Particle Size Fractal Characteristics of Soils in Desert-Steppe Transition Zone along the Northern Bank of Yellow River Basin in Lanzhou
-
摘要: 研究土壤粒径分形特征，可为地区土壤质量评价提供科学依据.利用分形理论分析了黄河北岸兰州段荒漠‒草原过渡带土壤粒径分形特征.（1）区域土壤颗粒主要为粉粒和极细砂粒，随荒漠化加重和土壤深度增加，土壤粗粒化，质地均匀性降低，粒径分布（PSD）频率曲线异质程度增大；（2）荒漠化加重和土壤深度增加降低了单重分形维数Dv和多重分形谱参数D1、D1/D0、D2、△α、△f；（3）Dv、D1、D2、D1/D0、△α和△f同黏粒、粉粒呈正相关，同砂粒呈负相关；黏粒、粉粒、Dv、D1、D2、D1/D0、△α和△f与荒漠化减弱程度呈正相关，砂粒与其呈负相关.土壤分形维数能反映区域土壤结构和变化，可为地区生态治理与巩固提升提供技术指导.Abstract: The study of soil grain fractal characteristics in the desert-steppe transition zone can provide a scientific basis for regional soil quality evaluation, ecological management, and restoration. In this study, we use fractal theory to analyze the soil particle composition and fractal characteristics of three vegetation types in the desert-steppe transition zone along the northern bank of the Yellow River basin in Lanzhou. (1) The soil in the study area is mainly composed of silt and very fine sand, and as desertification degree and soil depth increase, the contents of clay and silt decrease and sand contents show the opposite trend. In addition, the frequency curve of soil particle size distribution (PSD) becomes more heterogeneous, and the homogeneity of soil texture decreases. (2) The single fractal dimension (Dv), multifractal generalized dimension spectrum parameters (D1, D1/D0, and D2), and the singular spectral function parameters (△α and △f) decrease significantly with the increase of desertification degree and soil depth. (3) Dv, D1, D2, D1/D0, △α, and △f are significantly positively correlated with clay and silt contents, and significantly negatively correlated with sand contents. The clay contents, silt contents, Dv, D1, D2, D1/D0, △α, and △f are positively correlated with the decrease of desertification degree, while the sand content is negatively correlated with it. The single weight and multiple fractal dimensions of soil can well reflect the structural properties and changes of soil in different vegetation types of the desert-steppe transition zone, which can provide theoretical basis and technical guidance for regional ecological management and consolidation.
-
图 5 不同植被类型区土壤PSD单重分形维数
Fig. 5. Single fractal dimension of soil PSD in different vegetation types
图 6 不同植被类型区土壤PSD多重分形谱函数
Fig. 6. Multifractal spectrum function of soil PSD in different vegetation types
图 7 土壤分形维数同颗粒组成的相关关系
红色椭圆代表正相关；蓝色椭圆代表负相关；相关系数绝对值越高，椭圆越窄，系数值为1时为一条直线，系数小于0.01时为一个点；*为P < 0.05；**为P < 0.01
Fig. 7. Correlation between soil fractal dimension and soil particle composition
图 8 不同植被类型区土壤颗粒组成及分形维数的主成分分析
Fig. 8. PCA of soil particle composition and fractal dimension in different vegetation types
表 1 不同植被类型区土壤PSD多重分形参数
Table 1. Multifractal parameters of soil PSD in different vegetation types
指标 土壤深度（cm） 荒漠 草原化荒漠 荒漠草原 D0 0~20 1.000±0.000a 1.000±0.000a 1.000±0.000a 20~40 1.000±0.000a 1.000±0.000a 1.000±0.000a D1 0~20 0.991±0.006ab 0.997±0.003a 0.997±0.002a 20~40 0.983±0.006b 0.995±0.003a 0.996±0.006a D2 0~20 0.982±0.012ab 0.993±0.006a 0.994±0.005a 20~40 0.967±0.011b 0.991±0.006a 0.992±0.012a D1/D0 0~20 0.991±0.006ab 0.997±0.003a 0.997±0.002a 20~40 0.983±0.006b 0.995±0.003a 0.996±0.006a 注：不同小写字母代表两组数据间存在显著差异性，其中P < 0.05.
下载: 导出CSV
-
Dai, L., Wang, G. L., He, Y. J., 2021. The Relationship between Soil Structure and Water Characteristics Based on Fractal Theory. Earth Science, 46(9): 3410-3420 (in Chinese with English abstract). Dai, Y. J., Dong, Z., Li, H. L., et al., 2019. Effects of Checkerboard Barriers on the Distribution of Aeolian Sandy Soil Particles and Soil Organic Carbon. Geomorphology, 338: 79-87. https://doi.org/10.1016/j.geomorph.2019.04.016 Dai, Y. J., Li, J. R., Guo, J. Y., et al., 2017. Soil Particle Multi⁃Fractals and Soil Organic Carbon Distributions and Correlations under Different Shrubs in Ulan Buh Desert. Research of Environmental Sciences, 30(7): 1069-1078 (in Chinese with English abstract). Feng, R., Guo, Y. F., Zhang, X., et al., 2017. Soil Mechanical Composition of Two Main Soil Types in Aohan Banner. Agricultural Engineering, 7(6): 100-103 (in Chinese with English abstract). doi: 10.3969/j.issn.2095-1795.2017.06.029 Gao, J. L., Gao, Y., Luo, F. M., et al., 2014. Response of Surface Soil Grain Size Characteristics to Wind Erosion Desertification. Science & Technology Review, 32(25): 20-25 (in Chinese with English abstract). Guo, S. J., Yang, Z. J., Wang, D. Z., et al., 2018. The Fractural Characteristics of Soil Particle Size in the Oasis⁃Desert Transition Zone of Minqin. Soil and Water Conservation in China, (10): 53-56, 68 (in Chinese with English abstract). doi: 10.3969/j.issn.1000-0941.2018.10.017 Guo, S. W., Zhong, B., Xu, W. N., et al., 2022. Fractal Characteristics of Silt Loam Soil Particle Size in Different Land Use Types: A Case Study of Xialao River Small Watershed in Western Hubei. Science of Soil and Water Conservation, 20(1): 25-32 (in Chinese with English abstract). Han, L. W., Srocke, F., Masek, O., et al., 2020. A Graphical⁃User⁃Interface Application for Multifractal Analysis of Soil and Plant Structures. Computers and Electronics in Agriculture, 174: 105454. https://doi.org/10.1016/j.compag.2020.105454 He, Y., 2020. Study on Soil Quality and Soil Erosion Characteristics in Middle⁃Wertern Qilian Mountains (Dissertation). Lanzhou University, Lanzhou, 29-33 (in Chinese with English abstract). Hu, Y. F., Liu, J. Y., Zhuang, D. F., et al., 2015. Fractal Dimension of Soil Particle Size Distribution under Different Land Use/Land Coverage. Acta Pedologica Sinica, 42(2): 336-339 (in Chinese with English abstract). Jiang, J. Y., Liu, R. T., Zhang, A. N., 2021. Comparative Analysis of Soil Fractal Dimension and Soil Physical and Chemical Properties between Caragana Korshinskii Shrub Plantations in Arid and Semi⁃Arid Desert Steppe. Research of Soil and Water Conservation, 28(4): 54-61, 69 (in Chinese with English abstract). Kozak, E., Sokołowska, Z., Stępniewski, W., et al., 1996. A Modified Number⁃Based Method for Estimating Fragmentation Fractal Dimensions of Soils. Soil Science Society of America Journal, 60(5): 1291-1297. https://doi.org/10.2136/sssaj1996.03615995006000050002x Lan, L. Y., Ma, L. L., Guo, X. M., et al., 2022. Soil Particle Distribution and Fractal Characteristics of Different Grassland Types in Southern Jiangxi. Acta Agriculturae Universitatis Jiangxiensis, 44(1): 222-232 (in Chinese with English abstract). Li, G. Q., Zhao, P. P., Shao, W. S., et al., 2018. Effects of Fencing on Soil Particle Size Fractal Dimension and the Physicochemical Properties of Agropyron Mongolicum Community in Desert Steppe. Acta Agrestia Sinica, 26(3): 551-558 (in Chinese with English abstract). Li, K., Ni, R. Q., Lv, C. F., et al., 2022. The Effect of Robinia Pseudoacacia Expansion on the Soil Particle Size Distribution on Mount Tai, China. CATENA, 208: 105774. https://doi.org/10.1016/j.catena.2021.105774 Li, K., Yang, H. X., Han, X., et al., 2018. Fractal Features of Soil Particle Size Distributions and Their Potential as an Indicator of Robinia Pseudoacacia Invasion1. Scientific Reports, 8: 7075. https://doi.org/10.1038/s41598⁃018⁃25543⁃0 Liu, H. M., Lü, S. J., Ren, Q. N., et al., 2021. The Study on Particles Sizes and Spatial Distribution of Sandy Soil under Haloxylon ammodendron Forest in Badain Jaran Desert. Acta Agrestia Sinica, 29(6): 1249-1256 (in Chinese with English abstract). Ma, H. Y., Yong, Y. M., Liu, Z. S., 2012. Comprehensive Evaluation of Returning Cropland to Forest and Grassland in the Arid and Semi⁃Arid Region: A Case Study of Yuzhong County. Pratacultural Science, 29(9): 1359-1367 (in Chinese with English abstract). Qi, F., Zhang, R. H., Liu, X., et al., 2018. Soil Particle Size Distribution Characteristics of Different Land⁃Use Types in the Funiu Mountainous Region. Soil and Tillage Research, 184: 45-51. https://doi.org/10.1016/j.still.2018.06.011 Qi, Y. B., Chang, Q. R., Hui, Y. H., 2007. Fractal Features of Soil Particles in Desertification Reversing Process by Artificial Vegetation, Acta Pedologica Sinica, 44(3): 566-570 (in Chinese with English abstract). doi: 10.3321/j.issn:0564-3929.2007.03.027 Wan, Q., Wang, J., Wang, X. T., et al., 2022. Effects of Different Meadow Use Types on the Fractal Characteristics of Soil Particle in the Qinghai⁃Tibet Plateau. Acta Ecologica Sinica, 42(5): 1716-1726 (in Chinese with English abstract). Wang, D., Fu, B. J., Cheng, L. D., et al., 2007. Fractal Analysis on Soil Particle Size Distribution Sunder Different Land⁃Use Types: A Case Study in the Loess Hilly Areas of the Loess Plateau, China. Acta Ecologica Sinica, 27(7): 3081-3089 (in Chinese with English abstract). doi: 10.3321/j.issn:1000-0933.2007.07.050 Wang, X. D., Liu, S. Z., Liu, G. C., 2005. Fractal Characteristics of Soil under Different Land⁃Use Patterns in the Arid and Semi⁃Arid Region of the Western Tibet Plateau, China. Wuhan University Journal of Natural Sciences, 10(4): 785-790. https://doi.org/10.1007/BF02830395 Wei, C. Y., Li, C. A., Kang, C. G., et al., 2015. Grain⁃Size Characteristics and Genesis of the Huangshan Loess in Songnen Plain Area. Earth Science, 40(12): 1945-1954 (in Chinese with English abstract). Wu, C. C., Wang, S. J., 2021. Sensitivity Evaluation of Soil Erosion in Lanzhou Section of the Yellow River Basin. Science Technology and Engineering, 21(29): 12390-12397 (in Chinese with English abstract). doi: 10.3969/j.issn.1671-1815.2021.29.006 Xu, J. H., 2002. Mathematical Methods in Contemporary Geography. Higher Education Press, Beijing (in Chinese). Yang, Z. Q., Qing, F. C., Li, L., et al., 2021. Relationship Between Soil Particle Multifractals and Water Holding Capacity Under Different Erosion Degrees in Feldspathic Sandstone Region. Soils, 53(3): 620-627(in Chinese with English abstract). Yue, P., Zhang, Q., Zhao, W., et al., 2015. Influence of Environmental Factors on Land⁃Surface Water and Heat Exchange During Dry and Wet Periods in the Growing Season of Semiarid Grassland on the Loess Plateau. Science China (Series D), 45(8): 1229-1242 (in Chinese with English abstract). Zhang, A. H., Ding, J. L., Wang, J. Z., et al., 2019. Fractal and Multifractal Analysis on Saline Soil Particle Size Distribution in Arid Oasis. Arid Zone Research, 36(2): 314-322 (in Chinese with English abstract). Zhao, W. Z., Liu, Z. M., Cheng, G. D., 2002. Fractal Dimension of Soil for Sand Desertification, Acta Pedologica Sinica, 39(6): 877-881 (in Chinese with English abstract). doi: 10.3321/j.issn:0564-3929.2002.06.014 戴磊, 王贵玲, 何雨江, 2021. 基于分形理论研究土壤结构及其水分特征关系. 地球科学, 46(9): 3410-3420. doi: 10.3799/dqkx.2020.345 代豫杰, 李锦荣, 郭建英, 等, 2017. 乌兰布和沙漠不同灌丛土壤颗粒多重分形特征及其与有机碳分布的关系. 环境科学研究, 30(7): 1069-1078. https://www.cnki.com.cn/Article/CJFDTOTAL-HJKX201707010.htm 冯瑞, 郭月峰, 张霞, 等, 2017. 敖汉旗两种主要土壤类型的土壤机械组成. 农业工程, 7(6): 100-103. https://www.cnki.com.cn/Article/CJFDTOTAL-NYGE201706042.htm 高君亮, 高永, 罗凤敏, 等, 2014. 表土粒度特征对风蚀荒漠化的响应. 科技导报, 32(25): 20-25. doi: 10.3981/j.issn.1000-7857.2014.25.002 郭树江, 杨自辉, 王多泽, 等, 2018. 民勤绿洲‒荒漠过渡带土壤粒径分形特征研究. 中国水土保持, (10): 53-56, 68. doi: 10.3969/j.issn.1000-0941.2018.10.017 郭士维, 钟斌, 许文年, 等, 2022. 不同土地利用方式下粉壤土粒径分形特征: 以鄂西典型小流域下牢溪为例. 中国水土保持科学, 20(1): 25-32. https://www.cnki.com.cn/Article/CJFDTOTAL-STBC202201004.htm 贺燕, 2020. 祁连山区中西部土壤质量及侵蚀特征研究(硕士学位论文). 兰州: 兰州大学, 29-33. 胡云锋, 刘纪远, 庄大方, 等, 2005. 不同土地利用/土地覆盖下土壤粒径分布的分维特征. 土壤学报, 42(2): 336-339. https://www.cnki.com.cn/Article/CJFDTOTAL-TRXB200502024.htm 蒋嘉瑜, 刘任涛, 张安宁, 2021. 干旱与半干旱荒漠草原区柠条灌丛土壤分形维数与理化性质对比分析. 水土保持研究, 28(4): 54-61, 69. https://www.cnki.com.cn/Article/CJFDTOTAL-STBY202104009.htm 兰龙焱, 马丽丽, 郭晓敏, 等, 2022. 赣南不同草地类型区土壤粒径分布及分形特征. 江西农业大学学报, 44(1): 222-232. https://www.cnki.com.cn/Article/CJFDTOTAL-JXND202201024.htm 李国旗, 赵盼盼, 邵文山, 等, 2018. 封育对荒漠草原沙芦草群落土壤粒径分形维数及理化性质的影响. 草地学报, 26(3): 551-558. https://www.cnki.com.cn/Article/CJFDTOTAL-CDXU201803005.htm 刘红梅, 吕世杰, 任倩楠, 等, 2021. 巴丹吉林沙漠梭梭林下沙质土壤的粒径变化和空间分布特征研究. 草地学报, 29(6): 1249-1256. https://www.cnki.com.cn/Article/CJFDTOTAL-CDXU202106016.htm 马海芸, 雍雅明, 刘宗盛, 2012. 干旱半干旱区退耕还林还草工程效益综合评价: 以榆中县为例. 草业科学, 29(9): 1359-1367. https://www.cnki.com.cn/Article/CJFDTOTAL-CYKX201209008.htm 齐雁冰, 常庆瑞, 惠泱河, 2007. 人工植被恢复荒漠化逆转过程中土壤颗粒分形特征. 土壤学报, 44(3): 566-570. https://www.cnki.com.cn/Article/CJFDTOTAL-TRXB200703026.htm 宛倩, 王杰, 王向涛, 等, 2022. 青藏高原不同草地利用方式对土壤粒径分形特征的影响. 生态学报, 42(5): 1716-1726. https://www.cnki.com.cn/Article/CJFDTOTAL-STXB202205005.htm 王德, 傅伯杰, 陈利顶, 等, 2007. 不同土地利用类型下土壤粒径分形分析: 以黄土丘陵沟壑区为例. 生态学报, 27(7): 3081-3089. https://www.cnki.com.cn/Article/CJFDTOTAL-STXB200707052.htm 魏传义, 李长安, 康春国, 等, 2015. 哈尔滨黄山黄土粒度特征及其对成因的指示. 地球科学, 40(12): 1945-1954. doi: 10.3799/dqkx.2015.175 武翠翠, 王世杰, 2021. 黄河流域兰州段土壤侵蚀敏感性评价. 科学技术与工程, 21(29): 12390-12397. https://www.cnki.com.cn/Article/CJFDTOTAL-KXJS202129006.htm 徐建华, 2002. 现代地理学中的数学方法. 北京: 高等教育出版社. 杨振奇, 秦富仓, 李龙, 等, 2021. 砒砂岩区不同侵蚀程度表土多重分形特征与持水特性关系. 土壤, 53(3): 640-647. https://www.cnki.com.cn/Article/CJFDTOTAL-TURA202103023.htm 岳平, 张强, 赵文, 等, 2015. 黄土高原半干旱草地生长季干湿时段环境因子对陆面水、热交换的影响. 中国科学(D辑), 45(8): 1229-1242. https://www.cnki.com.cn/Article/CJFDTOTAL-JDXK201508012.htm 张桉赫, 丁建丽, 王敬哲, 等, 2019. 干旱区绿洲盐渍土粒径分布单重分形和多重分形特征. 干旱区研究, 36(2): 314-322. https://www.cnki.com.cn/Article/CJFDTOTAL-GHQJ201902006.htm 赵文智, 刘志民, 程国栋, 2002. 土地沙质荒漠化过程的土壤分形特征. 土壤学报, 39(6): 877-881. https://www.cnki.com.cn/Article/CJFDTOTAL-TRXB200206013.htm -
