Sandstone Distribution and Reservoir Characteristics of Shahejie Formation in Huangheko Sag, Bohai Bay Basin
-
摘要: 中央构造脊是在黄河口凹陷内受走滑挤压作用形成的水下同沉积洼内隆起，同时也是黄河口凹陷重要的油气聚集带；但脊内沙河街组储层非均质性强，其砂体展布与储层发育规律尚不明确，制约了深部勘探部署.通过三维地震、钻测井、岩矿数据分析恢复了沙河街组沉积期中央构造脊古地貌特征、落实构造脊东西砂体展布与南北物源供给界限，并将构造脊细分为东、西、南3个主要单元对储层发育的差异性进行详细研究. 通过微观储层分析刻画结合构造-沉积特征总结不同单元储层发育特征，表明东脊沙三段沉积期地势较低，为主物源通道，南北搬运距离远，砂体成熟度高；后期隆升诱导裂缝发育，渗透率升高，优质储层发育；西脊沉积期地势较高，为主物源侧翼，薄层杂砂岩，泥质含量高，局部钙质发育，储层欠发育；南脊持续隆升，作为南北物源交互区，脊内微隆起周期出露水面沉积淋滤碳酸盐岩造成临近砂体碳酸盐胶结强，物性相对较差.Abstract: The Central Structural Ridge, a synsedimentary subaqueous uplift controlled by strike-slip movement in Huanghekou Sag, is an important hydrocarbon bearing zone in Bohai Sea area. It is characterized by inapparent altitude difference, frequent internal reliefchange and strong reservoir heterogeneity. The characteristicsof sandbody distribution and reservoir development of thirdmemberof Shahejie Formationinthisbelt are not clear yet. In this paper, weconductpalaeogeomorphologic reconstruction bycombining seismic and drilling data and subdivide the belt into east, west and south parts. We separated the ranges of southern and northern source areas through light and heavy mineral data. Through synthetic analysis, we build the tectonic-deposition-reservoir patterns which could guide the exploration effectively. During the depositionof the thirdmemberof Shahejie Formation, the east Ridge was relativelylow and played the role of the major sediment channel. The sediment could transport longdistance towards the south with high maturity. The fractures developing inside the particles due to following tectonic inversion highly improved the permeability and resulted in development high-quality reservoirs. The west Ridge was relatively high and located aside the major channel and deposited thin sandstones with thick mudstone showing poor reservoir quality. The south Ridge located in the intersecting zone between north and south sediments adjacent to the central high landform causing strong carbonate cementing in sandstones.
-
图 1 黄河口凹陷区域地质图与典型剖面
Fig. 1. Regional geological map and typical seismic sections of the Huanghekou Sag
图 3 中央构造脊物源交互区B/C构造沙河街组格架矿物组成
Fig. 3. The mineral compositions of the Shahejie Formation from Structures B and Structures C located in the transition zones of north and south source areas, Central Structural Ridge
图 4 中央构造脊物源交互区B/C构造沙河街组主要重矿物组成
饼图内数字为样品深度，单位为m
Fig. 4. Heavy mineral compositions of the Shahejie Formation from the Structure B and Structure C located in the transition zones of north and south source areas, Central Structural Ridge
图 5 中央构造脊A与B构造典型钻井(左)与岩性特征（右）
a. A-1井，3 460.70 m，杂砂岩，粒间充填绘制，单偏光；b. E-2井，3 383 m，灰质杂砂岩，钙质充填；c. B-1井，3 365.70 m，净砂岩，孔隙发育，铸体薄片，红色铸体；d. B-2AD井，3 725 m，净砂岩，孔隙发育，铸体薄片，红色铸体
Fig. 5. Typical boreholes (left) and reservoir lithologic features of Structure A and Structure B in Central Structural Ridge
图 6 中央构造脊古地貌特征与砂体展布模式图
Fig. 6. Paleogeographic features and sandbody distribution pattern of the Central Structural Ridge
图 7 中央构造脊沙河街组西侧E, 东侧B与南部C构造储层物性特征
Fig. 7. Reservoir physical property of Shahejie Formation from Structure E in west part, Structure B in east part and Structure C in south part of the Central Structural Ridge
图 8 中央构造脊B构造沙河街组储层发育特征
a. 粒间孔与砾内裂缝发育，铸体薄片（蓝色铸体），3 365.7 m，B-1井；b. A的局部放大，可见铸体充注砾内裂缝；c. 粒间孔与砾内缝发育，铸体薄片（红色铸体），3 724 m（斜深），A-2D井；d. 砾内裂缝发育联通粒间孔隙，电子扫描电镜背散射图像，3 724.6 m（斜深），B-2D井；e. 裂缝切穿局部方解石胶结物，电子扫描电镜背散射图像，3 724.6 m（斜深），B-2D井，；f. 典型样品矿物相对成分组成，X衍射数据，B-1井，沙三段
Fig. 8. Reservoir features of Shahejie Formation from Structure B, Central Structural Ridge
图 9 中央构造脊C构造沙河街组储层发育特征
a. 为C-3井单井柱状图；b. 湖相泥晶云岩岩心照片，见岩溶角砾，3 303 m，C-3井；c. 湖相云岩岩溶角砾，原岩（Dol-1），发育一期白云石胶结（Dol-2），一期方解石胶结充填（Cal），可见残留粒间孔（P），铸体薄片，3 300 m，C-3井；d. 碳酸盐胶结砂岩，发育两期白云石胶结（Dol-1，Dol-2），一期方解石胶结充填（Cal），铸体薄片，3 297.7 m，C-3井；e. 云质胶结砂岩，扫描电镜背散射图像，3 510 m，C-5井；f. 云质胶结砂岩，阴极发光，首期白云石发亮橘黄色，次期发暗橘黄色光，3 510 m，C-5井
Fig. 9. Reservoir development characteristics of Shahejie Formation in Central Structural Ridge C Structure
-
[1] Cui, J. W., Yuan, X. J., Wu, S. T., et al., 2021. Rock Types and Reservoir Characteristics of Shahejie Formation Marl in Shulu Sag, Jizhong Depression, Bohai Bay Basin. Journal of Earth Science, 32(4): 986-997. https://doi.org/10.1007/s12583-020-1092-5 [2] Dickinson, W. R., 1979. Plate Tectonics and Sandstone Compositions. Bull. Amer. Assoc. Petrol. Geol, 63(12): 2164-2182. https://doi.org/10.1306/2f9188fb-16ce-11d7-8645000102c1865d [3] Folk, R. L., 1968. Petrology of Sedimentary Rocks. Hemphill Publishing Company, Austin, 170. [4] Folk, R. L., 1980. Petrology of Sedimentary Rocks. Hemphill Publishing Company, Austin, 184. [5] He, J., Wang, H., Eduardo, G., 2020. Petrographic Analysis and Classification of Sand and Sandstone. Earth Science, 45(6): 2186-2198(in Chinese with English abstract). [6] Jin, L., Wang, G., Song, W., et al., 2018. Review of Diagenetic Facies in Tight Sandstones: Diagenesis, Diagenetic Minerals, and Prediction Via Well Logs. Earth-Science Reviews, 185: 234-258. doi: 10.1016/j.earscirev.2018.06.009 [7] Kang, N. C., Cao, Y. Z., Zhang, X. Q., et al., 2013. Stand-by Exploration Field of Rift Basin: Deep Sag Belt. China Petroleum Exploration, 18(1): 29-34(in Chinese with English abstract). doi: 10.3969/j.issn.1672-7703.2013.01.004 [8] Kordi, M., Turner, B., Salem, A. M. K., 2011. Linking Diagenesis to Sequence Stratigraphy in Fluvial and Shallow Marine Sandstones: Evidence from the Cambrian-Ordovician Lower Sandstone Unit in Southwestern Sinai, Egypt. Marine and Petroleum Geology, 28(8): 1554-1571. https://doi.org/10.1016/j.marpetgeo.2011.05.003 [9] Li, P. L., Zhai, Q. L., Rong, Q. H., et al., 2000. Migration and Accumulation of Hydrocarbons in the Central Anticline Belt of Dongying Depression, Bohai Bay Basin. Petroleum Exploration and Development, 27(4): 64-66(in Chinese with English abstract). doi: 10.3321/j.issn:1000-0747.2000.04.015 [10] Liu, H., Tian, L. X., Zhou, X. H., et al., 2017. Slope Break Systems of Rift Lacustrine Basin and Erosion Depositional Response: A Case Study of the Paleogene in Huanghekou Sag, Bohai Sea. China Offshore Oil and Gas, 29(4): 28-38(in Chinese with English abstract). [11] Liu, Q. H., Zhu, H. T., Du, X. F., et al., 2020. Development and Hotspots of Sedimentary Response of Glutenite in the Offshore Bohai Bay Basin. Earth Science, 45(5): 1676-1705(in Chinese with English abstract). [12] Ozkan, A., Cumella, S. P., Milliken, K. L., et al., 2011. Prediction of Lithofacies and Reservoir Quality Using Well Logs, Late Cretaceous Williams Fork Formation, Mamm Creek Field, Piceance Basin, Colorado. AAPG Bulletin, 95(10): 1699-1723. https://doi.org/10.1306/01191109143 [13] Pang, X. J., Niu, C. M., Du, X. F., et al., 2020. Differences and Genesis of High-Quality Reservoirs of Mixed Siliciclastic Carbonate Rocks in the Es12 around Bozhong Depression, Bohai Sea. Earth Science, 45(10): 3853-3869(in Chinese with English abstract). [14] Qi, J. F., Zhou, X. H., Deng, R. J., et al., 2008. Structural Characteristics of the Tan-Lu Fault Zone in Cenozoic Basins Offshore the Bohai Sea. Science in China Series D: Earth Sciences, 51(S2): 20-31(in Chinese with English abstract). doi: 10.1007/s11430-008-6013-x [15] Qi, J. F., Zhou, X. H., Wang, Q. S., 2010. Structural Model and Cenozoic Kinematics of Tan-Lu Deep Fracture Zone in Bohai Sea Area. Geology in China, 37(5): 1231-1242(in Chinese with English abstract). doi: 10.3969/j.issn.1000-3657.2010.05.001 [16] Ramm, M., 2000. Reservoir Quality and its Relationship to Facies and Provenance in Middle to Upper Jurassic Sequences, Northeastern North Sea. Clay Minerals, 35(1): 77-94. https://doi.org/10.1180/000985500546747 [17] Tong, X. G., 1984. On the Petroleum Geological Features of Tertiary Half-Graben in Eastern China. Oil & Gas Geology, (3): 218-227(in Chinese with English abstract). [18] Wen, H. L., Deng, H., Li, Z. Y., et al., 2017. Quantitative Evaluation of Control Effect of Faults on Hydrocarbon Accumulation in the Minghuazhen Formation, Bohai Sea: a Case Study of Central Structural Ridg in Huanghekou Sag. Petroleum Geology and Recovery Efficiency, 24(4): 36-42(in Chinese with English abstract). doi: 10.3969/j.issn.1009-9603.2017.04.006 [19] Xu, Y. H., Yang, X. H., Mei, L. F., 2020. Reservoir Characteristics and Main Control Factors of Conglomerate Reservoir of El3 in the Northwest Steep Slope Zone of Weixinan Depression. Earth Science, 4(5): 1706-1721(in Chinese with English abstract). [20] Xue, Y. A., Yang, H. F., Xu, C. G., 2016. Differential Reservoir Control and Hydrocarbon Accumulation Rule in the Slope Belt in the Yellow River Estuary Depression in Bohai Sea. China Petroleum Exploration, 21(4): 65-74(in Chinese with English abstract). doi: 10.3969/j.issn.1672-7703.2016.04.007 [21] Xue, Y. A., Pang, X. J., Hao, Y. W., et al., 2020. Genesis of High-Quality Mixed Rock Reservoir and Its Exploration Significance in Es1around Southeast Margin of Qinnan Sag, Bohai Sea. Earth Science, 45(10): 3527-3542 (in Chinese with English abstract). [22] Ye, Z. Q., Zhu, H. T., Du, X. F., et al., 2020. Sedimentary Characteristics and Model of Mixed Siliciclastic-Carbonates of Member 1 of Paleogene Shahejie Formation, Huanghekou Sag, Bohai Bay Basin. Earth Science, 4(5): 1706-1721(in Chinese with English abstract). [23] Yi, S. W., Li, M. P., Xu, S. J., et al., 2020. Accumulation Condition and Model of Buried Hill in the Central Uplift, Songliao Basin, China. Journal of Natural Gas Geoscience, 6(3): 121-135(in Chinese with English abstract). [24] Zhang, J., Li, W., Wu, Z. P., et al., 2017. Structural Characteristics of Tan-Lu Fault Zone in South Area of Bohai Sea and Its Control on Basin Structure. Earth Science, 42(9): 1549-1564(in Chinese with English abstract). [25] Zhang, Y. X., Zhu, X. M., Chen, H. Q., 2014. Slope-Break Types and Sequence Stratigraphic Styles of the Oligocene Lingshui Formation in Qiongdongnan Basin, South China Sea. Oil & Gas Geology, 35(4): 473-479(in Chinese with English abstract). [26] Zhang, Z. L., Zhu, X. M., Liao, F. Y., et al., 2021. Features and Control Factors of Gentle-Sloped Fluvial Sand Bodies in Rift Basins: An example from the Wen'an Slope, Baxian Sag. Earth Science Frontiers, 28(1): 141-154(in Chinese with English abstract). [27] Zhang, Z. M., Zhou, J., Wu, X. W., 2006. Oil and Gas Migration Periods and Accumulation Process in Central Anticlinal Zone in the Xihu Sag, the East China Sea Basin. Petroleum Geology & Experiment, 1: 30-33+37(in Chinese with English abstract). [28] Zhao, H. G., Liu, C. Y., 2003. Approaches and Prospects of Provenance Analysis. Acta Sedimentologica Sinica, 21 (3): 409-415(in Chinese with English abstract). doi: 10.3969/j.issn.1000-0550.2003.03.007 [29] Zhao, X. Z., Pu, X. G., Wang, J. H., 2017. Sand and Reservoir Controlling Mechanism and Exploration Discovery in the Gentle Slope of Fault Basin: a Case Study of Qibei Slope in Qikou Sag. Acta Petrolei Sinica, 38(7): 729-739(in Chinese with English abstract). [30] Zhou, X. G., Huang, X. B., Ma, Z. W., 2020. Development Characteristics and Geological Significance of Recessive Thrust Provenance: A Case Study in Laibei Low Uplift of Bohai Sea. Journal of Xi'an University of petroleum: Natural Science Edition, 4: 26-29(in Chinese with English abstract). [31] Zhou, X. H., Zhang, X. T., Niu, C. M., 2019. Growth of Strike-Slip Zone in the Southern Bohai Bay Basin and Its Significances for Hydrocarbon. Oil & Gas Geology, (2), 215-222(in Chinese with English abstract). [32] Zhou, Y., Ji, Y. L., Zhang, S. W., et al., 2016. Controls on Reservoir Quality of Lower Cretaceous Tight Sandstones in the Laiyang Sag, Jiaolai Basin, Eastern China: Integrated Sedimentologic, Diagenetic and Microfracturing Data. Marine and Petroleum Geology, 76(Suppl. 1): 26-50. https://doi.org/10.1016/j.marpetgeo.2016.05.019 [33] 何杰, 王华, Eduardo, G., 2020. 砂岩(砂)的岩相分析和分类标准. 地球科学, 45(6): 2186-2198. doi: 10.3799/dqkx.2019.217 [34] 康南昌, 曹永忠, 张秀颀, 等, 2013. 断陷盆地的后备勘探领域——深陷带. 中国石油勘探, 18(1): 29-34. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY201301006.htm [35] 李丕龙, 翟庆龙, 荣启宏, 等, 2000. 东营凹陷中央背斜带油气运移聚集特征. 石油勘探与开发, (4): 64-66+113-121. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK200004016.htm [36] 刘豪, 田立新, 周心怀, 等, 2017. 断陷湖盆坡折体系与剥蚀沉积响应——以黄河口凹陷古近系为例. 中国海上油气, (4): 28-38. https://www.cnki.com.cn/Article/CJFDTOTAL-ZHSD201704004.htm [37] 刘强虎, 朱红涛, 杜晓峰, 等, 2020. 渤海海域砂砾岩体沉积响应进展及热点. 地球科学, 45(5): 1676-1705. doi: 10.3799/dqkx.2020.010 [38] 庞小军, 王清斌, 冯冲, 等, 2021. 渤海海域黄河口凹陷北缘沙河街组优质储层差异及成因. 沉积学报, 39(3): 751-766. https://www.cnki.com.cn/Article/CJFDTOTAL-CJXB202103019.htm [39] 漆家福, 邓荣敬, 周心怀, 等, 2008. 渤海海域新生代盆地中的郯庐断裂带构造. 中国科学(D辑: 地球科学), (S1): 19-29. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK2008S1003.htm [40] 漆家福, 周心怀, 王谦身, 2010. 渤海海域中郯庐深断裂带的结构模型及新生代运动学. 中国地质, (5): 1231-1242. https://www.cnki.com.cn/Article/CJFDTOTAL-DIZI201005004.htm [41] 童晓光, 1984. 中国东部第三纪箕状断陷斜坡带的石油地质特征. 石油与天然气地质, (3): 218-227. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT198403004.htm [42] 温宏雷, 邓辉, 李正宇, 等, 2017. 渤海海域新近系明化镇组断裂控藏作用定量评价——以黄河口凹陷中央构造脊为例. 油气地质与采收率, 24(4): 36-42. https://www.cnki.com.cn/Article/CJFDTOTAL-YQCS201704006.htm [43] 薛永安, 杨海风, 徐长贵, 2016. 渤海海域黄河口凹陷斜坡带差异控藏作用及油气富集规律. 中国石油勘探, 21(4): 65-74. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY201604008.htm [44] 薛永安, 庞小军, 郝轶伟, 等, 2020. 渤海海域秦南凹陷东南缘沙一段混积岩优质储层成因及勘探意义. 地球科学, 45(10): 3527-3542. doi: 10.3799/dqkx.2020.154 [45] 徐燕红, 杨香华, 梅廉夫, 2020. 涠西南凹陷西北陡坡带流三段砂砾岩储层特征与主控因素. 地球科学, 45(5): 1706-1721. doi: 10.3799/dqkx.2019.174 [46] 叶子倩, 朱红涛, 杜晓峰, 等, 2020. 渤海湾盆地黄河口凹陷古近系沙一段混积岩发育特征及沉积模式. 地球科学, 45(10): 3731-3745. doi: 10.3799/dqkx.2020.224 [47] 易士威, 李明鹏, 徐淑娟, 等, 2020. 松辽盆地中央隆起潜山成藏条件及模式. 天然气地球科学, 31(12): 1663-1676. https://www.cnki.com.cn/Article/CJFDTOTAL-TDKX202012001.htm [48] 赵红格, 刘池洋, 2003. 物源分析方法及研究进展. 沉积学报, 21(3): 409-415. https://www.cnki.com.cn/Article/CJFDTOTAL-CJXB200303006.htm [49] 张婧, 李伟, 吴智平, 李春锐, 等, 2017. 郯庐断裂带渤南段构造特征及其控盆作用. 地球科学, 42(9): 1549-1564. doi: 10.3799/dqkx.2017.110 [50] 周晓光, 黄晓波, 马正武, 等, 2020. 渤海海域莱北低凸起隐性"逆冲物源"发育特征及地质意义. 西安石油大学学报: 自然科学版, (4): 26-29. https://www.cnki.com.cn/Article/CJFDTOTAL-XASY202004006.htm [51] 周心怀, 张新涛, 牛成民, 等, 2019. 渤海湾盆地南部走滑构造带发育特征及其控油气作用. 石油与天然气地质, (2): 215-222. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201902002.htm [52] 赵贤正, 蒲秀刚, 王家豪, 等, 2017. 断陷盆地缓坡区控砂控藏机制与勘探发现——以歧口凹陷歧北缓坡带为例. 石油学报, 38(7): 729-739. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB201707001.htm [53] 张亚雄, 朱筱敏, 陈欢庆, 等, 2014. 琼东南盆地渐新统陵水组坡折带类型及层序地层样式. 石油与天然气地质, 35(4): 473-479. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201404005.htm [54] 张自力, 朱筱敏, 廖凤英, 等, 2021. 断陷盆地缓坡带河流沉积砂体定量表征及控制因素分析: 以霸县凹陷文安斜坡东营组三段为例. 地学前缘, 28(1): 141-154. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY202101015.htm [55] 张忠民, 周瑾, 邬兴威, 2006. 东海盆地西湖凹陷中央背斜带油气运移期次及成藏. 石油实验地质, (1): 30-33+37. https://www.cnki.com.cn/Article/CJFDTOTAL-SYSD200601005.htm -
