Sedimentary Architecture, Distribution Features and Genesis of Steep Slope Fan in Upper Liushagang Formation, Weixi'nan Sag
-
摘要: 断裂陡坡带是沉积盆地重要的油气勘探区，对其扇体展布规律及其控制因素展开研究可揭示储层发育规律，指导油气勘探.综合利用录井、测井、三维地震资料，并结合区域轻重矿物、岩心沉积构造与粒度分析，对涠西南凹陷流一段沉积时期一号断裂陡坡带扇体的沉积类型及展布特征进行研究.结果显示陡坡扇体的发育具有明显分区性：陡坡西段发育大型下切沟谷，发育的扇体规模较大，呈不对称朵状，以粗粒的砂质碎屑流沉积为特征；陡坡中段发育带狭长水道的小型扇体，以发育悬移质为主的浊流沉积为特征；陡坡东段发育一系列小型沟谷水道及对应的对称状扇体.结合边界断裂活动、物源区母岩类型及古地貌分布特征分析，揭示了物源、构造、古地貌等要素对扇体的控制作用.陡坡西侧边界断裂活动较强、处于断层转换部位、物源供给充分，为大型粗质扇体形成提供条件；而陡坡中段与东段断裂活动和物源供给较弱、地形平缓，使其扇体发育规模相对较小.Abstract: Using high quality 3D seismic data, combining analyses of light and heavy minerals, core observation and sand grain size distributions, sedimentary architecture and distribution features of steep slope fan in Upper Liushagang Formation of Weixi'nan Sag have been investigated in this study. These features vary along the NO.1 border fault:In the western part of steep slope belt, large-scale incised valleys developed, producing large-scale sub-lacustrine fans, which are characterized by thick beds of debris flow deposits; While in the middle part, small-scale channelized turbidite sub-lacustrine fans dominated; In eastern part, a series of small-scale symmetrical fans were located along the border fault, with sparse valleys present. Lateral variations of sediment supply, geomorphology and subsidence rate induced by multiple stages of border fault activity are considered the controlling factors:Fault slope in western part feeds coarser sediments from larger drainages. Meanwhile, large-scale incised valleys and complex morphology allow the growth of larger, asymmetrical fan lobes; On the other hand, fault slopes in the middle and eastern part with planar style and ramp-flat structure, respectively, provide a limited supply to multiple small fans.
-
Key words:
- border fault /
- Weixi'nan sag /
- fan distribution /
- controlling factors /
- paleogeomorphology /
- oil-gas geology
-
图 1 涠西南凹陷（a）区域位置图，（b）地层系统，（c）构造格架剖面图
Fig. 1. Geological map (a), stratum system (b) and structural framework (c) of Weixi'nan Sag
图 2 涠西南凹陷陡坡带流一段连井对比图
Fig. 2. Correlations of well logs along steep slope belt in Upper Liushagang Fm, Weixi'nan Sag
图 3 涠西南凹陷陡坡带流一段砂岩组分特征
Fig. 3. Rock composition of steep slope belt in Upper Liushagang Fm, Weixi'nan Sag
图 4 WZ11-X-2、WZ5-Y-2岩心沉积构造特征
a.粗砂岩，含不规则状大型泥砾，WZ11-X-2井，2 129.83 m；b.块状粗砂岩与上覆细砂岩呈突变接触，WZ11-X-2井，2 128.68 m；c.块状含砾粗砂岩上覆泥岩呈突变接触，WZ11-X-2井，2 123.01 m；d.中细砂岩，相序中上部含大型泥砾，底部含小型泥岩撕裂屑，WZ11-X-2井，2 117.36 m；e.泥岩撕裂屑，非定向排列，2 121.35 m；f.细砂岩，上部含泥砾，WZ5-Y-2井，2 895.20 m；g.细砂岩，与上覆泥岩突变接触，WZ5-Y-2井，2 895.64 m；h.中-细砂岩，可见正韵律，WZ5-Y-2井，2 894.35 m；o.中-细砂岩，可见正韵律及冲刷面，WZ5-Y-2井，2 892.00 m
Fig. 4. Sedimentary-architectural characteristics of WZ11-X-2 and WZ5-Y-2
图 5 涠西南凹陷陡坡带流一段砂岩粒度分布
Fig. 5. Sandstone grain size distribution of steep slope belt in Upper Liushagang Fm, Weixi'nan Sag
图 6 （a）涠西南凹陷陡坡带流一段ZTR指数等值线分布图，（b）重矿物相对含量
Fig. 6. (a)ZTR isoline of steep slope belt in Upper Liushagang Fm, Weixi'nan Sag, (b) Characteristic distribution of heavy minerals
图 7 涠西南凹陷陡坡带流一段扇体不同区域展布特征
Fig. 7. Distribution features of steep slope fan in Upper Liushagang Fm, Weixi'nan Sag
图 8 涠西南凹陷陡坡带流一段扇体平面分布与古地理格局叠合图
Fig. 8. Plane distribution of steep slope fan in Upper Liushagang Fm, Weixi'nan Sag
图 10 涠西南凹陷陡坡带流一段断层活动与构造样式分布特征
a.流一段T5~T4地层厚度图; b.不同位置构造组合样式; c.流二段沉积时期一号断层活动特征; d.流一段沉积时期一号断层活动特征
Fig. 10. Tectonic activities and fault structure of steep slope belt in Upper Liushagang Fm, Weixi'nan Sag
图 9 沿边界断层走向地层分布特征（沿流一段顶界T4拉平剖面，位置见图 8）
Fig. 9. Stratigraphic framework along No.1 border fault, Weixi'nan Sag
-
Back, S., Strecker, M. R., De Batist, M., et al., 2000. Tectonic and Sediment Supply Control of Deep Rift Lake Turbidite Systems: Lake Baikal, Russia: Comment and Reply. Geology, 28(2): 189. https://doi.org/10.1130/0091-7613(2000)28 < 189:tassco > 2.0.co; 2 doi: 10.1130/0091-7613(2000)28<189:tassco>2.0.co;2 Cao, L. C., Jiang, T., Wang, Z. F., et al., 2013. Characteristics of Heavy Minerals and Their Implications for Neogene Provenances Evolution in Qiongdongnan Basin. Journal of Central South University (Science and Technology), 44(5):1971-1981 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zngydxxb201305034 Cao, Y. C., Song, L., Wang, J., et al., 2011. Application of Heavy Mineral Data in the Analysis of Sediment Source:A Case study in the Paleogene Lower Submember of the Third Member of the Liushagang Formation, Weixinan Depression. Acta Sedimentologic Sinica, 29(5):835-841 (in Chinese with English abstract). Chen, P., 2006. Sand Reservoir Prediction of Steep Slope Zone in Biyang Sag. Petroleum Exploration and Development, 33(2):198-200 (in Chinese with English bstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syktykf200602015 Deibert, J. E., Camilleri, P. A., 2006. Sedimentologic and Tectonic Origin of an Incised-Valley-Fill Sequence along an Extensional Marginal-Lacustrine System in the Basin and Range Province, United States: Implications for Predictive Models of the Location of Incised Valleys. AAPG Bulletin, 90(2): 209-235. https://doi.org/10.1306/09140505028 Gawthorpe, R. L., Leeder, M. R., 2000. Tectono-Sedimentary Evolution of Active Extensional Basins. Basin Research, 12(3/4): 195-218. https://doi.org/10.1111/j.1365-2117.2000.00121.x Huang, S. B., Ye, J. R., Zhu, H. T., et al., 2011. Characteristics of Valley-Slope Break Zone in the Western Circle of the Bozhong Depression and Its Control over Reservoir Distribution. Marine Geology & Quaternary Geology, 31(1):119-124 (in Chinese with English bstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hydzydsjdz201101014 Hu, W. S., Wu, C., Liang, J. S., et al., 2011. Tectonic Transport Characteristics and Their Influences on Hydrocarbon Accumulation in Beibuwan Basin. Oil & Gas Geology, 32(54):920-927 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syytrqdz201106015 Jackson, C. A. L., Larsen, E., Hanslien, S., et al., 2011. Controls on Synrift Turbidite Deposition on the Hanging Wall of the South Viking Graben, North Sea Rift System, Offshore Norway. AAPG Bulletin, 95(9): 1557-1587. https://doi.org/10.1306/01031110037 Li, C. R., Zhang, G. C., Liang, J. S., et al., 2012. Characteristics of Fault Structure and Its Control on Hydracarbons in the Beibuwan Basin. Acta Petrolei Sinica, 33(2):195-203 (in Chinese with English abstract). Liao, J. H., Wang, H., Lv, M., et al., 2016. Evolution of Syndepositional Faulting andIts Controlling Effecton Sedimentary Fillingin Songnan-Baodao Sag of Qiongdongnan Basin South China Sea. Journal of China University of Mining and Technology, 45(2):336-346 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-ZGKD201602017.htm Liao, J. H., Wang, H., Sun, Z. P., et al., 2012. Tectonic Evolution and Its Controlling on Sequence Pattern of Chang-Chang Sag, Deepwater Area of Qiongdongnan Basin, South China Sea. Journal of Central South University (Science and Technology), 43(8):3121-3132 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zngydxxb201208035 Liu, Q. H., Zhu, X. M., Li, S. L., et al., 2017. Source-to-Sink System of the Steep Slope Fault in the Western Shaleitian Uplift. Earth Science, 42(11):1883-1896 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqkx201711003 Liu, Z., Tan, Z., Cai, D. S., al.ea, 2008. Analysis on Forming Conditions of Lithologic Trap in Liushagang Formation, Weixi'nan Depression of BBW Basin. Geoscience, 22(2):239-246 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-XDDZ200802010.htm Paton, S., 1992. Active Normal Faulting, Drainage Patterns and Sedimentation in Southwestern Turkey. Journal of the Geological Society, 149(6): 1031-1044. https://doi.org/10.1144/gsjgs.149.6.1031 Sun, S. M., Ji, H. C., Liu, X., et al., 2017. Architecture of Sequence Stratigraphy Responding to Segmentation of BoundaryFault: Taking an Example of Dongying Formation on Hanging Wall of Xinanzhuang Fault in Nanpu Sag. Journal of Jilin University (Earth Science Edition), 47(2):382-392 (in Chinese with English abstract). Tan, Z, Liu, Z. G., Li, Y. Z., et al., 2015. Forming Types and Evolution of Sand Body in Steep Slope Belt of Weixinan Sag, Beibu Gulf Basin. Geological Survey and Research. 38(1):1-9 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=qhwjyjjz201501001 Wang, H., Bai, Y. F., Huang, C.Y., et al., 2009. Reconstruction and Application of the Paleogene Provenance System of the Dongying Formation in Qikou Depression. Earth Science, 34(3):448-456 (in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/dqkx200903009 Wang, Q. M., Li, J., Zhou, X. G., et al., 2016. Tectonic-Paleogeomorphic Controlled on Deposition of Steep Slope Belt in Southwestern Margin of Shijiutuo Uplift. Journal of Northeast Petroleum University, 40(6):53-61(in Chinese with English abstract). Xia, J. S., Liu, X. H., Wang, Z. J., et al., 2017. Sedimentary Characteristics of Sandy Debris Flow in the 3rd Member of Dongying Formation and the 1st Member of the Western Nanpu Sag, Bohai Bay Basin and Its Significance in Hydracarbon Exploration. Acta Petrolei Sinica, 38(4):399-413 (in Chinese with English abstract). Xian, B. Z., Wang, Z., Ma, L. C., et al., 2017. Paleao-Drainage System and Integrated Paleo-Geomorphology-Restoration in Depositional and Erosional Areas: Guantao Formation in East Liaodong Area, Bohai Bay Basin, China. Earth Science, 42(11):1922-1935 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DQKX201711006.htm Xu, C. G., Zhou, X. H., Yang, B., et al., 2009. Forming and Distribution Regularity of Structural-Lithologic Composite Traps in the Shinan Steep Slope Zone, Bozhong Sag. Geoscience, 23(5):887-893 (in Chinese with English bstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=xddz200905018 Yang, B., Xu, C. G., Niu, C. M., 2011. Conditions for Hydracarben Reservoirs Formation of Lithologic Trap in Wall-Ccorner-Type Steepslope Belt: A Case on Paleogene Dongying Formation of BZ3 Block in Middle Part of Shinan Steep Slope Belt, Bohai Bay Basin. Journal of Paleogeography, 13(4):434-442 (in Chinese with English abstract). Yang, T., Cao, Y. C., Wang, Y. Z., et al., 2015. Types, Sedimentary Chracteristics and Genetic Mechanisms of Deepwater Gravity Flows: A Case Study of Submember in Member 3 of Shahejie Formation in JiyangDepression. Acta Petrolei Sinica, 36(9):1048-1059 (in Chinese with English abstract). Yuan, G. H., Cao, Y. C., Wang, Y. Z., 2012. Sedimentary Facies and Their Evolution of the 4th-Middle 3rd Members of Shahejie Formation in Minfeng Area, Dongying Sag. Oil & Gas Geology, 33(2):277-286 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syytrqdz201202014 Zhang, Z. W., Liu, Z. F., Zhang, G. C., et al., 2013. The Chasmic Stage and Structural Evolution Features of Beibuwan Basin. Journal of Oil and Gas Technology, 35(1):6-10 (in Chinese with English abstract). Zhu, H. T., Yang, X. H., Zhou, X. H., et al., 2013. Sediment Transport Pathway Characteristics of Continental Lacustrine Basins Based on 3-D Seismic Data:An Example From Dongying Formation of Western Slope of Bozhong Sag.Earth Science, 38(1):121-129 (in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/dqkx201301012 操应长, 宋玲, 王健, 等, 2011.重矿物资料在沉积物物源分析中的应用—以涠西南凹陷古近系流三段下亚段为例.沉积学报, 29(5):835-841. http://www.cnki.com.cn/Article/CJFDTotal-CJXB201105004.htm 曹立成, 姜涛, 王振峰, 等, 2013.琼东南盆地新近系重矿物分布特征及其物源指示意义.中南大学学报(自然科学版), 44(5):1971-1981. http://d.old.wanfangdata.com.cn/Periodical/zngydxxb201305034 陈萍, 2006.泌阳凹陷陡坡带砂砾岩体预测.石油勘探与开发, 33(2):198-200. doi: 10.3321/j.issn:1000-0747.2006.02.015 黄胜兵, 叶加仁, 朱红涛, 等, 2011.渤中西环古沟谷与坡折带特征及其对储层的控制.海洋地质与第四纪地质, 31(1):119-124. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hydzydsjdz201101014 胡望水, 吴婵, 梁建设, 等, 2011.北部湾盆地构造迁移特征及对油气成藏的影响.石油与天然气地质, 32(54):920-927. http://d.old.wanfangdata.com.cn/Periodical/syytrqdz201106015 李春荣, 张功成, 梁建设, 等, 2012.北部湾盆地断裂构造特征及其对油气的控制作用.石油学报, 33(2):195-203. http://d.old.wanfangdata.com.cn/Periodical/syxb201202003 廖计华, 王华, 吕明, 等, 2016.琼东南盆地深水区松南-宝岛凹陷同沉积断裂活动及其对沉积充填的控制.中国矿业大学学报, 45(2):336-346. http://d.old.wanfangdata.com.cn/Periodical/zgkydxxb201602017 廖计华, 王华, 孙志鹏, 等, 2012.琼东南盆地深水区长昌凹陷构造演化及其对层序样式的控制.中南大学学报(自然科学版), 43(8):3121-3132. http://d.old.wanfangdata.com.cn/Periodical/zngydxxb201208035 刘强虎, 朱筱敏, 李顺利, 等, 2017.沙垒田凸起西部断裂陡坡型源—汇系统.地球科学, 42(11):1883-1896. doi: 10.3799/dqkx.2017.119 刘震, 谭卓, 蔡东升, 等, 2008.北部湾盆地涠西南凹陷流沙港组岩性圈闭形成条件.现代地质, 22(2):239-246. doi: 10.3969/j.issn.1000-8527.2008.02.010 孙思敏, 季汉成, 刘晓, 等, 2017.断陷盆地边界断层分段的层序地层响应特征—以南堡凹陷西南庄断层上盘陡坡带东营组为例.吉林大学学报, 47(2):382-392. http://www.cnki.com.cn/Article/CJFDTOTAL-CCDZ201702006.htm 谭卓, 刘志国, 李运振, 等, 2015.北部湾盆地涠西南凹陷陡坡带砂体成因类型及其演化.地质调查与研究, 38(1):1-9. doi: 10.3969/j.issn.1672-4135.2015.01.001 王华, 白云风, 黄传炎, 等, 2009.歧口凹陷古近纪东营期古物源体系重建与应用.地球科学, 34(3):448-456. doi: 10.3321/j.issn:1000-2383.2009.03.009 王启明, 李瑾, 周晓光, 等, 2016.石臼坨凸起西南缘陡坡带东三段古地貌对沉积的控制.东北石油大学学报, 40(6):53-61. doi: 10.3969/j.issn.2095-4107.2016.06.007 夏景生, 刘晓涵, 王政军, 等, 2017.渤海湾盆地南堡凹陷西部东营组三段-沙河街组一段砂质碎屑流沉积特征及油气勘探意义.石油学报, 38(4):399-413. http://d.old.wanfangdata.com.cn/Periodical/syxb201704004 鲜本忠, 王震, 马立驰, 等, 2017.沉积区—剥蚀区古地貌一体化恢复及古水系研究:以渤海湾盆地辽东东地区馆陶组为例.地球科学, 42(11):1922-1935. doi: 10.3799/dqkx.2017.122 徐长贵, 周心怀, 杨波, 等, 2009.渤中凹陷石南陡坡带构造-岩性复合圈闭的形成及分布规律.现代地质, 23(5):887-893. doi: 10.3969/j.issn.1000-8527.2009.05.018 杨波, 徐长贵, 牛成民, 2011.墙角型陡坡带岩性圈闭油气成藏条件研究—以渤海湾盆地石南陡坡带中段BZ3区古近系东营组为例.古地理学报, 13(4):434-442. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gdlxb201104006 杨田, 操应长, 王艳忠, 等, 2015.深水重力流类型、沉积特征及成因机制—以济阳坳陷沙河街组三段中亚段为例.石油学报, 36(9):1048-1059. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syxb201509003 远光辉, 操应长, 王艳忠, 2012.东营凹陷民丰地区沙河街组四段-三段中亚段沉积相与沉积演化特征.石油与天然气地质, 33(2):277-286. http://d.old.wanfangdata.com.cn/Periodical/syytrqdz201202014 张智武, 刘志峰, 张功成, 等, 2013.北部湾盆地裂陷期构造及演化特征.石油天然气学报, 2013, 35(1):6-10. doi: 10.3969/j.issn.1000-9752.2013.01.002 朱红涛, 杨香华, 周心怀, 等, 2013.基于地震资料的陆相湖盆物源通道特征分析:以渤中凹陷西斜坡东营组为例.地球科学, 38(1):121-129. doi: 10.3799/dqkx.2013.012 -
