Provenance Characteristic of Devonian Chaganhabu Formation in the Northern Margin of the North China Craton and Its Tectonic Significance
-
摘要: 白乃庙岛弧带位于华北克拉通北缘，其与华北克拉通北缘的拼贴时限，是理解华北克拉通北缘增生过程的关键. 为了限定弧‒陆碰撞的时限，对白乃庙岛弧与华北克拉通拼合带的早古生代沉积地层——查干哈布组开展了锆石U-Pb定年和锆石Lu-Hf同位素测试. 结果显示，查干哈布组中3颗最年轻锆石的加权平均年龄为393.5± 4.9 Ma. 综合锆石年龄和前人化石资料，限定查干哈布组最大沉积年龄为早泥盆世晚期. 碎屑锆石U-Pb年龄谱和Hf同位素组成显示查干哈布组的物源为白乃庙岛弧带，基本没有来自华北克拉通的物源. 研究结果结合区域资料表明，白乃庙岛弧带与华北克拉通北缘在早泥盆世可能仍未发生弧‒陆碰撞.Abstract: The Bainaimiao arc belt is located in the northern margin of the North China Craton. The exact time of the collision between the Bainaimiao arc belt and the North China Craton is thus a key for understanding the accretionary process of the northern margin of the North China Craton. In order to constrain the collision time of the Bainaimiao arc belt and the North China Craton, this study carried out zircon U-Pb age dating and zircon Lu-Hf isotope analysis of the Chaganhabu Formation. The weighted average age of the three youngest zircons from the Chaganhabu Formation is 393.5±4.9 Ma, consistent with previous paleontological reports. Therefore, the maximum deposition age of the Chaganhabu Formation is the late Early Devonian. Moreover, the characteristic of zircon U-Pb age spectra and Hf isotope of the Chaganhabu Formation is similar to that of the Bainaimiao arc belt and different from that of the North China Craton, which means that the provenance of the Chaganhabu Formation is the Bainaimiao arc belt rather than the North China Craton. Combined with regional tectonic research, these data indicate that during the Early Devonian, there was still a wide ocean between the Bainaimiao arc belt and the northern margin of the North China Craton, and the arc-continent collision has not yet occurred.
-
图 1 中亚造山带大地构造位置简图（a据Windley and Xiao, 2018修改）及内蒙古中段区域地质简图（b据Xiao et al., 2003修改）
Fig. 1. Tectonic sketch map of the southern part of the Central Asian Orogenic Belt (a; modified after Windley and Xiao, 2018) and tectonic sketch map of central Inner Mongolia (b; modified after Xiao et al., 2003)
图 2 白云鄂博地区地质简图
据内蒙古自治区地质调查院, 2003, 内蒙古1∶25万白云鄂博幅（K49C003002）区域地质调查报告修改
Fig. 2. Simplified geological map of Bayan Obo area of the Bainaimiao arc belt
图 3 白云鄂博地区沉积岩样品野外和镜下照片
a.石英砂岩野外照片，20BY04；b.长石石英砂岩野外照片，20BY12；c.石英砂岩镜下照片，20BY04；d.长石石英砂岩镜下照片，20BY12. Bt.黑云母；Kfs.钾长石；L.岩屑；Mc.微斜长石；Pl.斜长石；Qz.石英
Fig. 3. Field photos and photomicrograph of sediments in the Bayan Obo
图 4 锆石阴极发光图像
a.石英砂岩，20BY04；b.长石石英砂岩，20BY12；红色圆圈为测年点位；黄色圆圈为Hf同位素测点
Fig. 4. Cathodoluminescence (CL) images of representative zircons dated in this study
图 5 碎屑锆石U-Pb年龄谐和图（左列）和碎屑锆石U-Pb年龄谱（右列）
Fig. 5. Detrital zircon U-Pb concordia diagrams of sediments (left columns) and detrital zircon U-Pb age spectra (right columns)
图 6 εHf(t) vs. 锆石U-Pb年龄
白乃庙岛弧带，据Zhang et al.（2014）、Chen et al.（2016）、Liu et al.（2020）、Zhou et al.（2021）；华北克拉通，据Zhang et al.（2014）、Zhou et al.（2021）
Fig. 6. εHf(t) vs. zircon U-Pb age
图 7 锆石U-Pb年龄谱对比
a.华北克拉通北缘，据Rojas-Agramonte et al.（2011）、Zhou et al.（2018b），20BY04；b.白乃庙岛弧带，据Zhang et al.（2014）、Chen et al.（2016）、Zhou et al.(2018a, 2021)、Tang et al.（2021）；c.西别河组，据Ma et al.（2019）、Chen et al.（2020）、Tang et al.（2021）；d.查干哈布组，本次研究，20BY12
Fig. 7. Comparison of detrital zircon U-Pb age spectra diagrams for sediments and volcanic rocks in the Bayan Obo area
-
Andersen, T., 2002. Correction of Common Lead in U–Pb Analyses that do not Report 204Pb. Chemical Geology, 192(1-2): 59-79. https://doi.org/10.1016/S0009-2541(02)00195-X Blichert-Toft, J., Albarède, F., 1998. The Lu–Hf Isotope Geochemistry of Chondrites and the Evolution of the Mantle-Crust System. Earth and Planetary Science Letters, 154(1-4): 349. https://doi.org/10.1016/S0012-821X(97)00040-X Chen, Y., Zhang, Z. C., Li, K., et al., 2016. Detrital Zircon U–Pb Ages and Hf Isotopes of Permo-Carboniferous Sandstones in Central Inner Mongolia, China: Implications for Provenance and Tectonic Evolution of the Southeastern Central Asian Orogenic Belt. Tectonophysics, 671: 183-201. https://doi.org/10.1016/j.tecto.2016.01.018 Chen, Y., Zhang, Z. C., Qian, X. Y., et al., 2020. Early to Mid-Paleozoic Magmatic and Sedimentary Records in the Bainaimiao Arc: An Advancing Subduction-Induced Terrane Accretion along the Northern Margin of the North China Craton. Gondwana Research, 79: 263-282. https://doi.org/10.1016/j.gr.2019.08.012 Chen, Y. C., Zhang, J. E., Tian, Z. H., et al., 2021. The Structure of Suture in Orogenic Belts and Its Tectonic Implications. Acta Petrologica Sinica, 37(8): 2324-2338 (in Chinese with English abstract). doi: 10.18654/1000-0569/2021.08.05 Dickinson, W. R., Gehrels, G. E., 2009. Use of U–Pb Ages of Detrital Zircons to Infer Maximum Depositional Ages of Strata: A Test Against a Colorado Plateau Mesozoic Database. Earth and Planetary Science Letters, 288(1-2): 115-125. https://doi.org/10.1016/j.epsl.2009.09.013 Dobretsov, N. L., Berzin, N. A., Buslov, M. M., 2010. Opening and Tectonic Evolution of the Paleo-Asian Ocean. International Geology Review, 37(4): 335-360. https://doi.org/10.1080/00206819509465407 Feng, L. X., Zhang, Z. C., Han, B. F., et al., 2013. LA-ICP-MS Zircon U-Pb Ages of Granitoids in Darhan Muminggan Joint Banner, Inner Mongolia, and Their Geological Significance. Geological Bulletin of China, 32(11): 1737-1748 (in Chinese with English abstract). doi: 10.3969/j.issn.1671-2552.2013.11.006 Hou, Q. L., Guo, Q. Q., Fang, A. M., 2018. Discussions on Some Basic Problems in the Research of Orogenic Belts Concerning on Flysch and Molasse. Acta Petrologica Sinica, 34(7): 1885-1896 (in Chinese with English abstract). Jackson, S. E., Pearson, N. J., Griffin, W. L., et al., 2004. The Application of Laser Ablation-Inductively Coupled Plasma-Mass Spectrometry to in Situ U–Pb Zircon Geochronology. Chemical Geology, 211(1-2): 47-69. https://doi.org/10.1016/j.chemgeo.2004.06.017 Jahn, B. M., Windley, B. F., Natal'in, B., et al., 2004. Phanerozoic Continental Growth in Central Asia. Journal of Asian Earth Sciences, 23(5): 599-603. https://doi.org/10.1016/S1367-9120(03)00124-X Jia, H. Y., Baoyinwuliji, Zhang Y. Q., 2003. Characteristics and Tectonic Significance of the Wude Suture Zone in Northern Damaoqi, Inner Mongolia. Journal of Chengdu University of Technology (Science & Technology Edition), 30(1): 30-34 (in Chinese with English abstract). doi: 10.3969/j.issn.1671-9727.2003.01.005 Jian, P., Liu, D. Y., Kröner, A., et al., 2008. Time Scale of an Early to Mid-Paleozoic Orogenic Cycle of the Long-Lived Central Asian Orogenic Belt, Inner Mongolia of China: Implications for Continental Growth. Lithos, 101(3-4): 233-259. https://doi.org/10.1016/j.lithos.2007.07.005 Li, J. L., Sun, S., Hao, J., et al., 1999. Time Limit of Collision Event of Collision Orogens. Acta Petrologica Sinica, 15(2): 315-320 (in Chinese with English abstract). Liu, M., Lai, S. C., Zhang, D., et al., 2020. Constructing the Latest Neoproterozoic to Early Paleozoic Multiple Crust-Mantle Interactions in Western Bainaimiao Arc Terrane, Southeastern Central Asian Orogenic Belt. Geoscience Frontiers, 11(5): 1727-1742. https://doi.org/10.1016/j.gsf.2020.01.012 Ma, S. X., Wang, Z. Q., Zhang, Y. L., et al., 2019. Bainaimiao Arc as an Exotic Terrane along the Northern Margin of the North China Craton: Evidences from Petrography, Zircon U–Pb Dating, and Geochemistry of the Early Devonian Deposits. Tectonics, 38(8): 2606-2624. https://doi.org/10.1029/2018TC005426 Naylor, M., Sinclair, H. D., 2008. Pro- vs. Retro-Foreland Basins. Basin Research, 20(3): 285-303. https://doi.org/10.1111/j.1365-2117.2008.00366.x Rocchi, S., Bracciali, L., Di Vincenzo, G., et al., 2011. Arc Accretion to the Early Paleozoic Antarctic Margin of Gondwana in Victoria Land. Gondwana Research, 19(3): 594-607. https://doi.org/10.1016/j.gr.2010.08.001 Rojas-Agramonte, Y., Kröner, A., Demoux, A., et al., 2011. Detrital and Xenocrystic Zircon Ages from Neoproterozoic to Palaeozoic Arc Terranes of Mongolia: Significance for the Origin of Crustal Fragments in the Central Asian Orogenic Belt. Gondwana Research, 19(3): 751-763. https://doi.org/10.1016/j.gr.2010.10.004 Scherer, E., Münker, C., Mezger, K., 2001. Calibration of the Lutetium-Hafnium Clock. Science, 293(5530): 683-687. https://doi.org/10.1126/science.1061372 Şengör, A. M. C., Natal'in, B. A., Burtman, V. S., 1993. Evolution of the Altaid Tectonic Collage and Palaeozoic Crustal Growth in Eurasia. Nature, 364(6435): 299-307. https://doi.org/10.1038/364299a0 Song, D. F., Xiao, W. J., Windley, B. F., et al., 2021. Closure of the Paleo-Asian Ocean in the Middle-Late Triassic (Ladinian-Carnian): Evidence from Provenance Analysis of Retroarc Sediments. Geophysical Research Letters, 48(14): e2021GL094276. https://doi.org/10.1029/2021gl094276 Tang, J. Z., Zhang, Z. C., Xue, J. Z., et al., 2021. Permo-Carboniferous Provenance Shifts at the Northern Margin of the North China Craton and Their Tectonic Implications: Detrital Zircon U–Pb–Hf Records from Central Inner Mongolia. Gondwana Research, 95: 134-148. https://doi.org/10.1016/j.gr.2021.03.012 Vervoort, J. D., Blichert-Toft, J., 1999. Evolution of the Depleted Mantle: Hf Isotope Evidence from Juvenile Rocks through Time. Geochimica et Cosmochimica Acta, 63(3-4): 533-556. https://doi.org/10.1016/S0016-7037(98)00274-9 Wang, X. A., Li, S. C., Xu, Z. Y., et al., 2016. Neoarchaean Quartz Diorites in the Jiefangyingzi Area, Central Asian Orogenic Belt: Geological and Tectonic Significance. International Geology Review, 58(3): 358-370. https://doi.org/10.1080/00206814.2015.1077480 Windley, B. F., Xiao, W. J., 2018. Ridge Subduction and Slab Windows in the Central Asian Orogenic Belt: Tectonic Implications for the Evolution of an Accretionary Orogeny. Gondwana Research, 61: 73-87. https://doi.org/10.1016/j.gr.2018.05.003 Wu, C., Liu, C. F., Zhu, Y., et al., 2016. Early Paleozoic Magmatic History of Central Inner Mongolia, China: Implications for the Tectonic Evolution of the Southeast Central Asian Orogenic Belt. International Journal of Earth Sciences, 105(5): 1307-1327. https://doi.org/10.1007/s00531-015-1250-7 Wu, F. Y., Yang, J. H., Wilde, S. A., 2007. Detrital Zircon U–Pb and Hf Isotopic Constraints on the Crustal Evolution of North Korea. Precambrian Research, 159(3-4): 155-177. https://doi.org/10.1016/j.precamres.2007.06.007 Xiao, Q. H., Liu Y., Xu, L. Q., et al., 2020. Preliminary Study on Geology and Mineralization of the Bayan Obo Ocean Plate. Earth Science, 45(7): 2258-2278 (in Chinese with English abstract). Xiao, W. J., Song, D. F., Windley, B. F., et al., 2020. Accretionary Processes and Metallogenesis of the Central Asian Orogenic Belt: Advances and Perspectives. Science China Earth Sciences, 63(3): 329-361. https://doi.org/10.1007/s11430-019-9524-6 Xiao, W. J., Windley, B. F., Hao, J., et al., 2003. Accretion Leading to Collision and the Permian Solonker Suture, Inner Mongolia, China: Termination of the Central Asian Orogenic Belt. Tectonics, 22(6): 1069. https://doi.org/10.1029/2002tc001484 Xiao, W. J., Windley, B. F., Sun, S., et al., 2015. A Tale of Amalgamation of Three Permo-Triassic Collage Systems in Central Asia: Oroclines, Sutures, and Terminal Accretion. Annual Review of Earth and Planetary Sciences, 43(1): 477-507. https://doi.org/10.1146/annurev-earth-060614-105254 Xu, B., Charvet, J., Chen, Y., et al., 2013. Middle Paleozoic Convergent Orogenic Belts in Western Inner Mongolia (China): Framework, Kinematics, Geochronology and Implications for Tectonic Evolution of the Central Asian Orogenic Belt. Gondwana Research, 23(4): 1342-1364. https://doi.org/10.1016/j.gr.2012.05.015 Yan, Z., Wang, Z. Q., Yan, Q. R., et al., 2018. Identification and Reconstruction of Tectonic Archetype of the Sedimentary Basin within the Orogenic Belt Developed along Convergent Margin. Acta Petrologica Sinica, 34(7): 1943-1958 (in Chinese with English abstract). Zhang, Q. Q., 2021. Geological Records of the Late Silurian-Devonian Arc-Continent Collision in the Northern Margin of the North China Block and Craton-Orogen Boundary (Dissertation). Chinese Academy of Geological Sciences, Beijing (in Chinese with English abstract). Zhang, S. H., Zhao, Y., Li, X. H., et al., 2017. The 1.33-1.30 Ga Yanliao Large Igneous Province in the North China Craton: Implications for Reconstruction of the Nuna (Columbia) Supercontinent, and Specifically with the North Australian Craton. Earth and Planetary Science Letters, 465: 112-125. https://doi.org/10.1016/j.epsl.2017.02.034 Zhang, S. H., Zhao, Y., Ye, H., et al., 2014. Origin and Evolution of the Bainaimiao Arc Belt: Implications for Crustal Growth in the Southern Central Asian Orogenic Belt. Geological Society of America Bulletin, 126(9-10): 1275-1300. https://doi.org/10.1130/B31042.1 Zhang, W., 2007. SHRIMP Dating of Early Paleozoic and Early Mesozoic Adakitic Plutons from Damaoqi, Inner Mongolia (Dissertation). Chinese Academy of Geological Sciences, Beijing (in Chinese with English abstract). Zhang, Y. P., Su, Y. Z., Li, J. C., 2010. Regional Tectonics Significance of the Late Silurian Xibiehe Formation in Central Inner Mongolia, China. Geological Bulletin of China, 29(11): 1599-1605 (in Chinese with English abstract). doi: 10.3969/j.issn.1671-2552.2010.11.001 Zhao, G. C., Cawood, P. A., Li, S. Z., et al., 2012. Amalgamation of the North China Craton: Key Issues and Discussion. Precambrian Research, 222-223: 55-76. https://doi.org/10.1016/j.precamres.2012.09.016 Zhou, H., 2019. The Paleozoic Tectonic Evolution of the West Segment of the Northern Margin of the North China Craton: Implication from the Magmatic Evidence of Damao Region (Dissertation). Northwest University, Xi'an (in Chinese with English abstract). Zhou, H., Zhao, G. C., Han, Y. G., et al., 2018a. Geochemistry and Zircon U–Pb–Hf Isotopes of Paleozoic Intrusive Rocks in the Damao Area in Inner Mongolia, Northern China: Implications for the Tectonic Evolution of the Bainaimiao Arc. Lithos, 314-315: 119-139. https://doi.org/10.1016/j.lithos.2018.05.020 Zhou, H., Zhao, G. C., Han, Y. G., et al., 2021. Tectonic Origin of the Bainaimiao Arc Terrane in the Southern Central Asian Orogenic Belt: Evidence from Sedimentary and Magmatic Rocks in the Damao Region. GSA Bulletin, 133(3-4): 802-818. https://doi.org/10.1130/b35496.1 Zhou, Z. G., Hu, M. M., Wu, C., et al., 2018b. Coupled U–Pb Dating and Hf Isotopic Analysis of Detrital Zircons from Bayan Obo Group in Inner Mongolia: Constraints on the Evolution of the Bayan Obo Rift Belt. Geological Journal, 53(6): 2649-2664. https://doi.org/10.1002/gj.3102 陈艺超, 张继恩, 田忠华, 等, 2021. 造山带中缝合面结构特征与构造意义. 岩石学报, 37(8): 2324-2338. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB202108005.htm 冯丽霞, 张志诚, 韩宝福, 等, 2013. 内蒙古达茂旗花岗岩类LA-ICP-MS锆石U-Pb年龄及其地质意义. 地质通报, 32(11): 1737-1748. doi: 10.3969/j.issn.1671-2552.2013.11.006 侯泉林, 郭谦谦, 方爱民, 2018. 造山带研究中有关复理石和磨拉石的几个问题. 岩石学报, 34(7): 1885-1896. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201807005.htm 贾和义, 宝音乌力吉, 张玉清, 2003. 内蒙古达茂旗乌德缝合带特征及大地构造意义. 成都理工大学学报(自然科学版), 30(1): 30-34. doi: 10.3969/j.issn.1671-9727.2003.01.005 李继亮, 孙枢, 郝杰, 等, 1999. 碰撞造山带的碰撞事件时限的确定. 岩石学报, 15(2): 315-320. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB902.019.htm 肖庆辉, 刘勇, 许立权, 等, 2020. 白云鄂博洋板块地质与成矿作用初探. 地球科学, 45(7): 2258-2278. doi: 10.3799/dqkx.2020.191 闫臻, 王宗起, 闫全人, 等, 2018. 造山带汇聚板块边缘沉积盆地的鉴别与恢复. 岩石学报, 34(7): 1943-1958. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201807009.htm 张琪琪, 2021. 华北地块北缘晚志留世‒泥盆纪弧‒陆碰撞的地质记录及克拉通与造山带边界(博士学位论文). 北京: 中国地质科学院. 张维, 2007. 内蒙古达茂旗地区早古生代和早中生代埃达克深成岩SHRIMP年代学(硕士学位论文). 北京: 中国地质科学院. 张允平, 苏养正, 李景春, 2010. 内蒙古中部地区晚志留世西别河组的区域构造学意义. 地质通报, 29(11): 1599-1605. https://www.cnki.com.cn/Article/CJFDTOTAL-ZQYD201011002.htm 周海, 2019. 华北克拉通北缘西段古生代构造演化: 来自达茂地区岩浆岩的证据(博士学位论文). 西安: 西北大学. -
