Palynological Assemblage and Its Significance of the Lower Cretaceous Chijinbao Formation in the Zhongkouzi Basin, Beishan Area
-
摘要: 孢粉化石在确定地层时代和恢复古气候方面都具有重要指示意义.本文首次对北山地区中口子盆地下白垩统赤金堡组中段的孢粉化石进行了细致的分析，共获得孢粉56属84种，其中蕨类植物孢子含量为29.3%，裸子植物花粉含量为62.6%，被子植物花粉含量为8.1%.依据具有时代意义孢粉分子，将赤金堡组中段的地质时代厘定为早白垩世中期Hauterivian-Aptian.并划分出3个孢粉组合，底部为Ephedripites-Pterisisporites-Retitricolpites组合，中部为Classopollis-Cicatricosisporites-Tricolpites组合，上部为Triporoletes-Laricoidites组合.3个孢粉组合带从老到新分别代表南亚热带半干半湿的针叶林、灌草丛到亚热带半干旱的针叶林、灌木丛再到北亚热带半湿润针叶林植被类型，气候呈现先变干热后变湿热的特征.Abstract: Fossil spores and pollen are important indicators for stratigraphic age determination and paleoclimate recovery. In this paper, we first reported the palynological assemblage in the middle part of the Lower Cretaceous Chijinbao Formation in the Zhongkouzi basin of the Beishan area. A total of 56 genera and 84 species of spores and pollens were obtained from the deposits, including 29.3% of fern spores, 62.6% of gymnosperm pollens, and 8.1% of angiosperm pollens. Based on the significant spore and pollen components in the palynological assemblage, we assigned the middle part of the Chijinbao Formation to the middle Early Cretaceous Hauterivian-Aptian. We divided three sequences based on palynological assemblage characteristics, with Ephedripites-Pterisisporites-Retitricolpites assemblage at the bottom, Classopollis-Cicatricosisporites-Tricolpites assemblage at the middle, and Triporoletes-Laricoidites assemblage at the top. Three Palynological assemblages from old to new respectively represent the vegetation of southern subtropical semi-dry and semi-humid coniferous forests, scrubs to subtropical semi-arid coniferous forests, northern subtropical semi-humid coniferous forests. The climate shows a characteristic of first becoming dry and hot and then becoming hot and humid.
-
图 2 北山地区赤金堡组中段代表性孢粉属种(1)
Fig. 2. Representative pollen and spores (1) from the Chijinbao Formation in the Beishan area
a. Apiculatasporites delicatus; b. Calamospora breviradiata; c. Verrucosisporites ovimammus; d. Toroisporis longilaeeatratus; e. Laevigatosporites ovatus; f.Verrucosisporites microtuberosus; g. Laevigatosporites robustus; h. Polypodiisporites usmensis; i. Triporoletes tornatilis; j. Archaeoperisaccus indistinctus; k. Cyathidites punctatas; l. Polypodiaceoisporites verrucatus; m. Punctatosporites venustus; n. Cicatricosisporites pseudotripartitus; o. Zlivisporis sp.; p. Pterisisporites verrus
图 3 北山地区赤金堡组中段代表性孢粉属种(2)
Fig. 3. Representative pollen and spores (2) from the Chijinbao Formation in the Beishan area
a. Playfordiaspora crenulata; b. Baculatisporites comaumensis; c. Perinopollenites elatoides; d. Deltoidospora hallii; e. Jugella claribaculata; f. Cedripites arcuatus; g. Protoconiferus.sp; h. Protoconiferus funarius; i. Monocolpopollenites microreticulatus; j. Jiaohepollis sp.; k. Contignisporites glebulentus; l. Densoisporites velatus; m. Yichangsporitessp.
图 4 北山地区赤金堡组中段代表性孢粉属种(3)
Fig. 4. Representative pollen and spores (3) from the Chijinbao Formation in the Beishan area
a. Abietineaepollieites cembraeformis; b、e、h. Piceaepollenites alatus; c. Psophosphaera minor; d. Piceapollis tobolicus; f. Tsugaepollenites sp.; g. Keteleeriaepollenites davidianaeformis; i. Exesipollenites pseudotriletes; j. Taxodiaceaepollenites bockwitzensis; k. Ephedripites megafusiformis
图 5 北山地区赤金堡组中段代表性孢粉属种(4)
Fig. 5. Representative pollen and spores (4) from the Chijinbao Formation in the Beishan area
a. Cedripites pachydermus; b. Pinuspollenites cf.hubeiensis; c. Tsugaepollenites cf.minimus; d. Podocarpidites piciformis; e. Podocarpidites elongatus; f. Abietineaepollenites microalatus cf.major; g. Podocarpidites andiniformis; h. Podocarpidites podocanpoidites; i. Cedripites deodariformis; j. Taxodiaceaepollenites cf.hiatus; k. Bennettiteaepillenites cf.chenxianensis; l. Ephedripites(Distachyapites)major; m. Tsugaepollenites viridifluminpites; n. Taxodiaceaepollenites hiatus
图 6 北山地区赤金堡组中段代表性孢粉属种(5)
Fig. 6. Representative pollen and spores (5) from the Chijinbao Formation in the Beishan area
a. Parcisporites annylatus; b. Araucariacites austrilis; c. Potonieisporites novicus; d. Parcusoirutes cf.apertus; e. Abietineaepollenites microalatus cf.minor; f. Podocarpidites unicus; g. Podocarpidites andiniformis; h. Cedripites medius; i. Pinuspollenites labdacus cf.minitus; j. Pinuspollenites labdacus cf.maximus; k. Classopollis classoides
图 7 北山地区赤金堡组中段代表性孢粉属种(6)
Fig. 7. Representative pollen and spores (6) from the Chijinbao Formation in the Beishan area
a. Laricoidites magnus; b. Ephedripites(Distachyapites)major; c. Tricolpites sp.; d. Ephedripites Psudotrinatus; e. Cycadopites cymbatus; f. Tsugaepollenites verruspinus; g. Ephedripites(Distachyapites)errumenosus; h. Ephedripites fushunensis; i. Ephedripites(Distachyapites)major; j. Taxodiaceaepollenites elongatus; k. Keteleeriaepollenites dubius; l. Taxodiaceaepollenites sp.; m. Latosporites ficoides; n. Labiisporites manos; o. Ephedripites longformis; p. Ephedripites sp.; q. Ephedripites(Distachyapites)major; r. Nanlingpollis projecensis
图 8 北山地区赤金堡组中段代表性孢粉属种(7)
Fig. 8. Representative pollen and spores (7) from the Chijinbao Formation in the Beishan area
a. Magnolipollis maximus; b. Magnolipopllis oblongus; c、d. Magnolipollis grandus; e. Magnolipopllis fusiformis; f. Magnolipopllis magnolioides
图 9 北山地区赤金堡组中段主要孢粉图谱
Fig. 9. Spore-pollen spectra map of the middle section of Chijinbao Formation in Beishan area
表 1 中口子盆地白垩纪孢粉植被类型划分
Table 1. Classification of cretaceous palynological vegetation in Zhongkouzi basin
地层厚度(m) 反映各植被类型的孢粉含量（%） 植被类型 针叶林 落叶阔叶林 常绿阔叶林 灌木 草本 其他 82.5~100.5 25.78 0.00 10.65 2.18 2.81 58.58 针叶林 61.5~82.5 53.00 0.36 10.27 12.70 2.54 21.12 针叶林、灌木丛 31.5~61.5 52.88 0.00 14.51 8.47 9.41 14.84 针叶林、灌草丛
下载: 导出CSV
表 2 中口子盆地白垩纪孢粉气侯带类型划分
Table 2. Classification of cretaceous palynological vegetation types in Zhongkouzi basin
地层厚度(m) 反映各气侯带类型的孢粉含量（%） 气候带类型 热带植物 热带‒亚热带植物 亚热带植物 热带‒温带植物 温带植物 其他 82.5~100.5 7.60 7.79 19.34 0.00 1.55 63.71 北亚热带 61.5~82.5 8.66 12.61 41.67 0.00 13.41 23.65 亚热带 31.5~61.5 21.91 11.16 35.16 0.08 8.56 23.13 南亚热带
下载: 导出CSV
表 3 中口子盆地白垩纪孢粉干湿度类型划分
Table 3. Classification of pollen dry humidity types in the Cretaceous of Zhongkouzi basin
地层厚度(m) 反映各干湿度类型的孢粉含量（%） 干湿度类型 旱生 中生 湿生 沼生 其他 82.5~100.5 1.55 10.95 4.45 0.00 83.06 半湿润 61.5~82.5 14.13 18.46 9.22 10.09 48.1 半干旱 31.5~61.5 9.06 21.08 9.12 17.27 43.46 半干半湿
下载: 导出CSV
-
Batten, D. J., 1996. Upper Jurassic and Cretaceous Miospores. In: Jansonius, J., Mcgregor, D. C., eds., Palynology: Principles and Applications, No. 2. American Association of Stratigraphic Palynologists' Foundation, Dallas, 807-830. Bureau of Geology and Mineral Resources of Gansu Province, 1997. Stratigraphy (Lithostratic) of Gansu Province. China University of Geosciences Press, Wuhan (in Chinese). Bureau of Geology and Mineral Resources of Nei Mongol Autonomous Region, 1996. Stratigraphy(Lithostratic) of Nei Mongol Autonomous Region. China University of Geosciences Press, Wuhan (in Chinese). Chen, J. H., Shang, Y. K., 2015. Early Cretaceous Palynological Assemblage Sequence and Palaeoclimate Research in Zhalainuoer Coalmine, Manzhouli, Inner Mongolia. Acta Palaeontologica Sinica, 54(3): 316-341 (in Chinese with English abstract). http://www.researchgate.net/profile/Jinhui_Cheng/publication/281899026_Early_Cretaceous_palynological_assemblage_sequence_and_palaeoclimate_research_in_Zhalainuoer_Coalmine_Manzhouli_Inner_Mongolia/links/55fd1c9808aeba1d9f4f3243.pdf Cui, Y., 2015. Analysis of Palynomorph Assemblage and Palaeoclimate in the Middle Part of Yixian Formation, Yixian Basin in Western Liaoning Province (Dissertation). Northeastern University, Shenyang (in Chinese with English abstract). Ding, Q. H., Li, Y. F., Zhang, J., et al., 2010. Early Cretaceous Palynological Assemblages from the Wulangai Basin, Inner Mongolia. Acta Micropalaeontologica Sinica, 27(2): 159-172 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-WSGT201002009.htm Dörhöfer, G., Norris, G., 1977. Discrimination and Correlation of Highest Jurassic and Lowest Cretaceous Terrestrial Palynofloras in North-West Europe. Palynology, 1(1): 79-93. https://doi.org/10.1080/01916122.1977.9989151 Du, B. X., 2013. Fossil Plants from the Lower Cretaceous of Yumen, Gansu Province and Palaeoenvironmental Reconstruction (Dissertation). Lanzhou University, Lanzhou (in Chinese with English abstract). Gao, R. Q., Zhao, C. B., Qiao, X. Y., et al., 1999. Cretaceous Oil Strata Palynology from Songliao Basin. Geological Publishing House, Beijing, 206-372 (in Chinese with English abstract). Herngreen, G. F. W., Kedves, M., Rovnina, L. V., et al., 1996. Cretaceous Palynofloral Provinces: A Review. In: Jansonius, J., Mcgregor, D. C., eds., Palynology: Principles and Applications, No. 3. American Association of Stratigraphic Palynologists'Foundation, Dallas, 1157-1188. Hochuli, P. A., 1981. North Gondwanan Floral Elements in Lower to Middle Cretaceous Sediments of the Southern Alps (Southern Switzerland, Northern Italy). Review of Palaeobotany and Palynology, 35(2-4): 337-358. https://doi.org/10.1016/0034-6667(81)90116-0 Huang, J. D., Ren, D., 2008. Ephemeropsis Trisetalis Eichwald might Have been Absent in the Jehol Biota from China. Geological Review, 54(5): 602-608 (in Chinese with English abstract). doi: 10.3321/j.issn:0371-5736.2008.05.004 Hughes, N. F., McDougall, A. B., 1987. Records of Angiospermid Pollen Entry into the English Early Cretaceous Succession. Review of Palaeobotany and Palynology, 50(3): 255-272. https://doi.org/10.1016/0034-6667(87)90003-0 Jin, Y. H., Chang, L., Peng, C., et al., 2020. Geochemical Anomaly Characteristics and Uranium Deposit Prospecting Indication in Zhongkouzi Basin, Beishan Mountains. Mineral Exploration, 11(3): 546-552 (in Chinese with English abstract). Li, W. B., 1984. Early Cretaceous Sporopollen Assemblages in Jiaohe, Jilin Province. Journal of Nanjing Institute of Geology and paleontology, Chinese Academy of Sciences, 19: 67-141 (in Chinese). Li, W. B., 2001. An Earliest Cretaceous Palynological Assemblage from the Tuntianyin Formation in Antu, Jilin Province. Acta Palaeontologica Sinica, 40(4): 450-456 (in Chinese with English abstract). Lin, M. Q., 2020. Late Jurassic to Early Cretaceous Palynofloras of Northern China and Xizang and Their Palaeoenvironmental Significances (Dissertation). University of Science and Technology of China, Hefei (in Chinese with English abstract). Lin, M. Q., Li, J. G., 2019. Late Jurassic-Early Cretaceous Palynofloras in the Lhasa Block, Central Xizang, China and Their Bearing on Palaeoenvironments. Palaeogeography, Palaeoclimatology, Palaeoecology, 515: 95-106. https://doi.org/10.1016/j.palaeo.2018.05.038 Lin, M. Q., Li, J. G., Peng, J. G., 2016. Early Cretaceous Palynological Assemblages from the Third Member of the Tuchengzi Formation at Sihetun, Beipiao County, Western Liaoning Province, Northeast China and Their Implications. Acta Micropalaeontologica Sinica, 33(3): 261-271 (in Chinese with English abstract). Liu, Z. S., 2000. Early Cretaceous Sporopollen Assemblage from the Hanxia of Yumen in Gansu, Nw China. Acta Micropalaeontologica Sinica, 17(1): 73-84 (in Chinese with English abstract). Ma, Q. H., Lin, Q. B., Ye, C. H., et al., 1982. Division and Comparison of Chijinbao Formation and Xinminbao Group in the West of Jiuquan Basin. Journal of Stratigraphy, 6(2): 112-120 (in Chinese with English abstract). Qiao, S. H., Wang, C. F., 1986. Early Cretaceous sporo-Pollen Assemblages from Southern Henan, China. Acta Palaeontologica Sinica, 25(1): 97-103 (in Chinese with English abstract). Ren, W. X., 2022. Early Cretaceous Plant Fossils and Paleoenvironment of Zhongkouzi Basin in Beishan Area (Dissertation). Lanzhou University, Lanzhou (in Chinese with English abstract). Ren, W. X., Han, L., Wu, G. T., et al., 2024. Discovery of Early Cretaceous Ginkgoites in Beishan, Gansu Province: Also on Changes of Paleoatmospheric CO2 in Jurassic to Cretaceous in Gansu Province. Earth Science, 49(1): 209-223 (in Chinese with English abstract). Schrank, E., 1992. Nonmarine Cretaceous Correlations in Egypt and Northern Sudan: Palynological and Palaeobotanical Evidence. Cretaceous Research, 13(4): 351-368. https://doi.org/10.1016/0195-6671(92)90040-w Wan, C. B., 2006. Cretaceous Palynological Flora in Hailar Basin (Dissertation). Jilin University, Changchun (in Chinese with English abstract). Wei, Y., Yang, B., Xia, H. D., et al., 2021. Paleovegetation and Paleoclimate during Mid-Late Eocene in Fushun Basin. Earth Science, 46(5): 1848-1861 (in Chinese with English abstract). Wu, S. B., Bai, Y. B., 2006. Jurassic-Cretaceous Source rock-Reservoir-Cap Associations and Hydrocarbon Potentials in the Beishan Basins. Chinese Journal of Geology, 41(1): 1-9 (in Chinese with English abstract). Yang, S. H., He, H. Y., Jin, F., et al., 2020. The Appearance and Duration of the Jehol Biota: Constraint from SIMS U-Pb Zircon Dating for the Huajiying Formation in Northern China. Proceedings of the National Academy of Sciences of the United States of America, 117(25): 14299-14305. https://doi.org/10.1073/pnas.1918272117 Yu, J. X., Pu, R. G., Wu, H. Z., 1986. Sporo-Pollen Assemblages from the Upper Part of the Rehe Group, Liaoning Province. Acta Geoscientica Sinica, 7(2): 93-119 (in Chinese with English abstract). Zhang, J. L., Pan, Z. L., Chen, C., et al., 2017. Sedimentary Characteristics and Age of the Early Cretaceous Chijinbao Formation in the Sandaomingshui of Beishan Area, Inner Mongolia. Geological Survey and Research, 40(1): 29-34, 80 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-QHWJ201701005.htm Zhang, M. Z., 2014. Late Mesozoic Environment and Ecology EvolutionBased on Palynological Records from Central East Asia (Dissertation). Lanzhou University, Lanzhou (in Chinese with English abstract). Zhang, Q. R., 2009. Preliminary Summary of Cretaceous Neogene Sporopollen Fossil Assemblages in Central South China. China University of Geosciences Press, Wuhan (in Chinese). Zhang, Y. Y., 1999. The Evolutionary Succession of Cretaceous Angiosperm Pollen in China. Acta Palaeontologica Sinica, 38(4): 435-453 (in Chinese with English abstract). 甘肃省地矿局, 1997. 甘肃省岩石地层. 武汉: 中国地质大学出版社. 内蒙古自治区地质局, 1996. 内蒙古自治区岩石地层. 武汉: 中国地质大学出版社. 程金辉, 尚玉珂, 2015. 内蒙古满洲里扎赉诺尔煤矿早白垩世孢粉组合序列和古气候研究. 古生物学报, 54(3): 316-341. 崔莹, 2015. 辽西义县盆地义县组中部孢粉组合分析及古气候探讨(博士学位论文). 沈阳: 东北大学. 丁秋红, 李永飞, 张健, 等, 2010. 内蒙古乌兰盖盆地早白垩世孢粉组合. 微体古生物学报, 27(2): 159-172. 杜宝霞, 2013. 甘肃玉门早白垩世植物及古环境重建(博士学位论文). 兰州: 兰州大学. 高瑞祺, 赵传本, 乔秀云, 等, 1999. 松辽盆地白垩纪石油地层孢粉学. 北京: 地质出版社, 206-372. 黄建东, 任东, 2008. 三尾拟蜉蝣在中国热河生物群可能并不存在. 地质论评, 54(5): 602-608. 靳拥护, 常磊, 彭成, 等, 2020. 北山地区中口子盆地地球化学异常特征及其对铀矿勘查指示作用. 矿产勘查, 11(3): 546-552. 黎文本, 1984. 吉林蛟河早白垩世孢粉组合. 中国科学院南京地质古生物研究所集刊, 19: 67-141. 黎文本, 2001. 吉林安图县早白垩世屯田营组孢粉组合. 古生物学报, 40(4): 450-456. 林妙琴, 2020. 中国北方和西藏地区晚侏罗世至早白垩世孢粉植物群及其古环境意义(博士学位论文). 合肥: 中国科学技术大学. 林妙琴, 李建国, 彭俊刚, 2016. 辽西北票四合屯早白垩世土城子组三段孢粉组合及其意义. 微体古生物学报, 33(3): 261-271. 刘兆生, 2000. 甘肃玉门旱峡早白垩世孢粉组合. 微体古生物学报, 17(1): 73-84. 马其鸿, 林启彬, 叶春辉, 等, 1982. 酒泉盆地西部赤金堡组与新民堡群的划分和对比. 地层学杂志, 6(2): 112-120. 钱少华, 王从风, 1986. 河南南部早白垩世孢粉组合. 古生物学报, 25(1): 97-103. 任文秀, 2022. 北山地区中口子盆地早白垩世植物及古环境(博士学位论文). 兰州: 兰州大学. 任文秀, 韩磊, 吴光涛, 等, 2024. 甘肃北山早白垩世似银杏化石的发现: 兼论甘肃侏罗‒白垩纪古大气CO2变化. 地球科学, 49(1): 209-223. doi: 10.3799/dqkx.2022.075 万传彪, 2006. 海拉尔盆地白垩纪孢粉植物群(博士学位论文). 长春: 吉林大学. 韦一, 杨兵, 夏浩东, 等, 2021. 抚顺盆地中‒晚始新世古植被与古气候. 地球科学, 46(5): 1848-1861. doi: 10.3799/dqkx.2020.142 吴少波, 白玉宝, 2006. 北山盆地群侏罗‒白垩系生储盖特征及油气远景. 地质科学, 41(1): 1-9. 余静贤, 蒲荣干, 吴洪章, 1986. 辽西热河群上亚群孢粉组合. 中国地质科学院院报, 7(2): 93-119. 张金龙, 潘志龙, 陈超, 等, 2017. 内蒙古北山地区三道明水一带早白垩世赤金堡组沉积特征及时代厘定. 地质调查与研究, 40(1): 29-34, 80. 张明震, 2014. 晚中生代东亚大陆内部孢粉植物群记录的环境、生态演化(博士学位论文). 兰州: 兰州大学. 张清如, 2009. 中南地区白垩纪‒新近纪孢粉化石组合序列的初步总结. 武汉: 中国地质大学出版社. 张一勇, 1999. 中国白垩纪被子植物花粉的宏演化. 古生物学报, 38(4): 435-453. -
