K1 Xiguayuan Formation Soft-Sediment Deformation Caused by Earthquake in Luanping Basin
-
摘要: 为完善对滦平盆地西瓜园组地震引发的软沉积变形构造的认识,综合利用野外观测与室内分析相结合、宏观沉积体系与微观软沉积变形构造等分析相结合的方法,对研究区震积成因的软沉积变形构造进行了研究.结果表明,在盆内主、次控盆断层夹角位置的两处剖面中,可见枕状构造、液化砂岩脉、液化砂岩侵位、液化角砾岩、液化卷曲变形、砂岩滴落体、火焰构造、球枕构造、枕状层、负荷构造和震积不整合的组合发育,且同一剖面具有垂向多次震积作用的连续发育特点,这些震积作用均被识别在扇三角洲前缘相带内.根据这些软沉积变形发育的位置、彼此组合伴生、连续发育和区域分布的特点,可识别出连续2次大地震的发生.Abstract: In order to improve the understanding of soft-sediment deformation structures caused by earthquake of the Xiguayuan Formation in Luanping basin, they were studied by the method of combination of both the field investigation with laboratory analysis, and the macroscopic sedimentary system with microscopic soft-sediment deformation structure. In two sections at the angle between the main and secondary basin-controlling faults in the basin, pillow structure, liquefied sand veins, liquefied sand emplacement, liquefied breccias, liquefaction curl deformation, liquefied droplet, flame structure, ball-and-pillow structure, pillow beds, load structure and seismic unconformity plane were developed. Seismites deposited continuously in fan delta front. According to the location of these soft-sediment deformation, their association, continuous development and regional distribution, two successive earthquakes can be identified.
-
Key words:
- Luanping basin /
- Xiguayuan Formation /
- soft-sediment deformation /
- earthquake /
- sedimentology
-
图 2 滦平盆地西瓜园组环境变化标志
a.石膏假晶(纪友亮等提供手标本的照片)、石膏(显微照片Gp)和白云石(显微照片Dol),反映湖盆处于干旱蒸发环境;b.多期泥裂(上半段图的观察角度为垂直泥岩水平层理面,下半段图为平行该面),反映泥时而处于水下接受沉积,时而暴露水面接触干燥空气;c.恐龙脚印化石与泥裂共生(平行泥岩水平层理面),恐龙脚印化石的出现反映了暗色泥岩指示的较深湖环境变为恐龙生活的浅水区环境(纪友亮等,2008);d.韵律层理,钙质成分与黑色泥质成分互层,反映了季节等引起的湖泊环境变化,小钙质结核,后期被上覆砂岩等压实,结核相对致密,因而向下压弯软的细粒沉积物;白色层为钙质成分较高层,黑色为有机质成分较高,红色为Fe含量较高层
Fig. 2. Indicators of environmental changes of the Xiguayuan Formation in Luanping basin
图 3 滦平盆地西瓜园组杨树沟剖面西半部分震积软沉积变形构造组合
a.杨树沟剖面西半部分剖面整体照片;b.剖面右侧局部放大照片,负荷构造、液化砂岩脉、液化砂岩侵位;c.剖面左侧局部放大照片,两期叠置的负荷构造、火焰构造和震积不整合;d.图c的局部放大图. 1.负荷构造; 2.液化砂岩脉; 3.原地砂岩液化向下侵位; 4.原地砂岩液化向上侵位; 5.火焰构造; 6①.第1次地震的震积不整合面; 6②.第2次地震的震积不整合面; 7.异地相沉积物
Fig. 3. Structural assemblage of seismic soft-sediment deformation in the western Yangshugou Section of the Xiguayuan Formation in Luanping basin
图 4 滦平盆地西瓜园组杨树沟剖面东半部分震积软沉积变形构造组合
a.液化砂岩脉、液化砂岩侵位、液化泥质角砾岩、液化卷曲变形和被破坏的震积不整合面;b.枕状构造、震积不整合、液化砂岩侵位、液化卷曲变形和滴落体; c.球枕构造和滴落体; d.枕状层和张性裂缝. 1.负荷构造; 3.原地砂岩液化向下侵位; 4.原地砂岩液化向上侵位; 5.火焰构造; 6①B.液化破坏的第1次地震的震积不整合面; 6②.第2次地震的震积不整合面; 6②B.液化破坏的第2次地震的震积不整合面; 7.异地相沉积物; 8.异地相沉积物与原地沉积物互层; 9.异地相沉积物液化向下侵位; 10.液化的异地相沉积物与原地沉积物混合向下侵位; 11.异地相沉积物滴落体; 12.原地沉积物滴落体; 13.液化脉; 14.液化卷曲变形; 15.球枕构造; 16.枕状层; 17.球枕内张性裂缝; 18.球枕构造内同心纹层
Fig. 4. Structural assemblage of seismic soft-sediment deformation in the eastern half of the Yangshugou Section of the Xiguayuan Formation in Luanping basin
-
Brogi, A., Capezzuoli, E., Moretti, M., et al., 2018.Earthquake-Triggered Soft-Sediment Deformation Structures (Seismites) in Travertine Deposits.Tectonophysics, 745:349-365. http://www.sciencedirect.com/science/article/pii/S0040195118303056 Deev, E., Korzhenkov, A., Turova, I., et al., 2018.Large Ancient Earthquakes in the Western Issyk-Kul Basin (Kyrgyzstan, Northern Tien Shan).Journal of Asian Earth Sciences, 166:48-65. doi: 10.1016/j.jseaes.2018.07.019 Deev, E., Turova, I., Borodovskiy, A., et al., 2019.Large Earthquakes in the Katun Fault Zone (Gorny Altai):Paleoseismological and Archaeoseismological Evidence. Quaternary Science Reviews, 203:68-89. doi: 10.1016/j.quascirev.2018.11.009 Er, C., Gu, J. Y., Niu, J. Y., et al., 2010.Gravity-Driven Processes:A More Important Transport Mechanism of Deposits in Xiguayuan Formation of Lower Cretaceous in Luanping Basin, Northern Hebei. Geological Review, 56(3):312-320 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DZLP201003002.htm Ezquerro, L., Moretti, M., Liesa, C. L., et al., 2015.Seismites from a Well Core of Palustrine Deposits as a Tool for Reconstructing the Palaeoseismic History of a Fault.Tectonophysics, 655:191-205. doi: 10.1016/j.tecto.2015.05.025 Ji, Y. L., Sun, Y. H., Jia, Y. H., 2008.Dinosaur Footprint Fossils in Dark Mudstones of the Xiguayuan Formation (Upper Jurassic-Lower Cretaceous) in Luanping Basin and Their Geological Significance. Journal of Palaeogeography, 10(4):379-384 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-GDLX200804009.htm Ji, Y. L., Wu, S. H., Zhou, Y., et al., 2013.Radiational Bedding in Sandstone and Analysis of Its Origin in Dongyangshugou Section of Luanping, Hebei Province. Journal of Palaeogeography, 15(1):43-48 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-GDLX201301006.htm Khan, R. A., Shah, M. Y., 2016.Earthquake Induced Liquefaction Features in the Karewas of Kashmir Valley North-West Himalayas, India:Implication to Paleoseismicity. Soil Dynamics and Earthquake Engineering, 90:101-111. doi: 10.1016/j.soildyn.2016.08.007 Li, H. T., Song, Z. G., Zou, Y. R., et al., 2008.Characteristics of Sedimentary Organic Matter and Paleoclimate and Environmental Evolution during Early Cretaceous Time in Northern Part of Hebei and Western of Liaoning Provinces. Acta Geologica Sinica, 82(1):72-76 (in Chinese with English abstract). http://www.researchgate.net/publication/285715404_Characteristics_of_sedimentary_organic_matter_and_paleoclimate_and_environmental_evolution_during_early_Cretaceous_time_in_northern_part_of_Hebei_and_western_of_Liaoning_Provinces Li, T.D., 2006.Lithospheric Tectonic Units of China. Geology in China, 33(4):700-709 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-DIZI200604002.htm Li, Y., 2003.Fan-Deltaic Depositional Systems of the Xiguayuan Formation in Luanping Basin. Acta Geoscientia Sinica, 24(4):353-356 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-DQXB200304013.htm Liang, D. Y., Nie, Z. T., Song, Z. M., 1994a.A Re-Study on Seismite and Seismo-Unconformity:Taking Western Sichuan and Western Yunnan as an Example. Earth Science, 19(6):845-850 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DQKX199406018.htm Liang, D. Y., Nie, Z. T., Song, Z. M., 1994b.Extensional Dongwu Movement in Western Margin of Yangtze Region. Earth Science, 19(4):443-453 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DQKX199404007.htm Liu, C., Yu, B. S., Jiang, R., et al., 2017.Sedimentary Feature and Mode of Gravity Flow in Lacustrine Basin:Example from Ordos Basin and Luanping Basin.Geological Science and Technology Information, 36(5):133-142 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-DZKQ201705018.htm Liu, H., Li, F. Q., Zhou, F., et al., 2018.Late Paleozoic Earthquake Events in the Nixiong Area and Its Geological Significance, Western Lhasa Block. Earth Science, 43(8):2767-2779 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-DQKX201808018.htm Montenat, C., Barrier, P., Estevou, P. O., et al., 2007.Seismites:An Attempt at Critical Analysis and Classification. Sedimentary Geology, 196 (1-4):5-30. doi: 10.1016/j.sedgeo.2006.08.004 Moretti, M., Loon, A. J., 2014. Restrictions to the Application of 'Diagnostic' Criteria for Recognizing Ancient Seismites. Journal of Palaeogeography, 3(2):162-173. http://www.sciencedirect.com/science/article/pii/S2095383615300699 Niu, S. W., Tian, S. G., 2008.Discovery of Conchostracans Occurring in the Yixian Formation of Western Liaoning in the Xiguayuan Formation of the Luanping Basin, Northern Hebei, China, and Its Significance. Geological Bulletin of China, 27(6):753-768 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-ZQYD200806006.htm Pan, L. C., Li, L. Q., Li, X., et al., 2010.Sedimentary Characteristics of the Jiufotang Formation Developed in Luanping Mesozoic Fault Basin of Northern Hebei Province. Journal of Geomechanics, 16(1):85-95 (in Chinese with English abstract). http://www.zhangqiaokeyan.com/academic-journal-cn_journal-geomechanics_thesis/0201253296653.html Pisarska-Jamroży, M., Loon, A.J., Mleczak, M., et al., 2019.Enigmatic Gravity-Flow Deposits at Ujście (Western Poland), Triggered by Earthquakes (as Evidenced by Seismites) Caused by Saalian Glacioisostatic Crustal Rebound.Geomorphology, 326:239-251. doi: 10.1016/j.geomorph.2018.01.010 Qiao, X. F., 1996.Study of Seismites of China and Its Prospects. Geological Review, 42(4):317-320 (in Chinese with English abstract) http://d.wanfangdata.com.cn/Periodical_OA000002764.aspx Qiao, X. F., Jiang, M., Li, H. B., et al., 2016.Soft-Sediment Deformation Structures and Their Implications for Tectonic Evolution from Mesozoic to Cenozoic in the Longmen Shan. Earth Science Frontiers, 23(6):80-106 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-DXQY201606013.htm Qiao, X. F., Li, H. B., Gao, L. Z., 1997.Sinian-Early Paleozoic Seismic Rhythms on the North China Platform. Earth Science Frontiers, 4(3-4):155-160 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DXQY7Z2.025.htm Qiao, X. F., Song, T. R., Gao, L. Z., et al., 2006.Seismic Record in Strata. Geological Publishing House, Beijing, 1-263 (in Chinese with English abstract). Tian, S. G., Niu, S. W., Pang, Q. Q., 2008.Redefinition of the Lower Cretaceous Terrestrial Yixianian Stage and Its Stratotype Candidate in the Luanping Basin, Northern Hebei, China. Geological Bulletin of China, 27(6):739-752 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-ZQYD200806005.htm Üner, S., Özsayın, E., Selçuk, A. S., et al., 2019.Seismites as an Indicator for Determination of Earthquake Recurrence Interval:A Case Study from Erciş Fault (Eastern Anatolia-Turkey).Tectonophysics, 766:167-178. http://www.sciencedirect.com/science/article/pii/S0040195119302410 Wallace, K., Eyles, N., 2015.Seismites within Ordovician-Silurian Carbonates and Clastics of Southern Ontario, Canada and Implications for Intraplate Seismicity. Sedimentary Geology, 316:80-95. doi: 10.1016/j.sedgeo.2014.12.004 Wu, F. D., Chen, Y. J., Hou, Y. A., et al., 2004.Characteristics of Sedimentary-Tectonic Evolution and High-Resolution Sequence Stratigraphy in Luanping Basin. Earth Science, 29(5):625-630 (in Chinese with English abstract). http://www.researchgate.net/publication/291106966_Characteristics_of_sedimentary-tectonic_evolution_and_high-resolution_sequence_stratigraphy_in_Luanping_basin Xiang, H., Zhang, L., 2007.Sequence Characters of the Fan Delta Outcrop of Xiguayuan Formation in Luanping Basin. Petroleum Geology and Recobery Efficiency, 14(6):20-23 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=yqdzycsl200706006 Xing, L. D., Lockley, M. G., Qin, Z. H., et al., 2019.Dinosaur Tracks from the Lower Cretaceous Xiguayuan Formation in the Luanping Basin, Hebei Province, China. Cretaceous Research, 103:104-163. http://www.sciencedirect.com/science/article/pii/S0195667119300540 Yu, Z. Y., He, B. Z., Qiao, X. F., et al., 2016.Seismites in the Early and Middle Silurian Strata of Shuntuoguole Area in Tarim Basin:Records of High-Resolution Tectonic Events. Acta Geoscientica Sinica, 37(3):313-325 (in Chinese with English abstract). http://www.en.cnki.com.cn/Article_en/CJFDTotal-DQXB201603011.htm Zhang, K. X., Pan, G. T., He, W. H., 2015.New Division of Tectonic-Strata Superregion in China. Earth Science, 40(2):206-233 (in Chinese with English abstract). http://gateway.proquest.com/openurl?res_dat=xri:pqm&ctx_ver=Z39.88-2004&rfr_id=info:xri/sid:baidu&rft_val_fmt=info:ofi/fmt:kev:mtx:article&genre=article&jtitle=Earth%20Science&atitle=New%20Division%20of%20Tectonic-Strata%20Superregion%20in%20China Zhang, Y. L., Meng, Q. R., 2008.Early Cretaceous Basin Characteristics in the Middle Segment of Yanshanian Stuctural Belt. Journal of Jilin Unibersity (Earth Science Edition), 38(4):604-612 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-CCDZ200804010.htm Zhang, Y. L., Qu, H. J., Meng, Q. R., 2007.Depositional Process and Evolution of Luanping Early Cretaceous Basin in the Yanshan Structural Belt. Acta Petrologica Sinica, 23(3):667-678 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-YSXB200703015.htm Zhao, X. F., Li, Z. K., Zhao, S. R., et al., 2018.Early Cretaceous Regional-Scale Magmatic-Hydrothermal Metallogenic System at the Southern Margin of the North China Craton. Earth Science, 44(1):52-68 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-DQKX201901005.htm Zheng, Y. J., Chen, S. W., Ding, Q. H., et al., 2011.Correlation between Yixian Formation in Western Liaoning and Dadianzi and Xiguayuan Formations in Northern Hebei. Geology and Resources, 20(1):21-26 (in Chinese with English abstract). http://d.wanfangdata.com.cn/Periodical/gjsdz201101005 耳闯, 顾家裕, 牛嘉玉, 等, 2010.重力驱动作用——滦平盆地下白垩统西瓜园组沉积时期主要的搬运机制.地质论评, 56(3):312-320. http://d.wanfangdata.com.cn/Periodical/OA000004009 纪友亮, 孙玉花, 贾爱林, 2008.滦平盆地西瓜园组(上侏罗统-下白垩统)暗色泥岩中恐龙脚印化石及其地质意义.古地理学报, 10(4):379-384. http://www.cnki.com.cn/Article/CJFDTotal-GDLX200804009.htm 纪友亮, 吴胜和, 周勇, 等, 2013.河北滦平东杨树沟剖面砂岩中的发散状层理及其成因探讨.古地理学报, 15(1):43-48. http://www.cnki.com.cn/Article/CJFDTotal-GDLX201301006.htm 李洪涛, 宋之光, 邹艳荣, 等, 2008.冀北-辽西早白垩世沉积有机质特征与古气候环境演变.地质学报, 82(1):72-76. http://d.wanfangdata.com.cn/periodical/dizhixb200801009 李廷栋, 2006.中国岩石圈构造单元.中国地质, 33(4):700-709. http://www.cnki.com.cn/article/cjfdtotal-dizi200604002.htm 李寅, 2003.滦平盆地西瓜园组扇三角洲沉积体系构成及其特征.地球学报, 24(4):353-356. http://www.cnki.com.cn/Article/CJFDTotal-DQXB200304013.htm 梁定益, 聂泽同, 宋志敏, 1994a.再论震积岩及震积不整合——以川西、滇西地区为例.地球科学, 19(6):845-850. http://www.earth-science.net/article/id/199 梁定益, 聂泽同, 宋志敏, 1994b.扬子西缘东吴伸展运动.地球科学, 19(4):443-453. http://www.earth-science.net/article/id/167 刘策, 于炳松, 蒋锐, 等, 2017.湖盆重力流沉积特征及模式:以鄂尔多斯盆地及滦平盆地为例.地质科技情报, 36(5):133-142. http://www.cqvip.com/QK/93477A/20175/673266131.html 刘函, 李奋其, 周放, 等, 2018.拉萨地块西段尼雄地区晚古生代地震事件及其地质意义.地球科学, 43(8):2767-2779. doi: 10.3799/dqkx.2018.167 牛绍武, 田树刚, 2008.辽西义县组叶肢介化石在冀北滦平盆地西瓜园组中的系统发现及其意义.地质通报, 27(6):753-768. http://d.wanfangdata.com.cn/Periodical/zgqydz200806004 潘立成, 李林庆, 李翔, 等, 2010.冀北滦平中生代陆相断陷盆地九佛堂组沉积特征分析与探讨.地质力学学报, 16(1):85-95. http://d.wanfangdata.com.cn/Periodical/dzlxxb201001011 乔秀夫, 1996.中国震积岩的研究与展望.地质论评, 42(4):317-320. http://d.wanfangdata.com.cn/Periodical_OA000002764.aspx 乔秀夫, 姜枚, 李海兵, 等, 2016.龙门山中、新生界软沉积物变形及构造演化.地学前缘(中国地质大学(北京)), 23(6):80-106. http://www.cqvip.com/QK/98600X/201606/670513018.html 乔秀夫, 李海兵, 高林志, 1997.华北地台震旦纪-早古生代地震节律.地学前缘(中国地质大学(北京)), 4(3-4):155-160. http://www.cnki.com.cn/Article/CJFDTotal-DXQY7Z2.025.htm 乔秀夫, 宋天锐, 高林志, 等, 2006.地层中地震记录.地质出版社, 1-263. 田树刚, 牛绍武, 庞其清, 2008.冀北滦平盆地早白垩世陆相义县阶的重新厘定及其层型剖面.地质通报, 27(6):739-752. 武法东, 陈永进, 侯宇安, 等, 2004.滦平盆地沉积-构造演化及高精度层序地层特征.地球科学, 29(5):625-630. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqkx200405020 项华, 张乐, 2007.滦平盆地西瓜园组扇三角洲露头层序特征.油气地质与采收率, 14(6):20-23. http://www.cnki.com.cn/Article/CJFDTotal-YQCS200706007.htm 余卓颖, 何碧竹, 乔秀夫, 等, 2016.塔里木盆地顺托果勒地区早中志留世震积岩.地球学报, 37(3):313-325. http://www.cqvip.com/qk/98325a/20163/669017512.html 张克信, 潘桂堂, 何卫红, 等, 2015.中国构造-地层大区划分新方案.地球科学, 40(2):206-233. doi: 10.3799/dqkx.2015.016 张英利, 孟庆任, 2008.燕山构造带中段早白垩世盆地特征.吉林大学学报(地球科学版), 38(4):604-612. http://www.cqvip.com/Main/Detail.aspx?id=28098501 张英利, 渠洪杰, 孟庆任, 2007.燕山构造带滦平早白垩世盆地沉积过程和演化.岩石学报, 23(3):667-678. http://www.cqvip.com/Main/Detail.aspx?id=25485327 赵新福, 李占轲, 赵少瑞, 等, 2019.华北克拉通南缘早白垩世区域大规模岩浆-热液成矿系统.地球科学, 44(1):52-68. doi: 10.3799/dqkx.2018.372 郑月娟, 陈树旺, 丁秋红, 等, 2011.辽西义县组与冀北大店子组、西瓜园组的对比.地质与资源, 20(1):21-26. http://d.wanfangdata.com.cn/Periodical/gjsdz201101005
