    基于嵌入离散裂缝的页岩气藏视渗透率模型

    冯其红 徐世乾 王森 杨毅 高方方 徐亚娟

    冯其红, 徐世乾, 王森, 杨毅, 高方方, 徐亚娟, 2017. 基于嵌入离散裂缝的页岩气藏视渗透率模型. 地球科学, 42(8): 1301-1313. doi: 10.3799/dqkx.2017.551
    引用本文: 冯其红, 徐世乾, 王森, 杨毅, 高方方, 徐亚娟, 2017. 基于嵌入离散裂缝的页岩气藏视渗透率模型. 地球科学, 42(8): 1301-1313. doi: 10.3799/dqkx.2017.551
    Feng Qihong, Xu Shiqian, Wang Sen, Yang Yi, Gao Fangfang, Xu Yajuan, 2017. A Stochastic Permeability Model for Shale Gas Reservoirs Based on Embedded Discrete Fracture Model. Earth Science, 42(8): 1301-1313. doi: 10.3799/dqkx.2017.551
    Citation: Feng Qihong, Xu Shiqian, Wang Sen, Yang Yi, Gao Fangfang, Xu Yajuan, 2017. A Stochastic Permeability Model for Shale Gas Reservoirs Based on Embedded Discrete Fracture Model. Earth Science, 42(8): 1301-1313. doi: 10.3799/dqkx.2017.551

    基于嵌入离散裂缝的页岩气藏视渗透率模型

    doi: 10.3799/dqkx.2017.551
    基金项目:

    国家重点基础研究发展计划(973计划)项目 2015CB250905

    中国博士后创新人才支持计划项目 BX201600153

    青岛市博士后应用研究项目 2016218

    中国博士后科学基金资助 2016M600571

    详细信息
      作者简介:

      冯其红(1969-), 男, 教授, 主要从事非常规油气勘探开发及提高采收率方面的科研工作

      通讯作者:

      王森

    • 中图分类号: P313.1

    A Stochastic Permeability Model for Shale Gas Reservoirs Based on Embedded Discrete Fracture Model

    • 摘要: 页岩储层具有不同类型的储集空间,但综合考虑不同储集空间,对页岩储层渗透率进行评价的模型未见报道.基于嵌入离散裂缝模型,建立的页岩气藏视渗透率模型包括4个步骤:(1)构建天然裂缝、有机质和无机质的空间分布模型;(2)筛选不同类型储集空间的渗透率计算方法;(3)基于嵌入离散裂缝模型,结合空间分布模型和渗透率计算方法,建立数值模拟模型;(4)在模型的入口和出口端施加压差,求得一定压差下通过该岩心的气体流量,采用达西定律得到该页岩气藏的视渗透率.其计算结果与文献报道的渗透率实验值吻合较好.通过对不同因素的探讨,结果表明,天然裂缝对页岩气藏视渗透率的贡献大于无机质和有机质孔隙.因此,计算页岩视渗透率时有必要对天然裂缝、有机质和无机质孔隙进行综合考虑.



    • 图  1  有机质方块尺寸概率密度分布函数

      Fig.  1.  Probability density function for patch-size distribution of organic matter

      图  2  四种随机生成的页岩基质模型

      黑色方块代表有机质;白色部分代表无机质

      Fig.  2.  Four stochastic shale matrix models

      图  3  四种随机生成的天然裂缝、有机质和无机质的空间分布模型

      红色实线代表天然裂缝

      Fig.  3.  Four stochastic spatial distribution models for natural fracture, organic matter and inorganic matter

      图  4  孔隙尺寸的概率密度分布函数

      a.氮气吸附实验测得的双峰孔隙尺寸分布特征曲线(美国鹰滩页岩样品);b.有机质孔隙;c.无机质孔隙

      Fig.  4.  Probability density function for pore size distribution

      图  5  EDFM原理示意

      a.物理模型;b.计算域模型;据Xu et al.(2016)

      Fig.  5.  The working principle diagram for EDFM

      图  6  渗透率分布场

      a.完整模型(200 μm×200 μm);b.局部放大模型(40 μm×30 μm)

      Fig.  6.  Permeability distribution model

      图  7  压力分布场

      模型尺寸为200 μm×200 μm

      Fig.  7.  The pressure distribution

      图  8  模型尺寸对视渗透率计算结果的影响

      Fig.  8.  The effect of model size to shale gas AP

      图  9  两个页岩样品的孔隙尺寸分布特征曲线

      Kuila and Prasad(2013)

      Fig.  9.  Bimodal pore size distribution curve of two shale samples

      图  10  不同类型储集空间对渗透率的影响.

      a.考虑天然裂缝,有机质和无机质孔隙对渗透率的影响;b.考虑有机质和无机质孔隙对渗透率的影响;c.只考虑有机质孔隙对渗透率的影响

      Fig.  10.  The effect on permeability of different types of pore space

      图  11  单条天然裂缝对视渗透率的影响

      a.存在一条天然裂缝;b.不存在天然裂缝;c.裂缝倾角(θ)示意;d.天然裂缝倾角对视渗透率的影响;模型尺寸为200 μm×200 μm

      Fig.  11.  The effect of single natural fracture to shale gas AP

      图  12  天然裂缝条数对视渗透率的影响

      模型尺寸为200 μm×200 μm;红色直线代表天然裂缝

      Fig.  12.  The effect of natural fracture number to shale gas AP

      图  13  天然裂缝开度对视渗透率的影响

      a.分析天然裂缝开度影响的基础模型(红色直线代表天然裂缝);b.天然裂缝开度对视渗透率的影响规律;模型尺寸为200 μm×200 μm

      Fig.  13.  The effect of natural fracture aperture to shale gas AP

      图  14  页岩气藏视渗透率的参数敏感性分析

      a.迂曲度对视渗透率的影响;b.系统压力对视渗透率的影响;c.有机质孔隙孔径分布特征(均值和标准差)对视渗透率的影响;d.无机质孔隙孔径分布特征(均值和标准差)对视渗透率的影响

      Fig.  14.  Sensitivity analysis for shale gas AP

      表  1  天然裂缝参数

      Table  1.   Natural fracture parameters

      参数 数值
      平均走向 北偏东60°
      Fisher常数K 120
      最小天然裂缝长度lmin 10 μm
      最大天然裂缝长度lmax 160 μm
      天然裂缝条数nf 10
      幂律分布指数α 0.8
      孔隙度φf 0.02
      迂曲度τf 1
      开度h 1 μm
      下载: 导出CSV

      表  3  页岩样品属性

      Table  3.   The properties of shale samples

      岩石样品属性 皮埃尔页岩 曼科斯页岩
      孔隙尺寸分布 图 9 图 9
      孔隙度 0.06 0.06
      体积TOC 18.00% 1.36%
      系统压力 13.8 MPa 13.8 MPa
      实验测量的渗透率 0.017 0 μD 0.016 0 μD
      模型计算的渗透率 0.016 9 μD 0.016 3 μD
      τm估计值 56 68
      Df估计值 2.6 2.8
      注:据Kuila and Prasad(2013).
      下载: 导出CSV

      表  2  示例模型中所用的属性

      Table  2.   Properties used in the sample model

      属性 数值
      孔隙尺寸分布 图 4
      孔隙度φm 0.1
      体积TOC 12.00%
      平均压力 10 MPa
      τm 10
      Df 2.2
      下载: 导出CSV

      表  4  天然裂缝的属性

      Table  4.   The properties of natural fractures

      参数 数值
      平均走向 北偏东60°
      Fisher常数K 120
      最小天然裂缝长度lmin 20 μm
      最大天然裂缝长度lmax 60 μm
      天然裂缝条数nf 2
      幂律分布指数α 0.8
      孔隙度φf 0.002
      迂曲度τf 1
      开度h 1 μm
      下载: 导出CSV
    • [1] Agrawal, A., Prabhu, S.V., 2008.Survey on Measurement of Tangential Momentum Accommodation Coefficient.Journal of Vacuum Science & Technology A:Vacuum, Surfaces, and Films, 26(4):634-645.doi: 10.1116/1.2943641
      [2] Akkutlu, I.Y., Fathi, E., 2012.Multiscale Gas Transport in Shales with Local Kerogen Heterogeneities.SPE Journal, 17(4):1002-1011.doi: 10.2118/146422-pa
      [3] Cai, J.C., Sun, S.Y., 2013.Fractal Analysis of Fracture Increasing Spontaneous Imbibition in Porous Media with Gas-Saturated.International Journal of Modern Physics C, 24(8):1350056.doi:org/ 10.1142/S0129183113500563.
      [4] Cai, J.C., Wei, W., Hu, X.Y., et al., 2017.Fractal Characterization of Dynamic Fracture Network Extension in Porous Media.Fractals, 25(2):1750023.doi:10.1142/S0218348X17500232" target="_blank">http:org/ 10.1142/S0218348X17500232
      [5] Civan, F., 2010.Effective Correlation of Apparent Gas Permeability in Tight Porous Media.Transport in Porous Media, 82(2):375-384.doi: 10.1007/s11242-009-9432-z
      [6] Darabi, H., Ettehad, A., Javadpour, F., et al., 2012.Gas Flow in Ultra-Tight Shale Strata.Journal of Fluid Mechanics, 710:641-658.doi: 10.1017/jfm.2012.424
      [7] Gale, J.F.W., Laubach, S.E., Olson, J.E., et al., 2014.Natural Fractures in Shale:A Review and New Observations.AAPG Bulletin, 98(11):2165-2216.doi: 10.1306/08121413151
      [8] Grad, H., 1949.On the Kinetic Theory of Rarefied Gases.Communications on Pure and Applied Mathematics, 2(4):331-407.doi: 10.1002/cpa.3160020403
      [9] Javadpour, F., 2009.Nanopores and Apparent Permeability of Gas Flow in Mudrocks (Shales and Siltstone).Journal of Canadian Petroleum Technology, 48(8):16-21.doi: 10.2118/09-08-16-da
      [10] Javadpour, F., McClure, M., Naraghi, M.E., 2015.Slip-Corrected Liquid Permeability and Its Effect on Hydraulic Fracturing and Fluid Loss in Shale.Fuel, 160:549-559.doi: 10.1016/j.fuel.2015.08.017
      [11] Jendele, L., Kutilek, M., 2005.Parameters Fitting of Soil Hydraulic Functions:Lognormal Pore Size Distribution in Bi-Modal Soils.Geophysical Research Abstracts, 7:02002.
      [12] Kang, Y.S., Deng, Z., Wang, H.Y., et al., 2016.Fluid-Solid Coupling Physical Experiments and Their Implications for Fracturing Stimulations of Shale Gas Reservoirs.Earth Science, 41(8):1376-1383 (in Chinese with English abstract). http://www.en.cnki.com.cn/Article_en/CJFDTotal-DQKX201608009.htm
      [13] Kazemi, M., Takbiri-Borujeni, A., 2015.An Analytical Model for Shale Gas Permeability.International Journal of Coal Geology, 146:188-197.doi: 10.1016/j.coal.2015.05.010
      [14] Kuila, U., Prasad, M., 2013.Specific Surface Area and Pore-Size Distribution in Clays and Shales.Geophysical Prospecting, 61(2):341-362.doi: 10.1111/1365-2478.12028
      [15] Kutílek, M., Jendele, L., Panayiotopoulos, K.P., 2006.The Influence of Uniaxial Compression upon Pore Size Distribution in Bi-Modal Soils.Soil and Tillage Research, 86(1):27-37.doi: 10.1016/j.still.2005.02.001
      [16] Li, L.Y., Lee, S.H., 2008.Efficient Field-Scale Simulation of Black Oil in a Naturally Fractured Reservoir through Discrete Fracture Networks and Homogenized Media.SPE Reservoir Evaluation & Engineering, 11(4):750-758.doi: 10.2118/103901-pa
      [17] Li, S.F., Wang, S.L., Bi, J.X., 2016.Characteristics of Xujiahe Formation Source Rock and Process of Hydrocarbon-Generation Evolution in Puguang Area.Earth Science, 41(5):843-852 (in Chinese with English abstract). http://www.en.cnki.com.cn/Article_en/CJFDTotal-DQKX201605010.htm
      [18] Loucks, R.G., Reed, R.M., Ruppel, S.C., et al., 2012.Spectrum of Pore Types and Networks in Mudrocks and a Descriptive Classification for Matrix-Related Mudrock Pores.AAPG Bulletin, 96(6):1071-1098.doi: 10.1306/08171111061
      [19] Loucks, R.G., Reed, R.M., Ruppel, S.C., Hammes, U., 2010.Preliminary Classification of Matrix Pores in Mudrocks.Gulf Coast Association of Geological Societies Transactions, 60:435-441.
      [20] McCain Jr, W.D., 1991.Reservoir-Fluid Property Correlations—State of the Art.SPE Reservoir Engineering, 6(2):266-272.doi:org/ 10.2118/18571-PA
      [21] Naraghi, M.E., Javadpour, F., 2015.A Stochastic Permeability Model for the Shale-Gas Systems.International Journal of Coal Geology, 140:111-124.doi: 10.1016/j.coal.2015.02.004
      [22] Shakiba, M., Sepehrnoori, K., 2015.Using Embedded Discrete Fracture Model (EDFM) and Microseismic Monitoring Data to Characterize the Complex Hydraulic Fracture Networks.SPE Annual Technical Conference and Exhibition, Dubai.
      [23] Singh, H., Javadpour, F., Ettehadtavakkol, A., et al., 2014.Nonempirical Apparent Permeability of Shale.SPE Reservoir Evaluation & Engineering, 17(3):414-424.doi: 10.2118/170243-pa
      [24] Sun, J.L., Gamboa, E.S., Schechter, D., et al., 2016.An Integrated Workflow for Characterization and Simulation of Complex Fracture Networks Utilizing Microseismic and Horizontal Core Data.Journal of Natural Gas Science and Engineering, 34:1347-1360.doi: 10.1016/j.jngse.2016.08.024
      [25] Vafaie, A., Habibnia, B., Moallemi, S.A., 2015.Experimental Investigation of the Pore Structure Characteristics of the Garau Gas Shale Formation in the Lurestan Basin, Iran.Journal of Natural Gas Science and Engineering, 27:432-442.doi: 10.1016/j.jngse.2015.06.029
      [26] Wang, S., Feng, Q.H., Javadpour, F., et al., 2016a.Breakdown of Fast Mass Transport of Methane through Calcite Nanopores.The Journal of Physical Chemistry C, 120(26):14260-14269.doi: 10.1021/acs.jpcc.6b05511
      [27] Wang, S., Javadpour, F., Feng, Q.H., 2016b.Confinement Correction to Mercury Intrusion Capillary Pressure of Shale Nanopores.Scientific Reports, 6:20160.doi: 10.1038/srep20160
      [28] Wang, S., Javadpour, F., Feng, Q.H., 2016c.Fast Mass Transport of Oil and Supercritical Carbon Dioxide through Organic Nanopores in Shale.Fuel, 181:741-758.doi: 10.1016/j.fuel.2016.05.057
      [29] Wu, S.T., Zou, C.N., Zhu, R.K.et al., 2015.Reservoir Quality Characterization of Upper Triassic Chang 7 Shale in Ordos Basin.Earth Science, 40(11):1810-1823 (in Chinese with English abstract). http://www.en.cnki.com.cn/Article_en/CJFDTotal-DQKX201511004.htm
      [30] Xu, Y.F., 2015.Implementation and Application of the Embedded Discrete Fracture Model (EDFM) for Reservoir Simulation in Fractured Reservoirs (Dissertation).University of Texas at Austin, Austin.
      [31] Xu, Y.F., CavalcanteFilho, J.S.A., Yu, W., et al.2016.Discrete-Fracture Modeling of Complex Hydraulic-Fracture Geometries in Reservoir Simulators.SPE Reservoir Evaluation & Engineering, 20(2):SPE-183647-PA.doi: org/10.2118/183647-PA
      [32] Yang, F., Ning, Z.F., Hu, C.P., et al., 2013a.Characterization of Microscopic Pore Structures in Shale Reservoirs.ActaPetroleiSinica, 34(2):301-311 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SYXB201302013.htm
      [33] Yang, F., Ning, Z.F., Kong, D.T., et al., 2013b.Pore Structure of Shale from High Pressure Mercury Injection and Nitrogen Adsorption Method.Natural Gas Geoscience, 24(3):450-455 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-TDKX201303002.htm
      [34] Yang, Y.F., Wang C.C., Yao, J., et al., 2016.A New Method for Microscopic Pore Structure Analysis in Shale Matrix.Earth Science, 41(6):1067-1073 (in Chinese with English abstract).
      [35] Zhang, L.H., Li, J.Y., Li, Z., et al., 2105.Development Characteristics and Formation Mechanism of Intra-Organic Reservoir Space in Lacustrine Shales.Earth Science, 40(11):1824-1833 (in Chinese with English abstract). http://europepmc.org/articles/PMC5024126/
      [36] Zuloaga-Molero, P., Yu, W., Xu, Y., et al., 2016.Simulation Study of CO2-EOR in Tight Oil Reservoirs with Complex Fracture Geometries.Scientific Reports, 6:33445.doi: 10.1038/srep33445
      [37] 康永尚, 邓泽, 王红岩, 等, 2016.流-固耦合物理模拟实验及其对页岩压裂改造的启示.地球科学, 41(8): 1376-1383. http://earth-science.net/WebPage/Article.aspx?id=3344
      [38] 李松峰, 王生朗, 毕建霞, 等, 2016.普光地区须家河组烃源岩特征及成烃演化过程.地球科学, 41(5): 843-852. http://earth-science.net/WebPage/Article.aspx?id=3306
      [39] 吴松涛, 邹才能, 朱如凯, 等, 2015.鄂尔多斯盆地上三叠统长7段泥页岩储集性能.地球科学, 40(11): 1810-1823. http://earth-science.net/WebPage/Article.aspx?id=3188
      [40] 杨峰, 宁正福, 胡昌蓬, 等, 2013a.页岩储层微观孔隙结构特征.石油学报, 34(2): 301-311. http://www.cnki.com.cn/Article/CJFDTOTAL-CDLG201603007.htm
      [41] 杨峰, 宁正福, 孔德涛, 等, 2013b.高压压汞法和氮气吸附法分析页岩孔隙结构.天然气地球科学, 24(3): 450-455. http://www.cnki.com.cn/Article/CJFDTOTAL-TDKX201303002.htm
      [42] 杨永飞, 王晨晨, 姚军, 等, 2016.页岩基质微观孔隙结构分析新方法.地球科学, 41(6): 1067-1073. doi: 10.11764/j.issn.1672-1926.2016.06.1067
      [43] 张林晔, 李钜源, 李政, 等, 2015.湖相页岩有机储集空间发育特点与成因机制.地球科学, 40(11): 1824-1833. http://earth-science.net/WebPage/Article.aspx?id=3189
