Characteristics of Paleogene Source Rocks and Fine Oil-Source Correlation in Liaohe Western Depression
-
摘要: 为了明确辽河西部凹陷南北部烃源岩条件差异、查明凹陷内不同地区原油来源，采用TOC、岩石热解、Ro、饱和烃色谱-质谱等方法对不同洼陷烃源岩及原油特征分析并进行精细油源对比. 结果表明，西部凹陷沙四段烃源岩在北部发育（厚约700 m）、有机质丰度高、但成熟度较低（Ro < 0.5%），有机质以陆源高等植物为主，混有少量低等水生生物，沉积于偏还原的咸水-微咸水环境；沙三段及沙一段烃源岩在凹陷南部更为发育，丰度高且成熟度高，有机质以低等水生生物为主，沉积于偏氧化的淡水环境. 结果表明，北部原油来自于沙四段烃源岩；中部原油主要来自于沙三段烃源岩（冷家地区原油存在少量沙四段原油混入），而南部原油主要来自于沙三段和沙一段烃源岩.Abstract: In order to clarify the differences in source rock characteristics and investigate the source of crude oil in different areas in the Liaohe Western Depression, the TOC, rock pyrolysis, Ro, and saturated hydrocarbon gas chromatography-mass spectrometry (GC-MS) are adopted to analyze the characteristics of source rock and crude oil, and the fine oil-source correlation is carried out. Results indicate that the Es4 source rock of Liaohe Western Depression is developed in the north (about 700 m), with high organic matter abundance but low maturity (Ro < 0.5%). The organic matter of Es4 source rock was dominated by terrestrial higher plants, mixed with a small amount of lower aquatic organisms, and the sedimentary environment was a partially reduced saline-brackish water environment; The Es3 and Es1 source rocks of Liaohe Western Depression are developed in the south with high abundance and maturity. The organic matter was mainly derived from aquatic organisms and deposited in the oxidized freshwater environment. Results show that the crude oil in the northern part comes from the Es4 source rock. The crude oil in the central part mainly comes from the Es3 source rock (the crude oil in the Lengjia area comes from the Es4 and Es3 source rock). The crude oil in the southern part comes from the Es3 and Es1 source rock.
-
图 1 辽河西部凹陷地层及构造特征综合示意图
修改自冷济高等(2008)
Fig. 1. Comprehensive map of structural and stratigraphic characteristics in Liaohe Western Depression
图 2 辽河西部凹陷沙河街组烃源岩厚度分布图
Fig. 2. Thickness distribution of source rocks in Shahejie Formation, Liaohe Western Depression
图 3 辽河西部凹陷沙河街组烃源岩有机质丰度评价（SY/T 5735-1995）
Fig. 3. Evaluation of organic matter abundance in Shahejie Formation, Liaohe Western Depression(SY/T 5735-1995)
图 4 辽河西部凹陷沙河街组烃源岩有机质类型判别图
修改自蔡来星等（2020）
Fig. 4. Organic matter types of source rocks in Shahejie Formation, Liaohe Western Depression
图 5 辽河西部凹陷各生烃洼陷沙河街组烃源岩Ro随深度变化关系
数据来源于中国石油辽河油田勘探开发研究院
Fig. 5. Relationship between Ro and depth of Shahejie Formation in different sags of Liaohe Western Depression
图 6 辽河西部凹陷沙河街组烃源岩气相色谱特征
Fig. 6. GC characteristics of source rocks in Shahejie Formation, Liaohe Western Depression
图 7 辽河西部凹陷各生烃洼陷沙河街组烃源岩Pr/nC17和Ph/nC18关系
Fig. 7. Relationship between Pr/nC17 and Ph/nC18 of source rocks in Shahejie Formation, Liaohe Western Depression
图 8 辽河西部凹陷沙河街组烃源岩甾烷、萜烷特征
Fig. 8. Characteristics of steranes and terpanes of source rocks in Shahejie Formation, Liaohe Western Depression
图 9 辽河西部凹陷原油物性特征
Fig. 9. Histogram of physical property of crude oil in Liaohe Western Depression
图 10 辽河西部凹陷不同油区沙河街组原油族组成特征
Fig. 10. Group composition of crude oil in different oil fields in Liaohe Western Depression
图 11 辽河西部凹陷沙河街组原油色谱-质谱特征
Fig. 11. GC-MS characteristics of crude oil in Shahejie Formation, Liaohe Western Depression
图 12 辽河西部凹陷沙河街组原油Pr/nC17和Ph/nC18相关性
Fig. 12. Relationship between Pr/nC17 and Ph/nC18 of crude oil in Shahejie Formation, Liaohe Western Depression
图 13 辽河西部凹陷沙河街组油-岩正构烷烃分布曲线对比图
Fig. 13. Correlation of n-alkanes between crude oil and source rock in Shahejie Formation, Liaohe Western Depression
图 14 辽河西部凹陷沙河街组油-岩规则甾烷含量特征对比
Fig. 14. Triangle diagram of regular sterane content of crude oil and source rocks in Shahejie Formation, Liaohe Western Depression
图 15 辽河西部凹陷沙河街组油-岩萜烷特征对比
Fig. 15. Terpane characteristics of crude oil and source rocks in Shahejie Formation, Liaohe Western Depression
图 16 辽河西部凹陷沙河街组沿凹陷北东向展布剖面油源对比示意图
Fig. 16. Profile of oil-source correlation in Shahejie Formation, Liaohe Western Depression
表 1 辽河西部凹陷沙河街组烃源岩地化分析数据表
Table 1. Geochemical characteristics of source rocks in Shahejie Formation, Liaohe Western Depression
生烃洼陷 牛心坨-台安洼陷 盘山-陈家洼陷 清水洼陷 层位地化参数 沙四段 沙三段 沙四段 沙三段 沙四段 沙三段 沙一段 TOC (%) 0.13~7.14 0.02~1.21 0.82~9.2 0.12~5.43 1.16~1.29 0.67~4.06 0.26~4.71 2.23 (72) 0.18 (43) 5.15 (47) 3.34 (29) 1.81 (6) 1.82 (70) 1.85 (24) S1+S2 (mg/g) 0.04~65.86 0.04~1.22 2.22~66.91 7.68~37.77 0.5~1.6 0.82~11.97 0.12~32.47 11.16 (71) 0.15 (18) 27.86 (47) 16.27 (29) 0.85 (6) 4.36 (70) 6.16 (24) HI
(mg/g TOC)17~810 74~93 246~740 272~490 15~56 35~4.7 107~674 350 (60) 83 (2) 481 (47) 405 (29) 34 (7) 190 (71) 247 (24) Tmax(℃) 423~442 431~439 426~448℃ 425~435 446~525 429~467 420~443 432 (60) 435 (2) 437 (47) 430 (29) 460 (7) 441 (71) 433 (24) Ro (%) 0.25~0.58 0.44~1.17 0.32~1.61 0.29~0.63 0.36 (43) 0.69 (60) 0.67 (133) 0.40 (24) 显微组分
（单衍胜等，2016）腐泥组(%) (1.3~97.2)/52.8 壳质组(%) (~68)/4.8 镜质组(%) (1~97)/35.9 惰质组(%) (~87.2)/6.4 注：表中数据为$ \frac{\mathrm{最}\mathrm{小}\mathrm{值}~\mathrm{最}\mathrm{大}\mathrm{值}}{\mathrm{平}\mathrm{均}\mathrm{值}\left(\mathrm{样}\mathrm{品}\mathrm{数}\right)} $或（最小值~最大值）/平均值.
下载: 导出CSV
表 2 辽河西部凹陷沙河街组烃源岩生物标志化合物组成特征
Table 2. Biomarkers from source rocks in Liaohe Western Depression
洼陷 层位 Pr/Ph Pr/C17 Ph/C18 ααα-C29 S/(S+R) C29 ββ/(αα+ββ) C31藿烷(S/S+R) Ts/Tm γ-蜡烷/C30H ααα20RC27/C29 牛心坨-台安洼陷 Es3 0.29 0.45 1.15 0.21 0.37 0.54 0.64 0.31 0.66 Es4 0.84 1.54 2.38 0.19 0.28 0.52 0.30 0.22 0.94 盘山-陈家洼陷 Es3 1.36 0.78 0.61 0.26 0.30 0.37 / 0.05 0.74 Es4 0.62 0.76 1.35 0.25 / 0.54 / 0.37 0.40 清水洼陷 Es1 0.86 0.65 0.71 0.23 0.20 0.57 0.25 0.29 1.31 Es3 1.55 1.11 1.06 0.51 0.46 0.6 0.96 0.1 0.74
下载: 导出CSV
表 3 辽河西部凹陷原油甾萜类生物标志化合物组成特征
Table 3. Biomarkers of sterane and terpane from crude oil in Liaohe Western Depression
油区 γ-蜡烷/C30
藿烷ααα-C29 S/
(S+R)C29 ββ/
(αα+ββ)Ts/Tm C31藿烷
(S/S+R)ααα-20R
C27/C29规则甾
烷/藿烷（孕甾烷+升孕甾烷）/ααα-
C2920R牛心坨 0.17 0.22 0.25 0.36 0.55 0.71 0.83 0.02 高升 0.29 0.25 0.23 0.26 0.55 0.50 1.12 0 冷家 0.14 0.36 0.32 0.46 0.56 0.60 0.52 0.06 曙光 0.27 0.36 0.35 0.58 0.57 0.62 0.39 0.13 兴隆台 0.11 0.42 0.41 1.64 0.58 0.80 0.34 0.30 双台子-双南 0.22 0.38 0.41 1.08 0.58 0.89 0.39 0.29 欢喜岭 0.23 0.36 0.35 1.18 0.57 0.73 0.31 0.17 小洼 0.26 0.44 0.38 0.66 0.56 0.78 0.40 0.15
下载: 导出CSV
-
Allen, M. B., Macdonald, D. I. M., Xun, Z., et al., 1997. Early Cenozoic Two-Phase Extension and Late Cenozoic Thermal Subsidence and Inversion of the Bohai Basin, Northern China. Marine and Petroleum Geology, 14(7/8): 951-972. https://doi.org/10.1016/s0264-8172(97)00027-5 Cai, L. X., Xiao, G. L., Dong, H. P., et al., 2020. Characteristics of Mesozoic Source Rocks and Exploration Direction of Oil and Gas in the Eastern Depression, North Yellow Sea Basin. Earth Science. 45(2): 583-601. (in Chinese with English abstract) Hao, F., Zhou, X. H., Zhu, Y. M., et al., 2010. Charging of Oil Fields Surrounding the Shaleitian Uplift from Multiple Source Rock Intervals and Generative Kitchens, Bohai Bay Basin, China. Marine and Petroleum Geology, 27(9): 1910-1926. https://doi.org/10.1016/j.marpetgeo. 2010. 07.005 doi: 10.1016/j.marpetgeo.2010.07.005 Hou, D. J., Feng, Z. H., 2011. Oil and Gas Geochemistry. Petroleum Industry Press, Beijing, 202-242+265-269. Hu, Y. J., Wang, Y. S., Huang, S. Q., et al., 2019. Petroleum Geological Conditions, Resource Potential and Exploration Direction in Liaohe Depression. Marine Oil and Gas Geology, 24: 43-54 (in Chinese with English abstract). Huang, D. F., Li, J. C., Zhang, D. J., et al., 1984. Evolution and Hydrocarbon Generation Mechanism of Continental Organic Matter. Petroleum Industry Press, Beijing (in Chinese with English abstract). Leng, J. G., Pang, X. Q., Li X. G., et al., 2008. Main Controlling Factors of Oil and Gas Accumulation in the Western Sag of Liaohe Fault Depression. Journal of Paleogeography, 473-480 (in Chinese with English abstract). Li, M. J., Ren, P., Hu, L. G., et al., 2000. Application of Carbon Isotope Type Curve in Oil Source Correlation in Liaohe Basin. Special Oil and Gas Reservoirs, 02: 11-12 (in Chinese with English abstract). Li, M. G., Qi, J. F., Tong, H. M., et al., 2010. Cenozoic Fault Structural Characteristics and Hydrocarbon Accumulation in Western Liaohe Sag. Petroleum Exploration and Development, 37: 281-288 (in Chinese with English abstract). Li, S. M., Pang, X. Q., Gao, X. Z., et al., 2008. Genetic Mechanism of Heavy Oil in Western Liaohe Depression. Chinese Science (Series D: Geoscience), S1: 138-149 (in Chinese). Li, X. G., 2021. Reservoir Forming Conditions and Key Exploration and Development Technologies of Heavy Oil in Huanxiling oilfield, Liaohe depression. Journal of Petroleum, 42 (4): 541-560 (in Chinese with English abstract). Liu, G. D., Zhang, H. F., 2009. Petroleum Geology. Petroleum Industry Press, Beijing (in Chinese). Liu, L. F., Jiang, Z. X., Zhou, X. M., et al., 2010. Analysis of Hydrocarbon Generation Potential Recovery and Hydrocarbon Expulsion Characteristics of Source Rocks: Taking Paleogene Source Rocks in Western Liaohe Sag as an Example. Petroleum Exploration and Development, 37(3): 378-384 (in Chinese with English abstract). Liu, X. Y., Chen, H. H., Xiao, X. W., 2022. Overpressure Evolution Recorded in Fluid Inclusions in the Dongpu Depression, Bohai Bay Basin, North China. Journal of Earth Science, 33(4): 916-932. https://doi.org/10.1007/s12583-020-1375-x Lu, S. F., Zhang, M., 2010. Oil and Gas Geochemistry. Beijing: Petroleum Industry Press (in Chinese). Lu, S. N., Li, W. M., Gao, J. J., et al., 1986. The Biological Markers in the Crude Oil and Source Rocks of Lower Tertiary from Western Depression, Liaohe Basin. Earth Science, 11(3): 295-302 (in Chinese). Mao, J. L., Jing, T. Y., Han, X., et al. 2016. Petrological Types and Organic Geochemical Characteristics of High-Quality Shale Intervals in Western Liaohe Sag. Geoscience Front, 23 (1): 185-194 (in Chinese with English abstract). Moldowan, J. M., Seifert, W. K., Gallegos, E. J., 1985. Relationship between Petroleum Composition and Depositional Environment of Petroleum Source Rocks. AAPGBulletin. 69: 1255-1268. Pang, X. Q., 1995. Theory and Application of Hydrocarbon Expulsion Threshold Control. Petroleum Industry Press, Beijing (in Chinese). Peters, K. E., 1986. Guidelines for Evaluating Petroleum Source Rock Using Programmed Pyrolysis. AAPG Bulletin, 70: 318-329. https://doi.org/10.1306/94885688-1704-11d7-8645000102c1865d Peters, K. E., Moldowan, J. M., 1993. The Biomarker Guide-Interpreting Molecular Fossils in Petroleum and Ancient Sediments. Prentic Hall, New Jersey. Peters, K. E., Walters, C. C., Moldowan, J. M., 2005. The Biomarker Guide: Volume 2, Biomarkers and Isotopes in Petroleum Systems and Earth History (Ⅱ). Cambridge University Press, Cambridge. Riediger, C., Carrelliand, G., Zonneveld, J. P., 2004. Hydrocarbon Source Rock Characterization and Thermal Maturity of the Upper Triassic Baldonnel and Pardonet Formations, Northeastern British Columbia, Canada. Bulletin of Canadian Petroleum Geology, 52(4): 277-301. https://doi.org/10.2113/52.4.277 Shan, J. F., Gao, X. F., Li, Y. J., et al, 2007. Oil and Gas Resource Potential and Key Zone Selection in Liaohe Oil Region. Special oil and Gas Reservoirs, 2: 18-21 (in Chinese with English abstract). Shan, Y. S., 2013. Accumulation Conditions and Distribution of Paleogene Shale Oil and Gas in Liaohe Depression (Dissertation), China University of Geosciences, Beijing, 142 (in Chinese with English abstract). Shan, Y. S., Zhang, J. C., Li, X. G., et al., 2016. Enrichment Conditions and Distribution Model of Continental Shale Oil and Gas in Western Liaohe Sag of Bohai Bay Basin. Experimental Petroleum Geology, 38: 496-501 (in Chinese with English abstract). Wang, Y. S., Hu, Y. J., Huang, S. Q., et al., 2018. Natural Gas Geological Conditions, Resource Potential and Exploration Direction in Liaohe Depression, Bohai Bay Basin. Natural Gas Geoscience, 29: 1422-1432 (in Chinese with English abstract). Yin, J., Wang, Q., Hao, F., 2017. Palaeolake Environment and Depositional Model of Source Rocks of the Lower Submember of Sha1 in Raoyang Sag, Bohai Bay Basin. Earth Science, 42(7): 1209-1222 (in Chinese with English abstract). Zhao, J. Z., Meng, X. G., Han, Z. H., 2020. Near-Source Hydrocarbon Accumulation: Geochemical Evidence of Lacustrine Crude Oil from the Member 6 of Yanchang Formation, Eastern Margin of Ordos Basin. Acta Petrolei Sinica, 41(12): 1513-1526 (in Chinese with English abstract). doi: 10.7623/syxb202012006 Zhu, F. B., 2002. Study on Source Rock Characteristics and Distribution Law of Low Mature Oil in Western Sag of Liaohe Basin. Earth Science, 1: 25-29 (in Chinese with English abstract). Zhu, F. B., Zhou, H., 2018. Biomarker Types of Crude Oil in the Western Depression of Liaohe Basin and Their Geochemical Significance. Earth Science, 43 (2): 594-598 (in Chinese with English abstract). 蔡来星, 肖国林, 董贺平, 等, 2020. 北黄海盆地东部坳陷中生界烃源岩特征及其指示的油气勘探方向. 地球科学, 45(2): 583-601. doi: 10.3799/dqkx.2019.004 侯读杰, 冯子辉, 2011. 油气地球化学. 北京: 石油工业出版社, 202-242+265-269. https://cdmd.cnki.com.cn/Article/CDMD-11415-1021167100.htm 胡英杰, 王延山, 黄双泉, 等, 2019. 辽河坳陷石油地质条件、资源潜力及勘探方向: 海相油气地质, 24: 43-54. https://www.cnki.com.cn/Article/CJFDTOTAL-HXYQ201903002.htm 黄弟藩, 李晋超, 张大江, 等, 1984. 陆相有机质的演化和成烃机理. 北京: 石油工业出版社. 冷济高, 庞雄奇, 李晓光, 等, 2008. 辽河断陷西部凹陷油气成藏主控因素. 古地理学报, 473-480. doi: 10.7605/gdlxb.2008.05.005 李美俊, 任平, 胡礼国, 等, 2002. 碳同位素类型曲线在辽河盆地油源对比中的应用. 特种油气藏, 2: 11-12. https://www.cnki.com.cn/Article/CJFDTOTAL-TZCZ200002003.htm 李明刚, 漆家福, 童亨茂, 等, 2010. 辽河西部凹陷新生代断裂构造特征与油气成藏: 石油勘探与开发, 37: 281-288. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK201003005.htm 李素梅, 庞雄奇, 高先志, 等, 2008. 辽河西部凹陷稠油成因机制. 中国科学(D辑: 地球科学). S1: 138-149. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK2008S1017.htm 李晓光, 2021. 辽河坳陷欢喜岭油田稠油成藏条件及勘探开发关键技术. 石油学报, 42(4): 541-560. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB202104010.htm 刘立峰, 姜振学, 周新茂, 等, 2010. 烃源岩生烃潜力恢复与排烃特征分析——以辽河西部凹陷古近系烃源岩为例. 石油勘探与开发, 37(3): 378-384. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK201003020.htm 柳广弟, 张厚福, 2009. 石油地质学. 北京: 石油工业出版社. 刘晓晶, 谢庆宾, 徐翔, 等, 2015. 辽河盆地东部凹陷古近系沙河街组层序地层及沉积相研究. 东北石油大学学报, 39(6), 1-11+13. https://www.cnki.com.cn/Article/CJFDTOTAL-DQSY201506002.htm 卢双舫, 张敏, 2010. 油气地球化学. 北京: 石油工业出版社. 卢松年, 李伟民, 郜建军, 等, 1986. 辽河盆地西部凹陷下第三系原油和生油岩的生物标记化合物研究. 地球科学—武汉地质学院学报, 11(3): 295-302. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX198603015.htm 毛俊莉, 荆铁亚, 韩霞, 等, 2016. 辽河西部凹陷优质页岩层段岩石学类型及其有机地球化学特征. 地学前缘, 23(1): 185-194. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201601020.htm 庞雄奇, 1995. 排烃门限控油气理论与应用. 北京: 石油工业出版社. 单俊峰, 高险峰, 李玉金, 等, 2007. 辽河油区油气资源潜力及重点区带选择. 特种油气藏, 2: 18-21. https://www.cnki.com.cn/Article/CJFDTOTAL-TZCZ200702005.htm 单衍胜, 2013. 辽河坳陷古近系页岩油气聚集条件与分布(博士学位论文). 北京: 中国地质大学, 142. 单衍胜, 张金川, 李晓光, 等, 2016. 渤海湾盆地辽河西部凹陷陆相页岩油气富集条件与分布模式. 石油实验地质, 38: 496-501. https://www.cnki.com.cn/Article/CJFDTOTAL-SYSD201604012.htm 王延山, 胡英杰, 黄双泉, 等, 2018. 渤海湾盆地辽河坳陷天然气地质条件、资源潜力及勘探方向. 天然气地球科学, 29: 1422-1432. https://www.cnki.com.cn/Article/CJFDTOTAL-TDKX201810004.htm 殷杰, 王权, 郝芳, 等, 2017. 渤海湾盆地饶阳凹陷沙一下亚段古湖泊环境与烃源岩发育模式. 地球科学, 42(7): 1209-1222. doi: 10.3799/dqkx.2017.098 赵靖舟, 孟选刚, 韩载华, 2020. 近源成藏——来自鄂尔多斯盆地延长组湖盆东部"边缘"延长组6段原油的地球化学证据. 石油学报, 41(12): 1513-1526. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB202012006.htm 朱芳冰, 2002. 辽河盆地西部凹陷源岩特征及低熟油分布规律研究. 地球科学, 27(1): 25-29. http://www.earth-science.net/article/id/1057 朱芳冰, 周红, 2018. 辽河盆地西部凹陷原油的生物标志物类型及其地球化学意义. 地球科学, 43(2): 594-598. doi: 10.3799/dqkx.2018.027 -
