U⁃Pb Age and Lu⁃Hf Isotope of Detrital Zircons, Geochemical Characteristics and Geological Significance for Zhuwo Formation Meta⁃Sedimentary Rocks in Ke'eryin Region, Western Sichuan
-
摘要: 为研究可尔因地区侏倭组的物源体系及其与可尔因地区李家沟伟晶岩之间的成因联系，对出露于西康群侏倭组中的变质沉积岩进行了全岩地球化学、锆石U⁃Pb定年以及Lu⁃Hf同位素分析. 分析结果显示侏倭组变质沉积岩具高SiO2、Al2O3的地球化学特征，稀土元素配分曲线整体右倾，与澳大利亚晚太古宙沉积岩（PAAS）配分一致. 阴极发光图像（CL）显示，碎屑锆石普遍具有岩浆震荡环带，部分受重结晶改造及存在变质增生边. 碎屑锆石的U⁃Pb年龄谱具有313~227 Ma和461~401 Ma两个主峰以及938~774 Ma和2 048~1 928 Ma两个次峰. εHf（t）值在-17.1~+13.3之间，二阶段模式年龄（TDM2）分布在3 240~499 Ma之间. 综合全岩地球化学、锆石U⁃Pb⁃Hf同位素特征及区域地质对比，认为可尔因地区侏倭组变质沉积岩的物源主要为来自大陆岛弧的长英质岩石，并伴有一些再循环沉积物，主要接收了来自东昆仑、北秦岭及扬子陆块的物质. 可尔因地区李家沟伟晶岩为侏倭组变质沉积岩直接部分熔融固结形成.Abstract: In order to decipher the provenance system of the Triassic Zhuwo Formation meta⁃sedimentary rocks and its genetic relationship with Lijiagou pegmatite in Ke'eryin area, LA⁃ICP⁃MS U⁃Pb micro⁃dating, Lu⁃Hf isotope analysis of detrital zircons and whole⁃rock geochemical analysis of meta⁃sedimentary rocks were conducted. Geochemical analysis results show that the meta⁃sedimentary rocks of Zhuwo Formation are characterized by high SiO2 and Al2O3 content. The chondrite⁃normalized REE patterns are characterised by light REE enrichment, which is similar to the Late Archean sedimentary rocks in Australia(PASS). Detrital Zircons show magmatic oscillating zonation, and are partially sorrounded by metamorphic accretionary rims due to recrystallization.U⁃Pb age of detrital zircons yields two main clusters at 313~227 Ma and 461~401 Ma, as well as two minor clusters at 938~774 Ma and 2 048~1 928 Ma. εHf(t) values of detrital zircons varies from -17.1 to +13.3 with two⁃stage Hf model ages(TDM2) of 3 240~499 Ma. Based on the results above, we conclude that the provenance of Zhuwo Formation meta⁃sedimentary rocks in Ke'eryin includes felsicrocks from continental arcsac companied by some recycled materials mainly receiving materials from East Kunlun, North Qinling orogenic belt and Yangtze blocks. Lijiagou pegmatite in Ke'eryin area was formed by direct partial melting of Triassic Zhuwo Formation meta⁃sedimentary rocks.
-
Key words:
- meta-sedimentary rocks of Zhuwo Formation /
- detrital zircon /
- U-Pb age /
- Lu-Hf isotope /
- Ke'eryin area /
- geochemistry
-
图 1 川西可尔因地质简图及采样位置
据Li et al.（2019）；Fei et al.（2020）修改；年龄数据引自Fei et al.（2020）；费光春（未发表）；五角星为本次研究采样点，三角形为前人研究采样点
Fig. 1. The geological sketch of Ke'eryin in western Sichuan
图 2 川西可尔因地区侏倭组变质沉积岩野外及镜下照片
a. 伟晶岩和围岩（T3zw）分界线；b. 侏倭组基岩；c. ZK1703⁃2手标本，深灰色部分为绿泥石黑云母石英角岩，浅灰色为白云母钠长花岗岩；d. PD3650⁃2镜下照片；e. PD3650⁃6镜下照片；f. LW⁃81镜下照片；Qz. 石英；Ms. 白云母；Bt. 黑云母；Ep. 绿帘石；Pl. 斜长石；Aln. 褐帘石；Tur. 电气石
Fig. 2. Field photographs and micrographs of meta⁃sedimentary rocks from Zhuwo Formation in Ke'eryin area, western Sichuan
图 3 川西可尔因地区侏倭组变质沉积岩典型碎屑锆石阴极发光图（实线为U⁃Pb测年位置，虚线为Hf同位素分析位置）
Fig. 3. Cathodicluminescence images of typical detrital zircons of meta⁃sedimentary rocks from Zhuwo Formation in Ke'eryin area, western Sichuan (Solidline is location of in⁃situ zircon U⁃Pb analysis; dotted line is location of in⁃situ zircon Hf analysis)
图 4 川西可尔因地区侏倭组变质沉积岩锆石Age⁃Th/U图（a）和U⁃Pb年龄谐和图（b）
Fig. 4. Zircon age⁃Th/U image (a) and U⁃Pb age concordia diagram (b) of meta⁃sedimentary rocks from Zhuwo Formationin Ke'eryin area, western Sichuan
图 5 川西松潘甘孜造山带三叠系复理石沉积及区内部分地层碎屑锆石U⁃Pb年龄频率图
松潘甘孜造山带三叠系沉积物数据刘飞等（2006）；Weislogel et al.（2006）；Enkelmann et al.（2007）；王伟等（2007）；秦宇龙等（2020）；甲基卡地区侏倭组数据秦宇龙等（2020）
Fig. 5. Detrital zircon U⁃Pb age histograms of Triassic sediments and some strata in SGFB, western Sichuan
图 6 川西可尔因地区侏倭组变质沉积岩碎屑锆石U⁃Pb年龄⁃εHf(t)图（a）、TDM2频率直方图（b）
Fig. 6. U⁃Pb age versus εHf(t) value plot (a) and TDM2 histogram (b) of detrital zircons from Zhuwo Formation meta⁃sedimentary rocks in Ke'eryin area, western Sichuan
图 7 川西可尔因地区侏倭组变质沉积岩及松潘甘孜三叠系沉积物稀土配分模式图（a）及微量元素蛛网图（b）
PASS⁃澳大利亚后太古宙沉积岩平均值, 据Mclennan（1989）；松潘甘孜三叠系沉积物数据据于远山等（2018）；Gong et al., （2021）; 标准化数值据Sun and McDonough（1989）
Fig. 7. Chondrite⁃normalized REE patterns (a) and primitive mantle⁃normalized trace element spider diagrams (b)
图 8 川西可尔因地区侏倭组变质沉积岩西蒙南（a）和∑REE⁃La/Yb（b）原岩恢复图解
Fig. 8. Simonen(a) and ∑REE⁃La/Yb plot(b) of sedimentary rocks from Zhuwo Formation in Ke'eryin area, western Sichuan
图 9 川西松潘甘孜三叠系西康群沉积岩物源属性判别图解
据Floyd and Leveridge（1987）；Gu et al.（2002）；松潘甘孜造山带三叠系沉积物数据白宪洲等（2010）；于远山等（2018）
Fig. 9. Discrimination diagram of provenance from Triassic Xikang Group in SGFB, western Sichuan
图 10 川西松潘甘孜造山带三叠系西康群沉积岩La⁃Th⁃Sc（a）、Th⁃Sc⁃Zr/10（b）物源区构造环境判别图
据Bhatia and Crook(1986); 松潘甘孜造山带三叠系复理石沉积数据曾宜君等（2006）；白宪洲等（2010）；于远山等（2018）
Fig. 10. Discriminate La⁃Th⁃Sc diagram(a) and Th⁃Sc⁃Zr/10 diagram(b) of tectonic setting meta⁃sedimentary rocks from Triassic Xikang Group in SGFB, western Sichuan
图 11 松潘甘孜造山带周缘构造单元锆石U⁃Pb年龄分布
b. 据裴磊等（2017）；c~f. 据Shi et al.（2013）
Fig. 11. Histograms of U⁃Pb ages ofzircons in the peripheral tectonic units of the SGFB
图 12 晚三叠世松潘甘孜可尔因地区侏倭组物质来源示意图（据邓飞，2006改）
Fig. 12. Sketch map for provenance of Zhuwo Formation in Ke'eryin area of SongpanGanzi in the Late Triassic(modified after Deng et al., 2006)
图 13 川西可尔因花岗岩（a）及伟晶岩（b）Hf同位素二阶段模式年龄频率直方图
数据来源Fei et al.（2020）
Fig. 13. TDM2 histogram of Hf isotope from granite(a) andpegmatite(b)in Ke'eryin area, western Sichuan
表 1 川西可尔因侏倭组变质沉积岩碎屑锆石LA-ICP-MS U-Pb分析结果（样品PD3650-2）
Table 1. LA⁃ICP⁃MS U⁃Pb analysis results of detrital zircons from Zhuwo Formation meta⁃sedimentary rocks in Ke'eryinaera, western Sichuan(Sample PD3650⁃2)
点位 含量（×10-6） 同位素比值 年龄（Ma） Pb Th U Th/U 207Pb/206Pb 1σ 207Pb/235U 1σ 206Pb/238U 1σ 207Pb/206Pb 1σ 207Pb/235U 1σ 206Pb/238U 1σ 1 184 522 706 0.739 0 0.057 8 0.001 2 0.513 6 0.012 5 0.064 6 0.001 5 523 45 421 8 403 9 2 18 28 75 0.376 7 0.062 9 0.002 1 0.531 0 0.018 6 0.061 4 0.001 5 704 68 433 12 384 9 3 86 230 309 0.746 2 0.053 8 0.001 2 0.484 6 0.012 1 0.065 5 0.001 6 362 48 401 8 409 9 4 100 98 135 0.724 3 0.079 6 0.001 7 2.029 1 0.051 0 0.185 2 0.004 4 1 188 42 1 125 17 1 095 24 5 106 454 613 0.740 0 0.055 8 0.001 3 0.335 3 0.009 0 0.043 7 0.001 0 443 52 294 7 276 6 6 64 122 226 0.540 7 0.056 4 0.001 2 0.552 3 0.014 0 0.071 2 0.001 7 468 48 447 9 443 10 7 38 66 139 0.477 2 0.055 2 0.001 3 0.501 4 0.013 5 0.066 0 0.001 6 420 52 413 9 412 9 8 65 250 395 0.6316 0.051 1 0.001 2 0.287 0 0.007 4 0.040 8 0.001 0 245 51 256 6 258 6 9 37 121 172 0.702 0 0.053 1 0.001 3 0.375 8 0.010 5 0.051 4 0.001 2 334 56 324 8 323 7 10 27 136 164 0.829 5 0.052 9 0.001 5 0.309 3 0.009 6 0.042 5 0.001 0 325 64 274 7 268 6 11 80 2 354 0.005 4 0.054 1 0.001 2 0.401 2 0.010 4 0.053 8 0.001 3 377 51 343 8 338 8 12 24 18 36 0.482 9 0.077 4 0.003 4 2.024 3 0.089 6 0.190 1 0.004 8 1 131 84 1 124 30 1 122 26 13 549 217 318 0.681 9 0.164 2 0.003 4 9.591 4 0.229 3 0.424 3 0.009 9 2 500 34 2 396 22 2 280 45 14 174 448 675 0.664 2 0.055 4 0.001 2 0.494 7 0.012 2 0.064 8 0.001 5 429 47 408 8 405 9 15 119 373 794 0.469 4 0.050 9 0.001 2 0.267 9 0.006 9 0.038 3 0.000 9 235 52 241 6 242 6 16 145 74 115 0.639 5 0.125 5 0.002 6 5.380 9 0.129 3 0.311 5 0.007 3 2 036 36 1 882 21 1 748 36 17 7 31 45 0.694 3 0.057 9 0.006 5 0.332 6 0.036 8 0.041 7 0.001 2 527 227 292 28 263 8 18 261 58 410 0.142 3 0.073 8 0.001 5 1.540 7 0.037 0 0.151 7 0.003 5 1 035 41 947 15 911 20 19 98 309 639 0.483 9 0.052 5 0.001 2 0.273 4 0.006 9 0.037 8 0.000 9 306 50 245 6 239 5 20 95 43 372 0.116 2 0.056 4 0.001 2 0.505 4 0.012 6 0.065 0 0.001 5 469 48 415 9 406 9 21 24 101 122 0.829 1 0.053 9 0.001 5 0.365 5 0.010 7 0.049 2 0.001 2 367 59 316 8 310 7 22 43 282 195 1.443 8 0.054 1 0.001 3 0.408 9 0.010 6 0.054 9 0.001 3 376 51 348 8 344 8 23 83 93 166 0.560 7 0.067 2 0.001 6 1.207 4 0.032 2 0.130 5 0.003 0 844 49 804 15 790 17 24 168 516 1144 0.450 7 0.054 3 0.001 2 0.278 6 0.006 7 0.037 3 0.000 9 381 47 250 5 236 5 25 32 135 205 0.659 5 0.052 8 0.001 3 0.288 3 0.007 8 0.039 6 0.000 9 320 55 257 6 251 6 26 57 426 385 1.105 6 0.053 3 0.001 2 0.270 3 0.006 9 0.036 8 0.000 9 341 51 243 6 233 5 27 106 387 432 0.896 6 0.054 8 0.001 2 0.453 1 0.011 1 0.060 0 0.001 4 405 47 380 8 376 8 28 116 92 192 0.478 9 0.068 5 0.001 5 1.390 2 0.033 6 0.147 4 0.003 4 883 43 885 14 886 19 29 302 124 236 0.525 3 0.119 3 0.002 5 5.227 9 0.124 1 0.318 2 0.007 3 1 946 37 1 857 20 1 781 36 30 66 71 245 0.289 0 0.055 2 0.001 3 0.503 6 0.013 0 0.066 2 0.001 5 420 50 414 9 413 9 31 171 213 339 0.628 9 0.070 3 0.001 5 1.236 0 0.029 7 0.127 6 0.002 9 938 43 817 13 774 17 32 12 71 71 1.001 7 0.052 3 0.001 9 0.300 3 0.011 2 0.041 7 0.001 0 298 80 267 9 263 6 33 40 129 266 0.486 6 0.051 2 0.001 3 0.268 7 0.007 5 0.038 1 0.000 9 250 58 242 6 241 5 34 27 143 166 0.858 6 0.053 1 0.001 3 0.299 6 0.008 1 0.040 9 0.000 9 334 55 266 6 259 6 35 137 365 912 0.400 0 0.051 7 0.001 1 0.270 7 0.006 6 0.038 0 0.000 9 270 49 243 5 241 5 36 35 106 168 0.631 3 0.052 7 0.001 5 0.346 4 0.010 3 0.047 7 0.001 1 317 62 302 8 300 7 37 74 610 391 1.559 2 0.054 7 0.001 3 0.363 9 0.009 2 0.048 3 0.001 1 399 50 315 7 304 7 38 44 83 155 0.534 0 0.055 7 0.001 7 0.560 5 0.018 0 0.073 0 0.001 7 440 66 452 12 454 10 39 40 21 36 0.581 9 0.098 3 0.002 2 3.674 3 0.091 4 0.271 2 0.006 2 1 592 41 1 566 20 1 547 31 40 47 7 242 0.029 8 0.056 9 0.001 5 0.419 3 0.012 0 0.053 5 0.001 2 485 58 356 9 336 8 41 118 386 464 0.832 1 0.056 8 0.001 3 0.505 6 0.012 6 0.064 6 0.001 5 482 49 416 8 404 9 42 50 150 190 0.792 8 0.056 8 0.001 3 0.524 9 0.013 5 0.067 1 0.001 5 483 51 428 9 418 9 43 40 173 206 0.839 5 0.075 4 0.002 0 0.516 8 0.014 7 0.049 7 0.001 1 1 080 52 423 10 313 7 44 36 98 240 0.407 6 0.055 1 0.001 6 0.275 3 0.008 3 0.036 2 0.000 8 417 61 247 7 229 5 45 158 473 788 0.600 0 0.050 4 0.001 1 0.345 3 0.008 2 0.049 7 0.001 1 213 49 301 6 313 7 46 28 47 20 2.364 1 0.126 4 0.003 0 6.442 7 0.166 7 0.369 9 0.008 5 2 048 41 2 038 23 2 029 40 47 72 129 415 0.310 4 0.056 9 0.001 3 0.334 5 0.008 4 0.042 7 0.001 0 485 50 293 6 269 6 48 168 196 609 0.321 3 0.056 1 0.001 3 0.535 9 0.013 2 0.069 4 0.001 6 454 49 436 9 432 9 49 49 212 323 0.657 0 0.053 3 0.001 3 0.283 3 0.007 4 0.038 6 0.000 9 342 53 253 6 244 5 50 99 43 178 0.239 3 0.071 3 0.001 6 1.394 5 0.034 1 0.141 9 0.003 2 966 45 887 14 855 18 51 196 55 152 0.364 5 0.118 1 0.002 5 5.185 0 0.121 8 0.318 5 0.007 1 1 928 37 1 850 20 1 782 35 52 474 141 269 0.526 3 0.167 4 0.003 6 10.86 8 0.256 3 0.470 9 0.010 6 2 532 35 2 512 22 2 488 46 53 44 198 315 0.629 0 0.050 6 0.001 4 0.249 5 0.007 4 0.035 8 0.000 8 222 63 226 6 227 5 54 78 290 518 0.559 1 0.054 7 0.001 2 0.280 5 0.006 9 0.037 2 0.000 8 399 49 251 5 236 5 55 74 398 506 0.785 7 0.050 4 0.001 1 0.258 8 0.006 4 0.037 3 0.000 8 213 51 234 5 236 5 56 535 131 402 0.325 5 0.124 6 0.002 6 6.057 0 0.141 1 0.352 7 0.007 9 2 023 37 1 984 20 1 947 38 57 123 67 128 0.526 6 0.114 1 0.002 5 3.798 4 0.090 0 0.241 4 0.005 4 1 866 38 1 592 19 1 394 28 58 107 411 606 0.678 2 0.053 5 0.001 2 0.333 7 0.008 2 0.045 2 0.001 0 351 50 292 6 285 6 59 61 71 224 0.317 7 0.058 1 0.001 4 0.515 0 0.013 4 0.064 3 0.001 4 534 52 422 9 402 9 60 44 38 32 1.195 3 0.125 9 0.002 8 6.188 4 0.151 4 0.356 6 0.008 0 2 041 39 2 003 21 1 966 38 61 282 471 1022 0.460 4 0.055 4 0.001 2 0.566 1 0.013 6 0.074 1 0.001 7 428 48 456 9 461 10 62 91 518 619 0.836 6 0.055 1 0.001 2 0.283 2 0.006 9 0.037 3 0.000 8 415 48 253 5 236 5 63 215 300 243 1.232 3 0.088 8 0.001 9 2.662 6 0.062 4 0.217 5 0.004 8 1 399 40 1 318 17 1 269 26 64 361 517 1369 0.377 5 0.056 6 0.001 2 0.504 8 0.011 9 0.064 7 0.001 4 476 47 415 8 404 9 65 799 277 552 0.5007 0.179 5 0.003 8 9.012 8 0.207 8 0.364 2 0.008 1 2 648 34 2 339 21 2 002 38 66 208 329 839 0.391 7 0.057 7 0.001 2 0.510 0 0.012 0 0.064 2 0.001 4 516 47 418 8 401 9 67 199 899 1344 0.668 8 0.051 6 0.001 1 0.273 0 0.006 4 0.038 4 0.000 9 267 49 245 5 243 5 68 40 258 178 1.446 7 0.054 4 0.001 3 0.432 3 0.011 4 0.057 7 0.001 3 387 54 365 8 361 8 69 92 253 365 0.695 2 0.054 5 0.001 2 0.484 0 0.011 7 0.064 4 0.001 4 391 49 401 8 403 9 70 231 90 182 0.494 4 0.119 7 0.002 5 5.376 7 0.124 3 0.325 7 0.007 2 1 952 37 1 881 20 1 817 35 71 30 51 109 0.468 0 0.055 0 0.002 0 0.506 2 0.018 6 0.066 7 0.001 5 414 78 416 13 416 9 72 105 222 406 0.545 6 0.056 1 0.001 3 0.508 8 0.012 5 0.065 8 0.001 4 454 50 418 8 411 9 73 249 612 1510 0.405 6 0.055 7 0.001 2 0.320 2 0.007 5 0.041 7 0.000 9 442 47 282 6 263 6 74 86 270 617 0.437 7 0.057 3 0.001 3 0.281 9 0.006 8 0.035 7 0.000 8 503 49 252 5 226 5 75 120 162 475 0.341 1 0.055 7 0.001 2 0.507 5 0.012 1 0.066 1 0.001 5 440 48 417 8 413 9 76 172 182 549 0.331 3 0.057 8 0.001 3 0.673 3 0.016 4 0.084 5 0.001 9 523 49 523 10 523 11 77 23 21 71 0.289 3 0.057 1 0.002 0 0.629 5 0.022 0 0.079 9 0.001 8 496 74 496 14 496 11 78 97 135 366 0.368 0 0.056 6 0.001 3 0.536 4 0.013 1 0.068 7 0.001 5 476 50 436 9 428 9 79 70 89 250 0.356 6 0.056 9 0.001 4 0.553 5 0.014 0 0.070 5 0.001 5 489 52 447 9 439 9 80 159 311 556 0.559 9 0.056 2 0.001 3 0.570 9 0.014 0 0.073 6 0.001 6 461 50 459 9 458 10 81 127 471 767 0.614 4 0.056 2 0.001 2 0.307 0 0.007 3 0.039 6 0.000 9 459 48 272 6 251 5 82 46 162 245 0.663 4 0.055 0 0.001 3 0.340 9 0.008 6 0.045 0 0.001 0 412 51 298 7 284 6 83 308 112 549 0.204 4 0.077 3 0.001 6 1.532 3 0.035 2 0.143 7 0.003 1 1 130 42 943 14 866 18 84 142 254 508 0.500 9 0.057 1 0.001 4 0.531 9 0.013 3 0.067 6 0.001 5 495 52 433 9 422 9 85 233 999 1302 0.767 8 0.055 8 0.001 2 0.352 9 0.008 1 0.045 8 0.001 0 446 47 307 6 289 6 86 50 305 303 1.007 0 0.057 3 0.001 3 0.326 5 0.008 0 0.041 4 0.000 9 501 51 287 6 261 6 87 112 106 91 1.162 0 0.119 7 0.002 6 5.296 7 0.124 7 0.321 0 0.007 0 1 951 39 1 868 20 1 795 34 88 40 300 256 1.172 8 0.052 9 0.001 4 0.283 5 0.007 7 0.038 8 0.000 8 326 58 253 6 246 5 89 48 184 233 0.791 9 0.056 5 0.001 4 0.422 8 0.010 7 0.054 3 0.001 2 469 53 358 8 341 7 90 1261 97 1140 0.084 7 0.100 6 0.002 1 3.826 2 0.086 7 0.275 9 0.005 9 1 635 39 1 598 18 1 571 30 91 79 314 504 0.623 2 0.054 7 0.001 2 0.304 0 0.007 2 0.040 3 0.000 9 400 49 270 6 255 5 92 774 317 419 0.756 7 0.174 8 0.003 7 11.246 0 0.254 1 0.466 7 0.010 0 2 604 35 2 544 21 2 469 44 93 152 281 592 0.475 1 0.058 3 0.001 3 0.534 1 0.012 3 0.066 4 0.001 4 541 47 435 8 415 9 94 79 293 357 0.820 7 0.056 2 0.001 3 0.442 2 0.010 4 0.057 1 0.001 2 460 49 372 7 358 7 95 47 170 305 0.557 0 0.055 3 0.001 3 0.293 9 0.007 2 0.038 5 0.000 8 425 50 262 6 244 5 96 58 198 361 0.547 6 0.052 0 0.001 2 0.292 4 0.007 1 0.040 8 0.000 9 284 52 261 6 258 5 97 468 20 1210 0.016 9 0.062 1 0.001 4 0.893 0 0.020 7 0.104 2 0.002 2 679 46 648 11 639 13 98 142 33 255 0.131 1 0.072 9 0.001 6 1.417 6 0.032 7 0.141 0 0.003 0 1012 43 896 14 850 17 99 595 130 300 0.433 8 0.199 5 0.004 2 13.69 1 0.308 7 0.497 8 0.010 6 2 822 34 2 729 21 26 04 46 100 162 59 264 0.222 1 0.073 5 0.001 6 1.587 3 0.036 4 0.156 7 0.003 3 1027 43 965 14 938 19
下载: 导出CSV
表 2 川西可尔因侏倭组变质沉积岩碎屑锆石LA-ICP-MS Lu-Hf同位素测试结果
Table 2. LA⁃ICP⁃MS Lu⁃Hf isotopic test results of detrital zircons from Zhuwo Formation meta⁃sedimentary rocks in Ke'eryin area, western Sichuan
点
位年龄(Ma) 176Yb/177Hf 176Lu/177Hf 176Hf/177Hf 2σ (176Hf/177Hf)i εHf() εHf(t) TDM1（Ma） TDM2(Ma) fLu/Hf 3 409 0.036 7 0.001 3 0.282 749 0.000 021 0.282 739 -0.8 7.8 718 899 -0.96 5 276 0.029 4 0.001 2 0.282 509 0.000 020 0.282 503 -9.3 -3.5 1 055 1 515 -0.96 6 443 0.054 4 0.002 1 0.282 740 0.000 015 0.282 722 -1.1 8.0 747 915 -0.94 7 412 0.011 0 0.000 4 0.282 279 0.000 016 0.282 275 -17.5 -8.5 1 352 1 937 -0.99 8 258 0.048 5 0.001 7 0.282 654 0.000 014 0.282 646 -4.2 1.2 862 1 205 -0.95 11 338 0.003 4 0.000 1 0.282 418 0.000 016 0.282 417 -12.5 -5.1 1 151 1 668 -1.00 15 242 0.039 2 0.001 4 0.282 509 0.000 016 0.282 502 -9.3 -4.2 1 063 1 538 -0.96 16 2036 0.017 6 0.000 6 0.281 624 0.000 029 0.281 602 -40.6 4.1 2 253 2 387 -0.98 18 911 0.042 9 0.001 4 0.282 091 0.000 020 0.282 067 -24.1 -4.8 1 650 2 081 -0.96 19 239 0.049 7 0.001 6 0.282 720 0.000 021 0.282 712 -1.9 3.2 766 1 067 -0.95 23 790 0.022 2 0.000 7 0.282 217 0.000 013 0.282 207 -19.6 -2.5 1 447 1 848 -0.98 25 251 0.034 1 0.001 2 0.282 659 0.000 012 0.282 653 -4.0 1.3 844 1 193 -0.96 28 886 0.042 9 0.001 4 0.282 257 0.000 018 0.282 233 -18.2 0.5 1 419 1 728 -0.96 29 1946 0.032 2 0.001 1 0.281 687 0.000 015 0.281 645 -38.4 3.6 2 200 2 350 -0.97 31 774 0.016 9 0.000 5 0.281 979 0.000 016 0.281 971 -28.0 -11.3 1 768 2 382 -0.98 32 263 0.022 2 0.000 7 0.282 417 0.000 014 0.282 413 -12.6 -6.9 1 171 1 724 -0.98 33 241 0.013 3 0.000 5 0.282 488 0.000 015 0.282 485 -10.1 -4.8 1 066 1 577 -0.98 34 259 0.033 5 0.001 1 0.282 670 0.000 015 0.282 664 -3.6 1.9 827 1 164 -0.97 35 241 0.035 5 0.001 4 0.282 512 0.000 015 0.282 505 -9.2 -4.1 1 058 1 533 -0.96 38 454 0.028 8 0.000 9 0.282 603 0.000 018 0.282 595 -6.0 3.7 917 1 195 -0.97 40 336 0.014 9 0.000 6 0.282 605 0.000 021 0.282 602 -5.9 1.4 905 1 255 -0.98 42 418 0.015 5 0.000 5 0.282 542 0.000 020 0.282 537 -8.1 0.9 992 1 347 -0.98 44 229 0.040 7 0.001 5 0.282 904 0.000 015 0.282 897 4.7 9.5 500 656 -0.95 46 2048 0.015 0 0.000 5 0.281 310 0.000 016 0.281 289 -51.7 -6.7 2 675 3 062 -0.98 48 432 0.045 0 0.001 5 0.282 556 0.000 014 0.282 544 -7.6 1.5 996 1 323 -0.96 49 244 0.028 0 0.001 0 0.282 727 0.000 016 0.282 722 -1.6 3.6 744 1 043 -0.97 50 855 0.035 0 0.001 2 0.282 239 0.000 016 0.282 220 -18.9 -0.6 1 435 1 777 -0.96 51 1928 0.045 1 0.001 5 0.281 571 0.000 029 0.281 516 -42.5 -1.4 2 382 2 643 -0.95 53 227 0.030 7 0.001 1 0.282 891 0.000 020 0.282 887 4.2 9.0 512 682 -0.97 60 2 041 0.013 5 0.000 4 0.281 227 0.000 021 0.281 209 -54.7 -9.7 2 780 3 240 -0.99 62 236 0.031 2 0.001 1 0.282 521 0.000 013 0.282 516 -8.9 -3.9 1 037 1 511 -0.97 64 404 0.012 1 0.000 5 0.282 466 0.000 012 0.282 462 -10.8 -2.1 1 097 1 526 -0.98 67 243 0.045 8 0.001 7 0.282 511 0.000 018 0.282 503 -9.2 -4.2 1 067 1 536 -0.95 70 1 952 0.040 8 0.001 3 0.281 676 0.000 015 0.281 628 -38.8 3.1 2 225 2 384 -0.96 71 416 0.014 5 0.000 6 0.282 680 0.000 016 0.282 675 -3.2 5.8 801 1 038 -0.98 72 411 0.019 9 0.000 7 0.282 798 0.000 014 0.282 792 0.9 9.8 639 778 -0.98 75 413 0.033 5 0.001 0 0.282 523 0.000 015 0.282 515 -8.8 0.0 1 031 1 400 -0.97 78 428 0.069 1 0.002 2 0.282 472 0.000 015 0.282 455 -10.6 -1.8 1 137 1 525 -0.93 80 458 0.020 2 0.000 8 0.282 498 0.000 015 0.282 492 -9.7 0.2 1 059 1 424 -0.98 82 284 0.048 6 0.001 7 0.282 121 0.000 018 0.282 112 -23.0 -17.1 1 620 2 382 -0.95 83 866 0.107 2 0.003 2 0.282 215 0.000 021 0.282 163 -19.7 -2.4 1 551 1 896 -0.90 87 1 951 0.029 2 0.000 9 0.281 440 0.000 020 0.281 405 -47.1 -4.8 2 526 2 871 -0.97 89 341 0.033 7 0.001 2 0.282 943 0.000 015 0.282 935 6.0 13.3 440 499 -0.97 91 255 0.023 0 0.000 9 0.282 535 0.000 016 0.282 531 -8.4 -2.9 1 011 1 467 -0.97 93 415 0.011 3 0.000 4 0.282 330 0.000 014 0.282 327 -15.6 -6.6 1 280 1 820 -0.99 100 938 0.014 8 0.000 4 0.282 207 0.000 016 0.282 199 -20.0 0.5 1 451 1 770 -0.99
下载: 导出CSV
表 3 四川西部可尔因侏倭组变质沉积岩主量元素（%）及微量元素（×10-6）含量
Table 3. Major(%) and trace(×10-6) elelments data of Zhuwo Formation meta⁃sedimentary rocks in Ke'eryin area, western Sichuan
样品编号 LW-80 LW-81 ZK1703-2 PD3650-2 PD3650-6 SiO2 67.47 70.81 70.24 73.70 72.47 TiO2 0.75 0.62 0.49 0.50 0.60 Al2O3 15.85 14.76 10.69 11.06 13.23 Fe2O3T 6.16 6.47 4.36 5.14 4.09 MnO 0.08 0.08 0.10 0.11 0.05 MgO 2.17 2.40 2.49 1.90 1.60 CaO 0.51 0.60 7.24 2.90 0.86 Na2O 2.18 1.21 0.23 1.53 2.37 K2O 2.74 1.33 1.57 1.58 2.75 P2O5 0.20 0.29 0.12 0.15 0.13 LOI/H2O+ 1.00 0.70 1.94 0.88 1.31 Total 99.11 99.26 99.46 99.46 99.45 DF -2.89 -6.03 -2.99 -3.85 -2.25 ICV 0.92 0.85 1.53 1.23 0.93 Li 1 080 611 822 773 890 B 2 640 2 010 22.6 20.5 230 Rb 655 391 640 173 151 Ba 478 207 220 375 437 Th 11.1 11.1 9.2 9.82 12 U 3.83 3.85 2.56 2.57 2.93 Ta 7.6 10.6 1.07 0.739 1.21 Nb 52.1 35.8 12.6 10.2 11.4 Sr 158 96.3 192 361 159 Zr 180 173 149 170 210 Hf 4.98 5.13 3.84 4.48 5.68 Y 28.4 25.7 22.7 24.9 23.8 La 32.9 27.2 29.6 32.9 36.6 Ce 64 53.7 54.8 67.6 68.4 Pr 7.53 6.57 6.38 8.46 8.36 Nd 29.2 25.7 24.3 32.6 30.3 Sm 6.06 5.57 4.67 6.57 5.74 Eu 1.27 0.982 0.921 1.25 1.24 Gd 5.62 5.15 4.39 5.71 5.08 Tb 0.866 0.805 0.7 0.876 0.781 Dy 5.1 4.81 3.96 4.59 4.38 Ho 0.961 0.907 0.753 0.876 0.812 Er 2.77 2.53 2.23 2.56 2.46 Tm 0.391 0.345 0.316 0.346 0.34 Yb 2.57 2.27 2.08 2.38 2.36 Lu 0.38 0.33 0.32 0.38 0.37 REE 159.62 136.87 135.42 167.09 167.22 δCe 0.96 0.95 0.93 0.97 0.92 δEu 0.65 0.55 0.61 0.61 0.69 （La/Sm）N 3.51 3.15 4.09 3.23 4.12 （La/Yb）N 9.18 8.60 10.21 9.92 11.12 （Sm/Nd）N 0.63 0.66 0.59 0.62 0.58 （Gd/Yb）N 1.81 1.88 1.75 1.98 1.78 LREE/HREE 7.55 6.98 8.18 8.43 9.09
下载: 导出CSV
表 4 川西可尔因地区花岗岩、伟晶岩锆石U-Pb年龄
Table 4. Zircon U-Pb ages of granites and pegmatites in Ke'eryinaera, western Sichuan
编号 岩性 结晶年龄（Ma） > 结晶年龄（Ma） 数量（个） 来源 LM107 白云母花岗岩 217±2.8 339~334 3 Fei et al.(2020) LM131 白云母花岗岩 214.9±1.0 383 1 费光春(未发表) LM122 二云母花岗岩 223.1±1.3 246~239 6 LMH3 二云母花岗岩 219.2±2.3 254~232 4 Fei et al.(2020) 1325 1 LM111 斑状黑云母花岗岩 224.5±2.4 293~245 8 费光春(未发表) T07 黑云母二长花岗岩 217.0±2.8 242~231 7 T03 花岗闪长岩 212.5±2.0 231、238 2 LKH3 钠长石伟晶岩 202.8±4.9 231、890 2 Fei et al. (2020) DB19-08 微斜长石钠长石伟晶岩 210.5±3.4 258~247 5 费光春(未发表) 424~417 6 368、376、836 3
下载: 导出CSV
-
Bai, X.Z., He, M.Y., Wang, Y.T., et al., 2010. Analysis of Geochemical Characteristics, Provenance Area and Paleo WeatheringDegree of Xikang Group in Ruo'ergai Area, Sichuan. Geoscience, 24(1): 151-157 (in Chinese with English abstract). Bhatia, M. R., Crook, K. A. W., 1986. Trace Element Characteristics of Graywackes and Tectonic Setting Discrimination of Sedimentary Basins. Contributions to Mineralogy and Petrology, 92(2): 181-193. https://doi.org/10.1007/bf00375292 Barros, R., Menuge, J. F., 2016. The Origin of Spodumene Pegmatites Associated with the Leinster Granite in Southeast Ireland. The Canadian Mineralogist, 54(4): 847-862. https://doi.org/10.3749/canmin.1600027 Chen, B., Huang, C., Zhao, H., 2020. Lithium and Nd Isotopic Constraints on the Origin of Li-Poor Pegmatite with Implications for Li Mineralization. Chemical Geology, 551(6): 119769. https://doi.org/10.1016/j.chemgeo.2020.119769 Cox, R., Lowe, D. R., Cullers, R. L., 1995. The Influence of Sediment Recycling and Basement Composition on Evolution of Mudrock Chemistry in the Southwestern United States. Geochimica et Cosmochimica Acta, 59(14): 2919-2940. https://doi.org/10.1016/0016-7037(95)00185-9 Chen, Y. L., Li, D. P., Zhou, J., et al., 2009. U-Pb Dating, Geochemistry, and Tectonic Implications of the Songpan-Ganzi Block and the Longmen Shan, China. Geochemical Journal, 43(2): 77-99. https://doi.org/10.2343/geochemj.1.0009 Deng, Y., Fei, G.C., Li, J., et al., 2018. Study on C-H-O Isotopes and Geochronology of the Lijiagou Pegmatite Spodumene Deposit in Sichuan Province. Mineral Petrology, 38(3): 40-47 (in Chinese with English abstract). Dill, H. G., 2018. Geology and Chemistry of Variscan-Type Pegmatite Systems (SE Germany) with Special Reference to Structural and Chemical Pattern Recognition of Felsic Mobile Components in the Crust. Ore Geology Reviews, 92(41-6): 205-239. https://doi.org/10.1016/j.oregeorev.2017.11.016 Ding, L., Yang, D., Cai, F. L., et al., 2013. Provenance Analysis of the Mesozoic Hoh-Xil-Songpan-Ganzi Turbidites in Northern Tibet: Implications for the Tectonic Evolution of the Eastern Paleo-Tethys Ocean. Tectonics, 32(1): 34-48. https://doi.org/10.1002/tect.20013 Enkelmann, E., Weislogel, A., Ratschbacher, L., et al., 2007. How was the Triassic Songpan-Ganzi Basin Filled? a Provenance Study. Tectonics, 26(4): 4007. https://doi.org/10.1029/2006tc002078 Floyd, P.A., Leveridge, B.E., 1987. Tectonic Environment of the Devonian Gramscatho Basin, South Cornwall: Framework Mode and Geochemical Evidence from Turbiditic Sandstones. Jour. Geol. Soc. London, 144(4): 531-542. https://doi.org/10.1144/gsjgs.144.4.0531 Federico, L., Capponi, G., Crispini, L., et al, 2004. Exhumation of Alpine Aigh-Pressure Rocks: Insights from Petrology of Eclogite Clasts in the Tertiary Piedmontese Basin (Ligurian Alps, Italy). Lithos, 74(1-2): 21-40. https://doi.org/10.1016/j.lithos.2003.12.001 Fei, G. C., Menuge, J. F., Chen, C. S., et al., 2021. Evolution of Pegmatite Ore-Forming Fluid: The Lijiagou Spodumene Pegmatites in the Songpan-Garze Fold Belt, Southwestern Sichuan Province, China. Ore Geology Reviews, 139(4): 104441. https://doi.org/10.1016/j.oregeorev.2021.104441 Fei, G. C., Menuge, J. F., Li, Y. Q., et al., 2020. Petrogenesis of the Lijiagou Spodumene Pegmatites in Songpan-Garze Fold Belt, West Sichuan, China: Evidence from Geochemistry, Zircon, Cassiterite and Coltan U-Pb Geochronology and Hf Isotopic Compositions. Lithos, 364-365(3): 105555. https://doi.org/10.1016/j.lithos.2020.105555 Fei, G.C., Yang, Z., Yang, J.Y., et al., 2020. New Precise Timing Constraint for the Dangba Granitic Pegmatite Type Rare-Metal Deposit, Markam, Sichuan Province, Evidence from Cassiterite LA-MC-ICP-MS U-Pb Dating. Acta Geologica Sinica, 94(3): 836-849 (in Chinese with English abstract). Fei, G.C., Yuan, T.J., Tang, W.C., et al., 2014. Classification Analysis of Ore-Bearing Pegmatite in Ke'eryin Orefield, West Sichuan. Mineral Deposit, 33(Suppl. ): 187-188 (in Chinese with English abstract). Feng, R., Kerrich, R., 1990. Geochemistry of Fine-Grained Clastic Sediments in the Archean Abitibi Greenstone Belt, Canada: Implications for Provenance and Tectonic Setting. Geochimica et Cosmochimica Acta, 54(4): 1061-1081. https://doi.org/10.1016/0016-7037(90)90439-r Gu, C.H., 2014. Metallogenic Regularity of Spodumene Deposits in the Closely Spaced Pegmatite Area in the Southeastern Ke'eryin Pegmatite Field, Sichuan Province. Contributions to Geology and Mineral Resources Research, 29(1): 59-65 (in Chinese with English abstract). Guo, Z.F., Deng, J.F., Xu, Z.Q., et al., 1998. Late Palaeozoic-Mesozoic Intracontinental Orogenic Process and Intermediate-Acidic-Igneous Rocks From the Eastern Kunlun Mountains of Northwestern China. Geoscience, 12(3): 344-352 (in Chinese with English abstract). Gu, X. X., Liu, J. M., Zheng, M. H., et al., 2002. Provenance and Tectonic Setting of the Proterozoic Turbidites in Hunan, South China: Geochemical Evidence. Journal of Sedimentary Research, 72(3): 393-407. https://doi.org/10.1306/081601720393 Gong, D. X., Wu, C. H., Zou, H., et al., 2021. Provenance Analysis of Late Triassic Turbidites in the Eastern Songpan-Ganzi Flysch Complex: Sedimentary Record of Tectonic Evolution of the Eastern Paleo-Tethys Ocean. Marine and Petroleum Geology, 126(B8): 104927. https://doi.org/10.1016/j.marpetgeo.2021.104927 Huang, H.Y., He, D.F., Li, Y.Q., et al., 2019. Determination and Formation Mechanism of the Luzhou Paleo-Uplift in the Southeastern Sichuan Basin. Earth Science Frontiers, 26(1): 102-120(in Chinese with English abstract). Hu, J.M., Meng, Q.R., Shi, Y.R., et al., 2005. SHRIMP U-Pb Dating of Zircons from Granitoid Bodies in the Songpan-Ganzi Terrane and Its Implications. Acta Petrologica Sinica, 21(3): 867-880 (in Chinese with English abstract). Jian, X., Weislogel, A., Pullen, A., 2019. Triassic Sedimentary Filling and Closure of the Eastern Paleo‐Tethys Ocean: New Insights from Detrital Zircon Geochronology of Songpan‐Ganzi, Yidun, and West Qinling Flysch in Eastern Tibet. Tectonics, 38(2): 767-787. https://doi.org/10.1029/2018tc005300 Liao, Y.A., Yao, X.L., 1992. Evolution Feature and Minerogenetic Ralations Peraluminous Granites from Jinchuan, Western Sichuan. Mineral Petrology, 12(1): 12-22 (in Chinese with English abstract). Liu, F., Chen, Y.L., Su, B.X., et al., 2006. Geochemistry and Zircon Ages of Triassic Detrital Sedimentary Rocks from the Garze-Songpan Block. Acta Geoscientica Sinica, 27(4): 289-296 (in Chinese with English abstract). Li, J.K., 2006. Mineralizing Mechanism and Continental Geodynamics of Typical Pegmatite Deposits in Western, Sichuan, China(Dissertation). China University of Geosciences, Beijing (in Chinese with English abstract). Li, P., Li, J. K., Chou, I. M., et al., 2019. Mineralization Epochs of Granitic Rare-Metal Pegmatite Deposits in the Songpan-Ganzê Orogenic Belt and their Implications for Orogeny. Minerals, 9(5): 280. https://doi.org/10.3390/min9050280 Li, Z.W., Song, T.H., Wang, Z.J., et al., 2021. Strike Variation Evolution of the Basin-Mountain System in Western Sichuan Longmenshan as Recorded by Deformation Exhumation and Deposition and Discussion on the Period of Key Structural Transformation. Journal of Chengdu University of Technology (Science and Technology Edition), 48(3): 257-282(in Chinese with English abstract). Ludwig, K.R., 2003. ISOPLOT: A Geochronological Toolkit for Microsoft Excel. Berkeley geochronology center special publication, Berkeley. Nance, W. B., Taylor, S. R., 1976. Rare Earth Element Patterns and Crustal Evolution-I. Australian Post-Archean Sedimentary Rocks. Geochimica et Cosmochimica Acta, 40(12): 1539-1551. https://doi.org/10.1016/0016-7037(76)90093-4 Nesbitt, H. W., Young, G. M., 1982. Early Proterozoic Climates and Plate Motions Inferred from Major Element Chemistry of Lutites. Nature, 299(5885): 715-717. https://doi.org/10.1038/299715a0 Mclennan, S.M., 1989. Rare Earth Elements in Sedimentary Rocks: Influence of Provenance and Sedimentary Processes. Reviews in Mineralogy and Geochemistry, 21(1): 169-200. Mu, H.X., 2020. Formation and Evolution of the Late Triassic Foreland Basin in Western Sichuan(Dissertation). China University of Geosciences, Beijing(in Chinese with English abstract). Pei, L., Li, R.B., Pei, X.Z., et al., 2017. Sediment Source Analysis for the Maerzheng Formation Sandstone in Gerizhuotuo Area, Southern Margin of East Kunlun Region: Evidence for Detrital Zircon U-Pb Geochronology. Acta Geologica Sinica, 91(6): 1326-1344(in Chinese with English abstract). Qin, Y.L., Li, M.Z., Xiong, C.L., et al., 2020. Depositional Provinces and Tectonic Background of the Zhuwo Formation in the Jiajika Region, Western Sichuan Province: Evidence from Detrital Zircon U-Pb Ages. Acta Geologica Sinica, 94(8): 2400-2409 (in Chinese with English abstract). Ren, G.M., Pang, W.H., Wang, L.Q., et al, 2020. Detrital Zircons of 3.8 Ga Southwestern Yangtze Block and Its Geological Implications. Earth Science, 45(8): 3040-3053 (in Chinese with English abstract). Roda-Robles, E., Villaseca, C., Pesquera, A., et al., 2018. Petrogenetic Relationships Between Variscan Granitoids and Li-(F-P)-Rich Aplite-Pegmatites in the Central Iberian Zone: Geological and Geochemical Constraints and Implications for Other Regions from the European Variscides. Ore Geology Reviews, 95: 408-430. https://doi.org/10.1016/j.oregeorev.2018.02.027 Selway, J.B., Breaks, F.W., Tindle, A.G., 2005. A Review of Rare-Element (Li-Cs-Ta) Pegmatite Exploration Techniques for the Superior Province, Canada, and Large Worldwide Tantalum Deposits. Exploration and Mining Geology, 14(1/2/3/4): 1-30. https://doi.org/10.2113/gsemg.14.1-4.1 Shaw, D. M., 1972. The Origin of the Apsley Gneiss, Ontario. Canadian Journal of Earth Sciences, 9(1): 18-35. https://doi.org/10.1139/e72-002 Shi, Y., Yu, J. H., Santosh, M., 2013. Tectonic Evolution of the Qinling Orogenic Belt, Central China: New Evidence from Geochemical, Zircon U-Pb Geochronology and Hf Isotopes. Precambrian Research, 231(Suppl. ): 19-60. https://doi.org/10.1016/j.precamres.2013.03.001 Simonen, A., 1953. Stratigraphy and Sedimentation of the Svecofennidic, Early Archean Supracrustal Rocks in southwestern Finland. Bulletin of the Geological Society of Finland, 160: 1-64. Sun, S. S., McDonough, W. F., 1989. Chemical and Isotopic Systematics of Oceanic Basalts: Implications for Mantle Composition and Processes. Geological Society, London, Special Publications, 42(1): 313-345. https://doi.org/10.1144/gsl.sp.1989.042.01.19 Sun, W. H., Zhou, M. F., 2008. The ∼860 Ma, Cordilleran‐Type Guandaoshan Dioritic Pluton in the Yangtze Block, SW China: Implications for the Origin of Neoproterozoic Magmatism. The Journal of Geology, 116(3): 238-253. https://doi.org/10.1086/587881 Sonder, L. J., England, P. C., Wernicke, B. P., et al., 1987. A Physical Model for Cenozoic Extension of Western North America. Geological Society, London, Special Publications, 28(1): 187-201. https://doi.org/10.1144/gsl.sp.1987.028.01.14 Vervoort, J. D., Patchett, P. J., Söderlund, U., et al., 2004. Isotopic Composition of Yb and the Determination of Lu Concentrations and Lu/Hf Ratios by Isotope Dilution Using MC-ICPMS. Geochemistry, Geophysics, Geosystems, 5(11): 1-5. https://doi.org/10.1029/2004gc000721 Weislogel, A. L., Graham, S. A., Chang, E. Z., et al., 2010. Detrital Zircon Provenance from Three Turbidite Depocenters of the Middle-Upper Triassic Songpan-Ganzi Complex, Central China: Record of Collisional Tectonics, Erosional Exhumation, and Sediment Production. Geological Society of America Bulletin, 122(11/12): 2041-2062. https://doi.org/10.1130/b26606.1 Weislogel, A. L., Graham, S. A., Chang, E. Z., et al., 2006. Detrital Zircon Provenance of the Late Triassic Songpan-Ganzi Complex: Sedimentary Record of Collision of the North and South China Blocks. Geology, 34(2): 97. https://doi.org/10.1130/g21929.1 Wang, K., Wang, L.X., Ma, C.Q., et al., 2020. Petrogenesis and Geological Implication of the Middle Triassic Garnet-Bearing Two-Mica Granite from Jialuhe Region, East Kunlun. Earth Science, 45(2): 400-418 (in Chinese with English abstract). Wang, T., Wang, X.X., Tian, W., et al., 2009. North Qinling Paleozoic Granite Associations and Their Variation in Space and Time: Implications For Orogenic Processes in the Orogens of Central China. Scientia Sinica Terrae, 39(7): 949-971 (in Chinese with English abstract). Wang, X.X., Wang, T., Zhang, C.L., 2015. Granitoid Magmatism in the Qinling Orogen, Central China and Its Bearing on Orogenic Evolution. Scientia Sinica Terrae, 45(8): 1109-1125 (in Chinese with English abstract). doi: 10.1360/zd2015-45-8-1109 Wang, W., Li, F.L., Bao, Z.Y., 2007. U-Pb Constraints on Provenance and Evolution of Middle to Late Triassic Sediment in Songpan-Garze Basin. Geological Science and Technology Information, 26(6): 35-44 (in Chinese with English abstract). Wu, F.Y., Li, X.H., Zheng, Y.F., et al., 2007. Lu-Hf Isotopic Systematics and Their Applications in Petrology. Acta Petrologica Sinica, 23(2): 185-220 (in Chinese with English abstract). Wu, Y.B., Zheng, Y., 2004. Zircon Genetic Mineralogy and its Constraints on U-Pb Age Interpretation. Chinese Science Bulletin, 49(16): 1589-1604 (in Chinese with English abstract). doi: 10.1360/csb2004-49-16-1589 Xu, J.B., Fei, G.C., Qin, L.Y., et al., 2020. LA-MC-ICP-MS U-Pb Dating of Cassiterite from the Lijiagou Pegmatitetype Rare-Metal Deposit in the Ke'eryin Orefield, Sichuan Province and Its Geological Implication. Geology and Exploration, 56(2): 346-358 (in Chinese with English abstract). Xu, Q., Jiang, T., Hou, L.C., et al., 2021. Detrital Zircon Composition of U-Pb Ages and Hf Isotope for the Sandstone of the Liantuo Formation from the Three Gorges Area, Yangtze Block and its Geological Significance. Earth Science, 46(4): 1217-1230 (in Chinese with English abstract). Xu, Z.Q., Wang, R.C., Zhao, Z.B., et al., 2018. On the Structure Backgrounds of the Large-Scale "Hard-Rock"Type Lithium Ore Belts in China. Acta Geologica Sinica, 92(6): 1091-1106 (in Chinese with English abstract). Yu, Y.S., Liao, S.P., Pan, Z.X., et al., 2018. Geochemical Characteristics and Formation Background of Triassic Fine Clastic Rocks in Daofu Area, Western Sichuan. Mineral Petrology, 38(2): 94-103 (in Chinese with English abstract). Zeng, Y.J., Huang, S.J., Kan, Z.Z., et al., 2006. Geochemical Characteristics and Tectonic Setting of the Xikang Group of Triassic in Western Sichuan. Sedimentary Geology and Tethyan Geology, 26(1): 22-29 (in Chinese with English abstract). Zhai, M.G., Bian, A.G., 2000. Late Neoarchean Supercontinent Merging and Paleoproterozoic Mid-Proterozoic Pyrolysis in North China Craton. Science in China (Series D), 30(Supp. ): 129-137 (in Chinese with English abstract). Zhao, J.H., Zhou, M.F., 2008. Neoproterozoic Adakitic Plutons in the Northern Margin of the Yangtze Block, China: Partial Melting of a Thickened Lower Crust and Implications for Secular Crustal Evolution. Lithos, 104(1-4): 231-248. https://doi.org/10.1016/j.lithos.2007.12.009 Zhao, Z.H., 1997. Geochemistry of Trace Elements. Science Press, Beijing, 1-238 (in Chinese). Zhang, Y.X., Zeng, L, Li, Z.W., et al., 2015. Late PermianBeijing: Triassic Siliciclastic Provenance, Palaeogeography, and Crustal Growth of the SongpanTerrane, Eastern Tibetan Plateau: Evidence from UBeijing: Pb Ages, Trace Elements, and Hf Isotopes of Detrital Zircons. Geology Review, 57(2): 159-181. https://doi.org/10.1080/00206814.2014.999356 白宪洲, 何明友, 王玉婷, 等, 2010. 四川若尔盖地区西康群地球化学特征及其物源区和古风化程度分析. 现代地质, 24(1): 151-157. doi: 10.3969/j.issn.1000-8527.2010.01.018 邓运, 费光春, 李剑, 等, 2018. 四川李家沟伟晶岩型锂辉石矿床碳氢氧同位素及成矿时代研究. 矿物岩石, 38(3): 40-47. https://www.cnki.com.cn/Article/CJFDTOTAL-KWYS201803006.htm 费光春, 杨峥, 杨继忆, 等, 2020. 四川马尔康党坝花岗伟晶岩型稀有金属矿床成矿时代的限定: 来自LA-MC-ICP-MS锡石定年的证据. 地质学报, 94 (3): 836-849. doi: 10.3969/j.issn.0001-5717.2020.03.012 费光春, 袁天晶, 唐文春, 等, 2014. 川西可尔因伟晶岩型稀有金属矿床含矿伟晶岩分类浅析. 矿床地质, 33(5): 187-188. https://www.cnki.com.cn/Article/CJFDTOTAL-KCDZ2014S1096.htm 古城会, 2014. 四川省可尔因伟晶岩田东南密集区锂辉石矿床成矿规律. 地质找矿论丛, 29(1): 59-65. https://www.cnki.com.cn/Article/CJFDTOTAL-DZZK201401007.htm 郭正府, 邓晋福, 许志琴, 等, 1998. 青藏东昆仑晚古生代末-中生代中酸性火成岩与陆内造山过程. 现代地质, (3): 51-59. https://www.cnki.com.cn/Article/CJFDTOTAL-XDDZ803.006.htm 黄涵宇, 何登发, 李英强, 等, 2019. 四川盆地东南部泸州古隆起的厘定及其成因机制. 地学前缘, 26(1): 102-120. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201901012.htm 胡健民, 孟庆任, 石玉若, 等, 2005. 松潘-甘孜地体内花岗岩锆石SHRIMP U-Pb定年及其构造意义. 岩石学报, (3): 867-880. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB200503027.htm 廖远安, 姚学良, 1992. 金川-过铝多阶段花岗岩体演化特征及其与成矿关系. 矿物岩石, (1): 12-22. https://www.cnki.com.cn/Article/CJFDTOTAL-KWYS199201002.htm 刘飞, 陈岳龙, 苏本勋, 兰中伍, 等, 2006. 松潘-甘孜地区三叠系碎屑沉积岩地球化学特征及其锆石年龄研究. 地球学报, 27(4): 289-296. https://www.cnki.com.cn/Article/CJFDTOTAL-DQXB200604001.htm 李建康, 2006. 川西典型伟晶岩型矿床的形成机理及其大陆动力学背景(博士毕业论文). 北京: 中国地质大学. 李智武, 宋天慧, 王自剑, 等, 2021. 川西-龙门山盆山系统走向差异演化的变形、隆升和沉积记录及关键构造变革期讨论. 成都理工大学学报(自然科学版), 48(3): 257-282. doi: 10.3969/j.issn.1671-9727.2021.03.01 木红旭, 2020. 川西晚三叠世前陆盆地的形成与演化(博士毕业论文). 北京: 中国地质大学. 裴磊, 李瑞保, 裴先治, 等, 2017. 东昆仑南缘哥日卓托地区马尔争组沉积物源分析: 碎屑锆石U-Pb年代学证据. 地质学报, 91(6): 1326-1344. doi: 10.3969/j.issn.0001-5717.2017.06.012 秦宇龙, 李名则, 熊昌利, 等, 2020. 川西甲基卡地区侏倭组沉积物源分析——来自碎屑锆石U-Pb年龄证据. 地质学报, 94(8): 2400-2409. doi: 10.3969/j.issn.0001-5717.2020.08.016 任光明, 庞维华, 王立全, 等, 2020. 扬子陆块西南缘3.8 Ga碎屑锆石及其地质意义. 地球科学, 45 (8): 3040-3053. doi: 10.3799/dqkx.2020.095 王珂, 王连训, 马昌前, 等, 2020. 东昆仑加鲁河中三叠世含石榴石二云母花岗岩的成因及地质意义. 地球科学, 45 (2): 400-418. doi: 10.3799/dqkx.2018.393 王涛, 王晓霞, 田伟, 等, 2009. 北秦岭古生代花岗岩组合、岩浆时空演变及其对造山作用的启示. 中国科学(D辑: 地球科学), 39(7): 949-971. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK200907008.htm 王伟, 李方林, 鲍征宇, 2007. 松潘-甘孜盆地中、晚三叠世沉积物来源及演化的锆石U-Pb年代学制约. 地质科技情报, (5): 35-44. doi: 10.3969/j.issn.1000-7849.2007.05.007 王晓霞, 王涛, 张成立, 2015. 秦岭造山带花岗质岩浆作用与造山带演化. 中国科学: 地球科学, 45(8): 1109-1125. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK201508003.htm 吴福元, 李献华, 郑永飞, 等, 2007. Lu-Hf同位素体系及其岩石学应用. 岩石学报, (2): 185-220. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB200702002.htm 吴元保, 郑永飞, 2004. 锆石成因矿物学研究及其对U-Pb年龄解释的制约. 科学通报, (16): 1589-1604. doi: 10.3321/j.issn:0023-074X.2004.16.002 许家斌, 费光春, 覃立业, 等, 2020. 四川可尔因矿田李家沟伟晶岩型稀有金属矿床锡石LA-MC-ICP-MS U-Pb定年及地质意义. 地质与勘探, 56 (2): 346-358. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKT202002010.htm 徐琼, 江拓, 侯林春, 等, 2021. 扬子陆块三峡地区莲沱组砂岩中碎屑锆石U-Pb年龄、Hf同位素组成及其地质意义. 地球科学, 46 (4): 1217-1230. doi: 10.3799/dqkx.2020.168 许志琴, 王汝成, 赵中宝, 等, 2018. 试论中国大陆"硬岩型"大型锂矿带的构造背景. 地质学报, 92 (6): 1091-1106. doi: 10.3969/j.issn.0001-5717.2018.06.001 于远山, 廖声萍, 潘忠习, 等, 2018. 川西道孚地区三叠系细碎屑岩的地球化学特征及成生背景. 矿物岩石, 38(2): 94-103. https://www.cnki.com.cn/Article/CJFDTOTAL-KWYS201802011.htm 曾宜君, 黄思静, 阚泽忠, 等, 2006. 四川西部三叠系西康群地球化学特征与大地构造背景. 沉积与特提斯地质, (1): 22-29. https://www.cnki.com.cn/Article/CJFDTOTAL-TTSD200601003.htm 翟明国, 卞爱国, 2000. 华北克拉通新太古代末超大陆拼合及古元古代末-中元古代裂解. 中国科学(D辑: 地球科学), (增刊): 129-137. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK2000S1016.htm 赵振华, 1997. 微量元素地球化学原理. 北京: 科学出版社, 1-238. -
