    莺歌海盆地高温高压盖层封盖能力定量评价

    谢玉洪

    谢玉洪, 2019. 莺歌海盆地高温高压盖层封盖能力定量评价. 地球科学, 44(8): 2579-2589. doi: 10.3799/dqkx.2019.095
    引用本文: 谢玉洪, 2019. 莺歌海盆地高温高压盖层封盖能力定量评价. 地球科学, 44(8): 2579-2589. doi: 10.3799/dqkx.2019.095
    Xie Yuhong, 2019. Quantitative Evaluation of Sealing Capacity of High Temperature and Pressure Caprocks in Yinggehai Basin. Earth Science, 44(8): 2579-2589. doi: 10.3799/dqkx.2019.095
    Citation: Xie Yuhong, 2019. Quantitative Evaluation of Sealing Capacity of High Temperature and Pressure Caprocks in Yinggehai Basin. Earth Science, 44(8): 2579-2589. doi: 10.3799/dqkx.2019.095

    莺歌海盆地高温高压盖层封盖能力定量评价

    doi: 10.3799/dqkx.2019.095
    基金项目:

    国家科技重大专项“莺琼盆地高温高压天然气富集规律与勘探开发关键技术(三期) 2016ZX05024005

    详细信息
      作者简介:

      谢玉洪(1961-), 男, 教授级高级工程师, 主要从事油气勘探研究工作

    • 中图分类号: P588

    Quantitative Evaluation of Sealing Capacity of High Temperature and Pressure Caprocks in Yinggehai Basin

    • 摘要: 莺歌海盆地是我国南海重要的新生代含油气盆地,随着浅层常压层系天然气开发程度的逐渐提高,中深层高温高压层系成为天然气勘探的主要目标,超压背景下盖层封闭的有效性受到广泛关注.近年来,不同学者针对莺歌海盆地盖层进行了大量的研究,但是对高温高压的气藏盖层的封闭机理、破坏条件及其定量评价仍存在一定的问题.通过对莺歌海盆地中深层高温高压层系盖层进行系统的分析,明确盖层的封闭机理为毛细管封闭和水力封闭.利用泥岩盖层排替压力、声波时差及孔隙度之间的关系,对莺歌海盆地区域性盖层的毛细管封闭能力进行预测.莺歌海盆地中深层盖层普遍具有较强的毛细管封闭能力.因此,超压诱发的水力破裂是油气多层位聚集的根本原因,进而提出了盖层水力破裂压力系数定量评价盖层水力破裂风险性.评价结果显示,盖层发生水力破裂与底辟构造活动具有明显的相关性,盖层水力破裂风险由底辟中心向外围逐渐减弱.位于莺歌海盆地斜坡近凹带,且紧邻乐东三大底辟的LD-B区块是油气富集的有利区域.



    • 图  1  莺歌海盆地构造纲要

      Fig.  1.  The stuctural map of Yinggehai Baisn

      图  2  莺歌海盆地地层综合柱状图

      Fig.  2.  The comprehensive strata log diagram of Yinggehai Baisn

      图  3  莺歌海盆地莺歌海组二段下部-黄流组一段上部泥岩盖层厚度分布

      Fig.  3.  The thickness contour map of Second Member of Yinggehai to First Member of Huangliu Formation caprocks, Yinggehai Basin

      图  4  莺歌海盆地泥岩排替压力与气柱高度关系

      Fig.  4.  Relationship between mudstone displacement pressure and gas column height in Yinggehai Basin

      图  5  莺歌海盆地泥岩排替压力预测

      a.盖层孔隙度与声波时差的关系; b.盖层排替压力与孔隙度的关系

      Fig.  5.  Prediction of displacement pressure in Yinggehai Baisn

      图  6  莺歌海盆地黄流组顶部盖层排替压力分布特征

      Fig.  6.  The displacement pressure in Huangliu Formation in Yinggehai Baisn

      图  7  不同地应力及力学性质条件下盖层的水力破裂能力

      A1C1, A2C2, A3C3分别为完整盖层在不同破裂类型下的水力破裂能力;B1C1, B2C2, B3C3分别为先存水力裂缝盖层在不同应力条件下水力破裂能力

      Fig.  7.  Hydraulic fracturing of caprock in different stress and mechanical properties

      图  8  莺歌海盆地地应力和流体压力分布

      Fig.  8.  The distribution of geostress and fluid pressure in Yinggehai Baisn

      图  9  莺歌海盆地黄流组一段盖层水力破裂压力系数

      Fig.  9.  The hydraulic fracturing pressure coefficient of Huangliu caprocks in Yinggehai Basin

      表  1  不同差应力条件下岩石的破裂方式及破裂准则

      Table  1.   The fracture mode and criterion of rocks in different differential stress

      破裂模式 破裂准则 差应力条件
      张性破裂 P=S3+T ΔS < 4T
      张性剪切破裂 P=Sn+(4T2-τ2)/4T 4T < ΔS < 6T
      剪切破裂 P=Sn+(C-τ)/μ ΔS > 6T
      注:P为破裂压力(MPa);ΔS为差应力(MPa);S3为最小主应力(MPa);T为岩石抗张强度(MPa);τ为剪应力(MPa);μ为摩擦系数;据Phillips et al.(1972)
      下载: 导出CSV

      表  2  莺歌海盆地盖层岩石力学参数分布范围

      Table  2.   Distribution range of mechanical parameters of caprocks in Yinggehai Basin

      井名 DF-B3 DF-A12
      地层 黄一段 黄一段 莺二段 莺二段
      岩性 泥质粉砂岩 泥岩 粉砂质泥岩 粉砂质泥岩
      内聚力(MPa) 21.30 16.93 14.74 17.00
      摩擦系数(μ) 0.437 0.480 0.590 0.610
      抗张强度(T)(MPa) 10.65 8.47 7.37 8.50
      范围(Tμ) 7.37 < T < 10.65 0.437 < μ < 0.610
      下载: 导出CSV
    • Berg, R. R., 1975. Capillary Pressures in Stratigraphic Traps. American Association of Petroleum Geologists Bulletin, 59(5):939-956.
      Duan, W., Chen, J. D., Luo, C. F., et al., 2013. Effects of Formation Overpressure on Diagensis in the Dongfang Block of Yinggehai Basin. Acta Petrolei Sinica, 34(6):1049-059(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syxb201306003
      Duan, W., Luo, C. F., Huang, X. S., et al., 2015. Effects of Formation Overpressure on Mudstone Diagenesis and Its Geological Significance in LD Block of Yinggehai Basin. Geological Science and Technology Information, 34(4):43-50(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzkjqb201504007
      Engelder, T., Lacazette, A., 1990. Natural Hydraulic Fracturing. Rock Joints, Rotterdam, AA Balkema, 35-44.
      Fan, C. W., 2018a. Tectonic Deformation Features and Petroleum Geological Significance in Yinggehai Large Strike-Slip Basin, South China Sea. Petroleum Exploration and Development, 45(2):190-198(in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/syktykf201802002
      Fan, C. W., 2018b. The Evolution, Characteristics and Identification of Transportation System Caused by High Pressure in Yinggehai and Qiongdongnan Basin. Oil & Gas Geology, 39(2):254-267(in Chinese with English abstract).
      Feng, C., Huang, Z. L., Tong, C. X., et al., 2011. Comprehensive Evaluation on the Sealing Ability of Mudstone Cap Rock in Member 2 of Yinggehai Formation of Yinggehai Basin. Journal of Earth Sciences and Environment, 33(4):373-377(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=xagcxyxb201104007
      Fu, G., Chen, Z. M., Lü, Y. F., et al., 1998. Comprehensive Evaluation on Sealing Ability of Mudstone Caprock. Experimental Petroleum Geology, 20(1):80-86(in Chinese with English abstract).
      Fu, G., Pang, X. Q., 1996. Method for Researching on Mud-Caprock Sealing Ability with the Use of Interval Transit Times. Oil Geophysical Prospecting, 31(4):521-529(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK199600509071
      Fu, G., Wang, Y. G., Su, Y. P., 2006. Evolution Law for Sealing of Overpressured Mudstone Caprock and Its Research Significance. Acta Mineralogica Sinica, 26(4):453-458(in Chinese with English abstract).
      Fu, X. F., Wu, T., Lv, Y. F., et al., 2018. Research Status and Development Trend of the Reservoir Caprock Sealing Properties. Oil & Gas Geology, 39(3):454-471(in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/syytrqdz201803004
      Hao, F., Liu, J. Z., Zou, H. Y., et al., 2015. Mechanisms of Natural Gas Accumulation and Leakage in the Overpresssured Sequences in the Yinggehai and Qiongdongnan Basins, Offshore South China Sea. Earth Science Frontiers, 22(1):169-180(in Chinese with English abstract).
      Huang, B. J., 2002. Genetic Types and Migration-Accumulation Dynamics of Natural Gases in the Ying-Qiong Basin, the South China Sea(Dissertation). State Key Laboratory of Organic Geochemistry, Guangzhou Institute of Geochemistry, Guangzhou(in Chinese with English abstract).
      Huang, Y. T., Yao, G. Q., Zhou, F. D., 2016. Provenance Analysis and Petroleum Geological Significance of Shallow-Marine Gravity Flow Sandstone for Huangliu Formation of Dongfang Area in Yinggehai Basin, the South China Sea. Earth Science, 41(9):1526-1542(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqkx201609008
      Hubbert, M. K., Rubey, W. W., 1959.Role of Fluid Pressures in Mechanics of Over Thrust Faulting. Geological Society of America Bulletin, 70(2):115-206. doi: 10.1130/0016-7606(1959)70[115:ROFPIM]2.0.CO;2
      Jia, R., 2018. The Integrity of Caprocks and Gas Accumulation in Yingqiong Basin(Dissertation). Northeast Petroleum University, Daqing(in Chinese with English abstract).
      Jiang, F. J., Pang, X. Q., OuYang, X., et al., 2012. The Main Progress and Problems of Shale Gas Study and the Potential Prediction of Shale Gas Exploration. Earth Science Frontiers, 19(2):198-211(in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/dxqy201202030
      Li, M. C., 2004. Oil and Gas Migration. Petroleum Industry Press, Beijing (in Chinese with English abstract).
      Liu, Z. J., Lu, Z. Q., Zhang, W., et al., 2015. Assessment of Accumulation Conditions for Medium-Deep Oil in Ledong Area of the Central Diaper Belt, Yinggehai Basin. Marine Geology & Quaternary Geology, 35(4):49-61(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hydzydsjdz201504007
      Lü, Y. F., Fu, G., Gao, D. L., et al., 1996. Research on Oil and Gas Reservoir Sealing. Petroleum Industry Press, Beijing (in Chinese with English abstract).
      Mallon, A. J., Swarbrick, R. E., 2008. Diagenetic Characteristics of Low Permeability, Non-Reservoir Chalks from the Central North Sea. Marine and Petroleum Geology, 25(10):1097-1108. https://doi.org/10.1016/j.marpetgeo.2007.12.001
      Mourgures, R., Gressier, J. B., Bodet, L., et al., 2011. "Basin Scale" Versus "Localized" Pore Pressure/Stress Coupling-Implications for Trap Integrity Evaluation. Marine and Petroleum Geology, 28(5):1111-1121. https://doi.org/10.1016/j.marpetgeo.2010.08.007
      Ozkaya, I., 1986. Analysis of Natural Hydraulic Fracturing of Shales during Sedimentation. SPE Production Engineering, 1(3):191-194. https://doi.org/10.2118/13343-pa
      Phillips, W. J., 1972. Hydraulic Fracturing and Mineralization. Journal of the Geological Society, 128(4):337-359. https://doi.org/10.1144/gsjgs.128.4.0337
      Ren, J. Y., Lei, C., 2011. Tectonic Stratigraphic Framework of Yinggehai-Qiongdongnan Basins and Its Implication for Tectonic Province Division in South China Sea. Chinese Journal of Geophysics, 52(12):3303-3314(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqwlxb201112028
      Tian, D. M., Jiang, T., Zhang, D. J., et al., 2017. Genesis Mechanism and Characteristics OD Submarine Channel:a Case Study of the First Member of Yinggehai Formation in Ledong Area of Yinggehai Basin. Earth Science, 42(1):130-139(in Chinese with English abstract).
      Wan, Z. F., Xia, B., Xu, L. F., et al., 2010. Study on the Dynamic Mechanism of Tectonic Evolution in Yinggehai Basin. Marine Science Bulletin, 29(6):654-657. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hytb201006010
      Wang, Y., Pei, J. X., Liu, Y., 2016. Caprock Sealing Mechanism of High-Temperature and Overpressure Gas Reservoirs in the Dongfang Block, Yinggehai Basin, South China. Geology and Mineral Resources of South China, 32(4):397-405(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hndzykc201604010
      Watts, N. L., 1987. Theoretical Aspects of Cap-Rock and Fault Seals for Single- and Two-Phase Hydrocarbon Columns. Marine and Petroleum Geology, 4(4):274-307. https://doi.org/10.1016/0264-8172(87)90008-0
      Xie, Y. H., Li, X. S., Tong, C. X., et al., 2015a. High Temperature and High Pressure Gas Enrichment Condition, Distribution Law and Accumulation Model in Central Diapir Zone of Yinggehai Basin. China Offshore Oil and Gas, 27(4):1-12(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zghsyq-gc201504001
      Xie, Y. H., Li, X.S., Tong, C. X., et al., 2015b. High Temperature and High Pressure Natural Gas Accumulation Theory and Exploration Practice in YingQiong Basin. Petroleum Industry Press, Beijing (in Chinese with English abstract).
      Xie, Y. H., Liu, P., Huang, Z. L., 2012. Geological Conditions and Pooling Process of High-Temperature and Overpressure Natural Gas Reservoirs in the Yinggehai Baisn. Natural Gas Industry, 32(4):19-23(in Chinese with English abstract).
      Zhao, B. F., Chen, H. H., Kong, L., et al., 2014. Vertical Migration System and Its Control on Natural Gas Accumulation in Yinggehai Basin. Earth Science, 39(9):1323-1332(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqkx201409008
      Zhou, X. Y., Wei, K. S., 2000. Sequence Stratigraphy and Source Reservoir Cap Rock Assemblage of QDN Basin. Oil & Gas Geology, 21(3):244-248(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syytrqdz200003012
      Zhou, Y., Jin, Z. J., Zhu, D.Y., et al., 2012. Current Status and Progress in Research of Hydrocarbon Cap Rocks. Experimental Petroleum Geology, 34(3):234-251(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=sysydz201203002
      段威, 陈金定, 罗程飞, 等, 2013.莺歌海盆地东方区块地层超压对成岩作用的影响.石油学报, 34(6):1049-1059. http://d.old.wanfangdata.com.cn/Periodical/syxb201306003
      段威, 罗程飞, 黄向胜, 等, 2015.莺歌海盆地LD区块地层超压对泥岩成岩作用的影响及其地质意义.地质科技情报, 34(4):43-50. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzkjqb201504007
      范彩伟, 2018a, 莺歌海大型走滑盆地构造变形特征及其地质意义.石油勘探与开发, 45(2):190-198. http://d.old.wanfangdata.com.cn/Periodical/syktykf201802002
      范彩伟, 2018b.莺-琼盆地高压成因输导体系特征、识别及其成藏过程.石油与天然气地质, 39(2):254-267. http://d.old.wanfangdata.com.cn/Periodical/syytrqdz201802005
      冯冲, 黄志龙, 童传新, 等, 2011.莺歌海盆地莺歌海组二段泥岩盖层封闭性综合评价.地球科学与环境学报, 33(4):373-377. doi: 10.3969/j.issn.1672-6561.2011.04.007
      付广, 陈章明, 吕延防, 等, 1998.泥质岩盖层封盖性能综合评价方法探讨.石油实验地质, 20(1):80-86.
      付广, 庞雄奇, 1996.利用声波时差资料研究泥岩盖层封闭能力的方法.石油地球物理勘探, 31(4):521-529. doi: 10.3321/j.issn:1000-7210.1996.04.008
      付广, 王有功, 苏玉平, 2006.超压泥岩盖层封闭性演化规律及其研究意义.矿物学报, 26(4):453-458. doi: 10.3321/j.issn:1000-4734.2006.04.015
      付晓飞, 吴桐, 吕延防, 等, 2018.油气藏盖层封闭性研究现状及未来发展趋势.石油与天然气地质, 39(3):454-471. http://d.old.wanfangdata.com.cn/Periodical/syytrqdz201803004
      郝芳, 刘建章, 邹华耀, 等, 2015.莺歌海-琼东南盆地超压层系油气聚散机理浅析.地学前缘, 22(1):169-180.
      黄保家, 2002.莺琼盆地天然气成因类型及成藏动力学研究(博士学位论文).广州: 中国科学院广州地球化学研究所. http://cdmd.cnki.com.cn/Article/CDMD-80165-2003041927.htm
      黄银涛, 姚光庆, 周锋德, 2016.莺歌海盆地黄流组浅海重力流砂体物源分析及油气地质意义.地球科学, 41(9):1526-1542. http://earth-science.net/WebPage/Article.aspx?id=3358
      贾茹, 2018.莺琼盆地盖层完整性及与天然气成藏(硕士学位论文).大庆: 东北石油大学.
      姜福杰, 庞雄奇, 欧阳学, 等, 2012.世界页岩气研究概况及中国页岩气资源潜力分析.地学前缘, 19(2):198-211. http://d.old.wanfangdata.com.cn/Periodical/dxqy201202030
      李明诚, 2004.石油与天然气运移.北京:石油工业出版社.
      刘志杰, 卢振权, 张伟, 等, 2015.莺歌海盆地中央泥底辟带东方区域乐东区中深层成藏地质条件.海洋地质与第四纪地质, 35(4):49-61.
      吕延防, 付广, 高大岭, 等, 1996.油气藏封盖研究.北京:石油工业出版社.
      任建业, 雷超, 2011.莺歌海-琼东南盆地构造-地层格架及南海动力变形分区.地球物理学报, 52(12):3303-3314. doi: 10.3969/j.issn.0001-5733.2011.12.028
      田冬梅, 姜涛, 张道军, 等, 2017.海底水道特征及其成因机制:以莺歌海盆地乐东区莺歌海组一段为例.地球科学, 42(1):130-139. http://earth-science.net/WebPage/Article.aspx?id=3420
      万志峰, 夏斌, 徐力峰, 等, 2010.莺歌海盆地构造演化动力学机制探讨.海洋通报, 29(6):654-657. doi: 10.3969/j.issn.1001-6392.2010.06.010
      汪洋, 裴健翔, 刘亿, 2016.莺歌海盆地东方区高温超压气藏盖层封盖机制.华南地质与矿产, 32(4):397-405. doi: 10.3969/j.issn.1007-3701.2016.04.010
      谢玉洪, 李绪深, 童传新, 等, 2015a.莺歌海盆地中央底辟带高温高压天然气富集条件、分布规律和成藏模式.中国海上油气, 27(4):1-12. http://d.old.wanfangdata.com.cn/Periodical/zghsyq-gc201504001
      谢玉洪, 李绪深, 童传新, 等, 2015b.莺琼盆地高温超压天然气成藏理论与勘探实践.北京:石油工业出版社.
      谢玉洪, 刘平, 黄志龙, 2012.莺歌海盆地高温超压天然气成藏地质条件及成藏过程.天然气工业, 32(4):19-23. doi: 10.3787/j.issn.1000-0976.2012.04.005
      赵宝峰, 陈红汉, 孔令涛, 等, 2014.莺歌海盆地流体垂向输到体系及其对天然气成藏的控制作用.地球科学, 39(9):1323-1332. http://earth-science.net/WebPage/Article.aspx?id=2943
      周小鹰, 魏魁生, 2000. QDN盆地层序地层及生储盖组合分析.石油与天然气地质, 21(3):244-248. doi: 10.3321/j.issn:0253-9985.2000.03.012
      周雁, 金之钧, 朱东亚, 等, 2012.油气盖层研究现状与认识进展.石油实验地质, 34(3):234-251. doi: 10.3969/j.issn.1001-6112.2012.03.002
