Segmentation Characteristic and Its Effect on Sag Evolution in Cenozoic of Chengbei Fault, Bohai Bay Basin
-
摘要: 形成于中生代、NW走向的埕北断层位于渤海湾盆地中部，为明确其新生代分段发育特征及对埕北凹陷演化的差异控制作用，在整合渤海油田和胜利油田探区三维地震勘探资料、测井资料基础上，对断层几何学、运动学特征和断层控制下的地层展布特征进行综合分析.结果表明：埕北断层新生代呈NW走向展布的"M"形，由2段NWW走向和2段NNW走向的断层分段相间排列、首尾相连而成；经历Ek-Es4（~65~42 Ma）分段复活，Es3-Ed（~42~23 Ma）连通拉张，N-Q（~23~0 Ma）走滑改造3个演化阶段；4个分段在新生代的差异演化控制了埕北凹陷内新生界基底形态、地层超覆、横向背斜发育以及次洼的差异演化，断层分段控制下的凹陷演化可分为3个阶段：Ek-Es4的横向扩张阶段，Es3-Ed的垂向加深阶段以及N-Q的走滑改造阶段.Abstract: The NW-trending Chengbei fault was formed in the Mesozoic and located at the central part of the Bohai bay basin. In order to clarify the fault segmentation characteristics and its control over the framework of the Chengbei sag during the Cenozoic evolution, we integrate 3D seismic exploration data, well logging data from Bohai oil field and Shengli oil field, and analyzes the geometric features, activity rate of the fault and the contact relationship and distribution characteristics of the strata in the sag. The results show that the Cenozoic Chengbei fault is connected by four segments in NWW-and NNW-trending with an 'M' shape on the plan view; the Chengbei fault experienced 3 stages during its evolution in the Cenozoic:reactivation in segment during Ek-Es4 (~65-42 Ma), connection stage during Es3-Ed (~42-23 Ma), and strike-slip transformation stage during N-Q (~23-0 Ma); the evolution of the four segments in the Cenozoic dominated the basement morphology, strata onlap, transverse anticline development, and the evolution of the sub-sag, by the control of the Chengbei fault segments the Chengbei sag evolution can be divided into three stages:the horizontal expansion stage during Ek-Es4, the vertical deepening stage during Es3-Ed and the strike-slip reconstruction stage during N-Q.
-
Key words:
- fault segment /
- sag evolution /
- Chengbei fault /
- Cenozoic /
- Bohai bay basin /
- petroleum geology
-
图 1 埕北地区构造纲要及地层序列图
Fig. 1. Structure map and stratigraphic sequences of the Chengbei area
图 3 埕北断层各层系界面断层发育平面图
三维资料缺失处以虚线表示
Fig. 3. Map view of the Chengbei fault at different surfaces
图 5 埕北断层各段不同时期断层垂向活动速率
数据点位置见图 1
Fig. 5. The fault activerate of Chengbei fault segments during different periods
-
Allen, M.B., MacDonald, D.I.M., Xun, Z., et al., 1997.Early Cenozoic Two-Phase Extension and Late Cenozoic Thermal Subsidence and Inversion of the Bohai Basin, Northern China.Marine and Petroleum Geolgoy, 14(7-8):951-972. https://doi.org/10.1016/s0264-8172(97)00027-5 Anders, M.H., Schlische, R.W., 1994.Overlapping Faults, Intrabasin Highs, and the Growth of Normal Faults.The Journal of Geology, 102(2):165-179. https://doi.org/10.1086/629661 Cheng, Y.J., Wu, Z.P., Lu, S.N., et al., 2018.Mesozoic to Cenozoic Tectonic Transition Process in Zhanhua Sag, Bohai Bay Basin, East China.Tectonophysics, (730):11-28. https://doi.org/10.1016/j.tecto.2018.02.010 Childs, C., Nicol, A., Walsh, J.J., et al., 2003.The Growth and Propagation of Synsedimentary Faults.Journal of Structural Geology, 25(4):633-648. https://doi.org/10.1016/s0191-8141(02)00054-8 Fossen, H., 2016.Structural Geology.Cambridge University Press.United Kingdom, 199-200. Gao, Z.W., Xu, J., Song, C.Q., et al., 2001.The Segmental Character of Zhangjiakou-Penglai Fault.North China Earthquake Sciences, 19(1):35-42(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hbdzkx200101006 Guo, L.L., Li, S.Z., Suo, Y.H., et al., 2015.Experimental Study and Active Tectonics on the Zhangjiakou-Penglai Fault Zone across North China.Journal of Asian Earth Sciences, 114:18-27. https://doi.org/10.1016/j.jseaes.2015.03.045 Harding, T.P., 1974.Petroleum Traps Associated with Wrench Faults.AAPG Bulletin, 58(7):1290-1304. https://doi.org/10.1306/83d91669-16c7-11d7-8645000102c1865d Hou, G.T., Qian, X.L., Cai, D.S., 2000.Space-Time Relationship between Tectonics and Sedimentation of Meso-Cenozoic Bohai Basin.Oil & Gas Geology, 21(3):201-206(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syytrqdz200003004 Huang, L., Liu, C.Y., Kusky, T.M., 2015.Cenozoic Evolution of the Tan-Lu Fault Zone (East China):Constraints from Seismic Data.Gondwana Research, 28(3):1079-1095. https://doi.org/10.1016/j.gr.2014.09.005 Huang, L., Liu, C.Y., Wang, Y.B., et al., 2014.Neogene-Quaternary Postrift Tectonic Reactivation of the Bohai Bay Basin, Eastern China.AAPG Bulletin, 98(7):1377-1400. https://doi.org/10.1306/03071413046 Kang, H.Q., Li, M.G., Jia, H.C., et al., 2017.Evaluation Method of Large Boundary Normal Fault Activity and Its Application.Fault-Block Oil & Gas Field, 24(3):307-310(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dkyqt201703002 Li, S.Z., Suo, Y.H., Dai, L.M., et al., 2010.Development of the Bohai Bay Basin and Destruction of the North China Craton.Earth Science Frontiers, 17(4):64-89(in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/dxqy201004006 Li, S.Z., Suo, Y.H., Santosh, M., et al., 2013.Mesozoic to Cenozoic Intracontinental Deformation and Dynamics of the North China Craton.Geological Journal, 48(5):543-560. https://doi.org/10.1002/gj.2500 Li, S.Z., Zhao, G.C., Dai, L.M., et al., 2012.Cenozoic Faulting of the Bohai Bay Basin and Its Bearing on the Destruction of the Eastern North China Craton.Journal of Asian Earth Sciences, 47(1):80-93. https://doi.org/10.1016/j.jseaes.2011.06.011 Li, W., Wu, Z.P., Zhang, M.H., et al., 2006.Development Characteristic of Mesozoic and Cenozoic Faults and Its Control over Deposition in Chengdao Area.Journal of China University of Petroleum(Edition of Natural Science), 30(1):1-6(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=sydxxb200601001 Liu, S.F., Gurnis, M., Ma, P.F., et al., 2017.Reconstruction of Northeast Asian Deformation Integrated with Western Pacific Plate Subduction since 200 Ma.Earth-Science Reviews, 175:114-142. https://doi.org/10.1016/j.earscirev.2017.10.012 Lu, S.N., Wu, Z.P., Cheng, Y.J., et al., 2018.Division of Differential Tectonic Evolution in Shengli Shallow Sea Area of Jiyang Depression.Petroleum Geology and Recovery Efficiency, 25(4):61-66(in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/yqdzycsl201804010 Morley, C.K., 2002.Evolution of Large Normal Faults:Evidence from Seismic Reflection Data.AAPG Bulletin, 86(6):961-978. https://doi.org/10.1306/61eedbfc-173e-11d7-8645000102c1865d Morley, C.K., Nelson, R.A., Patton, T.L., et al., 1990.Transfer Zones in the East African Rift System and Their Relevance to Hydrocarbon Exploration in Rifts.AAPG Bulletin, 74(8):1234-1253. http://doi.org/10.1306/0c9b2475-1710-11d7-8645000102c1865d Peacock, D.C.P., Sanderson, D.J., 1991.Displacements, Segment Linkage and Relay Ramps in Normal Fault Zones.Journal of Structural Geology, 13(6):721-733. doi: 10.1016/0191-8141(91)90033-F Qi, J.F., Yang, Q., 2010.Cenozoic Structural Deformation and Dynamic Processes of the Bohai Bay Basin Province, China.Marine and Petroleum Geology, 27(4):757-771. https://doi.org/10.1016/j.marpetgeo.2009.08.012 Qi, J.F., Yu, F.S., Lu, K.Z., et al., 2003.Conspectus on Mesozoic Basins in Bohai Bay Province.Earth Science Frontiers, 10(Suppl.1):199-206(in Chinese with English abstract. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dxqy2003z1028 Qin, T., Yu, H.B., Cai, J.Y., et al., 2017.Evolution of Chengbei Boundary Faults and Their Controlling Effect on Tectonic Framework.Society of Exploration Geophysicists. https://doi.org/10.1190/segam2017-17655491.1 Ren, J.Y., 2018.Genetic Dynamics of China Offshore Cenozoic Basins.Earth Science, 43(10):3337-3361(in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/dqkx201810002 Rotevatn, A., Jackson, C.A.L., Tvedt, A.B.M., et al., 2019.How do Normal Faults Grow? Journal of Structural Geology, 125:174-184. https://doi.org/10.1016/j.jsg.2018.08.005 Suo, Y.H., Li, S.Z., Cao, X.Z., et al., 2017.Mesozoic-Cenozoic Inversion Tectonics of East China and Its Implications for the Subduction Process of the Oceanic Plate.Earth Science Frontiers, 24(4):249-267(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dxqy201704023 Suo, Y.H., Li, S.Z., Liu, X., et al., 2013.Structural Characteristics of NWW Trending Active Fault Zones in East China:A Case Study of the Zhangjiakou-Penglai Fault Zone.Acta Petrologica Sinica, 29(3):953-966(in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/ysxb98201303017 Whipp, P.S., Jackson, C.A.L., Schlische, R.W., et al., 2017.Spatial Distribution and Evolution of Fault-Segment Boundary Types in Rift Systems:Observations from Experimental Clay Models.Geological Society, London, Special Publications, 439(1):79-107. doi: 10.1144/SP439.7 Wu, Z.P., Hou, X.B., Li, W., 2007.Disscussion on Mesozoic Basin Patterns and Evolution in the Eastern North China Block.Geotectonica et Metallogenia, 31(4):385-399(in Chinese with English abstract). Wu, Z.P., Li, W., Ren, Y.J., et al., 2003.Basin Evolution in the Mesozoic and Superposition of Cenozoic Basin in the Area of the Jiyang Depression.Acta Geologica Sinica, 77(2):280-286(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dizhixb200302017 Yu, Y.X., Zhou, X.H., Xu, C.G., et al., 2011.Characteristics and Formation Mechanisms of the Cenozoic Faults in the Bohai Sea Waters.Oil & Gas Geology, 32(2):273-279(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syytrqdz201102016 Yu, Y.X., Zhou, X.H., Xu, C.G., et al., 2018.Fault Interactions and Their Significances for Hydrocarbon Accumulation in Offshore Bohai Bay Basin, Eastern China.Oil & Gas Geology, 39(1):11-19(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syytrqdz201801002 Zhang, J., Li, W., Wu, Z.P., et al., 2017.Structural Characteristics of Tan-Lu Fault Zone in South Area of Bohai Sea and Its Control on Basin Structure.Earth Science, 42(9):1549-1564(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqkx201709009 Zhang, Q., Liu, L.F., Zhang, X.Q., et al., 2017.Development of Structure and Its Control on Sedimentary System of Paleogene in Chengbei Sag.Journal of Northeast Petroleum University, 41(4):88-98(in Chinese with English abstract). Zhang, X.Q., Wu, Z.P., Zhou, X.H., et al., 2017.Cenozoic Tectonic Characteristics and Evolution of the Southern Bohai Sea.Geotectonica et Metallogenia, 41(1):50-60(in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/hydzdt201711002 Zhou, X.H., Yu, Y.X., Tang, L.J., et al., 2010.Cenozoic Offshore Basin Architecture and Division of Structural Elements in Bohai Sea.China Offshore Oil and Gas, 22(5):285-289(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zghsyq-gc201005001 Zhu, R.X., Chen, L., Wu, F.Y., et al., 2011.Timing, Scale and Mechanism of the Destruction of the North China Craton.Science China:Earth Sciences, 42(5):583-592(in Chinese). 高战武, 徐杰, 宋长青, 等, 2001.张家口-蓬莱断裂带的分段特征.华北地震科学, 19(1):35-42. doi: 10.3969/j.issn.1003-1375.2001.01.006 侯贵廷, 钱祥麟, 蔡东升, 2000.渤海中、新生代盆地构造活动与沉积作用的时空关系.石油与天然气地质, 21(3):201-206. doi: 10.3321/j.issn:0253-9985.2000.03.004 康洪全, 李明刚, 贾怀存, 等, 2017.大型控盆边界正断层活动性评价方法及应用.断块油气田, 24(3):307-310. http://d.old.wanfangdata.com.cn/Periodical/dkyqt201703002 李三忠, 索艳慧, 戴黎明, 等, 2010.渤海湾盆地形成与华北克拉通破坏.地学前缘, 17(4):64-89. http://d.old.wanfangdata.com.cn/Periodical/dxqy201004006 李伟, 吴智平, 张明华, 等, 2006.埕岛地区中生代和新生代断层发育特征及其对沉积的控制作用.中国石油大学学报(自然科学版), 30(1):1-6. doi: 10.3321/j.issn:1000-5870.2006.01.001 卢姝男, 吴智平, 程燕君, 等, 2018.济阳坳陷滩海地区构造演化差异性分区.油气地质与采收率, 25(4):61-66. http://d.old.wanfangdata.com.cn/Periodical/yqdzycsl201804010 漆家福, 于福生, 陆克政, 等, 2003.渤海湾地区的中生代盆地构造概论.地学前缘, 10(增刊1):199-206. http://d.old.wanfangdata.com.cn/Periodical/dxqy2003z1028 任建业, 2018.中国近海海域新生代成盆动力机制分析.地球科学, 43(10):3337-3361. doi: 10.3799/dqkx.2018.330 索艳慧, 李三忠, 曹现志, 等, 2017.中国东部中新生代反转构造及其记录的大洋板块俯冲过程.地学前缘, 24(4):249-267. http://d.old.wanfangdata.com.cn/Periodical/dxqy201704023 索艳慧, 李三忠, 刘鑫, 等, 2013.中国东部NWW向活动断裂带构造特征:以张家口-蓬莱断裂带为例.岩石学报, 29(3):953-966. http://d.old.wanfangdata.com.cn/Periodical/ysxb98201303017 吴智平, 侯旭波, 李伟, 2007.华北东部地区中生代盆地格局及演化过程探讨.大地构造与成矿学, 31(4):385-399. doi: 10.3969/j.issn.1001-1552.2007.04.001 吴智平, 李伟, 任拥军, 等, 2003.济阳坳陷中生代盆地演化及其与新生代盆地叠合关系探讨.地质学报, 77(2):280-286. doi: 10.3321/j.issn:0001-5717.2003.02.017 余一欣, 周心怀, 徐长贵, 等, 2011.渤海海域新生代断裂发育特征及形成机制.石油与天然气地质, 32(2):273-279. http://d.old.wanfangdata.com.cn/Periodical/syytrqdz201102016 余一欣, 周心怀, 徐长贵, 等, 2018.渤海海域断裂相互作用及其油气地质意义.石油与天然气地质, 39(1):11-19. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syytrqdz201801002 张婧, 李伟, 吴智平, 等, 2017.郯庐断裂带渤南段构造特征及其控盆作用.地球科学, 42(9):1549-1564. doi: 10.3799/dqkx.2017.110 张强, 刘丽芳, 张晓庆, 等, 2017.埕北凹陷古近系构造对沉积的控制作用.东北石油大学学报, 41(4):88-98. doi: 10.3969/j.issn.2095-4107.2017.04.010 张晓庆, 吴智平, 周心怀, 等, 2017.渤海南部新生代构造发育与演化特征.大地构造与成矿学, 41(1):50-60. http://d.old.wanfangdata.com.cn/Periodical/ddgzyckx201701004 周心怀, 余一欣, 汤良杰, 等, 2010.渤海海域新生代盆地结构与构造单元划分.中国海上油气, 22(5):285-289. doi: 10.3969/j.issn.1673-1506.2010.05.001 朱日祥, 陈凌, 吴福元, 等, 2011.华北克拉通破坏的时间、范围与机制.中国科学:地球科学, 42(5):583-592. http://www.cnki.com.cn/Article/CJFDTotal-JDXK201105001.htm -
