Meso-Cenozoic Asthenosphere Upwelling of Eastern China and Its Impacts on Structure-Magma-Mineralization Concentration Region
-
摘要: 以深部地球物理资料为基础, 结合大地构造环境、岩浆岩同位素示踪及矿产资源分布规律, 加以综合分析.通过热力学计算可知, 中国东部近2亿年来的上地幔岩石圈/软流圈构造可以存留至今, 且能区分出中、新生代.软流圈上涌与矿集区：（1）中生代金属矿：（a）克拉通区, 软流圈沿柱身上涌, 其柱头上方形成幔壳混熔花岗质岩及相应Au、Cu、Mo、Pb-Zn等矿集区, 并于柱身与岩石圈块体陡接触带, 形成中基性杂岩及相应富Fe矿集区; （b）褶皱带区, 在软流圈上涌柱上方形成近幔源型花岗质岩, 相应为Cu、Au、Pb-Zn、Mo、Ag矿集区; （c）南岭带, 软流圈层在适当深度、热量充足、较大范围内"平卧", 因热传导而致使地壳内物质部分重熔, 形成壳源型花岗质岩及相应的W、Sn、稀有元素矿集区; （2）新生代油气田：（a）与太平洋板块俯冲有关的软流圈上涌, 其上方出露玄武岩, 形成较大型油田; （b）与裂陷盆地有关的软流圈上涌, 其上方形成大型油田, 也有中小型油田.软流圈上涌与大地构造：中生代J-K时期, 通过构造力特征等的综合分析, 阐明燕山运动的根源及其影响; 新生代侧重剖析大陆裂谷相关特征.总之, 软流圈上涌是岩石圈减薄, 以及中、新生代构造-岩浆-矿集区形成的根源.Abstract: Based on the deep geophysical data, a comprehensive study is carried out by analyzing the tectonic environment, magma isotopic tracing and laws of distribution of mineral resources. The thermodynamic calculation indicates that the structure of the upper mantle lithosphere and asthenosphere of the eastern China which is near 200 Ma can be kept to now, and the time of Mesozoic and Cenozoic can be recognized. Results show the following asthenosphere upwelling and mineralization concentration regions. (1) Mesozoic metal deposit:(a) Craton area, asthenosphere upwelled along the plume body, above the plume head, there formed intermingling granitic rock of crust and mantle melts and corresponding Au, Cu, Mo, Pb-Zn etc mineralization concentrated region. And in the steep contact belt of the plume body and lithosphere body, there formed mediate-basic complex and corresponding Fe mineralization concentrated region. (b) Fold belt area, above the asthenosphere upwelling plume, there formed near mantle-source granitic rocks, and corresponding Cu, Au, Pb-Zn, Mo, Ag mineralization concentrated region. (c) Nanling belt, asthenosphere was "recumbent" at suitable depth, with adequate heat and to a great extent, for heat conduction, the interior of crust remelted partially, and the crust-source granitic rocks, corresponding W, Sn and rare elements mineralization concentrated regions were formed. (2) Cenozoic oil and gas field:(a) Asthenosphere upwelling related with the Pacific subduction, above them, there outcropped basalt, and formed large-scale oil field. (b) Asthenosphere upwelling related with the rift basin, above them, there formed large-scale oil fields, also medium- and small-scale oil fields. Asthenosphere upwelling and tectonic:at J-K of Mesozoic, through comprehensive analysis of tectonic force etc, the origin and influence of Yanshan movement are presented. For Cenozoic, the characters related with continental rift should be analyzed essentially. In conclusion, asthenosphere upwelling is the origin of lithosphere thinning and formation of Meso-Cenozoic structure-magma-mineralization concentration region.
-
图 2 中国东部(大陆)岩石圈/软流圈构造图
据邢集善等(2009)修编
Fig. 2. Structure of lithosphere/asthenosphere of eastern China (mainland)
图 3 华北地震层折成象115°E南北向剖面
据邢作云等(2006a, 2006b)修编
Fig. 3. Seismic tomographic image along 115°E S-N section of North China
图 4 华南地震层析成像HW9东西向剖面
据邢集善等(2009)修编
Fig. 4. Seismic tomographic image along HW9 E-W section of South China
图 5 华南地震层析成像HW5东西向剖面
据邢集善等(2009)修编
Fig. 5. Seismic tomographic image along HW5 E-W section of South China
图 6 华北地震层析成像沿38.7°N东西向剖面
据邢作云等(2006a, 2000b)修编
Fig. 6. Seismic tomographic image along 38.7°N E-W section of North China
图 7 东北地区东乌旗-大兴安岭(南)-丹东大地电磁测深剖面
据国家地震局(1992)修编
Fig. 7. Magnetotelluric sounding profile of Dongwuqi-Daxing'anling (south)-Dandong in Northeast China
-
Changchun University of Geology, 1998.Manzhouli-Suifenhe Geoscience Transects of China.Geological Publishing House, Bejing (in Chinese). Chen, Y.C., 1999.The Prospective Evaluation of Mineral Resources in the Main Metallogenic Regions in China.Geological Publishing House, Beijing (in Chinese). China Seismological Bureau, 1992.Explanation of GGT from Dongwuzhumuqinqi of Inner Mongolia to Donggou of Liaoning Province.Seismological Press, Beijing (in Chinese). Deng, J.F., Mo, X.X., Zhao, H.L., et al., 1999.The Yanshanian Lithosphere-Asthenosphere Catastrophe and Metallogenic Environment in East China.Mineral Deposits, 18(4):309-315 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=kcdz199904003 Deng, J.F., Su, S.G., Zhao, H.L., et al., 2003.Deep Processes of Mesozoic Yanshanian Lithosphere Thinning in North China.Earth Science Frontiers, 10(3):41-50 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dxqy200303003 Deng, J.F., Teng, J.W., Peng, C., et al., 2008.Features and Deep Geology of Geophysical Field and Mineralization in China.Geological Publishing House, Beijing (in Chinese). He, L.J., Hu, S.B., Wang, J.Y., 2001.Heat Lithosphere Structural Characteristics of Eastern China Continent.Progress in Natural Science, 11(9):966-969 (in Chinese). Hong, D.W., Wang, T., Tong, Y., et al., 2003.Mesozoic Granitoids from North China Block and Qinling-Dabie-Sulu Orogenic Belt and Their Deep Dynamic Process.Earth Science Frontiers, 10(3):231-256 (in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/dxqy200303022 Hua, R.M., Chen, P.R., Zhang, W.L., et al., 2005.Three Major Metallogenic Events in Mesozoic in South China.Mineral Deposits, 24(2):99-107 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=kcdz200502002 Huang, J., Zhao, D., 2006.High-Resolution Mantle Tomography of China and Surrounding Regions.Journal of Geophysical Research (Solid Earth), 111(B9):396. https://doi.org/10.1029/2005JB004066 Lehedev, S., Nolet, G., 2003.Upper Mantle beneath Southeast Asia from S Velocity Tomography.Journal of Geophysical Research (Solid Earth), 108(B1):165. https://doi.org/10.1029/2000JB000073 Li, C., Robert, V.H., Nafl, T.M., 2006.Constraining P-Wave Velocity Variations in the Upper Mantle beneath Southeast Asia.Phys.Earth Planet.Inter., 154:180-195. doi: 10.1016/j.pepi.2005.09.008 Li, C., Wang, L.S., Shi, Y.S., 1996.Deep Thermal State and Lithospheric Thickness in the Lower Yangtze Area.Journal of Nanjing University (Natural Sciences), 32(3):494-499 (in Chinese with English abstract). Li, T.D., 2006.Lithospheric Tectonic Units of China.Geology in China, 33(4):700-710 (in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/dqwlxb201801013 Liu, F.T., Qu, K.X., Wu, H., et al., 1986.ST Image of North China.Acta Geoscientica Sinica, 29(5):442-449 (in Chinese with English abstract). Liu, G.D., 1985.Cenozoic Rift System of North China Plain and the Deep Internal Processes.In: Research on Crustal Movement (1).Seismological Press, Beijing, 17-25 (in Chinese with English abstract). Liu, H.F., Liang, H.S., Li, X.Q., et al., 2000.The Coupling Mechanisms of Mesozoic-Cenozoic Rift Basins and Extensional Mountain System in Eastern China.Earth Science Frontiers, 7(4):477-486 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dxqy200004015 Liu, J.H., Liu, F.T., Wu, H., et al., 1989.Three Dimensional Velocity Images of the Crust and Upper Mantle beneath North-South Zone in China.Acta Geoscientica Sinica, 32(2):143-152 (in Chinese with English abstract). Liu, J.H., Liu, F.T., Yan, X.W., et al., 2004.A Study of Lg Coda Attenuation beneath North China:Seismic Imaging Lg Coda Q.Chinese Journal Geophysics, 47(5):822-832 (in Chinese with English abstract). Liu, J.H., Wu, H., Liu, F.T., 1996.Features of 3-D Velocity Distribution and Lithosphere Structure in South China and Its Contiguous Sea Area.Acta Geoscientica Sinica, 39(4):483-492 (in Chinese with English abstract). Lu, F.X., Zheng, J.P., Hou, Q.Y., et al., 2006.Zones of Crust-Mantle and Lithosphere-Asthenosphere Interaction in Eastern China:Characteristics and Timing of Transformation.Geology in China, 33(4):773-781 (in Chinese with English abstract). Ma, X.Y., 1987.The Lithosphere Geodynamics Compendium in China.Geological Publishing House, Beijing (in Chinese). Mao, J.W., Xie, G.Q., Li, X.F., et al., 2004.Mesozoic Large Scale Mineralization and Multiple Lithospheric Extension in South China.Earth Science Frontiers, 11(1):45-55 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dxqy200401003 Mao, J.W., Xie, G.Q., Zhang, Z.H., et al., 2005.Mesozoic Large-Scale Metallogenic Pulses in North China and Corresponding Geodynamic Settings.Acta Petrologica Sinica, 21(1):169-188 (in Chinese with English abstract). Pei, R.F., Zhai, Y.S., Zhang, B.R., et al., 1999.Deep-Seated Tectonism and Mineralization.Geological Publishing House, Beijing (in Chinese). Ren, J.S., 2000.The Tectonic Map of China and Neighbour Area.Geological Publishing House, Beijing (in Chinese). Shao, J.A., Liu, F.T., Chen, H., et al., 2001.Relationship between Mesozoic Magmatism and Subduction in Da Hinggan-Yanshan Area.Acta Geologica Sinica, 75(1):56-63 (in Chinese with English abstract). Wang, D.Z., Shen, W.Z., 2003.Genesis of Granitoids and Crustal Evolution in Southeast China.Earth Science Frontiers, 10(3):209-220 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dxqy200303020 Wang, J.Y., 1990.Compilation of the Chinese Continental Geothermal Value Data.Seismology and Geology, 12(4):351-363 (in Chinese with English abstract). Wang, L.S., Li, C., Shi, Y.S., et al., 1995.Distributions of Geotemperature and Terrestrial Heat Flow Density in Lower Yangtze Area.Acta Geoscientica Sinica, 38 (4):469-476 (in Chinese with English abstract). Wang, Q., X
