    渤海海域沙一二段湖相混积岩储层测井分类与识别

    冯冲 代黎明 刘晓健 赵梦 张参

    冯冲, 代黎明, 刘晓健, 赵梦, 张参, 2020. 渤海海域沙一二段湖相混积岩储层测井分类与识别. 地球科学, 45(10): 3677-3692. doi: 10.3799/dqkx.2020.129
    引用本文: 冯冲, 代黎明, 刘晓健, 赵梦, 张参, 2020. 渤海海域沙一二段湖相混积岩储层测井分类与识别. 地球科学, 45(10): 3677-3692. doi: 10.3799/dqkx.2020.129
    Feng Chong, Dai Liming, Liu Xiaojian, Zhao Meng, Zhang Can, 2020. Logging Classification and Recognition of Lacustrine Mixed Sedimentary Reservoirs in First and Second Members of Shahejie Formation in Bohai Sea. Earth Science, 45(10): 3677-3692. doi: 10.3799/dqkx.2020.129
    Citation: Feng Chong, Dai Liming, Liu Xiaojian, Zhao Meng, Zhang Can, 2020. Logging Classification and Recognition of Lacustrine Mixed Sedimentary Reservoirs in First and Second Members of Shahejie Formation in Bohai Sea. Earth Science, 45(10): 3677-3692. doi: 10.3799/dqkx.2020.129

    渤海海域沙一二段湖相混积岩储层测井分类与识别

    doi: 10.3799/dqkx.2020.129
    基金项目:

    国家科技重大专项 2016ZX05024-003

    详细信息
      作者简介:

      冯冲(1985-), 男, 高级工程师, 硕士研究生, 主要从事沉积储层与油气勘探与综合评价研究工作.ORCID:0000-0002-1530-685X.E-mail:fengchong@cnooc.com.cn

    • 中图分类号: P631.8

    Logging Classification and Recognition of Lacustrine Mixed Sedimentary Reservoirs in First and Second Members of Shahejie Formation in Bohai Sea

    • 摘要: 渤海海域沙一二段广泛发育混积岩储层,岩石种类复杂多样,识别困难.在大量岩心、壁心、薄片和全岩分析标定基础上,结合生产实践,提出成分-结构二级分类的混积岩测井分类方法并系统总结2个大类6个亚类10余种混积岩储层测井响应特征,采用箱型图法优选混积岩成分和结构敏感曲线并确定其区分界限.研究结果表明成分-结构二级分类方法不但利于岩性测井识别而且对储层品质也具有较好的区分效果;中子和光电吸收截面指数对岩石成分识别敏感性较高,而自然伽马、电阻率以及中子对岩石结构识别敏感性较高;建立的成分-结构二级解释流程可实现湖相混积岩储层岩石成分和结构的识别,具有简单、高效、准确的特点.该方法在实践中取的良好的应用效果,为复杂岩性识别及储层评价分类提供了思路,在渤海海域沙一二段及其他地区相似地质背景下湖相混积岩储层岩性识别中具有较好的应用前景.



    • 图  1  岩石类型及显微照片

      a.Q29-A-5,3 383.32 m, 白云质砂砾岩;b.B29-D-5,2 351.27 m,含生屑表鲕状云质中砂岩;c.Q29-A-5,3 383.17 m,含生屑表鲕状云质砾岩;d.C5-C-3D,3 658.00 m,亮晶粒屑灰岩;e.S36-F-15,2 474.10 m,含陆屑生屑白云岩;f.Q29-A-5,含陆屑生屑表鲕状砂岩;g. B27-B-1,3 775.00 m,云质中-细粒岩屑长石砂岩;h. Q29-A-5,3 395.00 m白云质表鲕状砾岩;i.C5-C-3D,3 658.00 m,亮晶粒屑灰岩,泥晶白云石包壳包裹陆屑,粒间方解石胶结;j. B27-B-1,3 779.00 m,灰质粗粒岩屑长石砂岩; k. Q29-A-4,3 564.50 m,含灰质角砾岩

      Fig.  1.  Rock types and micrographs

      图  2  混积岩储层孔隙度(a)和渗透率特征(b)

      Fig.  2.  Porosity (a) and permeability (b) characteristics of mixed sedimentary reservoirs

      图  3  碳酸盐组分以白云石为主的混积岩储层及测井响应特征

      Fig.  3.  Mixed sedimentary reservoir with dolomite as dominant carbonate component and log response characteristics

      图  4  碳酸盐组分以方解石为主的混积岩储层及测井响应特征

      Fig.  4.  Mixed sedimentary reservoirs with calcite as dominant carbonate component and log response characteristics

      图  5  自然伽马成分分类箱型图(a)和结构分类箱型图(b)

      Fig.  5.  Natural gamma component classification box diagram(a) and structure classification box diagram(b)

      图  6  混积岩成分分类中子-密度交会图(a)、结构分类中子-密度交会图(b)、成分分类中子箱型图(c)和成分分类密度值箱型图(d)

      Fig.  6.  Mixed sedimentary rock of neutron-density crossplot for component classification (a), neutron-density crossplot for structure classification (b), component classification box diagram using CNCF (c) and component classification box diagram using ZDEN (d)

      图  7  电阻率对成分-结构指示作用箱型图

      Fig.  7.  Box diagrams of resistivity to component-structure indication

      图  8  光电吸收截面指数对成分-结构指示作用箱型图

      Fig.  8.  Photoelectric absorption cross section index for component-structure indicator box diagrams

      图  9  声波对成分-结构指示作用箱型图

      Fig.  9.  Component-structure indicator box diagrams of acoustic wave

      图  10  成分-结构二级分类流程图

      Fig.  10.  Component-structure secondary classification flow chart

      图  11  富钙质碎屑岩储层岩性测井识别:以P14-X-1井为例

      Fig.  11.  Lithologic logging identification of calcareous clastic rock reservoir:taking well PL14-X-1 as an example

      图  12  湖相碳酸盐岩储层测井岩性识别:以Q36-X-2井为例

      Fig.  12.  Log lithology identification of lacustrine carbonate reservoir:taking well Q36-X-2 as an example

      表  1  研究区混积岩测井地质学分类

      Table  1.   Logging geology classification of mixed sedimentary rocks in the research area

      岩石成分 岩石结构
      粒屑结构
      (碳酸盐岩)
      砂状结构
      (砂岩)
      砂砾状结构
      (砂砾岩)
      泥状结构
      (泥岩)
      云质 粒屑云岩(Ⅰ) 云质砂岩(Ⅲ) 云质砂砾岩(Ⅱ) 云质泥岩
      灰质 粒屑灰岩(Ⅵ) 灰质砂岩(Ⅴ) 灰质砂砾岩(Ⅳ) 灰质泥岩
      泥质 泥质砂岩 泥质砂砾岩 泥岩
      下载: 导出CSV

      表  2  渤海海域沙一二段混积岩储层测井响应特征

      Table  2.   Logging response characteristics of the mixed sedimentary reservoirs of E2s1-2 in Bohai Sea area

      岩性 自然伽马 深浅电阻率组合特征 中子与密度组合特征 代表井
      粒屑云岩 较低且齿状特征不明显 正差异较大 同向向左 Q36-D-2、J20-E-5
      云质砂岩 齿状特征明显,呈钟型或箱型 正差异中等 绞合状 B27-B-1、B27-B-2
      云质砂砾岩 相对较高 正差异较小 绞合状 Q29-A-5、B36-W-2
      粒屑灰岩 较低且呈平滑箱状特征 重合 同向向右 C5-C-3D、Q36-D-2
      灰质砂岩 较低且齿状特征明显 重合到较大 绞合状 P14-X-1、B27-B-1
      灰质砂砾岩 相对较高 重合 小的负差异 Q29-A-4
      下载: 导出CSV

      表  3  常规测井原理、影响因素及其在混积岩成分和结构的指示意义

      Table  3.   Principle of conventional logging, influencing factors and their indication significance in the composition and structure of mixed sedimentary reservoir

      测井曲线 响应机理 影响因素 结构指示意义 成分指示意义
      自然伽马 U、Th、K含量 粒度、碱性长石与沉积环境 泥状与砂砾状结构高
      粒屑与砂状结构低
      泥质高,云质和灰质低
      密度 康普顿效应 矿物类型与孔隙 灰质高,泥质中,云质低
      中子 弹性散射 矿物类型与含氢流体 粒屑云岩同向向左
      粒屑灰岩同向向右
      云质高,泥质中,灰质低
      电阻率 电导率 流体类型与岩石结构 泥状和砂砾状结构低
      粒屑和砂状结构高
      光电吸收截面指数 光电效应 矿物类型 泥质低、灰质中,云质高
      声波时差 纵波传播速度 骨架密度与孔隙度 灰质低、泥质中、云质高
      下载: 导出CSV
    • Dong, G.Y., Chen, H.D., He, Y.B., et al., 2007a. Some Problems on the Study of the Mixed Siliciclastic-Carbonate Sediments. Advances in Earth Science, 22(9): 931-939(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqkxjz200709007
      Dong, G.Y., He, Y.B., Chen, H.D., et al., 2007b. Mixed Sedimentation of Carbonates of Lagoonal Facies and Terrigenous Clastics of the Middle Submember of Member 1 of Shahejie Formation in Huimin Sag: Taking Shanghe Area in Shandong Province for an Example. Acta Sedimentologica Sinica, 25(3): 343-350(in Chinese with English abstract).
      Feng, J.L., Hu, K., Cao, J., et al., 2011. A Review on Mixed Rocks of Terrigenous Clastics and Carbonates and Their Petroleum-Gas Geological Significance. Geological Journal of China Universities, 17(2): 297-307(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gxdzxb201102015
      Han, J.B., Tian, X.P., Kang, K., et al., 2018.Mixed Sedimentation Characteristics and Evolution of Lower Member 3 of the Shahejie Formation in the KL Oilfield. Journal of Southwest Petroleum University (Science & Technology Edition), 40(5): 37-46 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=xnsyxyxb201805004
      Kou, Y., Shi, Y.M., Li, B.R., et al., 2010. The Complex Lithology Rock-Electricity Features of Volcanic Rocks in Kelameili Gas Field. Acta Petrologica Sinica, 26(1): 291-301(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=ysxb98201001031
      Li, N., Tao, H.G., Liu, C.P., 2009. Theory, Method and Application of Logging Interpretation for Acidic Volcanic Rocks. Petroleum Industry Press, Beijing (in Chinese).
      Liu, S.L., Wang, Q.F., Gong, Y.J., et al., 2012. Paleogene Microfossil Assemblages from the Bohai Area and Their Importance for the Oil and Gas Exploration. Journal of Stratigraphy, 36(4): 700-709(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DCXZ201204004.htm
      Liu, Z.G., Zhou, X.H., Li, J.P., et al., 2011. Reservoir Characteristics and Controlling Factors of the Paleogene Sha-2 Member in 36-3 Structure, Eastern Shijiutuo Uplift, Bohai Sea. Oil & Gas Geology, 32(6): 832-838(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syytrqdz201106004
      Mount, J.F., 1984. Mixing of Siliciclastic and Carbonate Sediments in Shallow Shelf Environments. Geology, 12(7): 432. https://doi.org/10.1130/0091-7613(1984)12432:mosacs>2.0.co;2 doi: 10.1130/0091-7613(1984)12<432:MOSACS>2.0.CO;2
      Mount, J., 1985. Mixed Siliciclastic and Carbonate Sediments: A Proposed First-Order Textural and Compositional Classification. Sedimentology, 32(3): 435-442. https://doi.org/10.1111/j.1365-3091.1985.tb00522.x
      Niu, Y.X., Pan, H.P., Wang, W.X., et al., 2004. Geophysical Well Logging in Main Hole (0-2 000 m) of Chinese Continental Scientific Drilling. Acta Petrologica Sinica, 20(1): 165-178(in Chinese with English abstract). http://www.researchgate.net/publication/287614217_Geophysical_well_logging_in_main_hole_0_2000m_of_Chinese_Continental_Scientific_Drilling
      Peng, X.Q., Wu, F., Zhang, Y.H., 2012. Reservoir Logging Evaluation of Hybrid Sedimentary Rocks in Xiaoliangshan, Qaidam Basin. Oil Geophysical Prospecting, 47(A01): 136-139, 151(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK201206320531
      Sima, L.Q., Yang, Y., Wu, F., et al., 2014. Lithology Identification on Mixing Deposit with Logging Data in Northwest Xiaoliangshan of Qaidam Basin. Geological Science and Technology Information, 33(2): 180-185(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzkjqb201402030
      Song, B.R., Hu, Y.J., Bian, S.Z., et al., 2011. Reservoir Characteristics of the Crystal Basement in the Xinglongtai Buried-Hill, Liaohe Depression. Acta Petrolei Sinica, 32(1): 77-82(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syxb201101011
      Song, Z.Q., Chen, Y.F., Du, X.F., et al., 2013. Study on Sedimentary Characteristics and Reservoir of Second Member of Shahejie Formation, a Structural Area, Bohai Sea. Offshore Oil, 33(4): 13-18(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hysy201304003
      Wang, J.Q., Liu, B., Luo, P., et al., 2014. Classification and Genesis of Sinian Mixosedimentite from Northwest Margin of Tarim Basin, China. Journal of Chengdu University of Technology (Science & Technology Edition), 41(3): 339-346(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=cdlgxyxb201403010
      Wang, J.Y., Zhang, L.Q., Zhang, S.Q., et al., 2013. Sedimentary Characteristics and Origin of Lacustrine Mixed Rocks of the Second Member of the Eogene Shahejie Formation in Zhanhua Sag, Jiyang Depression: Taking Luojia-Shaojia Area for an Example. Geological Review, 59(6): 1085-1096(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DZLP201306010.htm
      Wang, Q.B., Liu, L., Niu, C.M., et al., 2018. Impacts of the Freshwater Diagenetic Environment to the Mix-Deposition of Lacustrine Carbonate and Clastic at the Steep Slope of Shijiutuo Uplift, Bohai Bay Basin. Earth Science, 43(Suppl.2): 234-242(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-DQKX2018S2019.htm
      Wang, Q.B., Liu, L., Niu, C.M., et al., 2019.The Geological Evidences and Impacts of Deep Thermal Fluid on Lacustrine Carbonate Reservoir in the Actic Area of the North Part of Bozhong Depression, Bohai Bay Basin. Earth Science, 44(8):2751-2760(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqkx201908019
      Williams, H., Turner, F.J., Gilbert, C.M., 1982. Petrography: An Introduction to the Study of Rocks in Thin Section (2 nd ed.). W.H. Freeman and Company, San Francisco.
      Xie, X.N., Ye, M.S., Xu, C.G., et al., 2018. High Quality Reservoirs Characteristics and Forming Mechanisms of Mixed Siliciclastic-Carbonate Sediments in the Bozhong Sag, Bohai Bay Basin. Earth science, 43(10):3526-3539(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqkx201810015
      Yang, C.Q., Sha, Q.A., 1990.Sedimentary Environment of the Middle Devonian Qujing Formation, Qujing, Yunnan Province: A Kind of Mixing Sedimentation of Terrigenous Clastics and Carbonate. Acta Sedimentologica Sinica, 8(2):59-66 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-CJXB199002008.htm
      Zhang, L., Wang, D.Y., Zhang, X.T., et al., 2019. The Controlling Factors of the High-Quality Mixed Reservoirs in QHD29-2E Structure, Bohai Sea. Acta Sedimentologica Sinica, 37(1): 200-211(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=cjxb201901019
      Zhang, N.S., Ren, X.J., Wei, J.X., et al., 2006. Rock Types of Mixosedimentite Reservoirs and Oil-Gas Distribution in Nanyishan of Qaidam Basin. Acta Petrolei Sinica, 27(1): 42-46(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syxb200601009
      Zhang, X.H., 2000. Classification and Origin of Mixosedimentite. Geological Science and Technology Information, 19(4): 31-34(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzkjqb200004006
      Zhao, C., Li, X.B., Huan, J.L., et al., 2013. Mechanism of Mixied Siliciclastic-Carbonate Sediments and Its Controlling Factors. Geological Review, 59(4): 615-626(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DZLP201304005.htm
      董桂玉, 陈洪德, 何幼斌, 等, 2007a.陆源碎屑与碳酸盐混合沉积研究中的几点思考.地球科学进展, 22(9): 931-939. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqkxjz200709007
      董桂玉, 何幼斌, 陈洪德, 等, 2007b.惠民凹陷沙-中湖相碳酸盐与陆源碎屑混合沉积:以山东商河地区为例.沉积学报, 25(3): 343-350. http://www.cqvip.com/Main/Detail.aspx?id=24912038
      冯进来, 胡凯, 曹剑, 等, 2011.陆源碎屑与碳酸盐混积岩及其油气地质意义.高校地质学报, 17(2): 297-307. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gxdzxb201102015
      韩建斌, 田晓平, 康凯, 等, 2018. KL油田沙三下亚段混合沉积特征及演化.西南石油大学学报(自然科学版), 40(5):37-46. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=xnsyxyxb201805004
      寇彧, 师永民, 李珀任, 等, 2010.克拉美丽气田石炭系火山岩复杂岩性岩电特征.岩石学报, 26(1): 291-301. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=ysxb98201001031
      李宁, 陶宏根, 刘传平, 2009.酸性火山岩测井解释理论方法与应用.北京:石油工业出版社.
      刘士磊, 王启飞, 龚莹杰, 等, 2012.渤海海域古近纪微体化石组合特征及油气勘探意义.地层学杂志, 36(4): 700-709. http://www.cnki.com.cn/Article/CJFDTotal-DCXZ201204004.htm
      刘志刚, 周心怀, 李建平, 等, 2011.渤海海域石臼坨凸起东段36-3构造古近系沙二段储集层特征及控制因素.石油与天然气地质, 32(6): 832-838. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syytrqdz201106004
      牛一雄, 潘和平, 王文先, 等, 2004.中国大陆科学钻探主孔(0~2 000 m)地球物理测井.岩石学报, 20(1): 165-178. http://d.wanfangdata.com.cn/Periodical/ysxb98200401015
      彭晓群, 吴丰, 张延华, 2012.柴达木盆地小梁山地区混积岩储层测井评价.石油地球物理勘探, 47(A01): 136-139, 151. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK201206320531
      司马立强, 杨毅, 吴丰, 等, 2014.柴西北小梁山地区混积岩测井岩性识别.地质科技情报, 33(2): 180-185. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzkjqb201402030
      宋柏荣, 胡英杰, 边少之, 等, 2011.辽河坳陷兴隆台潜山结晶基岩油气储层特征.石油学报, 32(1): 77-82. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syxb201101011
      宋章强, 陈延芳, 杜晓峰, 等, 2013.渤海海域A构造区沙二段混合沉积特征及储层研究.海洋石油, 33(4): 13-18. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hysy201304003
      王杰琼, 刘波, 罗平, 等, 2014.塔里木盆地西北缘震旦系混积岩类型及成因.成都理工大学学报(自然科学版), 41(3): 339-346. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=cdlgxyxb201403010
      王金友, 张立强, 张世奇, 等, 2013.济阳坳陷沾化凹陷沙二段湖相混积岩沉积特征及成因分析:以罗家-邵家地区为例.地质论评, 59(6): 1085-1096. http://www.cqvip.com/QK/91067X/201306/48044059.html
      王清斌, 刘立, 牛成民, 等, 2018.石臼坨凸起陡坡带大气淡水成岩环境对湖相混积岩储层的影响.地球科学, 43(增刊2): 234-242. doi: 10.3799/dqkx.2018.138
      王清斌, 刘立, 牛成民, 等, 2019.渤中凹陷北部陡坡带热液活动及其对湖相碳酸盐岩储层的影响.地球科学, 44(8):2751-2760. doi: 10.3799/dqkx.2018.347
      解习农, 叶茂松, 徐长贵, 等, 2018.渤海湾盆地渤中凹陷混积岩优质储层特征及成因机理.地球科学, 43(10):3526-3539. doi: 10.3799/dqkx.2018.277
      杨朝青, 沙庆安, 1990.云南曲靖中泥盆统曲靖组的沉积环境:一种陆源碎屑与海相碳酸盐的混合沉积.沉积学报, 8(2):59-66. http://www.cqvip.com/QK/95994X/19902/221837.html
      张藜, 王德英, 张新涛, 等, 2019.渤海海域秦皇岛29-2东构造优质混积储层主控因素.沉积学报, 37(1): 200-211. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=cjxb201901019
      张宁生, 任晓娟, 魏金星, 等, 2006.柴达木盆地南翼山混积岩储层岩石类型及其与油气分布的关系.石油学报, 27(1): 42-46. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syxb200601009
      张雄华, 2000.混积岩的分类和成因.地质科技情报, 19(4): 31-34. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzkjqb200004006
      赵灿, 李旭兵, 郇金来, 等, 2013.碳酸盐与硅质碎屑的混合沉积机理和控制因素探讨.地质论评, 59(4): 615-626. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzlp201304003
