海相油气成藏定年技术及其对元坝气田长兴组天然气成藏年代的反演

王杰; 刘文汇; 陶成; 腾格尔; 席斌斌; 王萍; 杨华敏

doi:10.3799/dqkx.2018.605

海相油气成藏定年技术及其对元坝气田长兴组天然气成藏年代的反演

doi: 10.3799/dqkx.2018.605

王杰^1,2,,
刘文汇^1,2,
陶成^1,2,
腾格尔^1,2,
席斌斌^1,2,
王萍^1,2,
杨华敏^1,2

1.
中国石油化工集团公司油气成藏重点实验室, 江苏无锡 214126
2.
中国石化石油勘探开发研究院无锡石油地质研究所, 江苏无锡 214126

基金项目:

中国石化股份公司科技部四川项目群 P16079

国家重点基金项目 U1663201

详细信息

作者简介:
王杰(1975-), 男, 高级工程师, 博士, 主要从事油气地质及有机地球化学研究

中图分类号: P597
计量
- 文章访问数: 5914
- HTML全文浏览量: 2654
- PDF下载量: 49
- 被引次数: 0
出版历程
- 收稿日期: 2018-03-04
- 刊出日期: 2018-06-15

Key Dating Methods of Reservoir Accumulation in Marine Strata and Their Applications to Natural Gas of the Changxing Formation in Yuanba Gas Field

Wang Jie^{1,2
,},
Liu Wenhui^1,2,
Tao Cheng^1,2,
Tenger^1,2,
Xi Binbin^1,2,
Wang Ping^1,2,
Yang Huamin^1,2

1.
Key Laboratory of Petroleum Accumulation Mechanisms, SINOPEC, Wuxi 214126, China
2.
Wuxi Research Institute of Petroleum Geology, Exploration and Producation Research Institute, SINOPEC, Wuxi 214126, China

摘要

摘要: 我国海相叠合盆地的油气特征及成藏过程表现出很强的复杂性，确定油气成藏年代极其困难，建立有效的成藏定年技术显得尤为迫切.为此基于稀有气体He年代积累效应和油气藏保存机制，建立了油气藏⁴He成藏定年地质模型及年龄估算公式，明确其为油气成藏定型时间；基于天然气⁴⁰Ar/³⁶Ar比值与源岩钾丰度及地质时代的关系，建立了追溯油气源岩时代的Ar同位素估算模型.磷灰石、锆石（U-Th）/He定年体系的封闭温度与含油气盆地生油气窗的温度范围较为一致，磷灰石、锆石（U-Th）/He年龄可以揭示含油气盆地抬升剥蚀时间、由构造抬升导致的油气藏调整时间，建立了固体沥青、原油中沥青质提取、溶样、Re-Os纯化富集及分离等Re-Os同位素测年前处理技术，可以直接确定固体沥青、原油等的形成时间.按照含油气系统成藏地质要素形成时间或发生时间先后顺序，提出了从确定源岩形成-油气生成-运移充注-调整改造-成藏定型等成藏过程的定年技术序列.开展四川盆地元坝气田源岩时代、生排烃、运移充注、调整改造及成藏定型等关键过程的时间节点综合研究，明确了元坝气田的主力气源为上二叠统龙潭组烃源岩，两期原油充注时间分别为220~175 Ma、168~140 Ma；油裂解气发生在140~118 Ma，元坝地区约97 Ma以来发生构造抬升，尤其15 Ma以来气-水界面发生调整，约在12~8 Ma气藏最终定型并形成现今的气藏格局.
- He、Ar成藏定年模型 /
- Re-Os同位素定年法 /
- U-Th/He定年 /
- 元坝气田 /
- 成藏关键时间节点 /
- 石油地质
Abstract: Petroleum characteristics and accumulation of the marine superimposed basins show strong complexity, which makes it difficult to determine key time of reservoir accumulation. It is urgent to establish effective dating methods for hydrocarbon source age, hydrocarbon generation and expulsion time, reservoir adjustment and stabilization time. On the basis of helium age accumulation effect and reservoir preservation mechanism, the helium dating model and age estimating formulas are put forward to determine the time of reservoir formation and stabilization retention after large scale of petroleum charging in this paper. According to the relationships between the ⁴⁰Ar/³⁶Ar ratio of natural gas, potassium abundance of source rock and the geological time, argon isotopic estimation model on the source rock age is fitting by many parameters. Based on the closure temperature on U-Th/He dating system of apatite and zircon being consistent with the temperature scope of hydrocarbon generation in sedimentary basin, uplift time and reservoir transformation time induced by tectonic uplift are revealed by means of time and closure temperature difference of close system in apatite and zircon, and geothermal gradient of sedimentary basin. By means of a series of condition test, pretreatment techniques including asphaltene extraction, acid dissolving, rhenium-osmium purity, enrichment and separation are established. Re-Os isotopic dating can be used to directly date hydrocarbon source rock, solid bitumen, oil and oil sand and offer hydrocarbon generation and migration time. According to priority of the formation time or occurrence time of geological part of reservoir, the key dating technologies to determine source rock age, hydrocarbon generating time, charging time, reservoir adjustment and stabilization time are established. By means of dating technologies, the key time including source rock age, hydrocarbon charging time, gas reservoir adjustment and stabilization time are determined in Yuanba gas field in Sichuan basin. It is indicated that the main gas source is composed of the Longtan Formation hydrocarbon source rocks, and two stages crude oil charging time being from 220 Ma to 175 Ma and from 168 Ma to 140 Ma, large scale crude oil began to crack into gas between 140 Ma and 118 Ma.Tectonic uplift began to occur since 97 Ma, especially since 15 Ma, gas and water interface began to adjust until gas reservoir kept stabilization between 12 Ma and 8 Ma.
- He and Ar dating model /
- Re-Os isotopic chronology /
- U-Th/He dating method /
- Yuanba gas field /
- crucial time of reservoir accumulation /
- petroleum geology

HTML全文

图 1 四川盆地元坝气田构造位置

Fig. 1. The structural location map of Yuanba gas field in Sichuan basin

下载: 全尺寸图片幻灯片

图 2 流体包裹体古温压恢复过程示意

Fig. 2. The process diagram of the paleo temperature-pressure recovery of fluid inclusions

下载: 全尺寸图片幻灯片

图 3 反演油气成藏关键过程的定年技术序列

Fig. 3. The dating technique series to infer the key time of petroleum accumulation process

下载: 全尺寸图片幻灯片

图 4 元坝气田流体包裹体显微照片

Fig. 4. Microscopic photographs of fluid inclusions in Yuanba gas field

下载: 全尺寸图片幻灯片

图 5 元坝气田热史—埋藏史及成藏关键过程的时间节点

Fig. 5. The key time of petroleum accumulation and thermal-burial history of Yuanba gas field

下载: 全尺寸图片幻灯片

表 1 元坝气田长兴组天然气氩同位素组成数据

Table 1. The argon isotope compositions of the Changxing Formation natural gas in Yuanba gas field

井号	层位	深度(m)	Ar浓度(%)	⁴⁰Ar/³⁶Ar
元坝1	P₂ch	7 330.7~7 367.6	0.001	507.0
元坝221	P₂ch	6 686~6 720	0.010	304.9
元坝222	P₂ch	7 020~7 030	0.008	353.3
元坝224	P₂ch	6 625~6 636	0.029	458.0
元坝273	P₂ch	6 811~6 880	0.036	475.0
元坝103H	P₂ch	7 729.8	0.001	595.0

下载: 导出CSV

表 2 元坝气田长兴组天然气⁴He丰度、氦同位素组成数据

Table 2. The ⁴He abundances and helium isotope compositions of the Changxing Formation natural gas in Yuanba gas field

气井	地层	井深(m)	⁴He(10^-6)	²⁰Ne(10^-6)	³He/⁴He	⁴He/²⁰Ne
元坝9	P₂ch	6 840	112	0.5	1.1×10^-8	245
元坝27	P₂ch	6 280	227	0.2	1.0×10^-8	1 115
元坝204	P₂ch	6 550	121	0.2	0.8×10^-8	517
元坝224	P₂ch	6 625	120	-	5.5×10^-9	-
元坝273	P₂ch	6 811	160	-	6.2×10^-9	-
元坝103	P₂ch	7 729	87	0.34	7.2×10^-9	256
	平均值		138	0.3	1.0×10^-8	626

下载: 导出CSV

参考文献(74)

Chen, H.H., Li, C.Q., Zhang, X.M., et al., 2003.Using Fluid Inclusions Determine Hydrocarbon Accumulation Times and the Main Reservoir Formation Periods in Tahe Oilfield.Earth Science Frontiers, 10(1):190(in Chinese with English abstract).
Du, J.G., Xu, Y.C., Sun, M.L., 1998.Helium Isotopes and Heat Flow in the Oil and Gas Bearing Basins in China's Continent.Acta Geophysica Sinica, 41(4):494-501(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DQWX199804007.htm
Duan, J.B., Li, P.P., Chen, D., et al., 2013.Formation and Evolution of the Reef Flat Facies Lithologic Gas Reservoir of Changxing Formation in Yuanba Gas Field, Sichuan Basin.Lithologic Reservoirs, 25(3):43-47, 91(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-YANX201303010.htm
Fan, X.J., 2012.Causes of Differences of Natural Gas Pooling between the Changxing Formation and the Feixianguan Formation in Yuanba, Sichuan Basin.Natural Gas Industry, 32(6):15-20(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-TRQG201206005.htm
Feng, M.G., Yan, L., Wang, X.L., et al., 2012.Lower Limit for Physical Property of Effective Reservoir in Changxing Formation, Yuanba Gas Field.Petroleum Geology & Experiment, 34(5):535-538(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SYSD201205018.htm
Green, P.F., Duddy, I.R., Crowhurst, P.V., et al., 2003.Integrated (U-Th)/He Dating, AFTA and Vitrinite Reflectance Results in Seven Otway Basin Wells Confirm Regional Late Miocene Exhumation and Validate Helium Diffusion Systematic.Annual Meeting Expanded Abstracts-American Association of Petroleum Geologists, 12:67. http://www.mendeley.com/catalog/integrated-uthhe-dating-afta-vitrinite-reflectance-results-seven-otway-basin-wells-confirm-regional/
Guo, T.L., 2011.Basic Characteristics of Deep Reef-Bank Reservoirs and Major Controlling Factors of Gas Pools in the Yuanba Gas Field.Natural Gas Industry, 31(10):12-16(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-TRQG201110005.htm
Guo, X.S., Hu, D.F., 2011.Newest Progress and Key Techniques in Gas Exploration of Reef-Bank Reservoirs in the Northeastern Sichuan Basin.Natural Gas Industry, 31(10):6-11(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-TRQG201110004.htm
Guo, X.S., Huang, R.C., Fu, X.Y., et al., 2014.Gas Accumulation and Exploration Direction of the Permian and Triassic Reservois of Reef-Bank Facies in Sichuan Basin.Oil & Gas Geology, 35(3):295-302(in Chinese with English abstract). http://www.en.cnki.com.cn/Article_en/CJFDTOTAL-SYYT201403002.htm
House, M.A., Wernicke, B.P., Farley, K.A., 1998.Dating Topography of the Sierra Nevada, California, Using Apatite (U-Th)/He Ages.Nature, 396:66-69. https://doi.org/10.1038/23926
Lawley, C., Selby, D., Imber, J., 2013.Re-Os Molybdenite, Pyrite, and Chalcopyrite Geochronology, Lupa Goldfield, Southwestern Tanzania:Tracing Metallogenic Time Scales at Midcrustal Shear Zones Hosting Orogenic Au Deposits.Economic Geology, 108(7):1591-1613. https://doi.org/10.2113/econgeo.108.7.1591
Liu, B., Shen, K., 1999.Fluid Inclusion Thermodynamics.Geological Publishing House, Beijing, 200-268(in Chinese).
Liu, D.H., Dai, J.X., Xiao, X.M., et al., 2010.High Density Methane Inclusions in Puguang Gasfield:Discovery and a T-P Genetic Study.Science Bulletin, 55(Suppl.):359-366(in Chinese). http://kns.cnki.net/KCMS/detail/detail.aspx?filename=jxtw200924027&dbname=CJFD&dbcode=CJFQ
Liu, W.H., Chen, M.J., Guan, P., et al., 2007.Ternary Geochemical-Tracing System in Natural Gas Accumulation.Science in China(Series D), 37(7):908-915(in Chinese).
Liu, W.H., Tao, C., Borjigin, T., et al., 2017.Formation Time of Gas Reservoir Constrained by the Time-Accumulation Effect of ⁴He:Case Study of the Puguang Gas Reservoir.Chemical Geology, 469:246-251. https://doi.org/10.13039/501100001809
Liu, W.H., Wang, J., Tao, C., et al., 2013.The Geochronology of Petroleum Accumulation of China Marine Sequence.Natural Gas Geoscience, 24(2):199-209(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-TDKX201302002.htm
Liu, W.H., Xu, Y.C., 1993.Significance of the Isotopic Composition of He and Ar in Natural Gas.Chinese Science Bulletin, 38(20):1726-1730. https://doi.org/10.1360/sb1993-38-20-1726
Ma, Y.S., Cai, X.Y., Zhao, P.R., 2014.Characteristics and Formation Mechanisms of Reef-Shoal Carbonate Reservoirs of Changxing-Feixianguan Formations, Yuanba Gas Field.Acta Petrolei Sinica, 35(6):1001-1011(in Chinese with English abstract). http://www.en.cnki.com.cn/Article_en/CJFDTOTAL-SYXB201406001.htm
Mi, J.K., Zhang, S.C., Tu, J.Q., et al., 2006.Formation of Hadexun Oilfield in Tarim Basin, NW China.Geochimica, 35(4):405-412(in Chinese with English abstract). http://en.cnki.com.cn/article_en/cjfdtotal-dqhx200604008.htm
Qin, J.Z., Wang, J., Qiu, N.S., 2008.Evidence of Thermal Evolution History of Northeast Sichuan Basin-(U-Th)/He Low Temperature Thermochronometry of Apatite and Zircon.Journal of Earth Science, 19(6):591-601.
Qiu, N.S., Qin, J.Z., McInner, B.I.A., et al., 2008.Tectonothermal Evolution of the Northeastern Sichuan Basin:Constraints from Apatite and Zircon (U-Th)/He Ages and Vitrinite Reflectance Data.Geological Journal of China Universities, 14(2):223-230(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-GXDX200802012.htm
Reiners, P.W., Farley, K.A., Hickes, H.J., 2002.He Diffusion and (U-Th)/He Thermochronometry of Zircon:Initial Results from Fish Canyon Tuff and Gold Butte.Tectonophysics, 349(1-4):297-308. https://doi.org/10.1016/s0040-1951(02)00058-6
Reiners, P.W., Zhou, Z.Y., Ehlers, T.A., et a1., 2003.Post-Orogenic Evolution of the Dabie Shan, Eastern China, from (U-Th)/He and Fission Track Thermochronology.American Journal of Science, 303(6):489-518. https://doi.org/10.2475/ajs.303.6.489
Rooney, A.D., Selby, D., Lewan, M.D., et al., 2012.Evaluating Re-Os Systematics in Organic-Rich Sedimentary Rocks in Response to Petroleum Generation Using Hydrous Pyrolysis Experiments.Geochimica et Cosmochimica Acta, 77(2):275-291. https://doi.org/10.1016/j.gca.2011.11.006
Saigal, G.C., Bjorlykke, K., Later, S., 1992.The Effects of Oil Emplacement on Diagenetic Processes:Examples from the Fulmar Reservoir Sandstones, Central North Sea.AAPG Bulletin, 76(7):1024-1033. http://www.mendeley.com/research/effects-oil-emplacement-diagenetic-processes-examples-fulmar-reservoir-sandstones-central-north-sea/
Selby, D., Creaser, R.A., 2001.Re-Os Geochronology and Systematics in Molybdenite from the Endako Porphyry Molybdenum Deposit, British Columbia, Canada.Economic Geology, 96(1):197-204. https://doi.org/10.2113/gsecongeo.96.1.197
Selby, D., Creaser, R.A., 2005.Direct Radiometric Dating of Hydrocarbon Deposits Using Rhenium-Osmium Isotopes.Science, 308(5726):1293-1295. https://doi.org/10.1126/science.1111081
Selby, D., Creaser, R.A., Fowler, M.G., 2007.Re-Os Elemental and Isotopic Systematics in Crude Oils.Geochimica et Cosmochimica Acta, 71(2):378-386. https://doi.org/10.1016/j.gca.2006.09.005
Shi, W.J., Xi, B.B., 2016.Calculation of Paleo-Pressure in Gas Reservoirs Using Fluid Inclusions.Petroleum Geology & Experiment, 38(1):128-134(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-SYSD201601019.htm
Stein, H.J., Sundblad, K., Markey, R.J., et al., 1998.Re-Os Ages for Archean Molybdenite and Pyrite, Kuittila-Kivisuo, Finland and Proterozoic Molybdenite, Kabeliai, Lithuania:Testing the Chronometer in a Metamorphic and Metasomatic Setting.Mineralium Deposita, 33(4):329-345. https://doi.org/10.1007/s001260050153
Stock, G.M., Ehlers, T.A., Farley, K.A., 2006.Where does Sediment Come from? Quantifying Catchment Erosion with Detrital Apatite(U-Th)/He Thermochronometry.Geology, 34(9):725. https://doi.org/10.1130/g22592.1
Tao, M.X., Xu, Y.C., Shen, P., et al., 1996.Tectonic and Geochemical Characteristics and Reserved Conditions of a Mantle Source Gas Accumulation Zone in Eastern China.Science in China(Series D), 26(6):531-536(in Chinese). http://kns.cnki.net/KCMS/detail/detail.aspx?filename=jdxg199701008&dbname=CJFD&dbcode=CJFQ
Thiéry, R., Pironon, J., Walgenwitz, F., et al., 2002.Individual Characterization of Petroleum Fluid Inclusions (Composition and P-T Trapping Conditions) by Microthermometry and Confocal Laser Scanning Microscopy:Inferences from Applied Thermodynamics of Oils.Marine and Petroleum Geology, 19(7):847-859. https://doi.org/10.1016/s0264-8172(02)00110-1
Wang, J., Boltsjun, T., Qin, J.Z., et al., 2013.Mesozoic Tectonic Evolution and Thermal History of the Yuanba Area of Northeast Sichuan Basin-Low Temperature Thermochronology of Apatite and Zircon.Journal of Earth Science, 24(4):599-605. https://doi.org/10.1007/s12583-013-0355-9
Wang, J., Liu, W.H., Tao, C., et al., 2010.⁴⁰Ar Dating Model of Gas Source Rocks and the Quantitative Identification of Mixture Ratios for Duality Sourced Gases in Gas Reservoirs.Natural Gas Geoscience, 21(1):125-131(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-TDKX201001017.htm
Wang, J., Qin, J.Z., Liu, W.H., et al., 2012.Mesozoic Tectonics and Dynamic Thermal History in Yuanba Area of Northeastern Sichuan Basin:Application of (U-Th)/He Dating of Apatite and Zircon.Petroleum Geology & Experiment, 34(1):19-24(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-SYSD201201006.htm
Wang, J., Tenger, Liu, W.H., et al., 2016.Definition of Petroleum Generating Time for Lower Cambrian Bitumen of the Kuangshanliang in the West Sichuan Basin, China:Evidence from Re-Os Isotopic Isochron Age.Natural Gas Geoscience, 27(7):1290-1298(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=trqdqkx201607014
Wu, X.Q., Liu, G.X., Liu, Q.Y., et al., 2015.Geochemical Characteristics and Genetic Types of Natural Gas in the Changxing-Feixianguan Formations from Yuanba Gas Field in the Sichuan Basin.Natural Gas Geoscience, 26(11):2155-2165(in Chinese with English abstract). http://www.en.cnki.com.cn/Article_en/CJFDTotal-TDKX201511018.htm
Xi, B.B., Shi, W.J., Jiang, H., et al., 2014.Synthesis of N₂-CH₄ and N₂-CO₂ Gas Mixtures as an Online Standard and Determination of Their Raman Quantification Factors of CH₄ and CO₂.Rock and Mineral Analysis, 33(5):655-660(in Chinese with English abstract).
Xiao, X.M., Liu, Z.F., Liu, D.H., et al., 2002.Dating Formation of Natural Gas Pools Using Fluid Inclusion Data from Reservoirs.Chinese Science Bulletin, 47(12):957-960 (in Chinese). http://kns.cnki.net/KCMS/detail/detail.aspx?filename=jxtw200218015&dbname=CJFD&dbcode=CJFQ
Xu, Y.C., 1996.The Mantle Noble Gas of Natural Gases.Earth Science Frontiers, 3(3-4):63-71(in Chinese with English abstract).
Yamashita, Y., Takahashi, Y., Haba, H., et al., 2007.Comparision of Reductive Accumulation of Re and Os in Seawater-Sediment System.Geochimica et Cosmochimica Acta, 71(14):3458-3475. https://doi.org/10.1016/j.gca.2007.05.003
Yan, L., Feng, M.G., Zhang, C.Y., 2011.Hydrocarbon Accumulation Mode of Changxing Formation in YB Area of Northeastern Sichuan Basin.Journal of Yangtze University(Natural Science Edition), 8(10):19-21(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-CJDL201110005.htm
Zhang, Y.C., Zou, H.Y., Li, P.P., et al., 2010.Fluid Inclusion Feature and Hydrocarbon Charge History of Changxing Formation in Yuanba Area in Northeastern Sichuan Basin.Xinjiang Petroleum Geology, 31(3):250-251(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-XJSD201003013.htm
Zhang, Y.Y., Horst, Z., Liu, K.Y., et al., 2007.K-Ar Isotopic Dating of Authigenic Illite and Its Application to the Investigation of Hydrocarbon Accumulation History of the Silurian Bituminous Sandstone Reservoirs in the Tazhong Uplift, Tarim Basin.Oil & Gas Geology, 28(2):166-174(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-SYYT200702009.htm
Zhao, J.Z., 2002.Geochronology of Petroleum Accumulation:New Advances and the Future Trend.Advance in Earth Sciences, 17(3):378-383(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DXJZ200203013.htm
陈红汉, 李纯泉, 张希明, 等, 2003.运用流体包裹体确定塔河油田油气成藏期次及主成藏期.地学前缘, 10(1):190. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dxqy200301042
杜建国, 徐永昌, 孙明良, 1998.中国大陆含油气盆地的氦同位素组成及大地热流密度.地球物理学报, 41(4):494-501. http://www.cqvip.com/Main/Detail.aspx?id=3090048
段金宝, 李平平, 陈丹, 等, 2013.元坝气田长兴组礁滩相岩性气藏形成与演化.岩性油气藏, 25(3):43-47, 91. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yxyqc201303007
范小军, 2012.川东北元坝地区长兴组与飞仙关组天然气成藏差异性成因.天然气工业, 32(6):15-20. http://mall.cnki.net/magazine/Article/TRQG201206005.htm
冯明刚, 严丽, 王雪玲, 等, 2012.元坝气田长兴组气藏有效储层物性下限标准研究.石油实验地质, 34(5):535-538. doi: 10.11781/sysydz201205535
郭彤楼, 2011.元坝深层礁滩气田基本特征与成藏主控因素.天然气工业, 31(10):12-16. doi: 10.3787/j.issn.1000-0976.2011.10.003
郭旭升, 胡东风, 2011.川东北礁滩天然气勘探新进展及关键技术.天然气工业, 31(10):6-11. doi: 10.3787/j.issn.1000-0976.2011.10.002
郭旭升, 黄仁春, 付孝悦, 等, 2014.四川盆地二叠系和三叠系礁滩天然气富集规律与勘探方向.石油与天然气地质, 35(3):295-302. http://www.cqvip.com/QK/95357X/201403/661749434.html
刘斌, 沈昆, 1999.流体包裹体热力学.北京:地质出版社, 200-268.
刘德汉, 戴金星, 肖贤明, 等, 2010.普光气田中高密度甲烷包裹体的发现及形成的温度和压力条件.科学通报, 55(增刊):359-366. http://www.cnki.com.cn/Article/CJFDTotal-KXTB2010Z1010.htm
刘文汇, 陈孟晋, 关平, 等, 2007.天然气成藏过程的三元地球化学示踪体系.中国科学(D辑), 37(7):908-915. http://www.cqvip.com/QK/98491X/200707/25024320.html
刘文汇, 王杰, 陶成, 等, 2013.中国海相层系油气成藏年代学.天然气地球科学, 24(2):199-209. http://mall.cnki.net/magazine/article/TDKX201302002.htm
马永生, 蔡勋育, 赵培荣, 2014.元坝气田长兴组-飞仙关组礁滩相储层特征和形成机理.石油学报, 35(6):1001-1011. doi: 10.7623/syxb201406001
米敬奎, 张水昌, 涂建琪, 等, 2006.哈得逊油田成藏研究.地球化学, 35(4):405-412. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqhx200604008
邱楠生, 秦建中, McInner, B.I.A., 等, 2008.川东北地区构造-热演化探讨——来自(U-Th)/He年龄Ro的约束.高校地质学报, 14(2):223-230. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=gxdx200802012&dbname=CJFD&dbcode=CJFQ
施伟军, 席斌斌, 2016.应用包裹体技术恢复气藏古压力.石油实验地质, 38(1):128-134. doi: 10.11781/sysydz201601128
陶明信, 徐永昌, 沈平, 等, 1996.中国东部幔源气藏聚集带的大地构造与地球化学特征及成藏条件.中国科学(D辑), 26(6):531-536. http://mall.cnki.net/magazine/Article/TDKX200701003.htm
王杰, 刘文汇, 陶成, 等, 2010.天然气藏二元混源比例定量判识探讨及气源岩⁴⁰Ar年龄模型.天然气地球科学, 21(1):125-131. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=tdkx201001017&dbname=CJFD&dbcode=CJFQ
王杰, 秦建中, 刘文汇, 等, 2012.川东北元坝地区中生代构造与动态热演化史——磷灰石、锆石(U-Th)/He定年分析.石油实验地质, 34(1):19-24. doi: 10.11781/sysydz201201019
王杰, 腾格尔, 刘文汇, 等, 2016.川西矿山梁下寒武统沥青脉油气生成时间的厘定——来自固体沥青Re-Os同位素等时线年龄的证据.天然气地球科学, 27(7):1290-1298. doi: 10.11764/j.issn.1672-1926.2016.07.1290
吴小奇, 刘光祥, 刘全有, 等, 2015.四川盆地元坝气田长兴组-飞仙关组天然气地球化学特征及成因类型.天然气地球科学, 26(11):2155-2165. doi: 10.11764/j.issn.1672-1926.2015.11.2155
席斌斌, 施伟军, 蒋宏, 等, 2014.N₂-CH₄(CO₂)混合气体在线标样制备及其拉曼定量因子测定.岩矿测试, 33(5):655-660. http://www.adearth.ac.cn/article/2016/1001-8166-31-10-1032.html
肖贤明, 刘祖发, 刘德汉, 等, 2002.应用储层流体包裹体信息研究天然气气藏的成藏时间.科学通报, 47(12):957-960. doi: 10.3321/j.issn:0023-074X.2002.12.016
徐永昌, 1996.天然气中的幔源稀有气体.地学前缘, 3(3-4):63-71. http://www.cqvip.com/QK/98600X/1996003/2224516.html
严丽, 冯明刚, 张春燕, 2011.川东北元坝地区长兴组油气藏成藏模式.长江大学学报(自然版), 8(10):19-21. http://www.cnki.com.cn/Article/CJFDTOTAL-CJDL201110005.htm
张元春, 邹华耀, 李平平, 等, 2010.川东北元坝地区长兴组流体包裹体特征及油气充注史.新疆石油地质, 31(3):250-251. http://www.cnki.com.cn/Article/CJFDTotal-CJDL201320005.htm
张有瑜, Horst, Z., 刘可禹, 等, 2007.塔中隆起志留系沥青砂岩油气储层自生伊利石K-Ar同位素测年研究与成藏年代探讨.石油与天然气地质, 28(2):166-174. doi: 10.11743/ogg20070206
赵靖舟, 2002.油气成藏年代学研究进展及发展趋势.地球科学进展, 17(3):378-383. http://mall.cnki.net/magazine/Article/DXJZ200203013.htm
