The Source and Natural Gas Lateral Migration Accumulation Model of Y8-1 Gas Bearing Structure, East Deep Water in the Qiongdongnan Basin
-
摘要: 综合钻井天然气地球化学、地震资料，分析了琼东南盆地深水东区Y8-1构造天然气成因、来源及侧向运聚模式.天然气轻烃C6、C7组成分析表明，Y8-1构造天然气既有别于松东凹陷北坡的油型气，也不同于深水L17-2气田的煤型气.根据天然气乙烷、丙烷碳同位素特征，判断Y8-1构造天然气具有煤型气和油型气混合成因特征.选择盆地东部典型煤型气、油型气作为端元，计算得到Y8-1构造天然气中煤型气占53.3%、油型气占46.7%，分别来源于松南-宝岛凹陷下渐新统崖城组陆源海相烃源岩、始新统湖相烃源岩，两套烃源岩均具备生成成熟-高成熟天然气的地质条件.松南-宝岛凹陷中烃源岩生成的天然气沿断裂、构造脊、砂岩层侧向长距离运移，在Y8-1崖城组、花岗岩基岩圈闭中聚集成藏.Abstract: Based on the geochemical analyses of natural gases and seismic exploration data,the genesis,sources and lateral migration accumulation of Y8-1 bearing structure were comprehensively analyzed in the East deep water of the Qiongdong Basin. The analyses of C6,C7 light hydrocarbons show that the natural gas of the Y8-1 bearing structure is different from oil-type gas in the northern slope of Songdong sag,and coal-type gas of L17-2 gas field in the deepwater as well. According to the ethane and the propane carbon isotope,the natural gas in the Y8-1 bearing structurehas the mixing characteristics of coal-type gas and oil-type gas. The typical coal-type gas and the oil-type gas in the east Qiongdongnan Basin are selected to be end elements,the natural gas ethane carbon isotope of the Y8-1 bearing structure is calculated as coal-type gas for 53.3% and oil-type gas for 46.7% in the natural gas. The Y8-1 mixing source gas derived from the terrestrial marine source rock of Lower Oligocene Yacheng formation and Eocene lacustrine source rock in Songnan-Baodao sag respectively,and both sets of source rocks have geological conditions for the formation of mature-high mature natural gas. The natural gas generated from the source rocks in the Songnan,Baodao sags migrates along the tectonic ridges,faults,and sandstone carriers for a long distance,thenaccumulatedin the Yacheng formation and granite basement traps in the Songnan low-uplift,East deep water of the Qiongdong Basin.
-
Key words:
- genesis of the natural gas /
- light hydrocarbon /
- carbon /
- mixing source gas /
- east deep water /
- Qiongdongnan Basin
-
图 2 琼东南盆地及邻区天然气乙烷碳同位素（δ13C2）和丙烷碳同位素（δ13C3）相互关系
Fig. 2. Correlation between ethane carbon isotope(δ13C2) and propane carbon isotope(δ13C3)of the varied natural gases in the Qiongdongnan Basin and adjacent basins
图 3 琼东南盆地天然气轻烃石蜡指数-庚烷值关系
Fig. 3. Relationship between paraffin index and heptane value of natural gas light hydrocarbon in Qiongdongnan Basin
图 4 松南-宝岛凹陷-Y8-1典型剖面5.5 Ma以来构造发育史
Fig. 4. Structural development history since the typical 5.5 Ma of Songnan-Baodao sag across Y8-1
图 5 （a）过Y8-1含气构造地震剖面；（b）Y8-1天然气侧向运聚模式
Fig. 5. (a)The seismic section crossing Y8-1;(b)Lateral migration-accumulation mode of Y8-1
表 1 琼东南盆地东部天然气组分、干燥系数与碳同位素特征
Table 1. Natural gas composition, dry coefficient and carbon isotope characteristics, East Qiongdongnan basin
区带 井号 井段（m） 测试层号 天然气组分(%) 干燥系数 碳同位素δ13C(‰) C1 C2~5 N2 CO2 C1/C1~5 C1 C2 C3 C4 CO2 松东凹陷北坡带 SF24-1-1 2 122.5 MDT 74.30 9.80 6.77 7.81 0.88 -47.06 -30.92 -29.96 -28.64 -7.61 宝岛凹陷北坡带 BF13-1-1 1 573.0 ~1 580.0 DST 86.14 10.24 2.46 0.72 0.89 -48.65 -30.53 -31.15 -27.82 -25.54 BF13-3-1 1 740.0 MDT 84.70 11.40 2.80 0.61 0.88 -48.91 -27.45 -27.93 -27.84 BF13-3S-1 1 967.5 MDT 82.48 8.09 6.67 1.18 0.91 -45.53 -30.39 -29.84 -28.09 -29.33 BF19-2-3 3 911.0 MDT 79.70 8.29 6.28 1.19 0.91 -35.98 -30.39 -28.57 -27.41 -6.23 3 934.5 MDT 72.93 3.73 3.84 18.72 0.95 -35.17 -30.67 -28.60 -27.30 -4.26 松南低凸起 Y8-1-1 2 880.5 MDT 89.90 2.97 6.11 0.59 0.97 -45.44 -27.64 -27.80 -7.82 2 895.6 MDT 89.77 2.99 6.13 0.69 0.97 -45.59 -27.83 -27.88 -8.03 松涛凸起 SF34-3-1 2 301.8 MDT 93.92 4.50 0.43 0.65 0.95 -46.55 -27.57 -27.50 -16.70 2 311.6 MDT 92.70 5.42 0.39 0.72 0.94 -46.54 -25.59 -26.22 -16.22 注：SF24-1-1:下中新统三亚组; BF13-1-1:中中新统梅山组; BF13-3-1:中中新统梅山组; BF13-3S-1:中中新统梅山组; BF19-2-3:上渐新统陵水组Ⅰ气组和上渐新统陵水组Ⅱ气组; Y8-1-1:下渐新统崖城组; SF34-3-1:下中新统三亚组
下载: 导出CSV
表 2 琼东南盆地东区、北部湾盆地天然气轻烃C6和C7系列分析数据表
Table 2. The C6 and C7 light hydrocarbon series of the east Qiongdongnan Basin and the Beibu Gulf Basin
井名 井深(m) 采样方式 C6系列(%) C7系列(%) 正构烷烃 异构烷烃 环烷烃 芳香烃 正构烷烃 异构烷烃 环烷烃 芳香烃 SF24-1-1 2 122.5 FMT 21.72 41.95 34.08 2.25 15.52 31.90 49.14 3.45 BF13-1-1 1 573.0~1 580.0 DST 23.08 47.12 29.81 0 13.64 31.82 54.55 0 1 577.3 MDT 20.75 48.11 31.13 0 12.00 30.00 58.00 0 BF13-3-1 1 740.0 MDT 25.00 56.43 18.57 0 14.63 43.90 41.46 0 BF13-3S-1 1 967.5 MDT 21.19 41.53 36.44 0.85 13.21 26.42 58.49 1.89 BF19-2-3 3 911.0 MDT 15.15 36.36 39.39 9.09 16.67 33.33 33.33 16.67 3 934.5 MDT 9.09 18.18 27.27 45.45 6.25 6.25 31.25 56.25 Y8-1-1 2 880.5 MDT 12.82 46.15 30.77 10.26 11.43 31.43 48.57 8.57 2 895.6 MDT 13.33 44.44 28.89 13.33 12.50 32.50 45.00 10.00 L17-2-1 3 306.0 MDT 13.98 34.41 25.81 25.81 13.73 21.57 43.14 21.57 L18-1-1 2 819.9~2 846.7 DST 13.11 40.98 22.95 22.95 11.11 27.78 44.44 16.67 SF34-3-1 2 301.8 MDT 20.11 42.93 35.87 1.09 17.30 23.24 58.38 1.08 2 311.6 MDT 20.00 42.95 36.07 0.98 16.08 24.71 57.65 1.57 WZ1 2 137.5~2 265.8 DST3 29.53 42.13 27.95 0.39 19.63 23.36 56.07 0.93 WZ2 2 351.0~2 357.0 DST2 28.89 53.33 17.04 0.74 20.00 34.29 45.71 0 WZ3 2 459.0~2 473.5 DST2 28.85 48.72 18.59 3.85 20.45 31.82 43.18 4.55
下载: 导出CSV
表 3 琼东南盆地主要含气构造天然气C7轻烃组成
Table 3. The Composition of C7 light hydrocarbon series of natural gas in Qiongdongnan basin
井名 深度(m) 地层 天然气C7轻烃组成 甲基环己烷指数(%) 成因类型 甲基环己烷(MCH)(%) 正庚烷（nC7）(%) 二甲基环戊烷(ΣDMCP)(%) SF24-1-1 2 122.5 下中新统三亚组 42.60 24.00 33.30 42.60 油型气 BF13-1-1 1 573.0~1 580.0 中中新统梅山组 40.00 20.00 40.00 40.00 油型气 1 577.3 40.00 17.10 42.90 40.00 油型气 BF13-3-1 1 740.0 中中新统梅山组 30.40 26.00 43.60 30.40 油型气 BF13-3S-1 1 967.5 下中新统三亚组 42.10 18.40 39.50 42.10 油型气 45.80 18.80 35.40 45.80 油型气 BF19-2-3 3 911.0 上渐新统陵水组二段Ⅰ气组 50.00 10.00 40.00 50.00 煤型气 3 934.5 上渐新统陵水组二段Ⅱ气组 50.00 16.70 33.30 50.00 煤型气 57.10 14.30 28.60 57.10 煤型气 60.00 20.00 20.00 60.00 煤型气 L17-2-1 3 306.0 上中新统黄流组 48.30 24.10 27.60 48.30 煤型气 L17-2-2 3 331.3 50.00 21.40 28.60 50.00 煤型气 L18-1-1 2 819.9~2 846.7 莺二段T29A气组 40.00 20.00 40.00 40.00 油型气 Y8-1-1 2 880.5 下渐新统崖城组 47.60 19.10 33.30 47.60 油型气 2 895.6 43.50 21.70 34.80 43.50 油型气 WZ1 2 137.5~2 265.8 流-段 33.30 25.90 40.70 33.30 油型气 WZ2 2 351.0~2 357.0 涠三段 34.80 30.40 34.80 34.80 油型气 WZ3 2 459.0~2 473.5 涠三段 35.71 32.14 32.14 35.71 油型气 注：甲基环己烷指数=MCH/(MCH+nC7+ΣDMCP)×100%
下载: 导出CSV
表 4 Y8-1含气构造天然气混源比例计算表
Table 4. The calculation table of mixed source ratios of the natural gas in Y8-1 gas bearing structure
天然气组分 Y8-1气藏天然气碳同位素(‰) 湖相气端元：S24气藏 陆源浅海相气端元：L17气田 混源气藏天然气碳同位素(‰) 天然气组分含量m（%） 天然气碳同位素n (‰) 混合比例fh（%） 天然气组分含量x（%） 天然气碳同位素y (‰) 混合比例fq（%） 计算考虑天然气组分A 计算未考虑天然气组分B 乙烷 -27.74 4.45 -30.92 46.7 4.4 -24.93 53.3 -27.74 -27.73 丙烷 -28.84 3.36 -29.96 40.8 1.1 -23.38 59.2 -27.84 -26.06 注：丙烷同位素倒转偏轻，计算结果仅供参考，A=(m×n×fh+x×y×fq)/(m×fh+x×fq), B=n×fh+y×fq
下载: 导出CSV
-
Dai, J. X., 1992. Identification and Distinction of Various Alkane Gases. Science in China Series B, 35(10):1246-1257 (in Chinese with English abstract). Dai, J. X., 1993a. Discriminate of Kinds of Alkane Gas. Petroleum Exploration and Development, 20(5):26-32 (in Chinese with English abstract). Dai, J. X., 1993b. Carbon/Hydrogen Isotope Characteristic and Identification of Various Natural Gases. Natural Gas Geoscience, 4(2, 3):1-40 (in Chinese with English abstract). Dai, J. X., 1995.A Biogenic Gas in Oil-Gas Bearing Basins in China and Its Reservoirs. Natural Gas Industry, 15(3):22-27 (in Chinese with English abstract). Dai, J. X., Qi, H. F., Song, Y., 1985. On the Indicators for Identifying Gas from Oil and Gas from Coal Measure. Acta Petroleum Sinica, 6(2):31-38 (in Chinese with English abstract). Dai, J. X., Shi, X., Wei, Y, Z., 2001. Summary of the Abiogenic Origin Theory and the Abiogenic Gas Pools(Fields). Acta Petroleum Sinica, 22(6):5-10 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syxb200106002 Dai, J.X., Xia, X.Y., Qin, S.F., et al., 2003.Causation of Partly Reversed Orders of Carbon Isotopes in Biogenic Alkane in China.Oil & Gas Geology, 24(1):1-6(in Chinese with English abstract). Hu, T.L., Ge, B. X., Zhang, Y. G., et al., 1990. The Development and Application of Fingerprint Parameters for Hydrocarbons Absorbed by Source Rocks and Light Hydrocarbons in Natural Gas. Experimental Petroleum Geology, 12(4):375-393 (in Chinese with English abstract). Huang, B. J., Huang, H. T., Li, L., et al., 2010. Characteristics of Marine Source Rocks and Effect of High Temperature and Overpressure to Organic Matter Maturation in Yinggehai-Qiongdongnan Basins. Marine Origin Petroleum Geology, 15(3):11-18(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hxyqdz201003002 Liu, W. H., Xu, Y. C., 1996. Genetic Indicators of Natural Gas. Acta Sedimentologica Sinica, 14(1):110-116 (in Chinese with English abstract). http://d.old.wanfangdata.com.cn/OAPaper/oai_doaj-articles_9a1dd89486801d4aba68065885d6b611 Pei, L.X., Gang, W.Z, Zhu C.Z., 2018. Carbon Isotopic Composition and Source of Hydrocarbon Gases in the Junggar Basin. Natural Gas Geoscience, 29(7):1020-1030(in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/trqdqkx201807011 Schoell, M., 1983.Genetic Characterization of Natural Gases.AAPG Bulletin, 67(12):2225-2238. Song, Y., Xu, Y. C., 2005. Origin and Identification of Natural Gas.Petroleum Exploration and Development, 32 (4):24-29(in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/sysydz201802009 Sun, J. L., 1994.Characteristics of the Ya13-1 Gas Field in South China Sea and Its Integrated Reservoir Conditions. Natural Gas Industry, 14(2):1-7(in Chinese with English abstract). Wang, S.Y., Dai, H.M., Wang, H.Q., 2003.Method of Quantity Calculation of Mixed-Source Natural Gas Study of Baimamiao Gas Field of West in Sichuan Basin. Natural Gas Geoscience, 14(5):351-353(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=trqdqkx200305004 Xu, X.D., Zhang, Y.Z., Liang, G., et al., 2016.Hydrocarbon Source Condition and Accumulation Mechanism of Natural Gas in Deepwater area of Qiongdongnan Basin, Northern South China Sea. Natural Gas Geoscience, 27(11):1985-1992(in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/trqdqkx201611005 Xu, Y. C., 1996. The Mantle Noble Gas of Natural Gases.Earth Science Frontiers, 3(3):63-71(in Chinese with English abstract). http://d.old.wanfangdata.com.cn/OAPaper/oai_doaj-articles_eb09fa1316d6f64f0524f3046fcfd3ea Zhang, H. X., Ni, S., Wang, L., et al., 2014. Mixing Source Ratio of Nature Gas in South Branch of Dinan Salient, Zhunggar Basin. Fault-Block Oil and Gas Field, 21(2):176-180(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dkyqt201402009 Zhang, S. C., Zhu, G. Y., Chen, J. P., et al., 2007.A Discussion on Gas Sources of the Feixianguan Formation H2S Rich Giant Gas Fields in the North Eastern Sichuan Basin.Chinese Science Bulletin, 52 (Supp.Ⅰ):86-94(in Chinese with English abstract). Zhang, Y. Z., Chen, Z. H., Li, X.S., et al., 2011.Favorable Coastal Gas Reservoir Forming Conditions and Exploration Direction in Qiongdongan Basin of South China Sea.Journal of Oil and Gas Technology, 33(1):21-30(in Chinese with English abstract). Zhang, Y. Z., Fan, C.W., Xu, X.D., et al., 2015.Genesis and Sources of Natural Gas in Eastern Qiongdongnan Basin, South China Sea. Petroleum Geology & Experiment, 37(4):466-472, 478 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=sysydz201504009 Zhang, Y. Z., Xu, X. D., Gan, J., et al., 2017.Study on the Geological Characteristics, Accumulation Model and Exploration Direction of the Giant Deepwater Gas Field in the Qiongdongnan Basin. Acta Geologica Sinica, 91(7):1620-1633(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dizhixb201707013 Zhang, Y. Z., Gan, J., Yang, X.B., et al., 2017. Tectonic Evolution and Constraints on the Formation of Deepwater Giant Gas Field in Lingshui Sag, Qiongdongnan Basin. Marine Geology, 33(10):22-31(in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/hydzdt201710003 Zhu, G. Y., Zhang, S. C., Li, J., et al., 2004.Formation and Distribution of Hydrogen Sulfide Bearing Gas in China. Petroleum Exploration and Development, 31(3):18-21(in Chinese with English abstract). doi: 10.1016-j.thromres.2010.03.016/ 戴金星, 1992.各类烷烃气的鉴别.中国科学(B辑), 22(2):185-193. 戴金星, 1993a.利用轻烃鉴别煤成气和油型气.石油勘探与开发, 20(5):26-32. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK000004619882 戴金星, 1993b.天然气碳氢同位素特征和各类天然气鉴别.天然气地球科学, 4(2, 3):1-40. 戴金星, 1995.中国含油气盆地的无机成因气及其含气构造.天然气工业, 15(3):22-27. 戴金星, 戚厚发, 宋岩, 1985.鉴别煤成气和油型气若干指标的初步探讨.石油学报, 6(2):31-38. 戴金星, 石昕, 卫延召, 2001.无机成因油气论和无机成因的气田(藏)概略.石油学报, 22(6):5-10. doi: 10.3321/j.issn:0253-2697.2001.06.002 戴金星, 夏新宇, 秦胜飞, 等, 2003.中国有机烷烃气碳同位素系列倒转的成因.石油与天然气地质, 24(1):1-6. doi: 10.3321/j.issn:0253-9985.2003.01.001 胡惕麟, 戈葆雄, 张义纲, 等, 1990.源岩吸附烃和天然气轻烃指纹参数的开发和应用.石油实验地质, 12(4):375-393. doi: 10.1097-MOH.0b013e32832ea2f2/ 黄保家, 黄合庭, 李里, 等, 2010.莺-琼盆地海相烃源岩特征及高温高压环境有机质热演化.海相油气地质, 15(3):11-18. doi: 10.3969/j.issn.1672-9854.2010.03.002 刘文汇, 徐永昌, 1996.天然气成因类型及判识标志.沉积学报, 14(1):110-116. 裴立新, 刚文哲, 朱传真, 等, 2018.准噶尔盆地烷烃气碳同位素组成及来源.天然气地球科学, 29(7):1020-1030. http://d.old.wanfangdata.com.cn/Periodical/trqdqkx201807011 宋岩, 徐永昌, 2005.天然气成因类型及其鉴别.石油勘探与开发, 32(4):24-29. doi: 10.3321/j.issn:1000-0747.2005.04.004 王顺玉, 戴鸿鸣, 王海清, 2003.混源天然气定量计算方法-以川西地区白马庙气田为例.天然气地球科学, 14(5):351-353. doi: 10.3969/j.issn.1672-1926.2003.05.004 徐新德, 张迎朝, 梁刚, 等, 2016.南海北部琼东南盆地深水区烃源条件及天然气成藏机制.天然气地球科学, 27(11):1985-1992. doi: 10.11764/j.issn.1672-1926.2016.11.1985 徐永昌, 1996.天然气中的幔源稀有气体.地学前缘, 3(3):63-71. doi: 10.3321/j.issn:1005-2321.1996.03.006 张焕旭, 倪帅, 王力, 等, 2014.准噶尔盆地滴南凸起中段南支天然气混源比例研究.断块油气田, 21(2):176-180. http://d.old.wanfangdata.com.cn/Periodical/dkyqt201402009 张水昌, 朱光有, 陈建平, 等, 2007.四川盆地川东北部飞仙关组高含硫化氢大型气田群气源探讨.科学通报, 52(增刊Ⅰ):86-94. 张迎朝, 陈志宏, 李绪深, 等, 2011.琼东南盆地滨岸天然气成藏有利条件及勘探方向.石油天然气学报, 33(1):21-30. doi: 10.3969/j.issn.1000-9752.2011.01.005 张迎朝, 范彩伟, 徐新德, 等, 2015.南海琼东南盆地东区天然气成因类型与烃源探讨.石油实验地质, 37(4):466-472, 478. http://d.old.wanfangdata.com.cn/Periodical/sysydz201504009 张迎朝, 甘军, 杨希冰, 等, 2017a.琼东南盆地陵水凹陷构造演化及其对深水大气田形成的控制作用.海洋地质前沿, 33(10):22-31. http://d.old.wanfangdata.com.cn/Periodical/hydzdt201710003 张迎朝, 徐新德, 甘军, 等, 2017b.琼东南盆地深水大气田地质特征、成藏模式及勘探方向研究.地质学报, 91(7):1620-1633. http://d.old.wanfangdata.com.cn/Periodical/dizhixb201707013 朱光有, 张水昌, 李剑, 等, 2004.中国高含硫化氢天然气的形成及其分布.石油勘探与开发, 31(3):18-21. doi: 10.3321/j.issn:1000-0747.2004.03.005 -
