Zircon U-Pb Age and Stratigraphic Significance of Tuff in Heshanggou Formation, Southern North China Basin
-
摘要: 为了约束华北盆地自二叠纪-三叠纪大灭绝后生物复苏与气候转变的时限，对济源地区和尚沟组上部新发现的凝灰岩层进行了LA-ICP-MS锆石定年分析.部分凝灰岩锆石颗粒呈短柱状，少量长柱状，无磨圆，阴极发光照片显示明显的环带结构.剔除轻稀土含量较高的颗粒后，选择其中最年轻的一组样品进行年龄加权平均计算，得到凝灰岩层的就位年龄为244.6±2.8 Ma.该定年结果表明和尚沟组的沉积时代跨越了早-中三叠世，至中三叠世安尼期.同时也约束了华北盆地济源地区的陆地生态系统自奥伦尼克期开始复苏，在中三叠世安尼期全面重建，与海洋生态系统的恢复时限一致；古气候由极端温室向中等温室的转变也发生在中三叠世安尼期，与全球在中三叠的降温趋势一致.Abstract: In order to constrain the timing for biological recovery and climate change after the Permian-Triassic extinction in North China basin, in this contribution it applies zircon LA-ICP-MS dating of the newly discovered tuff layer in the upper part of the Heshanggou Formation in Jiyuan area. Some zircons occur as short cylindrical shape, with a few elongated grains. All zircons were not rounded, and showed obvious oscillatory zoning characteristics under a cathodoluminescence microscope. After removing zircons with enriched LREE, the remaining zircons showed a weighted mean U-Pb age of 244.6±2.8 Ma. The results show that the stratigraphic age of Heshanggou Formation spanned to the Middle Triassic Anisian age. The new age constrains that the terrestrial ecosystem in North China Basin was fully rebuilt during the Anisian after recovered during the Olenekian, which is consistent with the recovery time of marine ecosystem. The paleoclimate transition from extreme greenhouse to medium greenhouse also occurred in the Anisian age, which is consistent with the continuous global cooling trend in the Middle Triassic.
-
Key words:
- Heshanggou Formation /
- Triassic /
- tuff /
- biological recovery /
- paleoclimate /
- climate change /
- stratigraphy
-
图 1 中国地质简图（a）；研究区地质简图（b）；济源地区和尚沟组地层柱状图（c）
1.华北盆地；2.研究区；3.二叠系；4.下三叠统；5.中三叠统；6.上三叠统；7.侏罗系；8.古近系；9.新近系；10.第四系；11.细砂岩；12.粉砂岩；13.泥质粉砂岩；14.粉砂质泥岩；15.砾岩；16.凝灰岩层所在位置. 图a底图来自标准地图服务网无修改，审图号为GS（2022）4309
Fig. 1. Tectonic unit diagram of China (a); geological map of the studied area (b); Heshanggou Formation stratigraphic column of Jiyuan area (c)
图 2 华北盆地济源地区典型野外现象照片
a. 刘家沟组砾岩；b. 刘家沟组巨厚层砂岩夹泥岩；c. 和尚沟组细砂岩中的平行层理；d. 和尚沟组厚层泥岩中的钙质结核；e. 和尚沟组粉砂岩中的浪成交错层理；f. 和尚沟组凝灰岩层所在剖面的野外照片（图中黄色箭头指示的是凝灰岩层的位置）；g. 和尚沟组凝灰岩层（黄色方框指示采样位置）；h. 和尚沟组与二马营组交界处厚层黄色砂岩；i. 二马营组砂岩中的板状交错层理
Fig. 2. Typical field phenomena from Jiyuan area, North China basin
图 4 凝灰岩样品锆石稀土元素球粒陨石标准化分配图（a）；岩浆锆石U-Pb年龄协和图（b）；岩浆锆石年龄概率分布直方图（c）；岩浆锆石U-Pb年龄加权平均图（d）
Fig. 4. Chondrite-normalized REE curve of zircons from tuffs (a); U-Pb concordia diagram of zircons (b); U-Pb age distribution and probability density plot histogram of zircons (c); U-Pb age weighted average plot of zircon (d)
图 5 和尚沟组地层划分对比
Fig. 5. Summary of stratigraphic classification on the Heshanggou Formation
图 6 华北盆地中下三叠统生物扰动指数（a），晚二叠世至中三叠世海相生物属丰度变化（b）
图a据Guo et al.（2019）；Xing et al.（2021）
Fig. 6. Bioturbation index of the Lower-Middle Triassic strata (a), genus richness changes (b) throughout the Late Permian to the Middle Triassic
图 7 三叠纪海水表面温度与全球平均温度变化
据Song et al.（2020）；Scotese et al.（2021）
Fig. 7. Sea-surface temperature and global average temperature throughout Triassic
-
Brayard, A., Escarguel, G., Bucher, H., et al., 2009. Good Genes and Good Luck: Ammonoid Diversity and the End-Permian Mass Extinction. Science, 325(5944): 1118-1121. https://doi.org/10.1126/science.1174638 Chen, Z. Q., Benton, M. J., 2012. The Timing and Pattern of Biotic Recovery Following the End-Permian Mass Extinction. Nature Geoscience, 5(6): 375-383. https://doi.org/10.1038/ngeo1475 Chu, D. L., Tong, J. N., Song, H. J., et al., 2015. Early Triassic Wrinkle Structures on Land: Stressed Environments and Oases for Life. Scientific Reports, 5: 10109. https://doi.org/10.1038/srep10109 Erwin, D. H., 1994. The Permo-Triassic Extinction. Nature, 367(6460): 231-236. https://doi.org/10.1038/367231a0 Guo, W., Tong, J., Tian, L., et al., 2019. Secular Variations of Ichnofossils from the Terrestrial Late Permian-Middle Triassic Succession at the Shichuanhe Section in Shaanxi Province, North China. Global and Planetary Change, 181: 102978. https://doi.org/10.1016/j.gloplacha.2019.102978 Hoskin, P. W. O., 2005. Trace-Element Composition of Hydrothermal Zircon and the Alteration of Hadean Zircon from the Jack Hills, Australia. Geochimica et Cosmochimica Acta, 69(3): 637-648. https://doi.org/10.1016/j.gca.2004.07.006 Hu, B., Lu, X. H., Song, H. B., 2015. Lower Trassic Ichnofossils and Sedimentary Environments in the Dengfeng Area, Western Henan Provience. Journal of Stratigraphy, 39(4): 454-465 (in Chinese with English abstract). Hu, B., Yang, W. T., Song, H. B., et al., 2009. Early Triassic Lacustrine Trace Fossils and Trace Fabric of Heshanggou Formation in Jiyuan Area, Western Henan Province. Acta Sedimentologica Sinica, 27(4): 573-582(in Chinese with English abstract). Irmis, R. B., Whiteside, J. H., 2012. Delayed Recovery of Non-Marine Tetrapods after the End-Permian Mass Extinction Tracks Global Carbon Cycle. Proceedings Biological Sciences, 279(1732): 1310-1318. https://doi.org/10.1098/rspb.2011.1895 Joachimski, M. M., Lai, X., Shen, S., et al., 2012. Climate Warming in the Latest Permian and the Permian-Triassic Mass Extinction. Geology, 40(3): 195-198. https://doi.org/10.1130/g32707.1 Lan, Z. W., Huyskens, M. H., Lu, K., et al., 2020. Toward Refining the Onset Age of Sturtian Glaciation in South China. Precambrian Research, 338: 105555. https://doi.org/10.1016/j.precamres.2019.105555 Lan, Z. W., Li, X. H., Zhu, M., et al., 2015. Revisiting the Liantuo Formation in Yangtze Block, South China: SIMS U-Pb Zircon Age Constraints and Regional and Global Significance. Precambrian Research, 263: 123-141. https://doi.org/10.1016/j.precamres.2015.03.012 Liu, J., 2018. High-Precision Temporal Calibration of Middle Triassic Vertebrate Biostratigraphy: U-Pb Zircon Constraints for the Sinokannemeyeria Fauna and Yonghesuchus. Vertebrata Palasiatica, 56(1): 16-24. Lucas, S. G., 2010. The Triassic Timescale Based on Nonmarine Tetrapod Biostratigraphy and Biochronology. Geological Society, London, Special Publications, 334(1): 447-500. https://doi.org/10.1144/sp334.15 Ludwing, K. R., 2003. User's Manual for a Geochronological Toolkit for Microsoft Excel (Isoplot/Ex Version 3.0). Berkeley Geochronology Center, Special Publication, 4: 1-71. Ma, Q. L., Chai, R., Du, Y. S., et al., 2019. Geochronological Constraints on Tuffs of the Badong Formation along the North Margin of the Middle Yangtze Region. Acta Geologica Sinica, 93(11): 2785-2796 (in Chinese with English abstract). Mai, Y. J., Zhu, L. D., Yang, W. G., et al., 2021. Zircon U-Pb and Hf Isotopic Composition of Permian Felsic Tuffs in Southeastern Margin of Lhasa, Tibet. Earth Science, 46(11): 3880-3891(in Chinese with English abstract). Nesbitt, S. J., Liu, J., Li, C., 2011. A Sail-Backed Suchian from the Heshanggou Formation (Early Triassic: Olenekian) of China. Earth and Environmental Science Transactions of the Royal Society of Edinburgh, 101(3/4): 271-284. https://doi.org/10.1017/s1755691011020044 Orchard, M. J., 2007. Conodont Diversity and Evolution through the Latest Permian and Early Triassic Upheavals. Palaeogeography, Palaeoclimatology, Palaeoecology, 252(1/2): 93-117. https://doi.org/10.1016/j.palaeo.2006.11.037 Payne, J., Kump, L., 2007. Evidence for Recurrent Early Triassic Massive Volcanism from Quantitative Interpretation of Carbon Isotope Fluctuations. Earth and Planetary Science Letters, 256(1/2): 264-277. https://doi.org/10.1016/j.epsl.2007.01.034 Qu, L. F., Yang, J. D., Bai, Y. H., et al, 1983. A Preliminary Discussion on the Characteristics and Stratigraphic Divisions of Triassic Spores and Pollen in China. Bulletin Chinese Acad. Geol. Sci., (1): 81-94+121-124 (in Chinese with English abstract). Rubidge, B. S., 2005. 27th Du Toit Memorial Lecture: Re-Uniting Lost Continents-Fossil Reptiles from the Ancient Karoo and Their Wanderlust. South African Journal of Geology, 108(1): 135-172. https://doi.org/10.2113/108.1.135 Scotese, C. R., Song, H., Mills, B. J. W., et al, 2021. Phanerozoic Paleotemperatures: The Earth's Changing Climate during the Last 540 Million Years. Earth-Science Reviews, 215: 103503. https://doi.org/10.1016/j.earscirev.2021.103503 Shanxi Provincial Bureau of Geology and Mineral Resources, 1989. Shanxi Provincial Regional Geological Index. Geological Publishing House, Beijing (in Chinese). Shen, S. Z., Crowley, J. L., Wang, Y., et al., 2011. Calibrating the End-Permian Mass Extinction. Science, 334(6061): 1367-1372. https://doi.org/10.1126/science.1213454 Song, H. J., Huang, S., Jia, E. H., et al., 2020. Flat Latitudinal Diversity Gradient Caused by the Permian-Triassic Mass Extinction. PNAS, 117(30): 17578-17583. https://doi.org/10.1073/pnas.1918953117 Sun, Y. D., Joachimski, M. M., Wignall, P. B., et al., 2012. Lethally Hot Temperatures during the Early Triassic Greenhouse. Science, 338(6105): 366-370. https://doi.org/10.1126/science.1224126 Tan, C., Yu, B. S., Yuan, X. J., et al., 2020. Color Origin of the Lower Triassic Liujiagou and Heshanggou Formations Red Beds in the Ordos Basin. Geoscience, 34(4): 769-783 (in Chinese with English abstract). Tan, C., Yuan, X. J., Yu, B. S., et al., 2019. Geochemical Characteristics and Paleoclimatic Implications of the Upper Permian and Middle-Lower Triassic Strata in Southern Ordos Basin. Geoscience, 33(3): 615-628 (in Chinese with English abstract). Tong, J. N., Chu, D. L., Liang, L., et al., 2019. Triassic Integrative Stratigraphy and Timescale of China. Scientia Sinica Terrae, 49(1): 194-226 (in Chinese). doi: 10.1360/N072018-00012 Tong, J. N., Yin, H. F., 2009. Advance in the Study of Early Triassic Life and Environment. Acta Palaeontologica Sinica, 48(3): 497-508 (in Chinese with English abstract). Trotter, J. A., Williams, I. S., Nicora, A., et al., 2015. Long-Term Cycles of Triassic Climate Change: A New δ18O Record from Conodont Apatite. Earth and Planetary Science Letters, 415: 165-174. https://doi.org/10.1016/j.epsl.2015.01.038 Wang, L. X., Xie, Z. M., Wang, Z. Q., 1978. On the Occurrence of Pleuromeia from the Qinshui Basin in Shanxi Province. Acta Palaeontologica Sinica, (2): 195-212+248-251 (in Chinese with English abstract). Xin, B. S., 2019. SHRIMP Zircon U-Pb Dating and Source Analysis of Tuff Interlayer of Triassic Ermaying Formation in Xiabancheng Basin of Chengde Area, Northern Margin of North China Craton. Journal of Beijing Normal University (Natural Science), 55(6): 796-802 (in Chinese with English abstract). Xing, Z. F., Lin, X., Fu, Y. X., et al., 2021. Trace Fossils from the Lower Triassic of North China: A Potential Signature of the Gradual Recovery of a Terrestrial Ecosystem. Palaeoworld, 30(1): 95-105. https://doi.org/10.1016/j.palwor.2020.06.002 Yang, J. H., Yan, J. X., Huang, Y., 2017. The Earth's Penultimate Icehouse-to-Greenhouse Climate Transition and Related Sedimentary Records in Low-Latitude Regions of Eastern Tethys. Acta Sedimentologica Sinica, 35(5): 981-993 (in Chinese with English abstract). Zhao, X. M., Niu, Z. J., Tong, J. N., et al., 2010. "Staggered Facies" Deposit, a Special Deposit in the Early Triassic Biological Recovery Period. Acta Sedimentologica Sinica, 28(2): 314-323 (in Chinese with English abstract). Zheng, W., Xu, X., Qi, Y. A., et al, 2021. Evolution of Terrestrial Triassic Ichnofossils and Ecological Significance in Western Henan Province. Earth Science (in Chinese with English abstract)(in Press). Zhu, Z. C., Kuang, H. W., Liu, Y. Q., et al., 2020. Intensifying Aeolian Activity Following the End-Permian Mass Extinction: Evidence from the Late Permian-Early Triassic Terrestrial Sedimentary Record of the Ordos Basin, North China. Sedimentology, 67(5): 2691-2720. https://doi.org/10.1111/sed.12716 Zou, X. Y., Qin, K., Han, X., et al., 2019. Insight into Zircon REE Oxy-Barometers: A Lattice Strain Model Perspective. Earth and Planetary Science Letters, 506: 87-96. https://doi.org/10.1016/j.epsl.2018.10.031 胡斌, 芦旭辉, 宋慧波, 2015. 豫西登封地区下三叠统中的遗迹化石及其沉积环境. 地层学杂志, 39(4): 454-465. https://www.cnki.com.cn/Article/CJFDTOTAL-DCXZ201504013.htm 胡斌, 杨文涛, 宋慧波, 等, 2009. 豫西济源地区早三叠世和尚沟组湖相遗迹化石及遗迹组构. 沉积学报, 27(4): 573-582. https://www.cnki.com.cn/Article/CJFDTOTAL-CJXB200904000.htm 马千里, 柴嵘, 杜远生, 等, 2019. 中扬子区巴东组凝灰岩层的锆石U-Pb年龄约束. 地质学报, 93(11): 2785-2796. https://www.cnki.com.cn/Article/CJFDTOTAL-DZXE201911006.htm 麦源君, 朱利东, 杨文光, 等, 2021. 西藏东南缘早二叠世长英质凝灰岩锆石U-Pb年龄和Hf同位素特征. 地球科学, 46(11): 3880-3891. doi: 10.3799/dqkx.2020.397 曲立范, 杨基端, 白云洪, 等, 1983. 中国三叠纪孢粉组合特征及其分区的初步探讨. 中国地质科学院院报, (1): 81-94+121-124. https://www.cnki.com.cn/Article/CJFDTOTAL-DQXB198301006.htm 山西省地质矿产局, 1989. 山西省区域地质志. 北京: 地质出版社. 谭聪, 于炳松, 袁选俊, 等, 2020. 鄂尔多斯盆地下三叠统刘家沟组与和尚沟组红层成色机制. 现代地质, 34(4): 769-783. https://www.cnki.com.cn/Article/CJFDTOTAL-XDDZ202004014.htm 谭聪, 袁选俊, 于炳松, 等, 2019. 鄂尔多斯盆地南缘上二叠统-中下三叠统地球化学特征及其古气候、古环境指示意义. 现代地质, 33(3): 615-628. https://www.cnki.com.cn/Article/CJFDTOTAL-XDDZ201903014.htm 童金南, 楚道亮, 梁蕾, 等, 2019. 中国三叠纪综合地层和时间框架. 中国科学: 地球科学, 49(1): 194-226. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK201901010.htm 童金南, 殷鸿福, 2009. 早三叠世生物与环境研究进展. 古生物学报, 48(3): 497-508. https://www.cnki.com.cn/Article/CJFDTOTAL-GSWX200903019.htm 王立新, 解志民, 王自强, 1978. 山西沁水盆地早三叠世肋木属的发现及其地层意义. 古生物学报, (2): 195-212+248-251. https://www.cnki.com.cn/Article/CJFDTOTAL-GSWX197802007.htm 辛补社, 2019. 华北克拉通北缘承德下板城盆地三叠系二马营组凝灰岩夹层SHRIMP锆石U-Pb定年及源区分析. 北京师范大学学报(自然科学版), 55(6): 796-802. https://www.cnki.com.cn/Article/CJFDTOTAL-BSDZ201906002.htm 杨江海, 颜佳新, 黄燕, 2017. 从晚古生代冰室到早中生代温室的气候转变: 兼论东特提斯低纬区的沉积记录与响应. 沉积学报, 35(5): 981-993 https://www.cnki.com.cn/Article/CJFDTOTAL-CJXB201705010.htm 赵小明, 牛志军, 童金南, 等, 2010. 早三叠世生物复苏期的特殊沉积: "错时相" 沉积. 沉积学报, 28(2): 314-323. https://www.cnki.com.cn/Article/CJFDTOTAL-CJXB202305026.htm 郑伟, 许欣, 齐永安, 等, 2021. 豫西地区陆相三叠纪遗迹化石演化及生态学意义. 地球科学(待刊). -
