Reservoir Characteristics and Forming Mechanisms of Lacustrine Mixed Sedimentary Rock of First and Second Members of Shahejie Formation in BZ27-A Structure, Huanghekou Sag
-
摘要: 渤海海域黄河口凹陷BZ27-A（渤中27-A）构造沙一二段发育一套湖相混积岩，目前对该储层的特征及成因研究较少.通过岩心观察、铸体薄片、压汞测试等分析，系统阐述了该区混积岩储层的岩石学、储集空间类型、物性等特征，在此基础上探讨了混积岩储层控制因素.结果表明，混积岩岩性复杂多样，由陆源碎屑、黏土矿物、碳酸盐矿物及生物碎屑以多种组合方式混杂构成，发育钙质砂岩、白云质砂岩、陆屑泥晶云岩、泥晶鲕粒云岩、生物碎屑白云岩等类型，剖面上大多呈现夹层或薄互层的特点.多数混积岩储层孔隙度、渗透率低，为致密储层，局部薄层段发育相对较好储层.混积岩储层的发育主要受古地理背景、成岩作用、流体等因素影响，成岩早期大面积碳酸盐胶结是导致储层致密的主要成因，而生屑的贡献、晚期成藏时的油气侵位作用是改善储层物性的重要作用，具有形成相对优质储层的潜力.Abstract: There is a set of lacustrine mixed sedimentary rocks in the first and second members of Shahejie Formation(Es1-2) in BZ27-A structure in Huanghekou sag, Bohai Sea area. At present, the research on the characteristics and genesis of this reservoir is still weak. In this study, based on the core observation, casting thin section and mercury porosimetry, the characteristics of petrology, reservoir space type, physical property of mixed sedimentary rock reservoir are systematically described firstly, and then the controlling factors of the reservoir are put forward. The results show that the mixed sedimentary rock consists of terrigenous clastic, clay minerals, carbonate minerals and biodetritus. The lithology mainly includes calcareous sandstone, dolomitic sandstone, terrigenous clastic micrite dolomite, micrite oolitic dolomite and bioclastic dolomite, which are interbeded or thin interbeded in the vertical section. Most of the mixed sedimentary rock reservoirs are tight due to low porosity and permeability, with few relatively better reservoirs in thin intervals. The main factors controlling the mixed sedimentary rock reservoirs are paleogeographic background, provenance, diagenesis and fluid. Massive carbonate cementation in the diagenetic stage is the main cause of tight reservoir, however, the contributions of bioclastic, oil and gas emplacement in the later stage of hydrocarbon accumulation are important for improving the physical properties of reservoirs, and have the potential to form relatively high-quality reservoirs.
-
图 3 BZ27-A构造沙一二段混积岩岩石类型及特征
a.钙质粗粒岩屑长石砂岩，粒间大量方解石，较均匀胶结、交代碎屑颗粒，部分方解石重结晶，见部分颗粒完全被方解石交代，BZ27-A-1井，3 692.00 m；b.钙质含砾粗粒长石岩屑砂岩，见少量螺及介形虫等生物碎片发育.碎屑颗粒被铁方解石致密胶结、强烈交代现象普遍，部分颗粒已完全被铁方解石所交代，仅残留包壳外形，BZ27-A-2井，3 751.96 m；c.含生屑云质粉-细砂岩，BZ27-A-1井，3 752.00 m；d.含盆屑白云质粗粉砂岩，盆屑成分主要为介形虫及碎片、砂屑、粉屑和少量鲕粒，胶结物主要为显微晶白云石，BZ27-A-1井，3 772.00 m；e.白云质细砂岩，粒间填隙物主要为泥晶白云石，致密胶结、交代碎屑颗粒，BZ27-A-2井，3 872.50 m；f.泥晶砂屑云岩，岩石组构包括砂屑、生屑、陆源碎屑及泥晶，砂屑较均匀定向分布，生屑见螺屑及介形，保存较完整，泥晶白云石较均匀分布于粒屑间，BZ27-A-1井，3 765.00 m；g.含陆屑泥晶云岩，左上部分为泥晶白云岩，右下部分为泥晶白云石充填在陆源碎屑颗粒间，BZ27-A-1井，3 829.00 m；h.陆屑泥晶云岩，主要为细砂级的石英、长石等陆源碎屑及泥晶组成，泥晶白云石较均匀分布于陆屑间并交代部分颗粒，BZ27-A-1井，3 873.00 m；i.生物碎屑云岩，含少量陆源碎屑颗粒，BZ27-A-1井，3 750.00 m；j.陆屑生屑泥晶云岩，陆源碎屑主要为石英、长石、岩屑，岩屑主要见花岗岩岩块，生物碎屑主要为螺和介形虫，BZ27-A-2井，3 788.66 m；k.含陆屑粒屑泥晶白云岩，主要由泥晶白云石、陆源碎屑、方解石和生物碎屑组成，碎屑成分主要由石英、长石、变质石英岩岩屑等组成，生物碎屑主要为介形虫，BZ27-A-2井，3 788.59 m；l.含陆屑泥晶鲕粒云岩，岩石矿物成分主要为白云石，其次为方解石及石英、长石；包括鲕粒、泥晶及陆屑，鲕粒见同心鲕及表鲕，表鲕鲕核主要为石英及长石，泥晶白云石较均匀分布于鲕粒及陆屑间，BZ27-A-2井，3 787.00 m
Fig. 3. Rock type and characteristics of mixed sedimentary rock of Es1-2 in BZ27-A structure
图 4 沙一二段混积岩储集空间类型
a.原生粒间孔，BZ27-A-2井，3 875.00 m；b.粒间溶蚀孔，BZ27-A-2井，3 890.00 m；c.粒内溶蚀孔，BZ27-A-2井，3 746.91 m；d.生物碎屑体腔孔，BZ27-A-1井，3 750.00 m；e.充填残余孔隙，泥晶白云石部分充填生物体腔，BZ27-A-1井，3 752.00 m；f.陆源碎屑铸模孔，BZ27-A-2井，3 751.67 m；g.白云石晶间微孔，BZ27-A-2井，3 747.25 m；h.微裂缝，BZ27-A-2井，3 751.96 m；i.收缩缝，BZ27-A-2井，3 748.69 m
Fig. 4. Reservoir space types of the mixed sedimentary rock of Es1-2
图 5 沙一二段混积岩孔隙度直方图(a)和孔渗关系图(b)
Fig. 5. The porosity column(a) and relationship between porosity and permeability (b) of mixed sedimentary rock of Es1-2
图 6 沙一二段混积岩毛管压力曲线特征
φ表示孔隙度(%); K表示渗透率(10-3 μm2)
Fig. 6. Capillary curve characteristics of mixed sedimentary rock of Es1-2
图 7 沙一二段沉积期古地貌恢复图
Fig. 7. Restoring paleogeomorphology map of the Es1-2 sedimentary period
-
Cai, J.G., Li, C.X., 1994. Characteristics of Canbomferous Mixed Siliciclastic and Carbonate Sediments in Southwest Inner Mongoli. Oil & Gas Geology, 15(1):80-86(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SYYT401.007.htm Chiarella, D., Longhitano, S. G., Tropeano, M., 2017. Types of Mixing and Heterogeneities in Siliciclastic-Carbonate Sediments. Marine and Petroleum Geology, 88:617-627. https://doi.org/10.1016/j.marpetgeo.2017.09.010 Dai, L.M., Xu, C.G., Wang, Q.B., et al., 2017. Difference of Provenance Evolution Mode and Its Impact on Reservoir in the Western Steep Slope Zone of Shijiutuo Uplift, Bohai Sea. China Offshore Oil and Gas, 29(4):51-59(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zghsyq-gc201704006 Dong, G.Y., Chen, H.D., He, Y.B., et al., 2007. Some Problems on the Study of the Mixed Siliciclastic-Carbonate Sediments. Advances in Earth Science, 22(9):931-939(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqkxjz200709007 Dong, Y.L., Zhu, X.M., Hua, S.J., et al., 2011. Genetic Types and Evolutionary Model of Mixed Clastic-Carbonate Deposits in the Lower Part of the Sha-1 Formation, the Huanghua Depression. Oil & Gas Geology, 32(1):98-107(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-SYYT201101014.htm Guo, F.S., 2004. Characteristics and Tectonic Significance of Mixing Sediments of Siliciclastics and Carbonate of Outangdi Formation in Jiangshan, Zhejiang Province. Acta Sedimentologica Sinica, 22(1):136-141(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=cjxb200401021 Huo, S.J., Yang, X.H., Wang, Q.B., et al., 2015. Controlling Factors on Diamictite Reservoir in Shahejie Formation, H-1 Structure, Huanghekou Depression. Geoscience, 29(6):1348-1359(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=xddz201506009 Jiang, M.S., Sha, Q.A., Liu, M., 1996. Mixed Siliciclastic-Carbonate Sediments during the Lower-Middle Cambrian in the North China Platform. Acta Sedimentologica Sinica, 14(Suppl.):63-74(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-CJXB6S1.008.htm Li, T.T., Zhu, R.K., Bai, B., et al., 2015.Characteristics of Mixed Sedimentary Reservoir:Taking the Lower Cretaceous Mixed Sedimentary Rock of Qingxi Depression in Jiuquan Basin as an Example. Acta Sedimentologica Sinica, 33(2):376-384(in Chinese with English abstract). http://www.en.cnki.com.cn/Article_en/CJFDTotal-CJXB201502017.htm Li, X.N., Ma, Q., Liang, H., et al., 2015. Geological Characteristics and Exploration Potential of Diamictite Tight Oil in the Second Member of the Permian Lucaogou Formation, Santanghu Basin, NW China. Petroleum Exploration and Development, 42(6):763-771, 793(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syktykf201506009 Longhitano, S. G., Sabato, L., Tropeano, M., et al., 2010. A Mixed Bioclastic-Siliciclastic Flood-Tidal Delta in a Micro Tidal Setting:Depositional Architectures and Hierarchical Internal Organization (Pliocene, Southern Apennine, Italy). Journal of Sedimentary Research, 80(1):36-53. https://doi.org/10.2110/jsr.2010.004 Ma, Y.P., Liu, L., 2003. Sedimentary and Diagenetic Characteristics of Paleogene Lacustrine "Hunji" Rock in Beach District, Dagang. Acta Sedimentologica Sinica, 21(4):607-613(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=cjxb200304011 Morsilli, M., Bosellini, F., Pomar, L., et al., 2012. Mesophotic Coral Buildups in a Prodelta Setting (Late Eocene, Southern Pyrenees, Spain):A Mixed Carbonate-Siliciclastic System. Sedimentology, 59(3):766-794. https://doi.org/10.1111/j.1365-3091.2011.01275.x Mount, J. F., 1985. Mixed Siliciclastic and Carbonate Sediments:A Proposed First-Order Textural and Compositional Classification. Sedimentology, 32(3):435-442. https://doi.org/10.1111/j.1365-3091.1985.tb00522.x Sha, Q.A., 2001. Discussion on Mixing Deposit and Hunji Rock. Journal of Palaeogeography, 3(3):63-66(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gdlxb200103008 Sima, L.Q., Yang, Y., Wu, F., et al., 2014. Lithology Identification on Mixing Deposit with Logging Data in Northwest Xiaoliangshan of Qaidam Basin. Geological Science and Technology Information, 33(2):180-185(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzkjqb201402030 Wang, J.Y., Zhang, L.Q., Zhang, S.Q., et al., 2013. Sedimentary Characteristics and Origin of Lacustrine Mixed Rocks of the Second Member of the Eogene Shahejie Formation in Zhanhua Sag, Jiyang Depression:Taking Luojia-Shaojia Area for an Example. Geological Review, 59(6):1085-1096(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DZLP201306010.htm Xie, X.N., Ye, M.S., Xu, C.G., et al., 2018.High Quality Reservoirs Characteristics and Forming Mechanisms of Mixed Siliciclastic-Carbonate Sediments in the Bozhong Sag, Bohai Bay Basin. Earth Science, 43(10):3526-3539(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqkx201810015 Xue, Y.A., Yang, H.F., Xu, C.G., 2016. Differential Reservoir-Controlling Effect and Hydrocarbon Enrichment of Slope Zone in Huanghekou Sag, Bohai Bay Basin. China Petroleum Exploration, 21(4):65-74(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgsykt201604007 Yang, C.Q., Sha, Q.A., 1990. Sedimentary Environment of the Middle Devonian Qujing Formation, Qujing, Yunnan Province:A Kind of Mixing Sedimentation of Terrigenous Clastics and Carbonate. Acta Sedimentologica Sinica, 8(2):59-66(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-CJXB199002008.htm Ye, M.S., Xie, X.N., Xu, C.G., et al., 2018. Discussion for Classification-Designation System of Mixed Siliciclastic:Carbonate Sediments and the Implication for Their Reservoir Prediction-A Case Study of Mixed Sediments from Bohai Sea Area. Geological Review, 64(5):1118-1131(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-DZLP201805007.htm Zhang, X., 2002. Logging Evaluation Technique of Fractured Diamictite Reservoirs. Natural Gas Industry, 22(2):34-37(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=trqgy200202010 Zhang, X.H., 2000. Classification and Origin of Mixosedimentite. Geological Science and Technology Information, 19(4):31-34(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzkjqb200004006 Zhang, X.T., Zhou, X.H., Niu, C.M., et al., 2014. Constraints by Tectonic Slope-Break Zones on the Depositional Systems in Eogene in the Sag of the Yellow River Estuary. Geological Review, 60(2):332-338(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzlp201402008 Zhou, L.H., Chen, C.W., Han, G.M., et al., 2019.Geological Characteristics and Shale Oil Exploration Potential of Lower First Member of Shahejie Formation in Qikou Sag, Bohai Bay Basin. Earth Science, 44(8):2736-2750(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqkx201908018 蔡进功, 李从先, 1994.内蒙西南部石炭系碎屑岩-碳酸盐岩混合沉积特征.石油与天然气地质, 15(1):80-86. 代黎明, 徐长贵, 王清斌, 等, 2017.石臼坨凸起西部陡坡带古物源差异演化模式及其对储层的控制作用.中国海上油气, 29(4):51-59. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zghsyq-gc201704006 董桂玉, 陈洪德, 何幼斌, 等, 2007.陆源碎屑与碳酸盐混合沉积研究中的几点思考.地球科学进展, 22(9):931-939. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqkxjz200709007 董艳蕾, 朱筱敏, 滑双君, 等, 2011.黄骅坳陷沙河街组一段下亚段混合沉积成因类型及演化模式.石油与天然气地质, 32(1):98-107. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syytrqdz201101012 郭福生, 2004.浙江江山藕塘底组陆源碎屑与碳酸盐混合沉积特征及其构造意义.沉积学报, 22(1):136-141. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=cjxb200401021 霍沈君, 杨香华, 王清斌, 等, 2015.黄河口凹陷H-1构造沙河街组混积岩储层控制因素.现代地质, 29(6):1348-1359. 江茂生, 沙庆安, 刘敏, 1996.华北地台下中寒武统碳酸盐与陆源碎屑混合沉积——以山东张夏地区为例.沉积学报, 14(增刊):63-74. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK199600895927 李婷婷, 朱如凯, 白斌, 等, 2015.混积岩储层特征——以酒泉盆地青西凹陷下白垩统混积岩为例.沉积学报, 33(2):376-384. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=cjxb201502017 李新宁, 马强, 梁辉, 等, 2015.三塘湖盆地二叠系芦草沟组二段混积岩致密油地质特征及勘探潜力.石油勘探与开发, 42(6):763-771, 793. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syktykf201506009 马艳萍, 刘立, 2003.大港滩海区第三系湖相混积岩的成因与成岩作用特征.沉积学报, 21(4):607-613. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=cjxb200304011 沙庆安, 2001.混合沉积和混积岩的讨论.古地理学报, 3(3):63-66. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gdlxb200103008 司马立强, 杨毅, 吴丰, 等, 2014.柴西北小梁山地区混积岩测井岩性识别.地质科技情报, 33(2):180-185. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzkjqb201402030 王金友, 张立强, 张世奇, 等, 2013.济阳坳陷沾化凹陷沙二段湖相混积岩沉积特征及成因分析:以罗家-邵家地区为例.地质论评, 59(6):1085-1096. 解习农, 叶茂松, 徐长贵, 等, 2018.渤海湾盆地渤中凹陷混积岩优质储层特征及成因机理.地球科学, 43(10):3526-3539. doi: 10.3799/dqkx.2018.277 薛永安, 杨海风, 徐长贵, 2016.渤海海域黄河口凹陷斜坡带差异控藏作用及油气富集规律.中国石油勘探, 21(4):65-74. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgsykt201604007 杨朝青, 沙庆安, 1990.云南曲靖中泥盆统曲靖组的沉积环境一种陆源碎屑.沉积学报, 8(2):59-66. 叶茂松, 解习农, 徐长贵, 等, 2018.混积岩分类命名体系探讨及对混积岩储层评价的启示:以渤海海域混积岩研究为例.地质论评, 64(5):1118-1131. http://www.cnki.com.cn/Article/CJFDTotal-DZLP201805007.htm 张新涛, 周心怀, 牛成民, 等, 2014.黄河口凹陷古近纪构造坡折带对沉积体系的控制.地质论评, 60(2):332-338. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzlp201402008 张雄华, 2000.混积岩的分类和成因.地质科技情报, 19(4):31-34. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzkjqb200004006 张旭, 2002.裂缝性混积岩储层测井评价技术.天然气工业, 22(2):34-37. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=trqgy200202010 周立宏, 陈长伟, 韩国猛, 等, 2019.渤海湾盆地歧口凹陷沙一下亚段地质特征与页岩油勘探潜力.地球科学, 44(8):2736-2750. doi: 10.3799/dqkx.2019.112 -
