内蒙古北山造山带花岗岩地球化学、锆石U-Pb年龄和Hf同位素特征及地质意义

李敏; 任邦方; 滕学建; 张永; 段霄龙; 牛文超; 段连峰

doi:10.3799/dqkx.2017.598

内蒙古北山造山带花岗岩地球化学、锆石U-Pb年龄和Hf同位素特征及地质意义

doi: 10.3799/dqkx.2017.598

中国地质调查局天津地质调查中心, 天津 300170

基金项目:

中国地质调查局项目 12120114064601

中国地质调查局项目 121201006000172601

详细信息

作者简介:
李敏(1986-), 男, 工程师, 主要研究方向为岩石地球化学和构造地质学

中图分类号: P595
计量
- 文章访问数: 6373
- HTML全文浏览量: 1979
- PDF下载量: 62
- 被引次数: 0
出版历程
- 收稿日期: 2017-12-06
- 刊出日期: 2018-12-15

Geochemical Characteristics, Zircon U-Pb Age and Hf Isotope and Geological Significance of Granitoid in Beishan Orogenic Belt

Tianjin Center of Geological Survey, China Geological Survey, Tianjian 300170, China

摘要

摘要: 砾石滩地区位于内蒙古额济纳旗西部，晚古生代花岗岩出露广泛，是研究北山造山带晚古生代地质演化的关键地区.锆石LA-MC-ICP-MS U-Pb测年结果显示，该地区的花岗岩形成于晚石炭世，其中英云闪长岩年龄为310.8±1.4 Ma，花岗闪长岩年龄为310.3±1.4 Ma和306.0±1.2 Ma，二长花岗岩年龄为308.7±1.4 Ma.岩石学及化学成分显示其为准铝质-弱过铝质、中钾钙碱性系列岩石；稀土配分曲线呈现轻稀土元素相对富集的右倾分布特征，弱负铕异常（δEu为0.7~0.9）；岩石富集大离子亲石元素Rb、K等，具有负的Nb、Ta和Ti异常；英云闪长岩、花岗闪长岩具有不均一的ε_Hf（t）值（3.8~14.8）、（7.3~14.0），二阶段Hf同位素模式年龄t_DM^C分别为378~1 083 Ma、433~868 Ma.北山造山带北部晚石炭世英云闪长岩、花岗闪长岩、二长花岗岩的形成与壳幔混合有关，产生于大洋岩石圈俯冲过程中，形成于陆缘弧环境，该过程诱发了地幔对流，因而产生了幔源岩浆底侵，并将元古宙基底岩石熔融，壳幔混合之后形成晚石炭世大规模花岗岩类.
- 北山造山带 /
- 晚石炭世 /
- 构造环境 /
- 锆石LA-MC-ICP-MS U-Pb年龄 /
- 锆石Hf同位素 /
- 地球化学
Abstract: Lishitan area is located in west of Ejin County of Inner Mongolia, where Late Paleozoic granitoid is exposed in a wide range. And it's a key area to the geology evolution research of Beishan orogenic belt in Late Paleozoic. The zircon LA-MC-ICP-MS U-Pb dating results show that the granitoid in this area was formed in the Late Carboniferous, the tonalite was formed at 310.8±1.4 Ma, the granodiorite was formed at 310.3±1.4 Ma, 306.0±1.2 Ma respectively, and the monzonitic granite was formed at 308.7±1.4 Ma. The petrology and lithochemistry demonstrate that the tonalite, granodiorite and monzonitic granite belong to quasi-aluminous to weakly peraluminous rocks and middle-K calc-alcaline series. The tonalite, granodiorite and monzonitic granite are enriched in LREE and part of large iron lithophile elements, including Rb, K et al., relatively depleted in HREE, Nb, Ta and Ti with weakly negative europium anomaly (δEu is 0.7-0.9).The ε_Hf(t) values of tonalite and granodiorite are variable, ranging from 3.8 to 14.8 and 7.3 to 14.0 respectively. And the two stage Hf isotope model ages (t_DM^C) range from 378 to 1 083 Ma and from 433 to 868 Ma respectively. The formation of tonalite, granodiorite and monzonitic granite is related with crust-mantle mixing, which were formed in the active epicontinental arc environment in the process of the ocean lithosphere subduction in Northern Beishan orogenic belt in Late Carboniferous. Mantle convection was caused by the process, thus led to mantle-derived magma invasion, which melted the Proterozoic basement rocks, and massive granitoids formed after crust-mantle mixing in Late Carboniferous.
- Beishan orogenic belt /
- Late Carboniferous /
- tectonic setting /
- LA-MC-ICP-MS zircon U-Pb age /
- zircon Hf isotope /
- geochemistry

HTML全文

图 1 额济纳旗砾石滩地区地质简图

1.下石炭统绿条山组；2.下石炭统白山组；3.流纹岩；4.晚石炭世英云闪长岩；5.晚石炭世花岗闪长岩；6.晚石炭世二长花岗岩；7.二叠纪花岗岩；8.第四系；9.地质界线；10.采样位置；11.缝合带；12.构造分区界线；13.国界；14.上白垩统赤金堡组

Fig. 1. Geological sketch map of Lishitan area in Ejina county

下载: 全尺寸图片幻灯片

图 2 镁铁质包体

Fig. 2. Mafic inclusions

下载: 全尺寸图片幻灯片

图 3 研究区花岗岩类野外与显微照片

a.英云闪长岩；b.英云闪长岩偏光显微照片；c.二长花岗岩侵入花岗闪长岩；d.花岗闪长岩偏光显微照片；e.二长花岗岩；f.二长花岗岩偏光显微照片

Fig. 3. Field photos and photomicrographs of granitoids in the study area

下载: 全尺寸图片幻灯片

图 4 砾石滩地区花岗岩类部分锆石阴极发光图像及年龄

黄圈为U-Pb测点，蓝圈为Hf同位素测点

Fig. 4. CL image and dating of zircons for granitoids in Lishitan area

下载: 全尺寸图片幻灯片

图 5 砾石滩地区花岗岩类LA-MC-ICP-MS锆石U-Pb年龄谐和图

Fig. 5. Zircon LA-MC-ICP-MS U-Pb concordia diagrams of granitoids in Lishitan area

下载: 全尺寸图片幻灯片

图 6 砾石滩地区花岗岩类K₂O-SiO₂图解(a)和A/CNK-A/NK图解(b)

b.据Peccerillo and Taylor(1976)

Fig. 6. Diagrams of K₂O versus SiO₂ (a) and A/CNK-A/NK (b) of granitoids in Lishitan area

下载: 全尺寸图片幻灯片

图 7 砾石滩地区花岗岩类稀土元素球粒陨石标准化配分模式图(a)和原始地幔标准化微量元素蛛网图(b)

球粒陨石标准化值、原始地幔标准化值据Sun and McDonough(1989)

Fig. 7. Chondrite-normalized REE patterns (a) and primitive mantle-normalized trace element patterns (b) of granitoids in Lishitan area

下载: 全尺寸图片幻灯片

图 8 砾石滩地区花岗岩类构造判别图解

a.(Y+Nb)-Rb判别图, 据Pearce et al.(1984)；ORG.大洋脊花岗岩；WPG.板内花岗岩；VAG.火山弧花岗岩；syn-COLG.同碰撞花岗岩；b.R1-R2判别图, 据Batchelor and Bowden(1985), R1=4Si-11(Na+K)-2(Fe+Ti)，R2=6Ca+2Mg+Al

Fig. 8. Tectonic discrimination diagrams of granitoids in Lishitan area

下载: 全尺寸图片幻灯片

图 9 砾石滩地区英云闪长岩、花岗闪长岩的锆石Hf同位素时间演化图解

Fig. 9. Zircon Hf isotope time evolution diagram of the tonalite and granodiorite in Lishitan area

下载: 全尺寸图片幻灯片

表 1 砾石滩地区花岗岩LA-MC-ICP-MS U-Pb同位素分析结果

Table 1. Zircon LA-MC-ICP-MS U-Pb dating results of granitoids in Lishitan area

样品号	含量(10^-6)		同位素比值										表面年龄(Ma)
02TW1	Pb	U	²⁰⁶Pb/²³⁸U	1σ	²⁰⁷Pb/²³⁵U	1σ	²⁰⁷Pb/²⁰⁶Pb	1σ	²⁰⁸Pb/²³²Th	1σ	²³²Th/²³⁸U	1σ	²⁰⁶Pb/²³⁸U	1σ	²⁰⁷Pb/²³⁵U	1σ	²⁰⁷Pb/²⁰⁶Pb	1σ
1	4	76	0.049 6	0.000 6	0.357 3	0.024 9	0.052 2	0.003 7	0.012 8	0.000 3	0.396 0	0.000 9	312	4	310	22	296	161
2	4	77	0.049 3	0.000 7	0.362 5	0.045 7	0.053 3	0.006 8	0.012 2	0.000 5	0.531 5	0.001 1	310	4	314	40	343	287
3	5	98	0.048 8	0.000 6	0.353 1	0.015 9	0.052 5	0.002 4	0.013 0	0.000 3	0.386 1	0.000 5	307	4	307	14	307	103
4	4	86	0.049 7	0.000 5	0.359 4	0.020 1	0.052 4	0.002 9	0.014 1	0.000 3	0.378 8	0.000 6	313	3	312	17	303	126
5	6	117	0.049 8	0.000 5	0.360 3	0.016 2	0.052 5	0.002 3	0.013 3	0.000 2	0.400 5	0.000 3	313	3	312	14	308	101
6	5	108	0.049 5	0.000 5	0.356 3	0.015 6	0.052 2	0.002 3	0.013 8	0.000 2	0.360 8	0.000 6	312	3	309	14	293	99
7	6	114	0.049 6	0.000 5	0.359 8	0.019 9	0.052 6	0.002 9	0.012 3	0.000 2	0.435 7	0.001 3	312	3	312	17	311	125
8	6	127	0.049 3	0.000 5	0.362 1	0.014 9	0.053 3	0.002 1	0.012 4	0.000 2	0.396 4	0.000 8	310	3	314	13	341	90
9	4	77	0.049 4	0.000 6	0.362 8	0.028 7	0.053 3	0.004 3	0.010 7	0.000 4	0.369 4	0.000 6	311	4	314	25	343	181
10	6	127	0.049 5	0.000 5	0.362 2	0.013 8	0.053 1	0.002 0	0.013 8	0.000 2	0.445 4	0.001 5	311	3	314	12	331	86
11	4	92	0.048 0	0.000 6	0.348 3	0.023 3	0.052 6	0.003 5	0.015 3	0.000 4	0.341 2	0.001 3	303	4	303	20	310	154
12	6	121	0.049 2	0.000 5	0.361 3	0.018 0	0.053 3	0.002 6	0.014 7	0.000 4	0.354 3	0.000 9	309	3	313	16	341	109
13	4	82	0.049 2	0.000 6	0.364 1	0.025 0	0.053 7	0.003 9	0.014 1	0.000 3	0.455 5	0.000 7	309	4	315	22	358	163
14	6	115	0.049 6	0.000 6	0.364 3	0.021 9	0.053 3	0.003 4	0.014 3	0.000 2	0.636 3	0.004 2	312	4	315	19	341	145
15	4	84	0.049 9	0.000 6	0.360 3	0.021 6	0.052 3	0.003 2	0.013 9	0.000 3	0.395 1	0.000 6	314	4	312	19	300	139
16	6	117	0.049 4	0.000 5	0.362 5	0.017 8	0.053 2	0.002 7	0.014 6	0.000 2	0.446 1	0.000 9	311	3	314	15	336	114
17	5	101	0.049 8	0.000 5	0.361 4	0.022 9	0.052 6	0.003 3	0.015 7	0.000 3	0.514 7	0.003 0	314	3	313	20	311	144
18	4	71	0.049 0	0.000 6	0.360 2	0.041 3	0.053 3	0.006 4	0.015 5	0.000 7	0.385 8	0.000 8	309	4	312	36	340	270
19	4	73	0.049 2	0.000 6	0.357 8	0.026 6	0.052 7	0.004 5	0.014 9	0.000 4	0.482 5	0.001 2	310	4	311	23	318	194
20	5	97	0.049 4	0.000 5	0.360 5	0.024 3	0.053 0	0.003 6	0.007 3	0.000 4	0.461 0	0.000 4	311	3	313	21	327	153
21	6	115	0.049 6	0.000 5	0.361 0	0.015 4	0.052 8	0.002 3	0.014 3	0.000 2	0.510 3	0.000 4	312	3	313	13	321	100
22	7	132	0.049 6	0.000 6	0.362 7	0.013 3	0.053 0	0.001 9	0.015 3	0.000 2	0.593 8	0.003 2	312	4	314	12	328	83
23	7	132	0.049 6	0.000 6	0.360 2	0.013 2	0.052 7	0.001 9	0.014 6	0.000 2	0.489 7	0.001 9	312	4	312	11	315	81
24	20	372	0.049 6	0.000 6	0.362 1	0.007 0	0.053 0	0.000 9	0.015 3	0.000 1	0.577 6	0.004 0	312	4	314	6	328	39
25	9	167	0.048 9	0.000 5	0.358 0	0.012 7	0.053 1	0.001 9	0.014 8	0.000 2	0.504 6	0.002 2	308	3	311	11	334	79

样品号	含量(10^-6)		同位素比值										表面年龄(Ma)
06TW27	Pb	U	²⁰⁶Pb/²³⁸U	1σ	²⁰⁷Pb/²³⁵U	1σ	²⁰⁷Pb/²⁰⁶Pb	1σ	²⁰⁸Pb/²³²Th	1σ	²³²Th/²³⁸U	1σ	²⁰⁶Pb/²³⁸U	1σ	²⁰⁷Pb/²³⁵U	1σ	²⁰⁷Pb/²⁰⁶Pb	1σ
1	12	213	0.049 9	0.000 5	0.363 4	0.008 3	0.052 8	0.001 1	0.014 8	0.000 1	0.768 6	0.004 8	314	3	315	7	322	48
2	8	153	0.049 9	0.000 5	0.363 9	0.011 2	0.052 9	0.001 7	0.013 7	0.000 1	0.825 3	0.003 0	314	3	315	10	323	72
3	6	108	0.049 5	0.000 6	0.358 8	0.018 6	0.052 5	0.002 7	0.013 3	0.000 2	1.050 4	0.005 7	312	4	311	16	309	117
4	8	145	0.049 4	0.000 5	0.358 7	0.012 8	0.052 6	0.001 8	0.013 5	0.000 1	0.934 0	0.003 4	311	3	311	11	312	79
5	10	189	0.049 7	0.000 5	0.359 7	0.008 2	0.052 5	0.001 1	0.013 6	0.000 1	0.853 3	0.005 5	312	3	312	7	308	49
6	9	159	0.049 6	0.000 5	0.359 4	0.016 4	0.052 5	0.002 4	0.013 6	0.000 1	0.881 1	0.003 3	312	3	312	14	309	106
7	9	167	0.049 4	0.000 5	0.358 4	0.008 5	0.052 6	0.001 2	0.013 8	0.000 1	0.970 4	0.001 7	311	3	311	7	312	52
8	8	145	0.049 3	0.000 5	0.356 8	0.018 1	0.052 5	0.002 7	0.013 9	0.000 2	1.031 4	0.004 3	310	3	310	16	308	116
9	12	206	0.049 4	0.000 5	0.359 7	0.007 7	0.052 9	0.001 1	0.016 5	0.000 1	0.790 6	0.001 2	311	3	312	7	323	46
10	12	210	0.049 0	0.000 5	0.353 8	0.010 7	0.052 4	0.001 5	0.018 3	0.000 2	0.835 4	0.004 1	308	3	308	9	301	64
11	16	268	0.049 3	0.000 5	0.356 8	0.006 4	0.052 5	0.000 9	0.018 8	0.000 1	0.797 3	0.002 1	310	3	310	6	308	37
12	8	138	0.049 5	0.000 6	0.358 8	0.011 9	0.052 6	0.001 7	0.020 3	0.000 3	0.525 2	0.001 3	311	4	311	10	313	73
13	15	253	0.049 1	0.000 5	0.355 4	0.008 5	0.052 5	0.001 2	0.020 7	0.000 1	0.798 3	0.000 4	309	3	309	7	307	52
14	18	313	0.046 3	0.000 5	0.455 1	0.008 1	0.071 3	0.001 2	0.024 4	0.000 1	0.722 6	0.002 2	292	3	381	7	966	33
15	12	197	0.048 9	0.000 5	0.354 7	0.017 9	0.052 6	0.002 6	0.022 9	0.000 5	0.804 5	0.002 2	308	3	308	16	311	111
16	7	115	0.049 4	0.000 5	0.358 3	0.011 2	0.052 6	0.001 6	0.025 6	0.000 2	0.669 7	0.001 1	311	3	311	10	312	70
17	12	179	0.049 1	0.000 5	0.355 4	0.010 6	0.052 5	0.001 5	0.025 8	0.000 3	0.871 6	0.000 8	309	3	309	9	308	64
18	15	251	0.049 4	0.000 5	0.358 7	0.007 8	0.052 6	0.001 1	0.021 6	0.000 1	0.698 9	0.001 8	311	3	311	7	312	47
19	11	180	0.049 2	0.000 5	0.356 8	0.009 6	0.052 7	0.001 4	0.019 6	0.000 1	0.855 0	0.000 9	309	3	310	8	314	60
20	17	371	0.037 2	0.000 4	0.419 0	0.006 6	0.081 7	0.001 2	0.021 4	0.000 1	0.603 7	0.002 5	235	2	355	6	1239	29
21	9	166	0.049 4	0.000 6	0.360 3	0.013 2	0.052 9	0.001 9	0.019 5	0.000 3	0.716 3	0.008 5	311	4	312	11	326	82
22	12	206	0.048 8	0.000 5	0.352 4	0.006 9	0.052 3	0.001 0	0.017 2	0.000 1	0.842 3	0.001 9	307	3	307	6	299	42
23	8	154	0.039 2	0.000 5	0.629 0	0.016 6	0.116 3	0.002 8	0.023 2	0.000 2	0.714 0	0.001 3	248	3	495	13	1900	44
24	17	310	0.048 7	0.000 5	0.352 9	0.007 3	0.052 5	0.001 0	0.016 2	0.000 1	0.822 3	0.004 4	307	3	307	6	308	45

样品号	含量(10^-6)		同位素比值										表面年龄(Ma)
16TW10	Pb	U	²⁰⁶Pb/²³⁸U	1σ	²⁰⁷Pb/²³⁵U	1σ	²⁰⁷Pb/²⁰⁶Pb	1σ	²⁰⁸Pb/²³²Th	1σ	²³²Th/²³⁸U	1σ	²⁰⁶Pb/²³⁸U	1σ	²⁰⁷Pb/²³⁵U	1σ	²⁰⁷Pb/²⁰⁶Pb	1σ
1	10	196	0.048 6	0.000 5	0.353 7	0.007 2	0.052 8	0.001 0	0.015 8	0.000 1	0.596 1	0.002 9	306	3	308	6	320	44
2	13	237	0.048 3	0.000 5	0.349 0	0.007 7	0.052 4	0.001 1	0.015 9	0.000 1	0.674 0	0.002 6	304	3	304	7	304	49
3	10	203	0.048 6	0.000 5	0.353 6	0.008 9	0.052 7	0.001 3	0.015 3	0.000 1	0.526 5	0.000 9	306	3	307	8	317	55
4	12	230	0.048 2	0.000 5	0.350 9	0.006 7	0.052 8	0.001 0	0.015 3	0.000 0	0.714 9	0.000 7	304	3	305	6	319	41
5	12	213	0.048 5	0.000 5	0.353 3	0.007 3	0.052 8	0.001 0	0.015 6	0.000 1	0.753 1	0.001 5	305	3	307	6	322	45
6	10	198	0.048 5	0.000 5	0.351 5	0.007 1	0.052 6	0.001 0	0.015 7	0.000 1	0.637 1	0.000 7	305	3	306	6	310	44
7	16	312	0.048 6	0.000 5	0.351 0	0.005 8	0.052 3	0.000 8	0.016 0	0.000 1	0.476 4	0.001 8	306	3	306	5	301	34
8	9	182	0.048 6	0.000 5	0.352 0	0.008 8	0.052 5	0.001 2	0.015 8	0.000 1	0.532 5	0.001 9	306	3	306	8	309	54
9	12	234	0.048 4	0.000 5	0.351 8	0.006 3	0.052 7	0.000 9	0.015 9	0.000 1	0.648 6	0.002 7	305	3	306	6	316	39
10	9	181	0.048 6	0.000 5	0.350 9	0.008 5	0.052 4	0.001 2	0.016 0	0.000 1	0.473 2	0.002 9	306	3	305	7	303	53
11	4	80	0.048 7	0.000 5	0.354 0	0.015 0	0.052 7	0.002 2	0.016 3	0.000 2	0.479 7	0.001 4	307	3	308	13	316	96
12	8	156	0.048 7	0.000 5	0.353 3	0.009 9	0.052 7	0.001 4	0.016 0	0.000 1	0.557 7	0.002 7	306	3	307	9	315	62
13	16	311	0.048 9	0.000 5	0.354 4	0.006 1	0.052 6	0.000 9	0.015 4	0.000 1	0.558 3	0.002 6	308	3	308	5	311	37
14	10	192	0.048 8	0.000 5	0.353 5	0.007 9	0.052 5	0.001 1	0.015 0	0.000 1	0.486 3	0.001 0	307	3	307	7	307	49
15	9	186	0.048 7	0.000 5	0.351 2	0.008 6	0.052 3	0.001 2	0.014 5	0.000 1	0.512 7	0.002 2	306	3	306	7	300	52
16	9	186	0.048 7	0.000 5	0.354 0	0.007 5	0.052 7	0.001 1	0.013 2	0.000 1	0.439 7	0.002 2	307	3	308	6	316	46
17	13	257	0.048 5	0.000 5	0.352 1	0.006 1	0.052 6	0.000 8	0.013 1	0.000 1	0.507 7	0.002 8	306	3	306	5	312	36
18	15	295	0.048 8	0.000 5	0.353 8	0.005 7	0.052 6	0.000 8	0.013 4	0.000 1	0.479 5	0.002 1	307	3	308	5	310	34
19	13	252	0.048 2	0.000 5	0.353 4	0.006 0	0.053 2	0.000 9	0.012 3	0.000 0	0.521 5	0.001 4	304	3	307	5	336	36
20	14	272	0.049 1	0.000 5	0.356 0	0.005 8	0.052 6	0.000 8	0.012 9	0.000 0	0.544 8	0.001 4	309	3	309	5	311	34
21	15	272	0.048 8	0.000 5	0.352 6	0.007 4	0.052 4	0.001 0	0.013 1	0.000 0	0.866 5	0.001 1	307	3	307	6	303	45
22	22	396	0.048 6	0.000 5	0.352 4	0.005 1	0.052 6	0.000 7	0.012 5	0.000 0	0.920 0	0.002 1	306	3	307	4	313	30
23	12	234	0.048 8	0.000 5	0.354 5	0.006 2	0.052 7	0.000 8	0.013 2	0.000 0	0.625 2	0.000 5	307	3	308	5	316	36
24	13	242	0.048 6	0.000 5	0.352 6	0.005 9	0.052 6	0.000 8	0.013 5	0.000 0	0.745 9	0.002 1	306	3	307	5	311	36

样品号	含量(10^-6)		同位素比值										表面年龄(Ma)
14TW20	Pb	U	²⁰⁶Pb/²³⁸U	1σ	²⁰⁷Pb/²³⁵U	1σ	²⁰⁷Pb/²⁰⁶Pb	1σ	²⁰⁸Pb/²³²Th	1σ	²³²Th/²³⁸U	1σ	²⁰⁶Pb/²³⁸U	1σ	²⁰⁷Pb/²³⁵U	1σ	²⁰⁷Pb/²⁰⁶Pb	1σ
1	4	73	0.049 6	0.000 6	0.360 3	0.021 8	0.052 7	0.003 1	0.015 1	0.000 3	0.742 9	0.004 8	312	4	312	19	317	135
2	14	223	0.054 5	0.000 6	0.402 0	0.010 1	0.053 5	0.001 3	0.015 9	0.000 1	0.930 4	0.005 1	342	4	343	9	349	53
3	9	139	0.055 0	0.000 6	0.405 5	0.012 1	0.053 4	0.001 5	0.016 8	0.000 1	0.792 2	0.002 4	345	3	346	10	347	65
4	6	99	0.049 5	0.000 5	0.358 2	0.018 1	0.052 5	0.002 6	0.014 2	0.000 1	0.988 8	0.003 2	311	3	311	16	307	114
5	12	174	0.054 1	0.000 6	0.398 2	0.010 4	0.053 4	0.001 4	0.016 6	0.000 1	1.378 8	0.012 8	340	4	340	9	344	59
6	8	134	0.049 1	0.000 9	0.357 8	0.014 3	0.052 9	0.002 1	0.014 0	0.000 2	0.924 4	0.005 0	309	6	311	12	323	91
7	29	493	0.049 2	0.000 5	0.358 1	0.005 3	0.052 8	0.000 7	0.013 4	0.000 1	1.114 8	0.001 4	310	3	311	5	319	31
8	10	178	0.048 9	0.000 5	0.357 7	0.010 7	0.053 1	0.001 6	0.012 8	0.000 1	1.043 6	0.004 7	308	3	310	9	331	66
9	9	152	0.049 5	0.000 6	0.359 3	0.017 1	0.052 6	0.002 5	0.014 2	0.000 1	1.030 5	0.001 8	312	4	312	15	311	110
10	10	189	0.048 9	0.000 5	0.354 5	0.008 1	0.052 6	0.001 2	0.013 0	0.000 1	0.895 7	0.004 0	307	3	308	7	313	51
11	15	273	0.048 7	0.000 5	0.352 9	0.007 5	0.052 6	0.001 1	0.013 2	0.000 1	1.059 5	0.002 3	306	3	307	7	312	46
12	13	238	0.048 8	0.000 5	0.357 2	0.007 1	0.053 1	0.001 0	0.014 0	0.000 0	0.924 7	0.001 8	307	3	310	6	333	44
13	12	211	0.049 9	0.000 5	0.358 4	0.007 6	0.052 1	0.001 0	0.014 9	0.000 1	0.880 7	0.003 5	314	3	311	7	291	45
14	15	260	0.049 1	0.000 5	0.358 8	0.006 6	0.053 0	0.000 9	0.014 2	0.000 1	0.925 0	0.005 7	309	3	311	6	331	39
15	6	114	0.049 2	0.000 5	0.358 9	0.016 1	0.052 9	0.002 3	0.015 9	0.000 2	0.633 9	0.003 3	310	3	311	14	324	98
16	16	284	0.048 9	0.000 5	0.356 5	0.006 8	0.052 9	0.001 0	0.014 4	0.000 0	0.823 1	0.001 0	308	3	310	6	323	41
17	10	192	0.048 6	0.000 5	0.354 9	0.008 5	0.053 0	0.001 3	0.015 8	0.000 1	0.696 5	0.001 3	306	3	308	7	328	54
18	20	348	0.049 0	0.000 5	0.355 7	0.005 5	0.052 6	0.000 7	0.014 7	0.000 0	0.929 3	0.000 9	308	3	309	5	313	32
19	16	284	0.048 7	0.000 5	0.351 4	0.006 0	0.052 4	0.000 8	0.014 6	0.000 1	0.958 7	0.006 8	306	3	306	5	301	36
20	16	283	0.048 6	0.000 5	0.351 5	0.006 6	0.052 5	0.000 9	0.014 7	0.000 0	0.900 7	0.003 3	306	3	306	6	308	40
21	16	280	0.048 6	0.000 5	0.386 8	0.013 6	0.057 7	0.002 0	0.013 8	0.000 1	1.110 8	0.007 1	306	3	332	12	519	77
22	11	194	0.049 3	0.000 5	0.357 4	0.006 7	0.052 6	0.000 9	0.015 5	0.000 1	0.852 9	0.009 6	310	3	310	6	311	40
23	11	202	0.049 3	0.000 5	0.357 3	0.015 0	0.052 6	0.002 0	0.016 1	0.000 3	0.682 4	0.010 1	310	3	310	13	312	86
24	14	240	0.049 6	0.000 5	0.358 9	0.006 8	0.052 5	0.000 9	0.015 2	0.000 1	0.983 6	0.009 4	312	3	311	6	307	41
注：测试单位为天津地质矿产研究所实验室.

下载: 导出CSV

表 2 砾石滩地区花岗岩类主量元素(%)、微量元素(10^-6)分析结果

Table 2. Major (%) and trace element (10^-6) compositions of granitoids in Lishitan area

样号	英云闪长岩			花岗闪长岩1		花岗闪长岩2					二长花岗岩
样号	02.1	02.2	02.3	06.1	06.2	16.1	16.2	16.3	16.4	16.5	TW.1	TW.2
SiO₂	65.97	65.08	65.40	68.57	67.37	64.04	63.04	61.04	60.14	60.21	73.06	69.83
Al₂O₃	16.56	17.20	16.56	15.11	15.04	15.39	15.57	16.09	16.33	16.23	13.92	14.27
Fe₂O₃	1.04	1.02	1.12	2.02	2.57	2.65	3.29	3.28	3.26	2.86	1.85	1.83
FeO	2.00	2.20	2.03	1.40	1.53	2.55	2.46	3.01	3.25	3.48	0.52	1.22
CaO	4.91	4.07	4.92	3.39	3.78	4.28	4.61	5.45	5.66	6.16	1.83	2.84
MgO	2.50	2.85	2.58	1.18	1.43	2.36	2.49	2.93	3.04	2.96	0.51	0.86
K₂O	1.27	1.40	1.10	3.35	3.14	2.91	2.50	2.50	2.15	2.58	3.57	2.73
Na₂O	4.28	4.62	4.18	3.43	3.39	3.03	3.12	3.07	3.05	3.08	3.51	3.63
TiO₂	0.36	0.38	0.40	0.48	0.56	0.56	0.61	0.62	0.70	0.56	0.27	0.41
P₂O₅	0.098	0.100	0.095	0.120	0.140	0.130	0.140	0.140	0.140	0.140	0.060	0.100
MnO	0.058	0.058	0.054	0.079	0.090	0.100	0.110	0.110	0.120	0.120	0.050	0.080
FeO_T	2.94	3.12	3.04	3.22	3.84	4.94	5.42	5.96	6.18	6.05	2.19	2.87
Fe₂O_3T	3.26	3.47	3.38	3.58	4.27	5.48	6.02	6.63	6.87	6.73	2.43	3.19
Mg^#	64.10	65.72	64.04	43.47	43.83	50.07	49.06	50.75	50.76	50.63	32.86	38.61
AR	1.70	1.79	1.65	2.16	2.06	1.87	1.77	1.70	1.62	1.68	2.63	2.18
A/CNK	0.95	1.04	0.97	0.98	0.95	0.97	0.96	0.91	0.93	0.85	1.07	1.01
SI	22.54	23.57	23.43	10.37	11.86	17.48	17.97	19.81	20.61	19.79	5.12	8.37
FL	53.06	59.66	51.76	66.67	63.34	58.12	54.94	50.54	47.88	47.88	79.46	69.13
MF	54.87	53.05	54.97	74.35	74.14	68.78	69.78	68.22	68.17	68.17	82.29	78.01
δ	1.34	1.64	1.24	1.80	1.75	1.68	1.58	1.72	1.58	1.86	1.67	1.51
K₂O+Na₂O	5.55	6.02	5.28	6.78	6.53	5.94	5.62	5.57	5.20	5.66	7.08	6.36
K₂O/Na₂O	0.30	0.30	0.26	0.98	0.93	0.96	0.80	0.81	0.70	0.84	1.02	0.75
灼失量	0.72	0.76	1.33	0.71	0.80	1.73	1.80	1.42	1.80	1.22	0.90	2.17
Cr	45.60	50.30	42.70	3.63	3.83	10.10	11.40	15.70	12.00	17.80	2.94	2.54
Ni	45.60	52.50	45.00	2.36	2.58	8.70	9.25	11.30	12.10	12.20	1.59	1.38
Co	11.00	12.40	10.90	5.95	7.09	13.00	14.40	17.40	18.60	17.40	1.87	3.71
Rb	50.00	57.50	43.40	105.00	95.80	78.80	66.10	79.60	62.20	80.70	145.00	92.00
Cs	3.36	3.37	2.66	4.61	4.18	4.02	2.93	4.39	4.15	5.83	1.83	1.74
Sr	296	356	315	215	219	256	276	287	278	357	149	230
Ba	114	127	118	582	519	384	322	328	298	415	589	525
V	52.70	55.10	53.40	62.50	74.90	110.00	123.00	140.00	158.00	144.00	19.30	35.60
Sc	10.20	9.53	9.14	8.54	8.98	15.50	15.40	18.10	18.10	21.20	6.99	7.41
Nb	3.26	2.83	3.21	7.50	8.27	6.62	7.03	5.88	7.33	5.80	7.80	6.83
Ta	0.26	0.26	0.28	0.63	0.68	0.58	0.59	0.65	0.81	0.52	0.77	0.57
Zr	113.0	104.0	109.0	198.0	215.0	132.0	121.0	65.2	99.2	140.0	104.0	154.0
Hf	2.78	2.90	2.98	5.83	6.15	4.31	3.97	2.77	4.00	5.13	3.58	4.59
Ga	15.00	14.70	14.50	16.00	16.20	16.00	16.70	17.10	17.80	17.00	13.20	14.40
U	0.46	0.51	0.47	2.18	2.30	1.63	1.87	2.14	3.23	1.87	1.17	1.78
Th	3.88	3.61	4.23	13.00	11.80	11.50	10.70	12.60	14.30	9.53	11.50	7.49
La	9.75	9.29	8.90	23.40	26.10	21.20	18.90	20.70	16.10	17.80	20.70	19.00
Ce	17.10	17.30	15.40	47.70	51.70	42.30	39.20	41.60	37.90	41.20	37.50	36.30
Pr	2.46	2.42	2.31	5.98	6.37	5.15	4.76	5.32	5.30	5.72	4.22	4.26
Nd	9.73	9.67	8.84	22.60	24.20	19.30	18.30	21.20	21.60	23.40	14.70	15.80
Sm	2.25	2.30	1.90	4.42	4.77	3.66	3.67	4.53	4.74	4.98	2.57	2.97
Eu	0.58	0.59	0.55	1.06	1.08	0.86	0.85	1.08	1.10	1.19	0.58	0.77
Gd	2.30	2.25	2.02	4.01	4.44	3.29	3.30	4.35	4.31	4.69	2.29	2.67
Tb	0.36	0.36	0.31	0.63	0.70	0.52	0.51	0.68	0.72	0.76	0.35	0.44
Dy	1.97	2.08	1.78	3.85	4.24	3.14	3.15	4.06	4.41	4.66	2.01	2.61
Ho	0.38	0.40	0.34	0.82	0.92	0.65	0.65	0.83	0.94	0.98	0.42	0.52
Er	1.08	1.11	0.95	2.36	2.62	1.84	1.86	2.43	2.65	2.81	1.34	1.67
Tm	0.16	0.17	0.15	0.36	0.41	0.28	0.29	0.37	0.41	0.44	0.22	0.27
Yb	1.07	1.11	0.97	2.47	2.76	1.89	1.92	2.47	2.82	2.94	1.70	2.03
Lu	0.16	0.18	0.15	0.40	0.44	0.30	0.30	0.38	0.44	0.46	0.29	0.34
Y	12.20	12.10	10.30	21.80	24.30	16.40	16.50	18.60	21.00	22.60	11.70	15.50
δEu	0.77	0.78	0.85	0.76	0.71	0.74	0.73	0.73	0.73	0.74	0.72	0.82
ΣREE	61.55	61.33	54.87	141.86	155.05	120.78	114.16	128.60	124.44	134.63	100.59	105.15
LREE/HREE	5.60	5.43	5.68	7.06	6.91	7.76	7.15	6.06	5.19	5.32	9.31	7.50
(La/Lu)_N	6.53	5.53	6.36	6.27	6.36	7.57	6.75	5.84	3.92	4.15	7.65	5.99
(La/Sm)_N	2.80	2.61	3.02	3.42	3.53	3.74	3.32	2.95	2.19	2.31	5.20	4.13
(Gd/Lu)_N	1.78	1.55	1.66	1.24	1.25	1.36	1.36	1.41	1.21	1.26	0.98	0.97
注：测试工作由天津地质矿产研究所完成，常量元素采用XRF测试，其中FeO采用氢氟酸、硫酸溶样、重铬酸钾滴定容量法，微量元素采用ICP-MS测试.

下载: 导出CSV

表 3 英云闪长岩(02TW1)、花岗闪长岩(7218)锆石Hf同位素数据

Table 3. Zircon Hf isotopic data of the tonalite (02TW1) and granodiorite (7218)

点号	t(Ma)	¹⁷⁶Yb/¹⁷⁷Hf	¹⁷⁶Lu/¹⁷⁷Hf	¹⁷⁶Hf/¹⁷⁷Hf	2σ	¹⁷⁶Hf/¹⁷⁷Hf_i	ε_Hf(0)	ε_Hf(t)	t_DM(Ma)	t_DM^C(Ma)
02TW1.1	312	0.032 3	0.000 7	0.282 866	0.000 028	0.282 862	3.3	10.0	542	685
02TW1.2	307	0.036 8	0.000 8	0.282 964	0.000 033	0.282 960	6.8	13.4	406	466
02TW1.3	313	0.047 8	0.001 0	0.282 804	0.000 034	0.282 798	1.1	7.8	636	831
02TW1.4	313	0.034 2	0.000 8	0.282 893	0.000 028	0.282 888	4.3	11.0	506	624
02TW1.5	310	0.039 0	0.000 9	0.282 803	0.000 031	0.282 797	1.1	7.7	635	833
02TW1.6	311	0.032 6	0.000 8	0.282 691	0.000 030	0.282 687	-2.9	3.8	790	1 083
02TW1.7	311	0.041 0	0.000 9	0.282 732	0.000 035	0.282 726	-1.4	5.2	736	993
02TW1.8	303	0.033 6	0.000 8	0.282 727	0.000 031	0.282 723	-1.6	4.9	740	1007
02TW1.9	309	0.054 9	0.001 4	0.282 950	0.000 034	0.282 942	6.3	12.8	433	506
02TW1.10	314	0.025 4	0.000 7	0.282 776	0.000 032	0.282 772	0.1	6.9	669	888
02TW1.11	312	0.055 3	0.001 7	0.283 100	0.000 028	0.283 091	11.6	18.1	218	163
02TW1.12	309	0.020 1	0.000 5	0.283 121	0.000 033	0.283 119	12.4	19.1	181	101
02TW1.13	311	0.027 4	0.000 9	0.283 211	0.000 036	0.283 206	15.5	22.2	56	-101
02TW1.14	310	0.035 3	0.000 9	0.282 956	0.000 027	0.282 950	6.5	13.1	419	485
02TW1.15	311	0.020 1	0.000 6	0.282 972	0.000 023	0.282 968	7.1	13.8	393	444
02TW1.16	312	0.029 1	0.000 8	0.283 002	0.000 025	0.282 997	8.1	14.8	353	378
7218.1	318	0.035 4	0.001 0	0.282 837	0.000 020	0.282 831	2.3	9.1	589	753
7218.2	316	0.097 8	0.002 4	0.282 986	0.000 032	0.282 972	7.6	14.0	392	433
7218.3	317	0.086 9	0.002 3	0.282 879	0.000 026	0.282 865	3.8	10.3	548	675
7218.4	318	0.051 5	0.001 6	0.282 918	0.000 027	0.282 909	5.2	11.8	481	575
7218.5	318	0.084 9	0.002 6	0.282 824	0.000 025	0.282 808	1.8	8.3	634	803
7218.6	319	0.048 4	0.001 9	0.282 848	0.000 026	0.282 837	2.7	9.3	586	737
7218.7	318	0.064 7	0.002 0	0.282 824	0.000 023	0.282 812	1.8	8.4	623	794
7218.8	319	0.039 4	0.001 2	0.282 841	0.000 022	0.282 834	2.4	9.2	586	745
7218.9	319	0.055 4	0.001 8	0.282 890	0.000 023	0.282 880	4.2	10.8	523	640
7218.10	317	0.055 4	0.001 9	0.282 791	0.000 024	0.282 780	0.7	7.3	669	868
7218.11	318	0.073 6	0.002 1	0.282 830	0.000 025	0.282 818	2.1	8.6	616	782
7218.12	321	0.040 1	0.001 3	0.282 856	0.000 020	0.282 848	3.0	9.8	566	711
7218.13	320	0.045 7	0.001 2	0.282 865	0.000 022	0.282 858	3.3	10.1	552	689
7218.14	318	0.052 5	0.001 6	0.282 840	0.000 020	0.282 831	2.4	9.1	593	753
7218.15	317	0.049 3	0.001 4	0.282 933	0.000 025	0.282 924	5.7	12.4	458	541
7218.16	319	0.062 8	0.001 8	0.282 858	0.000 028	0.282 848	3.1	9.7	569	713
注：测试单位为天津地质矿产研究所实验室

下载: 导出CSV

参考文献(104)

Amelin, Y., Lee, D.C., Halliday, A.N., et al., 1999.Nature of the Earth's Earliest Crust from Hafnium Isotopes in Single Detrital Zircons. Nature, 399(6733):252-255. https://doi.org/10.1038/20426
Ao, S.J., Xiao, W.J., Han, C.M., et al., 2010.Geochronology and Geochemistry of Early Permian Mafic-Ultramafic Complexes in the Beishan Area, Xinjiang, NW China:Implications for Late Paleozoic Tectonic Evolution of the Southern Altaids. Gondwana Research, 18(2-3):466-478. https://doi.org/10.1016/j.gr.2010.01.004
Ao, S.J., Xiao, W.J., Han, C.M., et al., 2011.Cambrian to Early Silurian Ophiolite and Accretionary Processes in the Beishan Collage, NW China:Implications for the Architecture of the Southern Altaids. Geological Magazine, 149(4):606-625. https://doi.org/10.1017/S0016756811000884
Atherton, M.P., Petford, N., 1993.Generation of Sodium-Rich Magmas from Newly Underplated Basaltic Crust. Nature, 362(6416):144-146. https://doi.org/10.1038/362144a0
Barbarin, B., 1999.A Review of the Relationships between Granitoid Types, Their Origins and Their Geodynamic Environments. Lithos, 46(3):605-626. https://doi.org/10.1016/s0024-4937(98)00085-1
Batchelor, R.A., Bowden, P., 1985.Petrogenetic Interpretation of Granitoid Rock Series Using Multicationic Parameters. Chemical Geology, 48(1-4):43-55. https://doi.org/10.1016/0009-2541(85)90034-8
Belousova, E.A., Griffin, W.L., O'Reilly, S.Y., 2005.Zircon Crystal Morphology, Trace Element Signatures and Hf Isotope Composition as a Tool for Petrogenetic Modelling:Examples from Eastern Australian Granitoids. Journal of Petrology, 47(2):329-353 https://doi.org/10.1093/petrology/egi077
Bouvier, A., Vervoort, J.D., Patchett, P.J., 2008.The Lu-Hf and Sm-Nd Isotopic Composition of CHUR:Constraints from Unequilibrated Chondrites and Implications for the Bulk Composition of Terrestrial Planets. Earth and Planetary Science Letters, 273(1-2):48-57. https://doi.org/10.1016/j.epsl.2008.06.010
Cai, Z.H., Xu, Z.Q., He, B.Z., et al., 2012.Age and Tectonic Evolution of Ductile Shear Zones in the Eastern Tianshan-Beishan Orogenic Belt. Acta Petrologica Sinica, 28(6):1875-1895 (in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/ysxb98201206012
Dai, S., Fang, X.M., Zhang, X., et al., 2003.Island Arc North of the Tarim-SK Plate:The Geology and Geochemistry of Gongpoquan Group. Journal of Lanzhou University (Natural Sciences), 39(4):80-87 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-LDZK200304021.htm
Defant, M.J., Drummond, M.S., 1990.Derivation of Some Modern Arc Magmas by Melting of Young Subducted Lithosphere. Nature, 347(6294):662-665. https://doi.org/10.1038/347662a0
Dodson, J., Li, X.Q., Ji, M., et al., 2009.Early Bronze in Two Holocene Archaeological Sites in Gansu, NW China. Quaternary Research, 72(3):309-314. https://doi.org/10.1016/j.yqres.2009.07.004
Geng, J.Z., Li, H.K., Zhang, J., et al., 2011.Zircon Hf Isotope Analysis by Means of LA-MC-ICP-MS. Geological Bulletin of China, 30(10):1508-1513(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgqydz201110004
Gong, Q.S., Liu, M.Q., Li, H.L., et al., 2002.The Type and Basic Characteristics of Beishan Orogenic Belt, Gansu. Northwestern Geology, 35(3):28-34 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=xbdz200203004
Griffin, W.L., Pearson, N.J., Belousova, E., et al., 2000.The Hf Isotope Composition of Cratonic Mantle:LAM-MC-ICPMS Analysis of Zircon Megacrysts in Kimberlites. Geochimica et Cosmochimica Acta, 64(1):133-147. https://doi.org/10.1016/s0016-7037(99)00343-9
Griffin, W.L., Wang, X., Jackson, S.E., et al., 2002.Zircon Chemistry and Magma Mixing, SE China:In-Situ Analysis of Hf Isotopes, Tonglu and Pingtan Igneous Complexes. Lithos, 61(3-4):237-269. https://doi.org/10.1016/s0024-4937(02)00082-8
Guo, Q.Q., Xiao, W.J., Hou, Q.L., et al., 2014.Construction of Late Devonian Dundunshan Arc in the Beishan Orogen and Its Implication for Tectonics of Southern Central Asian Orogenic Belt. Lithos, 184-187:361-378. https://doi.org/10.1016/j.lithos.2013.11.007
He, S.P., Zhou, H.W., Ren, B.C., et al., 2005.Crustal Evolution of Palaeozoic in Beishan Area, Gansu and Inner Mongolia, China. Northwestern Geology, 38(3):6-15(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=xbdz200503002
Hou, Q.Y., Wang, Z., Liu, J.B., et al., 2012.Geochemistry Characteristics and SHRIMP Dating of Yueyashan Ophiolite in Beishan Orogen. Geoscience, 26(5):1008-1018(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=xddz201205022
Huang, Z.B., Jin, X., 2006.Tectonic Environment of Basic Volcanic Rocks in the Hongshishan Ophiolite Mélange Zone, Beishan Mountains, Gansu. Geology in China, 33(5):1030-1037 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgdizhi200605011
Jia, Y.Q., Zhao, Z.X., Xu, H., et al., 2016.Zircon LA-ICP-MS U-Pb Dating and Tectonic Setting of Rhyolites from Baishan Formation in Fengleishan Area of the Beishan Orogenic Belt. Geology in China, 43(1):91-98 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgdizhi201601006
Jiang, S.H., Nie, F.J., 2006.Nd-Isotope Constrains on Origin of Granitoids in Beishan Mountain Area. Acta Geologica Sinica, 80(6):826-842 (in Chinese with English abstract).
Jin, Z.M., Gao, S., 1996.Underplating and Its Geodynamical Significances for the Evolution of Crust-Mantle Boundary. Geological Science and Technology Information, 15(2):1-7 (in Chinese with English abstract).
Kemp, A.I.S., Hawkesworth, C.J., Foster, G.L., et al., 2007.Magmatic and Crustal Differentiation History of Granitic Rocks from Hf-O Isotopes in Zircon. Science, 315(5814):980-983. https://doi.org/10.1126/science.1136154
Koschek, G., 1993.Origin and Significance of the SEM Cathodoluminescence from Zircon. Journal of Microscopy, 171(3):223-232. https://doi.org/10.1111/j.1365-2818.1993.tb03379.x
Liu, J.L., Sun, F.Y., Wang, Y.D., et al., 2016.Tectonic Setting of Hadahushu Mafic Intrusion in Urad Zhongqi Area, Inner Mongolia:Implications for Early Subduction History of Paleo-Asian Ocean Plate. Earth Science, 41(12):2019-2030(in Chinese with English abstract). https://doi.org/10.3799/dqkx.2016.141
Liu, Q., Zhao, G.C., Sun, M., et al., 2015.Ages and Tectonic Implications of Neoproterozoic Ortho-and Paragneisses in the Beishan Orogenic Belt, China. Precambrian Research, 266:551-578. https://doi.org/10.1016/j.precamres.2015.05.022
Liu, X.C., Chen, B.L., Jahn, B.M., et al., 2010.Early Paleozoic (ca.465 Ma) Eclogites from Beishan (NW China) and Their Bearing on the Tectonic Evolution of the Southern Central Asian Orogenic Belt. Journal of Asian Earth Sciences, 42(4):715-731. https://doi.org/10.1016/j.jseaes.2010.10.017
Liu, Y., Gao, S., Hu, Z., et al., 2009.Continental and Oceanic Crust Recycling-Induced Melt-Peridotite Interactions in the Trans-North China Orogen:U-Pb Dating, Hf Isotopes and Trace Elements in Zircons from Mantle Xenoliths. Journal of Petrology, 51(1-2):537-571. https://doi.org/10.1093/petrology/egp082
Lu, J.C., Niu, Y.Z., Wei, X.Y., et al., 2013.LA-ICP-MS Zircon U-Pb Dating of the Late Paleozoic Volcanic Rocks from the Hongshishan Area of the Beishan Orogenic Belt and Its Tectonic Significances. Acta Petrologica Sinica, 29(8):2685-2694(in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/ysxb98201308006
Ludwig, K.R., 2003.Isoplot 3.0-A Geochronological Toolkit for Microsoft Excel.Berkeley Geochronology Center, Berkeley.
Murphy, J.B., Nance, R.D., 2002.Sm-Nd Isotopic Systematics as Tectonic Tracers:An Example from West Avalonia in the Canadian Appalachians. Earth-Science Reviews, 59(1-4):77-100. https://doi.org/10.1016/s0012-8252(02)00070-3
Niu, Y.Z., Lu, J.C., Wei, J.S., et al., 2014.Chronology of the Lütiaoshan Formation in the Beishan Area and Its Tectonic Significances. Geological Review, 60(3):567-576 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzlp201403008
Pearce, J.A., Harris, N.B.W., Tindle, A.G., 1984.Trace Element Discrimination Diagrams for the Tectonic Interpretation of Granitic Rocks. Journal of Petrology, 25(4):956-983. https://doi.org/10.1093/petrology/25.4.956
Peccerillo, A., Taylor, S.R., 1976.Rare Earth Elements in East Carpathian Volcanic Rocks. Earth and Planetary Science Letters, 32(2):121-126. https://doi.org/10.1016/0012-821x(76)90050-9
Pirajno, F., 2010.Intracontinental Strike-Slip Faults, Associated Magmatism, Mineral Systems and Mantle Dynamics:Examples from NW China and Altay-Sayan (Siberia). Journal of Geodynamics, 50(3-4):325-346. https://doi.org/10.1016/j.jog.2010.01.018
Pfänder, J.A., Münker, C., Stracke, A., et al., 2007.Nb/Ta and Zr/Hf in Ocean Island Basalts-Implications for Crust-Mantle Differentiation and the Fate of Niobium. Earth and Planetary Science Letters, 254(1-2):158-172. https://doi.org/10.1016/j.epsl.2006.11.027
Qi, R.R., Huang, Z.B., Jin, X., 2006.Geochemical Characteristics and Tectonic Implications of the Dashishan A-Type Granitic Intrusion in Beishan Area, Gansu Province. Acta Petrologica et Mineralogica, 25(2):90-96(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-YSKW200602002.htm
Ravikant, V., Wu, F.Y., Ji, W.Q., 2011.U-Pb Age and Hf Isotopic Constraints of Detrital Zircons from the Himalayan Foreland Subathu Sub-Basin on the Tertiary Palaeogeography of the Himalaya. Earth and Planetary Science Letters, 304(3-4):356-368. https://doi.org/10.1016/j.epsl.2011.02.009
Rogers, G., Hawkesworth, C.J., 1989.A Geochemical Traverse across the North Chilean Andes:Evidence for Crust Generation from the Mantle Wedge. Earth and Planetary Science Letters, 91(3-4):271-285. https://doi.org/10.1016/0012-821x(89)90003-4
Söderlund, U., Patchett, P.J., Vervoort, J.D., et al., 2004.The ¹⁷⁶Lu Decay Constant Determined by Lu-Hf and U-Pb Isotope Systematics of Precambrian Mafic Intrusions. Earth and Planetary Science Letters, 219(3-4):311-324. https://doi.org/10.1016/s0012-821x(04)00012-3
Song, D.F., Xiao, W.J., Han, C.M., et al., 2013.Progressive Accretionary Tectonics of the Beishan Orogenic Collage, Southern Altaids:Insights from Zircon U-Pb and Hf Isotopic Data of High-Grade Complexes. Precambrian Research, 227(1):368-388. http://www.sciencedirect.com/science/article/pii/S0301926812001532
Song, X.Y., Xie, W., Deng, Y.F., et al., 2011.Slab Break-off and the Formation of Permian Mafic-Ultramafic Intrusions in Southern Margin of Central Asian Orogenic Belt, Xinjiang, NW China. Lithos, 127(1-2):128-143. https://doi.org/10.1016/j.lithos.2011.08.011
Su, B.X., Qin, K.Z., Sun, H., et al., 2012.Subduction-Induced Mantle Heterogeneity beneath Eastern Tianshan and Beishan:Insights from Nd-Sr-Hf-O Isotopic Mapping of Late Paleozoic Mafic-Ultramafic Complexes. Lithos, 134-135:41-51. https://doi.org/10.1016/j.lithos.2011.12.011
Sun, S.S., McDonough, W.F., 1989.Chemical and Isotopic Systematics of Oceanic Basalts:Implications for Mantle Composition and Processes. Geological Society, London, Special Publications, 42(1):313-345. https://doi.org/10.1144/gsl.sp.1989.042.01.19
Tian, Z.H., Xiao, W.J., Windley, B.F., et al., 2014.Structure, Age, and Tectonic Development of the Huoshishan-Niujuanzi Ophiolitic Mélange, Beishan, Southernmost Altaids. Gondwana Research, 25(2):820-841. https://doi.org/10.1016/j.gr.2013.05.006
Wang, G., Sun, F.Y., Li, B.L., 2014.Zircon U-Pb Geochronology and Geochemistry of Diorite in Xiarihamu Ore District from East Kunlun and Its Geological Significance. Journal of Jilin University(Earth Science Edition), 44(3):876-891 (in Chinese with English abstract). https://doi.org/10.13278/j.cnki.jjuese.201403113
Wang, G.Q., Li, X.M., Xu, X.Y., et al., 2014.Zircon U-Pb Chronological Study of the Hongshishan Ophiolite in the Beishan Area and Their Tectonic Significance. Acta Petrologica Sinica, 30(6):1685-1694(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-YSXB201406011.htm
Wang, S.Q., Xin, H.T., Hu, X.J., et al., 2016.Geochronology, Geochemistry and Geological Significance of Early Paleozoic Wulanaobaotu Intrusive Rocks, Inner Mongolia. Earth Science, 41(4):555-569 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqkx201604001
Wang, Y.W., Jiang, F.Z., 1997.Features and Distribution of Volcanic Rock Associations of Various Ages in the Beishan Area, Gansu. Regional Geology of China, 16(3):298-304 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-ZQYD703.010.htm
Wei, Z.J., Huang, Z.B., Jin, X., et al., 2004.Geological Characteristics of Ophiolite Migmatitic Complex of Hongshishan Region, Gansu. Northwestern Geology, 37(1):13-18 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=xbdz200402003
Williams, I.S., Buick, I.S., Cartwright, I., 1996.An Extended Episode of Early Mesoproterozoic Metamorphic Fluid Flow in the Reynolds Range, Central Australia. Journal of Metamorphic Geology, 14(1):29-47. https://doi.org/10.1111/j.1525-1314.1996.00029.x
Wu, F.Y., Li, X.H., Zheng, Y.F., et al., 2007.Lu-Hf Isotopic Systematics and Their Applications in Petrology. Acta Petrologica Sinica, 23(2):185-220 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=ysxb98200702001
Wu, Y.B., Zheng, Y.F., 2004.Genetic Mineralogy of Zircons and Its Constraints to the Age of U-Pb Geochronology. Chinese Science Bulletin, 49(16):1589-1604(in Chinese).
Xiao, Q.H., Deng, J.F., Qiu, R.Z., et al., 2009.A Preliminary Study of the Relationship between Granitoids and the Growth of Continental Crust:A Case Study of the Formation of Key Orogen Granitoids in China. Geology in China, 36(3):594-622 (in Chinese with English abstract).
Xiao, W.J., Han, C.M., Liu, W., et al., 2014.How Many Sutures in the Southern Central Asian Orogenic Belt:Insights from East Xinjiang-West Gansu (NW China)?. Geoscience Frontiers, 5(4):525-536. https://doi.org/10.1016/j.gsf.2014.04.002
Xiao, W.J., Mao, Q.G., Windley, B.F., et al., 2010.Paleozoic Multiple Accretionary and Collisional Processes of the Beishan Orogenic Collage. American Journal of Science, 310(10):1553-1594. https://doi.org/10.2475/10.2010.12
Xu, X.W., Li, X.H., Jiang, N., et al., 2015.Basement Nature and Origin of the Junggar Terrane:New Zircon U-Pb-Hf Isotope Evidence from Paleozoic Rocks and Their Enclaves. Gondwana Research, 28(1):288-310. https://doi.org/10.1016/j.gr.2014.03.011
Xu, Z.Q., Zhang, J.X., Xu., H.F., 1996.Ductile Shear Zones in the Main Continental Mountain Chains of China and Their Dynamics.Geological Publishing House, Beijing, 1-294 (in Chinese).
Yang, H.Q., Zhao, G.B., Li, Y., et al., 2012.The Relationship between Paleozoic Tectonic Setting and Mineralization in Xinjiang-Gansu-Inner Mongolia Juncture Area. Geological Bulletin of China, 31(2):413-421 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgqydz201202027
Yu, F.S., Wang, C.Y., Qi, J.F., et al., 2000.The Clarification and Tectonic Implication of the Early Silurian Ophiolite Mélange in Hongliuhe Area. Journal of Mineralogy and Petrology, 20(4):60-66 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-KWYS200004011.htm
Yuan, H.L., Gao, S., Liu, X.M., et al., 2004.Accurate U-Pb Age and Trace Element Determinations of Zircon by Laser Ablation-Inductively Coupled Plasma-Mass Spectrometry. Geostandards and Geoanalytical Research, 28(3):353-370. https://doi.org//10.1111/j.1751-908x.2004.tb00755.x
Yuan, Y., Zong, K.Q., He, Z.Y., et al., 2015.Geochemical and Geochronological Evidence for a Former Early Neoproterozoic Microcontinent in the South Beishan Orogenic Belt, Southernmost Central Asian Orogenic Belt. Precambrian Research, 266:409-424. https://doi.org/10.1016/j.precamres.2015.05.034
Zhang, D.H., Zhao, L.S., 2013.Geochemistry.Geological Publishing House, Beijing, 70(in Chinise).
Zhang, Q., Wang, Y., Qian, Q., et al., 2001.The Characteristics and Tectonic-Metallogenic Significances of the Adakites in Yanshan Period from Eastern China. Acta Petrologica Sinica, 17(2):236-244(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=ysxb98200102008
Zhang, W., Pease, V., Wu, T.R., et al., 2012.Discovery of an Adakite-Like Pluton near Dongqiyishan (Beishan, NW China)-Its Age and Tectonic Significance. Lithos, 142-143:148-160. https://doi.org/10.1016/j.lithos.2012.02.021
Zhao, J., Wang, W.L., Dong, L.H., et al., 2012.Application of Geochemical Anomaly Identification Methods in Mapping of Intermediate and Felsic Igneous Rocks in Eastern Tianshan, China. Journal of Geochemical Exploration, 122:81-89. https://doi.org/10.1016/j.gexplo.2012.08.006
Zhao, Z.Y., Zhang, Z.C., Santosh, M., et al., 2015.Early Paleozoic Magmatic Record from the Northern Margin of the Tarim Craton:Further Insights on the Evolution of the Central Asian Orogenic Belt. Gondwana Research, 28(1):328-347./ https://doi.org/10.1016/j.gr.2014.04.007
Zheng, R.G., Wu, T.R., Zhang, W., et al., 2012.Geochemical Characteristic and Tectonic Settings of the Yueyashan-Xichangjing Ophiolite in Beishan Area. Acta Geologica Sinica, 86(6):961-971(in Chinese with English abstract). http://journals.cambridge.org/article_S0016756811000884
Zheng, R.G., Wu, T.R., Zhang, W., et al., 2014a.Geochronology and Geochemistry of Late Paleozoic Magmatic Rocks in the Yinwaxia Area, Beishan:Implications for Rift Magmatism in the Southern Central Asian Orogenic Belt. Journal of Asian Earth Sciences, 91:39-55. https://doi.org/10.1016/j.jseaes.2014.04.022
Zheng, R.G., Wu, T.R., Zhang, W., et al., 2014b.Late Paleozoic Subduction System in the Northern Margin of the Alxa Block, Altaids:Geochronological and Geochemical Evidences from Ophiolites. Gondwana Research, 25(2):842-858. https://doi.org/10.1016/j.gr.2013.05.011
Zhu, D.C., Zhao, Z.D., Pan, G.T., et al., 2009.Early Cretaceous Subduction-Related Adakite-Like Rocks of the Gangdese Belt, Southern Tibet:Products of Slab Melting and Subsequent Melt-Peridotite Interaction?. Journal of Asian Earth Sciences, 34(3):298-309. https://doi.org/10.1016/j.jseaes.2008.05.003
Zong, K.Q., Klemd, R., Yuan, Y., et al., 2017.The Assembly of Rodinia:The Correlation of Early Neoproterozoic (ca.900 Ma) High-Grade Metamorphism and Continental Arc Formation in the Southern Beishan Orogen, Southern Central Asian Orogenic Belt (CAOB). Precambrian Research, 290:32-48. https://doi.org/10.1016/j.precamres.2016.12.010
Zuo, G.C., He, G.Q., 1990.Series on Tectonics of North Plate, China:Plate Tectonics and Metallogenesis Regularities in Beishan Region.Peking University Press, Beijing, 1-226 (in Chinese).
Zuo, G.C., Zhang, S.L., He, G.Q., et al., 1991.Plate Tectonic Characteristics during the Early Paleozoic in Beishan near the Sino-Mongolian Border Region, China. Tectonophysics, 188(3-4):385-392. https://doi.org/10.1016/0040-1951(91)90466-6
蔡志慧, 许志琴, 何碧竹, 等, 2012.东天山-北山造山带中大型韧性剪切带属性及形成演化时限与过程.岩石学报, 28(6):1875-1895. http://d.old.wanfangdata.com.cn/Periodical/ysxb98201206012
戴霜, 方小敏, 张翔, 等, 2003.塔里木-中朝板块北缘的志留纪岛弧公婆泉群火山岩地质地球化学及构造意义.兰州大学学报, 39(4):80-87. http://d.old.wanfangdata.com.cn/Periodical/lzdxxb200304022
耿建珍, 李怀坤, 张健, 等, 2011.锆石Hf同位素组成的LA-MC-ICP-MS测定.地质通报, 30(10):1508-1513. doi: 10.3969/j.issn.1671-2552.2011.10.004
龚全胜, 刘明强, 李海林, 等, 2002.甘肃北山造山带类型及基本特征.西北地质, 35(3):28-34. doi: 10.3969/j.issn.1009-6248.2002.03.004
何世平, 周会武, 任秉琛, 等, 2005.甘肃内蒙古北山地区古生代地壳演化.西北地质, 38(3):6-15. doi: 10.3969/j.issn.1009-6248.2005.03.002
侯青叶, 王忠, 刘金宝, 等, 2012.北山月牙山蛇绿岩地球化学特征及SHRIMP定年.现代地质, 26(5):1008-1018. doi: 10.3969/j.issn.1000-8527.2012.05.022
黄增保, 金霞, 2006.甘肃北山红石山蛇绿混杂岩带中基性火山岩构造环境分析.中国地质, 33(5):1030-1037. doi: 10.3969/j.issn.1000-3657.2006.05.011
贾元琴, 赵志雄, 许海, 等, 2016.北山风雷山地区白山组流纹岩LA-ICP-MS锆石U-Pb年龄及构造环境.中国地质, 43(1):91-98. doi: 10.3969/j.issn.1000-3657.2016.01.006
江思宏, 聂凤军, 2006.北山地区花岗岩类成因的Nd同位素制约.地质学报, 80(6):826-842. doi: 10.3321/j.issn:0001-5717.2006.06.005
金振民, 高山, 1996.底侵作用(underplating)及其壳-幔演化动力学意义.地质科技情报, 15(2):1-7. doi: 10.1016-j.bmcl.2010.06.083/
刘金龙, 孙丰月, 王英德, 等, 2016.内蒙古乌拉特中旗哈达呼舒基性岩体形成的构造背景与古亚洲洋的早期俯冲历史.地球科学, 41(12):2019-2030. http://earth-science.net/WebPage/Article.aspx?id=3398
卢进才, 牛亚卓, 魏仙样, 等, 2013.北山红石山地区晚古生代火山岩LA-ICP-MS锆石U-Pb年龄及其构造意义.岩石学报, 29(8):2685-2694. http://d.old.wanfangdata.com.cn/Periodical/ysxb98201308006
牛亚卓, 卢进才, 魏建设, 等, 2014.甘蒙北山地区下石炭统绿条山组时代修正及其构造意义.地质论评, 60(3):567-576. http://d.old.wanfangdata.com.cn/Periodical/dzlp201403008
齐瑞荣, 黄增保, 金霞, 2006.甘肃北山大石山A型花岗岩体的地球化学特征及构造意义.岩石矿物学杂志, 25(2):90-96. doi: 10.3969/j.issn.1000-6524.2006.02.002
王冠, 孙丰月, 李碧乐, 等, 2014.东昆仑夏日哈木矿区闪长岩锆石U-Pb年代学、地球化学及其地质意义.吉林大学学报(地球科学版), 44(3):876-891. http://d.old.wanfangdata.com.cn/Periodical/cckjdxxb201403014
王国强, 李向民, 徐学义, 等, 2014.甘肃北山红石山蛇绿岩锆石U-Pb年代学研究及构造意义.岩石学报, 30(6):1685-1694. http://d.old.wanfangdata.com.cn/Periodical/ysxb98201406011
王树庆, 辛后田, 胡晓佳, 等, 2016.内蒙古乌兰敖包图早古生代侵入岩年代学、地球化学特征及地质意义.地球科学, 41(4):555-569. http://earth-science.net/WebPage/Article.aspx?id=3274
王玉往, 姜福芝, 1997.北山地区各时代火山岩组合特征及分布.中国区域地质, 16(3):298-304. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK199700735619
魏志军, 黄增保, 金霞, 等, 2004.甘肃红石山地区蛇绿混杂岩地质特征.西北地质, 37(1):13-18. doi: 10.3969/j.issn.1009-6248.2004.01.003
吴福元, 李献华, 郑永飞, 等, 2007.Lu-Hf同位素体系及其岩石学应用.岩石学报, 23(2):185-220. http://d.old.wanfangdata.com.cn/Periodical/ysxb98200702001
吴元保, 郑永飞, 2004.锆石成因矿物学研究及其对U-Pb年龄解释的制约.科学通报, 49(16):1589-1604. doi: 10.3321/j.issn:0023-074X.2004.16.002
肖庆辉, 邓晋福, 邱瑞照, 等, 2009.花岗岩类与大陆地壳生长初探——以中国典型造山带花岗岩类岩石的形成为例.中国地质, 36(3):594-622. doi: 10.3969/j.issn.1000-3657.2009.03.008
许志琴, 张建新, 徐慧芬, 1996.中国主要大陆山链韧性剪切带及动力学.北京:地质出版社, 1-294.
杨合群, 赵国斌, 李英, 等, 2012.新疆-甘肃-内蒙古衔接区古生代构造背景与成矿的关系.地质通报, 31(2):413-421. doi: 10.3969/j.issn.1671-2552.2012.02.027
于福生, 王春英, 漆家福, 等, 2000.甘新交界红柳河地区早志留世蛇绿混杂岩的厘定及大地构造意义.矿物岩石, 20(4):60-66. doi: 10.3969/j.issn.1001-6872.2000.04.012
张德会, 赵仑山, 2013.地球化学.北京:地质出版社, 70.
张旗, 王焰, 钱青, 等, 2001.中国东部燕山期埃达克岩的特征及其构造-成矿意义.岩石学报, 17(2):236-244. http://d.old.wanfangdata.com.cn/Periodical/ysxb98200102008
郑荣国, 吴泰然, 张文, 等, 2012.北山地区月牙山-洗肠井蛇绿岩的地球化学特征及形成环境.地质学报, 86(6):961-971. doi: 10.3969/j.issn.0001-5717.2012.06.010
左国朝, 何国琦, 1990.中国北方板块构造丛书——北山板块构造及成矿规律.北京:北京出版社, 1-226.
