Responses of Different Iron and Nitrogen Transformation Functional Microorganisms to Fe(Ⅱ) Chemical Oxidation
-
摘要: 在地下水位波动带、地表水-地下水交互带等氧化还原变化区域，O2会与Fe（II）发生反应产生活性氧，如·OH、·O2-、H2O2等.这些活性氧具有生物毒性，可能对微生物的存活产生影响，而不同的功能微生物对Fe（II）化学氧化产生活性氧的响应可能不同.为了验证这一科学假设，选取了一种Fe（II）氧化菌Pseudogulbenkiania sp.strain 2002（strain 2002）和两种氨氧化细菌Rhodococcus sp.（A1）和Arthrobacter oxydans（A2）作为模式菌种，并与铁还原菌Shewanella oneidensis strain MR-1（MR-1）对比，研究了Fe（II）化学氧化过程中微生物数量、细胞结构的变化，通过淬灭实验探究了活性氧的贡献.结果表明，不同功能微生物对Fe（II）化学氧化的响应截然不同.0.2 mmol/L Fe（II）氧化60 min后，MR-1数量下降了1.61个数量级，A1和A2分别下降了0.74和1.37个数量级，而strain 2002的存活几乎不受Fe（II）氧化的影响.透射电镜观察结果显示，MR-1、A1和A2菌细胞的外膜受到了不同程度的破坏，而strain 2002完好无损.淬灭实验结果表明，溶液中和胞内生成的活性氧是造成功能微生物死亡的原因，但是不同微生物由于对Fe（II）的吸附性能和对活性氧的抵御能力不同，因而对活性氧的响应机制不同.该研究结果对于诠释现代环境氧化还原变化区域微生物群落演化及地球史上氧气大爆发事件的生物地球化学过程具有重要的借鉴意义.Abstract: In redox fluctuation areas such as groundwater level fluctuation zone,surface water-groundwater interaction zone,O2 reacts with Fe(Ⅱ) to produce reactive oxygen species (ROSs),such as ·OH,·O2-,H2O2,etc. These ROSs are of biological toxicity and may have impact on the survival of microorganisms,and different functional microorganisms may respond differently to ROSs produced by Fe(Ⅱ) chemical oxidation. To validate this scientific hypothesis,a Fe (Ⅱ) oxidizing bacteria Pseudogulbenkiania sp. strain 2002 (strain 2002),two ammonia oxidation bacteria Rhodococcus sp. (A1) and Arthrobacter oxydans (A2) were selected as model strains,and contrasted with the iron reducing bacteria Shewanella oneidensis strain MR-1 (MR-1).The numbers of microorganisms,changes of cell structures,and the contribution of ROS were studied. The results show that different functional microorganisms respond differently to Fe(Ⅱ) chemical oxidation. After oxidation of 0.2 mmol/L Fe(Ⅱ) for 60 min,the MR-1 numbers decreased by 1.61 orders of magnitude,A1 and A2 decreased by 0.74 and 1.37 orders of magnitude,respectively,while the survival of strain 2002 was virtually unaffected by Fe (Ⅱ) oxidation. It was observed through transmission electron microscope that the outer membranes of MR-1,A1 and A2 bacteria cells were damaged to varying degrees,while strain 2002 was intact. The results of quenching test show that ROS produced in solution and in the cell caused death of functional microorganisms,but different microorganisms had different response mechanisms to ROS due to their adsorption ability to Fe(Ⅱ) and their resistance to ROS. The results of this study are of great significance for interpreting the microbial community evolution in the redox fluctuation region and the biogeochemical processes in the Great Oxygen Explosion in the history of the earth.
-
图 1 0.2 mmol/L Fe(Ⅱ)化学氧化过程中水溶态Fe(Ⅱ)浓度的变化
Fig. 1. Variations of dissolved Fe(Ⅱ) concentration during 0.2 mmol/L Fe(Ⅱ) oxidation
图 2 0.2 mmol/L Fe(Ⅱ)氧化过程中不同功能微生物的存活数量
Fig. 2. Surviving of different functional microorganisms during 0.2 mmol/L Fe(Ⅱ) oxidation
图 3 好氧条件下Fe(Ⅱ)化学氧处理60 min后的微生物TEM图片
a, b.MR-1；c, d. strain 2002；e, f.A1菌；g, h.A2菌.图a~d为全细胞TEM图片；图e~h为超薄切片的TEM图片
Fig. 3. TEM images of microorganisms under aerobic condition and Fe(Ⅱ) oxidation for 60 min
图 4 好氧条件下Fe(Ⅱ)氧化60 min过程中生成的累积·OH量
Fig. 4. Variations in cumulative ·OH concentrations during 60-min Fe(Ⅱ) oxidation
-
Chen, R., Liu, H., Tong, M., et al., 2018. Impact of Fe(Ⅱ) Oxidation in the Presence of Iron-Reducing Bacteria on Subsequent Fe(Ⅲ) Bio-Reduction. The Science of the Total Environment, 639: 1007-1014. https://doi.org/10.1016/j.scitotenv.2018.05.241 Chen, R., Liu, H., Zhang, P., et al., 2019. Attenuation of Fe (Ⅲ)-Reducing Bacteria during Table Fluctuation of Groundwater Containing Fe2+. Science of the Total Environment, 694: 133660. https://doi.org/10.1016/j.scitotenv.2019.133660 Cornelis, P., Wei, Q., Andrews, S. C., et al., 2011. Iron Homeostasis and Management of Oxidative Stress Response in Bacteria. Metallomics, 3(6): 540-549. https://doi.org/10.1039/c1mt00022e Emerson, D., De Vet, W., 2015. The Role of FeOB in Engineered Water Ecosystems: A Review. Journal American Water Works Association, 107(1): E47-E57. https://doi.org/10.5942/jawwa.2015.107.0004 Grannas, A. M., Martin, C. B., Chin, Y. P., et al., 2006. Hydroxyl Radical Production from Irradiated Arctic Dissolved Organic Matter. Biogeochemistry, 78(1): 51-66. https://doi.org/10.1007/s10533-005-2342-4 He, J.Z., Zhang, L.M., 2009. Advances in Ammonia-Oxidizing Microorganisms and Global Nitrogen Cycle. Acta Ecologica Sinica, 29(1): 406-415(in Chinese with English abstract). http://www.oalib.com/paper/1401250 Heffron, J., McDermid, B., Mayer, B. K., 2019. Bacteriophage Inactivation as a Function of Ferrous Iron Oxidation. Environmental Science: Water Research & Technology, 5(7): 1309-1317. https://doi.org/10.1039/C9EW00190E Hu, M., Li, F.B., 2014. Soil Microbe Mediated Iron Cycling and Its Environmental Implication. Acta Pedologica Sinica, 51(4): 683-698(in Chinese with English abstract). http://d.wanfangdata.com.cn/periodical/trxb201404002 Imlay, J.A., 2003. Pathways of Oxidative Damage. Annual Review of Microbiology, 57(1): 395-418. https://doi.org/10.1146/annurev.micro.57.030502.090938 Joo, S. H., Feitz, A. J., Sedlak, D. L., et al., 2005. Quantification of the Oxidizing Capacity of Nanoparticulate Zero-Valent Iron. Environmental Science & Technology, 39(5): 1263-1268. https://doi.org/10.1021/es048983d Keenan, C. R., Sedlak, D. L., 2008. Factors Affecting the Yield of Oxidants from the Reaction of Nanoparticulate Zero-Valent Iron and Oxygen. Environmental Science & Technology, 42(4): 1262-1267. https://doi.org/10.1021/es7025664 Kim, J. Y., Park, H. J., Lee, C., et al., 2010. Inactivation of Escherichia coli by Nanoparticulate Zerovalent Iron and Ferrous Ion. Applied and Environmental Microbiology, 76(22): 7668-7670. https://doi.org/10.1128/aem.01009-10 Lee, C., Kim, J. Y., Lee, W. I., et al., 2008. Bactericidal Effect of Zero-Valent Iron Nanoparticles on Escherichia coli. Environmental Science & Technology, 42(13): 4927-4933. https://doi.org/10.1021/es800408u Liu, G.F., Zhu, J.Q., Yu, H.L., et al., 2018. Review on Electron-Shuttle-Mediated Microbial Reduction of Iron Oxides Minerals. Earth Science, 43(Suppl. 1): 157-170(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-DQKX2018S1016.htm Lyons, T.W., Reinhard, C.T., Planavsky, N.J., 2014. The Rise of Oxygen in Earth's Early Ocean and Atmosphere. Nature, 506(7488): 307-315. https://doi.org/10.1038/nature13068 Ma, S.C., Tong, M., Yuan, S. H., et al., 2019. Responses of the Microbial Community Structure in Fe(Ⅱ)-Bearing Sediments to Oxygenation: The Role of Reactive Oxygen Species. ACS Earth and Space Chemistry, 3(5): 738-747. https://doi.org/10.1021/acsearthspacechem.8b00189 Melton, E.D., Swanner, E.D., Behrens, S., et al., 2014. The Interplay of Microbially Mediated and Abiotic Reactions in the Biogeochemical Fe Cycle. Nature Reviews Microbiology, 12(12): 797-808. https://doi.org/10.1038/nrmicro3347 Wang, R., Zheng, P., Zhang, M., et al., 2015. Nitrate-Dependent Anaerobic Ferrous/Iron Oxidation Microorganism: Review on Its Species, Distribution and Characteristics. Microbiology, 42(12): 2448-2456(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-WSWT201512018.htm Weber, K.A., Achenbach, L.A., Coates, J.D., 2006. Microorganisms Pumping Iron: Anaerobic Microbial Iron Oxidation and Reduction. Nature Reviews Microbiology, 4(10): 752-764. https://doi.org/10.1038/nrmicro1490 Xie, S.C., Yang, H., Luo, G.M., et al., 2012. Geomicrobial Functional Groups: A Window on the Interaction between Life and Environments. Chinese Science Bulletin, 57(1): 3-22(in Chinese). doi: 10.1360/csb2012-57-1-3 Zhang, P., Yuan, S.H., 2017. Production of Hydroxyl Radicals from Abiotic Oxidation of Pyrite by Oxygen under Circumneutral Conditions in the Presence of Low-Molecular-Weight Organic Acids. Geochimica et Cosmochimica Acta, 218: 153-166. https://doi.org/10.1016/j.gca.2017.08.032 Zhang, X., Chen, T.H., Wang, J., et al., 2018. Influence of Iron Oxides on Methanogenic Process of Organic Matter and Related Mechanism. Earth Science, 43(Suppl. 1): 136-144(in Chinese with English abstract). http://www.zhangqiaokeyan.com/academic-journal-cn_earth-science_thesis/0201272213930.html Zhao, L., 2013. Influence of Elodea Nuttallii-Nitrogen Cycling Bacteria on Nitrogen Cycling of Shallow Eutrophic Taihu Lake, China(Dissertation). Nanjing University, Nanjing(in Chinese with English abstract). Zhao, L.D., Dong, H.L., Kukkadapu, R., et al., 2013. Biological Oxidation of Fe(Ⅱ) in Reduced Nontronite Coupled with Nitrate Reduction by Pseudogulbenkiania sp. Strain 2002. Geochimica et Cosmochimica Acta, 119: 231-247. https://doi.org/10.1016/j.gca.2013.05.033 贺纪正, 张丽梅, 2009. 氨氧化微生物生态学与氮循环研究进展. 生态学报, 29(1): 406-415. doi: 10.3321/j.issn:1000-0933.2009.01.049 胡敏, 李芳柏, 2014. 土壤微生物铁循环及其环境意义. 土壤学报, 51(4): 683-698. https://www.cnki.com.cn/Article/CJFDTOTAL-TRXB201404002.htm 柳广飞, 朱佳琪, 于华莉, 等, 2018. 电子穿梭体介导微生物还原铁氧化物的研究进展. 地球科学, 43(增刊1): 157-170. doi: 10.3799/dqkx.2018.590 王茹, 郑平, 张萌, 等, 2015. 硝酸盐型厌氧铁氧化菌的种类、分布和特性. 微生物学通报, 42(12): 2448-2456. https://www.cnki.com.cn/Article/CJFDTOTAL-WSWT201512018.htm 谢树成, 杨欢, 罗根明, 等, 2012. 地质微生物功能群: 生命与环境相互作用的重要突破口. 科学通报, 57(1): 3-22. https://www.cnki.com.cn/Article/CJFDTOTAL-KXTB201201005.htm 张勋, 陈天虎, 王进, 等, 2018. 铁氧化物对有机质厌氧产甲烷过程的影响及其机制. 地球科学, 43(增刊1): 136-144. doi: 10.3799/dqkx.2018.545 赵琳, 2013. 伊乐藻-氮循环菌共同作用对太湖氮循环的影响(硕士学位论文). 南京: 南京大学. -
